Bessacarr E330 User manual

Bessacarr Motorhomes
Owner's Service Handbook

Motorhome Details
IMPORTANT Enter all your motorhome details on this page (see specification in rear of this handbook).
Supplied and Pre-delivery Inspection by:
Registration Number
Serial Number
Chassis Number
Delivery Date
Key Number
Overall Length
Overall Width
Maximum External Height
Mass in Running Order
User Payload
Maximum Technical Permissible Laden Mass
Tyre Size Front: Rear:
Service History
Signed/Dealer Date

CONTENTS
Annual Inspection Record.................................................2
Annual Servicing Record..................................................4
Warranty............................................................................7
Specifications....................................................................8
Water Capacities...............................................................9
Jacking............................................................................10
Wiring Diagrams..............................................................11
Bulb Replacement ..........................................................13
Change of Ownership

Annual Inspection
MOTORHOMES - ANNUAL INSPECTION RECORD
In order to comply with the warranty, you must have your motorhome inspected and
serviced by an authorised appointed Swift Group Dealer at least once per year.
It is important that the owner’s handbook is stamped on the appropriate page by the
appointed Swift Group Servicing Dealer. Failure to do this will invalidate the warranty and
the transfer of the warranty on the change of ownership.
The inspection should take approximately two hours and will cover the areas dealt with in
the annual service check list. Any areas requiring service and/or maintenance will be
highlighted by your dealer and we recommend that you authorise any necessary work to be
carried out.
NB. It is essential, to validate the warranty, that an annual inspection be carried out by an
appointed Swift Group Dealer covering the items listed.
1. Damp and lamination test.
2. Chassis and chassis to body security.
3. Corner steadies.
4. Motorhome step.
5. Road lights, wiring and reflectors.
6. Internal lights and 12V DC system.
7. Water heater — gas and 230V AC.
8. Hob, grill and oven.
9. Refrigerator 230V AC, 12V DC and gas.
10. Gas system.
11. Water pump, taps and water system.
12. Mains 240V AC system.
13. Windows and fittings.
14. Roof lights.
15. Furniture hinges/stays etc.
16. Exterior locks and hinges.
17. All internal vents.
18. Seals.
19. Blinds and fly screens.
20. Blown air heating and gas fire systems.
2

Inspection Record
ANNUAL INSPECTION RECORD
MOTORHOME MODEL REGISTRATION NUMBER
CHASSIS NUMBER REGISTRATION DATE
3
1st INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
2nd INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
3rd INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
4th INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
5th INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.
6th INSPECTION
DATE:
DEALER’S
STAMP
We certify that an annual inspection has been
carried out in accordance with the handbook.

Service Record
MOTORHOMES - ANNUAL SERVICE RECORD
Just as the engine/gearbox/roadwheels need regular servicing by your chassis dealer,
so there are components in your conversion that need regular maintenance by your
motorhome dealer.
These include the gas and electrical systems and the seals in the bodywork. Your dealer
will complete the record in this handbook to show that the work has been carried out.
4
1. Chassis and chassis to body security.
2. Corner steadies.
3. Motorhome step.
4. Tyres and tyre pressures.
5. Torque wheel nuts.
6. Road lights, wiring and reflectors.
7. Internal lights and 12V DC system.
8. Damp and lamination test.
9. Water heater — gas and 240V AC.
10. Hob, grill and oven.
11. Refrigerator 240V AC, 12V DC
and gas.
12. Gas system.
13. Water pump, taps and water system.
14. Mains 240V AC system.
15. Windows and fittings.
16. Roof lights.
17. Furniture hinges/stays etc.
18. Exterior locks and hinges.
19. All internal vents.
20. Seals.
21. Blinds and fly screens.
22. Blown air heating and gas fire systems.

Service Record
5
ANNUAL SERVICE RECORD
MOTORHOME MODEL REGISTRATION NUMBER
CHASSIS NUMBER REGISTRATION DATE
1st SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
2nd SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
3rd SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
4th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.

6
5th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
6th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
7th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
8th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
9th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.
10th SERVICE
DATE:
DEALER’S STAMP
We certify that an annual service has been carried out in
accordance with the handbook.

Warranty
All the illustrations and descriptive matter in
this service book are intended to give a
general idea of the motorhome. Changing
market and supply situations and our policy
of continuous product development may
prevent us from maintaining the exact
specifications detailed in this service book.
We therefore reserve the right to alter
specifications as materials and conditions
demand.
Dealers are not agents of Swift Group
Limited, and have absolutely no authority to
bind the manufacturer by any express or
implied undertaking or representation.
All motorhomes (other than the engine,
chassis cab and associated parts referred
to earlier in this handbook which are
subject to the relevant Fiat/Peugeot/VAG
warranty) have a 12 month warranty from
the date of purchase (or hire purchase). This
covers faults arising from a manufacturing
defect but not those which are a result of
normal wear and tear. The manufacturer will
honour the warranty for up to 60 days after
the end of the 12 months to enable the first
chargeable annual service to be carried out
and the SuperSure extended warranty (see
below) to commence.
The warranty will be invalidated if the
motorhome has been neglected, misused,
modified or used for hire or reward. The
motorhome will be deemed to have been
neglected if it has not been serviced and
maintained as stated in this service book.
Every owner of a new motorhome benefits
automatically from the SuperSure extended
warranty, covering the conversion element
of the motorhome, (i.e. other than the
engine, chassis cab and associated parts
referred to earlier in this service book which
are subject to the relevant Fiat/Peugeot/
VAG warranty) for years 2 and 3 from the
date of purchase. The detailed terms of the
extended warranty are set out in the
separate SuperSure policy document.
Your dealer should register you for cover
under the SuperSure extended warranty at
the time your new motorhome is handed
over to you. It is important to check this
registration has been completed to confirm
that the motorhome is registered under the
SuperSure Extended Warranty Scheme for
years 2 & 3.
The cost of transporting, towing or moving the
motorhome by any means to or from the place
of repair is the responsibility of the owner.
The benefit of this warranty may be transferred
to a new owner if the motorhome is sold,
provided that the motorhome has been
serviced by an authorised dealer in
accordance with the requirements of this
service book, and details of the change of
ownership form set out in this service book.
Failure to notify a change of ownership within
14 days of such change will invalidate the
warranty.
The benefit of the SuperSure extended
warranty may be transferred to a new owner if
the motorhome is sold in accordance with the
procedure detailed in the separate SuperSure
policy document.
This warranty only applies to motorhomes
purchased in the UK.
The above conditions in no way affect your
statutory rights in respect of the motorhome.
7

Specification
8
*Estimated
MODEL E330 E 350 E 370 E425 E705 E725 E745 E765 E795
Designated Passenger Seats 2 1 1 3 1 1 1 2 + 1Optional
Overall Length 5.19m/17'1" 5.19m/17'1" 5.92m/19'5" 5.96m/19'6" 6.40m/21'0" 6.40m/21'0" 7.26m/23'10" 7.26m/23'10"
Overall Width 2.11m/6'10" 2.11m/6'10" 2.13m/7'0" 2.13m/7'0" 2.13m/7'0" 2.13m/7'0" 2.13m/7'0" 2.13m/7'0"
Overall Height 2.66m/8'9" 2.66m/8'9" 2.83m/9'3" 3.07m/10'1" 3.07m/10'1" 3.07m/10'1" 3.07m/10'1" 3.07m/10'1"
Maximum Technical 2800kg 2800kg 3400kg 3400kg 3400kg 3400kg 3400kg 3400kg
Permissible Laden Mass (A) (3850kg optional) (3850kg optional)
Mass in Running Order (B) 2405kg 2385kg 2573kg 2737kg 2833kg 2781kg 2924kg* 2924kg
Maximum User Payload (A-B) 395kg 415kg 827kg 663kg 567kg 619kg 476kg 476kg
Essential Habitation Equipment 100kg 100kg 143kg 124kg 152kg 152kg 143kg 143kg
BED SIZES
Front Double 1.83m x 1.78m - - 1.85m x 2.00m 1.36m x 2.00m -1.89m x 2.00m -
6'0" x 5'10" 6'1" x 6'7" 4'6" x 6'7" 6'3" x 6'7"
Front Single - - - 1.85m x 0.69m - - 1.89m x 0.69m 1.89m x 0.90m
-6'1" x 2'3" 6'3" x 2'3" 6'3" x 2'11"
Front Single - - - 1.85m x 0.90m - - 1.89m x 0.69m
6'1" x 2'11" 6'3" x 2'3"
Rear Double -1.83m x 1.22m 2.01m x 1.30m - - 1.30m x 2.00m -1.89m x 2.00m
6'0" x 4'0" 6'7" x 4'3" 4'3" x 6'7" 6'3" x 6'7"
Rear Single - - - - - - - 1.89m x 0.69m
6'3" x 2'3"
Rear Single - - - - - - - 1.89m x 0.69m
6'3" x 2'3"
Nearside Single 1.78m x 0.66m - - - - - - -
5'10" x 2'2"
Offside Single 1.83m x 0.64m - - - - - - -
6'0" x 2'1"
Optional Overcab Bed --2.01m x 1.32m 2.00m x 1.33m 2.00m x 1.33m 2.00m x 1.33m 2.00m x 1.33m 2.00m x 1.33m
(Not on 'Esprit') 6'7" x 4'4" 6'7" x 4'4" 6'7" x 4'4" 6'7" x 4'4" 6'7" x 4'4" 6'7" x 4'4"
Optional Children's top bed 1.83m x 1.42m - - - - -
6'0" x 4'8"
NOTE: 1. The Maximum User Payload includes: a) the conventional load (this is the allowance for passengers)
b) essential habitation equipment (items and fluids required for safe and proper functioning of habitation equipment)
c) optional equipment (items available from the manufacturer over and above the standard specification)
d) personal effects (those items not covered by the above)
2. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE ALLOWED FOR THE MASSES OF ALL ITEMS YOU INTEND TO CARRY IN THE MOTORHOME,
e.g. passengers, optional equipment, essential habitation equipment and personal effects, such as clothing, food, pets, bicycles, sailboards, sports equipment etc.
3. WARNING - UNDER NO CIRCUMSTANCES SHOULD THE MAXIMUM TECHNICALLY PERMISSIBLE LADEN MASS OF THIS MOTORHOME BE EXCEEDED.

Water Capacities
9
CAPACITIES (litres) Fresh Water Tank Waste Water Tank Water Heater
Bessacarr 425, 700 range (except 725) 80 70 10
Bessacarr 725 90 70 10
Bessacarr 300 range 68 38 10
NOTICE
For technical data on the base vehicle please refer to your Fiat/Peugeot or VW handbook

Jacking
10
E600/E605/E625/E645/E695
E425
E350/E370
Jacking Points:

Wiring Diagrams
11
E300 RANGE

Wiring Diagrams
12
E425 RANGE

Wiring Diagrams
13
E700 RANGE

Bulb Replacement
14
Type Power E300 Series E400 Series E700 Series
EXTERIOR LIGHTS
Fiat Cab
Full beam headlight H4 12V-55/60W ✓ ✓ ✓
Dipped beam headlight H4 12V-55/60W ✓ ✓ ✓
Front side lights R5W 12V-5W ✓ ✓ ✓
Front directional indicators P21W 12V-21W ✓ ✓ ✓
Side directional indicators W5W 12V-5W ✓ ✓ ✓
Fiat Rear Light Cluster (Chassis Cab)
Rear directional indicators PY21W 12V-21W ✓
Brake lights P21W 12V-21W ✓
Reversing lights (RH side) P21W 12V-21W ✓
Rear foglight (LH side) P21W 12V-21W ✓
Side light R5W 12V-5W ✓
Fiat Rear Light Cluster (Hightop)
Rear directional indicators PY21W 12V-21W ✓
Brake lights P21W 12V-21W ✓
Reversing lights P21W 12V-21W ✓
Rear foglight/taillight (Twin bulb) P21/4W 12V-21/4W ✓
Hella Rear Light Cluster
Rear side light P21/5W 12V-21/5W ✓
Rear directional indicator PY21W 12V-21W ✓
Fog lamp (LH side) P21W 12V-21W ✓
Reversing light (RH side) P21W 12V-21W ✓
Note: Not all lights and bulbs feature on all models within a range

Bulb Replacement
15
Type Power E300 Series E400 Series E700 Series
EXTERIOR LIGHTS
Britax Valeo Rear Light Cluster
Rear directional indicator P21W 12V-21W
Stop lamp P21W 12V-21W
Position lamp R10W 12V-10W
Reverse lamp P21W 12V-21W
Fog lamp P21W 12V-21W
Fiat number plate light CW5 12V-5W ✓ ✓
Number plate light C5W 12V-5W ✓
Number plate light R19-10W 12V-10W
Number plate light C11-5W 12V-5W
Front marker light W5W 12V-5W ✓
Rear marker light W5W 12V-5W
Rear marker light R19-5W 12V-5W ✓
Red/white side marker light C5W 12V-5W ✓
Amber side marker light W5W 12V-5W ✓
Awning light L245 12V-10W ✓
INTERIOR LIGHTS
Lumo 1 Fluorescent 300mm 12V-8W ✓ ✓ ✓
Lumo 3 Fluorescent 300mm 12V-8W
Round ceiling lights Halogen G4 12V-20W ✓
Downlights Halogen G4 12V-10W ✓ ✓
Spot lights Halogen G4 12V-10W ✓ ✓
Cab interior ceiling light CW5 12V-5W ✓ ✓ ✓
Note: Not all lights and bulbs feature on all models within a range

DETAILS OF MOTORHOME: Model:
Chassis No:
Registration No:
Serial No:
CURRENT OWNER: Name:
Address:
NEW OWNER: Name:
Address:
Ownership
NOTIFICATION OF CHANGE OF OWNERSHIP
If you sell your motorhome, please notify the change of ownership by completing this page, detaching it and sending it to:
Swift Group Ltd., Dunswell Road, Cottingham, East Yorkshire, HU16 4JX.
Please note that the benefit of any unexpired warranty cannot be transferred to the new owner until the change of
ownership details above have been received.

Bessacarr Motorhomes,Dunswell Road, Cottingham, East Yorkshire HU16 4JX.
Tel: [phone] Fax: [phone] e-mail/web site: www.swiftleisure.co.uk
A MEMBER OF THE SWIFT GROUP
Issued September 1999 9830017
INDIVIDUALLYSTYLED, B EAUTIFULLY B UILT
