BenQ TEY21B User manual

TEY21B
User Manual

Disclaimer
BenQ Corporation makes no representations or warranties, either expressed or
implied, with respect to the contents of this document. BenQ Corporation reserves the
right to revise this publication and to make changes from time to time in the contents
thereof without obligation to notify any person of such revision or changes.
Copyright
Copyright 2021 BenQ Corporation. All rights reserved. No part of this publication may
be reproduced, transmitted, transcribed, stored in a retrieval system or translated into
any language or computer language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without the prior written permission
of BenQ Corporation.

Table of Contents i
Table of Contents
Introduction .......................................................................... 1
Features ............................................................................................. 1
Dimension ......................................................................................... 3
View Outlook ....................................................................... 4
Outside View.................................................................................... 4
View of I/O Front Panel................................................................. 4
View of I/O Back Panel................................................................... 5
First installation.................................................................... 6
OPS interface........................................................................ 8
CO2 Sensor (for CP6501K / CP8601K only)........................ 10
Three main features ..................................................................... 11
Side Tool Bar.................................................................................. 13
Quick Control............................................................................... 17
4/14/21

Introduction1
Introduction
TEY21B OPS provides a greater performance for the Interactive Display and Digital
Signage applications. This embedded PC module is rich with I/O's including one type-C
USB, two USB 3.1, one USB 3.0, one USB 2.0, one HDMI video port with up to
3840*2160 resolution, and support TPM2.0; Pre-load Win10 IoT Enterprise and BenQ
Launcher provide friendly user experience.
Features
PC
Model TEY21B-10I5M8S5 TEY21B-10I7M8S5
CPU i5 10210U, Intel® 10th Gen.
Comet Lake-U SOC
i7 10510U, Intel® 10th Gen.
Comet Lake-U SOC
Memory* DDR4 8G x 1 DDR4 8G x 1
Storage* 256 GB 256 GB
Graphics Intel® HD Graphics 6 Series Intel® HD Graphics 6 Series
Resolution Max. 3840 x 2160 @60Hz Max. 3840 x 2160 @60Hz
Chipset Integrated into CPU Integrated into CPU
Network Intel Gigabit Ethernet Intel Gigabit Ethernet
Wi-Fi Intel® AX200
802.11 a/b/g/n/ac/ax
(2.4 GHz and 5 GHz)
Intel® AX200
802.11 a/b/g/n/ac/ax
(2.4 GHz and 5 GHz)
Interfaces Frontside
USB 3.1 Type-C* x1
USB 3.1 Type-A x2
USB 3.0 Type-A x1
USB 2.0 Type-A x1
HDMI 2.0 (4K@60Hz) x1
RJ45 (10/100/1000M) x1
3.5mm Line out x1
3.5mm Mic in x1

Introduction 2
WiFi/BT ANT x2
Power button x1
Reset button x1
Power LED x1
SSD LED x1
DC-IN x1
Operation System
OS Support Win10 IoT Enterprise 64 bit
(Pre-load BenQ Launcher)
Power
Power Supply Mode DC input +12V~+19V
Physical Specifications
Cover Material Metal
Dimension L*W*H (mm) 119 x 180 x 30
Package Dimension (mm) 254 x 196 x 77
Net Weight 0.97 kg (1pcs)
Gross Weight 1.23 kg (1pcs)
Operation Temperature 5~45%
Operation Humidity 10%~95%
Storage Temperature -20 - 70%
Storage Humidity 10%~95%
• Memory up to 16GB
• Storage support M.2 2280 SATA SSD
• USB 3.1 Type-C supports data transfer and 5V/1A peripheral devices only.
Interfaces Frontside

Introduction3
Dimension

View Outlook 4
View Outlook
Outside View
View of I/O Front Panel
78

View Outlook5
View of I/O Back Panel
15
16
No. Name Description
WiFi WiFi antenna interface
LOCK LOCK button
HDD LED Hard Disk Drive indicator light
USB2.0 USB 2.0 connectors, backwards compatibility USB 1.1
POWER BUTTON Press the power button to turn on the device.
MIC IN This jack is used to connect an external microphone.
LINE OUT This jack is used to connect to the front left and right channel
speakers of the audio system.
POWER LED Power indicator light
USB3.1 TYPE-C Type-C connector
HDMI High-definition multimedia display interface
USB3.1 Gen2 Type-A USB 3.1 connector, backwards compatibility USB 3.0/2.0
LAN RJ-45 Ethernet network connector
USB3.0 USB 3.0 connector, backwards compatibility USB 2.0/1.1
RESET Reset button
JAE 80 pin Testing Interface
DC IN DC Power interface
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
The product may differ from that illustrated depending on your region of purchase. The images
are for reference only.

First installation 6
First installation
When using the TEY21B OPS module for the first time, you should follow the on-screen
steps.
1. Wait for a few minutes when first starting the OPS module.
2. After the boot screen, please enter the region and keyboard layout.
3. After some setup, sign in with Microsoft. Choose Domain join instead if you do
not have the aacount.

First installation7
4. Follow the on-screen steps to fill in the user name, password, security questions,
and other necessary settings. After finishing all the settings, wait for several minutes.
Then you will see the Windows desktop. Please wait for about one minute for the
BenQ UI setting to show up.
5. Check “Don’t ask me again” and press Ye s to proceed.
6. Read the privacy policy, check “I’ve read and accept Privacy Policy”, press Agree
and OK to finish the setting.

OPS interface 8
OPS interface
Optimizing Windows touch behavior, TEY21B is a friendly launcher for Windows users.
It provides similar user experience with Android launcher and has Windows Multi-
tasking functions and tools.
Item Description
1. CO2 Sensor Air quality sensor information. Read CO2 Sensor (for
CP6501K / CP8601K only) on page 10 for more
information.
2. Three main
features
Three main features are Whiteboard, File manager, and
Conference. Read Three main features on page 11 for
more information.
3. Shortcut area You can add your often-used Apps here.
4. Account You can access the account information here.
5. Switch input
source
Press to switch to the interactive display input source.
1
4
2
3
5678
9
10 11

OPS interface9
6. All Apps Collects all Windows software.
7. Android setting Press to open BenQ Android setting of IFP/Signage.
8. Help function Press to access the user manual.
9. Side Tool Bar Read Side Tool Bar on page 13 for more information.
10. OTA Press to access the OTA information.
11. Quick Control Read Windows Ink on page 15 for more information.

OPS interface 10
CO2 Sensor (for CP6501K / CP8601K only)
The concentration value of CO2 sensor may vary depending on the environment such as
temperature, humidity, and placement (by windows or under air conditioning). This
means that the CO2 sensor will always accurately measure the increments between ppm
levels, but the baseline of the measurement may shift over time.
It is normal if the concentration value is slightly higher or lower than its original
calibration.
The CO2 sensor has a self-correction mechanism to make the sensor more in line with
the current installation environment, so that the value can be more accurate.
To start the calibration, please follow the directions.
Auto calibration
To provide correction for the optimal CO2 concentration for the current environment,
the calibration mechanism will collect the CO2 concentration value for 25 consecutive
hours to meet the temperature and humidity of the current space.
During the automatic calibration, do not interrupt or turn off the power supply. Do not
move the IFP and make sure that the device is in an environment with good ventilation,
to ensure a better calibration result.

OPS interface11
Three main features
Whiteboard, File manager, and Conference are three main feature shortcuts.
The corresponding Apps for three main feature shortcuts are:
• Whiteboard: EZWrite Live.
Press Whiteboard, and you will see a pop-up window asking you which browser you
want to proceed. Select Google Chrome and always use the app.

OPS interface 12
EZWrite Live makes distance discussion and collaboration easier.
• File manager: Windows file manager
Windows file manager is a familiar file management method for users.
• Conference: Skype for Business
Skype for Business supports video conferences.

OPS interface13
Side Tool Bar
Function Description
Windows Launcher ( ) Switch between Windows desktop mode and Windows
launcher.
Windows Task View ( ) Support Windows task view for multi-windows behavior.
Refer to Windows Task View on page 14 for more
information.
Windows Ink ( ) Support Windows ink snapshot for painting and
discussion. Refer to Windows Ink on page 15 for more
information.
EZWrite Live ( ) Support EZWrite Live for distance discussion.

OPS interface 14
Windows Task View
Windows Task View enables you to work more efficiently with multiple apps. With it,
you can quickly jump between open applications and spread projects onto separate
desktops.
1. Press and you will see your running applications listed in the middle of the screen.
2. Long press and release an app to access its menu to perform common tasks,
including the ability to move the app to the left or right of the screen, to show
windows across desktops, or to quickly close the app.

OPS interface15
Windows Ink
Windows Ink enables you to share your ideas or draw on screenshots with your pen in
the Windows Ink Workspace.
1. Press and you can take a screenshot.

OPS interface 16
2. You can draw on whatever you're doing on your display at the moment. All
sketchpad tools are in Snip & Sketch.

OPS interface17
Quick Control
1. Press to open Quick Control.
2. You can switch to Desktop mode, control Internet, Bluetooth, and Connect.
