Better Homes and Gardens BG2503B-DG User manual

1
OUTDOOR 3 BURNER GAS GRILL
MODEL NO.:BG2503B-DG
VENDOR STOCK NO.: BH15-101-099-03
BH15-101-099-08
BH15-101-099-09
BH15-101-099-10
Call Customer Service Hotline
1-855-242-6887
WARNING
For Outdoor Use Only (outside any enclosure)
WARNING
1. Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage.
2. Read this instruction manual thoroughly
before installing or servicing this equipment.
3. Failure to follow these instructions could
result in fire or explosion, which could cause
property damage, personal injury or death.
4. This instruction manual contains important
information necessary for proper assembly and
safe use this appliance.
WARNING
1. Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
2. An LP tank not connected for use should not
be stored in the vicinity of this or any other
appliance.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open the lid.
4. If the odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
DANGER
Never operate this appliance unattended.
Save these instructions for future reference.
If you are assembling this unit for someone else,
give this manual to him or her to read save for
future reference.
DO NOT RETURN YOUR GRILL TO THE STORE
Question, problems, missing parts? Don’t return the grill to stores, please call our customer service
department at 1-855-CHANT-US (1-855-242-6887) from 8:00am to 5:00pm Eastern time, Monday
through Friday for assistance.

2
Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this
manual before attempting to use this gas barbecue grill to prevent possible bodily injury or
property damage.
Always keep this manual for convenient future reference.
WARNING
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
should not be stored in the vicinity of
this or any other appliance.
DANGER
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open flame
3. Open lid
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.

3
TABLE OF CONTENTS
Cover …………….…………………………………….………...….………….………….….………...1
Table of contents……………………………………….………...….………….……………………..3
Safety Information…………………………………….………...….………….….…………………..4
Exploded View……………….………………………………………………......................…..…. ...7
Parts list….……………..…..….……...…...................……………....………………............ .. ... ...8
Hardware Contents……………………………………………………………….……………………9
Assembly Instructions……………………..……………….………………………………………...11
Natural Gas Conversion…………………….. ……………….…………………… ………………17
L.P. Propane Gas Installation………….……...………………………….....................20
Operating Instructions………… ………………...…………………………............... ...................24
Lighting Instructions………… ………………...…………………………............... ...................27
Care and Maintenance……………………………….………………………………………………28
Troubleshooting …………………………………………………………………..….……………...30
Warranty………………………………………………………………………………………………..32

4
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or
install the product. If you have any questions regarding the product, please call our
customer service at 1-855-CHANT-US(1-855-242-6887) from 8:00am to 5:00pm Eastern
time, Monday through Friday for assistance.
The installation and repairs of this appliance must conform with local codes or, in the absence of local odes,
with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation
Code, CSA/CGA-B149.1.
All pipe sealants must be an approved type and resistant to the actions of L.P. gases. Never use pipe
sealant on flare fittings. All gas connections should be made by a competent qualified service technician and
in accordance with local codes and ordinances. In the absence of local codes, the installation must comply
with the National Fuel Gas Code, NFPA 54-2002/ANSI Z223.1-2002.
This grill must be isolated from the gas supply piping system by closing its individual manual shut-off valve
during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 PSI
(3.5 kPa.).
This grill is intended for use outdoors and should not be used in a building, garage or any other enclosed or
covered area.
A minimum clearance of 24 inches from combustible constructions to the sides of the grill and 24 inches
from the back of the grill to combustible constructions must be maintained. This outdoor cooking gas
appliance must not be placed under overhead combustible construction.
Natural Gas (NG) Characteristics:
a. NG is flammable and hazardous if handled improperly. Become aware of the characteristics before using
any NG products.
b. NG is explosive under pressure, heavier than air and settles and pools in low areas.
c. NG in its natural state has no odor. For your safety, an odorant is added than smells like rotten cabbage.
d. Contact with NG can cause freeze burns to skin.
Do not block holes in sides or back of the grill.
A fire causing, serious bodily injury or damage to property may occur if above is not followed exactly.
The use of alcohol, prescription or non- prescription drugs may impair the consumers’ ability to properly
assemble or safely operate the appliance.
Never use charcoal, lighter fluid, lava rocks, gasoline, kerosene or alcohol with this product.
Check for leaks even if your unit was assembled for you by someone else.
Do not operate if gas leak is present. Gas leaks may cause a fire or explosion.
You must follow all leak-checking procedures before operating. To prevent fire or explosion hazard when
testing for a leak:
a. Always perform leak test before lighting the grill and each time the tank is connected for us.
b. No smoking. Do not use or permit sources of ignition in the area while conducting a leak test.
c. Conduct the leak test outdoors in a well-ventilated area.
d. Do not use matches, lighters, or a flame to check for leaks.
e. Do not use grill until any and all leaks are corrected.
If you can unable to stop a leak, turn off the main valve on the NG supply line. Call a gas appliance
serviceman or your local NG supplier.
Never attach an unregulated gas line to the appliance. Connection to an unregulated gas line can cause
excessive heat or fire.
The appliance and its individual shutoff valve must be disconnected from the gas supply piping system
during any pressure testing of that system at pressures in excess of 1/2 psig (3.5kpa).
The appliance must be isolated form the gas supply piping system by closing its individual manual shutoff
valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2
psig (3.5kpa).
Do not store or use gasoline or other flammable liquids or vapors within 25 feet (7.62 m) of this appliance.
Do not use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline
and other flammable vapors and liquids.
It is essential to keep the grill’s valve compartment, burners and circulating air passages clean.
Use only the gas pressure regulator supplied with this appliance. This regulator is set for an outlet pressure
of 11.0 wc.
The cylinder used must include a collar to protect the cylinder valve.
Do not store a spare LP-gas cylinder under or near this appliance.
Do not alter grill in any manner. Any alteration will void your warranty.
Do not use grill in high winds.

5
SAFETY INFORMATION
Do not use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.
Do not build this model of grill in any built-in or slide in construction. Ignoring this warning could cause a fire
or an explosion that can damage properly and cause serious bodily injury or death
This grill should be thoroughly cleaned and inspected on a regular basis.
Clean and inspect the hose before each use of the appliance. If there is evidence of abrasion, wear, cuts or
leaks, hose must be replaced prior to the appliance being put into operation.
Use only the regulator and hose assembly provided. The replacement regulator and hose assembly shall be
that specified by the manufacturer.
Use only Chant Kitchen Equipment (H.K.) Ltd. company authorized
parts. The use of any part that is not company authorized can be
dangerous. Doing so will also void your warranty.
Never fill the cylinder beyond 80 percent full.
Only a 20 lb. LP-gas cylinder is allowed. The cylinder must be
constructed and marked in accordance with the Specifications for LP
Gas Cylinders of the U.S. Department of Transportation (D.O.T.) or the
National Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and
Tubes for Transportation of Dangerous Goods; and Commission.
A 20 lb. LP-Gas cylinder’s dimensions are:
Inspect grill before each use.
Do not operate this appliance without reading “Operating Instructions”
in this manual.
This grill is designed with to operate at an inlet pressure of: LP gas: 11 inches water column; NG 7inches
water column.
Never operate grill without heat plates installed.
Do not leave a lit grill unattended, especially keep children and pets away from grill at all times.
Always use a meat thermometer to ensure food is cooked to a safe temperature.
Use protective gloves when assembling this product.
Do not force parts together as this can result in personal injury or damage to the product.
Never lean over the grill when lighting.
Do not place empty cooking vessels on the appliance while in operation.
Use caution when placing anything on the grill while the appliance is in operation.
Do not touch metal parts of grill until it has completely cooled (about 45 minutes) to avoid burns, unless you
are wearing protective gear (pot holders, gloves, BBQ mittens, etc…).
Do not attempt to move grill when in use. Allow the grill to cool before moving or storing.
Always open grill led carefully and slowly as heat and steam trapped within grill can severely burn you.
Do not attempt to disconnect the gas regulator from the tank or any gas fitting while the grill is in us.
Always place your grill on a hard, on-combustible, level surface. An asphalt or blacktop surface may not be
acceptable for this purpose.
Move gas hoses as far away as possible from hot surfaces and dripping hot grease.
Keep all electrical cords away from a hot grill
After a period of storage and/or nonuse, check for leaks, burner obstructions and inspect for any abrasion,
wear or cuts to the hose.
Failure to open lid while igniting the grill’s burners, or not waiting 5 minutes to allow the gas to clear if the grill
does not light, may result in an explosive flam-up.
All electrical accessories (such as rotisserie) must be electrically grounded in accordance with local codes,
or National Electrical Code, ANSI / NFPA 70 or Canadian Electrical Code, CSA C22.1. Keep any electrical
cords and/or fuel supply hoses away from any hot surfaces.
When cooking, fire extinguishing materials shall be readily accessible. In the event of an oil/grease fire, do
not attempt to extinguish with water. Use type BC dry chemical fire extinguisher or smother with dirt, sand or
baking soda.
Do not leave grill unattended while preheating or burning off food residue on high if grill has not been
cleaned, a grease fire can occur that may damage the product.
To protect against electric shock, do not immerse cord or plugs in water or other liquid.
Unplug from the outlet when not in use and before cleaning. Allow to cool before putting on or taking off
parts.
Do not let the cod hang over the edge of a table or touch hot surface.
Do not use an outdoor cooking gas appliance for purposes other than intended.
When connecting, first connect plug to the outdoor cooking gas appliance then plug appliance into the
outlet.

6
SAFETY INFORMATION
Use only a ground Fault Interrupter (GFI) protected circuit with this outdoor cooking gas appliance.
Never remove the grounding plug or use with an adapter of 2 prongs; and use only extension cords with a 3
prong grounding plug, rated for the power of the equipment, and approved for outdoor use with a W-A
marking.
OUTDOOR USE ONLY. DO NOT EXPOSE TO RAIN.
CAUTION: Risk of Electric Shock. Keep extension cord connection dry and off the ground.
Use only on properly grounded outlet.
Deaths, serious injury or damage to properly may occur if the above is not followed exactly.
Never cover entire cooking area with aluminum foil.
CALIFORNIA PROPOSITION 65 WARNING:
(a)The burning of gas cooking fuel generates some byproducts which are on the list of substances known
by the State of California to cause cancer, reproductive harm, or other birth defects. To reduce exposure to
these substances, always operate this unit according to the use and care manual, ensuring you provide
good ventilation when cooking with gas.
(b)Handling the brass material on this product exposes you to lead, a chemical known to the State of
California to cause cancer and birth defects or other reproductive harm. Wash hands after handling.
(c)This product contains chemicals, including lead and lead compounds, known by the State of California to
cause cancer, reproductive harm, or other birth defects.
(d) Wash your hands after using this product.
IMPORTANT: We urge you to read this manual carefully and follow the recommendations
enclosed. This will ensure you receive the most enjoyable and trouble-free operation of
your new gas grill. We also advise you retain this manual for future reference.
WARNING: Your grill has been designed to operate using only the gas specified by
the manufacturer on the rating plate. Do not attempt to operate your grill on other gases.
Failure to follow this warning could lead to a fire hazard and bodily harm and will void your
warranty.
WARNING: Make certain your LP (propane) tank is filled by a reputable propane
dealer. An incorrectly filled or an overfilled LP tank can be dangerous. The overfilled
condition combined with the warming of the LP tank (a hot summer day, tank left in the
sun, etc.) can cause LP gas to be released by the pressure relief valve on the tank since
the temperature increase causes the propane to expand. LP gas released from the tank is
flammable and can be explosive. Refer to your Owner’s Manual for more information
concerning filling your LP tank.

7
EXPLODED VIEW

8
PARTS LIST
PART
DESCRIPTION
PART NO
QTY
1
※Temperature gauge
2406912
1
2
※Logo plate
2403888
1
3
※Lid assembly
2503B01
1
4
※Lid handle
5204364
1
5
※Lid handle bezel
5201176
2
6
※Lid spacer
2404055
2
7
※Side shelf support A
5204378
2
8
※Side shelf support B
5204377
2
9
※Tube burner
2409592
3
10
※Ignition Pin
2409585
3
11
Side shelf assembly
5204376
2
12
※Manifold & gas valve assembly
5207352
1
13
※Knob bezel
5003958
3
14
Knob
2404062
3
15
Cooking grate
2405330
2
16
Door assembly
2503B02
1
17
※Right grease tray Support
5202069
1
18
Right leg assembly
5204385
1
19
※Match-Light Extension
2307247
1
20
Unlockable Castor
2404362
2
21
Lockable castor
2100504
2
22
Side panel
5204384
2
23
Bottom bar
5204437
1
24
※Door handle
5204382
1
25
※Door handle bezel
5201175
2
※：NO ASSEMBLY REQUIRED

9
PART
DESCRIPTION
PART NO
QTY
26
Bottom panel
5204383
1
27
※Magnet
2300824
1
28
Top front door brace
5204379
1
29
※Reinforcing bar
5207382
2
30
※Hose clip hook
2405337
1
31
※Gas cylinder hook
2406914
1
32
Grease tray assembly
5109447
1
33
※Left grease tray Support
5202068
1
34
Left leg assembly
5204386
1
35
Grease cup
5201953
1
36
※Regulator & hose assembly
5204132
1
37
※Control panel assembly
5207381
1
38
Heat tent
5204371
3
39
※Heat Shield
5204372
1
40
※Firebox assembly
2503B03
1
41
Warming rack
2406969
1
42
※Firebox spacer
2100158
2
43
Lid axis
2307067
2
44
※Electronic Igniter
2306323
1
45
※Burner Support
5204373
3
46
※NG conversion Kit
5207434
1

10
HARDWARE CONTENTS
ASSEMBLY PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not
attempt to assemble the product.
NOTE: Some parts come with screws pre-installed. Loosen and tighten for final assembly.
Estimated Assembly Time: 30 mins by two people
Tools required for assembly:
Phillips Head
Screwdriver (Not included)
QTY: 1pc
17X19 Wrench
(Included)
QTY:1pc
19
17
X1
EE orifice removal tool
X17
AA M6X12 mm Screw
BB Wrench X1
DD Orifice X3
FF 一字螺丝批
X1
X1
CC AA Battery

11
ASSEMBLY INSTRUCTIONS
IMPORTANT: ASSEMBLE ON FLAT AND SOFT SURFACE TO AVOID SCRATCHING.
AA M6X12mm Screw X2
AA M6X12mm Screw X6
BB Wrench X1
3. Attach Unlockable Castors (20) and
Lockable Castors (21).
Note: The Unlockable Castors should be
at front.
1. Attach Bottom Bar (23) at the front of
Bottom Panel (26), on the opposite edge
with only one hole as shown.
Note: Assemble the Bottom Bar
4. Untie the Reinforcing Bar (29) from the legs
and fix them to bottom panel by using AA screw
as shown.
2. Attach Left side Panel Assembly and
Right side Panel Assembly on Bottom
Panel.
AA M6X12mm Screw X1

12
ASSEMBLY INSTRUCTIONS
AA M6X12mm Screw X4
8. Slide the Grease Tray Assembly (32) and
Grease Cup (35) from the back of the grill as
shown.
AA M6X12mm Screw X4
7. Attach Fire Box Assembly (40) onto the
cart.
5. Attach Top Front Door Brace (28).
6. The Regulator & Hose (36) is located inside
of the control panel. Please untie it before you
put the firebox onto the cart like the picture
shown.
Then attach the Control Knobs (14) onto
Bezels.

13
ASSEMBLY INSTRUCTIONS
11. Hang Side Shelf Assembly (11) by aligning the slots into side table supports ( See Fig. 1).
Lift the side shelf and slide it into the right position as per Fig.2 shows. Press the side shelf down
until it is fully fastened in place ( See Fig.3).
10. Attach door (16) to the cart.
Fig. 1
9. Pull out the hose clip hook (30) and
secure the hose into the hook.

14
ASSEMBLY INSTRUCTIONS
12. Insert Heat Tents (38), Cooking Grates (15) and Warming Rack (41).
Place AA battery into the Igniter with the positive (+) end facing out.
Your grill is now assembled.
Fig. 2
Fig. 3

15
NATURAL GAS CONVERSION
PREPARATION:
Before beginning conversion, make sure all parts are present. Compare parts with package
contents. If any part is missing or damaged, do not attempt to convert. Please have your owner’s
manual and part number available for reference, and contact customer service 1-855-242-6887
for replacement parts.
1. Turn off gas supply and then remove cap on gas supply side.
2. Recommended: Install a shut-off valve on gas supply side before installing the socket.
3. Socket should be installed by an authorized technician in accordance with the national fuel
gas code (NFPA 54/ANSI223.1).
4. Before inserting plug, turn on gas supply and leak test all connections including the stem of
the shut-off valve and the opening of the socket. For best results, use an ammonia-free
soap and water solution.
Leak Check
When checking for gas leaks, do not use an open flame. Use a soapy water solution and apply it
to the pipe joints and fittings with a brush and check for bubbles. Check flexible hoses for cuts
and wear that may affect the safe operation of the grill. Only use original equipment replacement
hoses. Use only replacement hose assemblies specified by manufacturer.
Before operating your grill, after refueling, check carefully to be certain that all connections
are tight and there are no gas leaks.
1. Make 2-3 ounces of leak solution by mixing liquid dishwashing soap with water.
2. Make certain all control knobs are in the “OFF” position.
3. Brush small amounts of the leak solution on all the fittings and turn the gas on.
4. If bubbles appear, there is a leak. Proceed to step 5.
5. Turn the gas off and tighten all connections.
6. Go back to step 1 to retest the fittings.
7. If bubbles continue to appear, turn the gas off. Contact customer service.
WARNING: Never use a match or open flame for leak detection. Use of an open flame could
result in a fire, explosion and bodily harm.
IMPORTANT: When connecting or replacing any gas pipe or fittings, all joints must be sealed with
approved leak-proof sealing compound or plumber's tape.
IMPORTANT: When connecting or replacing gas pipe or fittings, all joints must be sealed with
approved leak-proof sealing compound or plumber's tape. After making connections, check all
joints for leaks using a soapy water solution and a brush.
WARNING: Never use an open flame to test for gas leaks. Use of an open flame could
result in a fire, explosion and bodily harm.

16
NATURAL GAS CONVERSION
IMPORTANT:
After your grill is converted to natural gas, the working pressure for natural gas is 7 in. water
column (WC). Gas pressure is affected by gas line size and the length of gas line run from house.
Follow the recommendations in the chart below.
NG Conversion Kit ( Part No. 5207434) Package Content:
Orifice 1.45 mm
QTY: 3pcs
Orifice removal tool
QTY:1pc
NG Rating Label
QTY: 1 pc
NG Conversion Instruction
QTY: 1 pc
※The Natural Gas Conversion Pack is located inside of the door.
Tools required for assembly (Not Included):
12X3mm
Slotted Screwdriver
QTY: 1pC
17X19mm Wrench
QTY:1pc
NG Hose
QTY: 1 pc
19
17
From House to Grill
Distance
Tubing Size
Up to 25 ft.
3/8 in. DIA
26 –50 ft.
1/2 in. DIA
51 –100 ft.
2/3 in. of run 3/4 in.
1/3 in. of run 1/2 in.
More than 101 ft.
3/4 in. DIA

17
NATURAL GAS CONVERSION
WARNING:
Place the grill on a flat, level surface.
Before the conversion, make sure all control knobs are in the OFF position, LP tank valve is
closed, and tank is disconnected from regulator and removed from grill.
1, Open the lid and remove cooking grates and flame tamer.
2. Removed the R- pins at the back of main burners to detach burners from bracket. Lift back of
burners while sliding burners out of firebox, disengaging burners from gas valves as shown

18
NATURAL GAS CONVERSION
3, Loosen the screw from LPG setting, rotate the shutter opening counterclockwise, adjusting it
from LP setting to NG setting. Re-tighten the screw into NG setting for securing the air shutter
opening.
4, Unscrew the old LP orifice from each gas valve with the orifice removal tool. Put a new NG
orifice into the valves and tighten with tool. Repeat this step for all five main burners.
Orifice removal tool

19
NATURAL GAS CONVERSION
5. Reinstall the main burners and R pin. Make sure to engage the burner valves.
Then Put the flame tamer, cooking grates back to grill.
6, Step 1. Remove the Grease Tray out of the grill .
Step 2. Use a wrench to detach the LP regulator and hose from fitting as shown.
Step 3. Replace with the NG hose and
Step 4. Pull out the hose clip hook (30) to secure the NG hose into the hook.
Step 5. Re-attach the Grease tray back into the grill.
NG Hose

20
NATURAL GAS CONVERSION
7, Remove the 3 main burner control knobs by grasping and pulling out.
Insert slotted screwdriver (Not included) into the hole of each control valve shaft as shown.
Rotate the shaft counterclockwise (to the left) as far as it will go (about 2 complete turns) until it
stops. The shaft will now be set in the NG position.
Re-attach the control knobs. Paste the new rating label for NG under the original LP rating
label on the cart door inner panel.
NG Conversion is now completed.
!CAUTION:
If low flames or burner problems are observed after converting from LPG to NG, the natural gas
lines may not be large enough. Refer to the “From House to Grill”chart on page 16 for natural gas
supply line specifications. Please contact a plumber to assure proper pressure at 7 in. water
column.
DO NOT RETURN YOUR GRILL TO THE STORE.
