Beyond LAUNDRY PRO 2.0 User manual

READ MANUAL CAREFULLY FOR PROPER USE AND OPERATION.
2.0
A BEYOND BY AERUS TECHNOLOGY
COLD WATER LAUNDRY SYSTEM

2
CONTENTS
General Information . . . . . . . . . . . . . . . . . . . .2
Use & Safety Considerations . . . . . . . . . . . . . . . . 3
Installation Requirements . . . . . . . . . . . . . . . . . 4
Before You Start . . . . . . . . . . . . . . . . . . . . . .5
Removing Cover. . . . . . . . . . . . . . . . . . . . . .5
Installation of Wall Anchors or Screws . . . . . . . . . . . 6
Reinstall the Cover. . . . . . . . . . . . . . . . . . . . .7
Hose Installation . . . . . . . . . . . . . . . . . . . . 7-8
Connecting the Power Adapter . . . . . . . . . . . . . . 8
System Set Up. . . . . . . . . . . . . . . . . . . . . . .9
Before Washing Clothes . . . . . . . . . . . . . . . . . 10
Using Your Laundry Pro 2.0 . . . . . . . . . . . . . . . 10
Washers Requiring Hot & Cold Water . . . . . . . . . . . 11
Temp. Control & External Water Tap . . . . . . . . . . . 12
Status Indications . . . . . . . . . . . . . . . . . . . . 12
Frequently Asked Questions . . . . . . . . . . . . . . . 13
Installation Problems . . . . . . . . . . . . . . . . . . 13
Warranty Information . . . . . . . . . . . . . . . . . . 14
PRODUCT OVERVIEW
Laundry Pro 2.0 is designed to work in conjunction with your washing
machine, using cold water and our proprietary ActivePure®Technology to
clean clothes. As your washer begins to ll, Laundry Pro 2.0 will turn on.
Laundry Pro 2.0 is equipped with an internal leak sensor. See page 12
for more details.
There’s a smart new approach to laundry that’s based on earth-friendly
science and technology. Laundry Pro 2.0, designed and made in America,
eliminates the need for hot water, detergents, fabric softeners and bleaches,
thereby allowing it to pay for itself over and over again.
Laundry Pro 2.0 is easy to install. It is intended to work with residential clothes
washers and is for use by anyone interested in an economical, earth-friendly
alternative to the typical detergents and chemicals currently available,
without modifying existing appliances, electrical systems, or plumbing.
Laundry Pro 2.0 uses a variation of the technology originally developed for
use in the International Space Station and is recognized as a Certied Space
Technology by the Space Foundation.
FILL IN AND SAVE
The location of the serial number is on the back panel of the water unit,
below the water line connection. Write it here and retain for future
reference.
Model No.____________________________________________________________
Serial No. ____________________________________________________________
Date of Purchase ______________________________________________________
Aerus Distributor ______________________________________________________
_____________________________________________________________________
Distributor’s Oce Phone No. ___________________________________________
_____________________________________________________________________
Distributor’s Oce Address _____________________________________________
_____________________________________________________________________
SPECIFICATIONS
AC/DC Adapter:
• AC in: 100 - 240V ~ 50/60 Hz .45A
• DC out: 12V
Power Consumption:
• .4W AC (standby mode)
• 1.3W AC operating
Dynamic Water Pressure:
• Minimum 20 psi to 60 psi / 1.37 ~4.13 bar
Water Temperature:
• Use cold water only (do not use hot water)
Operating Environment:
• 50˚F - 100˚F ( 10˚C - 37.8˚C)
• Humidity 40% ~ 85%
Dimensions:
• 17.3” x 5.19” x 3.69”
• 43.94cm x 13.48cm x 9.37cm
Weight:
• 4.3 lbs
• 1.95 kg
GENERAL INFORMATION

3
• Read this manual in its entirety prior to installing or using your Laundry Pro 2.0.
• For indoor use only.
• Do not operate unit with cover removed.
• Disconnect all power before servicing.
• Do not use an extension cord or other adapter with this appliance.
• This appliance is not recommended for use with high sediment content water. If your water has a
high sediment content, consult a water ltration expert for available options.
• Maximum dynamic water inlet pressure is 60 psi.
• Use the new hose included with the unit, when connecting the Laundry Pro 2.0 to your washing
machine. You should also replace any washing machine hose that is more than
3 years old.
• Do not clean the cover of your Laundry Pro 2.0 with harsh chemicals, abrasives, or cleansers. To
clean, use a soft cloth dampened with water.
• Laundry Pro 2.0 is designed for normal residential use only. Use in a commercial or
non-residential setting may damage the unit and will void your warranty.
USE & SAFETY CONSIDERATIONS
IMPORTANT SAFETY PRECAUTIONS
• To prevent unnecessary risk of re, electrical shock, or personal injury, all wiring must be done in
accordance with the National Electrical Code ANSI/FNPA, No. 70 - Latest Revision and local codes
and ordinances in the USA. For Electrical Codes outside the USA, consult your local regulatory
agency for the latest codes and ordinances. It is the personal responsibility and obligation of the
appliance owner to provide adequate electrical service for this appliance.
We have provided important safety
warnings in this manual
and on your appliance. Always read
and obey all safety messages.
Safety warnings in this manual
are dened as follows:
WARNING:
Electrical shock hazard.
You can be killed or seriously
injured if you don’t follow
instructions.
CAUTION:
Damage to your appliance or the
surrounding area can occur if
you don’t follow instructions.
DANGER:
Death or serious injury can occur
if instructions are not followed
immediately.
NOTE:
This information is included to
aid in installation and use of this
appliance.
NOTE: Your Laundry Pro 2.0 Unit was factory tested. It is normal for some residual
water to still remain in the unit as a result of these tests.
Water treated by your Laundry Pro 2.0 unit is intended for clothes washing only and is NOT
approved for any internal consumption such as drinking, bathing, brushing teeth, etc. DO NOT
drink, ingest, or internally consume the water from your Laundry Pro 2.0 unit or washing machine.
DO NOT provide water from your Laundry Pro 2.0 to your pets or other animals.
CAUTION:
SAVE THESE INSTRUCTIONS

4
ELECTRICAL REQUIREMENTS
100 - 240 Volt 50/60 Hz 5 AMP (minimum) Fuse or Circuit Breaker.
Laundry Pro 2.0 is equipped with an AC to DC power supply.
NEVER USE AN EXTENSION CORD.
WATER REQUIREMENTS
A dynamic water pressure of greater than 20 psi / 1.37 bar and less than
60 psi / 4.13 bar is required to correctly operate your Laundry Pro 2.0.
See Cautions below.
WATER
OUTLET
WATER
INLET
INSTALLATION REQUIREMENTS
LOCATION CONSIDERATIONS
The Laundry Pro 2.0 must never be installed in areas where water
may freeze since the unit will always maintain some water in the unit,
the water valve, and hose areas. This can cause damage to internal
components. It is also recommended to avoid installation in areas of
high humidity, as it can eect the operation of the unit.
17.3”(43.94 cm)
5.19”(13.48 cm)
3.69”(9.37 cm)
Incoming water pressure must be greater than 20 psi / 1.37 bar. If your
household water pressure is greater than 60 psi / 4.13 bar, you must
install an in-line pressure reducer before installing Laundry Pro 2.0.
Failure to follow these instructions may result in water leakage, property
damage, personal injury, and may void your warranty. Water pressure
of 20 psi / 1.37 bar to 60 psi / 4.13 bar is required to correctly operate
your Laundry Pro 2.0. Low water pressure may prevent your unit from
operating properly and/or cause a failure in your washing machine’s
water valve.
The washer’s water valve may also not shut o completely. Check
the documentation supplied with your washing machine for exact
specications. Your washing machine and cold water faucet must be
within 4 feet of the right side of the unit to use the inlet hose provided
with your Laundry Pro 2.0.
TO AVOID THE POSSIBILITY OF WATER DAMAGE, SHOULD A HOSE
LEAK, ALWAYS HAVE FAUCETS ACCESSIBLE AND TURN OFF
FAUCETS WHEN WASHER IS NOT IN USE. DO NOT USE WITH A
CARBON FILTER.
CAUTION:

5
BEFORE YOU START
REMOVING COVER
• Remove your new Laundry Pro 2.0 from its packaging.
• Inspect the unit for any signs of shipping damage.
NOTE: Your Laundry Pro 2.0 unit was factory tested. It is normal for some residual water to still remain in the unit as a result of these tests.
Screws
1. Remove the two (2) cover screws located on
the bottom of the unit.
2. Remove the two (2) screws (not shown) along
the top of the Laundry Pro 2.0.
3. To remove the cover, pull the top away from the
unit, then lift o the cover.

6
INSTALLATION OF WALL ANCHORS OR SCREWS
A. If using supplied wall anchors, drill two 3/16” (4.76 mm) diameter holes.
Place two wall anchors into the wall. Install two supplied screws and tighten
until almost all the way in.
B. If mounting to wall studs, drill two 3/32” (2.381 mm) diameter holes
approximately 1” (25.4 mm) deep. Install two supplied screws and tighten
until almost all the way in.
17.3”(43.94 cm)
Keyholes
NOTE: Washing machine and cold water faucet must
be within 4 feet (1.21 m) of the right side of unit.
1. Place the Laundry Pro 2.0 to the wall and mark the appropriate keyholes
with a pencil.
Screws (not shown)
2. Position the keyholes of the Laundry Pro 2.0 onto the screws (not
shown). Finish tightening screws enough to securely mount unit, but
still allowing it to be removed from wall. Remove unit from wall.
NOTE: The provided hardware kit contains adhesive backed rubber spacers
to be placed on back of unit to provide additional clearance from
wall if needed for hose installation or the use
of ActiveClean Port. (Page 12)

7
1. Turn the cold water o by shutting o the cold water faucet.
NOTE: To help prevent water spray when disconnecting hoses, you can relieve
pressure in the water line by momentarily starting your washing machine.
NOTE: To ease hose installation and prevent cross threading, connect hose
prior to mounting unit on wall.
NOTE: Remove the two black caps from the hose connections
before installing hoses.
2. Remove the cold water hose from the cold water inlet on the back of
your washing machine. Leave hot water hose attached.
When connecting hoses to your Laundry Pro 2.0 start by hand tightening the hose
connector(s). Using adjustable pliers, nish tightening hose connector(s). Do not
remove or disconnect the hot water line from your washing machine or water valve.
CAUTION:
1. Return the Laundry Pro 2.0 cover to its original position, tting the bottom in
place and tipping upward.
2. Secure with two (2) screws (not shown) along the top edge.
3. Put the two (2) remaining screws along the bottom edge and tighten.
REINSTALL THE COVER
HOSE INSTALLATION
Screws
Screws

8
CONNECTING POWER ADAPTER
1. Insert the provided power cord into the POWER IN socket located on the side of the unit.
Do not use any AC/DC adapter other than the one supplied with your Laundry Pro 2.0 or Aerus replacement AC/DC adapter
(item#: 49873-US). Failure to follow these instructions may void your warranty and/or result in damage to your unit, re, or
electrical shock.
CAUTION:
HOSE INSTALLATION CONTINUED
3. Connect the hose from the cold water inlet on your washing
machine to the INLET connection on your Laundry Pro 2.0.
5. Finally, connect the new hose to the cold water inlet on your washing machine.
4. Connect the new hose provided with your Laundry Pro 2.0 to the water
OUTLET connector on your Laundry Pro 2.0 unit.
NOTE: To ease hose installation and prevent cross threading,
connect hoses prior to mounting unit on wall.
NOTE: If your existing hose is more than 3 years old, we recommend that you replace
it with the optional stainless steel hose (item#: 49701-US).
NOTE: Do not plug the adapter into the wall socket until installation is complete. See page 9.

9
SYSTEM SET UP
4. Start your washer. The status light should
illuminate blue after a few seconds.
NOTE: Your Laundry Pro 2.0 will automatically turn
on and o as your washing machine starts, and stops.
Electrical Shock Hazard. When working with electrical connections, the appliance
and surrounding area should be clean and dry of any standing water. Failure to
follow these instructions can result in death, re, or electrical shock.
Electrical Shock Hazard. Do no use an extension cord.
Failure to follow these instructions can result in death,
re, or electrical shock.
WARNING: WARNING:
1. Plug power cord into the wall outlet of your
home’s electrical power system. See page 4 for
electrical requirements.
Status Indicator Lights
2. Turn on the cold water valve.
3. Check all hoses to ensure no water
is leaking. Tighten if necessary.

10
BEFORE WASHING CLOTHES
IF YOUR WASHING MACHINE IS NOT NEW you will need to perform this
procedure to help remove any detergent buildup that may contaminate your
clothing.
1. Do not put clothes in the washer at this time.
Set your machine to its largest load setting, cold water only.
2. Start the washer and let it run through every cycle.
3. Once it has nished, repeat Steps 1 and 2 three more times.
Depending on the age and severity of detergent buildup,
it may be necessary to perform Step 3 several times.
NOTE: If you have a front loading washer, odors can develop
due to stagnant water left inside. If musty odors develop
it may be necessary to run a commercially available cleaner made
especially for front loading washers to eliminate such odors.
CAUTION:
To avoid the possibility of water damage, should a
hose leak, always have faucets accessible and turn o
faucets when washer is not in use.
IF YOUR WASHING MACHINE IS NEW, skip this section and continue
below.
BEFORE USING YOUR LAUNDRY PRO 2.0 FOR
THE FIRST TIME
USING YOUR LAUNDRY PRO 2.0
DETERGENT AND FABRIC SOFTENER
You may choose to continue to use detergent and/or fabric softeners if desired. However, to completely
experience all the benets of your new Laundry Pro 2.0, we recommend washing using nothing but cold water.
NEVER apply detergent directly to dry clothes. Allow washer to ll, then add detergent to prevent staining on
clothes.
COLD HOT NORMAL OPERATION
Using your Laundry Pro 2.0 is as simple as turning on the washing machine.
Laundry Pro 2.0 is designed to use the COLD/COLD setting of your washing machine.
HEAVY STAINS
For heavy stains, pre-treat area, apply pre-treater, rub gently and let stand for several minutes.
Wash as normal.

11
When connecting hoses to your
Laundry Pro 2.0 hand start the hose
connector(s). Using adjustable pliers, nish
tightening hose connector(s).
CAUTION:
Some washing machine models require water pressure to both the Hot and Cold valves for proper
operation. In some cases, if only the COLD water side is connected, the water valve will not operate
or the washing machine will not ll to the proper level. To solve this problem, the installation of
a “Y” adapter (available at most hardware stores) may be used. The use of the “Y” adapter allows
water to ow equally through both the HOT and COLD water valves. Optional stainless steel hose
(item #: 49701-US) must be installed on the hot water connection. To Install, turn water o at the
valves and disconnect the existing HOT water hose (at the valve and washing machine). Connect
the “Y” adapter to the outlet on your Laundry Pro 2.0, then connect both the optional stainless
steel hose (item #: 49701-US) and Cold hose from your washer to the “Y” adapter (see diagram
below). Operate your washer on the WARM/WARM setting (your Laundry Pro 2.0 will still be using
just cold water).
Turn o both water valves (hot and cold)
before disconnecting hoses. Failure to
follow these instructions may result in water
leakage and/or possible injury
from hot water.
CAUTION:
NOTE: Your hot source water valve will not have a hose connected to it.
Make sure it is fully turned o. It is recommended you secure a cap
(available at most home improvement stores) to prevent leakage.
NOTE: The “Y” adapter needs to be purchased locally. Use only a metal adapter.
DO NOT use plastic.
FOR WASHERS THAT REQUIRE HOT & COLD WATER INPUT
Connect to household
plumbing COLD water valve
“Y” adapter
Make sure the “Y” adapter
valve is in the on position.
NOTE: Use a metal “Y” adapter.
Do not use plastic
Connect to HOT water inlet
on washing machine
Connect to COLD water inlet
on washing machine
Disconnect the existing hose
from the HOT valve and washing
machine and remove. Replace with
optional stainless
steel hose. Part No.
49701-US
(not included).
Disconnect this stainless steel hose from
the OUTLET on your Laundry Pro 2.0, then
connect it to the “Y” adapter.
Connect the “Y” adapter to the OUTLET on your
Laundry Pro 2.0. Be sure to hold the tting with
pliers while tightening the adapter.
Stainless steel hose supplied
with Laundry Pro 2.0.

12
STATUS INDICATIONS
The Laundry Pro 2.0 monitors its operations with a blue LED indicator:
• Unit on = LED on steadily. (“unit on” means whenever water is owing
through the unit).
• ActivePure cell replacement upcoming (@ approx.. 7500 hours) = periodic
brief LED ash (visual chirp) when unit is o, but goes to steady on when
water is owing through the unit.
• ActivePure cell replacement required (@ approx. 9000 hours) = periodic
brief LED ash (visual chirp) whether unit is o or on. UV bulb will NOT be
turned on again until cell is replaced.
• UV bulb failure = periodic brief LED ash (visual chirp) – same as
ActivePure cell replacement required above.
• ActivePure cell replacement: When replacing the ActivePure cell, there
is a switch on the main circuit board which must pressed. When this
happens, the LED will blink 3 times (longer than the brief “chirp” ashes
above) and then shut o. This indicates that the ActivePure cell timer has
been reset to 0. Pressing the button at any time before the 7500 hour mark
*or* before a bulb failure has been detected will NOT reset the timer.
• Leak Alarm: LED will ash in conjunction with alarm beeping.
If this occurs, please contact Customer Service at [phone]
for assistance. España: www.laundrypro.es; Italia: www.laundrypro.it;
Portugal: www.laundrypro.pt.
Electrical Shock Hazard. Disconnect power before
attempting installation or service.
Electrical Shock Hazard. When working with electrical
connections, the appliance and surrounding area should
be clean and dry of any standing water. Failure to follow
these instructions can result in death, re, or electrical
shock.
Do not operate Laundry Pro 2.0 with the front cover
removed or improperly installed. Failure to follow these
instructions can result in severe eye damage, death,
or electrical shock.
WARNING:
CAUTION:
WARNING:
TEMPERATURE CONTROLLING WATER VALVES
Some washers monitor the incoming cold water temperature and adjust too cold of water by adding hot water, even if the water temperature is set to cold. If you
have one of these washers, do not install with the “Y” adapter as it may cause the washer to not operate correctly. Consult your washing machine owner’s manual
if needed.
An optional Laundry Pro 2.0 water tap allows you to run water with hydrogen and oxygen based oxidizers for cleaning surfaces, without the cost or chemical
irritants found in most traditional cleaning products. (ActiveClean Port - 49693-US)
EXTERNAL WATER TAP AVAILABLE SEPARATELY
Status Indicator Light
Circuit Board

13
FREQUENTLY ASKED QUESTIONS
Does Laundry Pro 2.0 get out tough stains without pretreating?
Tough stains will still require pretreatment.
Does the Laundry Pro 2.0 work with all types of water including hard
water? Laundry Pro 2.0 will work with all household water qualities,
however additional sediment pre-ltering may be necessary depending
on the source water condition.
NOTE: Never use with a carbon lter.
Will the Laundry Pro 2.0 work with commercial washing machines?
Laundry Pro 2.0 is designed for residential use only.
Is a plumber required to install Laundry Pro 2.0?
The customer is responsible for installation of their Laundry Pro 2.0 unit.
Some customers may prefer to have a plumber perform the installation
although Laundry Pro 2.0 can be installed in most homes by the home
owner using standard hand tools. It should be noted there are potential
problems which can arise during the installation depending on the
condition of the plumbing in the home and the conguration and
location of the washer. If the cold water valve is stuck or the washing
machine needs to be moved back which may require re-leveling, a
plumber may be required. Aerus is not liable for improper installation or
damage caused from improper installation and recommends a licensed
plumber. Appropriate warnings and concerns are included in this
owner’s manual. Always follow local plumbing codes when installing the
Laundry Pro 2.0.
Can I hook the Laundry Pro 2.0 unit up to things other than a washing
machine? No. However, Aerus has an optional ActiveClean port kit you
can install on the Laundry Pro 2.0 to create water with oxygen based
oxidizers for other cleaning uses (see page 12).
What eect does Laundry Pro 2.0 have on elastic?
Normal operation of a Laundry Pro 2.0 unit should have no negative
impact on elastic in clothing.
Can I let my clothes soak?
It is not recommended that clothes are allowed to soak in Laundry Pro
2.0 water.
Installation procedures can vary according to washing machine model. If you experience installation problems, read the manual rst to make sure you
have installed the unit correctly. Call Customer Service at 800-572-0502 for more information. España: www.laundrypro.es; Italia: www.laundrypro.it;
Portugal: www.laundrypro.pt.
INSTALLATION PROBLEMS?

14
LIMITED THREE 3 YEAR WARRANTY
Customer should not repackage and ship the Laundry Pro 2.0™ unit due to possibility of irreparable damage.
For warranty service, please contact your Distributor or our Customer Service for the address of the nearest service center.
Customer should not repackage and ship the Laundry Pro 2.0 unit because
irreparable damage can occur. For warranty service, please contact
Customer Service at [phone].
WHAT IS COVERED BY THIS WARRANTY
We warrant the Laundry Pro 2.0 to the consumer, subject to the conditions
below, against defects in workmanship or material, provided that the
products are returned to your distributor within the following time periods:
• Laundry Pro 2.0 within 3 years of date of purchase.
INSTALLATION AND MAINTENANCE REQUIREMENTS
This warranty is expressly conditioned upon the following installation
and maintenance requirements: (i) the Laundry Pro 2.0 must be installed,
used & maintained in accordance with the Owner’s Manual & by a licensed
professional (if applicable); and (ii) all hoses must be replaced at the
intervals prescribed in the Owner’s Manual (proof of hose change may be
required). Failure to meet any of these requirements will void this warranty.
Servicing your Laundry Pro 2.0 by parties other than an authorized
representative and/or using parts other than genuine parts will also void
this warranty.
HOW TO OBTAIN WARRANTY SERVICE
Customers must contact their distributor or Customer Service and provide
proof of purchase within the above time periods. We will repair or replace
and return the product, without charge and within a reasonable period of
time, subject to the conditions in the above paragraphs, if its examination
shall disclose any part to be defective in workmanship or material. If we, in
our discretion, are unable to repair the product after a reasonable number
of attempts, we will provide either a refund of the purchase price or a
replacement unit, at the company’s option.
WHAT IS NOT COVERED BY THIS WARRANTY
This product is intended for household use only and only for use with
municipal water systems. Ordinary wear and tear shall not be considered a
defect in workmanship or material. These warranties do not apply to lters
nor for loss or damage caused by accident, re, abuse, misuse, improper
installation, leaking, modication, misapplication, commercial use, or by
any repairs other than those provided by an authorized representative. This
warranty does not cover any water damage.
EXCLUSION OF OTHER WARRANTIES AND CONDITIONS
EXCEPT AS PROVIDED HEREIN, Aerus MAKES NO REPRESENTATION OR
WARRANTY OF ANY KIND. ALL OTHER WARRANTIES OF ANY KIND, EXPRESS
OR IMPLIED, ARE HEREBY EXPRESSLY DISCLAIMED, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
UNAUTHORIZED CHANNELS & MISSING SERIAL NUMBERS
Our products are authorized for sale through Authorized Representatives
only. All warranties are void if a product is purchased through unauthorized
channels. We will not extend warranty coverage on any product sold in a
manner that violates our Internet advertising policies and guidelines. This
includes websites that are not authorized to use our trademarked names,
images and logos, as well as Internet auction sites. These websites would
include ebay® and CraigsList®. If a valid serial number is missing from the
product, the warranty will be voided. To conrm warranty coverage prior to
purchasing a product, contact Customer Service.
LIMITATION OF LIABILITY FOR SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES
Aerus SHALL NOT IN ANY CASE BE LIABLE FOR SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING FROM BREACH OF EXPRESSED OR
IMPLIED WARRANTIES, CONDITIONS, GUARANTEES OR REPRESENTATIONS,
BREACH OF CONTRACT, NEGLIGENCE OR ANY OTHER LEGAL THEORY. Such
excluded damages include, but are not limited to, loss of prots or revenue,
loss of the use of the products, and any loss caused by leaks or other water
damage.
FOR U.S. APPLICATION ONLY
This warranty gives you specic legal rights, and you may also have other
rights which vary from state to state. Some states do not allow limitations
on warranties, or on remedies for breach. In such states, the above
limitations may not apply to you.
FOR CANADIAN APPLICATION ONLY
Exclusion of Subsequent Owners: Except as otherwise required by
applicable legislation, this warranty is not transferable. This warranty gives
you specic legal rights and you may also have other rights which vary
from province to province. Some provinces and territories do not allow
limitations on warranties, or on remedies for breach. In such provinces or
territories, the above limitations may not apply to you.
If any provision of this warranty or part thereof is held by a court of
competent jurisdiction to be invalid, illegal or unenforceable, the validity,
legality and enforceability of the remaining provisions or parts thereof will
not in any way be aected or impaired within the jurisdiction of that court.
This entire warranty shall continue to be valid, legal and enforceable in any
jurisdiction where a similar determination has not been made.
This warranty is provided by:
Aerus LLC
300 East Valley Drive,
Bristol, VA 24201
SERVICE
Every eort is made to ensure that customers receive an up-to-date
instruction manual on the use of our products; however, from time to time,
modications to our products may without notice make the information
contained herein subject to alteration. For the latest information, please call
customer service at [phone].
España: www.laundrypro.es
Italia: www.laundrypro.it
Portugal: www.laundrypro.pt

15

www.beyondbyaerus.com
España: www.laundrypro.es
Italia: www.laundrypro.it
Portugal: www.laundrypro.pt
Aerus LLC | 300 East Valley Drive | Bristol, VA 24201 | 800.572.0502
© Aerus LLC. All Rights Reserved
65-00659 VA-01015
For information regarding the use of this product please call Customer Service.
18005720502
This equipment has been tested and found to comply
with the limits for Industrial, Scientific, and Medical
Equipment (ISM), pursuant to Part 18 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can
radiate radio frequency energy, and if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the Independent Contractor for help.
FCC Declaration of Conformity
Name: Aerus LLC
Model: W1017C
Manufacturer: Aerus LLC
This device complies with Part 18 of the FCC Rules.
RESPONSIBLE PARTY
Aerus LLC
300 East Valley Drive
Bristol, VA 24201
Ph: 800.572.0502
Signature:___________________________
Printed Name: Andrew Eide
Title: Vice President of Product Development
and Manufacturing
Date: 04/17/18

2.0
A BEYOND BY AERUS TECHNOLOGY
ATTENTION : VEUILLEZ LIRE ATTENTIVEMENT LE PRÉSENT MANUEL POUR OBTENIR
LES INDICATIONS D’UTILISATION ET DE FONCTIONNEMENT CORRECTES.
SYSTÈME DE LESSIVE À EAU FROIDE

18
TABLE DES MATIÉRES
Informations générales . . . . . . . . . . . . . . . . . . . . 18
Considérations d’utilisation et de sécurité . . . . . . . . . . . 19
Exigences liées à l’installation . . . . . . . . . . . . . . . . . 20
Avant de commencer . . . . . . . . . . . . . . . . . . . . . 21
Retirer le couvercle . . . . . . . . . . . . . . . . . . . . . . 21
Installation des supports muraux ou des vis . . . . . . . . . . 22
Remettre le couvercle . . . . . . . . . . . . . . . . . . . . . 23
Installation des tuyaux . . . . . . . . . . . . . . . . . . . .23-24
Branchement de l’adaptateur électrique . . . . . . . . . . . 24
Mise en place du système . . . . . . . . . . . . . . . . . . . 25
Avant de nettoyer votre linge . . . . . . . . . . . . . . . . . 26
Utilisation du Laundry Pro 2.0 . . . . . . . . . . . . . . . . . 26
Pour les machines à laver qui utilisent une entrée
d’eau chaude et une entrée d’eau froide . . . . . . . . . . . . 27
Robinet externe de régulation de température . . . . . . . . 28
Indicateurs de panne . . . . . . . . . . . . . . . . . . . . . 28
Foire aux questions . . . . . . . . . . . . . . . . . . . . . . 29
Des problèmes d’installation? . . . . . . . . . . . . . . . . . 29
Renseignements sur la garantie . . . . . . . . . . . . . . . . 30
PRÉSENTATION DU PRODUIT
Le dispositif Laundry Pro 2.0 est conçu pour fonctionner en conjonction avec
votre machine à laver, et permet de laver du linge à l’eau froide grâce à notre
technologie exclusive ActivePure®. Lorsque votre machine à laver commence
à se remplir, le Laundry Pro 2.0 se met en marche. Le dispositif Laundry Pro
2.0 est équipé d’un capteur de fuite interne. Consultez la page 28 pour de plus
amples détails.
Il existe une nouvelle façon, plus ecace et plus astucieuse, de faire votre
lessive, basée sur la science et la technologie écoresponsables. Le Laundry
Pro 2.0, conçu et fabriqué aux États-Unis, élimine le recours à l’eau chaude,
aux détergents, aux assouplissants et aux eaux de javel, permettant donc
d’économiser de manière importante
à chaque brassée.
Le Laundry Pro 2.0 est conçu pour une utilisation et une installation faciles,
s’adaptant parfaitement à toute machine à laver standard ou haute ecacité.
Il est conçu pour une utilisation résidentielle par tout individu désirant
une alternative économique et écologique aux détergents et aux produits
chimiques habituellement utilisés, sans modier les appareils, la plomberie
ou les systèmes électroniques existants.
Le Laundry Pro 2.0 utilise une variante de la technologie initialement
développée pour une utilisation à bord de la Station spatiale internationale et
ore une Certied Space Technology exclusive reconnue par
l’Agence spatiale.
À COMPLÉTER ET À CONSERVER
Le numéro de série est situé sur le panneau à l’arrière de l’appareil, en
dessous de la ligne de branchement d’eau. Veuillez l’inscrire ci-dessous
et le conserver pour toute référence future.
Numéro de modèle________________________________________________________
Numéro de série _________________________________________________________
Date d’achat ____________________________________________________________
Représentant(e) des ventes___________________________________________________
_____________________________________________________________________
Numéro de téléphone de l’établissement Aerus______________________________________
_____________________________________________________________________
Adresse de l’établissement Aerus_______________________________________________
_____________________________________________________________________
SPÉCIFICATIONS
Adaptateur CA/CC :
• CA d’entrée : 100 - 240 V ~ 50/60 Hz 0,45 A
• CC de sortie : 12 V
Consommation électrique :
• 0,4 AC (mode veille)
• 1,3 AC (fonctionnement)
DyPression hydrodynamique :
• 20 psi (minimum) à 60 psi/1,37 à 4,13 bars
Température de l’eau :
• Utiliser de l’eau froide uniquement
(ne pas utiliser d’eau chaude)
Environnement de fonctionnement :
• 50 °F - 100 °F (10 °C - 37,8 °C)
• Humidité 40 % ~ 85 %
Dimensions:
• 17,3 po x 5,19 po x 3,69 po
• 43,94 cm x 13,48 cm x 9,37 cm
Poids :
• 4,3 lb
• 1,95 kg
INFORMATIONS GÉNÉRALES

19
• Veuillez lire ce manuel dans son intégralité avant d’installer ou d’utiliser votre système Laundry Pro 2.0.
• Utiliser à l’intérieur seulement.
• Ne pas utiliser l’appareil sans le couvercle en place.
• Débrancher l’alimentation électrique avant de procéder à l’entretien.
• Ne pas utiliser de rallonge électrique ou tout autre adaptateur avec cet appareil.
• Il n’est pas recommandé d’utiliser cet appareil avec de l’eau ayant des taux élevés de sédiments. Si
votre eau contient des taux élevés de sédiments, consultez un expert en ltration de l’eau pour en
savoir plus sur les options disponibles.
• La pression dynamique maximale de l’arrivée d’eau est de 60 psi.
• Utilisez le tuyau neuf fourni avec l’unité pour raccorder le Laundry Pro 2.0 à votre machine à laver. Vous
devez également remplacer tout tuyau de machine à laver datant de plus de trois ans.
• Ne nettoyez pas votre Laundry Pro 2.0 avec des produits chimiques corrosifs, des abrasifs ou des
détergents. Pour le nettoyer, utilisez un linge doux humidié avec de l’eau.
• Le dispositif Laundry Pro 2.0 est uniquement destiné à un usage résidentiel normal. L’utilisation de
l’appareil dans un lieu commercial ou non résidentiel, ou avec une laveuse non résidentielle, annulera
votre garantie.
CONSIDÉRATIONS D’UTILISATION ET DE SÉCURITÉ
PRÉCAUTIONS DE SÉCURITÉIMPORTANTES
• L’ensemble du câblage doit être eectué conformément au National Electrical Code ANSI/FNPA,
No. 70, selon la dernière version des codes et règlements locaux aux États-Unis. Pour les codes
de l’électricité à l’extérieur des États-Unis, consultez votre agence de réglementation locale an
de connaitre les derniers codes et règlements. Le propriétaire de l’appareil a la responsabilité
personnelle et l’obligation de fournir une alimentation électrique adéquate au dispositif.
Nous avons indiqué des
avertissements de sécurité
importants dans le présent manuel
et sur votre appareil. Lisez et
respectez toujours ces messages de
sécurité.
Les avertissements de sécurité
compris dans le présent manuel
sont dénis comme suit :
AVERTISSEMENT :
Risque d’électrocution. Le non-
respect des instructions vous
expose à un danger de mort ou à
un risque de blessure grave.
ATTENTION :
Le non-respect des instructions
expose votre appareil et la zone
environnante à des dégâts
potentiels.
AVERTISSEMENT :
Si les instructions ne sont pas suivies
immédiatement, vous vous exposez
à un danger de mort ou à un risque
de blessure grave.
REMARQUE :
Ces informations sont
fournies pour vous aider lors de
l’installation et de l’utilisation de
l’appareil.
REMARQUE : Votre dispositif Laundry Pro 2.0 a été contrôlé à l’usine. Il est normal
qu’une faible quantité d’eau résiduelle se trouve à l’intérieur de l’appareil :
elle est due aux contrôles en question.
L’eau traitée par votre dispositif Laundry Pro 2.0 est uniquement destinée au nettoyage de vos
vêtements et n’est approuvée pour AUCUN TYPE de consommation interne (boire, se baigner,
se brosser les dents, etc.). Il ne faut PAS boire, ingérer ou consommer l’eau provenant de votre
dispositif Laundry Pro 2.0 ou de votre machine à laver. NE donnez PAS l’eau provenant de votre
dispositif Laundry Pro 2.0 à vos animaux de compagnie.
ATTENTION :
VEUILLEZ CONSERVER CES INSTRUCTIONS

20
EXIGENCES ÉLECTRIQUES
Fusible ou disjoncteur de 100 - 240 V 50/60 Hz 0.45 A (minimum). Le
Laundry Pro 2.0 est équipé d’une alimentation électrique
CA vers CC.
NE JAMAIS UTILISER DE RALLONGE ÉLECTRIQUE.
EXIGENCES EN MATIÈRE D’EAU
Une pression d’eau dynamique comprise entre 20 psi/1,37 bar et
60 psi/4,13 bar est nécessaire pour que votre Laundry Scrubber 2.0
fonctionne correctement. Voir les Avertissements ci-dessous.
SORTIE
D’EAU
ARRIVÉE
D’EAU
EXIGENCES LIÉES À L’INSTALLATION
CONSIDÉRATIONS LOCALES
Le Laundry Pro 2.0 ne doit jamais être installé là où l’eau risque de geler,
car l’appareil contiendra toujours de l’eau dans le boitier, les robinets et
les exibles. Cela pourrait endommager les composants internes. Il est
également recommandé d’éviter l’installation dans des zones soumises
à une humidité élevée car le fonctionnement de l’appareil pourrait en
être aecté.
17,3 po (43,94 cm)
5,19 po (13,48 cm)
3,69 po (9,37 cm)
La pression d’entrée de l’eau doit être supérieure à 20 psi/1,37 bar.
Si votre pression d’eau est supérieure à 60 psi/4,13 bars, vous devez
installer un réducteur de pression en ligne avant l’installation du
système Laundry Pro 2.0. Le non-respect de ces instructions peut
entraîner des fuites d’eau, des dommages matériels ou des blessures
corporelles, et annuler votre garantie. Une pression d’eau comprise
entre 20 psi/1,37 bar et 60 psi/4,13 bars est nécessaire pour que votre
Laundry Pro 2.0 fonctionne correctement. Une pression d’eau trop
basse peut empêcher l’appareil de fonctionner correctement et/ou
causer une défaillance de la vanne d’entrée de votre machine à laver.
Le robinet de votre machine à laver peut également ne pas se refermer
complètement. Consultez la documentation fournie avec votre machine
à laver an d’obtenir de plus amples spécications. Votre machine à
laver ainsi que le robinet d’eau froide doivent se trouver à moins de 122
cm du côté droit de l’appareil an de permettre l’utilisation du exible
d’arrivée fourni avec votre Laundry Pro 2.0.
AFIN D’ÉVITER TOUT DÉGÂT CAUSÉ PAR L’EAU ET PROVOQUÉ PAR LA
FUITE D’UN FLEXIBLE, VEILLEZ À CE QUE LES ROBINETS SOIENT
ACCESSIBLES ET FERMEZ-LES LORSQUE LA MACHINE À LAVER N’EST
PAS UTILISÉE. NE PAS UTILISER AVEC UN FILTRE À CHARBON.
ATTENTION :
