Bibby Sterilin Stuart SB300 User manual

Model No.
Hotplates SB300
SB500
CB300
CB500
Digital Hotplates SD300
SD500
Magnetic Stirrer SB301
Stirrer Hotplates SB302
CB302
Infrared Hotplate CR300
Infrared Hotplate Stirrer CR302
Version 2..0
Hotplates & Stirrers
Instructions for use
Manuel d’utilisation
Istruzioni per l’uso
Instrucciones de funcionamiento
Bedienungsanweisung

English
Before Use
Thank you for purchasing this Bibby
Scientific product. To get the best
performance from the equipment, and for
your own safety, please read these
instructions carefully before use.
If the equipment is not used in the manner
described in this manual the protection
provided may be impaired.
This equipment is designed to operate under the
following conditions:-
❖For indoor use only
❖Use in a well ventilated area
❖Ambient temperature range +5°C to +40°C
❖Altitude to 2000m
❖Relative humidity not exceeding 80%
❖Mains supply fluctuation not exceeding 10%
❖Overvoltage category II IEC60364-4-443
❖Pollution degree 2 IEC664
❖Use with a minimum distance all around of
200mm from walls or other items
Electrical Installation
Before connection please read and
understand this instruction manual and
ensure that the line supply corresponds to
that shown on the rating plate. All models
require a supply rated at: 230V, 50Hz, ~,
single phase.
Power consumption is:
Model Power Model Power
SB300 600W CB300 1200W
SB301 50W CB302 1250W
SB302 650W CB500 2250W
SB500 1500W CR300 900W
SD300 600W CR302 950W
SD500 1500W
THIS INSTRUMENT MUST BE EARTHED
All models are supplied with two mains leads
fitted with IEC plugs for connection to the
instrument. One has a U.K. 3 pin plug and the
other has a 2 pin “Shuko” plug for connection to
the mains. Choose the lead appropriate for your
electrical installation and discard the other.
Should neither lead be suitable, take the lead
with the U.K. plug and replace the plug with a
suitable alternative. This involves cutting off the
moulded plug, preparing the cable and
connecting to the rewireable plug in accordance
with its instructions.
IT IS IMPORTANT THAT THIS OPERATION
SHOULD ONLY BE UNDERTAKEN BY A
QUALIFIED ELECTRICIAN
NOTE: Refer to the equipment’s rating plate to
ensure that the plug and fusing are suitable for
the voltage and wattage stated.

The wires in the mains cable are coloured as
follows:
BROWN - LIVE
BLUE - NEUTRAL
GREEN/YELLOW - EARTH
The instruments are fitted with an IEC socket at
the rear of the instrument for connection of the
mains lead. The appropriate mains lead should be
connected BEFORE connection to the mains
supply.
Should the mains lead need replacement a cable
of 1mm2of harmonised code H05W-F connected
to an IEC320 plug should be used.
N.B. The UK mains lead is protected by a 10A
fuse mounted in the plug top.
IF IN DOUBT CONSULT A QUALIFIED
ELECTRICIAN
When connected to the mains electricity supply a
green light on the front panel illuminates, except
for the digital SD300 and SD500 models where
the display will illuminate showing the word
“OFF”.
Safety Advice Before Use
❖If the mains supply is interrupted the units will
restart with its current settings on the
restoration of the electricity supply.
❖Do not use an instrument with a ceramic top
if the top plate is scratched, chipped or shows
signs of chemical etching.
❖Position the instrument on a firm level surface
away from any heat sensitive or flammable
material.
❖Do not use the units with flammable liquids or
in a hazardous atmosphere.
❖There is a danger of liquid spills if vessels are
stirred too vigorously. Always build stirrer
speed slowly and never stir faster than
necessary.
❖Never move or carry the instrument until it
has been switched off and allowed to cool.
❖Never move or carry the unit with containers
on the top plate or while the instrument is
connected to the mains electricity supply.
1
Hot Surfaces
WARNING: The top surface of the
instrument may be HOT. Do not leave
heaters switched on when not in use.
WARNING: When the surface becomes too
hot to touch the red "HOT" warning light
on the front panel will begin to flash. This
will continue to flash while the plate
temperature is above 50°C even if the unit
is switched off as long as it is connected to
the electricity supply.
WARNING: Do not disconnect or switch
off the electricity supply until the “HOT”
warning light has ceased flashing.
WARNING: The plate may still be hot
when large masses are left on the plate,
even though the "HOT" warning light has
gone out.
WARNING: The top surface of the
instrument may be HOT, especially in free
air when a surface temperature of up to
450°C can be achieved on some of the
ceramic top models and 300°C on the
metal top models.
Heating
Models SB300, SB302, SB500, CB300, CB302,
CB500:
The knob labelled “Heat” on the front panel
controls the heat output and hence the plate
temperature.
The knob is graduated from 1 - 9. Increasing the
value increases the heat output.
Turn the hotplate control knob clockwise to the
desired setting. The amber load indicator light
will illuminate and it will begin to cycle on and
off when the desired temperature is reached and
the hotplate begins to control.
Models SD300 and SD500:
When connected to the mains electricity supply
the digital display will illuminate and show the
word OFF.

2
Switch the unit on by pressing the left hand one
of the 2 buttons located to the left of the digital
display. The display will now show the actual
plate temperature in degrees Celsius.
Press and hold the “press to set” button, the
right hand one of the 2 buttons located to the
left of the digital display. The display will now
show the set temperature.
The set temperature may be adjusted by turning
the knob located to the right of the digital
display whilst continuing to hold in the “press to
set” button. When the desired setting is
displayed release the “press to set” button. The
display will revert to show the actual plate
temperature and the instrument will begin to
heat.
The set temperature can be observed at any time
by pressing the “press to set” button.
Turning the adjusting knob without pressing the
“press to set” switch will have no effect on the
hotplate setting.
Models CR300 and CR302:
The knob labelled “Heat” on the front panel
controls the heat output and hence the plate
temperature. When the heat is switched on the
amber pilot light illuminates.
The knob is graduated from 1 - 9. Increasing the
value increases the heat output.
In operation only the area defined by the pattern
will become fully heated. The outer edges remain
cooler for safety considerations.
Vessels larger than the described area should not
be used. Failure to observe this could give rise to
overheating of the outer parts of the instrument.
NOTE: To prevent overheating of the
infrared heater a temperature limiter is
fitted which switches off the heater should
the temperature exceed 580°C.
Stirring
Models SB301, SB302, CB302 and CR302:
The knob labelled “Stir” on the front panel
controls the stirrer speed.
It is labelled with an arbitrary numeric scale,
1 - 9 and turning the knob to a higher setting
increases stirrer speed.
When the stirrer is switched on the amber pilot
light illuminates.
Cleaning and Care
Before attempting cleaning disconnect from the
mains electricity supply and ensure that the top is
cool.
Periodically clean the body of the instrument
using a damp cloth and mild detergent solution.
Do not use harsh or abrasive cleaning agents.
Ceramic top models: The ceramic top is very
easy to keep clean. A damp cloth will normally
remove most types of contamination. For more
difficult stains a domestic cream cleanser is
recommended. Cleaning is made easier if
spillages are attended to promptly. In any case,
spillages of alkali, phosphoric acid and
hydrofluoric acid MUST be removed immediately
as these chemicals can attack and damage the
glass ceramic. Ensure that the appropriate safety
precautions are observed.
During cleaning and general operation take care
not to scratch the surface of the top plate as this
could result in subsequent thermal breakage.
WARNING:
A ceramic top which is scratched, chipped,
chemically etched or damaged must not be
used.
Metal top models: The metal top plates should
be cleaned using a damp cloth and mild
detergent solution. Do not use harsh or abrasive
cleaning agents. Cleaning is made easier if
spillages are attended to promptly. In any case,
spillages of acids and alkalis MUST be removed
immediately as these chemicals can attack and
damage the aluminium alloy. Ensure that the
appropriate safety precautions are observed.

3
Servicing and Repair
This product range does not require any routine
servicing.
Note: There are no internal user
replaceable parts
In the event of product failure any repair or
replacement of parts should only be undertaken
by suitably qualified personnel. For advice please
contact the Service Department of Bibby Scientific
Ltd. quoting model and serial number.
Only spare parts supplied or specified by Bibby
Scientific Ltd. or its agents should be used. Fitting
of non-approved parts may affect the
performance of the safety features designed into
the instrument.
Note: The magnetic stirrer drive utilises
strong magnets.
If in any doubt, please contact the Service
Department of Bibby Scientific Ltd. or the point
of sale.
Bibby Scientific Ltd.
Stone, Staffordshire ST15 0SA
United Kingdom
Tel: [phone]
Fax: [phone]
e-mail [email protected]
www.bibby-scientific.com
Warranty
Bibby Scientific Ltd warrants these instruments to
be free from defects in material and
workmanship, when used under normal
laboratory conditions, for a period of three (3)
years. In the event of a justified claim Bibby
Scientific will replace any defective component or
replace the unit free of charge.
This warranty does NOT apply if damage is
caused by fire, accident, misuse, neglect, incorrect
adjustment or repair, damage caused by
installation, adaptation, modification, fitting of
non approved parts or repair by unauthorised
personnel.
