Belling BI60COMWSTA User manual

Operating Instructions – Microwave Oven Belling BI60COMWSTA
Control Panel
1. Function dial
2. Power/weight button
3. Quickly preheating button
4. On/Off button
5. Temperature/automenu button
6. Clock button
7. Start/Pause button
8. Selection dial
.
Operation Instruction
This microwave oven uses modern electronic control to adjust cooking parameters to meet your needs better for
cooking.
1. Clock Setting
When the microwave oven is on “00:00” will blink, the buzzer will ring once.
-Turn dial to set the correct time (between 00:00 and 23:59)
-After you have set the right time press and the clock has been set.
-If you want to change the time you have to press and hold the button for 3 seconds. The actual time
disappears and then the time will blink in the display. Turn to set the new time and press the
button briefly. The time disappears. Press again and the clock appears in the display again.

2. Microwave Cooking
-Press the button to activate the microwave function. “01:00” is blinking in the display and the microwave
icon appears. If no operation in 10 seconds, the current power will be confirmed automatically.
-Turn dial to set the cooking time. The max. cooking time depends on the power that has been set. When
the power is 900W the max. time is 30 minutes and other powers are 90 minutes.
-Press button to adjust the power microwave power.
-Turn dial to set the microwave power (between 100W to 900W)
-Press button to start cooking.
-Note: The step quantities for the adjustment time of the coding switch are as follows:
-0-1 min: 1 second
-1-5 min: 10 seconds
-5-15 min: 30 seconds
-15-60 min: 1 minute
-60 min: 5 minutes
Microwave Power Chart
You can see from the table below from which power levels you can choose and for which foods the power levels are
suitable:

Functions

3. Grill Cooking
-Press button to activate the microwave function
-Turn to select the cooking mode, indicator lights.
-Turn to select grill mode. The default grill power is the third level. indicator will light when grill
function is selected.
-Press to enter the grill level/
-Turn to select the level 3 (the max.), level 2, or level 1 (the min).
-Press to select the time setting mode. The default time is 10 minutes.
-Turn to select the cooking time of grill. The maximum time is 90 minutes.

-Press button to start cooking.
4. Convection Cooking
-Press button to activate the microwave function.
-Turn to select the cooking mode. indicator lights.
-Turn to select convection mode. lights. The default temperature is 180 degrees.
-Press to enter the temperature mode.
-Turn to select temperature. The temperature is from 50 to 230 degrees.
-Press to select the time setting mode. The default time is 10 minutes.
-Turn to select the cooking time. The max. time is 5 hours.
-Press button to start cooking.
5. Grill fan cooking
-Press button to activate the microwave function.
-Turn to select the cooking mode. indicator lights.
-Turn to select grill fan mode. The default temperature is 180 degrees. indicator will light when
grill fan function is selected.
-Press to enter the temperature selection.
-Turn to select the temperature between 100 to 230 degrees. Press to select the time setting
mode. The default time is 10 minutes.
-Turn to select the cooking time. The max. time is 5 hours.
-Press button to start cooking.

6. Convection and bottom heat cooking
-Press button to activate the microwave function.
-Turn to select cooking mode. indicator lights.
-Turn to select bottom & convection mode. The default temperature is 180 degrees. indicator will
light when convection and bottom function is selected.
-Press to enter the temperature selection.
-Turn to select the temperature between 100 to 230 degrees. Press to select the time setting mode.
The default time is 10 minutes.
-Turn to select the cooking time. The max. time is 5 hours.
-Press button to start cooking.
7. Microwave and Grill cooking
-Press button to activate the microwave function.
-Turn to select the combination mode. and will light.
-Turn to select mode. The default power is level 3. indicator will light when grill function is selected.
-Press to enter the temperature selection.
-Turn to select the power.
-Press to select the power. The default power is 300W.
-Turn to select 700W, 450W, 300W and 100W.
-Press to select the time setting mode. The default time is 10 minutes.

-Turn to select the cooking time. The max. time is 90 minutes.
-Press button to start cooking.
8. Microwave & Convection Cooking
-Press button to activate the microwave function.
-Turn to select the cooking mode. and will light.
-Turn to select convection mode. The default temperature is 180 degrees. lights.
-Press to enter the temperature selection.
-Turn to select the temperature between 50 to 230 degrees.
-Press to select the power. The default power is 300W.
-Turn to select 700W, 450W, 300W and 100W.
-Press to select the time setting mode. The default time is 10 minutes.
-Turn to select the cooking time of grill. The max. time is 90 minutes.
-Press button to start cooking.
9. Microwave & Grill fan cooking
-Press button to activate the microwave function.
-Turn to select the combination mode. and will light.
-Turn to select cooking mode. The default time is 180 degrees. indicator will light when this
function is selected.
-Press to enter the temperature selection.

-Turn to select the temperature between 100 to 230 degrees.
-Press to select the power. The default power is 300W.
-Turn to select 700W, 450W, 300W and 100W.
-Press to select the time setting mode. The default time is 10 minutes.
-Turn to select the cooking time of grill. The max, time is 90 minutes.
-Press button to start cooking.
10. Microwave and bottom and convection cooking
-Press button to activate the microwave function.
-Turn to select the combination mode. and will light.
-Press to select convection mode. The default temperature is 180 degrees. indicator will light
when this function is selected.
-Press to enter the temperature selection.
-Press to select the temperature between 100 to 230 degrees.
-Press to select the power. The default power is 300W.
-Press to select 700W, 450W, 300W and 100W.
-Turn to select the time setting mode. The default time is 10 minutes.
-Press to select the cooking time of grill. The maximum time is 90 minutes.
-Press button to start cooking.
11. Auto Cook
There are 15 automatic cooking programs. You only have to choose the program and set the weight. The power, the
time and the temperature are already set.

-Press button to activate the microwave function.
-Turn to select the cooking mode. will light when auto menu is selected. Time, weight, the first
number of the automatic programs are all shown in the display.
-Turn to select auto menu. “P01, PO2, … P13 will display.
-Press button.
-Turn to select weight of the menu.
-Press button to start cooking.
The programmes with a * are preheated. During preheating, the cooking time pauses and the preheating symbol is
on. After preheating, you will hear an alarm and the preheating symbol will blink.
The programmes with a** only use the microwave function.
12. Preheating function

The preheating function can be activated after you have chosen the functions: Convection, Grill fan, bottom –
convection, MW-convection, MW-Grill fan and Microwave-Bottom convection,
1. Press button. The preheat icon appears in the display.
2. Press button to start preheating, If the right temperature is reached, you will hear three beeps. You can
stop the preheating by opening the oven door or by pressing the button.
The preheating function only works if you have already chosen one of the modes above. During preheating, the
microwave function is switched off.
13. Display Specification
-When setting, if no other operation, it will confirm automatically after 10 seconds. Except for when the clock is
set for the first time.
-During setting program, after adjusted for 3 seconds it will confirm after 3 seconds.
-When the oven is in setting state or pause state, including auto menu and defrost program, if no operation in 5
minutes it will enter into the off state.
-The oven lamp will light all the time if the door is open.
-The oven lamp will light all the time if the oven is paused.
-button must be pressed to continue cooking if the oven door is open during the cooking process.
