Bellezza Piccola 60 Titanio V2 User manual

Bellezza
Piccola 60 Titanio V2
MANUAL

FOREWORD
Dear coffee lover,
Dear coffee lover,
thank you for purchasing your Bellezza product.
Bellezza has over 40 years of experience with espresso machines.
Developed in Germany and manufactured by hand, Espres-som
machines from Bellezza combine tradition, know-how, technical
progress and quality. Always with the aim of making it possible to
enjoy the service and the greatest possible coffee enjoyment. And
if something does happen, please contact your Bellezza dealer or
contact us. You can find contact details on our website at
www. bellezza-espresso.de
You will also find other Bellezza products and accessories there.
Your Udo Bohneberg
Managing Director Bellezza GmbH
2/ 18 Bellezza | Espresso machines

5
5
5
5
5
6
7
7
9
9
9
10
10
10
11
12
13
14
16
3/ 18
17
17
17
CONTENT
About these instructions
Described products
Symbols and abbreviations used
Safety and warning notices
Important safety instructions
Intended Use
Improper Use
Get to know the grinder
Unpacking
Scope of delivery
Overview of the grinder
Set up and connect the grinder
Set up and connectthe grinder
Start up and operate the grinder
Grinding Degree
Cleaning and troubleshooting
Technical Specification
Maintain and repair the grinder
Non-use / Disposal / CE-Conformity
Disposal
CE-Conformity
Espresso machines | Bellezza

Bellezza
Piccola 60 Titanio
V2

ABOUT THIS MANUAL
►Read these instructions carefully and follow all instructions
given.
►Keep these instructions close to the grinder.
►If there is a change of owner, pass on the instructions with the
grinder.
Described products
These operating instructions apply to the following product:
Francesca
Representation conventions
Actions
Individual actions are marked by a preceding triangle:
►Individual instruction
Actions that have to be carried out in a certain order are
numbered:
1. Step 1
2. Step 2
3. Step 3
Symbols and abbreviations used
Safety and warning notices
Safety and warning notices protect you and your grinder. You
should therefore read this information carefully and follow the
instructions given.
Structure of warning notices
The warning notices are structured according to the following
scheme:
WARNINGWORD
The nature and source of the danger
Consequences if the measures to avoid the danger are not
observed
►Measures to avoid the danger.
Meaning of the warning words
–DANGER: Damage to or destruction of the product
–ATTENTION: Minor or moderate injuries
–WARNING: Serious injury or death
Here you will find important or interesting information
about the product and its operation.
5/ 18 Espresso machines | Bellezza
About these instructions

IMPORTANT SAFETY INSTRUCTIONS
When setting up
►Check the mains voltage available at the installation site and
only start up the grinderif it corresponds to the voltage range
specified on the nameplate.
►Lay the connection cable so that nobody can trip over it and it
does not come into contact with sharp or very hot objects.
►Only connect the grinder to an earthed socket. If you are
unsure, contact an electrician.
►Do not set up the device near strong heat or fire sources to
avoid damage.
►Set up the grinder on a level and stable surface. Avoid unsafe
documents that can tip over or be knocked over while walking
by.
►Set up the grinder out of the reach of children and people with
limited abilities.
During commissioning
►Do not operate the grinder if the device or the power
cord are damaged. In this case, contact your specialist
dealer or contact Bellezza.
Operational
►Switch the grinder off immediately and pull the power plug
out of the socket if the power cord is damaged. Be careful not
to touch the damaged area. Contact your specialist dealer and
have the defective cable replaced. Do not put the grinder back
into operation until the damage has been properly repaired.
►Children from the age of 8 and people with limited physical,
sensory or mental abilities may only operate the grinder after
receiving appropriate instruction. If necessary, supervise the
persons while operating the grinder.
For cleaning and maintenance
►Before cleaning and maintenance work:
–Let the grinder cool down.
–Disconnect the grinder from the mains voltage.
►Only use a damp cloth to clean the grinder. Do not immerse
the grinder in water or other liquids.
6/ 18 Bellezza | Espresso machines
Important safety instructions

►Cleaning and maintenance must not be carried out by
children or persons with restrictions without supervision.
When not in use for a long time
►Disconnect the grinderif it is not going to be used for a long
time (e.g. before a vacation) from the mains voltage.
►Check the grinder and power plug for damage after a long
period of non-use and only operate the grinder if it is
undamaged.
Intended Use
►The grindermay only be used indoors.
►The grinderis suitable for private and business use. Possible
places of use are e.g.
–private households
–Staff kitchens in shops, offices and companies
–Hotels, motels and boarding houses
►When using the grinderin a business environment, people
must be instructed in its operation and informed about the
possible dangers before using it.
Improper use
►The grinder must not be used outdoors.
►The grinder must not be used in environments in which the
permissible environmental conditions e.g. B. for temperature
and humidity are exceeded.
►Make sure that the device voltage on the nameplate
corresponds to the mains voltage. The nameplate is on the
underside of the grinder.
►Always fix the bean container with the locking screw.
►Connect the coffee grinder only in accordance with the
instructions given.
►Always disconnect the device from the power supply before
cleaning the device or perform maintenance work or replace
individual parts.
7 / 18Espresso machines | Bellezza
Important safety instructions

Bellezza
Piccola 60 Titanio
V2

GET TO KNOW THE GRINDER
Unpacking
1. Open the packaging and remove all parts.
2. Check all parts for completeness and damage. If parts are
missing or damaged, please contact your specialist dealer.
3. Keep the packaging, e.g. for a later transport or a possible
sending for a repair.
Fig. 1: The picture shows the Piccola 60 Titanio
Scope of delivery
Coffee grinder
1
2Cleaning brush
9 / 18Espresso machines | Bellezza
Get to know the grinder

Overview of the grinder
1
8
5
4
3
2
Fig. 2:
7
Overview: Piccola 60 Titanio
1
2
3
4
5
6
7
Funnel cap: Close the cap to keep the coffee beans fresh
Funnel: For inserting coffee beans
Scale adjustment pole: To change the scale of the outcoming
powder
Display: Shows grind time and options
Powder Outlet: Powder output
Startbutton: Button to start the grinding
On / Off switch
Handle holder: Holds the portafilter
10 / 18 Bellezza | Espresso machines
Set up and connect the grinder
SET UP AND CONNECT THE GRINDER
Set up the grinder
►Choose an easily accessible installation location with a level, stable
and sufficiently large surface.
►A mains socket must be available for the electrical connection.
►Make sure that people walking by cannot knock over the grinder.
Connect the grinder electrically
►Make sure that the values for the mains voltage and mains
frequency specified on the type plate match the mains at the
installation site.
►Only connect the grinder to an earthed mains socket. If you
are unsure, contact an electrician or your dealer.
►Insert the power plug into the socket.
6
8

11 / 18Espresso machines | Bellezza
Start up and operate the grinder
START-UP AND OPERATE THE GRINDER
Piccola 60 Titanio V2 usage
Grinder programming
1. By selecting the buttons "one coffee cup" or "two coffee
cups" or manually "finger button" choose which mode you
want to use. To start the grinding process, press the button on
the grinder.
2. Hold the "one coffee cup" or "two coffee cups" button until
the plus and minus buttons start to flash. Then you can set the
time for the modes with the "plus" or
"minus" buttons. Press the "one coffee cup" or "two coffee
cups" button again to save the changes.
3. The manually button ("finger button") has a time up function,
this allows you to try out which time is best for setting for the
one or two draw modes.
4. Take the portafilter, push it slightly against the button on the
and press the button again when you are satisfied with the
amount. The display counts how long the grinding process is
running, so you can see which time should be set for the 1 or 2
draw.
5. The button has a start / stop function, you can interrupt the
grinding process and have 10 seconds to continue. Otherwise
the time resets itself to the set time.
The Piccola 60 Titanio V2 has three diffrent grinding
modes which could be changed by switching the Power
switch.
Mode 0: Turns the grinder off
Mode 1: Automatic mode with display
Mode 2: Manually use mode (no display)
Buttons: One coffee cup Finger button
Two coffee cups
After 10 minutes of inactivity, the display goes into Eco
mode.
This can be ended by touching the display.

12 / 18 Bellezza | Espresso machines
Grinding degree setting
GRINDING DEGREE SETTING
How to set grinding degree
The grinding degree setting should be made with the grinder
running.
Emergency stop operation:
The mill can be stopped immediately in an emergency by
pressing the ON / OFF switch.
1. Switch on the grinder, the bean container is filled with coffee
beans.
2. Carry out a test grinding by pressing the contact rocker /
button.
3. Is the result
a. too coarse, then turn the grinding degree adjustment
wheel counterclockwise (numbers on the scale
become smaller)
b. too fine, turn it clockwise (numbers on the scale get
bigger)
4. Adjust the adjustment in small steps, half a turn on the
adjusting wheel.
ATTENTION
Risk of damage on grinder and body
Under no circumstances fill the bean container with coffee that
has already been ground. Under no circumstances should you
insert your finger or other objects into the grinder inlet shaft or
into the coffee outlet.

13 / 18Espresso machines | Bellezza
Cleaning and troubleshooting
CLEANING AND TROUBLESHOOTING
Cleaning grinding disks
►The grinding disc holder is very difficult to unscrew due to the
fine thread. There is a risk of injury.
►Make sure that there are no coffee residues in the thread,
otherwise it cannot be screwed on.
►Close the bean container with the slide lock and grind the
remaining beans from the grinder.
►Pull out the power plug and unscrew the safety screw
connection of the bean container.
►Remove the bean container. Make sure that the locking slide is
still locked.
We recommend that you clean your grinder regularly.
In this way you can keep the grinder functional and
ensure good, even results. This also prevents the aroma
and taste from being impaired by residues from old
coffee in the grinder.
Troubleshooting
If it happens that coffee beans get jammed in the
grinder of the grinder, this can be done easily
remedy.
1. Set the grinding degree coarser. To do this, turn the
grinding degree adjustment wheel two full turns
counterclockwise.
2. Press the portafilter against the button and grind
coffee. The jammed beans should now loosen.
3. Set the grinding degree again.
If the coffee outlet of the grinder is blocked by a
grinding degree that has been selected too finely
(depending on the temperature, humidity, fat and
oil content of the coffee in question), please
proceed as follows to rectify the problem:
1. Switch off the grinder and pull the power plug.
2. Empty the bean container so that later no more
beans can fall into the grinding area of the grinder.
3. Open the side screws of the spout and remove the
display.

14 / 18 Bellezza | Espresso machines
Technical specification
4. Insert a suitable object (e.g. espresso spoon, style of
grinder brush) into the coffee outlet of the grinder and
completely remove any coffee residue that has accumulated
and clogged the chute.
5. Memorize or write down the current grinding degree
setting using the number scale. Then use the rotary handle to
set the grinding degree to a coarser value on the scale so
that the remaining beans in the grinding area can escape
without great resistance.
6. Plug in the power plug. Turn on the grinder.
7. Start the grinding process as usual by pressing the button
or rocker. The rest Ground coffee should now escape
through the coffee chute. Then manually clean the coffee
chute again completely as already described (pull out the
mains plug beforehand!). Grind coffee again until no more
ground coffee falls out, if necessary clean the coffee chute
again.
8. If necessary, adjust the grinding degree and the grinding
time in the course of the following grinding processes.
9. A coarser grind can be compensated for with a larger
amount of coffee or a higher pressure when tamping.
TECHNICAL SPECIFICATIONS
Piccola Titanio V2
Mains voltage 110 V /220 V
Frequency 50/60 Hz
Power consumption 200 W
Dimensions [W x H x D]: 230 x 140 x 480 mm
Weight 7 Kg

Bellezza
Piccola 60 Titanio
V2

Warranty
Bellezza gives a one year warranty.
Structural changes to the grinder and repairs that are not
carried out by an authorized service partner will void any
warranty claims.
Customer service / Repair
Any work on the grinder such as maintenance, customer
service, repair or replacement of components may only be
carried out by authorized service partners.
You can find information on sales partners, service centers and
authorized repair centers on the Bellezza website at
www.bellezza-espresso.de
16 / 18 Bellezza | Espresso machines
Maintain and repair the grinder

NOT USE / DISPOSAL / CE-CONFORMITY
Disposal
This product contains valuable materials that can
be recycled. Therefore, at the end of its service
life, dispose of the product in an environmentally
friendly manner and in accordance with national
regulations. This product complies with the EU
Directive 2002/96 / CE and is registered in
accordance with the Electrical and Electronic
Equipment Act (ElektroG).
CE-Conformity
This product is CE-compliant and complies with
the applicable guidelines and standards.
17 / 18Espresso machines | Bellezza
Non-use / Disposal / CE-Conformity
Conformity
The following EU directives comply:
Machinery Directive 2006/42 / EG
Low voltage directive: 2014/35 / EU
Electromagnetic Compatibility Directive (EMC): 2014/30 / EU
Directive on the restriction of the use of certain hazardous substances
in electrical and electronic equipment
Electronic equipment (ROHS): 2011/65 / EU
Directive 2012/19 / EU on waste electrical and electronic equipment
The following regulations were also observed:
Regulation on the Registration, Evaluation, Authorization and
Restriction of Chemicals (REACH): 1907/2006 / EU.
Regulation (EC) No. 1935/2004 on materials and objects that are
intended to come into contact with food.
Regulation (EU) No. 10/2011 on materials and articles made of plastic
that are intended to come into contact with food.
Regulation (EC) No. 2023/2006 on good manufacturing practice for
materials and articles that are intended to come into contact with
food.
The following harmonized standards were applied to ensure
conformity:
EN 60335-1: 2012 + AC: 2014 + A11: 2014 + A13: 2017
EN 60335-2-15: 2016 + A11: 2018
EN 60335-2-64: 2002 + A1 + A2
EN 55014-1: 2017
EN 55014-2: 2015
EN 62233: 2008
IEC 60335-1 (ed5) + A1 + A2
IEC 60335-2-64: 2002 + A1 + A2
Note: If changes are made to the named devices that are not agreed
with us, this declaration of conformity becomes invalid.

Bellezza Espressomaschinen GmbH
Hertzstrasse 10
69126 Heidelberg
[email protected]
www.bellezza-espresso.de
Edition 01/2021
