Asus PRL-DLS User manual

15-15-065051000
E1096
®
www.asus.com
®
PRL-DLS

E1096
E1096
PRL-DLS
Dual Intel®Xeon™-based Motherboard
ServerWorks®GCSL SystemSet
®
PRL-DLS
User Guide

Motherboard
PRL-DLS
User Guide

ii
Checklist
Copyright © 2002 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of ASUSTeK COMPUTER INC.
(“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2)
the serial number of the product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FORAPARTICULAR PURPOSE.
IN NO EVENT SHALLASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE
OR DATA, INTERRUPTION OF BUSINESSAND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE ATANY TIME
WITHOUT NOTICE,AND SHOULD NOT BE CONSTRUEDAS A COMMITMENT BYASUS.
ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR
INACCURACIES THAT MAYAPPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS
AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.
E1096
First Edition
November 2002

iii
Features
ASUS Contact Information
ASUSTeK COMPUTER INC. (Asia-Pacific)
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
General Tel: [phone]
General Fax: [phone]
General Email: [email protected]
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel):[phone] (English)
Support Fax: [phone]
Support Email: [email protected]
Web Site: www.asus.com.tw
Newsgroup: cscnews.asus.com.tw
ASUS COMPUTER INTERNATIONAL (America)
Address: 6737 Mowry Avenue, Mowry Business Center,
Building 2, Newark, CA 94560, USA
General Fax: [phone]
General Email: [email protected]
Technical Support
Support Fax: [phone]
General Support: [phone]
Web Site: www.asus.com
Support Email: [email protected]
ASUS COMPUTER GmbH (Germany & Austria)
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
General Fax: [phone]
General Email: [email protected] (for marketing requests only)
Technical Support
Support Hotline: MB/Others: [phone]
Notebook (Tel): [phone]
Support Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
Web Site: www.asuscom.de

iv
Safeguards
Contents
Product introduction.................................................. Chapter 1
1.1 Welcome! .............................................................................. 1
1.2 Package contents.................................................................. 1
1.3 Special features..................................................................... 2
1.3.1 Product highlights ..................................................... 2
1.3.2 Value-added solutions............................................... 4
1.4 Motherboard overview........................................................... 6
1.4.1 Major components .................................................... 6
1.4.2 Core specifications ................................................... 8
Hardware information ................................................ Chapter 2
2.1 Motherboard installation ........................................................ 1
2.1.1 Placement direction .................................................. 1
2.1.2 Screw holes .............................................................. 1
2.2 Motherboard layout ............................................................... 2
2.3 Before you proceed ............................................................... 3
2.4 Central Processing Unit (CPU).............................................. 4
2.4.1 Overview ................................................................... 4
2.4.2 Installing the CPU ..................................................... 5
2.4.3 Installing the CPU heatsink and fan.......................... 6
2.5 System memory .................................................................... 8
2.5.1 Overview ................................................................... 8
2.5.2 Memory Configurations............................................. 9
2.5.3 Installing a DIMM .................................................... 10
2.5.4 Removing a DIMM .................................................. 10
2.6 Expansion slots ....................................................................11
2.6.1 Installing an expansion card ....................................11
2.6.2 Configuring an expansion card ................................11
2.6.3 PCI slots ................................................................. 13
2.7 Switches and jumpers ......................................................... 14
2.7.1 Switches ................................................................. 14
2.7.2 Jumpers .................................................................. 16
2.8 Connectors .......................................................................... 19
2.9 Onboard LEDs..................................................................... 27
2.9.1 Port 80h post code LEDs ........................................ 28

v
Contents
Powering up ............................................................... Chapter 3
3.1 Starting up for the first time ................................................... 1
3.2 Powering off the computer .................................................... 2
BIOS setup ................................................................. Chapter 4
4.1 Managing and updating your BIOS ....................................... 1
4.1.1 Creating a bootable disk ........................................... 1
4.1.2 Updating the BIOS .................................................... 3
4.2 BIOS Setup program ............................................................. 5
4.2.1 BIOS menu bar ......................................................... 6
4.2.2 Legend bar................................................................ 6
4.3 Main Menu............................................................................. 8
4.3.1 Primary/Secondary/Tertiary Master/Slave .............. 10
4.3.2 Keyboard Features ................................................. 14
4.4 Advanced Menu .................................................................. 15
4.4.1 Chip Configuration .................................................. 17
4.4.2 I/O Device Configuration......................................... 18
4.4.3 PCI Configuration ................................................... 20
4.5 Power Menu ........................................................................ 22
4.5.1 Power Up Control ................................................... 24
4.5.2 Hardware Monitor ................................................... 26
4.6 Boot Menu ........................................................................... 27
4.6.1 Slot Configuration ................................................... 30
4.7 Server Menu........................................................................ 31
4.7.1 Event Log Viewer.................................................... 32
4.8 Exit Menu ............................................................................ 33
Support CD................................................................. Chapter 5

vi
FCC/CDC statements
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations.
Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate this equipment.

vii
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from
the electrical outlet before relocating the system.
• When adding or removing devices to or from the system, ensure that
the power cables for the devices are unplugged before the signal
cables are connected. If possible, disconnect all power cables from the
existing system before you add a device.
• Before connecting or removing signal cables from the motherboard,
ensure that all power cables are unplugged.
• Seek professional assistance before using an adpater or extension
cord. These devices could interrupt the grounding circuit.
• Make sure that your power supply is set to the correct voltage in your
area. If you are not sure about the voltage of the electrical outlet you
are using, contact your local power company.
• If the power supply is broken, do not try to fix it by yourself. Contact a
qualified service technician or your retailer.
Operation safety
• Before installing the product and adding devices on it, carefully read all
the documentation that came with the package.
• Before using the product, make sure all cables are correctly connected
and the power cables are not damaged. If you detect any damage,
contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the
product in any area where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a
qualified service technician or your retailer.

viii
About this guide
This user guide contains the information you need when installing this
ASUS motherboard.
How this guide is organized
This manual contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of this motherboard. It includes
brief descriptions of the special attributes of the motherboard and the
new technology it supports.
• Chapter 2: Hardware information
This chapter lists the hardware setup procedures that you have to
perform when installing system components. It includes description of
the switches, jumpers, and connectors on the motherboard.
•Chapter 3: Powering up
This chapter describes the power up sequence and gives information
on the BIOS beep codes.
• Chapter 4: BIOS setup
This chapter tells how to change system settings through the BIOS
Setup menus. Detailed descriptions of the BIOS parameters are also
provided.
• Chapter 5: OS Installation
This chapter tells how to install SCSI, LAN, and VGA drivers for
various operating systems.

ix
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the
following symbols used throughout this manual.
Where to find more information
Refer to the following sources for additional information and for product
and software updates.
1. ASUS Websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. The ASUS websites are listed in the
ASUS Contact Information on page x.
2. Optional Documentation
Your product package may include optional documentation, such as
warranty flyers, that may have been added by your dealer. These
documents are not part of the standard package.
WARNING: Information to prevent injury to yourself when trying
to complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
IMPORTANT: Information that you MUST follow to complete a
task.
NOTE: Tips and additional information to aid in completing a task.

x
PRL-DLS specifications summary
CPU
Chipsets
Front Side Bus (FSB)
Memory
Onboard LAN
Onboard SCSI
Onboard VGA
Expansion slots
Rear panel I/O
Internal connectors
Support for Intel
®
Xeon™ processor
On-die 512KB L2 cache
RCC Grand Champion Super Lite North Bridge (GMIC-SL)
RCC Champion South Bridge 6.0 (CSB6)
RCC Champion I/O Bridge 2.0 (CIOB-X2)
400 MHz / 533 MHz
4 x 184-pin DDR DIMM sockets
Supports PC2100/PC1600 registered ECC DDR DIMMs
Supports 128MB to 4GB system memory
BroadCom 5703C Gigabit Ethernet controller
Intel
®
82540 Fast Ethernet controller
LSI
®
53C1010R PCI SCSI controller
or
LSI
®
53C1030 PCI-X SCSI controller
ATI
®
RAGE-XL PCI-based VGA controller
4 x PCI 64-bit/100MHz 3V (PCI-X1 to PCI-X4)
1 x PCI 64-bit/33MHz 3V (PCI64)
(PCI-X3 supports AMI Express 600 ZCR card
when LSI
®
53C1030 is onboard)
1 x PCI 32-bit/33MHz 5V (PCI32)
1 x Parallel port
1 x Serial port
1 x VGA port
1 x PS/2 keyboard port
1 x PS/2 mouse port
2 x USB 1.1 ports
2 x RJ-45 ports (with LED)
2 x 68-pin Ultra-160/320 SCSI connectors
3 x ATA/100 IDE connectors
1 x Floppy disk connector
1 x Serial Port 2 (COM2) connector
eRMC and IPMI connectors (for ASMC card)
CPU/Power/Chassis fan connectors
24-pin/8-pin ATX power connectors
IDE LED/Power LED connectors
20-pin Front panel connector
Chassis intrusion, SMBus, WOL, and WOR connectors
(Continued on the next page)

xi
PRL-DLS specifications summary
4Mb Flash ROM,Award BIOS with ACPI, DMI, Green, PnP
features, and Enhanced Server BIOS features
Extended ATX form factor: 12 in x 13 in (30.5 cm x 33 cm)
Device drivers
Management software
Utilities
Contact information
BIOS features
Form Factor
Support CD contents
* Specifications are subject to change without notice.

Chapter 1
This chapter describes the features of the
PRL-DLS motherboard. It includes brief
explanations of the special attributes of the
motherboard and the new technology it
supports.
Product introduction

ASUS PRL-DLS motherboard
Chapter summary
1.1 Welcome! ........................................................ 1-1
1.2 Package contents .......................................... 1-1
1.3 Special features ............................................. 1-2
1.4 Motherboard overview................................... 1-6

ASUS PRL-DLS motherboard user guide 1-1
1.1 Welcome!
Thank you for buying the ASUS
®
PRL-DLS motherboard!
The ASUS
PRL-DLS motherboard delivers a host of new features and
latest technologies making it another standout in the long line of ASUS
quality server motherboards!
The PRL-DLS incorporates dual Intel
®
Xeon™ and Gallatin™ processors
in 603-pin package coupled with the ServerWorks
®
Grand Champion
Super-Lite (GCSL) System Set to deliver a reliable and high performance
dual-processor server platform.
Before you start installing the motherboard, and hardware devices on it,
check the items in your package with the list below.
1.2 Package contents
Check your PRL-DLS package for the following items.
ASUS PRL-DLS motherboard
Extended ATX form factor: 12 in x 13 in (30.5 cm x 33 cm)
ASUS PRL-DLS support CD
I/O shield
80-conductor ribbon cable for UltraDMA100/66//33 IDE drives
68-pin LVD SCSI cable for Ultra 160/320 SCSI devices
Ribbon cable for a 3.5-inch floppy drive
Bag of extra jumper caps
PRL-DLS User Guide
LSI SCSI Controller User’s Manual
If any of the above items is damaged or missing, contact your retailer.

1-2 Chapter 1: Product introduction
1.3 Special features
1.3.1 Product highlights
Latest processor technology
The PRL-DLS motherboard supports both Intel
®
Xeon™ and Gallatin™
processors via dual 604-pin surface mount ZIF sockets. The processor
features the Intel
®
NetBurst™ micro-architecture that includes hyper-pipelined
technology, a rapid execution engine, a 533MHz or a 400MHz system bus,
and an execution trace cache to offer a significant increase in performance.
See page 2-4 for more information.
DDR memory support
Employing the Double Data Rate (DDR) memory technology, the PRL-DLS
motherboard supports up to 4GB of system memory using PC2100/1600
registered ECC DDR DIMMs. The ultra-fast 200MHz memory bus doubles
the speed of the PC100 SDRAM to deliver the required bandwidth for the
latest 3D graphics, multimedia, and Internet applications. See page 2-10.
Dual-channel Ultra-160/320 SCSI
The LSI
®
53C1010R 64-bit/66MHz PCI SCSI controller, or the
LSI
®
53C1030 64-bit/100MHz PCI-X SCSI controller , is onboard to support
dual-channel Ultra-160/320 SCSI connectors that provide high-speed data
transfer interfaces.
Advanced 64-bit PCI-X slots
The 64-bit/100MHz PCI-X slots onboard maximizes I/O bandwidth for the
next generation 64-bit PCI-X cards that support 100MHz bus. The PCI-X
specification 1.0a allows full peer-to-peer transactions between PCI buses
and provides options for intelligent I/O and server management cards.
ATA/100 IDE support
The dual-channel bus master IDE connectors comply with the ATA/100
protocol and supports ATA/100, Multi-Word DMA Mode2, PIO modes 3 & 4
IDE devices such as ATAPI IDE CD-ROM, CD-R/RW, ZIP, and LS-120
drives.

ASUS PRL-DLS motherboard user guide 1-3
Third IDE Channel support
The CSB6 South Bridge chip provides a third IDE with PIO mode 3/4
support which provides more device connectivity in this server system.
Onboard LAN
The motherboard comes with the Intel
®
82540 Gigabit Ethernet controller
and the Broadcom 5703C Gigabit Ethernet controller to support the latest
LAN technologies.
Onboard VGA
The ATI Rage-XL PCI-based VGA controller integrates an 8MB display
SDRAM to provide onboard video solution.

1-4 Chapter 1: Product introduction
1.3.2 Value-added solutions
Temperature, fan, and voltage monitoring
The CPU temperature is monitored by the ASUS ASIC to prevent
overheating and damage. The system fan rotations per minute (RPM) is
monitored for timely failure detection. The system voltage levels are
monitored to ensure stable supply of current for critical components.
Dual function power switch
While the system is ON, pressing the power switch for less than 4 seconds
puts the system to sleep mode or to soft-off mode, depending on the BIOS
setting. Pressing the power switch for more than 4 seconds lets the
system enter the soft-off mode regardless of the BIOS setting.
Remote Ring In
This feature allows the system to wake up remotely through an internal or
external modem, if present.
Wake-Up support
The motherboard includes Wake-On-LAN, Wake-On-Ring, and BIOS
Wake-Up features.
Server management
The motherboard comes with an ASMC connector that supports the
optional ASMC-HE/ME/LE card to comply with server reliability, availability,
and serviceability requirements. Remote management response via
remote diagnostics and troubleshooting still works even when the
operating system has stopped functioning.
ACPI ready
The Advanced Configuration power Interface (ACPI) provides more energy
saving features for operating systems that support OS Direct Power
Management (OSPM).
Concurrent PCI
This feature allows multiple PCI transfers from PCI master buses to the
memory and processor.
