BGS 9190
Multi-Function Jump Starter
TECHNICAL DATA
Battery capacity: 10,800 mAh (37 W/h)
Start current: 200A max. 400A (3s)
USB output (1): 5V / 0.1 bis 3A
USB output (2): 5V / 0.1 bis 3A
Notebook output: 12V / 16V / 19V
Battery cell (internal): 3,7V
Automatic power off: approx.15 sec..
Suitable for:
Petrol engines up to 5.0 l
Diesel engines up to 3.0 l
SAFETY ADVICE / WARNINGS
•After starting the vehicle, for safety, please remove the device ASAP.
•Use this product for short jumpstart only. Start attempts over a longer period of more than 3
seconds at a time are not allowed. Let the device cool down for minimum 10 minute after 3
seconds starting.
•For safety, please do not connect the two clamps directly when they are connected to the device
and the device is tuned on
•For safety, please do not dismantle the device.
•Please do not dismantle the device, otherwise no warranty.
•Do not use the product in bathroom or other damp places or places near the water.
•Do not remodel or dismantle the device.
•Keep the product away from the children.
•Do not reverse the connections of output or input.
•Do not throw the product into fire.
•Please don't use the charger whose charging voltage is more than the product to charge.
•The temperature should be kept between 0°C to 40°C when the device is being charged.
•Do not hit or throw the product.
•If there is problem with charging, please contact your dealer.
•Keep the product away from the flammable objects (bed or carpet)
•If the product is heating and discolouring, please stop using, as it may lead to liquid, smoke and
burn.
•After long term storage or not in use, please ensure that devices will be charged and discharged
in every three months.
ENVIRONMENTAL PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories
and packaging should be sorted, taken to a recycling centre and disposed of in a manner
which is compatible with the environment.
DISPOSAL
Do not dispose battery in household waste.
Batteries should be disposed of in a responsible manner, they must be disposed at
appropriate collection point. Dispose of this product at the end of its working life in
compliance with the EU Directive on Waste Electrical and Electronic Equipment. Contact
your local solid waste authority for recycling information or give the product for disposal
to BGS technic or to the dealer where you purchased the product.

BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[e-mail]
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
Connectios / Display / Led
1. Power display of car jump starter
2. Output current of dual USB
3. Output voltage: 12V, 16V or 19V
4. Output current of charging laptop
5V output ports
LED flashlight
LCD screen
19V/16V/12V intelligent output port
Switch
12V / 15V input port of charge
2
1
3
4
12V jump start output port

BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[e-mail]
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
LED EMERGENCY LIGHT
1. Short press the switch and start the device.
2. Press the switch for 3 seconds. The LED light system starts at a continous lighting state.
3. Short Press the switch once again. The light gives out SOS signal.
4. Short Press the switch one more time. The flash light is turned on.
5. Short Press the switch another time. The light and device is turned off.
INDICATOR LIGHT INSTRUCTION
Press the on-off key to check the power status; The data displayed is the percentage of the actual
power on screen.
CHARGING OF THE DEVICE
1. lnserting the matched adapter into socket.
2. lnserting the adapter into 12V/15V input port of the devices.
or
1. Inserting the one end of car charger into the jack of cigar
lighter.
2. Inserting the other end of car charger into the devices.
STARTING 12V VEHICLE
1.
Make sure the power status is no less than 50%
2.
Clamp positive pole of the battery with Red clip
and negative pole of the battery with Black clip.
3.
lnsert the devices connector into the 12V START terminal
on the product.
4. Turn the key to 'ON' and start the vehicle.
Attention:Do not carry out long attempts to start.
Do not start the engine for a longer period than 3 seconds
and let the device cool down for minimum 10 minute after
starting. Otherwise the device or its wiring may be
damaged.
5.
Once the vehicle has started, remove the end of the clamps
from the device immediately.
Pressing this button for 3 second can
turn on the LED lighting system
Battery power status

BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[e-mail]
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
CHARGING OF 5V USB DEVISES
1. Choosing suitable and intelligent charge connector.
Then inserting the USB connector into 5V USB output port.
2.
Connecting the charge connetor with intelligent equipment,
such as tablets, smartphone, bluetooth and so on.
3.
Automatic idetification charge smartphone automatically,
tablets and other's electronic product.
CHARGING OF 12V/16V/19V LAPTOP
1. Selecting suitable charge connector of computer and connect it.
2.
Pressing the switch lightly and start the power source.
3.
Pressing the switch again to change different Volt.
The relevant LED flashing will be blink.
The voltage will be auto locked automatically after three seconds.
Different computer have different voltage in the market.
Please make sure the computer's volt that you used.
4.
Connecting the computer's connector with power source in 15
seconds, the computer can be charged.
5.
lf you need to reselect the Volt, please turn off the computer and
power source.
After 15 seconds, when the power source auto-off, starting it from
the first step again. Take charging for 19V laptop as an example.
TROUBLE SHOOTING
If the following operations are unable to troubleshoot, please stop using the jump starter and contact
with the stores which you bought the jump starter from.
Trouble
Cause
Solution
The power capacity of the device
is shown in 100%, but did not fully
charged in charging process.
When the screen shows 100%
charged and this situation
means it is semi-state of
charge, which is conducive to
long-term storage when the
device is not in use for long
time.
Pull out the charge plug,
then reinsert.
Nothing happens when pressing
the switch button.
Low voltage protection of the
device is started and the device
cannot be turned on.
Insert the charger plug into
the input port to activate.
Switch the volt

BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[e-mail]
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
FREQUENTLY ASKED QUESTIONS (FAQ)
1
Q:
How to turn off the device?
A:
This device has function of intelligent detection, in the case of no load or the charging
completed, it will power off automatically, which could prevent power loss and make
service life longer:
2
Q:
How long does it take to charge this device fully?
A:
It takes 3-5 hours to fully charge the device using the 12V/1A or 15V/1A charger our
company equipped.
3
Q:
How long can this device charging for the mobile phone?
A:
By adopting the intelligent IC management system, intelligent detection charging
environment and intelligent matching the most secure current of the digital devices for
the intelligent charging, and the maximum current can reach 3A, it takes about 1-2 hours
to fully charge the phone.
5
Q:
How many times can the device start the vehicles if the power capacity is 100 %?
A:
Depending on different displacement and car motor, the device can intermittently
continuous start the car under 3.0 displacement for over 30 times.
6
Q:
How to maintain the device when not in use?
A:
The recommended temperature setting is 0°C-40°C, please keep the device far from
liquid, open fire or heating objects, do not storage the device in a damp place. The
storage age is 3-6 months, while please charge the product every 3 month, to prolong
the service life.
7
Q:
If the product is not being used after fully charge, how long can be stored to start the car?
A:
If the products are not being used in 3-6 months, and product of more than 50% of the
electricity there, you can normally start the car, if there is 10 % electricity left, you can
use them for charging the digital products.
8
Q:
If the device can not start the car, how to solve it?
A1:
Please check the power capacity of the device on screen and make sure the power is no
less than 50% (50% capacity) which can start the vehicles.
A2:
Please check the clamps tightly or not and make sure the positive and negative is not
wrongly. The right way is that Red with red and Black with black after holding tightly
which is the positive clamp and negative clamp of the device respectively connected with
the positive clamp and negative clamp of the vehicles, and connect the EC5 connector
with the device, twist-off the car keys to start the car one time. If the startup failed, please
wait a few seconds before the re-start operations. If the start-up is successful, please
quickly disconnect the clamps from the vehicle's battery to the device, then please
remove the clamps from the vehicle's battery.
ACCESSORIES LIST
1x
Main device
1x
Car charging cabel
1x
Battery clamps
1x
Charging device:
1x
USB charging cable
Input: 110-240V
1x
Laptop charging cable
Output: 15V / 1A
8x
Adaptersteker für Laptop-Ladekabel

SW-Stahl und Werkzeugvertriebs GmbH Tel. [phone] / 46438-0
F56essartSresukreveL ax +49 (0) 2191 / 46438-40
ed.lhatsws@ofni:liaM-EdiehcsmeR79824-D
CE-Erklärung
BGS technic KG
Bandwirkerstr. 3
42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[email protected]
www.bgstechnic.com
EU-KONFORMITÄTSERKLÄRUNG
EC DECLARATION OF CONFORMITY
DÉCLARATION„CE“ DE CONFORMITE
DECLARATION DE CONFORMIDAD UE
Wir erklären in alleiniger Verantwortung, dass die Bauart des Produktes:
We declare that the following designated product:
Nous déclarons sous propre responsabilité que ce produit:
Declaramos bajo nuestra sola responsabilidad que este producto:
folgenden einschlägigen Bestimmungen entspricht:
complies with the requirements of the:
est en conformité avec les réglementations ci-dessous:
esta conforme a las normas:
Angewandte Normen:

Norme appliquée:
Normas aplicadas:
ppa.
Frank Schottke, Prokurist
BGS technic KG, Bandwirkerstrasse 3, D-42929 Wermelskirchen
Wermelskirchen, den
Multifunktions-Starthilfegerät (Art. 9190)
Multi-Function Jump Starter
Mini Booster de démarrage
Arrancador de batería
EMC Directive 2014/30/EU
EN 55022:2010+AC:2011
EN 55024:2010
EN 61000-3-2:2006+A1:2009+A2:2009
EN 61000-3-3:2013
Certificate No.: 0O160819.ATTT07 / A3+S
Test Report No.: DEU(16)-08-H10013E
23.12.2016
