Washing Machine
User Manual
WDW 85120 B3
EN

Please read this user manual first!
Dear Customer,
Thank you for choosing a Beko product. We hope that you get the best results from
your product which has been manufactured with high quality and state-of-the-art
technology.Therefore,please readthisentire usermanual andall otheraccompanying
documents carefully before using the product and keep it as a reference for future
use. If you handover the product to someone else, give the user manual as well.
Follow all warnings and information in the user manual.
Throughout this user manual the following symbols are used:
B
DANGER!
Warning for electric shock.
DANGER!
Product weight warning
A
CAUTION
• Warning for hazardous situations with regard to life
and property.
A
PRECAUTION
• Precautionsthatneedtobetaken.
This product was manufactured using the latest technology in environmentally friendly conditions.

C
INFORMATION
• Importantinformationorusefulhintsaboutusage.
• Readusermanual.
• Packagingmaterialsoftheproductaremanufactured
from recyclable materials in accordance with
regulations.
• Do not dispose of the Packaging materials together
withthedomesticorotherwastes.Takethemtothe
packagingmaterialcollectionpointsdesignatedbythe
localauthorities.
• AllergyUK,isthebrandofBritishAllergyAssociation.
Theirmainendorsementisthe‚SealofApproval‘.When
you see a product with this logo on it, you have the
reassurancetheproducthasbeenscientificallytested
toproveitisefficientatreducing/removingallergens
fromtheenvironmentofallergyandasthmasufferers
or the products have significantly reduced allergen/
chemicalcontent.
“The wool wash cycle of this machine has been approved by
The Woolmark Company for the washing of machine washable
wool products provided that the products are washed according
to the instructions on the garment label and those issued by the
manufacturer of this washing machine. M1325 “
“In UK, Eire, Hong Kong and India the Woolmark trade mark is a
Certification trade mark.”

4 / EN Washer-Dryer / User’s Manual
TABLE OF CONTENTS
1 Important instructions for safety and environment 7
1.1 General safety.....................................................................................................................................7
1.1.1 Electrcal safety .........................................................................................................................................7
1.1.2 Product safety ............................................................................................................................................8
1.1.3 Warnngs for dryng..................................................................................................................................10
1.2 Intended use........................................................................................................................................13
1.3 Children's safety.................................................................................................................................13
1.4 Compliance with WEEE Directive and disposing of the waste product ...................14
1.5 Package information........................................................................................................................14
2 Your washer-dryer 15
2.1 Overview................................................................................................................................................15
2.2 Package contents..............................................................................................................................16
2.3 Technical specifications.................................................................................................................17
3 Installation 18
3.1 Appropriate installation location................................................................................................18
3.2 Removing packaging reinforcement........................................................................................19
3.3 Removing the transit bolts...........................................................................................................19
3.4 Connecting water supply..............................................................................................................20
3.5 Connecting to the drain .................................................................................................................21
3.6 Adjusting the feet.............................................................................................................................22
3.7 Electrical connection.......................................................................................................................22
3.8 Transportation of the product....................................................................................................23
4Preparation 24
4.1 Sorting the laundry ..........................................................................................................................25
4.2 Preparing laundry for washing...................................................................................................25
4.3 Tips for energy saving ....................................................................................................................26
4.4 Initial use ..............................................................................................................................................26
4.5 Correct load capacity.......................................................................................................................27
4.6 Loading the laundry ........................................................................................................................27
4.7 Using detergent and softener ....................................................................................................28
4.7.1 Detergent drawer.....................................................................................................................................28
4.7.2 Detergent, softener and other cleanng agents .......................................................................28
4.7.3 Choosng the detergent........................................................................................................................29
4.7.4 Adjustng the amount of detergent................................................................................................29
4.7.5 Usng softeners.........................................................................................................................................29
4.7.6 Usng lqud detergents.........................................................................................................................30
4.7.6.1 If the product contans a lqud detergent contaner................................................30
4.7.6.2 If the product does not contan a lqud detergent contaner..............................30
4.7.7 Usng gel and tablet detergent..........................................................................................................30
4.7.8 Usng laundry starch...............................................................................................................................31
4.7.9 Usng bleaches...........................................................................................................................................31

Washer-Dryer / User’s Manual 5 / EN
TABLE OF CONTENTS
4.7.10 Usng lmescale remover ....................................................................................................................31
4.8 Tips for efficient washing.............................................................................................................32
4.9 Tips for correct drying ....................................................................................................................33
5 Operating the product 34
5.1 Control panel........................................................................................................................................34
5.2 Display symbols..................................................................................................................................35
5.3 Preparing the machine...................................................................................................................35
5.4 Selecting the washing programme .........................................................................................36
5.5 Washing programmes ....................................................................................................................36
•Хлопок (Cottons) ......................................................................................................................................36
•Синтетика (Synthetcs) ......................................................................................................................... 37
•Шерсть (Woollens)................................................................................................................................... 37
•Хлопок Эко (Cottons Eco)....................................................................................................................38
•Бережная (Delcates)..............................................................................................................................38
•Ручная (Hand Wash) ...............................................................................................................................38
•Мини (Daly Express)................................................................................................................................38
•Экспресс 14’ (Super short express) ...............................................................................................39
•Рубашки (Shrts).......................................................................................................................................39
•Полоскание (Rnse) ................................................................................................................................40
•Отжим+Слив (Spn + Dran) ..............................................................................................................40
5.6 Temperature selection...................................................................................................................41
5.7 Spin speed selection........................................................................................................................42
5.7.1 If you want to spn your laundry after the Rnse Hold functon: ........................................43
5.7.2 Auxlary functon selecton for dryng...........................................................................................43
5.8 Drying programmes.........................................................................................................................44
•Синтетика сушка (Synthetcs Dryng) ...........................................................................................44
•Хлопок сушка (Cottons Dryng).........................................................................................................44
5.9 Washing and drying programmes.............................................................................................45
•5 кг стирка+сушка (5 kg Wash+Dry)..............................................................................................45
•Wash&Wear..................................................................................................................................................45
•Детские вещи стирка+сушка (BabyProtect+ Wash+Dry).................................................46
5.10 Programme and consumption table .....................................................................................47
5.11 Auxiliary function selection.......................................................................................................50
•Замачивание (Prewash)........................................................................................................................51
•Быстрая стирка (Quck Wash) ...........................................................................................................51
•Экстра полоскание (Rnse Plus).......................................................................................................51
5.12 Drying steps......................................................................................................................................52
5.12.1 Сушка для глажения (Iron Dry) ..............................................................................................52
5.12.2 Сушка для хранения в шкафу (Cupboard Dry) ...........................................................52
5.12.3 Экстра-сушка для хранения в шкафу (Extra Dry) ....................................................52
5.12.4 Tme based dryng-mnutes..............................................................................................................52
5.13 Time display ......................................................................................................................................53
5.14 End Time.............................................................................................................................................53
TABLE OF CONTENTS

6 / EN Washer-Dryer / User’s Manual
TABLE OF CONTENTS
5.15 Starting the programme..............................................................................................................54
5.16 Loading door lock............................................................................................................................54
5.17 Changing the selections after programme has started ...............................................55
5.17.1 Addng laundry after the programme has started:.................................................................55
5.17.2 Swtchng the machne to pause mode:......................................................................................55
5.17.3 Changng the programme selecton after programme has started:..............................55
5.17.4 Changng the auxlary functon, spn speed and temperature .......................................56
5.18 Child Lock............................................................................................................................................56
5.18.1 To actvate the chld lock: ...................................................................................................................56
5.18.2 To deactvate the chld lock: .............................................................................................................57
5.19 Cancelling the programme.........................................................................................................57
5.20 End of programme.........................................................................................................................58
5.21 Your machine features a "Standby Mode"...........................................................................58
6Maintenance and cleaning 59
6.1 Cleaning the detergent drawer ..................................................................................................59
6.2 Cleaning the loading door and the drum ...............................................................................59
6.3 Cleaning the body and control panel.......................................................................................60
6.4 Cleaning the water intake filters...............................................................................................60
6.5 Draining remaining water and cleaning the pump filter ................................................61
7 Troubleshooting 63

Washer-Dryer / User’s Manual 7 / EN
1 Important instructions for safety and environment
This section contains safety instructions that will help protect from risk of personal
injury or property damage. Failure to follow these instructions shall invalidate any
warranty.
1.1 General safety
A
CAUTION
• This product can be used by children at and above 8
years old and by persons whose physical, sensory or
mental capabilities were not fully developed or who
lack experience and knowledge provided that they
are supervised or trained on the safe usage of the
product and the risks it brings out. Children should not
play with the device. Cleaning and maintenance works
should not be performed by children unless they are
supervised by someone. Children under the age of 3
should be kept away unless continuously supervised.
A
PRECAUTION
• Never place the product on a carpet-covered floor.
Otherwise,lackofairflowbeneaththemachinewillcause
electricalpartstooverheat.Thiswillcauseproblemswith
yourproduct.
C
INFORMATION
• Always have the installation procedures carried out
by the competent persons. Manufacturer shall not be
heldliablefordamagesthatmayarisefromprocedures
carriedoutbyunauthorisedpersons.
1.1.1 Electrcal safety
B
DANGER!
If the product has a failure, it should not be operated
unless it is repaired by the Authorised Service
Agent. There is the risk of electric shock!
Never wash the product by spreading or pouring
water onto it! There is the risk of electric shock!

8 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment
A
CAUTION
• If the power cable is damaged, it must be replaced by
the manufacturer, after sales service or a similarly
qualified person (preferably an electrician) or
someone designated by the importer in order to avoid
possible risks.
A
PRECAUTION
• Unplugtheproductwhenitisnotinuse.
• Never touchtheplugwithwethands!Neverunplugby
pullingonthecable,alwaysunplugbyholdingtheplug.
• Product should be unplugged during installation,
maintenance,cleaningandrepairprocedures.
• Donotmakeconnectionsviaextensioncablesormulti-
plugs.
C
INFORMATION
• Thisproductisdesignedtoresumeoperatingintheevent
ofpoweringonafterapowerinterruption.Ifyouwishto
canceltheprogramme,see"Cancellingtheprogramme"
section.
1.1.2 Product safety
A
DANGER!
Never open the loading door or remove the filter
while there is still water in the drum. Otherwise,
risk of flooding and injury from hot water will occur.
A
CAUTION
• The water supply and draining hoses must be securely
fastened and remain undamaged. Otherwise, there is
the risk of water leakage.

Washer-Dryer / User’s Manual 9 / EN
Important instructions for safety and environment
C
INFORMATION
• Donotforceopenthelockedloadingdoor.Doorcanbe
opened a few minutes after the washing cycle ends. If
the machine has not cooled enough at the end of the
programme,loadingdoorcannotbeopened.Donotforce
theloadingdoortoopen.Itmustbelefttocoolitself.The
loadingdoorandthelockmechanismmaygetdamaged.
• Intheinstallationlocationofthisproduct,theremustnot
bealockable,slidingorhingeddoorthatwillrestrictthe
fullopeningoftheloadingdoor.
• Follow the instructions on the textile tags and on the
detergentpackage.
• Useonlydetergents,softenersandsupplementssuitable
forwashingmachines.
• Do not install or leave this product in places where it
mightbeexposedtooutdoorconditions.
• Controlsmustnotbetamperedwith.

10 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment
1.1.3 Warnngs for dryng
DANGER!
Laundry that is previously washed, cleaned, soiled
or stained with petrol / gasoline, dry cleaning
solvents or other flammable or explosive
substances must not be dried in the machine as
they give out flammable or explosive steam. It may
cause fire risk.
Laundry stained with Liquid cooking oil, acetone,
alcohol, petrol, kerosene, spot removers,
turpentine, waxes and wax removers must be
washed in hot water with plenty of detergent
before drying. It may cause fire risk.
Foam rubber (latex foam), shower caps, waterproof
textiles, clothes or pillows with rubber support or
rubber foam pads must not be dried with drying
function. It may cause fire risk.
If you use washing ball, detergent scale, laundry
clothing cages and balls in your machine, they can
melt during drying. Do not use these products if
drying option will be selected. It may cause fire
risk.
When you use industrial chemicals for cleaning, do
not use drying function. It may cause fire risk.
A
DANGER!
Do not touch loading door glass with bare hands
after drying. There is the risk of getting burnt.
In order to maintain laundry in a temperature that
will prevent them from getting damaged, a cooling
step is performed as a final step. You may be
exposed to hot steam if you open the door before
cooling is complete. There is the risk of scalding.
If the drying programmes are interrupted (as a result
of programme cancellation or power failure),
laundry in the machine can be hot. Be careful.

Washer-Dryer / User’s Manual 11 / EN
Important instructions for safety and environment
A
CAUTION
• Do not stop the machine before drying programme is
completed. If you have to stop the machine, remove
all laundry and lay them in a suitable place to let them
cool down.
• Your product is suitable to operate in ambient
temperatures between 0°C and +35°C.
• Ambient temperatures between 15°C and +25°C are
ideal temperatures for your product.
• Do not let pets enter the product. Check inside the
product before using.
• Do not overload the machine for drying. Observe the
maximum load levels specified for drying.

12 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment
A
PRECAUTION
• Do not dry leather laundry or laundry that contains
leather (such as leather jeans label). The colour from
Leatherpartscanrunintoothertextiles.
• In failures that cannot be repaired using information
giveninsafetyinstructions,turnoffthemachine,unplug
thepowercableandcalltheAuthorisedServiceAgent.
• Youcanjustwashlaundry,justdrylaundryorwashand
drylaundryinyourwasher-dryer.Machinemustnot be
usedonlytodrywetloadsforalongtime.Whenmachine
isusedonlyfordrying,itmustbeoperatedemptywithout
loadinglaundryinashort washprogrammeafterevery
15operation.
• Checkallclothesbeforeloadingthem intothemachine
andensurethattheydonothaveobjectssuchaslighters,
coins,metalpieces,needlesinthepocketsorinside.
• Underwearwithmetalsupportsmustnotbedriedinthe
machine. Metal supports might come off during drying
and cause damage in the machine. Place in a bag or
pillowcase.
• Do not dry large laundry such as tulle curtain, curtain,
bedding,blanket,ruginthemachine.Yourlaundrymight
getdamaged.
C
INFORMATION
• Donotdryunwashedlaundryinthemachine.
• Do not use fabric softeners or static preventers in the
machineunlessrecommendedbythemanufacturer.
• Products such as fabric softeners must be used in
accordancewithmanufacturer'sinstructions.
• Donotdrysensitiveclothessuchassilk,wool,etc.inthe
machine.Otherwise,woolclothesmaygetshrunkenand
othersensitiveclothesmaygetdamaged.
• Checksymbolsonthegarmenttagbeforewashingand
drying.

Washer-Dryer / User’s Manual 13 / EN
Important instructions for safety and environment
1.2 Intended use
C
INFORMATION
• Thisproducthasbeendesignedfordomesticuse.Itisnot
suitableforcommercialuseanditmustnotbeusedout
ofitsintendeduse.
• Theproductmustonlybeusedforwashing,rinsingand
dryingoftextileproductsthataremarkedaccordingly.
• Themanufacturerwaivesanyresponsibilityarisenfrom
incorrectusageortransportation.
• Theservicelife ofyourproductis 10years.Duringthis
period,originalspareparts will beavailabletooperate
theproductproperly.
1.3 Children's safety
A
CAUTION
• Children below the age of 3 must be kept away from
the machine unless they are continuously supervised.
• Packaging materials are dangerous to children. Keep
packaging materials in a safe place away from reach
of the children.
• Electrical products are dangerous for the children.
Keep children away from the product when it is in use.
Do not allow them to play with the product. Use child
lock to prevent children from intervening with the
product.
• Do not forget to close the loading door when leaving
the room where the product is located.
• Store all detergents and additives in a safe place away
from the reach of the children by closing the cover
of the detergent container or sealing the detergent
package.

14 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment
1.4 Compliance with WEEE Directive and
disposing of the waste product
•Thisproductdoesnotcontainharmfulandforbiddenmaterialsdescribedinthe
"Regulation on the Control of the Waste Electrical and Electronic Equipment". It
complies with the WEEE Directive.
This product has been manufactured with high
quality parts and materials which can be reused
and are suitable for recycling. Therefore, do not
dispose the product with normal domestic waste
at the end of its service life. Take it to a collection
point for the recycling of electrical and electronic
equipment. Please consult your local authorities
to learn the nearest collection point. Help protect
the environment and natural resources by
recycling used products. For children's safety, cut
the power cable and break the locking mechanism
of the loading door so that it will be non-functional
before disposing of the product.
Compliance with RoHS Directive:
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
1.5 Package information
Packaging materials of the product are manufactured from recyclable materials
in accordance with our National Environment Regulations. Do not dispose of the
packaging with normal domestic waste. Take them to the packaging material
collection points designated by the local authorities.

Washer-Dryer / User’s Manual 15 / EN
2 Your washer-dryer
2.1 Overview
1
2
3
4
5
6
7
8
1- Power cable
2- Top panel
3- Control panel
4- Water discharge hose
5- Loading door
6- Filter cover
7- Adjustable feet
8- Detergent drawer

16 / EN Washer-Dryer / User’s Manual
Your washer-dryer
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
Liquid detergent container (*)
User manual
Plastic plug group
NOTE
•Figuresinthismanualareschematicandmaynotmatchtheproductexactly.
(*) This may be supplied with the machine depending on the model of your product.
2.2 Package contents

Washer-Dryer / User’s Manual 17 / EN
Your washer-dryer
2.3 Technical specifications
Complying Commission Delegated Regulation (EU) No.96/60/EC/1996
Supplier name or trademark Beko
Model name WDW 85120 B3
Washer Dryer Energy efficiency class (1) B
Washing Energy efficiency class (1) A
(Washing & Drying) Energy Consumption - full load per cycle (kWh) 6.48
Washing Energy Consumption - full load per cycle (kWh) 0.76
Annual (Washing & Drying) Energy Consumption (kWh) (2) 1296
Annual Washing Energy Consumption (kWh) (2) 172
Water Consumption (Washing & Drying) full load per cycle- (l) 87
Water Consumption (Washing) full load per cycle (l) 47
Annual Water Consumption (Washing & Drying)- (l) (3) 17400
Annual Water Consumption (Washing) (l) (3) 9400
Spin-drying efficiency class (1) B
Maximum spin speed (rpm) 1200
Airborne acoustical noise emissions washing/spinning/drying (dB) 57/74/64
Built-in No
Rated capacity - Washing (kg) 8
Rated capacity - Drying (kg) 5
Height (cm) 84
Width (cm) 60
Depth (cm) 54
Net weight (±4 kg.) 66
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
VDE Main model code 9620
(1) Scale from A (Highest Efficiency) to G (Lowest Efficiency)
(2) Energy Consumption based on 200 standard washing cycles - full loads washing (and drying). Actual energy consumption will
depend on how the appliance is used.
(3) Water consumption based on 200 standard washing cycles - full loads washing (and drying). Actual energy consumption will
depend on how the appliance is used.
Technical specifications may be changed without prior notice to improve the quality of the product.

18 / EN Washer-Dryer / User’s Manual
3 Installation
To make the product ready for use, review the information in the user manual and
make sure that the electricity, tap water supply and water drainage systems are
appropriate before calling the Authorised Service Agent. If they are not, call a qualified
technician and plumber to have any necessary arrangements carried out.
B
DANGER!
Make sure that the installation and electrical
connections of the product are performed by
competent persons. Manufacturer shall not be held
liable for damages that may arise from procedures
carried out by unauthorised persons.
DANGER!
Your product is too heavy for one person to carry.
A
CAUTION
• Prior to installation, visually check if the product
has any defects on it. If so, do not have it installed.
Damaged products cause risks for your safety.
A
PRECAUTION
• Preparationofthelocationandelectrical,tapwaterand
waste water installations at the place of installation is
undercustomer'sresponsibility.
• Make sure that the water inlet and discharge hoses as
wellasthepowercablearenotfolded,pinchedorcrushed
whilepushingtheproductintoitsplaceafterinstallation
orcleaningprocedures.
3.1 Appropriate installation location
•Placetheproductonasolidandlevelfloor.Donotplaceitontoacarpetwithhigh
pile or other similar surfaces.
•Donotplacetheproductclosetotheedgeifthefloorcontainssteps.Donotalso
place the product on a platform.
•Donotplacetheproductonthepowercable.
•Do notinstall the product inenvironments where the temperaturefallsbelow0
ºC.(See. Warnings for Drying)
•Placetheproductatleast1,5cmawayfromtheedgesofotherfurniture.
In the area where this product is installed, there must not be a lockable, sliding or
hinged door that will restrict the full opening of loading door.

Washer-Dryer / User’s Manual 19 / EN
Installation
Operate the product in a well ventilated and dust free environment.
3.2 Removing packaging reinforcement
Tilt the machine backwards to remove the packaging reinforcement. Remove the
packaging reinforcement attached to the ribbon.
DANGER!
Your product is heavy. Remove packaging
reinforcement as displayed in the figure.
Be careful not to get your hand caught under the
machine during this procedure.
3.3 Removing the transit bolts
A
PRECAUTION
• Do not remove the transit bolts before removing the
packagingreinforcement.
• Removethe transitboltsbeforeoperatingthe washing
machine!Otherwise,theproductwillgetdamaged.
1 2 3

1 Use a tool to loosen all bolts until they rotate freely. (C)
2 Remove the transit bolts by turning them slightly.
3 Attach the plastic covers supplied in the user manual bag into the holes on the rear
panel. (P)

20 / EN Washer-Dryer / User’s Manual
Installation
C
INFORMATION
• Keepthetransitboltsinasafeplacetoreusewhenthe
productneedstobemovedagaininthefuture.
• Nevermovetheproductwithoutthetransitboltsproperly
fixedinplace!
3.4 Connecting water supply
C
INFORMATION
• Thewatersupplypressurerequiredtoruntheproductis
between1to10bars(0.1–1MPa).Itisnecessarytohave
10–80litersofwaterflowingfromthefullyopentapin
oneminutetohaveyourproductrunsmoothly.Attacha
pressurereducingvalveifwaterpressureishigher.
A
CAUTION
• Models with a single water inlet should not be
connected to the hot water tap. In such a case the
laundry will get damaged or the product will switch to
protection mode and will not operate.
• Do not use old or used water inlet hoses on the new
product. It may cause stains on your laundry.
1 2 3

1 Connect the special hose supplied with the product to the water inlet on the
product.
