Belkin F8Z439ea TuneCast User manual

TuneCast®Auto Universal
User Manual
8820cw00176 F8Z439ea
ENGLISH
FRANÇAIS
DEUTSCH
NEDERLANDS
ESPAÑOL
ITALIANO
PORTUGUÊS
РУССКИЙ
8820cw00176_F8Z439ea.indb 1 30/11/2009 14:05:15

TuneCast®Auto Universal i
SECTIONS 1 2 3 6 754Ta b l e o f C o n t e n t s
TABLE OF CONTENTS
1 Introduction ....................................................................1
2 Connecting Your TuneCast Auto.................................................2
3 Selecting an FM Frequency......................................................3
Using ClearScan to Select the Best FM Frequency (recommended) ................3
Manually Selecting an FM Frequency..............................................4
Storing and Selecting a Frequency ................................................4
4 Using the PRO Setting to Improve Performance .................................5
Listening to Mono Recordings ....................................................6
5 Getting the Most Out of TuneCast Auto .........................................7
Optimizing the Sound Quality of Your TuneCast Auto .............................7
6 Safety Warnings.................................................................8
7 Information .....................................................................9
8820cw00176_F8Z439ea.indb 1 30/11/2009 14:05:15

TuneCast®Auto Universal EN-1
SECTIONS 2 3 6 754Ta b l e o f C o n t e n t s 1
INTRODUCTION
Your TuneCast Auto is designed to transmit audio from your MP3 music device, including
iPod, to your car stereo, and to provide charging from the built-in USB port (charging cable
not included). Please review this User Manual carefully so that you can get the most from your
TuneCast Auto, virtually anywhere you go.
8820cw00176_F8Z439ea.indb 1 30/11/2009 14:05:15

TuneCast®Auto Universal EN-2
SECTIONS 1 3 6 754Ta b l e o f C o n t e n t s 2
CONNECTING YOUR TUNECAST AUTO
1. Turn down your stereo’s volume.
2. Connect your TuneCast Auto to the cigarette lighter or power outlet in your vehicle.
3. Connect your MP3 music device to your TuneCast Auto.
Note: Your TuneCast Auto will automatically turn off if no audio plays for approximately 60
seconds for European versions, but it will automatically turn on again when it detects audio from
your MP3 music device.
8820cw00176_F8Z439ea.indb 2 30/11/2009 14:05:16

TuneCast®Auto Universal EN-3
SECTIONS 1 2 6 754Ta b l e o f C o n t e n t s 3
SELECTING AN FM FREQUENCY
You can use ClearScan to find a frequency and match it to your stereo, or you can find a
frequency on your stereo and match your TuneCast Auto to the same frequency.
Using ClearScan to Select the Best FM Frequency (recommended)
Your TuneCast Auto uses ClearScan technology to scan for the clearest FM frequency in
your area.
1. Press the “ClearScan” button. Your TuneCast Auto will display the best frequency.
2. Tune your stereo to the frequency on your TuneCast Auto display.
Note: If you immediately press the “ClearScan” button when you turn on your TuneCast Auto,
it may take up to 30 seconds for ClearScan to locate the best frequency. If your audio signal
declines, just press “ClearScan” and the best FM frequency will instantly display.
8820cw00176_F8Z439ea.indb 3 30/11/2009 14:05:17

TuneCast®Auto Universal EN-4
SECTIONS 1 2 6 754Ta b l e o f C o n t e n t s 3
SELECTING AN FM FREQUENCY
Manually Selecting an FM Frequency
If you want to use a specific frequency, you can manually select it on your TuneCast Auto.
1. Tune your stereo to a frequency between stations. The ideal frequency is one not
broadcasting a radio station’s signal.
2. Press the + or - button on your TuneCast Auto to select the same frequency.
3. To identify the best available frequencies in your area, you can also visit:
www.belkin.com/mybestfm.
Storing and Selecting a Frequency
You can store two frequencies using the “m1” and “m2” buttons.
1. To store a frequency, select the desired frequency on your TuneCast Auto using the + or -
buttons. Press and hold the “m1” or “m2” preset button for two seconds. The “m1” or “m2”
icon will flash on the screen when the frequency is set.
2. To recall a preset frequency, press the “m1” or “m2” preset button. Your TuneCast Auto will
change to the preset frequency.
8820cw00176_F8Z439ea.indb 4 30/11/2009 14:05:17

TuneCast®Auto Universal EN-5
SECTIONS 1 2 3 6 75Ta b l e o f C o n t e n t s 4
USING THE PRO SETTING TO IMPROVE PERFORMANCE
Due to characteristics of FM transmission, you will experience better sound quality by adjusting
the volume on your car stereo when necessary, and by leaving your MP3 player volume at a
medium level.
You may be able to improve the audio performance of your TuneCast Auto by using the
PRO setting.
Normal – No change to the audio. This setting works well with all types of audio.
PRO 1 – Increases the average volume of the audio. This setting works well with most types
of music.
PRO 2 – Increases the average volume even further. This setting works well with quieter music,
but it may cause distortion with louder music.
– Increases the average volume and transmits in mono (instead of stereo). This setting
works well for podcasts and audio books. It can also be used to improve reception if you are not
receiving a clear signal from your TuneCast Auto.
When you press the “PRO” button, your TuneCast Auto will display the PRO setting. Pressing
the “PRO” button again will change the setting to PRO 1, PRO 2, and as follows:
OFF PRO 1 Pro 2
8820cw00176_F8Z439ea.indb 5 30/11/2009 14:05:17

TuneCast®Auto Universal EN-6
SECTIONS 1 2 3 6 75Ta b l e o f C o n t e n t s 4
USING THE PRO SETTING TO IMPROVE PERFORMANCE
Listening to Mono Recordings
Your TuneCast Auto transmits in stereo, but you can also transmit in mono if needed. We
suggest that you switch to mono transmission only if your car stereo is not receiving a clear
signal from the TuneCast Auto or if you are listening to a mono recording such as an audio book.
To switch to mono transmission, press the “PRO” button until “ ” is shown on the display.
The “PRO” button settings are as follows:
OFF PRO 1 Pro 2
8820cw00176_F8Z439ea.indb 6 30/11/2009 14:05:18

TuneCast®Auto Universal EN-7
SECTIONS 1 2 3 6 74Ta b l e o f C o n t e n t s 5
GETTING THE MOST OUT OF TUNECAST AUTO
Charging a Device
Your TuneCast Auto comes with a built-in USB charging port. Simply connect your device to the
USB charge port with the appropriate USB charging cable (charging cable not included). If your
device does not charge, make sure your TuneCast Auto is correctly connected to the cigarette
lighter outlet, and that the charge cable is securely connected to your device and the USB
charging port. The indicator light on the cigarette lighter adapter should be lit.
Note: Some vehicles do not provide power to the power outlet unless the vehicle is in ignition
mode or the engine is running.
Optimizing the Sound Quality of your TuneCast Auto
A variety of car radio and antenna configurations are available and you may optimize the sound
quality in your car based on the location of your TuneCast Auto (for example, placing the
TuneCast Auto on the center console may yield better performance than other locations within
your vehicle).
8820cw00176_F8Z439ea.indb 7 30/11/2009 14:05:18

TuneCast®Auto Universal EN-8
SECTIONS 1 2 3 754Ta b l e o f C o n t e n t s 6
SAFETY WARNINGS
Do not attempt to connect your TuneCast Auto while driving. Make sure your TuneCast
Auto fits securely and firmly into the power outlet before driving.
Do not attempt to adjust or retrieve an unsecured TuneCast Auto or MP3 music
device while driving. Position the TuneCast Auto so that both the TuneCast Auto and the MP3
music device do not interfere with any of the operating controls of the car.
Do not insert any objects other than the cigarette lighter adapter into the power outlet
without disconnecting the battery of the car first. Failure to observe this safety warning
can result in injury or property damage.
Belkin does not assume any responsibility for personal injury or property damage incurred due
to hazardous driving as a result of interaction with the TuneCast Auto, the MP3 music device, or
the vehicle’s power outlet.
8820cw00176_F8Z439ea.indb 8 30/11/2009 14:05:18

TuneCast®Auto Universal EN-9
SECTIONS 1 2 3 654Ta b l e o f C o n t e n t s 7
INFORMATION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthatwhichthereceiver
is connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Belkin International, Inc., is not responsible for any interference caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate
this equipment.
8820cw00176_F8Z439ea.indb 9 30/11/2009 14:05:18

TuneCast®Auto Universal EN-10
SECTIONS 1 2 3 654Ta b l e o f C o n t e n t s 7
INFORMATION
EU DECLARATION OF CONFORMITY
ýesky
[Czech]
[Belkin Ltd] tímto prohlašuje, že tento [F8Z439ea] je ve shodČ se základními požadavky a
dalšími pĜíslušnými ustanoveními smČrnice 1999/5/ES.
Dansk
[Danish]
Undertegnede [Belkin Ltd] erklærer herved, at følgende udstyr [F8Z439ea] overholder de
væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Deutsch
[German]
Hiermit erklärt [Belkin Ltd], dass sich das Gerät [F8Z439ea] in Übereinstimmung mit den
grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie
1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab [Belkin Ltd] seadme [F8Z439ea] vastavust direktiivi 1999/5/EÜ
põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
English Hereby, [Belkin Ltd], declares that this product [F8Z439ea] is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente [Belkin Ltd] declara que el [F8Z439ea] cumple con los requisitos
esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
ǼȜȜȘȞȚțȒ
[Greek]
ȂǼ ȉǾȃ ȆǹȇȅȊȈǹ [Belkin Ltd] ǻǾȁȍȃǼǿ ȅȉǿ [F8Z439ea] ȈȊȂȂȅȇĭȍȃǼȉǹǿ ȆȇȅȈ ȉǿȈ
ȅȊȈǿȍǻǼǿȈ ǹȆǹǿȉǾȈǼǿȈ Ȁǹǿ ȉǿȈ ȁȅǿȆǼȈ ȈȋǼȉǿȀǼȈ ǻǿǹȉǹȄǼǿȈ ȉǾȈ ȅǻǾīǿǹȈ 1999/5/ǼȀ.
Français
[French]
Par la présente [Belkin Ltd] déclare que l'appareil [F8Z439ea] est conforme aux exigences
essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
Italiano
[Italian]
Con la presente [Belkin Ltd] dichiara che questo [F8Z439ea] è conforme ai requisiti essenziali
ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo [Belkin Ltd Belkin Ltd ] deklarƝ, ka [F8Z439ea] / iekƗrtas tips] atbilst DirektƯvas 1999/5/EK
bnjtiskajƗm prasƯbƗm un citiem ar to saistƯtajiem noteikumiem.
Lietuviǐ
[Lithuanian]
Šiuo [Belkin Ltd] deklaruoja, kad šis [F8Z439ea] atitinka esminius reikalavimus ir kitas
1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart [Belkin Ltd] dat het toestel [F8Z439ea] in overeenstemming is met de
essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, [Belkin Ltd], jiddikjara li dan [F8Z439ea] jikkonforma mal-ƫtiƥijiet essenzjali u ma
provvedimenti oƫrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, [Belkin Ltd] nyilatkozom, hogy a [F8Z439ea] megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym [Belkin Ltd] oĞwiadcza, Īe [F8Z439ea] jest zgodny z zasadniczymi wymogami oraz
pozostaáymi stosownymi postanowieniami Dyrektywy 1999/5/EC.
Português
[Portuguese]
[Belkin Ltd] declara que este [F8Z439ea] está conforme com os requisitos essenciais e outras
disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
[I Belkin Ltd] izjavlja, da je ta [F8Z439ea] v skladu z bistvenimi zahtevami in ostalimi
relevantnimi doloþili direktive 1999/5/ES.
Slovensky
[Slovak]
[Belkin Ltd] týmto vyhlasuje, že [F8Z439ea] spĎĖa základné požiadavky a všetky príslušné
ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish]
[Belkin Ltd] vakuuttaa täten että [F8Z439ea] tyyppinen laite on direktiivin 1999/5/EY oleellisten
vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar Belkin Ltd] att denna [F8Z439ea] står I överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Íslenska
[Icelandic]
Hér með lýsir [Belkin Ltd] yfir því að [F8Z439ea] er í samræmi við grunnkröfur og aðrar kröfur,
sem gerðar eru í tilskipun 1999/5/EC.
Norsk
[Norwegian]
[Belkin Ltd] erklærer herved at utstyret [F8Z439ea] er i samsvar med de grunnleggende krav og
øvrige relevante krav i direktiv 1999/5/EF.
www.belkin.com/doc
8820cw00176_F8Z439ea.indb 10 30/11/2009 14:05:19

TuneCast®Auto Universal EN-11
SECTIONS 1 2 3 54Ta b l e o f C o n t e n t s 76
INFORMATION
Belkin International, Inc., Limited 3-year Product Warranty
What this warranty covers.
Belkin International, Inc. (“Belkin”) warrants to the original purchaser of this Belkin product that
the product shall be free of defects in design, assembly, material, or workmanship.
What the period of coverage is.
Belkin warrants the Belkin product for 3 years.
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product free of charge (except for
shipping charges for the product). Belkin reserves the right to discontinue any of its products
without notice, and disclaims any limited warranty to repair or replace any such discontinued
products. In the event that Belkin is unable to repair or replace the product (for example,
because it has been discontinued), Belkin will offer either a refund or a credit toward the
purchase of another product from Belkin.com in an amount equal to the purchase price of the
product as evidenced on the original purchase receipt as discounted by its natural use.
8820cw00176_F8Z439ea.indb 11 30/11/2009 14:05:19

TuneCast®Auto Universal EN-12
SECTIONS 1 2 3 54Ta b l e o f C o n t e n t s 76
INFORMATION
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not provided to Belkin for
inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin determines
that the Belkin product has been improperly installed, altered in any way, or tampered with.
The Belkin Product Warranty does not protect against acts of God such as flood, lightning,
earthquake, war, vandalism, theft, normal-use wear and tear, erosion, depletion, obsolescence,
abuse, damage due to low voltage disturbances (i.e. brownouts or sags), non-authorized
program, or system equipment modification or alteration.
How to get service.
To get service for your Belkin product you must take the following steps:
1. Contact Belkin Ltd Express Business park, Shipton Way, Rushden, NN106GL, United
Kingdom, Attn: Customer Service or call Free Tech Support (see last page), within 15 days of
the Occurence.
Be prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. Your Belkin Customer Service Representative will then instruct you on how to forward your
receipt and Belkin product and how to proceed with your claim.
8820cw00176_F8Z439ea.indb 12 30/11/2009 14:05:19

TuneCast®Auto Universal EN-13
SECTIONS 1 2 3 54Ta b l e o f C o n t e n t s 76
INFORMATION
Belkin reserves the right to review the damaged Belkin product. All costs of shipping the Belkin
product to Belkin for inspection shall be borne solely by the purchaser. If Belkin determines, in
its sole discretion, that it is impractical to ship the damaged equipment to Belkin, Belkin may
designate, in its sole discretion, an equipment repair facility to inspect and estimate the cost to
repair such equipment. The cost, if any, of shipping the equipment to and from such repair facility
and of such estimate shall be borne solely by the purchaser. Damaged equipment must remain
available for inspection until the claim is finalized. Whenever claims are settled, Belkin reserves
the right to be subrogated under any existing insurance policies the purchaser may have.
How state law relates to the warranty.
THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN. THERE ARE NO OTHER
WARRANTIES, EXPRESSED OR, EXCEPT AS REQUIRED BY LAW, IMPLIED, INCLUDING THE
IMPLIED WARRANTY OR CONDITION OF QUALITY, MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY, ARE LIMITED IN
DURATION TO THE TERM OF THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above
limitations may not apply to you.
IN NO EVENT SHALL BELKIN BE LIABLE FOR INCIDENTAL, SPECIAL, DIRECT, INDIRECT,
CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH AS, BUT NOT LIMITED TO, LOST
BUSINESS OR PROFITS ARISING OUT OF THE SALE OR USE OF ANY BELKIN PRODUCT,
EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
This warranty gives you specific legal rights, and you may also have other rights, which may
vary from state to state. Some states do not allow the exclusion or limitation of incidental,
consequential, or other damages, so the above limitations may not apply to you.
8820cw00176_F8Z439ea.indb 13 30/11/2009 14:05:19

TuneCast®Auto Universal EN-14
SECTIONS 1 2 3 54Ta b l e o f C o n t e n t s 76
INFORMATION
COUNTRY NUMBER INTERNET ADRESS
AUSTRIA 0820 200766 www.belkin.com/de/
BELGIUM 07 07 00 073 www.belkin.com/nl/
www.belkin.com/fr/
CZECH REPUBLIC 239 000 406 www.belkin.com/uk/
DENMARK 701 22 403 www.belkin.com/uk/
FINLAND 0972519123 www.belkin.com/uk/
FRANCE 08 - 25 54 00 26 www.belkin.com/fr/
GERMANY 0180 - 500 57 09 www.belkin.com/de/
GREECE 00800 - 44 14 23 90 www.belkin.com/uk/
HUNGARY 06 - 17 77 49 06 www.belkin.com/uk/
ICELAND 800 8534 www.belkin.com/uk/
IRELAND 0818 55 50 06 www.belkin.com/uk/
ITALY 02 - 69 43 02 51 www.belkin.com/it/
LUXEMBOURG 34 20 80 85 60 www.belkin.com/uk/
NETHERLANDS 0900 - 040 07 90 €0.10 per minute www.belkin.com/nl/
NORWAY 81 50 0287 www.belkin.com/uk/
POLAND 00800 - 441 17 37 www.belkin.com/uk/
PORTUGAL 707 200 676 www.belkin.com/uk/
RUSSIA 495 580 9541 www.belkin.com/
SOUTH AFRICA 0800 - 99 15 21 www.belkin.com/uk/
SPAIN 902 - 02 43 66 www.belkin.com/es/
SWEDEN 07 - 71 40 04 53 www.belkin.com/uk/
SWITZERLAND 08 - 48 00 02 19 www.belkin.com/de/
www.belkin.com/fr/
UNITED KINGDOM 0845 - 607 77 87 www.belkin.com/uk/
OTHER COUNTRIES +44 - 1933 35 20 00
You can find additional
support information
on our website www.
belkin.com through the
tech-support area. If you
want to contact technical
support by phone,
please call the number
you need from this list*.
Free Tech Support*
*National call rates may apply
www.belkin.com
8820cw00176_F8Z439ea.indb 14 30/11/2009 14:05:20

© 2009 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of
respective manufacturers listed.
8820cw00176
F8Z439ea
Belkin Tech Support
Europe: www.belkin.com/support
Belkin Ltd.
Express Business Park
Shipton Way, Rushden
NN10 6GL, United Kingdom
Belkin Iberia
C/ Anabel Segura, 10 planta baja, Of. 2
28108, Alcobendas, Madrid
Spain
Belkin SAS
130 rue de Silly
92100 Boulogne-Billancourt,
France
Belkin Italy & Greece
Via Carducci, 7
Milano 20123
Italy
Belkin GmbH
Hanebergstrasse 2
80637 Munich
Germany
Belkin B.V.
Boeing Avenue 333
1119 PH Schiphol-Rijk,
Netherlands
8820cw00176_F8Z439ea.indb 2 30/11/2009 14:05:20

TuneCast®Auto universel
Manuel de l'utilisateur
8820cw00176 F8Z439ea
ENGLISH
FRANÇAIS
DEUTSCH
NEDERLANDS
ESPAÑOL
ITALIANO
PORTUGUÊS
РУССКИЙ
8820cw00176_F8Z439ea.indb 1 30/11/2009 14:05:28

TuneCast®Auto universel i
SECTIONS 1 2 3 6 754Table des matières
TABLE DES MATIÈRES
1 Introduction.............................................................................1
2 Branchement du TuneCast Auto........................................................2
3 Sélection d'une fréquence FM ..........................................................3
Utilisation de ClearScan pour trouver la meilleure fréquence FM (recommandé)........3
Sélection manuelle d'une fréquence FM .................................................4
Mémorisation et sélection d'une fréquence..............................................4
4 Utilisation du réglage PRO pour de meilleures performances..........................5
Écoute d'enregistrements mono .........................................................6
5 Pour profiter pleinement de votre TuneCast Auto......................................7
Optimisation de la qualité sonore de votre TuneCast Auto ..............................7
6 Avertissements de sécurité .............................................................8
7 Information .............................................................................9
8820cw00176_F8Z439ea.indb 1 30/11/2009 14:05:28

TuneCast®Auto universel FR-1
SECTIONS 2 3 6 754Table des matières 1
INTRODUCTION
Votre TuneCast Auto est conçu pour transmettre l'audio de votre baladeur MP3, y compris
l'iPod, vers votre autoradio, tout en permettant de charger par le port USB intégré (câble de
chargement non fourni). Veuillez prendre connaissance de la totalité de ce manuel afin de tirer
le meilleur de votre TuneCast Auto, où que vous soyez.
8820cw00176_F8Z439ea.indb 1 30/11/2009 14:05:28
