INTRODUCTION
Better Music Builder (M) is proud to introduce the 3-Way
Line Array Active/Powered Speaker System, the M-8.
Completely unique from our traditional karaoke speakers, the
M-8 gives all the fundamental qualities for karaoke, and in
addition provides power and an astonishingly appealing
look for the users’ preference.
With a powerful set of 8 inch woofers and a total of twelve
midrange units this M-8 always performs its best. Completely
taking advantage of each midrange and subwoofer this
model creates the best audio quality when playing music.
No karaoke user is left behind here as the M-8 uses all
twelve midrange units to recreate the crisp clear voice from
the lowest to the highest pitch range singers. As an
additional feature the M-8 is equipped with a “FLAT”
function that allows the user to easily adjust echo from the
microphone input, making it more compatible for applica-
tions such as singing, speeches and lectures.
With main inputs and microphone inputs being balanced
XLR type connection, the M-8 assures the best audio quality
throughout the components, providing no unwanted
feedback. With the added line outputs an additional M-8 or
power amplifier can receive audio signal directly form the
M-8, no need for splitting cables and tangling frustrations.
Intro
SYSTEM FEATURES
• 3-Way Full Range Line Array Speaker System
• 2 x 8” woofer [low frequency woofer]
• 12 x 2.75” tweeter [paper cone middle frequency drivers]
• 2 x 1” tweeter [paper cone high frequency drivers]
• One unit of Active/Powered Subwoofer
• Two units of Line Array Column Speaker
• Built-In Power Amplifier
• Portable/Compact Design
• Top Mixer Control Panel
• Stereo/Mono Operating Mode Switch
• Line Input (Combined ¼ inch/XLR, RCA, 3.55mm)
• Microphone Input (Combined ¼ inch/XLR)
• Guitar Input (Combined ¼ inch/XLR)
• Line Output (XLR)
• Mix Output (XLR)
• Recording Output (RCA)
• Plug-in installation; no cables required
• Convenient Handle
• Mounting height: 5.7 feet
• Applications:
Restaurants, clubs, bars, conference rooms, churches,
schools and homes
Features
PACKAGE CONTENTS:
• Active/Powered Subwoofer: 1 pc
• Column Line Array: 2 pcs
• AC Power Cable: 1 pc
• Instructional Manual: 1 pc
• Warranty & Registration Card: 1 pc
LINE ARRAY SYSTEM
3-Way Active/Powered Speaker
BASS
LF
HIGH
HF
HIGH
HF
MID
MF
MID
MF

4
SAFETY INSTRUCTIONS
We will not notify you any errors or changes in this manual in
advance. If there are any errors and changes in this manual,
we will make the corrections in a timely manner. The
corrections and changes will be on our website. Therefore,
please visit our website at BetterMusicBuilder.com frequently
to find out the most updated information, corrections on errors
and changes in this manual. You may also contact us at toll
free at 1-800-318-2218.
CAUTIONS FOR INSTALLATION
POWER SUPPLY / POWER CORD
• Only use the voltage specified as correct for the device.
The required voltage is printed on the name plate of the
device.
• Use only the included power cord.
• Do not place the power cord near heat sources such as
heaters or radiators, and do not excessively bend or
otherwise damage the cord, place heavy objects on it, or
place it in a position where same could walk on, trip
over, or roll anything over it.
• Remove the electric plug from the outlet when the device is
not to be used for extended periods of time, and during
electrical storms.
• When removing the electric plug from the device or an
outlet, always hold the plug itself and not the cord. Pulling
by the cord can damage it.
DO NOT OPEN
• Do not open the device or attempt to disassemble the
internal parts or modify them in any way. The device
contains no user-serviceable parts. If it should appear to
be malfunctioning, discontinue use immediately and have
it inspected by qualified Better Music Builder service
personnel.
WATER WARNING
• Do not expose the device to rain, use it near water or in
damp or wet conditions, or place containers on it
containing liquids which might spill into an openings.
• Never insert or remove an electric plug with wet hands.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
Safety
ABNORMALITY
• If the power cord or plug becomes frayed or damaged,
or if there is a sudden loss of sound during use of the
device, or if any unusual smells or smoke should appear to
be caused by it, immediately turn off the power switch,
disconnect the electric plug from the outlet, and have the
device inspected by qualified Better Music Builder service
personnel.
• If this device should be dropped or damaged, immediately
turn off the power switch, disconnect the electric plug from
the outlet, and have the device inspected by qualified
Better Music Builder service personnel.
LOCATION
• Always consult qualified Better Music Builder service
personnel if the device installation requires construction
work, and make sure to observe the following precautions.
• Choose mounting hardware and an installation location
that can support the weight of the device.
• Avoid locations that are exposed to constant vibration.
• Inspect the device periodically.
• When transporting or moving the device, always use two
or more person. Attempting to lift the device by yourself
may damage your back, result in other injury, or cause
damage to the device itself.
• Before moving the device, remove all connected cables.
• Do not use the device in a confined, poorly-ventilated
location. If this device is to be used in a small space
other than an EIA-standard rack, make sure that there is
adequate space between the device and surrounding
walls or other devices: at least 30cm at the sides, 30cm
behind and 30cm above. Inadequate ventilation can
result in overheating, possibly causing damage to the
device(s), or even catch fire.
NO GOOD

5
NOTE
NOTE
• Do not use the speaker’s handles for suspended installation.
Doing so can result in damage or injury.
• Do no expose the device to excessive dust, vibrations,
extreme cold or heat (such as in direct sunlight, near a
heater, or in a car during the day) to prevent the possibility
of panel disfiguration or damage to the internal
components.
• Do not place the device in an unstable position where it
might accidentally fall over.
CONNECTIONS
• Before connecting the device to other devices, turn off the
power for all devices. Before turning the power on or off
for all devices, set all volume levels to minimum.
CAUTION
• When turning on the AC power in your audio system,
always turn on the device LAST, to avoid speaker damage.
When turning the power off, the device should be turned
off FIRST for the same reason.
• Do not insert your fingers or hands in any gaps or
openings on the device (ports, etc.).
• Avoid inserting or dropping foreign objects (paper, plastic,
metal, etc.) into any gaps or openings on the device
(ports, etc.). If this happens, turn off the power immediately
and unplug the power cord from the AC outlet. Then
have the device inspected by qualified Better Music
Builder service personnel.
• Do not use the device for a long period of time at a high
volume level, since this can cause permanent hearing loss.
If you experience any hearing loss or ringing in the ears,
consult a physician.
• Do not operate the device if the sound is distorting.
Prolonged use in this condition could cause overheating
and result in fire.
• Do not rest your weight on the device or place heavy
objects on it, and avoid using excessive force on the
buttons, switches or connectors.
GETTING STARTED
WIRING
IMPORTANT: Make sure all equipments are turned off before
making any connections.
For speaker connections, use a high-quality speaker wire with
polarity coding. The side of the wire with a ridge or other
coding is usually considered positive polarity.
If desired, consult Better Music Builder technical
support for speaker wire and connection options.
The speakers have coded terminals that accept a variety or
wire connectors.
To ensure proper polarity, connect each + terminal on the
back of the amplifier or receiver to the respective + (red)
terminal on each speaker. Connect the – (black) terminals in
a similar way. See the owner’s guides that were included
with your amplifier, receiver and television to confirm connec-
tion procedures.
IMPORTANT: Do not reverse polarities (i.e., + to – or – to +)
when making connections. Doing so will cause poor imaging
and diminished bass response.
ADJUSTING
Check the speakers for playback, first by setting the system
volume control to a minimum level, and then by applying
power to your audio system. Play a favorite music or video
segment and increase the system volume control to a comfort-
able level.
You should hear balanced audio reproduction across
the entire frequency spectrum. If not, check all wiring connec-
tions or consult the authorized dealer from whom you
purchased the system for more help.
The amount of bass you hear and the stereo-image quality
will be affected by a number of different factors, including the
room’s size and shape, the construction materials used to
build the room, the listener’s position relative to the speakers,
and the position of the speakers in the room.
Listen to a variety of music selections and note the bass level.
If there is too much bass, move the speakers away from
nearby walls. Conversely, if you place the speakers closer to
the walls, there will be more bass output.
CARING
Each enclosure has a finish that does not require any routine
maintenance. When needed, use a soft cloth to remove any
fingerprints or dust from the enclosure or grille.

6
OUTPUT INPUT
2+
1+
2–1–
TO
AMPLIFIER
Connector Panel
OUTPUT INPUT
2+
1+
2–1–
TO
AMPLIFIER
FULL
RANGE
BI-AMP
LF
HF
Connector Panel on Multi-Way Systems
OUTPUT INPUT
PASSIVE BI-AMPLING
INPUT PASSIVE OUTPUT
2+ 2+
2– 2–
1+ 1+
1– 1–
SUB
WOOFER
INPUT BI-AMPLING OUTPUT
2+ 2+
2– 2–
1+ 1+
1– 1–
SUB
WOOFER
Connector Panel on Subwoofers
EXAMPLE OF SPEAKON CONNECTOR
There are two groups on the speakon connectors: Group 1
(+1, –1) and Group 2 (+2, –2) as indicated in the diagram. In
order to use it, your speaker must have multi-functions (i.e.
enable two sources of signal for input). If your speaker does
not have multi-functions, it would not work with the Group 2
for connection. Please refer to the following diagram for
connection.
SYSTEM APPLICATIONS
Applications
Speakon Outputs
The upper Speakon jack has both Channel 1 and
Channel 2 outputs, so it is especially useful for parallel,
bi-amp, or BRIDGE mono operation. The other Speakon
carries only Channel 2's output. See the illustrations at
above.
SPEAKON Y CONNECTORS
INPUT OUTPUT
L
O
C
K
L
O
C
K
TO CHANNEL 2
SPEAKER
TO CHANNEL 1
SPEAKER
2–
1–
1+ 2+
REFERENCE CONNECT
8
4
2
+
–
8
4
2
–
+
SPEAKON CONNECTORS
INPUT OUTPUT
L
O
C
K
L
O
C
K
SOURCE
(from active/powered)
BRIDGE
2–
1–
1+ 2+
REFERENCE CONNECT
8
4
2
+
–
Source (INPUT) comes from the output source of the
active/powered speaker while the bridge (OUTPUT)
connects to the passive/non-powered speaker.
A speakon cable is required to connect the “OUTPUT”
of the acive/powered speaker to the “INPUT” of the
passive/non--powered speaker. Please order the speakon
cable from our authorized dealers.
NOTE

7
LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INPUT
MIX OUTRECORD OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1
Features Echo
• Reduce
during
speech
• Increase
when
singing
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
Microphone
usage
optional but
echo
nonoperative
LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INPUT
MIX OUTRECORD OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1
Features Echo
• Reduce
during
speech
• Increase
when
singing
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
Microphone
usage
optional but
echo
nonoperative
MAIN UNIT CONNECT TO
SECOND UNIT
• Connect the left and right audio output of the CD/DVD
player to the Left and Right MUSIC INPUT 2 of the main unit.
• For optimal performance, set The MUSIC 1 and/or
MUSIC 2 and MIC and/or GUITAR VOLUME on the
second unit to a high level.
• Be sure to connect the microphone/guitar to the main unit
to have sound on both units. If the microphone/guitar is
connected to the second unit, only the second unit will
have sound.
SECOND UNIT CONNECT
FROM MAIN UNIT
CONNECTION FOR TWO M-8 UNITS (MONO AUDIO)
MAIN UNIT
L + R
SECOND UNIT
L + R
MICROPHONE
CD/DVD PLAYER
AUDIO OUT
L R
MONO mode needs to be selected, otherwise, microphone
sound quality will be subpar if STEREO mode is selected.
NOTE

LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INPUT
MIX OUTRECORD OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1
Features Echo
• Reduce
during
speech
• Increase
when
singing
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
Microphone
usage
optional but
echo
nonoperative
LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INPUT
MIX OUTRECORD OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1
Features Echo
• Reduce
during
speech
• Increase
when
singing
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
Microphone
usage
optional but
echo
nonoperative
8
• First, connect the left audio output of the CD/DVD player
to the Left MUSIC INPUT 2 of the main unit.
• Then, connect the right audio output of the CD/DVD
player to the Right MUSIC INPUT 2 of the second unit.
• For optimal performance, set The MUSIC 1 and/or
MUSIC 2 and MIC and/or GUITAR VOLUME on the
second unit to a high level.
• Be sure to connect the microphone/guitar to the main unit
to have sound on both units. If the microphone/guitar is
connected to the second unit, only the second unit will
have sound.
MAIN UNIT CONNECT TO
SECOND UNIT
SECOND UNIT CONNECT
FROM MAIN UNIT
CONNECTION FOR TWO M-8 UNITS (STEREO AUDIO)
MAIN UNIT
L
SECOND UNIT
R
MICROPHONE
CD/DVD PLAYER
AUDIO OUT
L R
MONO mode needs to be selected, otherwise, microphone
sound quality will be subpar if STEREO mode is selected.
NOTE

9
LINE OUT
L
R
MULTI
INPUT
MIC
MONO STEREO
MUSIC INPUT 1
Features Echo
• Reduce during
speech
• Increase
when
singing
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
SECOND UNIT CONNECT
FROM MAIN UNIT
MAIN UNIT CONNECT TO
SECOND UNIT
LINE OUT
L
R
MULTI
INPUT
MIC
MONO STEREO
MUSIC INPUT 1
Features Echo
• Reduce during
speech
• Increase
when
singing
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
MAIN UNIT
L
SECOND UNIT
R
CONNECTION FOR TWO M-8 UNITS (PROFESSIONAL STEREO AUDIO)
LEFT MAIN OUT TO LEFT
RIGHT MAIN OUT TO RIGHT
• This is the most simplified way of connecting two units to
achieve the best live sound.
• Simply connect all inputs (CD/DVD player, microphone
and guitar) to the mixer such as our EX-8 Multi Effects
Mixer and control all the effects from it.
• First, connect the LEFT MAIN OUT of the EX-8 to the Left
MUSIC INPUT 1 of the main unit.
• Then, connect the RIGHT MAIN OUT of the EX-8 to the
RIGHT MUSIC INPUT 1 of the main unit.
GUITAR
CD/DVD PLAYER
EX-8 MULTI EFFECTS MIXER
DJ MIXER
MICROPHONE

10
LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INPUT
MIX OUTRECORD OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1
Features Echo
• Reduce during
speech
• Increase when
singing
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
Microphone
usage optional
but echo
nonoperative
LINE OUT CONNECTION
XLR FEMALE
AUDIO SIGNAL TO POWERED SPEAKER
M-8 SUBWOOFER REAR VIEW
XLR 3-Pin Male Connector Diagram
1 2
3
RCA LEFT
RCA RIGHT
PIN1 - SHIELD
PIN2 - LEFT
PIN3 - RIGHT
1 2
3
PIN1 - SHIELD PIN2 - HOT
PIN3 - COLD
2 1
3
“LINE OUT” is designed for connecting additional
active/powered speaker; useful for extending the sound to
other areas. Audio signal needs to be connected to the
MUSIC INPUT 1 in order for the audio signal to go through
the “LINE OUT.”
KTV-Series
PRO-LineCoaxial Driver
BetterMusic Builder
ACTIVE/POWERED
KTV-Series
PRO-LineCoaxial Driver
BetterMusic Builder
ACTIVE/POWERED
AUDIO SIGNAL TO POWERED SPEAKER
MONO mode needs to be selected, otherwise,
active/powered soeaker(s) will only play right channel.
NOTE

11
LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INPUT
MIX OUTRECORD OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INPUT
MIX OUTRECORD OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
M-8 SUBWOOFER REAR VIEW
MIX OUT CONNECTION
All audio signals received on the M-8 will go through the
“MIX OUT”. Additional speaker to the M-8, reproduces the
same audio signal playing via XLR connection.
KTV-Series
PRO-LineCoaxial Driver
Better Music Builder
PS-310A
ACTIVE/POWERED SPEAKER
10-INCH WOOFER
XLR FEMALE
AUDIO INPUT CONNECTION
For the home user or karaoke enthusiast, setup is very
simple. Connect KOD or DVD to “MUSIC INPUT 2 (DVD)”
or a smart phone to the 1/8” (3.55mm) input.
M-8 SUBWOOFER REAR VIEW
AUDIO
TV VIDEO DISPLAY
KOD KARAOKE SYSTEM
RCA
VIDEO
Smart
Phone
1/8 INCH (3.55mm)
2 1
3
CD/DVD PLAYER
AUDIO
RCA
AUDIO OUT

12
LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INPUT
MIX OUTRECORD OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
M-8 SUBWOOFER REAR VIEW
GUITAR
LIVE SOUND INPUT CONNECTION
For live audio using multiple instruments such as guitars,
drums, and microphones, “MUSIC INPUT 1” serves
perfectly. With no added powered mixer, setup is easy. This
form of live audio is perfect for small groups where
instruments and vocalists are limited.
LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INPUT
MIX OUTRECORD OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
For large multi-function systems such as a live performance
“MUSIC INPUT 1” can be used with a powered mixer.
Having all instruments and microphones connected to the
powered mixer allows the audio be individually controlled.
Additional music can play by connecting a CD/DVD player
MULTI-FUNCTION CONNECTION
M-8 SUBWOOFER REAR VIEW
CD/DVD PLAYER
AUDIO RECORDER
to “MUSIC INPUT 2.” An audio recorder can be further
connected to the “RECORD OUT” to record the audio.
AUDIO
RCA
AUDIO OUT
EX-8 MULTI EFFECTS MIXER
GUITAR
GUITAR
MONO mode needs to be selected, otherwise, right
channel instrument will not play.
NOTE
MONO mode needs to be selected, otherwise, right
channel will not play.
NOTE
MICROPHONE

13
MIN MAX
EQUALI ZER EQU ALIZERECHO Speech EQU ALIZER
MIN MAX MIN MAX MIN M AX
BASS
ON
LIMIT
SIGNAL
MIN MAX
MUSIC 2
VOLUME
MIC
VOLUME
GUITAR
VOLUME
MUSIC 1
VOLUME
Top View
LINE A RR AY SYSTEM
AC POW ER INPUT
110V / 60Hz, T5A L
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVECOVER. NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIEDSERVICE PERSONNEL.
RISKOF ELECTRIC SHOCK
DONOT OPEN
WITHOUTAUTHORIZATION
360151034000
SERI AL NO.
MODEL NO.: M-8
8” SUBWOOFER ACTIVE 2.1 POWERED SPEAKER
CALIFORNIA, UNITED STATES OF AMERICA
E-mail: [email protected]
www.BetterMusicBuilder.com
ENGINEERED AND DESIGNED INU.S.A.
Better Music Builder .com
®
Passionate about Music
Smart
Phone
M-8 G2
AUDIO
RCA
1/8
AUDIO
KOD
Karaoke
System TV Vi deo Displa y
VIDEO
Guitar
Wired Mic
LINE OU T
MUSIC IN PUT 2
(DVD)
L
R
MULTI
INP UT
MIX OUTRECOR D OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUI TAR
OR
MONO ST EREO
MUSIC IN PUT 1
Speaker
FRONT & REAR PANEL OF ACTIVE/POWERED SUBWOOFER
Front View
1
1
Rear View
CONTROLS AND FUNCTIONS
FRONT & REAR PANEL OF COLUMN LINE ARRAY
4
5
8-INCH WOOFER
HANDLE
REAR PANEL
CONTROL PANEL
SPEAKER 1/4” JACK (F) & MOUNT
1
2
3
4
5
SPEAKER 1/4” JACK (F) & MOUNT
1-INCH SILK DOME TWEETER
2.75-INCH FULL RANGE TWEETER
SPEAKER 1/4” JACK (M) & MOUNT
1
2
3
4
Side View Rear View
Top View
Bottom View
Front View
1
4
2
3
3
2
COLUMN LINE ARRAY ACTIVE SUBWOOFER

11
14
LINE ARRAY SYSTEM
AC POWER INPUT
110V / 60Hz, T5AL
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WITHOUT AUTHORIZATION
360151034000
SERIAL NO.
MODEL NO.: M-8
8” SUBWOOFER ACTIVE 2.1 POWERED SPEAKER
CALIFORNIA, UNITED STATES OF AMERICA
E-mail: [email protected]
www.BetterMusicBuilder.com
ENGINEERED AND DESIGNED IN U.S.A.
Better Music Builder .com
®
Passionate about Music
Smart
Phone
M-8 G2
AUDIO
RCA
1/8
AUDIO
KOD
Karaoke
System TV Video Display
VIDEO
Guitar
Wired Mic
LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INPUT
MIX OUTRECORD OUT
1/8 inch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1
Features Echo
• Red uce dur ing
speech
• Increase wh en
sin ging
STEREO: Left audio
plays, Right audio
bypasses to other
speaker
Micr ophone
usage opt ional
but echo
nonoper ative
MIN MAX
EQUALIZER EQUALIZERECHO Speech EQUA LIZER
MIN MAX MIN M AX MIN MA X
BASS
ON
LIMIT
SIGNAL
MIN MAX
MUSIC 2
VOLUME
MIC
VOLUME
GUITAR
VOLUME
MUSIC 1
VOLUME
REAR PANEL:
16
12
MUSIC 1 VOLUME
MICROPHONE VOLUME
GUITAR VOLUME
MUSIC 2 VOLUME
BASS:Adjusts the strength of the low frequencies to the
subwoofer
MUSIC 1 EQUALIZER: To define the level of the aurally
compensated sound correction
MICROPHONE ECHO: Continuously adjustable echo
fades between vocals, neutral and speech
GUITAR EQUALIZER: Continuously adjustable EQ fades
between neutral and speech
MUSIC 2 EQUALIZER: To define the level of the aurally
compensated sound correction
LED INDICATORS:
ON = Power indicator; SIGNAL = Signal indicator;
LIMIT = Limiter indicator lights up when the signal level is
too high; the limiter will reduce the signal level to protect
the speaker
MICROPHONE INPUT: Combined 1/4 inch/XLR
connection for microphone input; features echo function
MUSIC INPUT 1: Combined 1/4 inch/XLR connection for
music source
LINE OUTPUT: XLR audio output to a second active
speaker unit
OPERATING MODE SWITCH:
MONO = Reproduces the signal monophonically
STEREO= Separates the left and right side audio
GUITAR INPUT: Combined 1/4 inch/XLR connection for
guitar input; does not feature echo function
MUSIC INPUT 2 (DVD): RCA or 1/8” (3.55mm)
connection for music source
MIX OUTPUT: XLR audio output to a second M-8 unit
RECORD OUTPUT: RCA audio to connect a recorder
AC POWER SWITCH
AC POWER: 110V for USA & Canada. 220V for Asia
and Europe
FUSE: Housing for the power supply fuse
1
2
3
4
5
6
7
8
9
12
13
14
10
16
CONTROL PANEL:
12345
6 7 8 9 10
1713
11
14 18
15
20
19
21
15
17
18
19
21
20

Floor
15
SYSTEM SETUP GUIDELINES
Set Up
HOW TO SETUP SPEAKER SYSTEM
Place the subwoofer on even surface.
Insert the linkable line array speaker to the top of the
subwoofer at 45° counterclockwise. Be sure to fully insert
it into the socket to assure stability and good connection.
Once inserted, turn 45° clockwise to lock in the line
array speaker.
Insert the top line array speaker to the top of the linkable
line array speaker at 45° counterclockwise. Be sure to
fully insert it into the socket to assure stability and good
connection.
Once inserted, turn 45° clockwise to lock in the top line
array speaker.
1
2
3
4
5
1
2
3
4
5
ACTIVE/POWERED
SUBWOOFER
LINE ARRAY
LINE ARRAY

16
INPUT LEVEL MUSIC INPUT 1: 775mVrms, MUSIC INPUT 2: 200mVrms
MIC: 20mVrms, GUITAR: 40mVrms
MUSIC INPUT 1: 3.5Vrms, MUSIC INPUT 2: 2Vrms
MIC: 200mVrms, GUITAR: 400mVrms
INPUT
OVERLOADING LEVEL
Lightweight and high power
HIGHLIGHTED
FEATURES
PIN 1: Ground, PIN 2: Signal+, PIN 3: Signal–
WIRE
CONNECTION
MAX. SPL 113 dB / 119 dB (PEAK)
DISPERSION (HxV) 90° x 40°
INPUT IMPEDANCE 20k ohm balanced input
10k ohm unbalanced input
45Hz ~ 20kHz
FREQUENCY
RESPONSE
CABINET TYPE Selected High Intensity Plywood
FRONT VIEW
68 inch
172.6 cm
23.1 inch
58.6 cm
9.8 inch
25 cm
SIDE VIEW
15.8 inch
40 cm
REAR VIEW
4.3 inch
10.9 cm
3.4 inch
8.7 cm
TOP VIEW
COLUMN LINE ARRAY
M-8 = 1 x ACTIVE SUBWOOFER + 2 x COLUMN LINE ARRAY
SIDE VIEW REAR VIEW
BOTTOM VIEW
FRONT VIEW
22.4 inch
57 cm
1.4 inch
3.6 cm
SPECIFICATIONS
Spec
PHYSICAL DIMENSIONS
Dimensions
SHIPPING WEIGHT 55.1 Lbs / 25 Kg
NET WEIGHT
PACKING
DIMENSIONS
(W x H x D)
24 x 27.6 x 13.8 in
61 × 70 × 35 cm
DIMENSIONS
(W x H x D)
LINE ARRAY (each)
3.4x22.4x4.3 in
8.7x57x10.9 cm
SUBWOOFER
9.8x23.1x15.8 in
25x58.6x40 cm
FULL SYSTEM
9.8x23.1x15.8 in
25x58.6x40 cm
LINE ARRAY (each)
7.4 Lbs/3.4 Kg
SUBWOOFER
36.4 Lbs/16.5 Kg
FULL SYSTEM
51.2 Lbs/23.2 Kg
MODEL
3-WAY FULL RANGE ACTIVE SPEAKER
M-8
MAX. POWER
HANDLING
400 Watts
LF: 200 Watts, MF: 180 Watts, HF: 30 Watts
SUPPORTED FIXTURE Ground
TWEETER [HF] 1” (2 units) High Frequency
RATED IMPEDANCE 4 ohms
“SPOT” RANGE Compression Driver
300Hz between LF & MF, 5KHz between MF & HF
CROSSOVER
FREQUENCY
SENSITIVITY 95dB/1W/1M
WOOFER [LF] 8” (2 units) Low Frequency
TWEETER [MF] 2.75” (12 units) Middle Frequency
MODEL M-8
TYPE Front
3-WAY FULL RANGE ACTIVE SPEAKER
LINE ARR AY SYSTEM
ACP OWER INPUT
110V/ 60H z, T5AL
TOREDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVECOVER.NO USER SERVICEABLE PARTS INSIDE
REFERSERVICINGTO QUALIFIED SERVICE PERSONNEL.
RISKOFELECTRIC SHOCK
DONOTOPEN
WITHOUTAUTHORIZATION
360151034000
SERIAL NO.
MODEL NO .: M-8
8”SUBWOOFER ACTIVE 2.1 POWERED SPEAKER
CALIFORNIA,UNITED STATES OF AMERICA
E-mail:[email protected]
www.BetterMusicBuilder.com
ENGINEE RED AND DES IGNED IN U. S.A.
Better Music Builder .com
®
Passionate about Music
Smart
Phone
M-8G2
AUDIO
RCA
1/8
AUDIO
KOD
Karaoke
System TV Video Display
VIDEO
Guitar
Wired Mic
LINE OUT
MUSIC INPUT 2
(DVD)
L
R
MULTI
INP UT
MIX OUTRECORD OUT
1/8in ch
3.55mm
L
R
L
R
L
R
L
R
MIC GUITAR
OR
MONO STEREO
MUSIC INPUT 1

17
Troubleshooting
TROUBLESHOOTING
1. SYMPTOM: NO POWER
Possible causes:
• Loose power cable
• Fuse failure
• Improper power cable
• Impact damage
Remedy:
A. The product uses standard A/C power cable housing that
fits snug onto the connection; be sure the cable is inserted
completely.
B. A replaceable safety fuse protects the M8 if there is a
power spike or a short circuit. If the fuse fails, replacement is
needed.
C. Three prong A/C power cable comes with a standard; in
some occasions, the grounding prong is clipped off in order
to fit certain wall plugs. The removal of the Grounding plug
may cause internal damage to the M-8 and/or the personal
injuries, so be sure to use a proper 3-prong wall plug or UL
certified adapter.
D. If the product received significant impact damage and no
longer operates, inspect the fuses, connections and speaker
positive & negative contacts for damage. If the problem
persists, you may need to send it in for inspections and
repairs.
2. SYMPTOM: NO SOUND COMING FROM SPEAKER(S)
Possible cause:
• Power is turned OFF or no power current to the product
• Improper audio input connections
• Volume set to minimum
• Speaker connections not inserted correctly
Remedy:
A. Be sure the power switch is set ON and/or power cable
is connected properly.
B. Be sure the sources are connected to audio Inputs (Line
Out, Record Out, and Mix Out are audio outputs and do not
play any received audio)
C. The default volume setting is minimum. After connecting
sources, adjust the volume control on top of the subwoofer to
a proper level.
D. The column speakers connecting to the powered
subwoofer receive their power via the mounting location; this
connection has a locking mechanism that will engage audio
to the column speakers once properly locked. To properly
lock the column speakers; insert the column speaker onto the
mounting location at a counterclockwise angle and then turn
clockwise, an audible click confirms proper mounting.
3. SYMPTOM: ONLY LEFT SPEAKER PLAYS AUDIO (RIGHT
SPEAKER NO AUDIO)
Possible cause:
• Right speaker power is OFF
• Right speaker volume is set to minimum
• Audio source is set improperly
Remedy:
A. Be sure the power switch is set ON
B. The left and right speakers have independent volume
controls; depending on how you connect, the right speaker
needs to be leveled with the left speaker.
• If the left speaker acts as the master volume control in the
setup, adjust the right speaker to the same level as the left
speaker.
• If the setup includes a professional mixer, set both left
and right volume levels the same, then control the volume
through the mixer.
C.When using the MONO/STEREO feature, keep in mind
the right audio when set to STEREO will bypass through
“LINE OUT” for connection to the right speaker (the right
audio input of MUSIC INPUT 1 not play on the primary
speaker, it bypasses to LINE OUT to another speaker).
When connecting to the right channel speaker, if connected
to Right audio in MUSIC INPUT 1, the MONO/STEREO
switch must be on MONO since it only receives one audio
source (right audio source).
• Additionally, to avoid this issue completely, connect the
right speaker MUSIC INPUT 1 to the Left insert of the right
speaker. Since the audio is for the right channel,
it is played and be controlled as the right speaker.

18
4. SYMPTOM: NOISE/SIGNAL COMING FROM
SPEAKER(S)
Possible causes:
• The A/C power cord of the speaker(s) is not grounded
• Audio source is presenting a short circuit
• Audio cable is damaged
Remedy:
A. The product comes with a standard 3-prong A/C power
cable; do not remove the grounding prong in order to
connect to a two-prong power outlet. By removing the
grounding prong interference is no longer eliminated.
Removing the grounding prong not only voids the
warranty but could results in injury or even death.
B. The audio source is generating noise and sending the
signal to the speakers. Test a new audio source for proper
operation.
C. The audio cable is contacting opposite leads and causing
interference; replace the audio cable for a higher quality
audio cable.
5. SYMPTOM: CRACKLING SOUND COMING FROM
COLUMN SPEAKERS
Possible cause:
Tweeter(s) may be damaged.
Remedy:
Replace tweeter. We recommend hiring a professional to
change the tweeter properly.
6. SYMPTOM: SOUNDS LIKE DAZZ, DAZZ, DAZZ ........
COMING FROM SPEAKER(S)
Possible cause:
The speaker cable (with small gauges) is over 100 feet.
Remedy:
Change to a higher quality cable, preferably 12 and 14
gauges.
7. SYMPTOM: TOO MUCH MICROPHONE FEEDBACK
FROM SPEAKER(S)
Possible cause:
Incorrect tremble and bass adjustments on the speaker.
Remedy:
Adjust the tremble and bass to an appropriate level to avoid
microphone feedback.
8. SYMPTOM: SPEAKERS SOMETIMES HAVE NO SOUND
Possible cause:
When the master volume reaches the maximum level, the
speaker automatically shuts down because it has a built-in
auto circuit to protect itself when the master volume becomes
too high.
Remedy:
Change to a higher power amplifier to work with the
speakers. Be sure the output power of the amplifier matches
the speakers. Another option is to add more speakers or
subwoofers for higher output as below.
1. Add one more loudspeaker.
2. Add one more powered subwoofer.
We highly recommend hiring an audio professional for
advise on the right engineering for the amplifier and
speakers.
NOTE

19
WARRANTY
ONE-YEAR LIMITED WARRANTY FOR HOME USE
EQUIPMENT
Our one-year warranty covers both parts and labors. The
warranty becomes effective from the date of your purchase
for one year.
Our warranty only covers defects due to product
defectiveness with free of defects in materials or
workmanship. However, our warranty does not cover defects
due to normal wears, damage in transit, improper use, abuse
or failure to follow the proper instructions for maintenance.
This warranty is void in the event of unauthorized repairs,
alternations, modifications and removing of the product label.
Please also note that our warranty does not cover any
shipping cost for the return of defective products to us for
inspection, repair and maintenance. Our warranty for Better
Music Builder products can only be executed in North
America.
90-DAY LIMITED WARRANTY FOR PUBLIC AND
COMMERCIAL USE EQUIPMENT
Our 90-day warranty applies to speakers, amplifiers, mixers
and microphones for both public and commercial use such as
restaurant, coffee shop, KTV nightclub, church and school,
etc. It covers both parts and labors. The warranty becomes
effective from the date of your purchase for 90 days.
Our warranty only covers defects due to product
defectiveness with free of defects in materials or
workmanship. However, our warranty does not cover defects
due to normal wears, damage in transit, improper use, abuse
or failure to follow the proper instructions for maintenance.
This warranty is void in the event of unauthorized repairs,
alternations, modifications and removing of the product label.
Please also note that our warranty does not cover any
shipping cost for the return of defective products to us for
inspection, repair and maintenance. Our warranty for Better
Music Builder products can only be executed in North
America.
Warranty
ADDITIONAL NOTES:
1. Limited warranty for home use equipment is only valid in
North America.
2. Limited warranty is valid only if you purchase our products
from our authorized dealers (including both regular retailers
and online retailers) in North America. If you choose to
purchase our products from an authorized dealer, we will not
provide any limited product warranty for you. To protect your
limited product warranty, please purchase our products from
one of our authorized dealers in North America near you.
3. Limited warranty is automatically void if the yellow label
stating “No Warranty After Opening” is removed from the
product.
TO REGISTER YOUR WARRANTY
Please fill out the warranty card that came with your unit,
download or submit online warranty form. However, we need
the invoice for your purchase in order to process this warranty.
You may also register your warranty online.
Please visit our website at ww w.bet termusicbuilder.com.

20
AGENCY REGULATORY NOTICES
FEDERAL COMMUNICATIONS COMMISSION NOTICE
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio or television
technician for help.
Modifications
The FCC requires the user to be notified that any changes or
modifications made to this device that are not approved may
void the user’s authority to operate the equipment.
Cables
Connections to this device must be made with shielded cables
with metallic RFI/EMI connector hoods to maintain
compliance with FCC rules and regulations.
MATERIALS DISPOSAL
Disposal of this material can be regulated because of
environmental considerations. For disposal or recycling
information, contact your local authorities or the Electronic
Industries Alliance (EIA) (http://www.eiae.org).
DISPOSAL OF WASTE EQUIPMENT BY USERS IN
PRIVATE HOUSEHOLDS IN THE EUROPEAN UNION
This symbol on the product or on its packaging indicates that
this product must not be disposed of with your other
household waste. Instead, it is your responsibility to dispose of
your waste equipment by handing it over to a designated
collection point for the recycling of waste electrical and
electronic equipment. The separate collection and recycling of
your waste equipment at the time of disposal will help to
conserve natural resources and ensure that it is recycled in a
manner that protects human health and the environment. For
more information about where you can drop off your waste
equipment for recycling, please contact your local city office,
your household waste disposal service or the shop where you
purchased the product.
JAPANESE NOTICE
JAPANESE POWER CORD NOTICE
JAPANESE MATERIAL CONTENT DECLARATION
A Japanese regulatory requirement, defined by Specification
JIS-C-0950, 2005, mandates that manufacturers provide
Material Content Declarations for certain categories of
electronic products offered for sale after July 1, 2006.
KOREAN NOTICE
RECYCLING PROGRAM
The terms and availability of these programs vary by
geography because of differences in regulatory requirements
and local customer demand.
因为在当地的监管要求和客户的需求，这些条件和程序的情
况不同。
Notices
