Lindy CPU Switch Smart DVI Quick start guide

© LINDY ELECTRONICS LIMITED
LINDY CPU Switch Smart DVI
Installation and Use
Part Model
32340 LINDY CPU Switch Smart DVI
CPU Switch Smart - Installation and Use
First Edition (February 2002)
Part Number 32340
© 2002 LINDY Electronics Ltd.

CPU Switch Smart DVI ENGLISH
Quick Installation and Operation Guide
QUICK INSTALLATION
Power off all your computers and connect them to the ORANGE ports on the rear
of the CPU Switch Smart DVI.
Connect your keyboard, monitor and mouse to the GREY port on the rear of the
CPU Switch Smart.
OPERATION GUIDE SUMMARY
The CPU Switch Smart's default configuration is suitable for most systems.
A computer may be selected using the front panel key, a three button mouse or a
keyboard hotkey combination. To select a computer using the mouse press and
release the left or right hand buttons whilst holding down the central button. To
select a computer using the keyboard hotkeys hold down the CTRL and ALT
keys, press and release the required port key (e.g. 1) and then release the CTRL
and ALT keys.
Safety information
For use in dry, oil free indoor environments only.
Do not attempt to service the CPU Switch Smart DVI yourself.
Follow all warnings and instructions marked on the CPU Switch Smart DVI, its
optional power adapter and its accessories.
Warning - live parts contained within optional power adapter.
No user serviceable parts within optional power adapter - do not dismantle.
Replace the optional power adapter with a manufacturer approved type only.
If you use a power extension cord with the CPU Switch Smart DVI, make sure the
total ampere rating of the devices plugged into the extension cord does not
exceed the cord’s ampere rating. Also, make sure that the total ampere rating of
all the devices plugged into the wall outlet does not exceed the wall outlet’s
ampere rating.
GB
USA

CPU Switch Smart DVI ENGLISH
Kurzanleitung
Installation & Betrieb
EIGENSCHAFTEN
Der LINDY CPU Switch SMART DVI ist für den Betrieb mit PCs mit DVI-D Monitor-
anschluss konzipiert. Der DVI-D Anschluss ist der moderne Digitalanschluss für
Flachbildschirme. Der LINDY CPU Switch SMART DVI unterstützt die analogen
Signalleitungen, wie im DVI-I Anschluss spezifiziert, NICHT.
Er unterstützt digitale Monitorauflösungen bis 1600x1200 bis 60Hz (zur Zeit ist dies die
höchste spezifizierten Auflösungen für DVI-D Single Link, Stand 03/2002) sowie DDC
Monitorerkennung.
Der LINDY CPU Switch benötigt bei Kabellängen unter 5m kein Netzteil. Werden größere
Kabellängen benötigt, so sollte ein optional erhältliches Netzteil verwendet werden; hiermit
können in den meisten Fällen auch noch Kabellängen bis 7,5m realisiert werden. Beachten
Sie bitte, dass für DVI Monitore und Kabel eine Maximallänge von 7,5m genannt wird!
Je nach Hardwarekombination können diese Distanzen im Einzelfall auch größer sein, in
Einzelfällen konnten 12m realisiert werden. Ebenfalls kann die erreichbare Auflösung von
der Kabellänge abhängen, z.B. 1280x1024 ab 5m und nur noch 1024x768 bei 10m. Dies
alles sehr stark von der verwendeten Hardware abhängig.
Der LINDY CPU Switch emuliert für alle angeschlossenen Rechner permanent Monitor,
Maus und Tastatur. Dies sorgt dafür, dass zwischen den angeschlossenen Rechnern
beliebig oft hin und her geschaltet werden kann, ohne dass die Rechner das Maus- bzw.
Tastatursignal verlieren und neu gebootet werden müssen.
KURZANLEITUNG INSTALLATION
Schalten Sie alle anzuschliessenden Computer aus und schliessen Sie sie an die
ORANGEFARBENEN Ports auf der Rückseite des CPU Switch SMART DVI an.
Der Rechneranschluss erfolgt über Standardkabel (LINDY Art.Nr.n in Klammern):
PS/2 (Maus, Tastatur): 1m (33265), 2m (33266), 3m (33267) , 5m (33268) , 10m (33270)
DVI-D (Monitor): 2m (41240), 3m (41241), 5m (41242) , 7,5m (41244) , [10m*s.o. (41243)]
Serielle PC-Mausanschlüsse (COM-Port, Sub-D-9) werden nur mit dem korrekten
Mausadpter (z.B. LINDY Art.Nr. 70058) unterstützt (nähere Angaben im ausführlichen
englischen Handbuch).
Schließen Sie Ihre Tastatur, Monitor und Maus an den GRAUEN Ports auf der Rückseite
des CPU Switch SMART an.
D

CPU Switch Smart DVI FRENCH
ZUSAMMENFASSUNG DES HANDBUCHES
Verschiedene DVI Grafikkarten müssen über die DVI Hot Plug Detect Funktion und
die DDC Monitorerkennung erst den DVI Monitor erkennen, bevor sie ein Bildsignal
an den Monitor senden (dürfen). Dies geschieht in der Regel in den ersten 5
Sekunden des Bootvorganges. Die Grafikkarte kann nur mit dem Monitor kom-
munizieren, wenn der entsprechende Computer aktuell als der Aktive selektiert ist!
Um diesen Vorgang und das Booten möglichst einfach zu gestalten, schaltet der
CPU Switch SMART DVI automatisch auf den Kanel / den Computer, der gerade
gebootet wird. Wenn mehrere Computer gebootet werden sollen, muss dies daher
der Reihe nach mit kurzer Wartezeit geschehen!
Die Voreinstellungen (Defaultkonfiguration) des CPU Switch SMART ist für die meisten
Einsatzzwecke geeignet. Der CPU Switch SMART DVI kann über die angeschlossenen
Rechner mit Strom versorgt werden. Beim Anschluss mehrerer Rechner wird die
Stromentnahme auf alle Rechner verteilt, so dass auch das Abschalten einzelner Rechner
kein Problem darstellt.
Der Computer, auf dem gearbeitet werden soll, kann auf verschiedene Arten ausgewählt
werden: entweder durch Drücken der Kanalwahltaste auf der Frontblende, durch Drücken
einer Hotkey-Tastenkombination auf der Tastatur oder durch eine 3-Tasten-Maus.
Um einen Computer per Tastatur-Hotkey auszuwählen werden die Strg und ALT Tasten
sowie die erforderliche Port-Taste (z.B. 1 ) gleichzeitig gedrückt.
Zum Umschalten zwischen den angeschlossenen Rechnern mit der Maus müssen die
mittlere Taste der Maus und gleichzeitig die linke oder rechte Taste kurz gedrückt werden.
Der LINDY CPU Switch SMART DVI bietet die Möglichkeit, viele integrierte Optionen wie
Umschalt-Hotkey, Bildschirmschoner, Passwort, AutoScan-Modus weitgehend zu
konfigurieren. Informationen hierzu finden Sie im ausführlichen englischen Handbuch.
Weitere Hinweise finden Sie dort auch zu den Themen:
Problembehebung
Kaskadierung mehrerer CPU Switches
Hot-Plugging von Rechnern am CPU Switch
Einstellungen für das Mausprotokoll
Mouse Recovery nach Verlust des PS/2 Maussignals an einem der angeschlossenen PC
Mouse Recovery nach Abziehen der Maus vom CPU Switch
Flash-Upgrade der Firmware
Sicherheitstechnische Informationen
Nur für den Gebrauch innerhalb von trockenen Räumen vorgesehen.
Die Wartung des CPU Switch SMART DVI darf ausschließlich von dazu qualifiziertem
Fachpersonal vorgenommen werden.
Sämtliche Warnhinweise und Anweisungen auf dem CPU Switch SMART DVI, seinem
Netzteil und Zubehörteilen sind zu beachten und befolgen.
Warnung – im Netzteil sind unter Spannung stehende Teile enthalten, es darf nicht
geöffnet werden.
Das Netzteil darf nur durch ein von LINDY zugelassenes ersetzt
werden.

CPU Switch Smart DVI FRENCH
Guía rápida de instalación y funcionamiento
INSTALACIÓN RÁPIDA
Desconecte todos los ordenadores y conéctelos a los puertos NARANJA en la parte
posterior del CPU Switch Smart DVI.
Conecte el teclado, el monitor y el ratón al puerto GRIS en la parte posterior del CPU
Switch Smart.
RESUMEN DE LA GUÍA DE FUNCIONAMIENTO
La configuración por defecto del CPU Switch Smart es adecuada para la mayoría de los
sistemas.
Puede seleccionarse un ordenador utilizando la tecla del panel frontal, un ratón de tres
botones o una combinación de teclas rápidas en el teclado. Para seleccionar un
ordenador utilizando el ratón, pulse y suelte los botones izquierdo o derecho mientras
mantiene pulsado el botón del medio. Para seleccionar un ordenador utilizando las
teclas rápidas del teclado, mantenga pulsadas las teclas CTRL y ALT, pulse y suelte la
tecla del puerto requerida (p.e. 1) y a continuación suelte las teclas CTRL y ALT.
Información sobre seguridad
Solamente debe usarse en interiores, en entornos secos y sin grasa.
No intente realizar ningún tipo de mantenimiento al CPU Switch Smart DVI usted
mismo.
Siga todos los avisos e instrucciones marcadas en el CPU Switch Smart DVI, el
adaptador de potencia opcional y todos sus accesorios.
Aviso –el adaptador de potencia opcional tiene piezas con tensión.
El adaptador de potencia opcional no contiene piezas que pueda mantener el usuario –
no desmontarlo.
Cambie el adaptador de potencia opcional solamente con un tipo aprobado por el
fabricante.
Si utiliza una cable de extensión con el CPU Switch Smart DVI, compruebe que el
amperaje nominal total de los equipos enchufados en el cable de extensión no superen
el amperaje nominal del cable de extensión. Asimismo, compruebe que el amperaje
nominal total de todos los equipos conectados a la toma de red no superen el amperaje
nominal de la toma.
E

CPU Switch Smart DVI FRENCH
Guide d'installation rapide et mode d'emploi
INSTALLATION RAPIDE
Mettez tous vos ordinateurs hors tension et raccordez-les aux ports ORANGE à l'arrière
d'CPU Switch Smart DVI.
Raccordez votre clavier, moniteur et souris au port GRIS à l'arrière de l'CPU Switch
Smart.
MODE D'EMPLOI SOMMAIRE
La configuration par défaut de l'CPU Switch Smart convient à la plupart des systèmes.
Pour sélectionner un ordinateur, utilisez la touche du panneau avant, une souris à trois
boutons ou une combinaison de touches de raccourci clavier. Pour sélectionner un
ordinateur à l'aide de la souris, maintenez la pression sur le bouton central et appuyez
sur le bouton gauche ou droite avant de relâcher. Pour sélectionner un ordinateur avec
les touches de raccourci clavier, maintenez les touches CTRL et ALT enfoncées,
appuyez sur la touche du port souhaité (ex. 1) et relâchez, puis relâchez les touches
CTRL et ALT.
Consignes de sécurité
A n'utiliser qu'à l'intérieur, dans un environnement sec et exempt d'huile.
Ne pas assurer soi-même l'entretien de l'CPU Switch Smart DVI.
Observer tous les avertissements et instructions marqués sur l'CPU Switch Smart DVI,
son adaptateur de courant optionnel et ses accessoires.
Avertissement – l'adaptateur de courant optionnel renferme des pièces sous tension.
L'adaptateur de courant optionnel ne contient aucune pièce devant être révisée par
l'utilisateur – ne pas le démonter.
Ne remplacer l'adaptateur de courant optionnel que par un adaptateur approuvé par le
fabricant.
Lorsqu'une rallonge est utilisée pour l'CPU Switch Smart DVI, vérifier que l'intensité
nominale totale des périphériques branchés sur la rallonge ne dépasse pas l'intensité
nominale du câble. Par ailleurs, vérifier que l'intensité nominale totale de tous les
périphériques branchés sur la prise murale ne dépasse pas l'intensité nominale de la
prise murale elle-même.
F

CPU Switch Smart DVI ITALIAN
Guida di installazione rapida e funzionamento
INSTALLAZIONE RAPIDA
Spegnere tutti i computer e collegarli alle porte ARANCIONI sul retro dell’CPU
Switch Smart DVI.
Collegare la tastiera, monitor e mouse alla porta GRIGIA sul retro dell’CPU
Switch Smart.
SOMMARIO GUIDA OPERATIVA
La configurazione di default dell’CPU Switch Smart è adatta alla maggior parte
dei sistemi.
Si può selezionare un computer usando il tasto sul pannello frontale, un mouse a
tre bottoni o una tastiera con tasti attivi. Per selezionare un computer con il
mouse, premere e rilasciare i bottoni sinistro o destro trattenendo
contemporaneamente quello centrale. Per selezionare un computer con tasti attivi
tastiera, tener premuti i tasti CTRL e ALT, premere e rilasciare il tasto porta
richiesta (es. 1) e quindi rilasciare i tasti CTRL e ALT.
Informazionoi riguardanti la sicurezza
Da usare esclusivamente in interni asciutti e privi di olio.
Non cercare di effettuare manutenzione sull’CPU Switch Smart DVI.
Seguire tutti gli avvertimenti ed istruzioni presenti sull’CPU Switch Smart DVI,
sull’adattatore opzionale di potenza e sugli accessori.
Attenzione – l’adattatore opzionale di potenza contiene parti sotto tensione.
L’adattatore opzionale di potenza non contiene parti soggette a manutenzione da parte
dell’utente – non smontarlo.
Sostituire l’adattatore opzionale di potenza solo con uno di tipo approvato dal
produttore.
Se si usa una prolunga con l’CPU Switch Smart DVI, controllare che la potenza
nominale totale in ampère dei dispositivi collegati alla prolunga non superi la potenza
nominale in ampère della prolunga stessa. Controllare inoltre che la potenza nominale
totale in ampère dei dispositivi collegati non superi la potenza nominale in ampère della
presa a muro.
I

CPU Switch Smart DVI Installation and Use Page 1
About this manual
CPU Switch Smart DVI - Installation and Use
First edition (February 2002) (c) 2002 LINDY
Part No. 32340 www.LINDY.com
All rights reserved. Whilst every precaution has been taken in the preparation of this
manual, LINDY assumes no responsibility for errors or omissions. Neither is any
liability assumed for damages resulting from the use of the information contained
herein. We reserve the right to change the specifications, functions and circuitry of
the product without notice. All trademarks acknowledged.
Safety information
For use in dry, oil free indoor environments only.
Do not attempt to service the CPU Switch Smart DVI yourself.
Follow all warnings and instructions marked on the CPU Switch Smart DVI, its
optional power adapter and its accessories.
Warning - live parts contained within optional power adapter.
No user serviceable parts within optional power adapter - do not dismantle.
Replace the optional power adapter with a manufacturer approved type only.
If you use a power extension cord with the CPU Switch Smart DVI, make sure the
total ampere rating of the devices plugged into the extension cord does not
exceed the cord’s ampere rating. Also, make sure that the total ampere rating of
all the devices plugged into the wall outlet does not exceed the wall outlet’s
ampere rating.

CPU Switch Smart DVI Installation and Use Page 2
Warranty
LINDY warrants that this product shall be free from defects in workmanship and
materials for a period of three years from the date of original purchase. If the product
should fail to operate correctly in normal use during the warranty period, LINDY will
replace or repair it free of charge. No liability can be accepted for damage due to
misuse or circumstances outside LINDY’s control. Also LINDY will not be
responsible for any loss, damage or injury arising directly or indirectly from the use
of this product. LINDY’s total liability under the terms of this warranty shall in all
circumstances be limited to the replacement value of this product.
If any difficulty is experienced in the installation or use of this product that you are
unable to resolve, please contact your supplier.
Trademarks
All trademarks mentioned in this manual are acknowledged to be the property of the
respective trademark owners.
Compaq is a registered trademark of Compaq Computer Corporation.
Hewlett-Packard is a registered trademark of Hewlett-Packard.
IBM, PC/AT, PS/2, RS/6000 and ThinkPad are registered trademarks of
International Business Machines Corporation.
Logitech, MouseMan+ and Pilot Mouse+ are trademarks of Logitech Inc.
Microsoft and Windows are registered trademarks, and IntelliMouse is a trademark
of Microsoft Corporation.
Velcro is a trademark of Velcro USA Inc.

CPU Switch Smart DVI Installation and Use Page 3
Radio Frequency Energy
Shielded cables must be used with this equipment to maintain compliance with radio
frequency energy emission regulations and ensure a suitably high level of immunity
to electromagnetic disturbances.
European EMC directive 89/336/EEC
This equipment has been tested and found to
comply with the limits for a class A computing
device in accordance with the specifications in
the European standard EN55022. These limits
are designed to provide reasonable protection
against harmful interference. This equipment
generates, uses and can radiate radio frequency
energy and if not installed and used in
accordance with the instructions may cause
harmful interference to radio or television
reception. However, there is no guarantee that
harmful interference will not occur in a particular
installation. If this equipment does cause
interference to radio or television reception,
which can be determined by turning the
equipment on and off, the user is encouraged to
correct the interference with one or more of the
following measures: (a) Reorient or relocate the
receiving antenna. (b) Increase the separation
between the equipment and the receiver. (c)
Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected. (d) Consult the supplier or an
experienced radio / TV technician for help.
FCC Compliance Statement (United States)
This equipment generates, uses and can radiate
radio frequency energy and if not installed and
used properly, that is, in strict accordance with
the manufacturer’s instructions, may cause
interference to radio communication. It has been
tested and found to comply with the limits for a
class A computing device in accordance with the
specifications in Subpart J of part 15 of FCC
rules, which are designed to provide reasonable
protection against such interference when the
equipment is operated in a commercial
environment. Operation of this equipment in a
residential area may cause interference, in
which case the user at his own expense will be
required to take whatever measures may be
necessary to correct the interference. Changes
or modifications not expressly approved by the
manufacturer could void the user’s authority to
operate the equipment.
Canadian Department of Communications
RFI statement
This equipment does not exceed the class A
limits for radio noise emissions from digital
apparatus set out in the radio interference
regulations of the Canadian Department of
Communications.
Le présent appareil numérique n’émet pas de
bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la
classe A prescrites dans le règlement sur le
brouillage radioélectriques publié par le
ministère des Communications du Canada.

CPU Switch Smart DVI Installation and Use Page 4
Contents
1. Introduction.....................................................................................6
1.1 Key features............................................................................................6
1.2 Package contents...................................................................................7
1.3 Remote controller contents.....................................................................7
1.4 Product information ................................................................................8
2. Installation.......................................................................................9
2.1 What you will need .................................................................................9
2.2 Mounting the CPU Switch Smart DVI ....................................................10
2.3 Connecting your devices .......................................................................10
2.4 ‘Interface powered' operation without the optional power adapter ........11
2.5 Configuring your PCs .............................................................................11
2.6 Configuring the CPU Switch Smart DVI .................................................12
2.7 Summary of CPU Switch Smart DVI configuration options.....................13
2.8 Resetting the CPU Switch Smart DVI without disconnecting your
devices...................................................................................................15
2.9 Other useful installation information ......................................................15
2.10 Re-enabling a disconnected PS/2 mouse ............................................16
2.11 Hot plugging the CPU Switch Smart DVI into running systems and
re-enabling disconnected PS/2 CPU mouse connections ...................17
2.12 Upgrading the CPU Switch Smart's flash memory ..............................18
3. Using the CPU Switch Smart DVI .................................................21
3.1 Power on status......................................................................................21
3.2 Front panel keys and remote controller..................................................22
3.3 Status display .........................................................................................22
3.4 Keyboard hotkey control.........................................................................24
3.5 Mouse control.........................................................................................25
3.6 RS232 control.........................................................................................26
3.7 Cascading CPU Switch Smart DVIs ......................................................26
3.8 Synchronising CPU Switch DVIs for multiple video head applications ..27

CPU Switch Smart DVI Installation and Use Page 5
4. CPU Switch Smart DVI configuration options.............................29
4.1 Screen saver time delay ........................................................................29
4.2 Autoscan lock on mode and delay time .................................................29
4.3 Mouse mode and mouse switching of channels.....................................30
4.4 Keyboard hotkey combination ...............................................................31
4.5 Cycling between all channels or just the active channels ......................32
4.6 Firmware functions (version query, mouse restore and reset) ..............32
4.7 Setting a security password ...................................................................33
4.8 Cascade query code ..............................................................................34
4.9 Resolving slow mouse problems ...........................................................34
4.10 Exit configure mode .............................................................................35
Appendices
A - Cable and connector specifications.................................................................36
B - Problem solving...............................................................................................40

CPU Switch Smart DVI Installation and Use Page 6
1. Introduction
Thank you for purchasing the CPU Switch Smart DVI. Your CPU Switch Smart DVI
is a high performance keyboard, monitor and mouse sharing device which supports
a wide range of PC hardware and software platforms.
1.1 Key features
Control multiple PCs from a single keyboard, monitor and mouse.
Continuous keyboard and mouse emulation on all ports ensures problem free
computer bootup.
Interface powered operation – CPU Switch Smart DVI draws its power from the
connected computers for maximum convenience.
Intelligent switching feature enables users to switch between all ports or just the
active ports.
Supports DVI Flat Panels and monitors at resolutions up to 1600 x 1200 @ 60Hz
(165MHz) – i.e. the maximum DVI single-link bandwidth.
Regenerates the DVI video signal and typically doubles the total cable run length
supported between the computer and the monitor.
Mixed AT/PS2 keyboards and PS2/RS232 mice supported as standard.
Flash upgradeable - CPU Switch Smart DVI's firmware may be upgraded by
connecting a computer's serial port and running a download program.
Can be cascaded to provide a video switching network.
Video channels support Display Data Channel (DDC2B) signalling.
DVI Hot Plug Detect support.
Password security prevents unauthorised use.
User options stored in EEPROM memory.
Remote control module for convenient operation.
Channel switching by front panel key, keyboard hotkey, or 3 button mouse.
Automatically restores keyboard and mouse states when channel changed.
Can be controlled remotely via an RS232 serial port.

CPU Switch Smart DVI Installation and Use Page 7
Supports keyboard modes 1,2 and 3 and mouse prompt and stream modes for
maximum compatibility.
Includes screen saver, auto-scan and variable hotkey options.
Supports Microsoft IntelliMouse, IntelliMouse Explorer and other common wheel mice.
Mouse restoration functions to enable ‘hot plugging’ of certain systems.
Keyboard, mouse and CPU Switch Smart DVI resets may be performed without
disconnecting devices.
Supports IBM ThinkPad ‘Y’ cables.
Power and activity indication confirm correct operation.
Standard cable connections make installation easy and inexpensive.
All ports are active simultaneously – all PCs may all be booted at the same time.
Robust metal case ensures good shielding.
Supports desktop and laptop PCs, RS6000s, DEC Alphas, and Silicon Graphics
computers .
Supports very wide range of software including Windows 3.X, WFWG, 95, 98,
2000, NT, DOS, ME, XP, Unix, Linux, NetWare, OS/2, BSD etc.
Optional power adapter can be used for ‘video only’ or cascade applications.
1.2 Package contents
CPU Switch Smart DVI.
This installation guide.
(Please note that a power adapter is NOT required for most applications and so
is not included. This may be purchased separately if required -
part code:32290 IEC Power Adaptor with UK Mains Lead
part code:32265 IEC Power Adaptor with US Mains Lead
part code:32263 IEC Power Adaptor with Schuko Mains Lead part
code:32274 Wall Mount Power Adaptor with Euro Plug)
1.3 Remote controller contents (part code: 32255)
Remote control module.
Velcro strip for mounting remote controller.

CPU Switch Smart DVI Installation and Use Page 8
1.4 Product information
Figure 1 - CPU Switch Smart DVI front view
Figure 2 - CPU Switch Smart DVI rear view (4 port model)
Figure 3 - Remote control pad / display (optional accessory - part code 32255)
Key for changing
channels. Also used
to access configure
mode
Display indicates
selected channel and
CPU Switch Smart
status
User monitor
connection
Power connection
for optional power
adapter
User mouse
connection for
PS/2 style
mouse
Computer video connections
coloured WHITE (1 to 4)
Computer mouse and keyboard connections
Keyboard coloured PURPLE
Mouse coloured GREEN
(1 to4)
Key for changing channels
Options port – used
to connect remote
controller. Also used
to connect computer
for flash upgrades
Display is duplicate of front
panel display and shows status
and mouse / keyboard data
activity

CPU Switch Smart DVI Installation and Use Page 9
2. Installation
2.1 What you will need
Cables to connect the CPU Switch Smart DVI to each of your PC keyboard, video
and mouse ports. Cable specifications are given in appendix A. (You do not need to
connect a mouse cable if you are not using the mouse).
A monitor with a DVI-D connector that will work when connected directly to each
of your PCs. The CPU Switch Smart DVI supports (single-link) DVI-D compatible
Flat Panel displays and monitors.
A computer fitted with a DVI graphics card and DVI-D connector.
A standard AT or PS/2 style keyboard. If you are using an AT keyboard with a 5
pin connector you may connect this to the CPU Switch Smart DVI using a standard
AT to PS/2 keyboard adapter.
A PS/2 style two or three button Microsoft or Logitech compatible mouse or a
Microsoft IntelliMouse / IntelliMouse Explorer compatible mouse. If you wish to use
the mouse to switch the CPU Switch Smart DVI's channel then you will need a three
button mouse or an IntelliMouse.
(The CPU Switch Smart DVI supports ‘Internet Mice’ that are compatible with the
Microsoft IntelliMouse. These are fitted with a wheel or other scroll control and
sometimes have additional buttons. Examples are: Microsoft IntelliMouse, Logitech
Pilot Mouse+, Logitech MouseMan+, Genius NetMouse and Genius NetMouse Pro.)
A suitable mouse driver for your PCs. Supported types are:
- PS/2 or RS232 two button mouse driver (any manufacturer).
- Microsoft mouse driver (including IntelliMouse).
- Logitech mouse driver (including two button, three button and wheel mouse)
Use of PS/2 and RS232 style mice with the CPU Switch Smart DVI - All of the
mouse connections from CPU Switch Smart DVI to PCs support either a PS/2 or an
RS232 mouse. CPU Switch Smart DVI automatically converts from the PS/2 mouse
commands to RS232 serial mouse commands. Serial mice types are selected by

CPU Switch Smart DVI Installation and Use Page 10
using an adapter as described in Appendix A. The CPU Switch Smart DVI will
operate without a mouse connected if you do not wish to use one.
2.2 Mounting the CPU Switch Smart DVI
The CPU Switch Smart DVI has been designed for use on a desktop or shelf in
close proximity to the user’s monitor and peripherals. The optional remote controller
may be used if you wish to locate the CPU Switch Smart DVI on a desk or shelf that
is some distance from the monitor and peripherals.
2.3 Connecting your devices
Ensure that the optional power adapter is disconnected from the CPU Switch Smart
DVI and that all the devices which are to be attached are switched off. Connect the
shared keyboard, PS/2 mouse and monitor to the connectors at the rear of the CPU
Switch Smart DVI (see figs 1, 2 and 3). Next, connect each computer system unit in
turn with the keyboard cable, mouse cable and video cable. Any unused computer
connections can be left unconnected. To connect computers with serial mouse
connections and AT style keyboard connections use the adapters specified in
appendix A. If you have an existing 6-pin mini-DIN to 9-pin serial adapter that came
with a mouse it may not be suitable for use with the CPU Switch Smart as there are
several different standard wiring configurations for these adapters.
The CPU Switch Smart DVI is now ready for use and will start to operate as soon as
one of the attached PCs is powered on. If you are connecting to PCs using cables
that are longer than 5 metres or are cascading the CPU Switch Smart DVI to
another CPU Switch Smart DVI you will need to use the optional power adapter.
When using the optional power adapter, ensure that it is connected to the mains and
powering the CPU Switch Smart DVI before you switch on the connected computers.

CPU Switch Smart DVI Installation and Use Page 11
Failure to switch the CPU Switch Smart DVI and computers on in the correct order
can lead to the mouse and/or keyboard not being recognised by the computers
when they are switched on.
2.4 ‘Interface powered’ operation without the optional power
adapter
The CPU Switch Smart DVI draws its power from the connected computers via the
keyboard cables. A single keyboard connection is normally sufficient to power the
CPU Switch Smart DVI provided that the cable is no longer than 5 metres. If more
than one computer is connected then the power will be intelligently drawn from all
computers. Cables longer than 5 metres may be used provided that the CPU Switch
Smart DVI is already powered by another connected computer or the optional power
adapter. If you are cascading the CPU Switch Smart DVI to another CPU Switch
Smart DVI then a power adapter must be connected to all CPU Switch Smart DVIs.
2.5 Configuring your PCs
Configure your PC in the same way that you would if your keyboard, mouse and
monitor were all connected directly to your PC. CPU Switch Smart DVI emulates
Microsoft compatible serial, IntelliMouse, IntelliMouse Explorer and PS/2 mice, so
ensure that your PC software is configured for a Microsoft mouse of the correct type.
Refer to the list of supported drivers in section 2.1.

CPU Switch Smart DVI Installation and Use Page 12
2.6 Configuring the CPU Switch Smart DVI
IMPORTANT NOTE
Some DVI video cards need to communicate with a monitor before they will
output a video signal. This communication normally occurs within the first 5
seconds after the computer has been powered on. The computer can only
communicate with the monitor if it is the currently selected computer. If you
have this type of DVI video card you will need to select the computer before
switching the computer on. To make this process easy for you we have built
an auto-switch function into the CPU Switch Smart DVI. With the auto-switch
function enabled the CPU Switch Smart will automatically switch to a
computer when the computer is powered on. When powering on several
computers you should power them on in sequence, waiting a few seconds
between each one to allow the video card to communicate with the monitor.
•To enable the auto-scan function move switch 1 on the underside of the
CPU Switch Smart DVI to the ON position.
•To disable the auto-scan function move switch 1 on the underside of the
CPU Switch Smart DVI to the OFF position.
The CPU Switch Smart DVI is supplied pre-configured with factory defaults which
are suitable for most applications. There are a number of more advanced options
which can be set by the user. These are stored in the CPU Switch Smart DVI's
EEPROM memory and are retained when the power is disconnected.
The options may be changed whilst the CPU Switch Smart DVI is in configure mode.
You may enter configure mode at initial power on or whilst the CPU Switch Smart
DVI is running:
To enter configure mode at power on:
Switch off all the attached PCs and the CPU Switch Smart DVI. Hold down the front
panel key whilst powering on the CPU Switch Smart DVI. Remember that the CPU
Switch Smart DVI draws its power from any attached PC via the keyboard cable and
so will power itself on when the attached PC is switched on or when the optional
power adapter is connected. Do not release the key until the CPU Switch Smart DVI
displays 'C' to show that it has entered configure mode.

CPU Switch Smart DVI Installation and Use Page 13
To enter configure mode whilst the CPU Switch Smart DVI is running:
Hold down the front panel key for 5 seconds until the front panel display shows ‘C’.
In configure mode, options are entered by typing a letter followed by a number
followed by (return). Use ESC to abort the entry of an option. The CPU Switch Smart
DVI will remain in configure mode until you type 'E' (return).
For example: to set hotkey option 2 type the following at the 'C' prompt
(at CPU Switch Smart DVI 'C' prompt) HH 22 ff
To exit configure mode type: EE ff
2.7 Summary of CPU Switch Smart DVI configuration options
Full details of each of the configuration options and their uses are given in section 4.
B1 - screen saver disabled (default)
B2 - Blank screen after 1 minute of inactivity
B3 - Blank screen after 2 minutes of inactivity
B4 - Blank screen after 4 minutes of inactivity
B5 - Blank screen after 8 minutes of inactivity
B6 - Blank screen after 12 minutes of inactivity
B7 - Blank screen after 16 minutes of inactivity
B8 - Blank screen after 20 minutes of inactivity
L1 - CPU Switch Smart DVI locks on to active ports only during autoscanning
(default)
L2 - CPU Switch Smart DVI locks on to every port during autoscanning
L3 - CPU Switch Smart DVI powers on in autoscan mode and locks on to active
ports only
L4 - CPU Switch Smart DVI powers on in autoscan mode and locks on to all ports
