Binatone F350 - EDITION 5 User manual

User Guide
F350
8
th
edition
www.binatonegps.com
Binatone Navigation software
Binatone Helpline (for UK only)
Monday to Friday from 9:00am to 5:00pm
Tel : [phone]
** Please note that all calls are charged at local rate

IMPORTANT
1
IMPORTANT
Satellite signals are required for this product to function in Navigation Mode.
There may be occasions within your home or surrounding area when the signal
strength is limited and Navigation may not be possible.
This is quite normal for products of this type.
You can check the number of satellite signals that the unit is receiving and the
strength of those signals by viewing the GPS Receiver.
Unpacking your Binatone Navigation System
In the box you will find
·
GPS navigation device
·
Car mounting kit
·
In-car charger
·
USB cable
·
User guide
·
Stylus
Keep the packaging materials in a safe place in
case you later need to transport the unit. Keep your
sales (till) receipt, which is your guarantee. Before
you can use the unit, you’ll need to fully charge the
battery as described on page 6, please also read
the notes on the page 2.
WARNING:
Your GPS device operates under open sky
conditions in order to receive a satellite signal.
Please ensure that you are not using the device
indoors or in areas where the satellite signal is
weak.
For the first time of use or after a few days of no
use, it may take up to 10 minutes to acquire a
satellite signal. It is recommended to be stationary
during the start up process.
*USB cable can be either used to charge your device with your computer or
update your system. Charging via the USB cable will take much longer than by
mains/car charger and is not advised.

IMPORTANT
2
Safety
The Global Positioning System
The Global Positioning System (GPS) is a satellite based system that provides
location and timing information around the globe. The GPS is operated and
controlled under the sole responsibility of the Government of the United States of
America, who are responsible for its availability and accuracy. Any changes in
GPS availability and accuracy, or in environmental conditions, may impact the
operation of you Binatone Personal Navigation Device (PND).
Using Your PND in the Car
When using your PND while driving it is essential that you drive with due care
and attention. Never modify the settings or program you PND while driving. Only
look at the PND map when it is safe to do so. When mounting the PND in your
car make sure that it does not obscure your view or impede the operation of any
driving controls.
Prohibited Areas
Do not operate your PND in hospitals or near any electrical medical equipment.
Do not operate your PND in aircraft.
Do not operate while on a petrol station forecourt.
Battery
Your PND uses a Li-polymer battery. Do not use it in humid, wet or corrosive
environments. Do not operate or store your PND in high temperatures (>60 ℃ ) or
in direct sun light. Do not pierce or break the battery casing.
Failure to follow these cautions will invalidate the warranty and may
cause the battery to leak acid, become hot, explode or ignite and
cause injury or damage.
If you come into contact with leaked battery acid wash the contact
area thoroughly and seek medical attention.
The Li-polymer battery contained in this unit must be recycled or
disposed of properly.
Do not dispose of in household waste or burn.

CONTENTS
3
CONTENTS
Important………………………………………………………………………. 01
In the Box ……….………………………………………………………... 01
Safety …………………………………………………………………………… 02
The Global Positioning System ……………………………………………02
Using Your PND in the Car .…………………………………………….. 02
Prohibited Areas .…………………………………………………….…… 02
Battery..…………………………………………………………………….. 02
Contents .………………………………………………………………………. 03
Quick Start Guide …………………………………………………………… 06
Position of the Controls ………………………………………………… 06
Charging the Battery ……………………………………………………. 07
SD Memory Card ………………………………………………………... 07
Car Adaptor ……………………………………………………………… 07
Turning the Sat Nav Unit On/Off ……………………………………….. 08
Turning the Sat Nav Unit Off (Sleep Mode) .………………………….. 08
System Reset ……………………………………………………………. 08
Windscreen Holder Installation ………………………………………… 09
Getting Started
…….…………………………………………………………. 10
Starting Up ... ……………………………………………………………… 10
Settings ……………………………………………………………………. 11
Multi-Media ………………………………………………………………… 12
Picture Viewer..……………………………………………………... 12
Document Viewer …………………………………………………... 13
GPS Receiver ……………………………………………………………… 14
Additional maps and upgrades …………………………………………… 14

CONTENTS
4
NAVIGATION
1. Introduction.…………………………………………………………. 15
1.1 GPS connection.……………………………………………… 15
2. Getting Started...……………………………………………………… 16
3. Navigational Map Screens.………………………………………….. 17
3.1 Free Navigation………………………………………………….. 17
3.2 Route Navigation………………………………………………… 18
4. Browsing the Map……………………………………………………. 19
5. Navigation…………………………………………………………….. 19
5.1 Free navigation…………………………………………………... 19
5.2 Route Navigation………………………………………………… 19
6. Go to…………………………………………………………………… 19
6.1 Entering an Address/Postcode……………………………… 20
6.2 Searching for a POI (Point of Interest)………...…………… 22
6.2.1 POI near Current Position…………………………… 22
6.2.2 POI in City…………………………………….……….. 23
6.3 Selecting an Entry from the Address Book………………… 24
6.4 Selecting a Recent Destination……………………….…….. 24
6.5 Selecting a Point on the Map………………………………… 24
6.6 Entering a set of Co-ordinates………………………………. 25
6.7 To Navigate Directly Home……………………..…………… 26
7. Map Options………………………………………………………….. 26
7.1 North Up/Heading Up………………………………...…………. 26
7.2 3D/2D……………………………………………………………... 27
7.3 Motorway Sign Post…………………………………………….. 27
7.4 Voice Guidance………………………………………………….. 28
7.5 Auto Zoom………………………………………………………... 28
7.6 Simulation Speed…………………………………………..……. 28
8. Settings……………………………………………………………..… 28
8.1 Language………………………………………………………… 29
8.2 Safety Alert………………………………………………..…... 29
8.3 Trace Record…………………...……………………………….. 29
8.4 Address Book…………………...………………………………. 30
8.4.1 Add an Entry…………………………………………. 31
8.4.2 Edit an Entry…………………………...………………. 31
8.4.3 Delete an Entry………………………...……………… 32
8.5 Day/Night Mode…………………... ……... ……... ....….. 32
8.6 Set Home Address…………………………………………… 32
8.7 GPS Status………………………………………………….… 33
8.8 Miles/Kilometre……………….….…………………………..… 33
8.9 About……………………………………………………………… 33
8.10 Time Zone………………………….……………………..……. 33

CONTENTS
5
8.11 Brightness…………………………………………………………. 34
8.12 Calibration…………………………………………………….…… 34
9. Route Plan…………………………………………………..……….....…… 34
9.1 Navigating…………………………………………………….…….. 34
9.2 Waypoints……………………………………………………….….. 35
9.3 Simulate………………………………………………………….……. 35
9.4 Route Options…………………………………………………….…… 36
10. Route Navigation Menu………………………………………….…… 36
10.1 Route Plan………………………………………………………… 36
10.2 Detour……………………………………………………………… 36
10.3 Cancel Route……………………………………………………… 37
10.4 Go to……………………………………………………………….. 37
10.5 Route Information………………………………………………… 37
10.6 Map Options………………………………………………………. 37
10.7 Settings……………………………………………………………. 37
Frequently asked questions……………………………………. 38
The map contains an error / POI’s are missing……………………… 38
I am experiencing problems getting a GPS fix………………………. 38
Where can I get technical support?…………………………………… 38
Where can I get additional maps and guides……………….……….. 38
Guarantee and service
……………………………………….………. 39
Technical Specifications
…………………………………….………. 40
EC Declaration of Conformity …………………………………….. 41

QUICK START GUIDE
6
Quick Start Guide
Please make sure that you read all of the information contained within this user
guide before operating this unit.
If you experience any problems, please go through the user guide before contacting
the customer helpline.
Position of the controls
1. Touch Screen
2. Charge Indicator– Displays the battery charging status.
Red; charging, Green; fully charged.
3. On/Off button – Turn On the unit when it is Off or in Sleep mode.
Turn the unit to Off or put into Sleep mode during operation.
4. Reset – System reset switch.
5. Speaker – For voice guidance instructions.
6. Memory Card Slot – Compatible with MicroSD cards. Do not remove a
memory card while it is in use.
7. Power Connection USB Port – For charging and data transfer.
8. Headphone Jack– Allows connection to external headphones.
2
3
1
6
7
8
4
5

QUICK START GUIDE
7
Charging the Battery
Before using your GPS device for the first time, we recommend that you charge the
unit for 5 hours via the mains/car charger, or until the charge light turns green.
Plug the mains/car charger into the USB socket.
NOTE: Charging via USB cable. It is possible to charge the unit via the USB cable
but the charge time will be significantly increased. Also if the battery is very low the
unit will not fully charge.
The charging indicator on the unit will light up red. When fully charged the red light
will turn green.
When using the GPS device in your car, we recommend that you always use the car
charger in order to maintain the battery level.
If you have a MicroSD memory Card, you may install it refer to the picture
(below)
Switch the unit off first before installing or removing the MicroSD card.
When installing it can only be fitted one way – the contacts should be away from you
and the cut-off corner at the top (as shown above). Slide the card in and push it in so
that it clicks into place.
Once the card is installed it does not need to be removed.
If you need to remove the card, push the card in and it will eject from the slot.
Car Adapter
When using your PND in the car we recommend that you always use the in-car
charger to power the unit, especially on long journeys.
Plug the in-car charger into the USB socket of the unit. Pug the other end of the
adapter into the car’s cigarette-lighter / 12V DC socket.
The adaptor is also compatible with 24V DC sources, as found in many heavy goods
vehicles.

QUICK START GUIDE
8
Turning the Sat Nav Unit On/Off
Press and hold the On/Off button on the top of the unit for around 3 seconds, the unit
will power up and display the Menu screen.
Press and hold the On/Off button for
around 3 seconds during operation,
the unit will show the following display,
Turning the Sat Nav Unit Off or
Sleep Mode
Press the sleep icon to put
the unit into sleep mode. Press and
hold the On/Off button again, to bring
the unit out of sleep mode. When
brought out of sleep mode the unit will
show the same screen as when the
unit entered sleep mode.
Press the Off icon to turn the unit Off.
There is a 10 second timer which starts to count down, if there is no selection made
within 10 seconds, the unit will turn off automatically.
Note: If the unit is not to be used for a long period of time it is advised that you switch
the unit Off.
System Reset
Under extreme circumstances it may be necessary to reboot the system. Reset the
system if the following situation occurs:
• Long delay experienced with screen refresh rate or operation, resulting in an
inoperable unit.
• The system will not turn Off with the power button.
• No response with selection made on the screen.
The reset button can be found at the rear of the unit. Insert the tip of the stylus pen
or a small blunt implement into the reset switch hole in order to press. The system
will be immediately reset.

QUICK START GUIDE
9
Windscreen Holder Installation
The car mount has a suction pad that fits to the windscreen or a flat area on the
dashboard.
A. Fitting to windscreen
Pull the lever away from the suction pad. Place the pad on the widescreen and push
the lever towards the pad until it clicks into place.
B. Fitting the holding bracket
It is best to fit this to the unit before it is attached to the windscreen.
Slide the bracket onto the securing lug on the end of the ball mount at the end of the
car mount and then push down firmly, until it clicks in to place. The bracket can only
be fitted one way.
C. Fitting the Unit
Slide the unit into the bottom of the bracket and carefully push the unit up and back
until it clicks into place at the top.
To remove the unit from the car mount; Press and lift the tab at the top of the bracket
then pull the unit forward and out of the bottom of the bracket.
To remove the Car mount from the windscreen; Lift the lever away from the
windscreen, then gentle pull the tab on the suction cup to release the suction as you
pull the mount away from the windscreen.

MAIN MENU
10
Starting Up
Press the On/Off button on the top until the following screens are displayed,
When you press MENU, the following screens will be displayed:

MAIN MENU
11
Settings
NOTE: You do not need to enter the SETTINGS menu before you start to navigate.
If you press on the SETTINGS icon the following screen is displayed.
To exit this page or exit any subsequent page, press the at the bottom of the
screen. Any changes in settings will not be saved if you exit by using this key.
Volume
Press ’volume’ you can modify the volume level of the voice prompts. You can
increase or decrease the level by clicking “ ” or “ ”. This can also be done via
the navigation software later. Pressing the speaker button will mute/un-mute the
speaker.
is shown when un-muted, is shown when muted. Clicking “ ” or “
” can release the mute status.
Press to confirm and exit
Backlight
Press ‘Backlight’ to change the brightness of the screen. You can make it darker or
brighter by clicking “ ” or “ ”. This can also be done via the navigation software
later.
Press to confirm and exit
Date & Time
This device can auto-set the current date and time by receiving 3 GPS signals.
Time Zone this is defaulted to the area of sale.
To change the date & time, select the item to be changed e.g. for the date select Day,
Month or Year, so that it is highlighted blue. Then use the and keys, to
increase or decreased the value.
Press to confirm and exit.
Power
The power page contains the information on your battery level.

MAIN MENU
12
Language
Press ”Language” to change the language. Use the and keys to
scroll between further language options. Select the language you desire from the
available options so that it is highlighted white. Then press to confirm and exit.
About
The About page contains information about your operating system software version.
It also allows you to default the unit or to calibrate the screen to your touches.
Default
The unit will be returned to how it was when it left the factory. After selecting this
option you will be asked to confirm the reset.
Note : If you encounter any problems when connecting your unit to a PC using
ActiveSync. Carry out a reset of the unit before trying again.
Calibration
This function calibrates the unit to respond to your screen taps. You will need to use
this function only if the unit begins to respond inconsistently to your screen taps.
After selecting follow the on screen directions. Once the calibration has been
completed, press anywhere on the screen to return to the previous menu.
Multi Media
NOTE: if you press on the MULTI MEDIA icon the following screen is displayed.
Picture Viewer
This device supports, .bmp, .jpg and .gif file formats only (recommended picture size
for optimum usage: 500kb – it is not recommended to view pictures over 2mb). Press
the “Picture viewer” to show a list of names for all the picture files then click on the
file you want to view.
To view pictures (bmp and jpeg formats only):
1) Copy all the pictures you want to view onto a MicroSD card.
2) Insert your MicroSD card into the PND.
3) Select Multi Media and then the Picture viewer option.

MAIN MENU
13
4) Click on SDMMC folder to open it and then click on a picture or a further folder.
To continue searching or to load a photo it into the viewer. To go back through
the menu structure press the option “...”
The following screen will be shown:
Button function list of Picture Files:
1. Return : Press this to return back to the list of pictures on the unit.
2. Zoom out : Press to zoom out of the picture.
3. Zoom in : Press to zoom into the picture.
4. Previous : Press to view the previous picture in the list.
5. Forward : Press to view the next picture in the list.
6. Full screen : Press to enlarge the picture so that it fills the whole screen. You can
now use the stylus to scroll around the picture. To return back to the above
screen, double tap the screen. You can also double tap to switch to full screen
mode.
7. Rotate : Press to rotate the image 90 degree right.
8. Document name : This shows the file name of the current document.
Document Viewer
This device supports, txt file format
viewing only, as with the picture
viewer copy the files you want to read
to a SD card. Press the “Doc Viewer”
you can then access the SDMMC
folder. The procedure for viewing
documents is the same for viewing
pictures. But once loaded the
following screen will be shown.

MAIN MENU
14
Button function list of Document Files:
1. Return : Press this to return back to the list of pictures on the unit.
2. Page number : This shows the number of the current page and the total number
of pages in the document.
3. Page up : Press to scroll to the previous page.
4. Page down : Press to scroll to the next page.
5. Document name : This shows the file name of the current document.
GPS Receiver
NOTE: This page is for information only. You can view the number of satellite signals
the unit is receiving also the strength of these signals.
This page gives your current position in degrees longitude and latitude, your current
speed and the status of your position, i.e. Fixed 3D or Fixed Invalid etc.
The compass circle shows the satellites that the unit is receiving and the bar chart
shows the signal strength for these satellites
NOTE:
At least four GPS signals are required for the PND to function.
There may be occasions within your home or surrounding area when the
signal strength is limited and GPS navigation may not be possible.
This is quite normal of products of this type.
Additional maps and upgrades:
Please visit www.binatonegps.com or contact the helpline on 0845 3459677 for
more information.

NAVIGATION
15
1 Introduction
You have chosen a cutting-edge navigation system. Congratulations! Please enjoy using
it. This navigation system leads you straight to your destination, whether you are travelling
by car or on foot. You can navigate and plan your route with an easy-to-use and intuitive
interface, just by using your finger. You can also use this application to plan your trip to
suit your personal preferences and interests and to save interesting destinations before
you set off on your journey.
This manual leads you through the main features of the system.
1.1 GPS connection
Your navigation device uses GPS technology for navigation. The device receives signals
from a number of GPS satellites in order to determine your current position.
•
Place your navigation device in a location with an unobstructed view to the sky to set up
your first satellite connection. In the car this will usually mean mounting the unit on the
lower part of the windscreen.
Note; It may take up to 10 minutes to establish the first connection. Subsequent
connections will be faster (30 seconds to 1 minute), but if you have not used the unit for
several days or are far away from the last location where you used the unit, it may take up
to 10 minutes again to find a strong signal.

NAVIGATION
16
2 Getting Started
Please make sure that the battery in your device is charged (see page 6).
Switch on the unit and from the menu select Navigation. The navigational software will
start to load.
First you will see the warning statement screen.
Tap on “Accept” to confirm that you have read the
statement and to continue. If you do not wish to
be shown this screen in the future check the box
next to “Don’t show this statement again”. You will
now be shown the Binatone screen, which shows
the progress of the loading software on the yellow
bar at the bottom.
Once the software has loaded you will be shown the
Free Navigation Menu screen, this is the starting
point for all your navigating needs.
For more information on free navigation mode (see
page 19).
In order to enter destinations and access the many
settings of the navigational software, tap Menu. This
will then take you to the Free Navi Menu screen.
You can choose from the 3 following options;
Go to – Opens the Search Menu screen. From here
you can select a point to navigate to.
Map Options – Allows you change the way the map
looks and behaves during navigation.
Settings – Allows access to the main settings menu
of the unit, which you can set to your personal
preference.
- Tap to return to the Free Navigation mode
- Tap to exit Navigation. You will be asked to confirm if you wish to exit, tap
Yes to exit, tap No to cancel and return to the Free Navi Menu.
- Returns you to either the Free Navigation screen or Route Navigation
screen if a route has been planned. This option is always available when not on any
Navigation screen.

NAVIGATION
17
3 Navigational Map Screens
The navigational map screens will be the most frequently used screens. The two
navigation screens are free navigation and route navigation and are shown below. Though
the screens look very similar there are some differences.
3.1 Free Navigation
1 Zoom out – Tap to zoom out on the maps.
2 Compass – Shows your current heading by means of a letter, while the red part of
the compass needle always points North. (Tapping will change
between 2D & 3D view).
3 GPS reception – Shows the current status of the GPS signal, Shown greyed out if you
do not have a valid signal and green if you do. Tap to enter the GPS
status screen (see page 31).
4 Time – Shows the current time.
5 Current position – Shows you current position in Longitude and Latitude co-ordinates.
6 Menu button – Tap to access the Free Navi Menu screen. (Only when in Free
Navigation)
7 Map scale – Show a scale bar which changes as the map zoom level is altered
8 Position icon – Shows your current position on the map as well as showing your
current direction of travel.
9 Volume – Tap to access the volume control menu.
10 Zoom in – Tap to zoom in on the map.

NAVIGATION
18
3.2 Route Navigation
11 Speed limit– Shown when you exceed the speed limit of the current road, if
switched on via the settings (see page 29).
12 POI icon – Show the position of a point of interest.
13 Turn indicator – Shows a graphical representation of the next manoeuvre and the
distance to the manoeuvre. Tap to replay the voice instruction.
14 Current road – Shows the name of the road you are currently on.
15 Menu button – Tap to access the navigation options. (Only when in Route
Navigation)
16 Arrival time – Shows the estimated time you will arrive at your destination.
Distance – Shows the remaining distance to your destination.
17 Route – Indicates the planned route to be followed.
18 Next road – Shows the name of the road you will be using next.

NAVIGATION
19
4 Browsing the Map
When in Free Navigation or Route Navigation it is possible to browse the map so that you
can look at parts of the map which are currently not shown.
To move the map around use the stylus (if provided) or your finger to press and hold on a
point on the map, then drag the map in the opposite direction you want to look at. E.g. to
view the map above the currently shown section, press on the screen and move the stylus
(if provided) or your finger down, the map will then re-draw to show the new section of
map.
You can also change the zoom level of the map to be shown more detail or a larger
section of the map. In order to zoom simply tap on the and . Each tap will zoom the
map one level.
You can tap on roads or Point of Interest icons shown on the map to be given more
information relating to that point.
After moving the map from the starting location you will see the following icon appear
, Tapping on this icon will return you to your current or last known GPS position.
5 Navigation
There are two modes of navigation; Free navigation and Route Navigation.
5.1 Free navigation
In free navigation the unit does not have a planned route for you to follow, so simply plots
your GPS position on the map and then follows your movement as you drive. The unit
shows you the current time and date, as well as your current position in latitude and
longitude co-ordinates.
5.2 Route Navigation
In route navigation the unit directs you via the map and with spoken directions to your
chosen destination. In order to plan a route you need to have a valid GPS signal, this can
be easily checked by looking at the GPS reception screen on the free navigation screen. If
the icon is greyed out then there is no valid signal, if the icon is white with green signal
waves then you have a valid GPS signal and navigation is possible.
From the Free Navi Menu screen select Go to, this allows you to enter your destination.
6 Go to
Tapping this opens up the Search menu screen,
from here you can enter a destination to
navigate too in several different ways. Each will
be described in turn in the pages that follow.
