Introduction
Thank you for purchasing the Powerline AV Networking Adapter
(the Adapter). Most people don’t enjoy buying long and expensive
Ethernet cables or pulling the cables from one place to another, but
the Adapter offers one of the easiest ways to enjoy home or small-
business networking. Users can now experience a total network
solution with the Adapter. The Powerline AV Networking Adapter
operates on the HomePlug®Powerline Specification 2.0 standard,
providing up to 200Mbps* bandwidth over home AC wiring. Since
the home power lines are the most pervasive medium in households
with multiple outlets in every room, the Adapter allows multiple
home desktop and notebook computers to be networked to share
an Internet connection, printers, and files, and play games without
any additional wiring. The advanced signal processing is capable
of maintaining coverage throughout the entire house, even across
different phase rings.
The installation of the Adapter only requires that a 10/100Mbps
network adapter is installed on the computers. This makes the
Powerline AV Networking Adapter compatible with any device,
including Mac, Windows, and UNIX machines.
For security, all HomePlug devices are equipped with 128-bit AES
encryption. The private home power grid plus encryption makes
HomePlug significantly more secure than competing technologies.
The Powerline AV Networking Adapter provides the best solution for
no-new-wires home networking. With easy plug-and-play installation,
and the reliability of HomePlug Ethernet’s products, the Powerline AV
Networking Adapter is the best solution for high-speed networking.
Features
• Upto200Mbps*bandwidthoverstandardhomepowerlines
• HomePlugsignaleasilypassesthroughcircuitbreaker
• 128-bitAESencryptionensuresdatasecurity
• Encryptioncompletedbyhardware,withoutsacrificeto
bandwidth
• UsesIEEE802.3computerinterface
• Plug-and-playinstallation
• HomePlugPowerlineSpecification2.0-compliant
• CoexistencewithHomePlug1.0and1.0Turbonetworks

2
32
Product Specifications
ComputerInterface:IEEE802.3/802.3u
OperatingTemperature:32–104degreesF(0–40degreesC)
StorageTemperature:-4–176degreesF(-20–80degreesC)
Humidity:Max.5%–90%(non-condensing)
*The standard transmission rate—200Mbps—is the physical data rate.
Actual data throughput will be lower.
Introduction

2
section
32
Introduction
Power LED
 SolidBlue–Connectedtopowerline
 Off–Poweroff
 BlinkingBlue–Encryptionsettingup
 SolidBlue–Encryptionsetupsuccessful
 DoubleFlash–Failinencryption
Powerline Link LED
 Blinking–Powerlinedatatransmittingorreceiving
 ColorBlue–Linkrateexcellent:greaterthan80Mbps
 ColorAmber–Linkratelow:0–80Mbps
 Off–Noactivity
Ethernet Link LED
 SolidBlue–10/100Mbpsportlinked
 Off–NoEthernetlink
System Requirements
• Atleast2HomePlugdevices
• AvailableEthernetportoneachcomputerornetworkdevice
• Availablepoweroutlet
• Standardhomepowerlinewiring
• CD-ROMdrive
Package Contents
• One/TwoPowerlineAVNetworkingAdapters
• HomePlugQuickInstallationGuide
• HomePlugUserManual(onCD)
• CD-ROM
• LimitedWarrantyCard
• One/TwoPowerCables
• One/TwoCAT5/RJ45EthernetCables
• One/TwoWallPlugAdapters

44 54
Overview
Installation of the Powerline AV Networking Adapter takes only
seconds and does not require setting up long wires throughout the
house. Simply plug the units directly into any available wall outlet and
connect to any device with an Ethernet port. Users have the option to
randomly change the security password for their powerline network.
Hardware Setup
1. Plugyournetworkcableintothecomputer’sRJ45networkadapter
port.
2. PlugtheotherendofyournetworkcableintotheRJ45port
located at the back of the Adapter.
3. Plugthepowercableorwalladapterintothepowerconnectorat
the back of the Adapter.
4. Insert the power plug of your power cable or wall adapter directly
into a power outlet in the wall.
NOTE: Do not plug the device into a UPS or power strip with surge protection.
The Adapter has its own power filter for protection against surges.
5. RepeatthisprocessforthesecondAdapter
Installing and Setting Up the Adapters

4
4 54
section
Configuration
Overview
The Adapter uses 128-bit AES encryption to block access from the outside. By
default, the protection is enabled. However, it is recommended that you change
the default network password with the “Encryption” button located on the units.
Changing the Network Password
1. With both Adapters plugged into
the wall, press the “Encryption”
button on the first unit for 10
seconds. The password on this
Adapter has now been changed
to a random value.
2. Next, press the “Encryption”
button on this unit for more than
0.5 seconds, but less than three
seconds.
3. Withintwominutes,pressthe
“Encryption” button on the
second unit for more than 0.5
seconds, but less than three
seconds.
4. The new network password has now been saved to the second unit. The
password will not be lost, even if the Adapters are unplugged from the wall.
Adding Another Adapter to the Network
1. If the default network password has been changed, a new Adapter will
have to load the new password before it can join the network.
2. Press the “Encryption” button on an encrypted unit for more than 0.5
seconds, but less than three seconds.
3. Withintwominutes,pressthe“Encryption”buttononthenewunitformore
than 0.5 seconds, but less than three seconds.
4. The new device has now been loaded with the network password and
added to the current powerline network
Resetting to Factory Defaults
Usingapointedobject,pressandholdthe“Reset”buttonforonesecondtorestore
defaults. This procedure resets the network password to the default out-of-box
value.
Encryption
Reset

676
Technical Support
You can find technical-support information on our website,
www.belkin.com, by navigating to the tech-support section.
If you want to contact technical support by phone, please call the
number you need from the list below*.
*Localratesapply.
Country Number Internet adress
AUSTRIA 0820200766 http://www.belkin.com/uk/networking/
BELGIUM 070700073 http://www.belkin.com/nl/networking/
CZECHREPUBLIC 239000406 http://www.belkin.com/uk/networking/
DENMARK 70122403 http://www.belkin.com/uk/networking/
FINLAND 00800-22355460 http://www.belkin.com/uk/networking/
FRANCE 08-25540026 http://www.belkin.com/fr/networking/
GERMANY 0180-5005709 http://www.belkin.com/de/networking/
GREECE 00800-44142390 http://www.belkin.com/uk/networking/
HUNGARY 06-17774906 http://www.belkin.com/uk/networking/
ICELAND 8008534 http://www.belkin.com/uk/networking/
IRELAND 0818555006 http://www.belkin.com/uk/networking/
ITALY 02-69430251 http://www.belkin.com/it/networking/
LUXEMBOURG 3420808560 http://www.belkin.com/uk/networking/
NETHERLANDS 0900-0400790
€0.10 per minute http://www.belkin.com/nl/networking/
NORWAY 81 50 0287 http://www.belkin.com/uk/networking/
POLAND 00800-4411737 http://www.belkin.com/uk/networking/
PORTUGAL 707200676 http://www.belkin.com/uk/networking/
RUSSIA 4955809541 http://www.belkin.com/networking/
SOUTHAFRICA 0800-991521 http://www.belkin.com/uk/networking/
SPAIN 902-024366 http://www.belkin.com/es/networking/
SWEDEN 07-71400453 http://www.belkin.com/uk/networking/
SWITZERLAND 08-48000219 http://www.belkin.com/uk/networking/
UNITEDKINGDOM 0845-6077787 http://www.belkin.com/uk/networking/
OTHERCOUNTRIES +44-1933352000
