BEL MS64-F User manual

Installation and User Guide
MADI-SWITCH
8x1 MADI SOURCE SELECTOR
MS64-F, MS64-C, MS64-FC
SELPSU
MADI-SWITCH
OUT IN OUT IN OUT
IN OUT IN OUT IN OUT IN OUT IN OUT IN
SIG SEL SIG SEL
SIG SEL SIG SEL SIG SEL SIG SEL SIG SEL SIG SEL
MS64-C
SWITCHMADI
D
I
G
I
T
A
L
G
R
O
U
P

MADI-SWITCH User Manual v1.1
2
Bel Digital Audio Limited
This document confirms that products bearing the CE
label meet all the requirements in the EMC directive
2004/108/EC and LV directive 2006/95/EC laid
down by the Member States Council for adjustment
of legal requirements. Furthermore the products
comply with the rules and regulations from 30
August 1995 referring to the electromagnetic
compatibility of devices. Bel Digital Audio
MADI-SWITCH units bearing the CE label comply with
the following harmonised or national standards:
EMC:
BS EN 55103-1 :2009
BS EN 55103-2 :2009
Safety:
BS EN 60950-1: 2006 (ed. 2) + A1:2010
Insulation:
Class1
Instructions for Disposal of WEEE by Users
in the European Union
The symbol shown here is on the product
or on its packaging, which indicates that
this product must not be disposed of with
other waste. Instead, it is the user’s responsibility to
dispose of their waste equipment by handing it over
to a designated collection point for recycling of waste
electrical and electronic equipment.
The separate collection and recycling of your
waste equipment at the time of disposal will help
to conserve natural resources and ensure that it is
recycled in a manner that protects human health and
the environment. For more information about where
you can drop off your waste equipment for recycling,
please contact your local city office, your household
waste disposal service or where you purchased the
product.
User’s Notice and disclaimer:
No part of this manual may be reproduced,
transmitted, transcribed, stored in a database
system or translated without the express written
permission of Bel Digital Audio Ltd. Documentation
kept by the end user for back-up purposes is excluded
from the above.
All products and corporate names mentioned in this
manual may be registered trademarks or copyrights
of their respective companies. They are used here
for indicative purposes only.
The information contained in this manual has been
carefully checked for accuracy; however no guarantee
is given with respect to its correctness. Bel Digital
Audio Ltd. accepts no responsibility or liability for
any errors or inaccuracies that may appear in this
manual or the products and software described in
it. Specifications and information contained in this
manual are subject to change at any time without
notice.
© 2014 Bel Digital Audio Ltd. All rights reserved.
This appliance has a serial number located on the
rear panel. Please record the serial number here for
your records.
Model Number…………MADI-SWITCH
Serial Number………………………………………...
Reference To Statement Of Conformity

MADI-SWITCH User Manual v1.1
3
Bel Digital Audio Limited
Reference To Statement Of Conformity .............2
Important Safety Instructions ..........................4
Important Safety Precautions .......................... 5
Important Safety Information........................... 5
Introduction...................................................6
What’s In The Box ......................................... 6
MADI-SWITCH Main Features ......................... 6
Front Panel Description.................................. 7
Rear Panel Description .................................. 8
Installation ....................................................9
Hardware Considerations ............................... 9
Power Supply Considerations .......................... 9
Fuses And Ratings ...................................... 9
Unit Connections........................................... 9
Operation ....................................................10
Connection ................................................. 10
Source Selection ......................................... 10
Example Connection Diagram.........................11
Technical Specifications.................................12
Contents

MADI-SWITCH User Manual v1.1
4
Bel Digital Audio Limited
1. Read these instructions
2. Keep these instructions
3. Heed all warnings
4. Follow all instructions
5. Do not use this apparatus near water
6. Do not expose this apparatus to rain or moisture.
7. Clean only with a dry cloth
8. Do not block any ventilation openings. Install with
accordance with the manufacturer’s instructions.
9. No naked flames, such as lighted candles, should
be placed on the apparatus.
10.Do not install near any heat sources such as
radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce
heat.
11.There are no user-adjustments, or user-
servicable items, inside this apparatus. Do not
remove the covers of this apparatus; doing so
will invalidate your warranty.
12.Adjustments or alterations to this apparatus
may affect the performance such that safety
and/or international compliance standards may
no longer be met.
13. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally or has been dropped.
Caution
14.Hazardous voltages may be present inside this
apparatus.
15.Do not operate this apparatus with the covers
removed.
16.To reduce the risk of electric shock, do not
perform any servicing other than that contained
in these Installation Instructions unless you are
qualified to do so. Refer all servicing to qualified
service personnel and ensure that all power
cords are disconnected when servicing this
apparatus.
17.Only use attachments/accessories specified by
the manufacturer.
Power Safety
18.This apparatus is fitted with a universal power
supply, approved and certified for operation in
this apparatus. There are no user-replaceable
fuses.
19.An external over-current protection device is
required to protect the wiring to this apparatus.
This protection device must be installed according
to current wiring regulations. In certain countries
this function is supplied by use of a fused plug.
20.If an extension power cable or adaptor is used,
ensure that the total power rating of the power
cable and/or adaptor is not exceeded.
21.An external disconnect device is required for this
apparatus; a detachable power cord is a suitable
disconnect device.
22.The apparatus should be located close enough
to an AC outlet so that you can easily grasp the
power cord plug at any time.
23.This apparatus is a Class I construction and shall
be connected to an AC outlet with a protective
grounding connection.
24.Protect the power cord from being walked on
or pinched, particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
25.Unplug this apparatus during lightning storms or
when unused for long periods of time.
26.All power cords must be disconnected to isolate
this apparatus completely.
27.Caution: To reduce the risk of electric shock, plug
each power supply cord into separate branch
circuits employing separate service grounds
28.This equipment is not supplied with a detachable
power cord. The device should be connected to
a power supply only of the type described in the
Installation Guide or as marked on the device.
The power cord must be earthed and precautions
should be made so that the grounding is not
defeated. A mains cord, fitted with an IEC 60320
C13 type socket, appropriate sized conductors
and plug to suit local electrical requirements.
29.The power supply cord (i.e. conductor, coupler
(IEC60320 C13) and plug combination) must be
suitably rated for apparatus and the country of
use (meeting local electrical requirements). A
power supply cord with a rating of not less than
125% of current rating is suitable. The minimum
rating for the power supply cord at 110 / 230V
AC to be 1A.
Important Safety Instructions

MADI-SWITCH User Manual v1.1
5
Bel Digital Audio Limited
Installation
30.When installing this apparatus, either fix it into
a standard 19” rack or place the apparatus on
a secure level surface. When this apparatus is
rack mounted, fit all rack screws.
31.Ensure that no strain is placed on the cables
connecting to this apparatus. Ensure also that
such cables are not placed where they can be
stepped on, pulled or tripped over.
32.Do not operate this apparatus whilst it is covered
or boxed in any way.
Important Safety Precautions
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL
CAUTION: RISK OF ELECTRIC SHOCK. THIS
EQUIPMENT HAS MORE THAN ONE POWER CORD.
TO REDUCE THE RISKS OF ELECTRIC SHOCK
DISCONNECT BOTH POWER SUPPLY CORDS
BEFORE SERVICING
The lightning flash with arrowhead symbol, within
equilateral triangle, is intended to alert the user to
the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating instructions and maintenance
(servicing) instructions in the literature accompanying
the appliance.
Important Safety Information
This apparatus has no mains switch or other user-
operated control for disconnecting the AC mains
power. The mains plugs or the appliance couplers
(IEC sockets) are used as the disconnect devices.
Either device must remain readily operable and
accessible when the apparatus is installed for use.
This unit includes thermally resettable fuses that are
integral to the power supply circuitry, but the unit
must always be powered from a supply fitted with an
HRC type (High In-Rush Current) fuse with a rating
of 1 A.

MADI-SWITCH User Manual v1.1
6Bel Digital Audio Limited
Designed to complement the BM-A2-64MADI Audio
and Data Monitor, the MADI-SWITCH provides the
ideal routing solution when monitoring multiple MADI
streams is required.
The MADI-SWITCH is an 8x1 selector allowing
manual selection of one of eight incoming MADI
streams. The selected MADI stream is then routed
directly to the switch’s main MADI output ports - one
coaxial and one fibre (multimode as standard). Each
incomming MADI port is paired with an active front
panel mounted MADI loopthrough output. With up
to eight incoming MADI streams the MADI-SWITCH
enables up to 512 audio channels to be monitored
on just one MADI monitoring device; thus resulting
in significant saving in real estate.
Three versions are available:
MS64-F: Fibre switch
MS64-C: Coaxial switch
MS64-FC: 4 x Fibre and 4 x Coaxial switch
The front panel provides eight MADI inputs, with
active loop-through outputs for connection to
downstream devices. Input source selection is made
using the front panel momentary toggle switch.
Indication of the selected MADI input is provided by
the SEL LED illuminating.
A SIG LED on each MADI input illuminates when an
input source is present.
A traditional scribble strip is provided to allow the
naming of incoming MADI sources to be labelled for
clarity and ease of operation.
The MADI-SWITCH is a very high quality product,
engineered for maximum reliability in professional
broadcast, live and production environments. It
requires virtually no configuration on installation, or
adjustment in normal use.
This manual covers the MADI-SWITCH’s
connections and indications. Please keep
the manual in a safe place once you have
installed the unit.
Important – Please do take the time to register your
MADI-SWITCH with Bel Digital Audio Ltd., by emailing
us the unit’s serial number and your contact details
to [email protected]. Thank you.
Environment – The MADI-SWITCH’s range of
operating temperature and relative humidity (RH)
are as follows:
Temperature: 5ºC to 40ºC
RH: Operating 20 to 80%
What’s In The Box
Unpacking
Unpack the MADI-SWITCH with care. It is always
a good idea to store all packaging (if practical), in
case you ever need to return the unit to Bel for any
reason.
The shipping carton should contain the items listed
below. Please contact your distributor immediately if
any of them are missing or damaged.
• MADI-SWITCH
• Instruction manual
• 2 x IEC connector retaining clamp
MADI-SWITCH Main Features
• 8x1 MADI source selector
• Active MADI loop-through outputs for all inputs
• Coaxial and fibre MADI outputs on rear panel
• Fast and intuitive to use
• LED status indication
• Scribble strip for naming input sources
• Compact 1U design
• Two independent PSUs with separate IEC inputs
for redundancy
Introduction

MADI-SWITCH User Manual v1.1 7 Bel Digital Audio Limited
Front Panel Description
PSU status – two bi-colour LEDs confirming
the current status of each PSU. The LEDs are green
in normal operation and red if a PSU fault condition
is detected.
SEL – a momentary toggle switch with lock
position. Used to select the MADI source to route to
the MADI outputs on the rear panel.
IN – MADI input connector. Conector
type depends on model: BNC (75 ohm) or Fibre
(multimode as standard)
OUT – Active MADI loop-through connector.
Connector type depends on model: BNC (75 ohm) or
Fibre (multimode as standard)
SIG – LED indication of active source being
connected to the MADI input connector.
SEL – LED used to indicate which MADI
source is routed to the rear panel fibre and coaxial
MADI outputs.
Scribble Strip – traditional scribble strip to
label the incoming MADI streams.
SELPSU
MADI-SWITCH
OUT IN OUT IN OUT IN OUT IN OUT IN OUT IN OUT IN OUT IN
SIG SEL SIG SEL SIG SEL SIG SEL SIG SEL SIG SEL SIG SEL SIG SEL
MS64-C
SWITCHMADI
D
I
G
I
T
A
L
G
R
O
U
P

MADI-SWITCH User Manual v1.1
8Bel Digital Audio Limited
Rear Panel Description
COAX OUT – Coaxial MADI output (BNC),
derived from the selected front panel MADI source.
FIBRE OUT – Optical fibre MADI output (SC),
derived from the selected front panel MADI source
(multimode as standard).
PSU 1 – AC input (IEC Socket)
PSU 2 – AC input (IEC Socket)
OUTOUT
COAX FIBRE
Not Used
MADI

MADI-SWITCH User Manual v1.1 9 Bel Digital Audio Limited
Hardware Considerations
The MADI-SWITCH is built in a 1U 19” enclosure. It
is intended to be permanently installed in a standard
19” equipment rack. There are ventilation grilles in
the enclosure, and care must be taken to ensure that
these are not blocked by cables or other equipment
when the unit is installed. Do not install any other
items of equipment immediately above or below to
the MADI-SWITCH; the use of 1U blanking panels is
recommended.
Power Supply Considerations
The MADI-SWITCH is fitted with two separate,
auto-ranging switch-mode power supplies (PSUs).
The operating voltage range is 100 to 240 V AC,
50/60 Hz. The internal power rails are diode-
paralleled to the two supplies, and the unit will
operate normally if only one PSU is powered or
functional. For maximum protection when using both
PSUs, the two AC inlet cables should be connected
to mains circuits which are as independent of each
other as possible.
If redundant operation is not required, only one AC
supply cable need be connected; either AC inlet may
be used.
Fuses And Ratings
Each of the MADI-SWITCH’s PSUs has an internal
resettable fuse for PSU protection. These fuses
are not accessible to the user. The unit should be
powered from a mains supply (supplies) fitted with an
external HRC-type fuse (High Inrush Current) rated
at 1 A.
Installation
Unit Connections
MADI Inputs and Outputs
MADI inputs are provided as either fibre on an SC type
connector (multimode as standard), coaxial (on BNC)
or a combination of both, depending on the model
purchased.
The characteristic impedance of the coaxial input is
75 ohms.
Active loop-through outputs are also provided for
each MADI input. These are located next to its
corresponding MADI input connector on the front
panel.
The selected MADI source is also available as both
fibre and coaxial outputs on the rear panel to simplify
the connection of further equipment, such as a BM-
A2-64MADI audio monitor.
Coaxial MADI outputs are on BNC sockets, and are
compliant with AES10id-2008. The characteristic
impedance is 75 ohms, at a nominal data rate of
125Mbps. Transmission distances up to 50 m are
generally achievable.
Fibre MADI outputs are provided on SC type
connectors. Recommended fibre types are
62.5/125 µm or 50/125 µm, multimode.
Transmission distances of at least 1000 m are
achievable.
Note: A singlemode fibre option is available, but only
at time of order.

MADI-SWITCH User Manual v1.1
10
Bel Digital Audio Limited
Connection
The MADI-SWITCH provides a very intuitive front
panel interface that allows the user to select any one
of the incoming MADI streams to feed the rear panel
outputs.
First, connect the incoming MADI sources to the
input connectors located on the front panel (whether
fibre, coax or both - depending on model purchased).
Connect the loop-through outputs so that the MADI
streams can continue to other down-stream MADI
devices.
Connect the MADI outputs on the rear panel
(note that both coaxial and fibre outputs operate
simultaneously) to your MADI monitor (or other)
device.
See “Example Connection Diagram” on page 11
for an example of how to connect the MADI-SWITCH
to a BM-A2-64MADI monitor unit.
Source Selection
Source selection is very straight forward:
The front panel mounted toggle switch (marked SEL)
allows you to scroll through the front panel MADI
ports in sequential order, enabling you to select
the one you wish to route to the rear panel MADI
outputs.
The SEL switch has a momentary action when
pushed down, which advances the port selection.
The active port is indicated by the illumination of the
SEL LED (located adjacent to each front panel port).
Also on the front panel, again located by each port,
is an LED marked SIG. This LED illuminates if the
input is connected and active at the source (for
example; the transmitter end of the fibre). It is a
useful indicator to tell you that at least the other end
of the fibre is a) plugged in and b) the transmitter is
powered.
Each MADI input on the front panel has an active
MADI loop-through output port adjacent to it. This is
active all the time the unit is powered, irrespective
of the SEL position.
Two bi-colour LEDs indicate the status of the PSUs.
Green indicates all is good, and red indicates that
one has an issue (such as not being connected to
the mains for example).
Finally, a traditional scribble strip across the front
panel allows you to write down details of each
incoming stream. You can remove the plastic cover
by sliding it left or right. This will reveal a strip of
paper on which you can write down the details of
each incoming MADI stream. Once written, replace
the clear plastic cover.
Operation

MADI-SWITCH User Manual v1.1 11 Bel Digital Audio Limited
MADI-SWITCH MS64-F
BM-A2-64MADI
COAXIAL MADI OUTPUT
OPTICAL MADI OUTPUT
MADI STREAM #1
INPUT
LOOP-THROUGH
MADI STREAM #8
INPUT
LOOP-THROUGH
MADI STREAM #2 MADI STREAM #3 MADI STREAM #4 MADI STREAM #5 MADI STREAM #6 MADI STREAM #7
Example Connection Diagram
Connection example based on the MS64-F.
(Similar principle applies to the
MS64-C and MS64-FC.)

MADI-SWITCH User Manual v1.1
12
Bel Digital Audio Limited
Technical Specifications
MADI
Input 8 x SC socket multi-mode (single-mode option available) for MS64-F
8 x BNC for MS64-C
4 x SC socket multi-mode and 4 x BNC for MS64-FC
Loop-through output 8 x SC socket multi-mode (single-mode option available) for MS64-F
8 x BNC for MS64-C
4 x SC socket multi-mode and 4 x BNC for MS64-FC
Output 1 x SC socket multi-mode
1 x BNC
Data Rate 125 Mbps ±25ppm (accepts any data format)
Sampling frequency 44.1 kHz to 384 kHz
POWER SUPPLY
Type 2 x independent switch-mode regulated, auto-ranging
Inputs 2 x 90 to 264 V AC, 50/60 Hz
Power consumption 16 W
Connectors 2 x IEC with retaining clips
PHYSICAL
Dimensions (w x d x h) 483 x 249 x 45 (mm) / 19” x 10” x 1.77” [1U]
Weight 4.5 kg / 9.92 lbs
Specifications and information contained in this manual are subject to change at any time without notice.

Bel Digital Audio Limited
3 Horwood Court
Bletchley
Milton Keynes
MK1 1RD
United Kingdom
Tel: [phone]
Email: [email protected]
URL: www.beldigital.com
