Biasi Riva Plus Installation instructions

BOILER INSTALLATION, OPERATION
INSTRUCTIONS
WALL HUNG GAS BOILER FOR
CENTRAL HEATING SUPPLY
Please Read Instructions Carefully
Save for Future Reference
Do not store or use gasoline or other flammable vapors and liquids— in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS— Do not try to light any appliance.• Do not touch any electric switch; do not use any phone in your• building.
Immediately call your gas supplier from a neighbor’s phone. Fol-• low the gas supplier’s instructions.
If you can not reach your gas supplier call the fire department.•
Installation and service must be performed by a qualified installer,— service agency or the gas supplier.
WARNING: If the information in this manual is not followed
exactly, a fire or explosion may result causing property dam-
age, personal injury or loss of life.
RivaPLUS
RivaPLUS

2 RIVA PLUS MANUAL
Dear Customer:
Thank you for buying a Biasi Riva Plus Boiler System.
The Riva Plus is a high ef ciency condensing, wall mounted gas boiler which provides central
heat supply water.
We realize that it is not possible to answer all questions about the Riva boiler system in this
manual. Reading this installation manual does not make the reader an expert in all aspects
of installation and operation, and does not replace the need for a quali ed, licensed heating
contractor. We urge you to contact your installing contractor or distributor if you are in question
about any aspect of your boiler’s performance. Our main concern is that you are satis ed with
your boiler and its performance. We require that your contractor complete ef ciency tests using
instruments.
The external controls and accessories listed in this manual (excluding those supplied inside
the boiler) are intended to serve as guidelines rather than speci c recommendations. We re-
alize that other makes and models of such devices are available and can be used as suc-
cessfully as those we specify. The installing contractor is the best judge of a system’s speci c
requirements, as well as the local availability of certain makes and models of controls and
accessories. The preceding does not apply, however, to the equipment that comes with every
boiler, such as the overheat control and pressure relief valves. The installation of the spe-
cific devices supplied with every boiler is absolutely necessary to the safe operation of
the boiler and protection of the heating system.
All BIASI wall hung boilers are built in accordance with the ASME boiler and pressure vessel
code, and bear the “H” stamp. The Entire range of applications for the Riva boiler has been
tested to standard CSA 4.9 and is CSA compliant.
This Riva Plus boiler has a 2 year warranty, a copy of which is provided with the boiler. Please
be sure to return the warranty registration card as the warranty will be void without your boiler’s
serial numbers (located on the ratings label af xed to the boiler), date of installation and the
name of your installer being on record in our les.
Thank you for purchasing our Riva Plus boiler. If you have questions or comments, please
don’t hesitate to contact us immediately. Our goal is 100% customer satisfaction.
QHT inc.

RIVA PLUS MANUAL 3
Table of Contents
Section Title Section Number Page Number
Warnings - 5-6
Important Information - 7
General Information 1 8
Technical Information (M135.30CR) 2 8-9
Parts List 3 10
Internal Piping and Parts List 4 11
Electric Diagrams 5 12-13
Sequence of Operation 5.1 13
Installation Location 6 14
Exhaust Pipe Location 7 15
Mounting Bracket 8 16
Venting 9 17-19
Restrictor Sizing 9.1 18
Fitting the Flue System 9.2 18
Choice of Flue 9.3 19-24
Pipe Connections 10 25
Gas Pipe Connections 11 26
Electrical Connections/Wiring 12 27-29
Power Connection 12.1 27
Connection to the Electricity Supply 12.2 27
Room Thermostat Connection 12.3 28
Relay Panel Control Connection 12.4 28
Zone Valve Microswitch Connection 12.5 29
Finishing 12.6 29
Circulator Sizing 13 30
Circ. Cap. as a Function of Flow Rate 13.1 30
Expansion Vessel 13.2 30
Piping 14 31-34
Primary-Secondary Piping 14.1 32
Primary-Secondary with Zone Valves 14.2 33
Manifold Piping with Zone Valves or Circ. 14.3 34

4 RIVA PLUS MANUAL
Table of Contents
Section Title Section Number Page Number
Commissioning 15 35-40
Initial Filling of the System 15.1 35
Lightning the Boiler 15.2 35
Checking the Gas Pres. at the Burner 15.3 36
Adjustment of the Gas Pressure 15.4 37
Checking the Ignition Device 15.5 37
Checking the Burner Ignition 15.6 38
Adjustment of the Useful c.h. Output 15.7 38
Labels Placement 15.8 39
Checking the Flue System and Comb 15.9 40
Instructing the User 15.10 40
Gas Conversion 16 41
Annual Maintenance 17 42-44
Warnings 17.1 42
Dismantelling the External Panels 17.2 42
Emptying the C.h. System 17.3 42
Cleaning the Primary Heat Exch. 17.4 43
Checking the Pressuris. in C.h. Vess. 17.5 43
Cleanig the Burner 17.6 43
Checking the Combustion Fan 17.7 43
Checking the Flue 17.8 43
Visual Inspection of Appliance 17.9 44
Gas Pressures and Soundness 17.10 44
Condensate trap 17.11 44
Venting Spare Parts 18 45-47
Separate Vent 18.1 45
Coaxial Vent 18.2 46
Roof Vent 18.3 47
Installer Notes 19 48

RIVA PLUS MANUAL 5
WARNING
DANGER
Boiler is certi ed as an indoor appliance. Do not install boiler outdoors or locate where it will
be exposed to freezing temperatures.
Caution: Do not store or use flammable materials, chemicals or flammable liquids,
especially gasoline, in the vicinity of this heating appliance.
Caution: Should overheating occur or the gas supply fail to shut off, do not turn
off or disconnect the electrical supply to the pump. Instead, shut off the gas
supply at a location external to the appliance.
Caution: Do not use this boiler if any part has been under water. Immediately
call a qualified service technician to inspect the boiler and to replace any part of
the control system and any gas control which has been under water.
Do not store or use gasoline or other flammable vapors and liquids in the— vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS— Do not try to light any appliance.• Do not touch any electric switch; do not use any phone in your build-• ing.
Immediately call your gas supplier from a neighbor’s phone. Follow the• gas supplier’s instructions.
If you can not reach your gas supplier call the fire department.•
Installation and service must be performed by a qualified installer, ser-— vice agency or the gas supplier.
WARNING: If the information in this manual is not followed
exactly, a fire or explosion may result causing property dam-
age, personal injury or loss of life.

6 RIVA PLUS MANUAL
WARNING
Any appliance that burns natural gas, propane gas, fuel oil, wood or coal is capable of pro-
ducing carbon monoxide (CO). Carbon Monoxide (CO) is a gas which is odorless, colorless
and tasteless but is very toxic. CO is lighter than air and thus may travel throughout the
building.
BRIEF EXPOSURE TO HIGH CONCENTRATIONS OF CO, OR
PROLONGED EXPOSURE TO LESSER AMOUNTS OF CO MAY
RESULT IN CARBON MONOXIDE POISONING. EXPOSURE CAN BE
FATAL AND EXPOSURE TO HIGH CONCENTRATIONS MAY RESULT
IN THE SUDDEN ONSET OF SYMPTOMS INCLUDING
UNCONSCIOUSNESS.
Symptoms of CO poisoning include the following:
dizziness vision problems shortness of breath
headache loss of muscle control unclear thinking
nausea weakness unconsciousness
The symptoms of CO poisoning are often confused with those of in uenza, and the highest
incidence of poisoning occurs at the onset of cold weather or during u season.
A victim may not experience any symptoms, only one symptom, or a few symptoms.
Suspect the presence of carbon monoxide if symptoms tend to disappear when you
leave your home.
The following signs may indicate the presence of carbon monoxide:
Hot gasses from appliance, venting system pipes or chimney, escaping into the living•
space.
Flames coming out around the appliance.•
Yellow colored ames in the appliance.•
Stale or smelly air.•
The presence of soot or carbon in or around the appliance.•
Very high unexplained humidity inside the building.•
If any of the symptoms of CO occur, or if any of the signs of carbon monoxide are present,
VACATE THE PREMISES IMMEDIATELY AND CONTACT A QUALIFIED HEATING SER-
VICE COMPANY OR THE GAS COMPANY OR THE FIRE DEPARTMENT.
ONLY QUALIFIED, LICENSED SERVICE CONTRACTORS SHOULD PERFORM WORK
ON YOUR BIASI RIVA PLUS BOILER.

RIVA PLUS MANUAL 7
IMPORTANT INFORMATION
Please read this page carefully.
ALL BOILERS MUST BE INSTALLED IN ACCORDANCE WITH NATIONAL,• STATE AND LOCAL PLUMBING, HEATING AND ELECTRICAL CODES
AND ORDINANCES, AS WELL AS THE REGULATIONS OF THE SERVING
ELECTRICAL, WATER AND GAS UTILITIES.
All systems should be designed by competent contractors, and only persons• knowledgeable in the layout and installation of heating systems should attempt
the installation of any boiler. It is the responsibility of the installing contractor
to see that all controls are correctly installed and operating properly when the
installation is completed.
This boiler is intended for use, only with propane or natural gas. All flammable• liquids (especially gasoline), chemicals, rags, paper, wood scraps, debris, etc.,
should be kept away from the boiler at all times. Keep the boiler area clean and
free of all fire hazards.
Please read the literature and warranties supplied by the manufacturers of the• various accessory equipment. This equipment is warranted by the respective
manufacturers, not by Quincy Hydronic Technologies, Inc. Each piece of
equipment must be installed and used according to the recommendations of
the manufacturer.
Codes and Regulations:
Installation of the boiler and related equipment must conform to national, state and
local regulating agencies and codes applicable to the installation of the equipment. In
the absence of local requirements, the following codes apply:
A. ANSI/NFPA - #70 National Electric Code
B. ANSI/NFPA - #211 Chimneys and Vents
C. ANSI/NFPA - #Z223.1 National Fuel Gas Code
C. ANSI/NFPA - Domestic Gas Conversion Burner
D. CAN/CGA - B149 Installation Codes
E. ANSI/ASME - CSD-1
The above codes are available from:
National Fire Protection Association (NFPA) CSA International
Battery March Park 8501 E. Pleasant Valley Road
Quincy, Massachusetts, 02269 Cleveland, OH 44134-5575
http://www.nfpa.org http://www.csa-international.org

8 RIVA PLUS MANUAL
General Information1.
Technical Information (M135.30CR)2.
The Riva Plus is a high ef ciency condensing, wall mounted gas boiler which provides central
heat. The boiler features a gas valve which modulates the energy input from
49476 BTU/h to 116008 BTU/h. The boiler is shipped fully assembled with the components list-
ed on page 11. All units are pressure and combustion tested at the factory prior to shipping.
Key Features:
Wall mountable - saving valuable oor•
space.
Several ue options available•
Electronic spark ignition•
Safety ow switch - positioned on the•
main circuit, which monitors the ow and
protects the main heat exchanger from
thermal shock should there be a lack of
water in the system.
Frost protection - contains an integral frost•
protection system to prevent frost dam-
age which can occur in areas susceptible
to very cold weather conditions.
Boiler operation recognition system -•
should the boiler not be used for longer
than 24 hours, it then performs a control-
led system test to ensuring the motorized
components within the boiler do not be-
come inoperable due to lack of use.
Gas valve modulation - the gas input•
modulates based off central heating tem-
perature to within ± 2 ºF
Diagnostic information system equipped•
with three LED diagnostic lights for quick
error assessment.
GENERAL
Height in 31.6
Width in 15.8
Depth in 13.8
Weight lb 98.1
CENTRAL HEATING
Maximum working temp. °F 185
Temp. Regulation range* °F 100-176
Maximum pressure psi 30.0
Minimum pressure psi 4.35
Max head loss (at 4.4 GPM) ft 8.3
*At the minimum useful output

RIVA PLUS MANUAL 9
2. Technical Information Cont.
ENERGY CAPACITY
Nominal heat input
(0/2000ft) MBH 116.0
Nominal heat input
(2000/4500ft) MBH 110.2
Minimum heat input MBH 49.5
Maximum useful output
(0/2000ft) MBH 102.0
Maximum useful output
(2000/4500ft) MBH 97.2
Minimum useful output MBH 41.6
GAS SUPPLY PRESSURE
Gas Normal Min Max
Natural inwc 7.0 3.5 10.5
Propane inwc 11.0 8.0 13.0
GAS PRESSURE AT BURNER
Gas Min Max Ignition
Natural inwc 1.0 4.8 2.4
Propane inwc 2.0 10.3 5.1
FLUE DESIGN
Minimum Venturi pressure inwc 0.64
Flue pipe diameter
Coaxial in 2.25/4
3.25/5
Twin split pipes in 3.25/3.25
Nominal heat ow rate
(0/2000ft) MBH 116.0
Nominal heat ow rate
(2000/4500ft) MBH 110.2
Min Exhaust temperature °F 158
Max Exhaust temperature °F 158
INJECTORS No. Size
Natural 14 130
Propane 14 85
GAS FLOW RATE
Gas Min Max
Natural ft³/h 48.7 115.1
Propane lb/h 2.23 5.25
ELECTRICAL
Voltage V 120
Frequency Hz 60
Current A 1.6
Power consumption W 180
FLUE GAS FIGURES
Gas Min Max
CO2 2.5% 6.3%
O2 16.5% 9.7%
CLEARANCE TO COMBUSTIBLES
Front in 18
Back in 0
Top in 8
Sides in 2
Bottom in 8
Flue pipe enclosed in 2
Flue pipe free air in 0

10 RIVA PLUS MANUAL
Parts List3.
Primary Components:
1 Pump
2 Pump vent plug
3 Automatic air purger valve
4 Modulation gas valve
5 Flame-detecting electrode
6 Ignition electrodes
7 Burner
8 Combustion chamber
9 Primary heat exchanger
10 Fan
11 Air pressure switch
12 Air switch pres. Test points
13 Safety thermostat
14 Modulation operator
15 Gas valve outlet pres. Test point
16 Gas valve inlet pres. Test point
17 Central heating expansion vessel
18 Central heating temp. Probe NTC
19 Central heating pressure relief valve
20 Primary circuit ow switch
21 Main circuit drain cock
22 By-pass valve
23 Venturi device
24 Flue outlet pipe
25 Air Intake Pipe
26 Control panel
27 Safety thermostat probe
28 Pressure reducing automatic ll valve
29 Back ow preventer
30 Gas supply line cock
31 Water supply inlet cock
32 Condensate trap
33 Condensing heat exchanger
34 Flue termostat

RIVA PLUS MANUAL 11
Internal Piping & Parts List4.
14
4
15
16
7
9
11
27
3
1
18
20
22
21
19
17
24
15
25
33
10
5
c
32
Note: Pressure Relief Valve (#19) should be piped to a drain or to the oor as lose as pos-
sible to a drain.

12 RIVA PLUS MANUAL
Electric Diagrams5.
ye bk wh gy bu rd
bk gy
gy
gy
M
~
t
C.h. temperature
probe NTC
Pump Gas
Valve
COM
NO
M
~
COM
NO
NC
1 2 3 bk
bubn
rd
rd
gnye
gywh
bu
rd
bk
bu
wh
gy
bu
gnye
bkbk
ubeyngyg
bk
bk
bubu
bu
bu
rdbk
ygyg
L N
rd bu bn gnye gnye
gnye bu
bn
burd
gnye
Primary Circuit
Flow Switch
External
controls
terminal
block
Electric supply
terminal
block Fan
Safety
Thermostat
Air Pressure
Switch
Ignition
Electrodes
Flame Detection
Electrode
bn - brown
bu - blue
bk - black
wh - white
rd - red
gy - grey
ye - yellow
gnye - green/yellow
wh
gy
rd
rd
bk
bu
bn
gy
ye wh burd
bk
rd
Thermostat
Flue
Caution: Label all wires prior to disconnection when
servicing controls. Wiring errors can cause im-
proper and dangerous operation.
Verify proper operation after servicing

RIVA PLUS MANUAL 13
5. Electric Diagrams Cont.
Sequence of Operation5.1

14 RIVA PLUS MANUAL
Installation Location6.
The installation location chosen must:
Comply with all clearances listed below.•
Provide suitable location for the exhaust and intake venting.•
Not be installed in an unheated space.•
Comply with all local codes and standards.•
Note: Dimensions shown are minimums. Greater clearances will simplify installation
and service.
Figure 6.1
WARNING: Do not install the boiler on carpeting
If the boiler is to be installed in an enclosed room with no fresh air intake, the room must have
proper vent louvers installed. There should be two louvers, place each within 12” of the ceiling
and oor respectively. Each vent will have a free area of 54 square inches.
8.0 in
31.6 in
15.2 in
3.0 i n
18.0 in
2.0 i n
15.8 in
10.0 in
2.0 in CLOSET INST
A
LL
A
TI ON
MINI MU M PER M
A
N
A
NT
CLE
A
R
A
NCE
FRONTV ISWEIDEVIEWCLOSET
INST
A
LL
A
TI ON
CLOSET INST
A
LL
A
TI ON
SERVICECLE
A
R
A
NCE
Figure 6.2
Outside
Air Opening
Air Opening
Each opening free area =
1 sq. inch per 2,000 BTU/h
0 to 12"
0 to 12"
When choosing an installation location insure the exhaust and intake pipes comply with NFPA
54. The drawing on the next page illustrates the restrictions on exhaust locations.
Note: For boilers in an enclosed space
it is recommended to install a CO
detector in the boiler room.

RIVA PLUS MANUAL 15
Exhaust Pipe Location7.
CAUTION
EXTERNAL VENT SURFACES ARE HOT.
IT IS RESPONSABILITY OF THE HOMEOWNER TO KEEP THE VENT
TERMINAL CLEAR OF SNOW AND ICE
NOTE: USE ONLY LISTED COMPONENTS SUPPLIED WITH THE BOILER. SURFACE
DISCOLORATION OF THE BUILDING MAY OCCUR DUE TO IMPROPER INSTALLATION. QHT
WILL NOT ACCEPT RESPONSIBILITY OR LIABILITY FOR SUCH DISCOLORATION.
The Exhaust Hood must be installed on the leeward side of house and conform to the
following guidelines:
The Vent hood shall not be less than 3 feet above any forced air inlet to the house.1.
The Vent hood shall not be less than 1 feet below, 1 foot horizontally, or 1 foot above any door,2.
window or gravity inlet into any building.
The Vent hood shall not be less than 2 feet from an adjacent building.3.
The Vent hood shall be not less than 7 feet above grade when located adjacent to public4.
walkway.
The Vent hood shall be located so that ue gasses are not directed to jeopardize people, overheat5.
combustible structures, materials or enter buildings.
Minimum of 4 feet horizontal clearance from electric meters, gas meters, regulators and relief6.
equipment.
All joints in system are to be sealed to prevent leakage of products of combustion in the 7.
building.
Avoid installing exhaust hood on the North, West, or the side of the house receiving the prevailing8.
winds.
The vent should not be situated so that the ue gases are directed towards brickwork, siding,9.
or other construction, in such a manner that may cause damage from heat or condensate from
the ue gases

16 RIVA PLUS MANUAL
Mounting Bracket8.
After a suitable installation location is chosen, verify that the mounting wall is properly
braced and strong enough to support the 110 pound weight of the unit when filled with
water.
NOTE: The boiler shall be installed such that the gas ignition system components are
protected from water and liquids in general (dripping,spraying, rain, etc) during
the appliance operation and service.
Use the paper template provided with the boiler to determine the location of the mounting
bracket. Securely mount the bracket to the wall using appropriate hardware for the particular
wall construction.
Mounting Steps:
Tape the paper template to the wall in the chosen location. Be sure to level the template.1.
Pre-drill two holes in the center of the “oval” slots on the mounting bracket, sized for the2.
hardware being used.
Mount the bracket to the wall. Be sure to level the bracket by adjusting the screw in the3.
vertical slot.
Pre-drill the remaining hole in the mounting bracket and secure the nal screw.4.
Mark and drill the exhaust/intake pipe holes through the house. If you are using a coaxial5.
pipe system, drill the hole marked A (ø 4”) in the drawing below and on the paper template.
If you are using a separate pipe system drill holes marked B and C (ø 3.25”) shown below
as well as on the paper template.
Remove paper template and hang boiler on bracket.6.
Figure 8.1
A, B, C
8
.
9
6.9
g
as
6
.
5
7.
9
1
5
.2
B
Ø
3.1
Ø3
.1
27.6
9.6
15.8
7.7
Ø
4.0
C
2.
9
7.
9
.
9
1
2
1.4
4.5 5.6
0.6
1.2
1.4
4.6
2.5 2.6
10.1
3.
9
2.4
2.4
Condense
A
31.6

RIVA PLUS MANUAL 17
Venting9.
The Riva is a mechanical draft, side wall vented boiler. There are two side wall ue options
available – separate and coaxial. The coaxial option has one con guration shown on the next
page. The separate option has two possible con gurations shown on the following pages.
There is also a vertical roof venting option. Regardless of what vent kit is installed, they should
all conform to the Provisions for combustion and ventilation air in accordance with sec-
tion 5.3,Air for Combustion and Ventilation, of the National Fuel Gas Code,ANSI Z223.1,
or Sections 7.2, 7.3 or 7.4 of CAN/CGA B149, Installation Codes, or applicable provi-
sions of the local building codes.
If the Biasi Riva replaces a boiler that was attached to a common vent system, the common
venting system is likely to be too large for proper venting of the appliances remaining con-
nected to it. To ensure the remaining appliances will function properly, the test procedure below
should be followed:
At the time of removal of an existing boiler, the following steps shall be followed with each
appliance remaining connected to the common venting system placed in operation, while the
other appliances remaining connected to the common venting system are not in operation.
(a) Seal any unused openings in the common venting system.
(b) Visually inspect the venting system for proper size and horizontal pitch and determine
there is no blockage or restriction, leakage, corrosion and other de ciencies which could
cause an unsafe condition.
(c) Insofar as is practical, close all building doors and windows and all doors between the
space in which the appliances remaining connected to the common venting system are
located and other spaces of the building. Turn on clothes dryers and any appliance not
connected to the common venting system. Turn on any exhaust fans, such as range
hoods and bathroom exhausts, so they will operate at maximum speed. Do not operate
a summer exhaust fan. Close replace dampers.
(d) Place in operation the appliance being inspected. Follow the lighting instructions. Adjust
thermostat so appliance will operate continuously.
(e) Test for spillage at the draft hood relief opening after 5 minutes of main burner opera-
tion. Use the ame of a match or candle, or smoke from a cigarette, cigar or pipe.
(f) After it has been determined that each appliance remaining connected to the common
venting system properly vents when tested as outlined above, return doors, windows,
exhaust fans, replace dampers and any other gas-burning appliance to their previous
condition of use.”
(g) Any improper operation of the common venting system should be corrected so the
installation conforms with the National Fuel Gas Code, ANSI Z223.1 and/or CAN/CGA
B149, Installation Codes. When resizing any portion of the common venting system,
the common venting system should be resized to approach the minimum size as de-
termined using the appropriate tables in Part 11 of the National Fuel Gas Code, ANSI
Z223.1 and/or CAN/CGA B149, Installation Codes.

18 RIVA PLUS MANUAL
Restrictor sizing9.1
fitting the flue system9.2
Figure 9.1
Figure 9.2
Table 9.1
9. Venting Cont.

RIVA PLUS MANUAL 19
Choice of flue:9.3
The following ue kits are available for connecting to the boiler:
A Standard coaxial horizontal flue kit (Exhaust & intake outside)
(Coaxial 2.4/4.0 inches – nominal lenght 3.3 ft)Figure 9.3
It can be tted to allow discharge to the rear or either side of the boiler via the anged
boiler adapter elbow. Minimum lenght required is 2.9 ft. Maximum equivalent lenght of
8.8 ft can be achieved utilising extensions. This ue system can only be used to dis-
charge horizontally; it is not designed to enable termination in the vertical plane.
Installation:
Drill hole A (on the wall template) through the outside wall that is less than 18” thick.•
Cut the pipe as necessary so that a no more than 6” protrudes from the house.•
Slide the intake and exhaust pipes through the hole.•
Slide one rubber wall trim piece on the pipe from inside and one from outside.•
Connect exhaust (inner) pipe to concentric elbow.•
Connect intake (outer) pipe to concentric elbow.•
Secure elbow to boiler using gasket and four screws provided.•
Secure end cap on the intake pipe outside the house.•
9. Venting Cont.

20 RIVA PLUS MANUAL
9. Venting Cont.
BStandard separate horizontal flue kit (Exhaust & intake outside)
(Twin pipeFigure 9.4 φ3.25 in)
Various twin (split) pipes kits and optional accessories (elbows) are available to assist in
the termination of the ue where the boiler is installed in a location remote to an outside
wall. These kits allow for separation of the air supply pipe from the pipe that discharges
the exhaust gasses. Consequently it is possible to extend the ue system to a greater
distance than that provided by the standard coaxial horizontal ue.
If either an additional 45° or 90° accessory elbow is used then the maximum permis-
sible lenght of either pipe must be reduced by 3.0 ft or 5.4 ft respectively. The sum of the
lenghts of the two horizontal part must be less than 49.2 ft.
Installation:
Drill holes B & C (on the wall template) through the outside wall that is less than 18” thick•
Cut the pipes as necessary so that no more than 6” of intake pipe protrudes from the•
house and the exhaust pipe is a minimum of 4 inches longer than the intake pipe.
Slide the Intake and exhaust pipes through the respective holes.•
Slide one rubber wall trim piece on each pipe from inside and one from outside.•
Attach each collar to the boiler with the gasket and screws provided.•
Insert each elbow into its corresponding collar.•
Connect each pipe to its corresponding elbow (as shown in the diagram).•
Secure end cap on the intake and exhaust pipe outside the house.•
