Beyerdynamic Interpreter Console SID 202 User manual

SID 202
Interpreter Console
Order # 483.915
Germany
beyerdynamic GmbH & Co. KG
Theresienstr. 8 · 74072 Heilbronn – Germany
Tel. [phone] / 6 17-0 · Fax [phone] / 617-224
[email protected] · www.beyerdynamic.de
United States
beyerdynamic Inc. USA
56 Central Ave. · Farmingdale, NY 11735
Tel. [phone] · Fax [phone]
[email protected] · www.beyerdynamic.com
Great Britain
beyerdynamic U.K. Ltd.
17 Albert Drive · Burgess Hill RH15 9TN
Tel. [phone] / 258 258 · Fax [phone] / 258 444
[email protected] · www.beyerdynamic.co.uk
DESCRIPTION
The SID 202 is a “Stand Alone” interpreter console for simple
interpreting applications with two target languages. The
interpreter console has been designed for two interpreters
who take turns. Each interpreter can connect one headset or
one microphone and headphone to the console. For powering,
the console does not need a control unit; it is powered via
the supplied power supply unit.
The audio channels for input and 2-channel output are
connected via a set of cables. As the work of an interpreter
requires a lot of concentration, all controls and indicators are
designed economically for a convenient operation. Unnoticed
by the participants of the meeting, the interpreter can contact
a technician at any time by using a call button.
FEATURES
• Original language and two target languages
• Buttons operate silently
• Very rugged fully metal housing with
ergonomic design of all controls and indicators
• 2 output channels (A and B) with LED
• Connections for 2 headsets or
2 headphones and microphones
• Bass and treble controls
as well as one volume control for each interpreter
• Two independent microphone buttons with LED
• Cough button (“Mute”)
• Call and voice communication to the technician (“Service”)
• Powered by supplied power supply unit
TECHNICAL SPECIFCIATIONS
Microphone input. . . . . . . . . . . . . . . . 8-pin DIN 45326,
-55 dB / 4.7 kΩ,
with 7.5 V supply
Frequency response . . . . . . . . . . . . . . 70 - 18,000 Hz (-3 dB)
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.15%
Signal-to-noise ratio . . . . . . . . . . . . . . > 72 dB (A)
Cross-talk attenuation . . . . . . . . . . . . > 68 dB / 1 kHz
Bass control . . . . . . . . . . . . . . . . . . . . . -15 - +15 dB / 125 Hz
Treble control . . . . . . . . . . . . . . . . . . . -15 - +12 dB / 8 kHz
Headphone outputs . . . . . . . . . . . . . . on boths sides of the
unit, 1/4" (6.35 mm)
jack for headphones
with 100 - 600 Ω
Switching operation . . . . . . . . . . . . . . fully electronic,
silent
Weight. . . . . . . . . . . . . . . . . . . . . . . . . 2.4 kg
Dimensions . . . . . . . . . . . . . . . . . . . . . 340 x 196 x 102/35 mm
Surface. . . . . . . . . . . . . . . . . . . . . . . . . matt, grey / black
Non-contractual illustrations. Subject to change without notice. E2 /SID 202 (06.07)
