BELIMED WD 200 User manual

Rack for containers WD 200
Loading Manual

These instructions apply to:
Product Rack
Rack for containers WD 200
Material 643019
Document | Version 1007-4247 | 02
Language EN-US English
Month | Year 12 | 2020
Copyright 2020
© Belimed AG

Rack for containers WD 200 | © Belimed
001 3 | 18
Content
1 Introduction 4
1.1 Purpose of these instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Target group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Changes and copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 Symbols and notices used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Safety instructions 6
2.1 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2.1 Instructing Personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2.2 Loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2.3 Resolve the error and repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.2.4 Servicing the rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.5 Personnel requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.6 Summary of the safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Description 10
3.1 Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Loading 11
5 Maintenance and cleaning work 13
5.1 Optimize cleaning performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6 Disposal 16

Rack for containers WD 200 | © Belimed
4 | 18 001
1 Introduction
1.1 Purpose of these instructions
These instructions inform the operator how to safely and correctly load the racks. This manual con-
stitutes a component of the product and must therefore be stored together with the product at a suit-
able location which is easily accessible for the operator.
1.2 Target group
Instructions are a component of the product.
The instructions are addressed to the following persons:
•Operator
Read the instructions completely before working with the product.
Understand the instructions before working with the product.
Ensure that the instructions are accessible with the product at all times.
1.3 Changes and copyright
The text, graphics, and data contained here represent the technical status of the product at the time
of printing of this manual. Changes due to further development may occur. The original version of this
document is in German (DE).
This manual, including all parts thereof, are protected by copyright law. Utilization of any kind, wheth-
er for duplication, translation, or processing in other media, is not permissible without the consent of
Belimed AG. The content of this manual must not be used for commercial purposes.
1.4 Symbols and notices used
The following symbols and notices are used to indicate precautionary measures for handling and for
occupational safety that are important to avoid harm to health and life.
DANGER
Indicates hazard with high risk
If the hazard is not avoided, it will lead to death or serious injury.
Possible consequences of the hazard.
Work steps to avoid the hazard.
WARNING
Indicates hazard with medium risk
If the hazard is not avoided, it can lead to death or serious injury.
Possible consequences of the hazard.
Work steps to avoid the hazard.

Rack for containers WD 200 | © Belimed Introduction
001 5 | 18
CAUTION
Indicates hazard with low risk
If the hazard is not avoided, it will lead to minor or moderate injury.
Possible consequences of the hazard.
Work steps to avoid the hazard.
NOTICE
Warning of damage to property
If warnings are not heeded, this can lead to damage to the product or nearby objects.
Possible consequences of the warning.
Work steps to avoid damage to property.
TIP
Tips for use
Tips for use and useful information on the best possible utilization.
Helpful action.
Work step, perform in sequence.
Partial work step, perform according to sequence.
– Reaction to the completed work step.
–
– Reaction to all work steps.
1Position numbers that refer to diagrams.
2
• Indicates a list.
• Indicates a subsection of a list.
•
‹ › indicates a software text and proper noun.

Rack for containers WD 200 | © Belimed
6 | 18 001
2 Safety instructions
2.1 Declaration of conformity
With the EC Declaration of Conformity and the CE mark, Belimed AG affirms that this product com-
plies with the essential health and safety requirements.
2.2 General safety instructions
The machine and accessories may only be operated in faultless condition, which is why the following
safety instructions must be complied with to avoid risks to patients and operators.
2.2.1 Instructing Personnel
Only allow trained and authorized personnel to operate the machine and auxiliaries.
Wear the required personal protective equipment, e.g., protective goggles, protective gloves,
while operating the machine and during inspections and cleaning work.
Keep body parts and clothing away from automatically moving parts.
Always mop up and dry wet floors immediately.
In case of eye or skin contact with escaping fluids or steam, immediately rinse with clear water
and consult a doctor.
2.2.2 Loading
Wear the required personal protective equipment, e.g., protective goggles and protective gloves,
when handling the wash items.
Use the appropriate loading and unloading equipment for transporting, loading, and unloading the
wash items.
Take care when transporting the wash items after completion of the cleaning process. The wash
items and the racks are hot. Wear protective gloves and apron when loading or unloading.
Observe recommended loading heights.
Make sure that all medical devices to be cleaned can be optimally rinsed on all sides by the water.
Observe the loading pattern defined in the scope of the validation.
2.2.3 Resolve the error and repair
If errors or damage occur, the supervisor must be informed.
Errors may only be resolved by Belimed-Service or personnel trained and authorized by
Belimed AG.
Do not perform any unauthorized repairs, changes, or manipulation in or on the product.
2.2.4 Servicing the rack
Allow the rack to cool down prior to implementation of inspection and cleaning work.
Extensive maintenance work may only be performed by personnel trained and authorized by Be-
limed AG.
2.3 Intended use
The rack is intended for use with washer-disinfectors only. The rack is only intended and approved
for the applications specified in this Loading Manual, namely for the cleaning and disinfection of:

Rack for containers WD 200 | © Belimed Safety instructions
001 7 | 18
• DIN sterilization containers
• AESCULAP Aicon®sterilization containers
All other applications are considered to be non-intended use.
Use suitable transport carts.
Coordinate the sizes of the sterilization containers and the racks with each other.
Table 2-1 External dimensions and number of sterilization containers
2.4 Warranty
The product must only be installed and commissioned by personnel employed by Belimed AG or per-
sonnel who have been trained by Belimed AG. Belimed AG accepts no responsibility for work per-
formed by personnel neither directly employed by Belimed AG, nor trained by Belimed AG.
No repairs or modifications in or on the product must be carried out by non-authorized personnel.
Unauthorized repairs and modifications exclude any liability of the manufacturer for resulting damage
to the operator and the product. Furthermore, modifications that affect operation may violate local
laws and jeopardize insurance coverage in the event of malfunction.
Repairs and modifications must only be carried out by personnel either directly employed by
Belimed AG or trained by Belimed AG. Improperly executed repairs and modifications can entail con-
siderable danger to both patient and operator; moreover, such actions will void the warranty claim.
Furthermore, no warranty service is provided for defects caused by non-compliance with these in-
structions, improper use or normal wear and tear of the product.
Defective components must only be replaced by original spare parts from Belimed. Only if original
spare parts are used can it be ensured that the spare parts meet safety requirements. If spare parts
are used that neither originate from Belimed AG, nor have not been approved by Belimed AG, the
warranty is rendered void.
2.5 Personnel requirements
The operating facility must ensure that this product is only operated by trained persons.
Operators must have the following knowledge:
• Authorized by the operating facility.
• Responsibilities clearly defined by the operating facility.
• Appropriately trained.
• Thoroughly familiarized with the product.
• Demonstrated required technical expertise.
• Necessary prerequisites and required means to properly execute the tasks.
• Read and understood these instructions in full.
The operating facility clearly defines responsibilities for the operation, inspection, and cleaning work.
The operating facility regularly checks compliance with the responsibilities.
Non-compliance may lead to hazards for patients and operators.
Height [mm] Depth [mm] Width [mm] Sterilization containers
per rack [units]
185 600 300 2

Safety instructions Rack for containers WD 200 | © Belimed
8 | 18 001
2.6 Summary of the safety instructions
Summary of all safety instructions for safe operation of the product.
Safety instructions are listed in all places where hazards may arise.
Always follow the safety instructions!
Read, understand, and follow the safety instructions.
DANGER
Risk of infection due to contaminated racks
The rack can be contaminated by the last work processes.
Wear personal protective equipment, e.g., protective gloves.
Disinfect the entire rack before disposal.
If there are technical defects, a manual chemical disinfection must be carried out.
WARNING
Risk of infection due to incorrect reprocessing
Incorrect reprocessing of the medical devices leads to an inadequate cleaning result, entailing an in-
fection hazard.
It is obligatory to observe the reprocessing instructions of the medical device manufacturer.
Only prepare devices that have been recommended and released by the manufacturer for repro-
cessing in the washer-disinfector.
WARNING
Risk of infection due to soiled wash items
Contaminated wash items can lead to life-threatening infections.
Wear the required personal protective equipment, e.g., protective goggles, protective gloves, etc.
Follow local work instructions.
WARNING
Risk of infection due to residues
Residual contamination can lead to infections.
Wear the required personal protective equipment, e.g., protective goggles, protective gloves, etc.,
while performing inspection and cleaning work.

Rack for containers WD 200 | © Belimed Safety instructions
001 9 | 18
WARNING
Risk of infection due to irregular maintenance
For safe and reliable operation, regular maintenance by Belimed-Service is required.
Have regular maintenance work carried out by Belimed-Service.

Rack for containers WD 200 | © Belimed
10 | 18 001
3 Description
Fig. 3-1 Rack
1 Handle
2 Rotating nozzle
3 Roller
4 Coding magnet (option)
3.1 Option
Coding magnets are optionally included with the rack.
Manually install coding magnets depending on the load.
1
2
34

Rack for containers WD 200 | © Belimed
001 11 | 18
4 Loading
WARNING
Risk of infection due to soiled wash items
Contaminated wash items can lead to life-threatening infections.
Wear the required personal protective equipment, e.g., protective goggles, protective gloves, etc.
Follow local work instructions.
WARNING
Risk of infection due to irregular maintenance
For safe and reliable operation, regular maintenance by Belimed-Service is required.
Have regular maintenance work carried out by Belimed-Service.
CAUTION
Risk of infection due to inadequate pre-cleaning
Inadequate pre-cleaning can lead to deficient reprocessing.
Prior to loading for thermal disinfection, ensure that all manual pre-cleaning steps have been care-
fully carried out according to the description in the instructions for use of the manufacturer.
NOTICE
Risk of damage due to incorrect loading and unloading
Incorrect loading and unloading of the machine can lead to damage.
Follow the user manual for the machine.
Follow the loading manual for the rack.

Loading Rack for containers WD 200 | © Belimed
12 | 18 001
Fig. 4-1 Example of loading of sterilization container
1 Fixing tube (option)
2 Trough
3 Cover
Loading sterilization containers
Load 2 troughs 2.
Place the troughs 2on their short sides.
Place troughs 2with the openings facing each another in front of the rotating nozzles.
Secure the troughs 2with the fixing tube 1(option).
– The rotating nozzle sprays into the openings of the troughs 2.
Load 2 covers 3.
Place the covers 3on their short sides.
Position the covers 3at an angle with their insides facing downward.
– Liquids drain away.
1
3
2

Rack for containers WD 200 | © Belimed
001 13 | 18
5 Maintenance and cleaning work
WARNING
Risk of infection due to residues
Residual contamination can lead to infections.
Wear the required personal protective equipment, e.g., protective goggles, protective gloves, etc.,
while performing inspection and cleaning work.
CAUTION
Burn hazard
At the end of a program, the rack can have a temperature of up to 80°C.
Allow the rack to cool down before removing it.
Fig. 5-1 Removing and installing rotation nozzles, rollers, and handles
1 Knurled screw
2Washer
3 Rotating nozzle
4 Rollers
5Washer
6 Clamping washer
7 Handle
1
2
3
4
56
7

Maintenance and cleaning work Rack for containers WD 200 | © Belimed
14 | 18 001
Cleaning the rotating nozzle
Unscrew the knurled screw 1.
Remove the washer 2.
Pull out the rotating nozzle 3.
Clean the rotating nozzle 3.
Check for possible clogging.
If necessary, remove soiling with a suitable tool, e.g., a brush or needle.
Rinse with water.
Clean the knurled screw 1.
Clean the washer 2.
Replace the rotating nozzle 3if there is significant damage.
Install in the reverse order after cleaning.
Cleaning the 8 rollers
Remove the clamping washer 6.
Remove the washer 5.
Pull off the roller 4.
Clean the roller 4.
If necessary, remove soiling with a suitable tool, e.g., a brush or needle.
Rinse with water.
Clean the clamping washer 6.
Clean the washer 5.
Replace the roller 4if there is significant damage.
Install in the reverse order after cleaning.
Check that the roller 4moves freely.
Cleaning the 2 handles
Pull off the handle 7.
Clean the handle 7.
If necessary, remove soiling with a suitable tool, e.g., a brush or needle.
Replace the handle 7if there is significant damage.
Install the handle 7after cleaning.

Rack for containers WD 200 | © Belimed Maintenance and cleaning work
001 15 | 18
5.1 Optimize cleaning performance
WARNING
Risk of infection due to soiled wash items
Contaminated wash items can lead to life-threatening infections.
Wear the required personal protective equipment, e.g., protective goggles, protective gloves, etc.
Follow local work instructions.
WARNING
Risk of infection due to incorrect reprocessing
Incorrect reprocessing of the medical devices leads to an inadequate cleaning result, entailing an in-
fection hazard.
It is obligatory to observe the reprocessing instructions of the medical device manufacturer.
Only prepare devices that have been recommended and released by the manufacturer for repro-
cessing in the washer-disinfector.
Optimizing cleaning performance
Select the correct program for the wash items.
Ensure the wash items are appropriate for the rack as described in Chapter 2.3 «Intended use».
Clean the rotating nozzles daily as described in Chapter 5 «Maintenance and cleaning work».
Check the docking of the rack in the machine.
Pre-treat the wash items correctly.

Rack for containers WD 200 | © Belimed
16 | 18 001
6 Disposal
DANGER
Risk of infection due to contaminated racks
The rack can be contaminated by the last work processes.
Wear personal protective equipment, e.g., protective gloves.
Disinfect the entire rack before disposal.
If there are technical defects, a manual chemical disinfection must be carried out.
Dispose of the rack in a technically correct manner in accordance with the local regulations.
TIP
Re-using raw materials
The product is no worthless waste material. If disposed of appropriately, the raw materials can be re-
covered and recycled.
Re-use raw materials or dispose of properly.
Follow local specifications.

Rack for containers WD 200 | © Belimed Disposal
001 17 | 18

Belimed AG | Grienbachstrasse 11 | 6300 Zug | Switzerland | [phone] | [phone] | www.belimed.com
OBJ_DCL-0000001018-001.dcl EN-US
