Fortinet FortiGate 300C User manual

FortiGate 300C
QuickStart Guide

August 20, 2012
01-430-149396-20120820
Copyright© 2012 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®,
and FortiGuard®, are registered trademarks of Fortinet, Inc., and other
Fortinet names herein may also be trademarks of Fortinet. All other
product or company names may be trademarks of their respective
owners. Performance metrics contained herein were attained in internal
lab tests under ideal conditions, and performance may vary. Network
variables, different network environments and other conditions may
affect performance results. Nothing herein represents any binding
commitment by Fortinet, and Fortinet disclaims all warranties, whether
express or implied, except to the extent Fortinet enters a binding written
contract, signed by Fortinet’s General Counsel, with a purchaser that
expressly warrants that the identified product will perform according to the
performance metrics herein. For absolute clarity, any such warranty will be
limited to performance in the same ideal conditions as in Fortinet’s internal
lab tests. Fortinet disclaims in full any guarantees. Fortinet reserves the
right to change, modify, transfer, or otherwise revise this publication
without notice, and the most current version of the publication shall be
applicable.

Table of Contents
1 Package Contents
2 Installation
3 FortiExplorer
4 Device Configuration
5 Technical Specifications
6 LED Specifications
7 Register Your Product
8Technical Documentation and Links
9Cautions and Warnings
10 Product License Agreement

Power Cable
2 Rack-Mount
Brackets
4 Rubber FeetEthernet Cable
USB Cable Console Cable
Tools and Documentation
Tools and
Documentation
CD
QuickStart
Guide
FortiGate 300C
QuickStart Guide
1. Package Contents
Thank you for purchasing the FortiGate 300C. The FortiGate 300C delivers
wire-speed performance, integrated threat management and flexibility at an
affordable price. Fortinet’s technologies provide outstanding firewall throughput,
enabling you to protect your applications and network without affecting
performance.
Your box contains the following:
FortiGate 300C
QuickStart Guide
Tools and Documentation CD
Ethernet Cable
Console Cable
USB Cable
Power Cable
4 Rubber Feet
2 Rack-Mount Brackets

The FortiGate unit can be placed on any flat surface, or mounted in any standard
19in (48.3cm) rack unit with the provided rack-mount brackets and screws.
Caution: Electrostatic discharge (ESD) can damage your Fortinet equipment.
To install the FortiGate unit into a rack:
Caution: To avoid personal injury or damage to the unit, it is recommended that
two or more people install the unit into the rack.
1. Ensure that the FortiGate unit is placed on a stable surface prior to rack-mount
installation.
2. Attach the provided rack-mount brackets to the sides of the unit using the
provided screws.
a. If you are installing the unit into a four-post rack, attach the rack-mount
brackets with the handles aligned with the front of the unit.
b. If you are installing the unit into a two-post rack, attach the rack-mount
brackets with the handles aligned with the middle of the unit.
2. Installation

3. Position the FortiGate unit in the rack. Ensure there is enough room around the
unit to allow for sufficient air flow.
4. Line up the rack-mount bracket holes to the holes on the rack and ensure that the
FortiGate unit is level.
5. Finger tighten four rack-mount screws to attach the unit to the rack.
6. Verify that the spacing around the FortiGate unit conforms to requirements and
that the unit is level, then tighten the rack-mount screws with an appropriate
screwdriver.
7. Using the provided power cables, plug the cables into the rear of the unit and then
into an electrical outlet.
Note: If the unit has a redundant power supply, each power cable should be
connected to a different power source. In this way, if one power source fails, the
other may still be operational and the unit will not lose power.
To install the unit on a flat surface:
1. Ensure that the surface onto which the FortiGate unit to be installed is clean, level,
and stable and that there is at least 2in (5.08cm) of clearance on all sides to allow
for adequate airflow.
2. Attach the provided rubber feet to the bottom of the FortiGate unit.
3. Place the unit in the designated location.
4. Verify that the spacing around the FortiGate unit conforms to requirements
and that the unit is level.
5. Using the provided power cables, plug the cables into the rear of the unit and
then into an electrical outlet.
Note: If the unit has a redundant power supply, each power cable should be
connected to a different power source. In this way, if one power source fails, the
other may still be operational and the unit will not lose power.
Caution: Do not place heavy objects on the unit.
2.0in
2.0in

3. FortiExplorer
FortiExplorer provides a user-friendly tool that you can use to configure
a FortiGate unit over a standard USB connection, rather than using a
console cable or Ethernet connection.
Caution: Do not connect the USB cable until after FortiExplorer
has been installed.
Note: When using FortiExplorer for the first time, ensure the FortiGate
unit is using its factory default settings.
Installing FortiExplorer
FortiExplorer is available for Microsoft Windows XP, Vista, and 7. It is
also available for Mac OS 10.6 and higher.
Microsoft Windows Install
1. Extract the ZIP file (if downloaded) and double-click the .msi, or .exe
file and follow the instructions on-screen. If loading from the CD,
select the appropriate version for your operating system.
2. Connect the USB cable to the FortiGate unit and then to the
management computer.
3. The FortiExplorer Easy Configuration Utility opens when the USB
cable is connected. Select Install the hardware automatically and
select Next.
4. After a moment, FortiExplorer will launch.
FortiASIC Powered
1/2 3/4 5/6 7/8
STATUS
POWER
ALARM
HA
CONSOLE
9/10
USB USB MGMT
USB A to USB B Cable
USB A cable end into
Management Computer
USB B cable end into
FortiWiFi Unit

Mac OS Install
1. Double-click the .dmg file and drag the FortiExplorer program file
into the Applications folder.
2. Connect the USB cable to the FortiGate unit and then to the
management computer.
3. Double-click the FortiExplorer icon to launch the application.
Configuration Options
With FortiExplorer, you are provided a number of options on how to
configure the FortiGate unit, depending on your level of comfort with
various interfaces.
The below image shows the FortiExplorer Easy Configuration Wizard.
Updating FortiExplorer and Firmware
FortiExplorer may be automatically updated from time to time.
You can also use FortiExplorer to check for new firmware for a
FortiWiFi unit. To check for new firmware, select the FortiWiFi unit
from the device list and select Check for New Firmware. FortiExplorer
will also monitor firmware updates for your devices and provide an
alert when one is available.

4. Device Configuration
The FortiGate unit requires some basic configuration to add it to your
network. These basic steps include assigning IP addresses, DNS
settings, and the default gateway. Until these steps are completed
traffic will not flow through the device.
In addition to FortiExplorer, the FortiGate unit can be configured using
the Web-based Manager or the CLI.
This section will step you through both methods of connecting to the
unit. Use whichever method you are most comfortable with.
To Connect to the Web-based Manager:
1. Connect from the management port on the FortiGate unit to a
management computer using the provided Ethernet cable.
2. Configure the management computer to be on the same
subnet as the internal interface of the FortiGate unit:
a. Browse to the Network and Sharing Center > Change
Adapter Settings > Local Area Connection Properties
> Internet Protocol Version 4 (TCP/IPv4) Properties.
b. Change the IP address of the management computer
to 192.168.1.2 and the netmask to 255.255.255.0.
3. To access the FortiGate unit Web-based Manager, start a
browser of your choice and browse to https://192.168.1.99
(remember to include the “s” in https://).
4. Type admin in the Name field, leave the
Password field blank, and select Login.
You can now proceed with configuring your FortiGate unit.

To Connect to the CLI:
You can configure all FortiGate configuration options from the CLI
using config commands. The CLI also includes get, show, diagnose,
and execute commands for performing various configuration and
monitoring tasks.
1. Connect the FortiGate unit console port to the management
computer using the provided console cable.
2. Start a terminal emulation program on the management computer.
Use the following settings:
• Baud Rate: 9600
• Data bits: 8
• Parity: None
• Stop bits: 1
• Flow Control: None
3. Press Enter on your keyboard to connect to the CLI.
4. Type admin in the Name field, leave the
Password field blank, and press Enter.
You can now proceed with configuring your FortiGate unit.
