DesignerPlus V6 - Carving Stamps
Open a New File
• Select File/New or click on the New File icon.
• Right click on Show Hoop.
• Make sure Display Hoops is checked and select artista 400 x
150 Mega—Auto Split Machines.
Draw the rectangles
• Select C42 from the Color Bar.
• Select the Rectangle tool and draw a rectangle by clicking in the
upper left hand corner and dragging to the lower right hand cor-
ner.
• Press Escape.
• Select the rectangle and open Object Properties. Click on the
General tab. Make sure Proportional Scaling is turned off.
• Change the width of the rectangle to 70 mm and the height to
85 mm. Click OK.
• Quick Clone (right click and drag on the object) to make a copy
of the rectangle. Move the copy in a below the first rectangle.
• Clone the second rectangle; position below the second object.
• Select File/Save As.
• Navigate to the folder in which the file will be stores. Name the
file Carving Stamps. Click Save.
Using an Object for a Stamp
• Select File/Insert Design.
• Navigate to My Computer/C: My Designs Embroidery Software
6. Select the Animal folder. Open the folder.
• Select FB 253-48. Open the file.
• Decrease the size of the dragonfly by clicking and dragging on
one of the corner black sizing handles. Move it away from the
rectangles.
Note: Decrease th object so that it will fit within the rectangle, or
use the stamp so that only part of the object stamps the back-
ground.
• Open the Carving Stamp dialog box.
• Click on the Use Object Tab.
• Click on the Start Selecting button and use one of the selection
tools to select the dragonfly. The dragonfly will appear in the
Use Object window. Press Esc.
• Select one of the rectangles. Click on Use Stamp—the outline
of the stamp is visible.
Notes:
Carving stamp defines a pat-
tern of needle penetrations in
a fill. There are three different
ways to stamp— use a de-
sign, use a built-in stamp, or
create a custom stamp.
Any of the selection tools be
used to select the object that
will be used as a stamp.
Select part of the object by
drawing the bounding box
around part of the design or
by using Polygon Select
(remember to first ungroup).
Add stamps to selected back-
ground objects or choose to
not pre-select an object and
add the stamp to other ob-
jects.
Follow the prompts on the
lower left corner of the screen
for information on setting the
stamps.

2009 BERNINA®of America, Inc DL Page 2 of 3
• Click on one of the rectangles at the point where the
stamp will be places and move the cursor to rotate the
dragonfly as desired. Click a second time to set the stamp.
Press Esc to deactivate the stamp.
• Click on the inserted dragonfly design, Delete.
Changing the background + stamp appearance proper-
ties
• Select the rectangle. Open Object Properties.
• Click on the Fill Stitch Tab. Select Step Stitch 6; click Ap-
ply.
• Click on the Stitch Angle Tab and change the stitch angle
to 0.°
• Click OK to activate the changes and close the dialog box.
• Click on the Appearance tab of the Carving Stamp dialog
box and select Softened Stamp.
Using a pattern for a stamp
• Select the Use Pattern tab from the Carving stamp dialog
box.
• From the Set selection drop down menu choose Carving
Stamps. Scroll down to select Ring Ellipse..
• Select the ellipse. Notice that it now appears in the win-
dow.
• Select another rectangle.
• Click Use Stamp.
• To set the stamps, click on the base fill and rotate the cur-
sor to rotate the stamp as desired; click again to set the
stamp at that angle.
⇒ To increase the size of the stamp, hold the shift key
down, and drag the cursor away from the first click and
click again once the stamp reaches the desired size.
⇒ To decrease the size of the stamp, hold the shift key
down and drag the cursor toward the first click and click
again once the stamp reaches the desired size.
• Stamp the background fill as desired. Press Esc.
• Select the background rectangle. Open Object Properties
and select the Angle tab. Set the stitch angle to 90° and
click on OK.
• To remove stamps created, click, Clear All Stamps in the
Appearance tab.
Notes:
The stamp will remain active
for multiple uses until the Es-
cape key is pressed.
To save an object as a stamp
for future use, it must be
saved by adding it to the li-
brary.
Vary the type of the back-
ground fill and the angle of
the fill, for different effects.
Carving stamps can be used
with satin, step or fancy fills.
They may also be used with
satin outlines.
