Belden Hirschmann EAGLE One User manual

Installation EAGLE One
Release 07 03/2023
Technical support
https://hirschmann-support.belden.com
User Manual
Installation
Industrial Ethernet Firewall
EAGLE One

2023-03-22 Installation EAGLE One
Release 07 03/2023
The naming of copyrighted trademarks in this manual, even when not specially indicated, should
not be taken to mean that these names may be considered as free in the sense of the trademark
and tradename protection law and hence that they may be freely used by anyone.
© 2023 Hirschmann Automation and Control GmbH
Manuals and software are protected by copyright. All rights reserved. The copying, reproduction,
translation, conversion into any electronic medium or machine scannable form is not permitted,
either in whole or in part. An exception is the preparation of a backup copy of the software for
your own use.
The performance features described here are binding only if they have been expressly agreed
when the contract was made. This document was produced by Hirschmann Automation and
Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right
to change the contents of this document without prior notice. Hirschmann can give no guarantee
in respect of the correctness or accuracy of the information in this document.
Hirschmann can accept no responsibility for damages, resulting from the use of the network
components or the associated operating software. In addition, we refer to the conditions of use
specified in the license contract.
You can get the latest version of this manual on the Internet at:
https://www.doc.hirschmann.com
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany

Contents
Important information 5
Safety instructions 7
About this manual 23
Key 24
1 Description 25
1.1 General description 25
1.2 Device name and product code 26
1.3 Device view 29
1.4 Power supply 30
1.5 Ethernet ports 31
1.5.1 10/100 Mbit/s twisted pair port 31
1.5.2 100 Mbit/s F/O port 31
1.6 Display elements 32
1.6.1 Device status 32
1.6.2 Additional status information 33
1.6.3 Port status 33
1.7 Management interfaces 34
1.7.1 V.24 interface (external management) 34
1.7.2 ACA21-USB interface 35
1.8 Input/output interfaces 35
1.8.1 Signal contact 35
1.8.2 Digital input 35
2 Installation 36
2.1 Overview 36
2.2 Checking the package contents 36
2.3 Installing and grounding the device 37
2.3.1 Installing the device onto the DIN rail 37
2.3.2 Mounting on a vertical flat surface 38
2.3.3 Grounding the device 38
2.4 Connecting the terminal blocks 39

4Installation EAGLE One
Release 07 03/2023
2.4.1 Connecting the power supply and the signal contact
lines 39
2.4.2 Wiring the digital input (optional) 41
2.5 Operating the device 41
2.6 Connecting data cables 42
3 Configuration 43
3.1 Making basic settings 43
3.2 Firewall and VPN functions 44
3.2.1 Firewall functions 44
3.2.2 VPN functions 44
3.3 Operating modes 45
3.3.1 Delivery state 45
3.3.2 Transparent mode 45
3.3.3 Router mode 45
3.3.4 PPPoE mode 45
3.4 Starting configuration 46
4 Monitoring the ambient air temperature 48
5 Maintenance and service 49
6Disassembly 50
7 Technical data 51
A Further support 61

Installation EAGLE One
Release 07 03/2023 5
Important information
Note: Read these instructions carefully, and familiarize yourself with the
device before trying to install, operate, or maintain it. The following notes may
appear throughout this documentation or on the device. These notes warn of
potential hazards or call attention to information that clarifies or simplifies a
procedure.
Symbol explanation
This is a general warning symbol. This symbol alerts you to
potential personal injury hazards. Observe all safety notes that
follow this symbol to avoid possible injury or death.
If this symbol is displayed in addition to a safety instruction of the
type “Danger” or “Warning”, it means that there is a danger of
electric shock and failure to observe the instructions will
inevitably result in injury.
This symbol indicates the danger of hot surfaces on the device.
In connection with safety instructions, non-observance of the
instructions will inevitably result in injuries.
DANGER
DANGER draws attention to an immediately dangerous situation, which will
inevitably result in a serious or fatal accident if not observed.
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a possible danger which, if not avoided, may result in
minor injuries.

6Installation EAGLE One
Release 07 03/2023
NOTICE
NOTICE provides information about procedures that do not involve the risk
of injury.

Installation EAGLE One
Release 07 03/2023 7
Safety instructions
General safety instructions
You operate this device with electricity. Improper usage of the device
entails the risk of physical injury or significant property damage. The
proper and safe operation of this device depends on proper handling
during transportation, proper storage and installation, and careful
operation and maintenance procedures.
Before connecting any cable, read this document, and the safety
instructions and warnings.
Operate the device with undamaged components exclusively.
The device is free of any service components. In case of a damaged
or malfunctioning device, turn off the supply voltage and return the
device to Hirschmann for inspection.
Qualification requirements for personnel
Only allow qualified personnel to work on the device.
Qualified personnel have the following characteristics:
Qualified personnel are properly trained. Training as well as practical
knowledge and experience make up their qualifications. This is the
prerequisite for grounding and labeling circuits, devices, and systems
in accordance with current standards in safety technology.
Qualified personnel are aware of the dangers that exist in their work.
Qualified personnel are familiar with appropriate measures against
these hazards in order to reduce the risk for themselves and others.
Qualified personnel receive training on a regular basis.
WARNING
UNCONTROLLED MACHINE ACTIONS
To avoid uncontrolled machine actions caused by data loss, configure all
the data transmission devices individually.
Before you start any machine which is controlled via data transmission, be
sure to complete the configuration of all data transmission devices.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.

8Installation EAGLE One
Release 07 03/2023
Certified usage
Use the product only for the application cases described in the
Hirschmann product information, including this manual.
Operate the product only according to the technical specifications.
See “Technical data” on page 51.
Connect to the product only components suitable for the requirements
of the specific application case.
National and international safety regulations
Verify that the electrical installation meets local or nationally applicable
safety regulations.
Grounding the device
Grounding the device is by means of a separate ground connection on the
device.
Ground the device before connecting any other cables.
Disconnect the grounding only after disconnecting all other cables.
The overall shield of a connected shielded twisted pair cable is connected
to the grounding connector on the front panel as a conductor.
Supply voltage
The supply voltage is electrically isolated from the casing.
Exclusively connect a supply voltage that corresponds to the type
plate of your device.
Every time you connect the electrical conductors, make sure that the
following requirements are met:
The power supply conforms to overvoltage category I or II.
The power supply has an easily accessible disconnecting device
(for example a switch or a plug). This disconnecting device is
clearly identified. So in the case of an emergency, it is clear which
disconnecting device belongs to which power supply cable.
The electrical wires are voltage-free.
The power supply is Class 2 compliant.
The supply voltage inputs are designed for operation with safety
extra-low voltage. Connect only SELV circuits with voltage
restrictions in line with IEC/EN 60950-1 to the supply voltage
connections.
Supply with AC voltage:
A back-up fuse is located in the outer conductor of the power
supply.
The neutral conductor is on ground potential at both voltage inputs.
Otherwise, a back-up fuse is also located in the neutral conductor.
Regarding the properties of this back-up fuse: See “General
technical data” on page 51.

Installation EAGLE One
Release 07 03/2023 9
Supply with DC voltage:
A back-up fuse suitable for DC voltage is located in the plus
conductor of the power supply.
The minus conductor is on ground potential. Otherwise, a back-up
fuse is also located in the minus conductor.
Regarding the properties of this back-up fuse: See “General
technical data” on page 51.
The wire diameter of the power supply cable is at least 1 mm²
(North America: AWG16) on the supply voltage input.
The cross-section of the protective conductor is the same size as
or bigger than the cross-section of the power supply cables.
The cables used are permitted for the temperature range of the
application case.
Relevant for North America:
Exclusively use 60/75 °C (140/167 °F) or 75 °C (167 °F) copper
(Cu) wire.
Internal fuses are triggered only in the case of a detected error in the
device. In case of damage or malfunction of the device, turn off the
supply voltage and return the device to the plant for inspection.
Input/output interfaces
Every time you connect the electrical conductors, make sure that the
following requirements are met:
The electrical wires are voltage-free.
The connected voltage is limited by a current limitation device or a
fuse.
Observe the electrical threshold values for the signal contact.
See “General technical data” on page 51.
Observe the electrical threshold values for the digital input.
See “Digital input” on page 52.
Installation site requirements
Verify that there is at least 10 cm (4 in) of space above and below the
device.
Verify that there is at least 2 cm (0.8 in) of space on the right and left
sides of the device.
Install the device in a fire enclosure according to IEC 60950-1.

10 Installation EAGLE One
Release 07 03/2023
Strain relief
Note: If the strain relief is insufficient, there is a potential risk of torsion,
contact problems and creeping interruptions.
Relieve the connection points of cables and lines from mechanical
stress.
Design strain reliefs in such a way that they help prevent any
mechanical damage to cables, wires or conductors caused by external
influences or their own weight.
To help prevent damage to device connections, connectors and
cables, follow the instructions for proper installation in accordance with
DIN VDE 0100-520:2013-06, sections 522.6, 522.7 and 522.13.
Device casing
Only technicians authorized by the manufacturer are permitted to open
the casing.
Never insert pointed objects (narrow screwdrivers, wires, etc.) into the
device or into the connection terminals for electric conductors. Do not
touch the connection terminals.
Keep the ventilation slits free to ensure good air circulation.
Mount the device in the vertical position.
At ambient air temperatures > +60 °C (+140 °F):
The surfaces of the device housing may become hot. Avoid touching
the device while it is operating.
LED or laser components
LED or LASER components according to IEC 60825-1 (2014):
CLASS 1 LASER PRODUCT
CLASS 1 LED PRODUCT

Installation EAGLE One
Release 07 03/2023 11
CE marking
The labeled devices comply with the regulations contained in the following
European directive(s):
2011/65/EU and 2015/863/EU (RoHS)
Directive of the European Parliament and of the Council on the
restriction of the use of certain hazardous substances in electrical and
electronic equipment.
2014/30/EU (EMC)
Directive of the European Parliament and of the Council on the
harmonisation of the laws of the Member States relating to
electromagnetic compatibility.
2014/34/EU (ATEX)
Directive of the European Parliament and of the Council on the
harmonisation of the laws of the Member States relating to equipment
and protective systems intended for use in potentially explosive
atmospheres.
The ATEX Directive applies exclusively to the device variants labeled with
an ATEX certificate number:
See “ATEX directive 2014/34/EU – specific regulations for safe
operation” on page 16.
In accordance with the above-named EU directive(s), the EU conformity
declaration will be at the disposal of the relevant authorities at the
following address:
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
You find the EU conformity declaration as PDF file for downloading on the
Internet at: https://www.doc.hirschmann.com/certificates.html
The device can be used in industrial environments.
Interference immunity: EN 61000-6-2
Emitted interference: EN 55032
You find more information on technical standards here:
See “Technical data” on page 51.
Warning! This is a class A device. This device can cause interference in
living areas, and in this case the operator may be required to take
appropriate measures.
Note: The assembly guidelines provided in these instructions must be
strictly adhered to in order to observe the EMC threshold values.

12 Installation EAGLE One
Release 07 03/2023
UKCA marking
The labeled devices comply with the following UK regulations:
S.I. 2012 No. 3032
Restriction of the Use of Certain Hazardous Substances in Electrical
and Electronical Equipment Regulations
S.I. 2016 No. 1091
Electromagnetic Compatibility Regulations 2016
S.I. 2016 No. 1107
Equipment and Protective Systems Intended for use in Potentially
Explosive Atmospheres Regulations 2016
Note:The regulation applies exclusively to the device variants labeled
with a UKEX certificate number: See “UK regulation S.I. 2016:1107
(as amended by S.I. 2019:696) - Schedule 3A, Part 6” on page 19.
The UKCA conformity declaration will be available to the relevant
authorities at the following address:
Belden UK Ltd.
1 The Technology Centre, Station Road
Framlingham, IP13 9EZ, United Kingdom
You find the UKCA conformity declaration as PDF file for downloading on
the Internet at: https://www.doc.hirschmann.com/certificates.html
The device can be used in industrial environments.
Interference immunity: EN 61000-6-2
Emitted interference: EN 55032
You find more information on technical standards here:
See “Technical data” on page 51.
Warning! This is a class A device. This device can cause interference in
living areas, and in this case the operator may be required to take
appropriate measures.
Note: The assembly guidelines provided in these instructions must be
strictly adhered to in order to observe the EMC threshold values.
Relevant for use in North America
Use this device solely in Class 2 Circuits.

Installation EAGLE One
Release 07 03/2023 13
Relevant for use in explosion hazard areas (Hazardous
Locations, Class I, Division 2)
The relay connections are to be installed and used within their Entity
Parameters as per the following Control Drawing 000174247DNR.
Avertissement - Risque d'explosion - Ne pas débrancher tant que le
circuit est sous tension à moins que l'emplacement soit connu pour ne
contenir aucune concentration de gaz inflammable.
Avertissement - Risque d'explosion - La substitution de tout composant
peut rendre ce matériel incompatible pour une utilisation en classe I,
division 2.

14 Installation EAGLE One
Release 07 03/2023
1RQLQFHQGLYH¿HOGZLULQJSDUDPHWHUV
THE RELAY TERMINALS ARE DEPENDENT UPON THE FOLLOWING ENTITY
3$5$0(7(56
Vmax Imax CiLi
30 V 90 mA 3 nF 1 μH
CONTROL DRAWING to EAGLEONE and TOFINOXE series
devices for use in Hazardous Locations
Class I Division 2, Groups A, B, C, D
Rev. 0 2014-12-01 Document No.: 000174247DNR Page 1/2
DI (+) DI (-)
+24V (P2)
+24V (P1)
FAULT
OV
OV
Aufkleber MAC-Adresse
IP-Adresse
EAGLE One
USB
Power ACA LS/DA
Status RR
1 2 VPN
!
!
PB
1
2
V24
FAULT contacts
USB pin 4
USB pin 1
7KH86%FRQQHFWRULVIRUWHPSRUDU\FRQQHFWLRQ
RQO\'RQRWXVHFRQQHFWRUGLVFRQQHFWXQOHVV
DUHDLVNQRZQWREHQRQKD]DUGRXV&RQQHFWLRQ
RUGLVFRQQHFWLRQLQDQH[SORVLYHDWPRVSKHUH
FRXOGUHVXOWLQDQH[SORVLRQ
2UGLQDU\/RFDWLRQ1RQ+D]DUGRXV$UHD
1RQH[SORVLYH$WPRVSKHUH
&ODVV,'LYLVLRQ *URXSV$%&'+D]DUGRXV/RFDWLRQ
The earth conductor must be at least of the same wire size
(mm² or AWG) as the supply conductors.
Any
EAGLEONE-0200xxx
or
TOFINOXE-200xxx-
device

Installation EAGLE One
Release 07 03/2023 15
7KHPD[LPXPFDEOHOHQJWKKDVWREHGHWHUPLQHGDVIROORZV
DPD[&DEOH/HQJWK/D/i&DEOHL
³&DEOHL´GHQRWHVWKHLQGXFWDQFHSHUXQLWOHQJWKRIXVHGFDEOHDQG
EPD[&DEOH/HQJWKPD[&DEOH/HQJWK&D&i&DEOH&
³&DEOH&´GHQRWHVWKHFDSDFLWDQFHSHUXQLWOHQJWKRIXVHGFDEOH
7KHORZHUYDOXHRIDDQGELVWRDSSO\
CONTROL DRAWING to EAGLEONE and TOFINOXE series
devices for use in Hazardous Locations
Class I Division 2, Groups A, B, C, D
Rev. 0 2014-12-01 Document No.: 000174247DNR Page 2/2
68,7$%/()2586(,1&/$66,',9,6,21*52836$%&'+$=$5'286
/2&$7,21625121+$=$5'286/2&$7,21621/<
)RUXVHLQ+$=$5'286/2&$7,216RQO\DOORZHGIRUPRGHO1RVZKLFKDUH
ODEHOOHGDFFRUGLQJO\
  1RQLQFHQGLYH¿HOGZLULQJFLUFXLWVPXVWEHZLUHGLQDFFRUGDQFHZLWKWKH   1DWLRQDO(OHFWULFDO&RGH1(&1)3$DUWLFOH   86%$1'5(/$<&217$&76)$8/7,QVWDOOSHU&RQWURO'UDZLQJ    '15
:$51,1*(;3/26,21+$=$5'±68%67,787,212)$1<&20321(1760$< 
 ,03$,568,7$%,/,7<)25&/$66,',9,6,21
:$51,1*(;3/26,21+$=$5''2127',6&211(&7(48,30(17:+,/(7+(
 &,5&8,7,6/,9(2581/(667+($5($,6.12:172%()5((2)  ,*1,7$%/(&21&(175$7,216
1RWHV
7KHQRQLQFHQGLYH¿HOGZLULQJFLUFXLWFRQFHSWDOORZVLQWHUFRQQHFWLRQRIQRQLQFHQGLYH¿HOGZLULQJ
DSSDUDWXVDQGDVVRFLDWHGQRQLQFHQGLYH¿HOGZLULQJDSSDUDWXVXVLQJDQ\RIWKHZLULQJPHWKRGV
SHUPLWWHGIRUXQFODVVL¿HGORFDWLRQVZKHQFHUWDLQSDUDPHWULFFRQGLWLRQVDUHPHW
&DSDFLW\&D&i&&DEOH,QGXFWLYLW\/DLi+ L&DEOH
Manufactured in 72654 Neckartenzlingen / Germany by Hirschmann Automation and
Control GmbH.
DOM: ww/yy (Date of manufactur w - week, y - year. Refer to the device label).

16 Installation EAGLE One
Release 07 03/2023
ATEX directive 2014/34/EU – specific regulations for safe
operation
In Ex Zone 2, only the devices with a corresponding label may be
operated.
The devices are to be installed and used according to the European
Directive 2014/34/EU. Details see the next 2 pages.

Installation EAGLE One
Release 07 03/2023 17
Use of EAGLEONE and TOFINOXE series devices
according to the European directive 2014/34/EU
DI (+) DI (-)
+24V (P2)
+24V (P1)
FAULT
OV
OV
Aufkleber MAC-Adresse
IP-Adresse
EAGLE One
USB
Power ACA LS/DA
Status RR
1 2 VPN
!
!
PB
1
2
V24
FAULT contacts
USB pin 4
USB pin 1
Ordinary Location, Non-Hazardous Area,
Nonexplosive Atmosphere
THE Fault Relays are tested as Sealed Device according to
ATEX EN 60079-7. Switching current max. 1 A,
(resistive load)
Switching voltage max. 60 V DC or 30 V AC, SELV
The USB connector is for temporary connection
only. Do not use, connect, or disconnect unless
area is known to be non-hazardous. Connection
or disconnection in an explosive atmosphere
could result in an explosion.
Temperature Code: T4
Ambient Temperature rating:
Ta: 0 °C to +60 °C for “S” types 7Dí&WR&IRU“T” or “E” types
íUHIHUWRWKHW\SHGHVLJQDWLRQRQWKHGHYLFH
(item 18 of product code: “Temperature range”)
Atex Zone 2 Explosive Atmosphere
The earth conductor must be at least of the same wire size
(mm² or AWG) as the supply conductors.
Any
EAGLEONE-0200xxx
or TOFINOXE-200xxx- device

18 Installation EAGLE One
Release 07 03/2023
Use of EAGLEONE and TOFINOXE series devices
according to the European directive 2014/34/EU
For Use in explosive atmospheres according to the European directive 2014/34/EU:
Applied Standards:
The Use in Hazardous Locations with explosive atmospheres is only allowed for EAGLEONE or TOFINOXE model No´s. which are labeled accordingly - including “Ex II 3 G”,
“Ex ec nC IIC T4 Gc” “DEKRA 13ATEX0184X”.
EN IEC 60079-0 EN 60079-7
SPECIAL CONDITIONS FOR SAFE USE:
 The modules shall be installed in a suitable enclosure in accordance with EN IEC 60079-0
providing a degree of protection of at least IP54 according to EN 60529, taking into account
the environmental conditions under which the equipment will be used.
 Provisions shall be made to prevent the rated voltage from being exceeded by transient
disturbances of more than 119 V.
 When the temperature under rated conditions exceeds 70 °C at the cable or conduit entry
SRLQWRU&DWWKHEUDQFKLQJSRLQWRIWKHFRQGXFWRUVWKHWHPSHUDWXUHVSHFL¿FDWLRQRIWKH
selected cable shall be in compliance with the actual measured temperature values.
Manufactured in 72654 Neckartenzlingen / Germany by Hirschmann Automation and
Control GmbH.
DOM: ww/yy (Date of manufactur w - week, y - year. Refer to the device label).

Installation EAGLE One
Release 07 03/2023 19
UK regulation S.I. 2016:1107
(as amended by S.I. 2019:696) - Schedule 3A, Part 6
In Ex Zone 2, only the devices with a corresponding label may be
operated.
The devices are to be installed and used according to UK S.I. 2016:1107.
Details see the next 2 pages.

20 Installation EAGLE One
Release 07 03/2023
Use of EAGLEONE and TOFINOXE series devices
according to the UK regulation S.I. 2016:1107 (as amended by
S.I. 2019:696) - Schedule 3A, Part 6
DI (+) DI (-)
+24V (P2)
+24V (P1)
FAULT
OV
OV
Aufkleber MAC-Adresse
IP-Adresse
EAGLE One
USB
Power ACA LS/DA
Status RR
1 2 VPN
!
!
PB
1
2
V24
FAULT contacts
USB pin 4
USB pin 1
Ordinary Location, Non-Hazardous Area,
Nonexplosive Atmosphere
The Fault Relays are tested as Sealed Device according to
ATEX EN 60079-7. Switching current max. 1 A,
(resistive load)
Switching voltage max. 60 V DC or 30 V AC, SELV
The USB connector is for temporary connection
only. Do not use, connect, or disconnect unless
area is known to be non-hazardous. Connection
or disconnection in an explosive atmosphere
could result in an explosion.
Temperature Code: T4
Ambient Temperature rating:
Ta: 0 °C to +60 °C for “S” types 7Dí&WR&IRU“T” or “E” types
íUHIHUWRWKHW\SHGHVLJQDWLRQRQWKHGHYLFH
(item 18 of product code: “Temperature range”)
Zone 2 Explosive Atmosphere
The earth conductor must be at least of the same wire size
(mm² or AWG) as the supply conductors.
Any
EAGLEONE-0200xxx
or TOFINOXE-200xxx- device
