English
1
Q1900M Pro3
Motherboard Layout
RoHS
USB 3.0
CMOS
Battery
Super
I/O
LAN
AUDIO
CODE C
PS2
Keyboard
PS2
Mouse
Top:
RJ-45
USB 3.0:
USB3
USB 2.0:
USB2
Top:
LINE I N
Center:
FRON T
Bottom:
MIC IN
PCIE1
PCIE2
ATXPWR1
1
HD_AUDIO1
CI1
1
1
TPMS1
COM2
1
1
USB4 _5
1
SPE AKE R1
CLRM OS 1
1
1
USB 6
HDL ED RE SE T
PLE D PWR BT N
PANE L1
1
SATA2 _2
CPU_ FAN 1
DDR3_A1 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
1
3
2
4
5
6
7
8
13 12 11 9
10
14
15
Q1900M Pro3
PCI1
PCI2
SATA2 _1
CHA_FAN1
PARALLEL PORT
COM1
VGA1
HDMI1
USB 2.0
T: USB0
B: USB1
English
2
No. Description
1 CPU Fan Connector (CPU_FAN1)
2 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
3 ATX Power Connector (ATXPWR1)
4 Chassis Speaker Header (SPEAKER1)
5 Chassis Fan Connector (CHA_FAN1)
6 Clear CMOS Jumper (CLRCMOS1)
7 System Panel Header (PANEL1)
8 SATA2 Connector (SATA2_1)
9 SATA2 Connector (SATA2_2)
10 USB 2.0 Header (USB6)
11 USB 2.0 Header (USB4_5)
12 TPM Header (TPMS1)
13 COM Port Header (COM2)
14 Chassis Intrusion Header (CI1)
15 Front Panel Audio Header (HD_AUDIO1)
English
3
Q1900M Pro3
I/O Panel
No. Description No. Description
1 PS/2 Mouse Port 8 Microphone (Pink)
2 Parallel Port 9 USB 3.0 Port (USB3)
3 USB 2.0 Ports (USB01) 10 HDMI Port
4 LAN RJ-45 Port* 11 D-Sub Port
5 USB 2.0 Port (USB2) 12 COM Port
6 Line In (Light Blue) 13 PS/2 Keyboard Port
7 Front Speaker (Lime)
* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
1
13 9
5
46
7
8
2
1112
3
10
English
4
Chapter 1 Introduction
ank you for purchasing ASRock Q1900M Pro3 motherboard, a reliable
motherboard produced under ASRock’s consistently stringent quality control.
It delivers excellent performance with robust design conforming to ASRock’s
commitment to quality and endurance.
1.1 Package Contents
• ASRock Q1900M Pro3 Motherboard (Micro ATX Form Factor)
• ASRock Q1900M Pro3 Quick Installation Guide
• ASRock Q1900M Pro3 Support CD
• 2 x Serial ATA (SATA) Data Cables (Optional)
• 1 x I/O Panel Shield
Because the motherboard specications and the BIOS soware might be updated, the
content of this documentation will be subject to change without notice. In case any
modications of this documentation occur, the updated version will be available on
ASRock’s website without further notice. If you require technical support related to
this motherboard, please visit our website for specic information about the model
you are using. You may nd the latest VGA cards and CPU support list on ASRock’s
website as well. ASRock website http://www.asrock.com.
English
5
Q1900M Pro3
1.2 Specications
Platform • Micro ATX Form Factor
• Solid Capacitor design
• High Density Glass Fabric PCB
CPU • Intel® Quad-Core Processor J1900 (2 GHz)
Memory • Dual Channel DDR3/DDR3L Memory Technology
• 2 x DDR3/DDR3L DIMM Slots
• Supports DDR3/DDR3L 1333/1066 non-ECC, un-buered
memory
• Max. capacity of system memory: 16GB
(see CAUTION)
* If only one DIMM module is installed, please install it into
DDR3_A1.
Expansion
Slot
• 1 x PCI Express 2.0 x16 Slot (PCIE2 @ x1 mode)
• 1 x PCI Express 2.0 x1 Slot
• 2 x PCI Slots
Graphics
• Intel®7th generation (Gen 7) graphics
• DirectX 11.0, Pixel Shader 5.0
• Dual graphics output: support HDMI and D-Sub ports by
independent display controllers
• Supports HDMI Technology with max. resolution up to
1920x1200 @ 60Hz
• Supports D-Sub with max. resolution up to 2560x1600 @
60Hz
• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI Port (Compliant
HDMI monitor is required)
• Supports HDCP with HDMI Port
• Supports Full HD 1080p Blu-ray (BD) playback with HDMI
Port
Audio • 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
• Supports Surge Protection (ASRock Full Spike Protection)
• ELNA Audio Caps
English
6
LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s
• Realtek RTL8111GR
• Supports Wake-On-WAN
• Supports Wake-On-LAN
• Supports Lightning/ESD Protection (ASRock Full Spike
Protection)
• Supports LAN Cable Detection
• Supports Energy Ecient Ethernet 802.3az
• Supports PXE
Rear Panel
I/O
• 1 x PS/2 Mouse Port
• 1 x PS/2 Keyboard Port
• 1 x Serial Port: COM1
• 1 x Parallel Port (ECP/EPP support)
• 1 x D-Sub Port
• 1 x HDMI Port
• 3 x USB 2.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))
• 1 x USB 3.0 Port (Supports ESD Protection (ASRock Full
Spike Protection))
• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
• HD Audio Jacks: Line in / Front Speaker / Microphone
Storage • 2 x SATA2 3.0 Gb/s Connectors, support NCQ, AHCI and
Hot Plug
Connector • 1 x COM Port Header
• 1 x TPM Header
• 1 x Chassis Intrusion Header
• 1 x CPU Fan Connector (3-pin)
• 1 x Chassis Fan Connector (3-pin)
• 1 x 24 pin ATX Power Connector
• 1 x Front Panel Audio Connector
• 2 x USB 2.0 Headers (Support 3 USB 2.0 ports) (Supports ESD
Protection (ASRock Full Spike Protection))
English
7
Q1900M Pro3
BIOS
Feature
• 64Mb AMI UEFI Legal BIOS with GUI support
• Supports Plug and Play
• ACPI 1.1 compliant wake up events
• Supports jumperfree
• SMBIOS 2.3.1 support
Hardware
Monitor
• CPU/Chassis temperature sensing
• CPU/Chassis Fan Tachometer
• CPU/Chassis Quiet Fan (Auto adjust chassis fan speed by
CPU temperature)
• CPU/Chassis Fan multi-speed control
• CASE OPEN detection
• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
OS • Microso® Windows® 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-
bit / 7 32-bit / 7 64-bit
Certica-
tions
• FCC, CE, WHQL
• ErP/EuP ready (ErP/EuP ready power supply is required)
* For detailed product information, please visit our website: http://www.asrock.com
Due to limitation, the actual memory size may be less than 4GB for the reservation
for system usage under Windows® 32-bit operating systems. Windows® 64-bit operat-
ing systems do not have such limitations. You can use ASRock XFast RAM to utilize
the memory that Windows® cannot use.
English
8
is is a Micro ATX form factor motherboard. Before you install the motherboard,
study the conguration of your chassis to ensure that the motherboard ts into it.
Pre-installation Precautions
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
• Make sure to unplug the power cord before installing or removing the motherboard.
Failure to do so may cause physical injuries to you and damages to motherboard
components.
• In order to avoid damage from static electricity to the motherboard’s components,
NEVER place your motherboard directly on a carpet. Also remember to use a grounded
wrist strap or touch a safety grounded object before you handle the components.
• Hold components by the edges and do not touch the ICs.
• Whenever you uninstall any components, place them on a grounded anti-static pad or
in the bag that comes with the components.
• When placing screws to secure the motherboard to the chassis, please do not over-
tighten the screws! Doing so may damage the motherboard.
Chapter 2 Installation
English
9
Q1900M Pro3
2.1 Installing Memory Modules (DIMM)
is motherboard provides two 240-pin DDR3/DDR3L (Double Data Rate 3)
DIMM slots. If only one DIMM module is installed, please install it into DDR3_A1.
e DIMM only ts in one correct orientation. It will cause permanent damage to
the motherboard and the DIMM if you force the DIMM into the slot at incorrect
orientation.
It is not allowed to install a DDR or DDR2 memory module into a DDR3/DDR3L
slot; otherwise, this motherboard and DIMM may be damaged.
English
10
1
2
3
English
11
Q1900M Pro3
2.2 Expansion Slots (PCI and PCI Express Slots)
ere are 2 PCI slots and 2 PCI Express slots on the motherboard.
PCI slots:
e PCI1 and PCI2 slots are used to install expansion cards that have 32-bit PCI
interface.
PCIe slots:
PCIE1 (PCIe 2.0 x1 slot) is used for PCI Express x1 lane width cards.
PCIE2 (PCIe 2.0 x16 slot) is used for PCI Express x1 lane width cards.
Before installing an expansion card, please make sure that the power supply is
switched o or the power cord is unplugged. Please read the documentation of the
expansion card and make necessary hardware settings for the card before you start the
installation.
English
12
2.3 Jumpers Setup
e illustration shows how jumpers are setup. When the jumper cap is placed on
the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper
is “Open”. e illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”
when a jumper cap is placed on these 2 pins.
Clear CMOS Jumper
(CLRMOS1)
(see p.1, No. 6)
CLRMOS1 allows you to clear the data in CMOS. To clear and reset the system
parameters to default setup, please turn o the computer and unplug the power
cord from the power supply. Aer waiting for 15 seconds, use a jumper cap to
short pin2 and pin3 on CLRMOS1 for 5 seconds. However, please do not clear the
CMOS right aer you update the BIOS. If you need to clear the CMOS when you
just nish updating the BIOS, you must boot up the system rst, and then shut it
down before you do the clear-CMOS action. Please be noted that the password,
date, time, and user default prole will be cleared only if the CMOS battery is
removed.
Clear CMOSDefault
If you clear the CMOS, the case open may be detected. Please adjust the BIOS option
“Clear Status” to clear the record of previous chassis intrusion status.
English
13
Q1900M Pro3
2.4 Onboard Headers and Connectors
System Panel Header
(9-pin PANEL1)
(see p.1, No. 7)
Connect the power
switch, reset switch and
system status indicator on
the chassis to this header
according to the pin
assignments below. Note
the positive and negative
pins before connecting
the cables.
GND
RESET#
PWRBTN#
PLED-
PLED+
GND
HDLED-
HDLED+
1
GND
PWRBTN (Power Switch):
Connect to the power switch on the chassis front panel. You may congure the way to
turn o your system using the power switch.
RESET (Reset Switch):
Connect to the reset switch on the chassis front panel. Press the reset switch to restart
the computer if the computer freezes and fails to perform a normal restart.
PLED (System Power LED):
Connect to the power status indicator on the chassis front panel. e LED is on when
the system is operating. e LED keeps blinking when the system is in S1/S3 sleep state.
e LED is o when the system is in S4 sleep state or powered o (S5).
HDLED (Hard Drive Activity LED):
Connect to the hard drive activity LED on the chassis front panel. e LED is on when
the hard drive is reading or writing data.
e front panel design may dier by chassis. A front panel module mainly consists
of power switch, reset switch, power LED, hard drive activity LED, speaker and etc.
When connecting your chassis front panel module to this header, make sure the wire
assignments and the pin assignments are matched correctly.
Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over
these headers and connectors. Placing jumper caps over the headers and connectors
will cause permanent damage to the motherboard.
English
14
Serial ATA2 Connectors
(SATA2_1:
see p.1, No. 8)
(SATA2_2:
see p.1, No. 9)
ese two SATA2
connectors support SATA
data cables for internal
storage devices with up to
3.0 Gb/s data transfer rate.
USB 2.0 Headers
(9-pin USB4_5)
(see p.1, No. 11)
(4-pin USB6)
(see p.1, No. 10)
Besides three USB 2.0
ports on the I/O panel,
there are two headers on
this motherboard.
Front Panel Audio Header
(9-pin HD_AUDIO1)
(see p.1, No. 15)
is header is for
connecting audio devices
to the front audio panel.
J_SENSE
OUT2_L
1
MIC_RET
PRESENCE#
GND
OUT2_R
MIC2_R
MIC2_L
OUT_RET
DUMMY
GND
GND
P+
P-
USB_PWR
P+
P-
USB_PWR
1
1. High Denition Audio supports Jack Sensing, but the panel wire on the chassis must
support HDA to function correctly. Please follow the instructions in our manual and
chassis manual to install your system.
2. If you use an AC’97 audio panel, please install it to the front panel audio header by
the steps below:
A. Connect Mic_IN (MIC) to MIC2_L.
B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to OUT2_L.
C. Connect Ground (GND) to Ground (GND).
D. MIC_RET and OUT_RET are for the HD audio panel only. You don’t need to
connect them for the AC’97 audio panel.
E. To activate the front mic, go to the “FrontMic” Tab in the Realtek Control panel
and adjust “Recording Volume”.
1
USB_P WR
P- P + GND
SATA2_2 SATA2_1
English
15
Q1900M Pro3
Chassis Speaker Header
(4-pin SPEAKER1)
(see p.1, No. 4)
Please connect the chassis
speaker to this header.
Chassis Fan Connector
(3-pin CHA_FAN1)
(see p.1, No. 5)
Please connect fan cable
to the fan connector and
match the black wire to
the ground pin.
CPU Fan Connectors
(3-pin CPU_FAN1)
(see p.1, No. 1)
Please connect the CPU
fan cable to the connector
and match the black wire
to the ground pin.
ATX Power Connector
(24-pin ATXPWR1)
(see p.1, No. 3)
is motherboard pro-
vides a 24-pin ATX power
connector. To use a 20-pin
ATX power supply, please
plug it along Pin 1 and Pin
13.
Chassis Intrusion Header
(2-pin CI1)
(see p.1, No. 14)
is motherboard supports
CASE OPEN detection feature
that detects if the chassis cove
has been removed. This feature
requires a chassis with chassis
intrusion detection design.
TPM Header
(17-pin TPMS1)
(see p.1, No. 12)
is connector supports Trusted
Platform Module (TPM) system,
which can securely store keys,
digital certicates, passwords,
and data. A TPM system also
helps enhance network security,
protects digital identities, and
ensures platform integrity.
12 1
24
13
1
+5V
DUMMY
DUMMY
SPEAKER
1
GND
SMB _DATA_MAIN
LAD2
LAD1
GND
S_P WRDWN#
SER IRQ #
GND
PCI CLK
PCI RST#
LAD3
+3V
LAD0
+3VS B
GND
FRA M E SMB_CLK_MAIN
GND
FAN_VOLTAGE
FAN_SPEED
GND
FAN_VOLTAGE
FAN_SPEED
1
Signal
GND
English
16
Serial Port Header
(9-pin COM2)
(see p.1, No. 13)
is COM2 header
supports a serial port
module.
CCTS#1
RRTS#1
DDSR#1
DDTR#1
RRXD1
GND
TTXD1
DDCD#1
1
RRI#1
17
Deutsch
Q1900M Pro3
1 Einleitung
Vielen Dank, dass Sie sich für das Q1900M Pro3 von ASRock entschieden haben – ein
zuverlässiges Motherboard, das konsequent unter der strengen Qualitätskontrolle von
ASRock hergestellt wurde. Es liefert ausgezeichnete Leistung mit robustem Design,
das ASRocks Streben nach Qualität und Beständigkeit erfüllt.
1.1 Lieferumfang
•ASRock Q1900M Pro3-Motherboard (Micro ATX-Formfaktor)
•ASRock Q1900M Pro3-Schnellinstallationsanleitung
•ASRock Q1900M Pro3-Support-CD
•2 x Serial-ATA- (SATA) Datenkabel (optional)
•1 x E/A-Blendenabschirmung
Da die technischen Daten des Motherboards sowie die BIOS-Soware aktualisiert werden
können, kann der Inhalt dieser Dokumentation ohne Ankündigung geändert werden.
Falls diese Dokumentation irgendwelchen Änderungen unterliegt, wird die aktualisierte
Version ohne weitere Hinweise auf der ASRock-Webseite zur Verfügung gestellt. Sollten
Sie technische Hilfe in Bezug auf dieses Motherboard benötigen, erhalten Sie auf unserer
Webseite spezischen Informationen über das von Ihnen verwendete Modell. Auch nden
Sie eine aktuelle Liste unterstützter VGA-Karten und Prozessoren auf der ASRock-
Webseite: ASRock-Webseite http://www.asrock.com.
18
Deutsch
1.2 Technische Daten
Plattform •Micro ATX-Formfaktor
•Solides Kondensatordesign
•PCB mit hochverdichtetem Glasfasergewebe
Prozessor •Intel® Quad-Core-Prozessor J1900 (2 GHz)
Speicher •Dualkanal-DDR3/DDR3L-Speichertechnologie
•2 x DDR3/DDR3L DIMM-Steckplätze
•Unterstützt DDR3/DDR3L 1333/1066 non-ECC, ungepuerter
Speicher
•Systemspeicher, max. Kapazität: 16 GB
(siehe ACHTUNG)
* Wenn nur ein SIMM-Modul eingesetzt wird, installieren Sie dies
bitte in Sockel DDR3_A1.
Erweiterungs-
steckplatz
•1 x PCI-Express 2,0-x16-Steckplatz (PCIE2: x1-Modus)
•1 x PCI-Express 2.0-x1-Steckplatz
•2 x PCI-Steckplatz
Grakkarte •Intel®-Grakkarte der 7ten Generation (Gen 7)
•DirectX 11.0, Pixel Shader 5.0
•Doppel-VGA Ausgabe: unterstützt HDMI und D-Sub Ports
durch unabhängige Bildschirmanzeige Kontrolleure
•Unterstützt HDMI mit maximaler Auösung von 1920 x 1200
bei 60 Hz
•Unterstützt D-Sub mit maximaler Auösung von 2560 x 1600
bei 60 Hz
•Unterstützt Auto-Lippensynchronizität, hohe Farbtiefe (12
bpc), xvYCC und HBR (Audio mit hoher Bitrate) mit HDMI
(konformer HDMI-Monitor erforderlich)
•Unterstützt HDCP-Funktion mit HDMI-Port
•Unterstützt Blu-ray- (BD) Wiedergabe (Full HD/1080p) mit
HDMI-Port
Audio •5.1-Kanal-HD-Audio (Realtek ALC662-Audiocodec)
•Unterstützt Überspannungsschutz (ASRocks Komplettschutz
vor Spannungsspitzen)
•ELNA Audio Caps.
Table of contents
Languages:
