HUSTLER FasTrak Super Duty 48 User manual

Starter 12-volt (.8 kw) (see engine manufacturer specs)
Ignition Electronic
Charging System 12-volt, 15-amp (see engine manufacturer specs)
Fuel Unleaded gasoline (see engine manufacturer specs)
Fuel Filter Replaceable, automotive-type
Air Cleaner Heavy-duty, remote mounted
Cooling Air cooled. Fly-wheel fan
Governor Mechanical
Traction Drive System
Type Dual hydrostatic. Commercial-duty Hydro-Gear ZT 2800. ZT transmis-
sions feature relief valve, charge pump, spin-on oil filter, expansion tank, and
steel cut gears. Hydraulic system operates on 20W50 motor oil.
Hydrostatic Drive V-belt drive from engine crankshaft
Ground Speed Infinitely variable: 0-8 mph (0-12.9 kph) forward, 0-5 mph
(0-8 kph) reverse
Steering Twin-lever SmoothTrak™ steering provides independent control of
each drive wheel. Speed, forward, reverse, brake, and turns are all controlled
with hand-operated controls
Turning Radius True zero turning radius. Turns within its own length.
Counter-rotating, independent drive wheels
Brakes
Service: Hydrostatic dynamic braking
Parking: Internal transmission mechanical brake. When steering levers are
placed in neutral position, integral park brakes are automatically engaged
Mower Drive Single V-belt drive from engine with electric clutch. Spring
tension idler for extended belt life
Tires
Front: 13 x 5 – 6, rib tread
Drive: 48 in: 20 x 10 – 10, turf tread
54 in: 20 x 12 – 10, turf tread
Capacities Fuel System: 10 US gal (37.85 l)
Dimensions
Height: 41.8 in (106.17 cm)
W/48 in Deck
Length: 74.42 in (189.02 cm)
Overall width: 51.77 in (131.50 cm) w/discharge chute up
Tire-to-tire width: 47 in (119.38 cm)
Weight: 835 lbs (378 kg)
W/54 in Deck
Length: 74.42 in (189.02 cm)
Overall width: 61.30 in (155.70 cm) w/discharge chute up
Tire-to-tire width: 51 in (129.54 cm)
Weight: 860 lbs (390 kg)
601449 1-08
Hustler Turf Equipment • Hesston, Kansas 67062 • 1-800-395-4757
For more information : www.hustlerturf.com
W/60 in Deck
Length: 75.92 in (193 cm)
Overall width: 66 in (168 cm) w/discharge chute up
Tire-to-tire width: 51 in (129.54 cm)
Weight: 885 lbs (401 kg)
Safety Features Operator presence system connected to deck and drive
clutches. Stabilizer rollers at rear of tractor
Seat Molded, cool-grey vinyl seat with adjustable armrests. Fore and aft slid-
ing adjustment. Seat-pan suspension springs standard.
Construction Mainframe is 1.5 in x 1.5 in x .188 in (3.8 cm x 3.8 cm x .48
cm) square steel tubing. Front caster wheels mounted with roller bearings
on each wheel Front caster forks are .375 in (.95 cm) steel
Deck Lift Foot-operated deck height adjustment. Pin for setting height,
detent for transport position
Controls Hand-operated choke, throttle, ignition switch, electric mower
clutch. Integrated parking brakes
Indicators Engine warning light (low oil pressure)
Cup Holder Two cup holders molded into the left side fuel tank.
Accommodates nearly any cup size.
Decks 48”, 54” or 60” Side-Discharge Decks
Type Free-floating mower using three blades with center blade to the front.
Mower is suspended at the corners. Includes 4 deck-mounted rollers
to improve flotation in rolling and uneven terrain
Deck Lift Raise and lower deck from driver’s seat with simple foot-operated
deck height adjustment. Pin for setting height, transport position. Change
cutting heights, hop curbs and trailer more easily
Construction .125 in (.317 cm) welded steel. Solid 1 in x .375 (2.55 cm x .95
cm) steel bars reinforce impact areas on trim edges. Commercial-style box-
section reinforced front edge. Reinforcements welded onto spindle mount
areas. Molded rubber discharge chute.
Cutting Heights Foot-operated deck height adjustment. Pin for setting
height, detent for transport position. Height adjustment in .25 in increments
from 1.5 in to 4.5 in (3.81 cm to 11.43 cm)
Mowing Blades Heavy-duty, heat-treated, high-lift Fusion™ blades
48 in: 16.5 in x 2.5 in x .20 in
54 in: 18.5 in x 2.5 in x .20 in
Blade Tip Speed
48 in: 18,306 fpm (at 3500 RPM engine speed)
54 in: 18,464 fpm
60 in: 18,331 fpm
Blade Drive V-belt drive to all three spindles. Spring tension idler pulleys-
Spindles Aluminum casting with steel shafts and sealed ball bearings
Flotation Suspended mower floats on four spring-assisted chains. 4 anti-
scalp wheels are standard
Width of Cut
48 in: 47.1 in (120 cm)
54 in: 53.1 in (135 cm)
60 in: 59.1 in (150 cm)
Trim Capacity (left side)
48 in: 0.5 in (1.25 cm)
54 in: 2.5 in (6.5cm)
60 in: 5.9 in (15 cm)
Accessories
Flex Forks™ Shock-absorbing front caster forks for a smooth ride and
smoother cut
Mulch Kit Recycles clippings under deck allowing clippings to be cut and
recut, then discharged down into the grass. Reduces handling of clip-
pings, improves appearance, and recycles nutrients back to the soil
Catcher Commercial-duty, 6.5 bushel, rear-mounted, two-bag catcher
ROPS Certified, 2-post, foldable ROPS
Stripe Kit Make your lawn look like Yankee stadium
Personalized Bumper Have your name laser-cut into the rear bumper of
your mower. Ask your dealer for details.
Snow Blower 48”, two-stage blower utilizes the deck-lift to raise and
lower. The blower is powered by deck belt and features a rotating chute
adjustable from the seat and a heavy-duty gear box
Snow Blade 56” wide, 3-position angling, heavy-duty, reversible,
replaceable cutting edge
Gator™ Blades Patented mulching blade design
Wavy Blades Improved performance for mulching
Jack Kit Mounts to unit and can be carried onboard at all times
Other Accessories Light Kit, Tire Chains, Steering Lever Extension Kit,
Weight/Utility Box
Specifications subject to change without notice.
FasTrak™Super Duty 48/54/60 Specifications
Engine
Model 23/48 25/54 25/60
Make Kawasaki Kawasaki Kawasaki
Horsepower 23 25 25
No. of Cylinders 2 2 2
Max. Torque 39.8 ft lbs @ 2400 rpm 41.2 ft lbs @ 2400 rpm 41.2 ft lbs @ 2400 rpm
Hustler Turf Equipment FasTrak™ Super Duty 48/54/60
(Mower shown with optional ROPS)
