Belkin F5U015-TPW User manual

1
P73276 F5U015-TPW
USB SCSI Adapter
with Termpower

Introduction and System Requirements
1
Thank you for purchasing the Belkin Components®USB-SCSI
Adapter. Now, you can easily add up to 7 SCSI devices on
your Windows®98 PC, or Mac™through USB port! No more
opening your computer case, no more IRQ conflicts or driver
problems! Simply plug it in!
Your PC must have:
• 486 processor or faster
• 16MB memory or more
• A free USB port (on the computer
or at a hub)
• Windows®98 or Windows®98 SE
Your Macintosh®must have:
• OS 8.6 or higher
• A free USB port (on the computer or at a hub)
Notes:
1. It is NOT recommended that you plug in the
USB-SCSI adapter to the USB ports on the
iMac™keyboard. The keyboard does not supply
enough power, and is a low-speed device.
2. If you own a non-iMac™machine and wish to add
USB ports, please obtain a Belkin USB BusPort™
for Mac®(model # F5U005-Mac®)
Your SCSI device must be able to supply termination power
to the USB SCSI Adapter. Some devices such as Iomega
Zip®Drives and some brands of scanners will not be able to
provide the required +5V termination power. In such an
event, a SCSI device that can provide termination power
must be connected to the device chain or you can use the
power supply adapter supplied with the package.
If you are going to plug the USB-SCSI Adapter into a USB
Hub, make sure that it is a self-powered hub.
(A self-powered hub has its own power supply.)

Package Contents
2
• Belkin Components®USB SCSI Adapter withTermpower
• CD containing both Windows®and Macintosh®drivers
• Power supply adapter (7.5VDC, 600mA) with DB25 adapter
• Registration card
• This manual

Macintosh®Installation and Usage
3
MACINTOSH®INSTALLATION:
1. Insert the Belkin USB to SCSI Adapter with Termpower CD
into your CD-ROM drive. Double-click on the CD icon.
You will see two folders: MAC®Driver and PC Driver.
Double click on the "MAC®Driver" folder. Now, you will
see two files named:
"Belkin USB-SCSI"
"Belkin USB-SCSI SIM"
2. Double click on your "Hard Drive" icon and look for
"System Folder". Double click on "System Folder".
3. In "System Folder", look for another folder called
"Extensions". Once you have located the "Extensions"
folder, you will need to select the two files in the Belkin
USB to SCSI CD (see #1 above), and drag the two files
onto the "Extensions" folder. You will see your system
copying both files over.
USAGE:
1. When copying is finished connect your SCSI device or
device chain to the USB SCSI Adapter. See appendices for
adapters and cables you may need. Make sure that the
devices are powered up.
Plug in the USB SCSI Adapter to a free USB port on your
computer, or USB Hub. Restart your computer. To do this
click on "Special" at the top menu bar, and choose "Restart".
2. After restart, icons of your SCSI device(s) should appear
on your desktop.

4
Note: If you unplug the USB SCSI Adapter from the
computer, or the device(s) from the SCSI chain,
the operating system may not recognize this and
might think that the device(s) are still connected. In
the event that the device(s) and/or the USB-SCSI
Adapter is unplugged from the computer, and an
application tries to access the device(s), your
computer will hang. You must cycle power in order
to recover your system.
Hence, to disconnect a device from the SCSI chain,
always drag its icon to the TRASH first, then
disconnect the USB SCSI Adapter or devices.
Macintosh®Installation and Usage (continued)

Windows®98 Installation and Usage
5
WINDOWS®98 INSTALLATION:
1. Connect your SCSI device or device chain to the
USB SCSI Adapter. See appendices for adapters and
cables you may need. Make sure that the device(s) are
powered up.
2. Plug in the USB SCSI Adapter to a free USB port on
your computer, or USB Hub. A "New Hardware
Found…" dialog box will appear:
Click on NEXT.
Note: Even if the Adapter is plugged into your USB
port (or Hub), it must first be plugged into a SCSI
device that provides termination power, before
Windows®will detect and enumerate the
Adapter, and the SCSI device(s). If your SCSI
device(s) does not provide termination power,
make sure the power supply adapter that came
with the package is connected.

Windows®98 Installation and Usage (continued)
6
3. On the screen that appears select "Search for the best
driver for your device (Recommended)", and then
click Next.
4. Windows®will now prompt you for drivers. Insert the
Belkin USB SCSI Adapter CD-ROM in your CD-ROM
drive. Put a check mark at the box named "Specify a
location:". Type D:\PC Driver. (In this example, D is the
driver letter for the CD-ROM drive; it may be different on
your computer, you may need to check it.) Click Next.

Windows®98 Installation and Usage (continued)
7
5. Windows®will automatically find and install the drivers
from the CD-ROM, and display the next dialog box,
confirming it has loaded the correct files:
Click on NEXT.
6. Lastly, Windows®will display this final dialog box.
Click FINISH.
Windows®will then detect the "USB Mass Storage
Class Adapter", and automatically install its drivers.
There will be no more prompts.

Appendices
8
Troubleshooting
The SCSI device(s) connected to the USB-SCSI Adapter is
not detected by my computer.
• Make sure the SCSI device(s) are powered up and at
least one device provides termination power necessary
for the Adapter’s operation. If you are just connecting
one device and that device does not have termination
power, make sure the power supply adapter provided
with the package is connected. The SCSI device(s) must
be powered up AND connected to the Adapter prior to
plugging into the USB port.
• If you are using a USB Hub or composite device that
has a built-in hub, make sure that the device is
self-powered, providing the full 500mA of current
required by the Adapter.
• After shutting down your computer, try unplugging then
plugging in the Adapter from the USB port.
• Try unplugging the Adapter, turn the power off and back
on of the SCSI device(s), then plugging the Adapter back
into the USB port.
• Restart your computer with the Adapter connect to the
USB port, and all the SCSI device(s) powered up.

Belkin External SCSI Cross-Reference Table
This is only a partial listing of our most common SCSI Cable Assemblies. Contact your
Belkin sales representative for assistance in choosing the cable you need.
9

Belkin USB to SCSI Uninstall
To uninstall the USB to SCSI Adapter,
do the following:
Note: Do not unplug the Belkin USB to SCSI from the
computer until completing the following.
A. For PC
1. Right click on the "My Computer" icon on your desktop.
Select “Properties” then “Device Manager”. Look for
"Universal serial bus controller", click on the "Plus" sign
beside it, highlight "Belkin eUSB SCSI Adapter" then
click Remove. Click OK. Close Device Manager.
2. Click on Start/Find/Files and Folders. Under "Named"
type Bel*.*, under "Look In" put it on the C drive then
click on "Find Now". Delete all the four items that will
appear namely: Beluscsi.sys, Belsmsd.pdr, Belsmsd, and
Belkin Component….
3. You can now unplug the Belkin USB to SCSI adapter from
the computer. Restart your computer.
B. For Mac
1. Double click on your "Hard Drive" icon and look for
"System Folder”/Double click on "System Folder".
2. In "System Folder", look for another folder called
"Extensions". Under "Extensions" look for the following
files: "Belkin USB-SCSI" and "Belkin USB-SCSI SIM".
Drag these 2 files to the Trash Bin.
3. You can now unplug the Belkin USB to SCSI adapter from
the computer. Restart your computer.
10

Information
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Components, of 501 West Walnut Street, Compton CA 90220,
declare under our sole responsibility that the product:
F5U015-TWP
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operation.
CE Declaration of Conformity
We, Belkin Components, declare under our sole responsibility that the F5U105-TWP, to
which this declaration relates, is in conformity with Generic Emissions Standard EN50081-1
and with Generic Immunity Standard EN500A1-1 1992.
Belkin Components Limited Lifetime Product Warranty
Belkin Components warrants this product against defects in materials and workmanship for
its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at
no charge provided it is returned during the warranty period, with transportation charges
prepaid, to the authorized Belkin dealer from whom you purchased the product. Proof of
purchase may be required.
This warranty does not apply if the product has been damaged by accident, abuse, misuse,
or misapplication; if the product has been modified without the written permission of Belkin;
or if any Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS,
WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS
ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
No Belkin dealer, agent, or employee is authorized to make any modification, extension,
or addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER
LEGAL THEORY, INCLUDING BUT NOT LIMITED TO LOST PROFITS, DOWNTIME,
GOODWILL, DAMAGE TO OR REPROGRAMMING, OR REPRODUCING ANY PROGRAM
OR DATA STORED IN OR USED WITH BELKIN PRODUCTS.
Some states do not allow the exclusion or limitation of incidental or consequential damages
or exclusions of implied warranties, so the above limitations of exclusions may not apply to
you. This warranty gives you specific legal rights, and you may also have other rights that
vary from state to state.

Compatibility List
A. Devices that work Stand-alone
"SCSI Hard Drives
• Seagate ST31220A - 2GB
• Seagate ST51080N - 1GB
• Microtech P-E-2000 - 2GB
"SCSI Removable Media Drives
• Coniglio MO 230MB ( FujitsuDrive M2512A )
• Fujitsu 640 Dyna MO - M2513A - F/W: 1300
• Fujitsu 640 Dyna MO SE - M2513EL - F/W: 0010
• Iomega Jaz - 1 GB F/W J.66
• Iomega Jaz - 2GB F/W E.17
• Olympus 640 MO - S350 - F/W: 1.20
• SCSI - Panasonic PD device - LF 1000
• SyQuest SQ270 - 270MB
"SCSI CDD\CDR\CD-Changer
• Sony 4X - CDU 76S SCSI CDD F/W 1.0a.
• NAKAMICHI 4 tray CD-Changer - MJ 4.8
• NEC Multispin 4x - 7 tray CD-Changer - NRC MBR - 7.4
• Sanyo CRD-254S F/W 1.02
• Philips Omniwriter26 (Ricoh) F/W 2.03
• Sony CDR CDU948S F/W 1.0h
• Philips CDD2600 F/W 1.07
• Plextor DX-327S F/W 1.02
• Teac CD-532S 1.0a
"SCSI Tape drives
• Exabyte 8585S F/W 06M0
• Conner-TR4 CTT- 8000IS F/W 1.17
• HO-C1533A F/W 9503
• Microtech MicroDAT 8000

Compatibility List (cont.)
"SCSI Scanners
• HP 5P C5110A F/W 3638
• Pixelcraft Pro Image 2400 Scanner
• UMAX ProLook 2000
"Other
•Microtech Digital PhotoAlbum - PC Card Reader
• Microtech Digital PhotoAlbum.p - PC Card Reader
• Microtech Digital PhotoAlbum Pro - PC Card Reader
• SCM Microsystems (Intermart) PCD-10
• SCM Microsystems (Intermart) PCD-15
• SCM Microsystems (Intermart) PCD-25
B. Devices that work on a SCSI chain/or may require the
included power adapter and DB25 adapter
"SCSI Hard Drives
•Seagate ST31220A - 2GB
• Seagate ST51080N - 1GB
• Microtech P-E-2000 - 2 GB
"SCSI Removable Media Drives
• Iomega Jaz - 1 GB F/W J.66
• Iomega Jaz - 2GB F/W E.17
• Iomega Zip 100 (SCSI) F/W J.66
• Fujitsu 640 Dyna MO - M2513A - F/W: 1300
• Fujitsu 640 Dyna MO SE - M2513EL - F/W: 0010
• Olympus 640 MO - S350 - F/W: 1.20
• SCSI - Panasonic PD device - LF 1000

Compatibility List (cont.)
• SyQuest SQ270 - 270MB
"SCSI CDD\CDR\CD-Changer
•Sony 4X - CDU 76S SCSI CDD F/W 1.0a.
• NAKAMICHI 4 tray CD-Changer - MJ 4.8
• NEC Multispin 4x - 7 tray CD-Changer - NRC MBR - 7.4
• Sanyo CRD-254S F/W 1.02
• Philips Omniwriter26 (Ricoh) F/W 2.03
• Sony CDR CDU948S F/W 1.0h
• Philips CDD2600 F/W 1.07
• Plextor DX-327S F/W 1.02
• Teac CD-532S 1.0a
"SCSI Tape drives
•Exabyte 8585S F/W 06M0
• Conner-TR4 CTT- 8000IS F/W 1.17
• HO-C1533A F/W 9503
• Microtech MicroDAT 8000
"SCSI Scanners
•HP 5P C5110A F/W 3638
• Pixelcraft Pro Image 2400 Scanner
• UMAX Power Look 2000
"Other
• Microtech Digital PhotoAlbum - PC Card Reader
• Microtech Digital PhotoAlbum.p - PC Card Reader
• Microtech Digital PhotoAlbum Pro - PC Card Reader
• SCM Microsystems (Intermart) PCD-10
• SCM Microsystems (Intermart) PCD-15

Compatibility List (cont.)
• SCM Microsystems (Intermart) PCD-25
C. Currently incompatible devices
"Nikon LS-2000 Film Scanner (Super Coolscan 2000)
"Microtech Digital PhotoAlbum_P (Old MP01625)
"Microtech Digital PhotoAlbum (Old MP01610A)
"UMAX Power Look III

Belkin Components B.V.
Diamantlaan 8 • 2132 WV
Hoofddorp • The Netherlands
Tel: [phone]
Fax: [phone]
Belkin Components, Ltd.
Unit 13 • Gatelodge Close • Round Spinney
Northampton • Northants • NN3 8RX • UK
Tel: [phone]
Fax: [phone]
belkin.com
Belkin Components
501 West Walnut Street
Compton • CA • 90220 • USA
Tel: [phone]
Fax: [phone]
© 2000 Belkin Components. All rights reserved. All trade names are registered trademarks of
respective manufacturers listed.
