Axio AX-OC-MWS-UHL User manual
1. Description and Operation
2. LCD Navigation
The AX-OC-MWS-UHL is the programming tool for all products in
the MWS range.
On button
To turn the unit on press the „on‟ button. This button is also used for
selecting parameters and then sending to the device being
programmed.
Up, down. Left and right buttons
Use to navigate through the menus. The up and down buttons are
also used for selecting values or toggling between on / off, yes / no
etc.
To turn the unit off, either select the final main menu item or the unit
will turn off after 30 seconds.
Section Contents Page
1 Description and operation 1
2 LCD Navigation 1
3 2
4
Detector Parameter Menu
2
5
Modes menu
2
6
Ch1 (sw) set Menu
3
7 3
User menu
Ratings
Menu selection
Use the < > buttons to scroll through the menus. Press „on‟ to select.
Parameter selection
Use the < > buttons to scroll through the menus. Press „on‟ to select
menu. Use the up and down buttons to select values or toggle
between on / off, yes / no. Press „on‟ to send parameter to device.
Contents
Product Guide
AX-OC-MWS-UHL
ANNICOM Ltd Unit 21, Highview, High Street, Bordon, Hampshire, GU35 0AX
Tel: +44 (0)1420 487788 Fax: +44(0)1420 477799 Email: [email protected] Website: www.annicom.com
Copyright Annicom Ltd. All rights reserved.
2
IR cmd Description Default Products
Time Mins 10 seconds to 99 minutes time delay (select 0 for 10 second delay –use for commis-
sioning only).
All
Sens on Sensitivity level when the detector is already operational adjustable between 1 (min.)
and 9 (max.)
Product
dependant
All
Sens off Sensitivity level for switching the detector on –adjustable between 1 (min.) and 9
(max.).
Product
dependant
All
Power Up On Select No for a 30 second delay on start up. If Yes is selected, there will be no delay on
start up and the detector will always power up detecting.
Y All
Walk test If set, walk test mode will flash the internal LED when occupancy is detected N All
Disable Det Disables detection, leaving the relay output permanently off with the dimming output
operational. This mode is used when the unit is for maintained illuminance only.
N All
Factory default Restores factory default settings
Use with caution
All
Menus
The final column for each menu section shows which products can programmed with specific parameters.
3. Detector Parameter Menu
IR cmd Description Products
Channel modes Selects the channel modes menu All
Switch modes Selects the switch modes menu All
4. Modes Menu
IR cmd Description Default Products
Presence Auto switch on with detection, auto off after movement ceases and time delay ends. Product
dependant
All
Absence Manual switch on, auto off after movement ceases and time delay ends. Product
dependant
All
Sw lev on Switch level on
Lux level setting to prevent the luminaires being switched on if the ambient light level
is sufficient (adjustable between 1 and 9). The luminaires will always be switched on at
level 9. For a higher resolution of „switch level on‟ a scale of 101-199 is available in the
„Special menu‟.
9 All
Sw lev off Switch level off
Lux level setting to switch the luminaires off during occupancy if the ambient light level
goes above the setting (adjustable between 1 and 9). Level 9 will always keep the lights
on. This setting can be used for “window row switching”.
9 All
Special Selects the special menu below All
5. Ch1 (sw) set Menu
Use this menu for programming Channel 1. This is the switched channel.
3
IR cmd Description Default Products
Sw lev on Switch level on
Lux level setting to prevent the luminaires being switched on if the ambient light
level is sufficient (adjustable between 101 and 199).
Use to provide finer adjustment than parameters above.
None All
Sw lev off Switch level off
Lux level setting to switch the luminaires off during occupancy if the ambient light
level goes above the setting (adjustable between 101 and 199).
Use to provide finer adjustment than parameters above.
None All
Special Menu
IR cmd Description Products
Lux up Increase light level. Reverts when occupancy cycle complete. All
Lux down Decrease light level. Reverts when occupancy cycle complete. All
Override on Permanently overrides the luminaire output on. All
Override off Permanently overrides the luminaire output off. All
Cancel Cancels the on or off override, returning the detector to normal operation. All
Set If sent before using lux up or lux down, it will set the light level as in „ Light lev‟ found „Ch2 (dim) set‟
menu
All
6. User Menu
Battery 4 x 1.5Vdc AA
Temperature 0ºC to 35ºC
Compliance EMC-2004/108/EC
LVD-2006/95/EC
7.Ratings
Every effort has been taken in the production of this datasheet to ensure accuracy. Annicom Ltd does not accept responsibility for any
damage, expense, injury, loss or consequential loss resulting from any errors or omissions. Annicom Ltd has a policy of continuous
improvement and reserves the right to change this specification without notice.
