Beyondvape Centurion User manual

User Manual

Specification & Features
Size: 52.5*32.5*96.5mm
Thread Type: 510 thread
Cell type: High-rate 26650 cell(discharging current should be above 35A)
High-rate 18650 cell with the help of battery sleeve(discharging current should
be above 25A )
Output Mode: TC-Ni/TC-Ti/TC-SS/TCR/VW/Bypass Mode
Output Wattage: 1-100w
Resistance Range:
0.05-1.5ohm for TC modes
0.1-3.5ohm for VW/ Bypass mode
Temperature Range: 100-315°C/ 200-600°F(TC modes)
Standard Configuration
1*Beyond Vape Centurion 1*Decorative Ring
1*Battery Sleeve 1*USB Cable
1*User Manual 1*Warranty Card
1*Disclaimer Card
510 spring
connector
Fire button
Decorative ring
Up button
Down button
OLED screen
How to use:
1. Power On/Off: Unscrew the bottom cover and put one 26650 cell into the battery body. Press the fire button 5 times in
quick succession to turn the device on and off.
You can also use one 18650 cell with the help of battery sleeve, and then the maximum output power recommended is 75W.
(Note: Please adjust the wattage to a proper range to match your atomizer before using. Also, for safety reasons, please
refrain form using damaged batteries, i.e., dents, torn wrapping, burnt, etc.)
2. Stealth Function: While the device is on, simultaneously hold the fire button and the down button. This will switch the
screen display on and off.
English1
3. Resistance Lock Function: While the device is on, simultaneously hold the fire button and
the up button to enter Resistance Lock mode. To disable resistance lock, repeat the
procedure.(Note: Such operation should be carried out at room temperature.)
4. Adjustment Lock function: While the device is on, simultaneously press the up and down
buttons. This will Lock and Unlock the adjustment button functions.
5. Micro USB Port Function: The USB port can be used for upgrading firmware, but it is
recommended that the battery is removed to charge.
6. Switch the Display Mode: To rotate the screen display 180 degrees, press the up and down
buttons simultaneously in shutdown(power off) state.

How to use:
1. Power On/Off: Unscrew the bottom cover and put one 26650 cell into the battery body. Press the fire button 5 times in
quick succession to turn the device on and off.
You can also use one 18650 cell with the help of battery sleeve, and then the maximum output power recommended is 75W.
(Note: Please adjust the wattage to a proper range to match your atomizer before using. Also, for safety reasons, please
refrain form using damaged batteries, i.e., dents, torn wrapping, burnt, etc.)
2. Stealth Function: While the device is on, simultaneously hold the fire button and the down button. This will switch the
screen display on and off.
English 2
3. Resistance Lock Function: While the device is on, simultaneously hold the fire button and
the up button to enter Resistance Lock mode. To disable resistance lock, repeat the
procedure.(Note: Such operation should be carried out at room temperature.)
4. Adjustment Lock function: While the device is on, simultaneously press the up and down
buttons. This will Lock and Unlock the adjustment button functions.
5. Micro USB Port Function: The USB port can be used for upgrading firmware, but it is
recommended that the battery is removed to charge.
6. Switch the Display Mode: To rotate the screen display 180 degrees, press the up and down
buttons simultaneously in shutdown(power off) state.
- -

How to use:
1. Power On/Off: Unscrew the bottom cover and put one 26650 cell into the battery body. Press the fire button 5 times in
quick succession to turn the device on and off.
You can also use one 18650 cell with the help of battery sleeve, and then the maximum output power recommended is 75W.
(Note: Please adjust the wattage to a proper range to match your atomizer before using. Also, for safety reasons, please
refrain form using damaged batteries, i.e., dents, torn wrapping, burnt, etc.)
2. Stealth Function: While the device is on, simultaneously hold the fire button and the down button. This will switch the
screen display on and off.
Shift among TC-Ni/TC-Ti/TC-SS/TCR/VW/Bypass Mode
When the device is powered on, press the fire button 3 times in quick succession to enter the mode switching state. By
pressing the up or down button to shift among TC-Ni, TC-Ti, TC-SS, TCR M1, TCR M2, TCR M3, VW and Bypass mode.
TC-Ni/TC-Ti/TC-SS/TCR Mode:
TC-SS Mode: The newly added TC-SS mode is suitable to SS316 coil.
TCR Mode: TCR(Temperature Coefficient of Resistance) Mode is a new vaping mode introduced by Wismec. In this mode,
English3
3. Resistance Lock Function: While the device is on, simultaneously hold the fire button and
the up button to enter Resistance Lock mode. To disable resistance lock, repeat the
procedure.(Note: Such operation should be carried out at room temperature.)
4. Adjustment Lock function: While the device is on, simultaneously press the up and down
buttons. This will Lock and Unlock the adjustment button functions.
5. Micro USB Port Function: The USB port can be used for upgrading firmware, but it is
recommended that the battery is removed to charge.
6. Switch the Display Mode: To rotate the screen display 180 degrees, press the up and down
buttons simultaneously in shutdown(power off) state.
users can set the parameters according to the TCR of a coil.
The Setting of TCR Mode: In powered-off state, keep pressing the fire button and the up button simultaneously, then enter
the following into the TCR menu:
1. Press the up or down button to choose among TCR M1, M2 and M3;
2. Press the fire button to confirm the mode you have chosen;
3. Press the up or down button to increase or decrease the parameter according to the TCR of the coil;
4. Keep pressing the fire button or leave the interface for approximately 10 seconds to confirm.
TCR value range of Beyond Vape Centurion for your reference
Note: 1. The TCR value in the sheet is 10 multiplied by the actual TCR.
2. The TCR value range for Beyond Vape Centurion is 1-1000.
Supplementary TC Modes Functions:
Wattage adjustment: In TC modes, press the fire button 4 times in quick succession to enter the menu, press the up button
to increase wattage and the down button to decrease wattage. Long pressing the up or down button will make the wattage
setting rapidly increase or decrease.
Temperature adjustment: In TC modes, the temperature can be adjusted from (100-315°C or 200-600˚F) with the up and
down buttons.
Shift between °C and ˚F: If you increase the temperature to 315 °C, and continue to press the up button, the temperature
readings will automatically change to the lowest Fahrenheit(200˚F). Equally, if the temperature is decreased below the
minimum(100 °C), the unit will change back to ˚F automatically, and the temperature will start to decrease from 600˚F.
Note:
1. In TC modes, be careful to attach new atomizers that have cooled to room temperature. If a new atomizer has not cooled
down before attaching, the temperature may read and protect incorrectly until the new atomizer cools.
2. When you connect a new atomizer or disconnect and reconnect your existing atomizer, the device will prompt you to
confirm this change and a message will prompt “new coil up same down”. Press the up button to confirm that a new atomizer
has been attached. Press the down button to confirm that the same atomizer has been reconnected.
3. When using non-TC coils or TC coils with a resistance higher than 1.5ohm in TC modes, the device will automatically
switch to VW mode.
VW Mode:
In this mode, output wattage can be adjusted from 1W to 100W with the up and down buttons.
Bypass Mode:
Bypass mode is a direct output mode of voltage. In this mode, the internal chip is “bypassed” and the supporting atomizer
resistance is 0.1-3.5ohm.
Malfunction Indication and Protection:
No Atomizer Alert: When the device does not detect an atomizer, the OLED screen will
display “No Atomizer”.
Atomizer Low Alert: When the resistance of atomizer is lower than 0.1ohm in VW/Bypass
mode or lower than 0.05ohm in TC modes, the OLED screen will display “Atomizer Low”.
Atomizer Short-circuit Protection: When an atomizer short-circuit occurs, the OLED
Screen will display “Atomizer Short”.
Temperature Alert: If the internal temperature of the device is over 70°C(or 158˚F) , the output
will shut off automatically and the screen will display “Device too hot”.
Temperature Protection: In TC modes, if the actual temperature of coil reaches the set
temperature, the device shows “Temp Protection”.
Weak Battery Alert: In TC/VW/Bypass mode, when the device installed with an atomizer is
working and the voltage of battery is below 2.9V, the device shows “Weak Battery”. Meanwhile,
the output power will be reduced accordingly.

How to use:
1. Power On/Off: Unscrew the bottom cover and put one 26650 cell into the battery body. Press the fire button 5 times in
quick succession to turn the device on and off.
You can also use one 18650 cell with the help of battery sleeve, and then the maximum output power recommended is 75W.
(Note: Please adjust the wattage to a proper range to match your atomizer before using. Also, for safety reasons, please
refrain form using damaged batteries, i.e., dents, torn wrapping, burnt, etc.)
2. Stealth Function: While the device is on, simultaneously hold the fire button and the down button. This will switch the
screen display on and off.
Shift among TC-Ni/TC-Ti/TC-SS/TCR/VW/Bypass Mode
When the device is powered on, press the fire button 3 times in quick succession to enter the mode switching state. By
pressing the up or down button to shift among TC-Ni, TC-Ti, TC-SS, TCR M1, TCR M2, TCR M3, VW and Bypass mode.
TC-Ni/TC-Ti/TC-SS/TCR Mode:
TC-SS Mode: The newly added TC-SS mode is suitable to SS316 coil.
TCR Mode: TCR(Temperature Coefficient of Resistance) Mode is a new vaping mode introduced by Wismec. In this mode,
Material
Nickel
TCR value range
600-700
NiFe 300-400
Titanium 300-400
SS (303, 304, 316, 317) 80-200
English 4
3. Resistance Lock Function: While the device is on, simultaneously hold the fire button and
the up button to enter Resistance Lock mode. To disable resistance lock, repeat the
procedure.(Note: Such operation should be carried out at room temperature.)
4. Adjustment Lock function: While the device is on, simultaneously press the up and down
buttons. This will Lock and Unlock the adjustment button functions.
5. Micro USB Port Function: The USB port can be used for upgrading firmware, but it is
recommended that the battery is removed to charge.
6. Switch the Display Mode: To rotate the screen display 180 degrees, press the up and down
buttons simultaneously in shutdown(power off) state.
users can set the parameters according to the TCR of a coil.
The Setting of TCR Mode: In powered-off state, keep pressing the fire button and the up button simultaneously, then enter
the following into the TCR menu:
1. Press the up or down button to choose among TCR M1, M2 and M3;
2. Press the fire button to confirm the mode you have chosen;
3. Press the up or down button to increase or decrease the parameter according to the TCR of the coil;
4. Keep pressing the fire button or leave the interface for approximately 10 seconds to confirm.
TCR value range of Beyond Vape Centurion for your reference
Note: 1. The TCR value in the sheet is 10 multiplied by the actual TCR.
2. The TCR value range for Beyond Vape Centurion is 1-1000.
Supplementary TC Modes Functions:
Wattage adjustment: In TC modes, press the fire button 4 times in quick succession to enter the menu, press the up button
to increase wattage and the down button to decrease wattage. Long pressing the up or down button will make the wattage
setting rapidly increase or decrease.
Temperature adjustment: In TC modes, the temperature can be adjusted from (100-315°C or 200-600˚F) with the up and
down buttons.
Shift between °C and ˚F: If you increase the temperature to 315 °C, and continue to press the up button, the temperature
readings will automatically change to the lowest Fahrenheit(200˚F). Equally, if the temperature is decreased below the
minimum(100 °C), the unit will change back to ˚F automatically, and the temperature will start to decrease from 600˚F.
Note:
1. In TC modes, be careful to attach new atomizers that have cooled to room temperature. If a new atomizer has not cooled
down before attaching, the temperature may read and protect incorrectly until the new atomizer cools.
2. When you connect a new atomizer or disconnect and reconnect your existing atomizer, the device will prompt you to
confirm this change and a message will prompt “new coil up same down”. Press the up button to confirm that a new atomizer
has been attached. Press the down button to confirm that the same atomizer has been reconnected.
3. When using non-TC coils or TC coils with a resistance higher than 1.5ohm in TC modes, the device will automatically
switch to VW mode.
VW Mode:
In this mode, output wattage can be adjusted from 1W to 100W with the up and down buttons.
Bypass Mode:
Bypass mode is a direct output mode of voltage. In this mode, the internal chip is “bypassed” and the supporting atomizer
resistance is 0.1-3.5ohm.
Malfunction Indication and Protection:
No Atomizer Alert: When the device does not detect an atomizer, the OLED screen will
display “No Atomizer”.
Atomizer Low Alert: When the resistance of atomizer is lower than 0.1ohm in VW/Bypass
mode or lower than 0.05ohm in TC modes, the OLED screen will display “Atomizer Low”.
Atomizer Short-circuit Protection: When an atomizer short-circuit occurs, the OLED
Screen will display “Atomizer Short”.
Temperature Alert: If the internal temperature of the device is over 70°C(or 158˚F) , the output
will shut off automatically and the screen will display “Device too hot”.
Temperature Protection: In TC modes, if the actual temperature of coil reaches the set
temperature, the device shows “Temp Protection”.
Weak Battery Alert: In TC/VW/Bypass mode, when the device installed with an atomizer is
working and the voltage of battery is below 2.9V, the device shows “Weak Battery”. Meanwhile,
the output power will be reduced accordingly.
5

Shift among TC-Ni/TC-Ti/TC-SS/TCR/VW/Bypass Mode
When the device is powered on, press the fire button 3 times in quick succession to enter the mode switching state. By
pressing the up or down button to shift among TC-Ni, TC-Ti, TC-SS, TCR M1, TCR M2, TCR M3, VW and Bypass mode.
TC-Ni/TC-Ti/TC-SS/TCR Mode:
TC-SS Mode: The newly added TC-SS mode is suitable to SS316 coil.
TCR Mode: TCR(Temperature Coefficient of Resistance) Mode is a new vaping mode introduced by Wismec. In this mode,
English5
users can set the parameters according to the TCR of a coil.
The Setting of TCR Mode: In powered-off state, keep pressing the fire button and the up button simultaneously, then enter
the following into the TCR menu:
1. Press the up or down button to choose among TCR M1, M2 and M3;
2. Press the fire button to confirm the mode you have chosen;
3. Press the up or down button to increase or decrease the parameter according to the TCR of the coil;
4. Keep pressing the fire button or leave the interface for approximately 10 seconds to confirm.
TCR value range of Beyond Vape Centurion for your reference
Note: 1. The TCR value in the sheet is 10 multiplied by the actual TCR.
2. The TCR value range for Beyond Vape Centurion is 1-1000.
Supplementary TC Modes Functions:
Wattage adjustment: In TC modes, press the fire button 4 times in quick succession to enter the menu, press the up button
to increase wattage and the down button to decrease wattage. Long pressing the up or down button will make the wattage
setting rapidly increase or decrease.
Temperature adjustment: In TC modes, the temperature can be adjusted from (100-315°C or 200-600˚F) with the up and
down buttons.
Shift between °C and ˚F: If you increase the temperature to 315 °C, and continue to press the up button, the temperature
readings will automatically change to the lowest Fahrenheit(200˚F). Equally, if the temperature is decreased below the
minimum(100 °C), the unit will change back to ˚F automatically, and the temperature will start to decrease from 600˚F.
Note:
1. In TC modes, be careful to attach new atomizers that have cooled to room temperature. If a new atomizer has not cooled
down before attaching, the temperature may read and protect incorrectly until the new atomizer cools.
2. When you connect a new atomizer or disconnect and reconnect your existing atomizer, the device will prompt you to
confirm this change and a message will prompt “new coil up same down”. Press the up button to confirm that a new atomizer
has been attached. Press the down button to confirm that the same atomizer has been reconnected.
3. When using non-TC coils or TC coils with a resistance higher than 1.5ohm in TC modes, the device will automatically
switch to VW mode.
VW Mode:
In this mode, output wattage can be adjusted from 1W to 100W with the up and down buttons.
Bypass Mode:
Bypass mode is a direct output mode of voltage. In this mode, the internal chip is “bypassed” and the supporting atomizer
resistance is 0.1-3.5ohm.
Malfunction Indication and Protection:
No Atomizer Alert: When the device does not detect an atomizer, the OLED screen will
display “No Atomizer”.
Atomizer Low Alert: When the resistance of atomizer is lower than 0.1ohm in VW/Bypass
mode or lower than 0.05ohm in TC modes, the OLED screen will display “Atomizer Low”.
Atomizer Short-circuit Protection: When an atomizer short-circuit occurs, the OLED
Screen will display “Atomizer Short”.
Temperature Alert: If the internal temperature of the device is over 70°C(or 158˚F) , the output
will shut off automatically and the screen will display “Device too hot”.
Temperature Protection: In TC modes, if the actual temperature of coil reaches the set
temperature, the device shows “Temp Protection”.
Weak Battery Alert: In TC/VW/Bypass mode, when the device installed with an atomizer is
working and the voltage of battery is below 2.9V, the device shows “Weak Battery”. Meanwhile,
the output power will be reduced accordingly.

Shift among TC-Ni/TC-Ti/TC-SS/TCR/VW/Bypass Mode
When the device is powered on, press the fire button 3 times in quick succession to enter the mode switching state. By
pressing the up or down button to shift among TC-Ni, TC-Ti, TC-SS, TCR M1, TCR M2, TCR M3, VW and Bypass mode.
TC-Ni/TC-Ti/TC-SS/TCR Mode:
TC-SS Mode: The newly added TC-SS mode is suitable to SS316 coil.
TCR Mode: TCR(Temperature Coefficient of Resistance) Mode is a new vaping mode introduced by Wismec. In this mode,
English 6
users can set the parameters according to the TCR of a coil.
The Setting of TCR Mode: In powered-off state, keep pressing the fire button and the up button simultaneously, then enter
the following into the TCR menu:
1. Press the up or down button to choose among TCR M1, M2 and M3;
2. Press the fire button to confirm the mode you have chosen;
3. Press the up or down button to increase or decrease the parameter according to the TCR of the coil;
4. Keep pressing the fire button or leave the interface for approximately 10 seconds to confirm.
TCR value range of Beyond Vape Centurion for your reference
Note: 1. The TCR value in the sheet is 10 multiplied by the actual TCR.
2. The TCR value range for Beyond Vape Centurion is 1-1000.
Supplementary TC Modes Functions:
Wattage adjustment: In TC modes, press the fire button 4 times in quick succession to enter the menu, press the up button
to increase wattage and the down button to decrease wattage. Long pressing the up or down button will make the wattage
setting rapidly increase or decrease.
Temperature adjustment: In TC modes, the temperature can be adjusted from (100-315°C or 200-600˚F) with the up and
down buttons.
Shift between °C and ˚F: If you increase the temperature to 315 °C, and continue to press the up button, the temperature
readings will automatically change to the lowest Fahrenheit(200˚F). Equally, if the temperature is decreased below the
minimum(100 °C), the unit will change back to ˚F automatically, and the temperature will start to decrease from 600˚F.
Note:
1. In TC modes, be careful to attach new atomizers that have cooled to room temperature. If a new atomizer has not cooled
down before attaching, the temperature may read and protect incorrectly until the new atomizer cools.
2. When you connect a new atomizer or disconnect and reconnect your existing atomizer, the device will prompt you to
confirm this change and a message will prompt “new coil up same down”. Press the up button to confirm that a new atomizer
has been attached. Press the down button to confirm that the same atomizer has been reconnected.
3. When using non-TC coils or TC coils with a resistance higher than 1.5ohm in TC modes, the device will automatically
switch to VW mode.
VW Mode:
In this mode, output wattage can be adjusted from 1W to 100W with the up and down buttons.
Bypass Mode:
Bypass mode is a direct output mode of voltage. In this mode, the internal chip is “bypassed” and the supporting atomizer
resistance is 0.1-3.5ohm.
Malfunction Indication and Protection:
No Atomizer Alert: When the device does not detect an atomizer, the OLED screen will
display “No Atomizer”.
Atomizer Low Alert: When the resistance of atomizer is lower than 0.1ohm in VW/Bypass
mode or lower than 0.05ohm in TC modes, the OLED screen will display “Atomizer Low”.
Atomizer Short-circuit Protection: When an atomizer short-circuit occurs, the OLED
Screen will display “Atomizer Short”.
Temperature Alert: If the internal temperature of the device is over 70°C(or 158˚F) , the output
will shut off automatically and the screen will display “Device too hot”.
Temperature Protection: In TC modes, if the actual temperature of coil reaches the set
temperature, the device shows “Temp Protection”.
Weak Battery Alert: In TC/VW/Bypass mode, when the device installed with an atomizer is
working and the voltage of battery is below 2.9V, the device shows “Weak Battery”. Meanwhile,
the output power will be reduced accordingly.

Shift among TC-Ni/TC-Ti/TC-SS/TCR/VW/Bypass Mode
When the device is powered on, press the fire button 3 times in quick succession to enter the mode switching state. By
pressing the up or down button to shift among TC-Ni, TC-Ti, TC-SS, TCR M1, TCR M2, TCR M3, VW and Bypass mode.
TC-Ni/TC-Ti/TC-SS/TCR Mode:
TC-SS Mode: The newly added TC-SS mode is suitable to SS316 coil.
TCR Mode: TCR(Temperature Coefficient of Resistance) Mode is a new vaping mode introduced by Wismec. In this mode,
English7
users can set the parameters according to the TCR of a coil.
The Setting of TCR Mode: In powered-off state, keep pressing the fire button and the up button simultaneously, then enter
the following into the TCR menu:
1. Press the up or down button to choose among TCR M1, M2 and M3;
2. Press the fire button to confirm the mode you have chosen;
3. Press the up or down button to increase or decrease the parameter according to the TCR of the coil;
4. Keep pressing the fire button or leave the interface for approximately 10 seconds to confirm.
TCR value range of Beyond Vape Centurion for your reference
Note: 1. The TCR value in the sheet is 10 multiplied by the actual TCR.
2. The TCR value range for Beyond Vape Centurion is 1-1000.
Supplementary TC Modes Functions:
Wattage adjustment: In TC modes, press the fire button 4 times in quick succession to enter the menu, press the up button
to increase wattage and the down button to decrease wattage. Long pressing the up or down button will make the wattage
setting rapidly increase or decrease.
Temperature adjustment: In TC modes, the temperature can be adjusted from (100-315°C or 200-600˚F) with the up and
down buttons.
Shift between °C and ˚F: If you increase the temperature to 315 °C, and continue to press the up button, the temperature
readings will automatically change to the lowest Fahrenheit(200˚F). Equally, if the temperature is decreased below the
minimum(100 °C), the unit will change back to ˚F automatically, and the temperature will start to decrease from 600˚F.
Note:
1. In TC modes, be careful to attach new atomizers that have cooled to room temperature. If a new atomizer has not cooled
down before attaching, the temperature may read and protect incorrectly until the new atomizer cools.
2. When you connect a new atomizer or disconnect and reconnect your existing atomizer, the device will prompt you to
confirm this change and a message will prompt “new coil up same down”. Press the up button to confirm that a new atomizer
has been attached. Press the down button to confirm that the same atomizer has been reconnected.
3. When using non-TC coils or TC coils with a resistance higher than 1.5ohm in TC modes, the device will automatically
switch to VW mode.
VW Mode:
In this mode, output wattage can be adjusted from 1W to 100W with the up and down buttons.
Bypass Mode:
Bypass mode is a direct output mode of voltage. In this mode, the internal chip is “bypassed” and the supporting atomizer
resistance is 0.1-3.5ohm.
Malfunction Indication and Protection:
No Atomizer Alert: When the device does not detect an atomizer, the OLED screen will
display “No Atomizer”.
Atomizer Low Alert: When the resistance of atomizer is lower than 0.1ohm in VW/Bypass
mode or lower than 0.05ohm in TC modes, the OLED screen will display “Atomizer Low”.
Atomizer Short-circuit Protection: When an atomizer short-circuit occurs, the OLED
Screen will display “Atomizer Short”.
Temperature Alert: If the internal temperature of the device is over 70°C(or 158˚F) , the output
will shut off automatically and the screen will display “Device too hot”.
Temperature Protection: In TC modes, if the actual temperature of coil reaches the set
temperature, the device shows “Temp Protection”.
Weak Battery Alert: In TC/VW/Bypass mode, when the device installed with an atomizer is
working and the voltage of battery is below 2.9V, the device shows “Weak Battery”. Meanwhile,
the output power will be reduced accordingly.

Designed by Beyondvape in USA
Manufactured by WISMEC in China
