BILLFET JLT-9025D User manual

User Manual
3.2inch LCD Digital Wireless Baby Monitor
Model：JLT-9025D
1. charge/discharge:
RX: when the RX connected to external DC power supply, power supply for
the battery.Charging indicator LED normally on (if the boot, you can see
the LCD display battery in the top right corner symbols are charging).When
the battery charging LED out, battery showed full;When the RX battery
power supply, the upper right corner of the LCD display the current battery
capacity.When low battery LCD displays low bat, speakers, there will be
a prompt power indicator LED will flash.Press any key when low electricity
will exit when time report to the police.Alarm again after 3 min.When the
battery voltage to shutdown a tipping point, the machine automatically
enter the shutdown state.
TX: when TX connected to external DC power supply, power supply for the
battery.Charging indicator LED normally on, when the battery charging LED
out;When using battery power and achieve low power, low power indicator
LED will flash, when low electricity shutdown point is reached, TX will
automatically power off.
2. Turn on/off:
TX: off 3 s long switch, the machine turned on, the power LED display for
the green.3 s on long press switch to turn it off, the power LED will
extinguish.
RX: off 3 s long switch, power LED display for the green, the machine open,
LCD display images;3 s on long press switch, the machine shutdown.
3、The code/cancellation of code:
how to code the operation details are as follows:
TX: on light press press pair, the signal light flashing, into a state
machine to code.
RX: on light press press pair, matching channel displayed on the LCD,
press on, under the direction key, select the channel according to
the pair, LCD display "pairing......"After, when the RX and TX on code,
LCD screen pop up "pairing succeed, CH2 is selected press OK button
to back Menu" time to confirm the code.If the machine within 20 s were
not as TX, deserve to go up to the LCD display on "waiting for
Connecting..."The machine state of the code will exit, back to the
current interface.
how to cancel the yard operation details are as follows:
RX: on light press press pair, matching channel displayed on the LCD,
press the left and right direction key, press Del channel selection,
can eliminate the code information.

4. simple instructions:
TX：
RX：
power indicators
Low Voltage LED
Signal indicators
power indicators
Signal
TEM
Channel
Battery
Menu
1.1: Menu
1.2: Up
1.3: Down
1.4: Left
1.5: Right
1.6: Exit
1.7: alarm
Sensor
photosensitive diode
sensor
Infrared light-emitting
MIC

5. Main unction description:
around the main course, with key selection to prompt the bell of the
submenu, respectively is set to the low battery alarm, no alarm signal,
and then press up and down keys on or off.
around the main course, with key selection to a brightness control
of sub menu, and then press the up, down key can set the LCD brightness
of light and shade.
about where the main key to choose to play music sub menu, and then
press up, down keys can be set to single, single sequence repeat play,
play.
around the main course, with key selection to VOX sub menu, and then
press the up, down key can set the VOX sensitivity of high, medium
and low, according to the high, medium and low VOX, with the size of
the sound to awaken VOX sleep VOX value (the higher the sensitivity
Settings, wake up the smaller).
around the main course, with key selection to the submenu of the
thermometer, and then press the up, down key switch can be set up
degrees Celsius and Fahrenheit.High temperature alarm and low
temperature alarm can be set within the menu.
around the main course, with key selection to the night light function
of sub menu, and then press the up, down key can set the night lights
on or off, or night light switch (night night lights, night lights
during the day).
about where the main key selection to the language switch sub menu,
and then press the up, down key can set different languages.
about where the main button to exit the function of the sub menu, and
then press the up, down key whether can set the exit from the main
menu.

FCCCaution
Thisdevice complieswithpart15 oftheFCCRules. Operation issubjecttothe
followingtwoconditions:(1)Thisdevice maynotcauseharmfulinterference,and (2)
thisdevice mustacceptanyinterferencereceived, including interferencethatmay
causeundesired operation.
AnyChangesormodifications notexpresslyapprovedbythepartyresponsiblefor
compliance could void theuser's authorityto operatetheequipment.
Note: Thisequipmenthasbeentestedand foundtocomplywiththelimitsforaClass
Bdigitaldevice,pursuanttopart15 oftheFCCRules. Theselimitsare designedto
providereasonableprotection againstharmfulinterferenceinaresidentialinstallation.
Thisequipmentgeneratesusesand canradiateradiofrequencyenergyand, ifnot
installedand usedinaccordancewiththeinstructions, maycauseharmfulinterference
toradiocommunications. However,there isno guaranteethatinterference will not
occurinaparticular installation. Ifthisequipmentdoescauseharmfulinterferenceto
radioortelevision reception, whichcanbedeterminedbyturning theequipmentoff
and on, theuser isencouragedtotrytocorrecttheinterferencebyoneormore ofthe
followingmeasures:
-Reorient or relocatethereceivingantenna.
-Increase theseparation between the equipment and receiver.
-Connectthe equipment into an outleton acircuitdifferent from thatto which the
receiver is connected.
-Consultthe dealer or an experienced radio/TV technician for help.
FCCID:2AK33-JLT9025D
