Blaupunkt Compact Drive MP3 User manual

MP3-Player
Compact Drive MP3
Operating instructions

ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
11
CONTENTS
General .................................. 12
Road safety ................................... 12
Verification .................................... 12
Installation ..................................... 13
Accessories .................................. 13
Handling the Microdrive™ ............. 13
Installation steps .................... 14
Write-/ read device ........................ 14
IBM Microdrive™ ................... 15
Microdrive™ (hard disk) ................ 15
Storing MP3 files in a
directory on your hard disk ............ 15
Converting audio files
into MP3 files ................................ 15
Compatibility .......................... 15
Compatibility with
Blaupunkt car radios...................... 15
Update DX-R70 / RNS149/150 ..... 15
Display .......................................... 16
Changing the display ..................... 16
Display when changing directory ... 16
Display when changing tracks
within a directory ........................... 17
Temperature monitoring ................. 17
MP3 mode .............................. 17
Switching to MP3 mode ................ 17
Selecting directories ...................... 17
Selecting tracks ............................ 17
Fast searching............................... 18
Repeating individual tracks or
whole directories (REPEAT)........... 18
Random track play (MIX) ............... 18
Scanning all tracks in all
directories (SCAN) ........................ 18
Pausing playback (PAUSE)............ 19
TPM .............................................. 19
Update ................................... 19
Update over the Internet ................ 19
Installation instructions .......... 83

12
GENERAL
Thank you for deciding to use a Blau-
punkt product. We hope you enjoy us-
ing this new piece of equipment.
Please read these operating instruc-
tionsbeforeusing the equipment for
the first time.
The Blaupunkt editors are constantly
working on making the operating in-
structions clearer and easier to under-
stand. However, if you still have any
questions on how to operate the equip-
ment, please contact your dealer or the
telephone hotline for your country. You
will find the hotline telephone numbers
printed at the back of this booklet.
We provide a manufacturer guarantee
for our products bought within the Eu-
ropean Union. You can view the guar-
antee conditions at
www.blaupunkt.de or ask for them di-
rectly at:
Blaupunkt GmbH
Hotline CM/PSS 6
Robert Bosch Str. 200
D-31139 Hildesheim
Germany
Road safety
Road safety has absolute prior-
ity. Only operate your COMPACT
DRIVE MP3 Player if the road and
traffic conditions allow you to do so.
Familiarise yourself with the unit be-
fore setting off on your journey.
You should always be able to hear
police, fire and ambulance sirens
from afar. For this reason, set the
volume of whatever you are listen-
ing to to a reasonable level.
TheCOMPACTDRIVEMP3 isan MP3
playerthatplaysMP3musicfilesstored
on the Microdrive™ (hard disk).
CF cards (storage media) are not re-
cognized by the COMPACT DRIVE
MP3. MP3 is a process developed by
the Fraunhofer Institute for compress-
ingCDaudiodata.Compressionallows
data to be reduced to around 15% of
their original size without a noticeable
loss in quality (at a bit rate of 192 Kbit/
s). If a lower bit rate is used to convert
CD audio data to MP3, you can create
smaller files but there will be a loss of
quality. You can store MP3 files on the
Microdrive™ (hard disk) using the sup-
pliedSCM(write-/readdevice).Forfur-
therdetails,pleasereadthechapteren-
titled “Write-/ read device”.
YoucanconnecttheCOMPACTDRIVE
MP3 Player to many Blaupunkt car ra-
dios.Forfurtherdetails,pleasereadthe
chapterentitled“CompatibilitywithBlau-
punkt car radios”.
Verification
Microdrivearetrademarksorregistered
trademarks of International Business
Machines Corporation in the United
States other countries or both.
Microdrive is used under license by
Blaupunkt.

ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
13
Installation
If you want to install your COMPACT
DRIVE MP3 Player yourself, please
read the installation and connection in-
structions that follow these operating
instructions.
Accessories
We recommend you use accessories
thathavebeenapprovedbyBlaupunkt.
Handling the Microdrive™
Please observe the following details to
ensure trouble-free operation and to
makeoptimaluseofalltheMicrodrive™
features.
●Regularly create a backup of your
data. Blaupunkt does not accept
responsibility for any loss of data.
●Always carry and keep your Micro-
drive™ in the supplied protective
transportation cover.
●Never drop the Microdrive™.
●Ensure that the Microdrive™ does
not become wet.
●Never expose the Microdrive™ to
strong magnetic fields.
●Never expose the Microdrive™ to
extreme temperatures.
●Never attach any additional stick-
ers.
●Do not remove the sticker that is al-
ready attached.
●Do not write anything on the sticker
that is already attached.
GENERAL
●Never press down on the out-
side cover of the Microdrive™.
●Always switch off the car radio
before removing the Micro-
drive™.
●Always take care when remov-
ing it. The Microdrive™ may be
warm after use.
Microdrivearetrademarksorregistered
trademarks of International Business
Machines Corporation in the United
States other countries or both.
Microdrive is used under license by
Blaupunkt.

14
INSTALLATION STEPS
Installation steps
Before starting the installation process,
please back up your personal data and
closeanyprogramsrunningonyourPC.
Blaupunkt does not accept liability for
any deleted data.
Notes: The following driver installation
is only required for Windows 98 USB.
In the case of WIN ME / WIN 2000
and WIN XP, all you need do is con-
necttheread/writedevicetotheUSB
portofyourPC.Afterafewseconds,
the Windows hardware recognition
feature will make the read/write de-
viceaccessibleasanadditionaldrive
in Explorer and My Computer.
Write-/ read device
Installation for Windows 98 USB
➮Connect the write-/ read device to
your computer using the USB con-
nection.
➮The Windows Installation Man-
ager starts automatically.
➮Please close it again.
➮Insert the CD-ROM into the CD-
ROM drive. If the CD-ROM does
not start automatically, open Win-
dow’s Desktop icon and then open
the CD-ROM drive. Run the
“Start.html” file by double clicking
on it.
➮Select your language and then the
“Write-/ read device”, and start un-
packing the drivers by clicking on
“Driver installation”.
➮This Step 1 will be completed when
you close the “WinZip Self-Extrac-
tor”.
➮During Step 2 you will install the
driver on your PC.
After Step 2 is complete, the “Write-/
read device” will appear as a “Com-
pact Flash Drive” in Explorer or in
Desktop.

ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
15
IBM Microdrive™
Microdrive™ (hard disk)
The hard disk can be inserted into
and removed from the write-/ read
device whilst the computer is
switched on.
➮Carefully hold and pull the hard
disk between your thumb and in-
dex finger out of the protective
transportation cover.
➮Insert the hard drive (with its con-
tact edge foremost) into the write-/
read device. Click it into place with
a light press.
Theharddiskisvisible,anddatacan
now be written onto it.
Storing MP3 files in a directory
on your hard disk
You can create up to 99 directories.
Each of these directories can contain
up to 99 music tracks.
Themaximumnumberofcharactersfor
directorynamesandtracknamesis90.
Note:
MP3 files that are stored in subdi-
rectories and not in directories are
not recognized by Compact Drive
MP3.
Converting audio files into MP3
files
➮Run the “MP3 Software” on the
CD-ROM and follow the program’s
instructions.
Tip: You can also use any other stand-
ard conversion program.
IBM MICRODRIVE™
Compatibility
Compatibility with Blaupunkt car
radios
Ourengineershavemadeit possibleto
connect the COMPACT DRIVE MP3
Player to the following car radios:
●Skyline 2 and future Skyline de-
vices
Dallas MD 70, Denver CD 70,
Frankfurt C 70, Hamburg CD 70,
London CD 70, Madrid C 70, New
Orleans MD 70, Orlando CD 70,
San Francisco CD 70
●Funline 3 devices (only with CD-
Naming) and future Funline de-
vices
Acapulco CD 51, Casablanca CD
51, Heidelberg CD 51, Palm Beach
C 51, Verona C 51
●Navigation devices
Update DX-R70 / RNS149/150
For the navigation devices DX-R70,
RNS 149 and RNS 150, you will need
to carry out the following update:
Note:
Theread/writedeviceisinstalledand
the Microdrive™ is visible as an ad-
ditional drive (removable disk) in
Explorer.
Insert the CD-ROM into the CD-ROM
drive. If the CD-ROM does not start au-
tomatically, open the Windows „My
Computer“ icon and then open the CD-
ROM drive. Run the “Start.html” file by
double clicking on it.
COMPATIBILITY

16
➮Now select the language and then
select “Updates”.
➮Please follow the displayed
steps.
After copying has completed (approx.
15seconds),youcanremovetheMicro-
drive™ from the read/write device.
Now all you need do is carry out the
followingthreestepsontheDX-R70:
1. The DX-R70 and Compact Drive
MP 3 must be switched off!
2. Insert the Microdrive™. Switch on
the DX-R70 and wait for the device
to start playing.
3. Switch off the DX-R70. When you
switch on the device again, it will
be ready to operate.
You cannowchangeMP3 directories
usingthedisplaybuttonsonthe right
that are located next to the new “up /
down” display text.
The up/down rocker switch is used to
change tracks.
Note:
YoushoulddeletetheDxr70.fkporRNS
149/150.fkp file from the Microdrive™.
Ifyoudelete thesefiles,youwill beable
torestoretheCompactDrive MP3toits
original delivery condition by carrying
out the update again using the
CLEAR.FKP file.
Note:
Some devices cannot display the
whole character set.
The following characters are either in-
correctly displayed or not displayed at
all.
●Funline 3 series:
; : ! ß § % & = ? Ü Ö Ä # ¤ @
●Skyline 2 series:
$ ~ ¤ ^ ´
Display
In order to display directory names
and tracks (scrolling) in the display,
you have to switch to the “Track
number and CD name” display
mode.
Changing the display
➮To switch between the track number
and playing time display / track
number and clock display / track
number and CD number display /
track number and CD name display,
press the /DIS button 7once or
several times for longer than two
seconds until the required display
appears.
If no information (track name) is con-
tained in the ID3 tag, the file name ap-
pears in the display instead.
Display when changing directory
When a directory is selected, the first
7 characters of the directory name ap-
pear in the display.After approx. 1 sec-
ond, the remaining characters scroll
once across the display.
Afterwards,thenameofatrackappears
in the same fashion in the display.
The artist’s name then scrolls across
once.
COMPATIBILITY

ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
17
MP3 MODE
Finally,thefirst7charactersofthetrack
name appear and remain visible in the
display until the next manual or auto-
matic change.
Display when changing tracks
within a directory
When a track is selected, the first 7
characters of the track name appear in
the display.After approx. 1 second, the
remainingcharactersscrollonceacross
the display.
The artist’s name then scrolls across
once.
Afterwards, the first 7 characters of the
track name appear and remain visible
in the display until the next manual or
automatic change.
Temperature monitoring
Your device is fitted with a protection
system to deal with extreme tempera-
tures in the vehicle. The device will ei-
ther switch off or will not switch on if
extreme temperatures are detected.
Display if the temperature is too low:
ERROR TEMPERATURE TOO LOW
Display if the temperature is too high:
ERROR TEMPERATURE TOO HIGH.
MP3 ode
Switching to M 3 mode
N ote:
The Microdrive™ must only be in-
sertedorremovedfromtheCompact
Drive MP3 when the car radio is
switched off.
Info:
The control functions for MP3 mode
correspond to those described in
your car radio’s operating instruc-
tions for CDC mode.
Thefollowingdescription offunctionsis
taken from the Acapulco CD 51 car ra-
dio in the FunLine series. Other car ra-
dios are similar.
➮Keep pressing the CD•C button @
until “CHANGER” appears in the
display.
Playback begins with the directory
containing MP3 files that was lis-
tened to last.
Selecting directories
➮To move up/down from one CD to
another, press the or button
:once or several times.
Selecting tracks
➮To move up/down from one track to
another in the current directory,
press the or button :once or
several times.
COMPATIBILITY

18
Fast searching
To fast search backwards or forwards,
➮keep one of the buttons :
pressed until fast searching back-
wards / forwards begins.
Repeating individual tracks or
whole directories (RE EAT)
➮If you wish to repeat the current
track, briefly press button 4 RPT
>.
“REPEAT TRCK” appears briefly and
RPT lights up in the display.
➮If you wish to repeat the current di-
rectory, press button 4 RPT >
again.
“REPEAT DISC” appears briefly and
RPT lights up in the display.
Cancelling RE EAT
➮If you want to stop repeating the
current track or current directory,
press button 4 RPT >until “RE-
PEAT OFF” appears briefly in the
display and RPT disappears.
Random track play (MIX)
Info:
Limited MIX function.
It is possible that a track is repeated.
➮To play all the tracks in the current
directory in random order, briefly
press button 5 MIX >.
“MIXCD”appearsbrieflyandMIXlights
up in the display.
➮To play the tracks in all the directo-
ries in random order, press button
5 MIX >again.
“MIXALL”appearsbrieflyandMIXlights
up in the display.
Cancelling MIX
➮Press button 5 MIX >until “MIX
OFF” appears briefly in the display
and MIX disappears.
Scanning all tracks in all directo-
ries (SCAN)
➮To briefly play all the tracks in all di-
rectories in ascending order, press
the OK button ;for longer than
two seconds.
“SCAN” appears in the display.
“CD1”remainsinthedisplayduringthe
scanning process.
Cancelling SCAN
➮To cancel scanning, briefly press
the OK button ;.
The currently scanned track will then
continue to be played normally.
Note:
You can set the scanning time (scan-
time). For further details on setting the
scantime, please read the section ent-
itled “Setting the scantime” in the “Ra-
dio mode” chapter of the radio’s ope-
rating instructions.
MP3 MODE

ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
DANSK
19
ausing playback ( AUSE)
➮Press button 3>.
“PAUSE” appears in the display.
Cancelling pause
➮Press button 3>while in
pause mode.
Playback is resumed.
T M
A TPM function (Track Program
Memory) is not available.
Update
Update over the Internet
Notes on the update facility
Your COMPACT DRIVE MP3 is
equippedwithanupdatefacilityfornew
functions.
An update can be downloaded free of
charge over the Internet from
www.blaupunkt.de
The installation path is as follows: In-
ternet > PC > Write-/ read device >
Microdrive™>COMPACTDRIVEMP3.
UPDATEMP3 MODE
