A - INTRODUCTION
INTRODUCTION
This handbook must be considered as part of the machine. The seller
of new and second-hand machines must record in the selling document
that this booklet has been given along with the machine.
PICTURES USED IN THE HANDBOOK
Before starting use this machine, it is necessary to read carefully
this hand-book, learn and observe all the safety rules indicated with the
following symbols.
DANGER This symbol is used to highlight an important safety information.
If this information is ignored, people are in danger either of
possible injures - even serious ones - or death.
In these messages are also described the normal precautions
which have to be taken to avoid the danger.
Ignoring these precautions can cause serious damages to the
machine.
ATTENTION This warning is used in the handbook safety messages when the
danger can cause minor or moderate damages and injuries.
The message can be used also for dangers which can cause
damages to the machine or its components.
IMPORTANT It is used for precautions which have to be taken to avoid
operations which can shorten the life of the machine or of its
component.
NOTE This word is used to highlight information which refers to
operations in progress.
Any time you see these symbols, whether on the machine or on the
following of this manual you must pay attention to avoid danger to
yourself and to other people.
Following some rules suggested by the common sense, you will avoid
any break risk and your machine will function longer and more efficiently.
A - INTRODUCTION

2
B - CONDITIONS AND LIMITS OF USE
DEFINITION OF PROPER USE
• Thismachinehavebeendesignedforgrasscuttingandweedcontrolin
agriculture and public green, flat and sloped areas.
• Theexactobservanceofuseconditions,maintenanceandreparationare
the essential element for a correct use.
• Themachineshouldbeused,maintainedandrepairedonlybypeoplewho
have knowledge of the security rules.
• Thegeneralrulesaboutaccidentpreventionandpublicroadcirculation
rules should be respected
IMPROPER USES
• Anyotheruseisnotallowed.Themanufacturerisnotresponsiblefor
damages caused by any use than the intended one. The user is fully
responsible for any possible risk.
• Eacharbitrarymodificationcarriedoutonthemachinecouldreleasethe
manufacturer from the responsibility for any damage or accident derived by
the machine.
ONLY ONE OPERATOR
The machine was designed to be used by one operator only. The presence of
other people in the closeness could be dangerous for the safety of both user
and people.
ACCESSORIES ON THE MARKET (ONLY IF AUTHORIZED)
Any use of accessories different from the authorized ones by the manufacturer
is not allowed. For further applications different from the authorized one or
in case of misunderstanding of this handbook, please contact the technical
department of the manufacturer.
BARBIERI s.r.l. - Technical department
36040 SOSSANO - (Vl) - ITALY
Tel:0444/885722-Fax:0444/885482
e-mail [email protected]
Descriptions, figures and technical features mentioned herein are non-
binding for the Manufacturer. These are mentioned as mere information.
The Manufacturer reserves the right to make any change at any time without
notice, to improve the quality of the products without being bound to update
this publication.
B - CONDITION AND PROPER USE

3
C - INDEX
MACHINE IDENTIFICATION
o Chassis number
o Type and number of the engine
o Dimensions
SECTION 1 - TECHNICAL DATA
1.1 Technical data
1.2 Noise
1.3 Vibrations
SECTION 2 - SECURITY RULES
2.1 Safety devices
2.2 Safety advices
SECTION 3 - MACHINE PREPARATION
3.1 Packaging and endowment
3.2 Preliminary tests
SECTION 4 - CONTROLS
4.1 Name of the Major Components
SECTION 5 - RULES FOR A SAFE USE
5.1 Connect the Radio Control
5.2 Engine start
5.3 Engine stop
5.4 Drive
5.5 Drive in a slope
5.6 Brakes system and Parking
5.7 PTO (Mowing blade switching ON)
5.8 Cutting height adjustment
5.9 Aux port
5.10 Controls during the use
5.11 In and out of the work field
5.12 Safety in work field
C - INDEX OF CONTENT
SECTION 6 - TROUBLESHOOTING
SECTION 7 - MAINTENANCE
Main Maintenance components
Lubrification Points
Electric scheme
7.1 Tests before using
7.1.1 Control of the engine oil
7.1.2 Engine's air filter
7.1.3 Refuelling
7.1.3 Control of crawler tension and conditions
7.1.4 Radio Control battery charge
7.1.5 Control Cutting blades
7.2 Maintenance and adjustments
7.2.1 Lubrication program
7.2.2 Changing of engine oil and filters
7.2.3 Control and replacement of gear box oil
7.2.4 Lubrication of the joints
7.2.5 Cleaning of the air filter
7.2.6 Tension adjustement of the PTO belt.
7.2.7 Sharpening and replacement of the blade
7.2.8 Replacement of the Crawler
7.2.9 Battery of the Radio-Control
7.3 Notice for disposal
SECTION 8 - COMPLAINTS AND WARRANTY
SECTION 9 - CERTIFICATE OF CONFORMITY

Tiller B70
4
D - IDENTIFICATION NUMBER
In case of a trouble, when You contact Your dealer for a reparation or to ask
for spare parts, it is necessary to identify the machine with the following data:
• Modelandchassisnumber
• Enginetypeandnumber
MODELANDCHASSISNUMBER
ENGINETYPEANDNUMBER(KawasakiENGINE)
DIMENSIONS(mm)
D - IDENTIFICATION NUMBERS
G
1254 1314
760
150
Fig 1
Fig 2
Fig 3

I. SAFETY
5
SECTION 1 - TECHNICAL DATA
1.1 Technical data
ENGINE GENERATOR
Make KAWASAKI Generator 1 Phases 68VAC - 80A
Model FS481V Generator 2 Monophase 17VAC - 10A
Engine type Air cooled 4S OHV petrol vert.
Forced lubrication
Net Power 9.9 kW (13.2 CV) / 3 600 rpm CUTTING DEVICE
Max. Torque 38.4 Nm / @ 1 800 rpm Type Mulcher back discharge
Displacement 603 (2 cylindres) cm3Blade type 2 floating Multy-cut - 2600 rpm
Bore x stroke 73 x 72 mm Cutting Width 80 cm
Ignition system Transistorised Height Adjust. 30 ÷ 150 mm stepless electric
Starting system Electric START Transmission By belt with EM Clutch (Ogura)
Air Filter Paper + Foam cartridge
Fuel tank capacity 10 Lt RADIO-CONTROL 2,4 GHz
Fuel cons. @ rat power 2.5 L/hr - 3 000 rpm Transm. technology AFA (Aut. Freq. Adjustment)
Engine oil capacity 2 Lt Controls Optic - contactless
Radio transm. distance 200 m
Regulations compl. Dir R&TTE 1999/5/CE
2006/42/CE
PLe category 4 /SIL 3
ISO 13849-1:2008 / EN62061:2005”
Weight 1,3 Kg
TRANSMISSION DIMENSIONS
Type Hybrid-Electric motors 48V
with reduction gear Overall dimensions 119 x 117 x 68
Contrôle Stepless electric - speed control Weight 368 Kg
Gamme de Vitesse 0÷ 8 Km/h Soil pressure 115 g/cm²
Pente max. 35°Uphill - Longitudinal 45° Crawler contact area (17,5x80x2) = 2800 cm²
Inclin. / h p. de gravité 65° / 15cm
Type de Moteur Brushless Perm. Magnetes
Système d'alimentation 3 Phases
Puissance du moteur 1 kW
Système de contrôle BHV - 48V 60A
1 - TECHNICAL DATA

Tiller B70
6
SECTION 1 - TECHNICAL DATA
1.2 Noise
The noise level was obtained during the equipment in action, in neutral
position and the results are the following:
Kawasaki Engine FS481V (4 courses) with original muffler.....
- Acoustic pressure level (LpAm) .......... 87,0 dB(A)
- Acoustic power level (LwA) ..........107,0 dB(A)
1.3 Vibrations
The vibrations level was obtained with the machine at work at 3060 rpm (85%
of the nominal condition of 3600 rpm) and the results are the following:
- Not applicable
LABELS AND WARNINGS POSITION
Fig 4

I. SAFETY
7
SECTION 2 - SAFETY NORMS
2 - SAFETY NORMS
Fig 5
Front
Back Left
Right
2.1 SECURITY DEVICES
Theterms“FRONT”-“REAR”-“RIGHT”-“LEFT”usedinthishandbookand
in the spare parts catalogue, are referred to the machine as shown in Fig. 5
SAFETYDEVICES
The machine is equipped with a series of safety devices to comply with the
Machinery Directive.
More precisely the following devices are provided :
1-engineSTOPdevice(B)(fig.5)
2-engineSTOPontheremotecontrol(A)(fig.5).
3-engineSTOPonstartingkey(C)(fig5)
4- Automatic brake system in case of engine stop
5- Front and rear shield to stop the object throwed by the blade
6- Automatic switching OFF of the blade in case of engine stop
7- Automatic engine stop in case of loosing of radio control
8- Transmission belt cover
The most important warning labels are placed near to the danger around the
machine. Be sure to understand the meaning of the lables in order to use a
proper behavior to avoid any danger operation.
These labels are very important for the safe use of the machine along the
time.Keeptheselablecleanandinagoodcondition.Incaseofdamageor
lack of such a lables it is mandatory to replace them with original ones.
EngineSTOP
A
B
C
Belt
cover

8
SECTION 2 - SAFETY NORMS
CAUTION LABEL AND WARNINGS
BesidesCEmark,safetypicturesandindicationsareappliedonthemachine
and mentioned in the fig. 4.
WARNING: BEFORE SERVICING
Read the technical instructions in the operation
manual before servicing the machine.
WARNING: RISK OF INJURY
Stay away of the discharge opening of the mower deck
because stones or other hard objects ejected from
the mower may hit you
Use visor to protect from flying object
WARNING: RISK OF ENTANGLEMENT
Stay clear of the belt while it is running
DANGER FOR HAND AND FEET:
Cutting blade: Keep hands and feet away.
WARNING:
Radiocontrolledmachine.
Keepawayifengineisrunning
WARNING:
Danger of hand crushing
WARNING:
Exhaustgasesarepoisonous!
Never start the engine in not ventilated room
WARNING:
Petrolgasesareexplosive.
Do not refueling with free flames, sparks
or while smoking
ATTENTION:
Do not work in slopes over the limits
Stability and engine lubrication can be lost

I. SAFETY
9
SECTION 2 - SAFETY NORMS
1) Beforestartingtheengine,besurethattheSAFETYDEVICESarewell
working and fitting. Without these cares the operator might work in a
danger situation.
2) This machine has been designed and manufactured for being used by one
operatoronlywhoholdtheRadiocontrol.Anyotheruseisnotpermitted!
3) It is important to ensure a safe distance between the operator and the
machine in the operating area (see cap.5.12)
4) Beforethemachineisoperating,readtheUseandMaintenancemanual
thoroughly, so that you are fully aware of all the operating controls and
safety aspects of the machine.
5) No modification to the machine or use of not genuine spare parts can
bedonewithouttheManufacturerconsent.Thispraxiscanleadtovery
dangerous and unpredictable situation and will anyway nullify the warranty.
6) Do not under any circumstances transport people or objects on the
machine.
7) Before using, check that all the controls are in good working order.
8) Move the controls gradually; sudden engagement could cause the loose of
stability of the machine.
9) Checkanytimethatallpartsallwellfixed
10) Thismachinehavenottobeusedbychildrenorinexperiencedpersons.
Operators that are not duly trained of people that are under effect of
alcohol or other substances.
11) Before operating the machine, check that the area is clear and free of
debris and that there are no people within the working area (danger zone).
The operator, will be held responsible for the safety of third parties, if these
are found within the working area of the machine. Do not use the machine
under these conditions.
12) Do not use the machine when you are tired
13) Keep awayfromcuttingbladesatalltimeswhilethemachineisin
operation.

Tiller B70
10
SECTION 2 - SAFETY NORMS
14) Useonlygenuinesparepartsandaccessoriestoguaranteethesecurity
and functioning of the machine.
15) Stop engine before refuelling
16) Handlethefuelwithcaretoavoidspillingonthemachine;cleanany
spillage immediately.
17) Avoid overfilling the fuel tank
18) Planwellyourworkbeforestarting
20) Theareanexttotheengineexhaustwillmostlikelyreachtemperatures
above 80°.
ATTENTION! Danger of scalding.
21) Keeptheareaofworkclearandclean.
22) Only use the machine in clear visibility.
23) If you hit any objects during work, stop the machine and check for any
damage immediately.
24) It is advisable to keep a first aid kit
25) The speed of the machine must be convenient to the environment
conditions
26) Never do maintenance or cleaning works when the engine running.
27) When possible, avoid working up or down hill .Always travel across the
slope.
28) Donotworkonverysteepslopes(max.70%).
29) During use, keep the hot sections of the engine (i.e. cylinder head,
exhaust,etc.)cleantoavoidabuildupofdebristhatwilloverheatthe
engine.
30) Whenever possible, stop the machine on level ground.

I. SAFETY
11
SECTION 2 - SAFETY NORMS
31) Park themachinewherechildrenorunablepeoplecan'treachit:stop
the machine and remove the Start key from the dashboard.
32) Donotleavethemachinewiththeenginerunning.Reachaflatground
and stop the engine.
33) Follow carefully the maintenance instructions and replace always the
worn parts if necessary.
34) Storage the machine after cleaning it, only.
35) If any, it is necessary to take heed of the specific safety norms in force in
theCountrywherethemachineisoperating.
36) Never refuel in confined places, in vicinity of open flames or near the
sourceofsparks.Nosmokingduringfuelhandling!
37) Neverstarttheengineinaclosedplace.Exhaustfumescontain
poisonouscarbonmonoxide,sosufficientventilationshouldbeprovided
when starting the engine indoors.
38) After storage of the machine for a long period, make a deep cleaning and
lubricate the machine according to the lubrication program.

12
SECTION 3 - MACHINE PREPARATION
3 - MACHINE PREPARATION
3.1 Packaging and endowment
The machine is supply with:
1 x Basic Unit X-Rot
1 x Radio Control
2 x Lithium battery for Radio control
1 x Battery charger
1 x Radio control’s hanging belt
1 x User Manual
1 x Engine user manual
1 x Rod (to replace the crawler)
Before to use the machine, check the fuel and engine’s oil level and read
carefully the instruction manual about the safety regulation and the proce-
dures to start and control the machine.
3.2 PRELIMINARY TESTS
Before using the machine for the first time, it is necessary to do the following
checks:
• Engineoillevel(seeCap.7.1.1)
• Fuellevelinthetank(seeCap.7.1.3)
• BatterychargeontheRadioreceiver(seeCap.7.1.5)
- The engine oil should be always on the mark of the upper level. Lack of
oil will decrease the engine performance on the slope.
- The fuel level should be near to the max but not reaching the collar of the
tank. In case of slope the fuel can spill out and create a danger of fire.
- The 2 battery set have to be charged before to start any work. One battery
should be enough for one day operation but the 2nd one should be available
in case of need.
Fig6

I. SAFETY
13
SECTION 4 - COMPONENTS AND CONTROLS
4 - COMPONENTS AND CONTROLS
4.1 NAME OF MAJOR COMPONENTS (fig.7)
G
I
M
L
N
F
E
D
C
BA
O
Q
P
H
H1
Basic Unit: Identification of the main components.
A) Tensor wheels G) Antenna N) Air filter
B) Crawler’s roller H) Battery case O) Belt case
C) Drive wheel H1) Start key P) Mower deck
D) Crawler Belt I) Engine - air inlet Q) Remote control
E) Drive motors L) Emergency switch R) Blade support
F) Electric cabin M) Fuel Tank S) Blade
Fig7
S
R

Tiller B70
14
SECTION 4 - COMPONENTS AND CONTROLS
4.2 ENGINE (fig.7-i)
The machine is equipped by a high quality petrol engine made in Japan and
designed to grant a long operating life. The engine is provided by an electric
start.TostarttheenginefollowtheprocedureofCap.5.2.
The engine is also provided by a forced lubrication system which help to work
inaslopingareas,neverthelessitishighlyrecommendnottoexceedthe35°.
The instruction of the max. angle are reported on the bottom of the radio con-
trol.
IMPORTANT
Do not leave the machine in the slope with the engine running. The
lubrication can be insufficient and cause the engine failure.
ATTENTION
Never stop the engine while the machine is on the slope. The engine
stop will cause the switching off of the drive motors and the lose of the
machine control.
 Thefirst50workinghoursrepresenttherun-inoftheengine.Duringthis
first period we recommend not to use the machine at the full power.
It is also necessary to leave the engine running for few minutes at the idle
speed for warming after starting. A sudden use at the max power just after
starting cause a thermal shock to the engine components.
4.2.1 AIR FILTER(Fig.7-n)
The engine is equipped by an air filter. In case of dry grass and dusty environ-
menttheairfilterhavetobecleanedveryoften(every2hours).Ifsomeflying
grassaretrappedbythenetoftherecoilstarter(Fig.7-i)itmeansthatprob-
ablyalsotheairfilterneedtobecleanedout.(seecap.7.1.2).Theclogging
of the air filter can cause a lose of engine power. In normal condition, the air
filter should be cleaned every day.
4.2.2 FUEL TANK(Fig.7-m)
Thefueltankhaveacapacityof10litreofpetrolandshouldassure4hoursof
operation. Before to start any work remind to fill up the fuel tank. A reserve of
fuelof3litres(markedbyapilotlightontheradiocontrol)warnthatitistime
to refuel. stop working and move the machine in a flat hard soil for fill it up.

I. SAFETY
15
SECTION 4 - COMPONENTS AND CONTROLS
DANGER
The engine stop can be dangerous in case of slope. the stop of the engine
cause the loosing of control of the electric motors. In case of slope the
machine could start to move downhill.
DANGER
Pay attention while refuelling: The gas of petrol are highly explosive. Do not
attempt to refuel if somebody are smoking or in presence of sparks or open
flames.
4.3 MOWER DECK (fig.7-p)
The mower deck has a special design to reduce the power required. It is con-
necteddirectlytotheenginebybeltanddisconnectedbyanEMclutch.
The engagement of the Mower can be done if the engine is at a suitable
speed.(seeCap.5.7).Thebladesystemdependfromthetypeofwork:multi-
cut for a perfect mulching result and a stronger blade for heavy duty opera-
4 - CONTROLES
Fig9
Boîte à fusible
Récepteur
tions. The cutting height can be adjust from
the remote control and it is visible from an
indicator on the right hand side of the ma-
chine(seeFig.8).FormaintenanceofEM
Clutch,BladesandtransmissionBeltplease
refertoCap.7.2.7.
4.4 ELECTRIC SYSTEM
The driving system of this mower is electric.
The alternator driven by the petrol engine
generates an electricity supply voltage of
48Vinarange(Extra-lowvoltage- ELV)
which carries a no risk of electrical shock.
The crawler are then driven by 2 brushless
electric motors controlled electronically by 2
inverter which follow a sophisticate software
that makes the machine easy to use and
flexible.
The electric cabinet on the back of the ma-
chine have a easy access to the radio re-
ceiverandtothefuseandrelaysboxes(Fig
9).Theelectricsystemhasawaterproof
grade of IP 54.
Fig8

Tiller B70
16
SECTION 4 - COMPONENTS AND CONTROLS
4.5 TRANSMISSION
The transmission of the power to the crawler are made by 2 strong and si-
lent gear reductors. The portal shape of the transmission allows to keep very
lowthecentreofgravityofthemachinewhichis15cmofftheground,only.
The technology of these electric motors grants the maximal torque also at a
standstill. These 2 features make this machine suitable to work in very sloped
ground. Moreover in case of electric power failure, a passive breakage device
save the machine from running downhill without any control.
4.6 REMOTE CONTROL
The remote control is a heavy duty and reliable unit which allow to carry out
all the controls and the adjustment of the machine. It works on a frequency of
2,4GHzwiththeTransmissiontechnologyAFA(AutomaticFrequencyAdjust-
ment)thatautomaticallyshifttoanewfreechannelincaseofdisturbsonthe
transmission.
CONTROLS OF THE RADIO TRANSMITTER
1
2
3
5
4
6
87
9
10
1 Radio connection button 6 Drive control Forw./Rev. - Left/Right
2 Engine Start button (with (1)) 7 Aux actuator adjustment lever
3 Engine's throttle 8 Drive reference inverter switch
4 PTO Switch button 9 Alarm switch (motorstop)
5 Cutting hight adjustment lever 10 Aux socket switch
Fig10

I. SAFETY
17
SECTION 4 - COMPONENTS AND CONTROLS
NOTE

Tiller B70
18
SECTION 5 - HOW TO USE THE MACHINE
5 - RULES FOR A SAFE USE
1700
2200
2700
3200
rpm
rpm
rpm
rpm
Fig11
AB
C
D
E
F
5.1 CONNECTING THE RADIO CONTROL
TurntheStartingKeyswitchtoONposition.Thebuzzerwill
starttosoundtowarnthattheRadiocontrolisnotconnected.
ToconnecttheRadioControlpressoncetheGreenButton1
(Fig.10)onthelefthandsideoftheremotecontrolandwait
untilthe2warninglampsgreen(a)andblu(b)starttoblink;
thanpushagainthegreenbutton1(Fig.10)andkeepitpressed1secondand
releaseit.ThewarninglampswillstopblinkingandtheBuzzerstoptosound.
The radio control is now linked .
5.2 ENGINE START(fig.10-11)
Movethethrottleleverup(Fig10(c))up
to the maximum. To start the engine at low
temperature, pull the starter at the left hand
side(Fig11.b).Pushthebutton2 andthan
the 1 (Fig.10(2)and(1))untiltheengine
starts.
Move the throttle lever down up to reach the
idle speed and leave the engine warming up.
Now the engine speed can be adjusted and
the value is shown from the warning light
column(Fig11(E)).

I. SAFETY
19
SECTION 5 - COMMENT UTILISER LA MACHINE
5.3 ENGINE STOP(fig.11)
To stop the engine push anytime
theRedAlarmButton(Fig11(F))
and the engine will suddenly stop.
Just after stop, remind to release
the emergency Button in its normal
position. The engine can be turned
OFFalsobyAlarmButtononthetop
ofthemachine(Fig.7(L)),turningthe
StarKey(Fig7(H1))OFForifthe
machinelosetheRadioconnectionwiththeremoteControl.
NOTE: If possible it is always recommended to move the machine in a flat
ground before to stop the engine. In case of emergency STOP as soon as
possible start the engine and move the machine in suitable flat ground for
parking.
5.4 HOW TO DRIVE (fig.12)
Checkthatthelever(H)issetU P. 
Thisleverreversethemotion.Move(A)theJoystick(G)FORWARD
gradually and continuously. The machine will move ahead. The machine can
be controlled easely by one finger which control the speed and the direction.
The speed is also controlled by the displacement of the Joystick lever.
Fig12
H
G
F
R
A-A A-B
DX
R
JOYSTICK
(h)
(h)
Fig13
Fig14
5.5 HOW TO DRIVE IN A SLOPE
In a slope it is recommend to drive in
alongitudinalwayand(ifpossible)
with the left hand side downhill.
To work on the slope area it is not
necessary to change direction
because the machine can work in
both direction. So the suggested path is A-B as represent in the
Fig13.
In case it is necessary to work
according to A-A path, it is provide
a"REVERSINGSWITCH"Fig12(H)
which make easier to drive as the
machine will follow the Joystick
direction.(seeFig14thedrive
direction with the 2 positions of the
switch(H)).
5.6 BRAKE SYSTEM AND PARKING
The machine is supplied with an
automatic e-motor brakes which stop
the machine while not driving. This
brake system works if the engine
runs and all the control systems
areworking.Forthisreason,ifyou
