Biostar K8VHA PRO User manual

iEnglish
BIOSTAR Motherboard
FCC Statement
Thisequipmenthasbeentested andfound to complywith thelimitsforaClass
Bdigitaldevice, pursuantto Part15 oftheFCC rules. Theselimitsaredesigned to
providereasonableprotection againstharmfulinterference in aresidentialinstallation.
Any changesormodification madeto thisequipmentvoidtheuser’sauthority
to operatethisequipment.
Thisequipmentgenerates,uses, and radiateradio frequency energy and, ifnot
installed and usedin accordance with theinstructions, may causeharmfulinterference
to radio communications. However, thereisno guarantee thatinterference will not
occurin aparticularinstallation. Ifthisequipmentdoescauseharmfulinterference to
radio ortelevisionreception,which can bedetermined by turningtheequipmentoff and
on, theuserisencouraged to try to correcttheinterference by oneormoreofthe
followingmeasures:
* Reorientorrelocatethereceivingantenna.
* Increasetheseparation between theequipmentand receiver.
* Connecttheequipmentintoan outleton acircuit differentfromthatto which
thereceiverisconnected.
* Consult thedealeroran experienced radio/TVtechnician forhelp.
* All externalcablesconnectingto thisbasicunit mustbeshielded.
C.D.C.Statement
ThisdigitalapparatusdoesnotexceedtheClassBlimitsforradionoiseemissions
fromdigitalapparatusassetoutin theradio interference regulationsortheCanadian
DepartmentofCommunications.
CEMark
Thisequipmentisin conformity with theEMCdirective.

iiEnglish
BIOSTAR Motherboard
Overview
Theinformation in thisdocumentissubjectto changewithoutnotice and
should notbeconstrued asacommitmentby themanufacturer.
Themanufacturerassumesno responsibility forany errorsthatmightappear
in thisdocument.
Thesoftwaredescribed in thisdocumentisfurnished underalicenseand may
beusedorcopied only inaccordance with thetermsofsuch license. No responsibility
isassumedfortheuseorreliability ofsoftwareorequipmentthatisnotsuppliedby the
manufactureroritsaffiliated companies.
CopyrightNotice
No partofthismanualmay bereproduced ortransmitted in anyformorby any
means, electronicormechanical, photocopying, recordingorotherwise, stored in any
retrievalsystemofany naturewithoutthepriorwrittenpermission ofthemanufacturer.
Trademark
Otherproductandcompany namesmentioned herein may betrademarksand/
orservice marksoftheirrespectiveowners.
Inteland Pentiumareregistered trademarksofIntelCorporation.
Nvidiaand nforce isregistered trademark ofNvidia.
Sisisregistered trademark ofSilicon Integrated SystemsCorporation.
PS/2 isregistered trademarkofInternationalBusiness MachinesCorporation.
VIAisregistered trademark ofVIATechnologies, Inc.
ATIisregistered trademark ofATITechnologies, Inc.
AMDisregistered trademark ofAdvanced Micro Devices, Inc.

iii English
BIOSTAR Motherboard
ImportantSafetyInformation
1. Pleaseread thesesafety instructionscarefully.
2. Pleasekeep thisUser’sManualforlaterreference.
3. PleasedisconnectthisequipmentfromACoutletbeforecleaning. Don‘tuse
liquid orsprayed detergentforcleaning. Usemoisturesheetorclothefor
cleaning.
4. Forpluggableequipment, thesocket-outletshall beinstalled neartheequip-
mentand shall beeasily accessible.
5. Pleasekeep thisequipmentfromhumidity.
6. Lay thisequipmentonareliablesurfacewhen install. Adrop orfallcouldcause
injury.
7. Do notleavethisequipmentin an environmentunconditioned, storage
temperatureabove40°C, it may damagetheequipment.
8. Theopeningsontheenclosureareforairconvectionhenceprotecttheequipment
fromoverheating. DO NOTCOVERTHEOPENINGS.
9. Makesurethevoltageofthepowersource whenconnecttheequipmentto the
poweroutlet.
10. Place thepowercord suchaway thatpeoplecan notstep onit. Do notplace
anythingoverthepowercord. Thepowercord mustberated fortheproduct
and forthevoltageand currentmarked on theproduct’selectricalratingslabel.
Thevoltageand currentratingofthecord should begreaterthan thevoltageand
currentratingmarked on theproduct.
11. All cautionsand warningson theequipmentshould benoted.
12. If theequipmentisnotuseforlongtime,disconnecttheequipmentfrommains
to avoid beingdamaged by transientover-voltage.
13. Neverpourany liquid intoventilation openings,thiscouldcausefireorelectrical
shock.
14. Neveropen theequipment. Forsafety reason, qualified service personnel
should only open theequipment.
15. If oneofthefollowingsituationsarises, gettheequipmentchecked by service
personnel:
a. ThePowercord orplugisdamaged.
b. Liquid haspenetrated into theequipment.
c. Theequipmenthasbeen exposed to moisture.
d. Theequipmenthasnotwork well oryou can notgetit work accordingto
user‘smanual.
e. Theequipmenthasdropped and damaged.
f. If theequipmenthasobvioussign ofbreakage

ivEnglish
BIOSTAR Motherboard
TableofContents
FCC Statement..................................................i
Overview..........................................................ii
ImportantSafetyInformation...................iii
Section1.LayoutofK8VHAPro...............1
Section2.ComponentIndex .......................2
Section3.K8NHAProFeatures..................3
Section4.Packagecontents.........................4
Section5.Installationand Setup ...............7
Section6.TroubleShooting......................16
StudioFun!TM..................................................18
WarpSpeederTM..............................................19

11
11
1EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
Section 1. Layout of K8VHA Pro
NOTE: “ ” represents the first pin.
JKBMS1
K/B
&
Mouse
Parallel Port
JCOM2
JPRNT1
COM2
COM1
JUSBLAN1
USB
&
LAN
JCOM1
JAUDIO
USB
&
1394
JATXPWR2
JKBV1
1
1
JUSBV2 JATXPWR1
K8T800
CPU1
AGPSLOT
PCI1
PCI2
PCI SLOT
PCI4
PCI5
PCI3
PCI SLOT
PCI SLOT
PCI SLOT
PCI SLOT
SPDIF_OUT
1
JAUDIO1
1
213
14
Codec
JCDIN11
JWOL1
1
CNR1
JGAME11
2
15
16 2
9
10
1
J1394B1
IEEE 1394
CHIP
JCMOS1
1
JPANEL1
12
FLOPPY DISK CONN.
FDD1
DIMM1
DIMM2
JCFAN1
JUSB4
29
110
JUSBV4
1
JUSB3
291 10
JUSBV3
1
V
T8237
23
24
JSFAN1
1
PRIMARYIDE CONN.
SECONDARYIDE CONN.
BAT1
IDE1
IDE2
JSATA2
17 4
JSATA1
17 4
Winbond
I/O
IDE RAID
Chip
(optional)
IDE4
IDE3
LAN
Phy
(op tion al)
Wireless
LAN Chip
(optional)
LAN Chip
CNR SLOT
Wireless
LAN SLOT
BIOS
1
JUSBV1

22
22
2
EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
Section 2. Component Index
This section helps you to locate the components in the motherboard and to find
the details about them.
A. ATXPowerConnector(JATXPWR1) B. ATXPowerConnector(JATXPWR2)
C. PowerSourceSelectionforKeyboardandMouse(JKBV1) D. PowerSourceSelectionforUSB(JUSBV2)
E. PowerSourceSelectionforUSB(JUSBV1) F. BackPanelConnectors
G. CPUFanConnector(JCFAN1) H. AcceleratedGraphicsPortSlot(AGP1)
I. PCIBUSSlots(PCI1-5) J. DigitalAudioConnector(SPDIF_OUT)
K. FrontAudioHeader(JAUDIO1) L. CD-ROMAudio-InHeader(JCDIN1)
M. WakeOnLANHeader(JWOL1) N. WirelessLANSlot(optional)
O. CommunicationNetworkRiserSlot(CNR1) P. GamePortHeader(JGAME1)
Q. Front1394header(J1394B1) R. IDE-RaidConnectors(IDE3-4)(optional)
S. ClearCMOSFunction(JCMOS1) T. FrontPanelConnector(JPANEL1)
U. SystemFANHeader(JSFAN1) V. PowerSourceSelectionforUSB(JUSBV3)
W. FrontUSBHeader(JUSB3) X. PowerSourceSelectionforUSB(JUSBV4)
Y. FrontUSBHeader(JUSB4) Z. SerialATAConnectors(JSATA1-2)
A1. IDEConnectors(IDE1-2) B1. FloppyDiskConnector(FDD1)
C1. DIMMModules(DIMM1/DIMM2)
K8T800
Codec
IEEE 1394
CHIP
VT8237
Winbond
I/O
SATA-Raid
Chip
(optional)
LAN
Phy
(optional)
Wireless
LAN Chi
p
(
o
p
tional
)
LANChip
BIOS
A
B
C
D
F
H
I
J
K
L
M
NO
PQ
RS
T
UV
W
XYZ
BAT1
A1
B1
C1
G
E

33
33
3EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
Section 3. K8VHA Pro Features
In this section, you shall find all the information about the
motherboard in your computer, including its features, layout,
component index, various jumpers, headers, connectors, and also
the installation guide to help you a quick and correct installation
of your system.
A. Hardware
CPU * Supports Socket 754.
* Supports AMD AthlonTM 64 K8/ ClawHammerTM processor with 6.4 GB.
* Processor interface via Hyper-TransportTM Technology.
* 800/ 600/ 400/ 200 clock rates with “DoubleData Rate” style operation for
1600/ 1200/ 800/ 400 MT/s in both directions simultaneously.
Chipset
* North Bridge: VIA K8T800.
* South Bridge: VIA VT8237.
Main Memory
* Supports 72-bit (64-bits + 8-bits ECC) DDR SDRAM.
* Supports 266, 333, 400 and 200 MHz DDR technologies.
* Maximum memory size is 2 GB.
Super I/O
Chip: Winbond W83697HF.
- Low Pin Count Interface.
- Integrate hardware monitor functions.
Slots * Five 32-bit PCI bus master slots.
* One CNR slot.
* One AGP 4X/ 8X slot.
* One wireless LAN slot. (optional)

44
44
4
EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
On Board IDE
* Supports four IDE disk drives.
* Supports PIO Mode 5, Bride Mode and Ultra DMA 33/ 66/ 100/ 133 Bus
Master Mode.
LAN Chip (optional)
* Chip: Realtek RTL8100C/ RTL8110S.
* Supports 10 Mb/s, 100 Mb/s auto-negotiation operation. (1000Mb/s only
for RTL8110S.)
* Half/ Full duplex capability.
* Supports ACPI, PCI power management.
LAN PHY (optional)
* Chip: Realtek RTL8201BL.
* Supports 10/ 100 Mb/s operation. (1000Mb/s operation only for
RTL8110s)
* Half/ Full duplex operation.
* Supports MII interface.
Wireless LAN - Air LinkTM (optional)
* Chip: Realtek RTL8180.
* Full compliance with IEEE802.11b specifications.
* Supports Advanced Configuration Power management Interface (ACPI) and
PCI power management system for modern operating systems.
* Supports remote wake-up in both ACPI and APM environments.
* Keeps network maintenance costs low and eliminates usage barriers.
* Uses one RF card for Wireless LAN.
IEEE 1394 Chip
* Chip: VIA VT6307.
* Support 2 ports with transfer up to 400 mb/s.
* Compliant with PCI specification v2.2.
On Board AC'97 Sound Codec
* Chip: CMI9739A.
* Compliant with AC'97 specification.
* AC97 2.2 interface.
* Supports 6 channels.

55
55
5EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
IDE RAID Chip (optional)
* Supports RAID Level 0, RAID Level 1, RAID Level 0+1 and JBOD.
* Complies with PCI Local Bus Specification Revision 2.2.
*Dual channel master mode hard disk controller supporting four Enhanced IDE
devices.
* Transfer rate up to 22 MB/s to cover PIO mode 4, multi-word DMA mode 2
drivers and beyond.
* Extension to UltraDMA-133 interface for up to 133 MB/s transfer rate.
* Supports UltraDMA-mode0.
On Board Peripherals
a. Rear side
- 2 serial ports, 1 parallel port. (SPP/EPP/ECP mode)
- Audio ports in vertical position.
- 1 RJ-45 LAN jack. (optional)
- PS/2 mouse and PS/2 keyboard.
- 4 USB2.0 ports.
- 1 IEEE1394 (FirewireTM) connector. (optional)
b. Front Side
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88
Mbytes.
- 4 USB2.0 ports.
- 1 front audio header, 1 S/PDIF Out header.
- 1 IEEE1394 (FirewireTM) port. (optional)
Dimensions
ATX Form Factor: 24.4 cm x 30.5 cm (W X L)
B. BIOS & Software
BIOS *Award legal BIOS.
* APM1.2.
* ACPI.
* USB Function.
Software
* Supports WarpspeederTM, 9th TouchTM, BootBlockerTM, WinFlasherTM,
FLASHERTM and StudioFunTM (optional).
* Offers the highest performance for Windows 98 SE, Windows 2000,
Windows Me, Windows XP, SCO UNIX, etc.

66
66
6
EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
Section 4. Package contents
Checkwhat youhave boughtbefore youstart yourDIY action.
If there are anything missing, please contact your dealer
immediately.
* HDD Cable x 1
* FDDCable x 1
* User's Manual x 1
* Fully SetupDriver CD x 1
* StudioFun! Application CD x 1 (optional)
* USB 2.0 Cable x 1 (optional)
* S/PDIF Cable x 1 (optional)
* Rear I/O Panel for ATX Case x 1
* SerialATA Cable x 1 (optional)
* Serial ATA Power Switch Cable x 1 (optional)
* Front IEEE 1394 Cable x 1 (optional)

77
77
7EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
Section 5. Installation and Setup
In this section, you will learn how to install the CPU, DDR
Module, and also how to set up jumpers and all the information
about the components on the motherboard. Not only can you find
the installation steps, but also the details and locations of the
components on the motherboard.
1. CPU Installation
The motherboard supports VIA processor in the 754 pin package. The
motherboard uses a CPU socket called PGA754 for easy CPU installation. When you
are installing the CPU, make sure the CPU has a cooling fan attached on the right to
prevent overheating. If you do not find the cooling fan, contact your dealer and make
sure to install them before turning on the computer.
Step1: Pull the lever sideways away from the socket and then raise the
lever up to a 90-degree angle.
Step2: Look for the white dot/cut edge. The white dot/cut edge should
point towards the lever pivot. The CPU will fit only in the
correct orientation.
Step3: Hold the CPU down firmly, and then close the lever.
Step4: Put the CPU fan on the CPU and buckle it. Connect the CPU fan
power cable to the JCFAN1. This completes the installation.
2 Central Processing Unit: CPU
These fan headers support cooling fans built in the computer. Orient the fans to
make the heat sink fins to allow air flow to go across the onboard heat sinks instead of
the expansion slots. The fan wiring and plug may be different according to the fan
manufacturer. Connect the fan cable to the connector while matching the black wire to
the ground pin.
(1) CPU Fan Headers: JCFAN1
Pin Assignment
1 Ground
2 +12V
3 FAN RPM Sense
3
1
Step 2Step 1 Step 3 Step 4

88
88
8
EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
(2) System Fan Header: JSFAN1
Pin Assignment
1 Ground
2 +12V
3 FAN RPM Sense
3. Installing DDR Module
1. Unlock a DIMM slot by
pressing the retaining clips
outward. Align a DIMM on the
slot such that the notch on the
DIMM matches the break on
the slot.
2. Insert the DIMM firmly and
vertically into the slot until the
retainingchipsnap back inplace
and the DIMM is properly
seated.
4. DDR DIMM Modules: DIMM1/ DIMM2
DRAM Access Time: 2.5V Unbuffered/ no registered DDR SDRAM
PC2100/ PC2700/ PC3200 Type required.
DRAM Type: 128MB/ 256MB/ 512MB/ 1GB DIMM Module. (184 pin)
TotalMemorySizewithUnbufferedDIMMs
DIMM Socket
Location DDR Module Total Memory Size
(MB)
DIMM1
DIMM2
64MB/ 128MB/ 256MB/ 512MB/
1GB *1
64MB/ 128MB/ 256MB/ 512MB/
1GB *1
Max is 2GB
***Only for reference***

99
99
9EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
5. Wireless LAN Card Installation (optional)
1. Align the wireless LAN on the slot such a way that wireless LAN card
matches in the slot. Be sure to face the wireless LAN card with its compo-
nents towards the inner part of the motherboard.
2. Insert the wireless LAN card vertically and firmly into the slot till the
wireless card is properly seated.
3. Screw the brackets.
4. Insert the wireless LAN antenna by turning it clockwise.

1010
1010
10
EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
6. How to set up Jumpers?
The illustration shows how to set up jumpers. When the Jumper cap is placed
on pins, the jumper is “close”. If no jumper cap is placed on the pins, the jumper is
”open”. The illustration shows a 3-pin jumper whose pin1and 2 are “close” when
jumper cap is placed on these 2 pins.
Jumper open Jumper close Pin1-2 close
7. Jumpers, Headers, Connectors & Slots:
(1) Floppy Disk Connector: FDD1
The motherboard provides a standard floppy disk connector that supports
360K, 720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector
supports the provided floppy drive ribbon cables.
(2) Hard Disk Connectors: IDE1/ IDE2
The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO
Mode 0~4, Bus Master, and Ultra DMA 33/ 66/ 100/ 133 functionality. It has
two HDD connectors IDE1 (primary) and IDE2 (secondary).
The IDE connectors can connect a master and a slave drive, so you can connect
up to four hard disk drives. The first hard drive should always be connected to
IDE1.
(3) Peripheral Component Interconnect Slots: PCI1-5
This motherboard is equipped with 5 standard PCI slots. PCI stands for Pe-
ripheral Component Interconnect, and it is a bus standard for expansion cards.
This PCI slot is designed as 32 bits.
(4) Accelerated Graphics Port Slot: AGP1
Your monitor will attach directly to that video card. This motherboard sup-
ports video cards for PCI slots, but it is also equipped with an Accelerated
Graphics Port (AGP). An AGP card will take advantage of AGP technology to
improve video efficiency and performance, especially with 3D graphics.
(5) Communication Network Riser Slot: CNR1
The CNR specification is an open Industry Standard Architecture, and it de-
fines a hardware scalable riser card interface, which supports modem only.

1111
1111
11 EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
2
1
31
3 1
1
23
4
56
7
(6) Serial ATA Connector: JSATA1/ JSATA2
The motherboard has a PCI to SATAController with 2 channels SATAinterface.
It satisfies the SATA 1.0 spec and can transfer data with 1.5GHz speed.
Pin Assignment Pin Assignment
1 Ground 2 TX+
3 TX- 4 Ground
5 RX- 6 RX+
7 Ground
(7) IDE-Raid Connector: IDE3/ IDE4 (optional)
This connector supports RAID0 or RAID1 or RAID 0+1 configuration through
the onboard Parallel ATA (VT6410) controller chip. You can use the IDE
feature to set up a disk array configuration and to support additional IDE
devices. However, it can only support master mode IDE HDD.
(8) Clear CMOS Jumper: JCMOS1
This jumper helps you to clear the Real Time Clock (RTC) Ram in CMOS.You
can erase the CMOS RTC Ram data to clear the CMOS memory of date, time,
and system setup parameters.
JCMOS1 Assignment
Pin 1-2 Close Normal Operation (default)
Pin 2-3 Close Clear CMOS Data
* Clear CMOS Procedures:
1. RemoveAC power line.
2. Set the jumper to "Pin 2-3 Close".
3. Wait for five seconds.
4. Set the jumper to "Pin 1-2 Close".
5. Power on the AC.
6. Reset your desired password or clear the CMOS data.
(9) Front USB Header: JUSB3/ JUSB4
The motherboard provides two USB 2.0 Pin Header. USB 2.0 technology
increases data transfer rate up to a maximum of 480 Mbps, which is 40 times
faster than USB 1.1, and is ideal for connecting high-speed USB interface
peripherals such as USB HDD, digital cameras, MP3 players, printers, modems,
etc.
Pin Assignment Pin Assignment
1 +5V(fused) 2 +5V(fused)
3 USBP4- 4 USBP5-
5 USBP4+ 6 USBP5+
7 Ground 8 Ground
9 KEY 10 NC

1212
1212
12
EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
(10) Power Source Selection for USB: JUSBV1/ JUSBV2/ JUSBV3/ JUSBV4
(11) Front Panel Connector: JPANEL1
The connector is for electrical connection to the front panel switches and LEDs.
JUSBV1/ JUSBV2/ Assignment Description
JUSBV3/ JUSBV4
JUSBV1: 5V for USB port located at
the JUSBLAN1 connector port.
JUSBV2: 5V for USB port located at
the J1394_USB1 connector port.
JUSBV3: 5V for USB port located at
the JUSB3 connector port.
JUSBV4: 5V for USB port located at
the JUSB4 connector port.
Pin 1-2 close
+5V
JUSBV1: JUSBLAN1 port powered
with standby voltage of 5V.
JUSBV2: J1394_USB1 port powered
with standby voltage of 5V.
JUSBV3: JUSB3 port powered with
standby voltage of 5V.
JUSBV4: JUB4 port powerered with
standby voltage of 5V.
1 3
Pin 2-3 close
+5V Standby
Voltage
Note: 1. In order to support this function “Power-on the sytem via USB
devices”, "JUSBV1/JUSBV2/ JUSBV3/ JUSBV4" jumper cap should
be placed on pin 2-3 respectively.
2. Use +5V Standby Voltage for S3 mode.
Pin Assignment Function Pin Assignment Function
1 +5V 2 Sleep Control Sleep Button
3 NA Speaker 4 Ground
5 NA Connector 6 NA NA
7 Speaker 8 Power LED (+) Power LED
9 HDD LED (+) Hard Drive 10 Power LED (+)
11 HDD LED (+) LED 12 Power LED (-)
13 Ground Reset 14 Power Button Power-on Button
15 Reset Control Button 16 Ground
17 NA 18 KEY
19 NA IrDA 20 KEY IrDA Connector
21 +5V Connector 22 Ground
23 IRTX 24 IRRX
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
(+) (-)
(+) (-)(+)

1313
1313
13 EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
1
2
9
10
1

10
11
20
+5V
10 +12V 20 +5V
(13) Power Connectors: JATXPWR1/ JATXPWR2
The motherboard supports ATX power supply for the power system. Before
installing the power supply connector, please make sure that all components are
installed properly.
PIN Assignment PIN Assignment
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 Ground 13 Ground
4 +5V 14 PS_ON
5 Ground 15 Ground
6 +5V 16 Ground
7 Ground 17 Ground
8 PW_OK 18 -5V
9 Standby Voltage 19 +5V
PIN Assignment PIN Assignment
1 +12V 3 Ground
2 +12V 4 Ground
(14) Front 1394 Header: J1394B1
Pin Assignment Pin Assignment
1 A1+ 2 A1-
3 Ground 4 Ground
5 B1+ 6 B1-
7 +12V 8 +12V
9 KEY 10 NA
(15) Digital Audio Connector: SPDIF_OUT
The connector is used to connect SPDIF (Sony & Philips Digital Interconnect
Format) interface for digital audio transmission.
Pin Assignment
1 +5V
2 SPDIF_OUT
3 Ground
2
4
1

1414
1414
14
EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
1
21
4
13
(16) Front PanelAudio Header: JAUDIO1
The connector allows you to connect to the front panel audio.
Pin Assignment Pin Assignment
1 Mic In 2 Ground
3 Mic Power 4 Audio Power
5 RT Line Out 6 RT Line Out
7 Reserved 8 Key
9 LFT Line Out 10 LFT Line Out
11 RT Line In 12 RT Line In
13 LFT Line In 14 LFT Line In
(17) CD-ROM Audio-In Header: JCDIN1
This header allows you to receive stereo audio input from sound sources, such
as CD-ROM, TV Tuner, MPEG card, etc.
(18)Game Header: JGAME1
(19) Wake On LAN Header: JWOL1
1 +5V 2 +5V
3 Joystick B Button 1 4 Joystick A Button 1
5 Joystick B Coordinate X 6 Joystick A Coordinate X
7 MIDI Output 8 Ground
9 Joystick B Coordinate Y 10 Ground
11 Joystick B Button 2 12 Joystick A Coordinate Y
13 MIDI Input 14 Joystick A Button 2
15 NA 16 +5V
Pin Assignment Pin Assignment
JWOL1
1
Pin Assignment
1 +5V_SB
2 Ground
3 Wake up
Pin Assignment
1 Left Channel Input
2 Ground
3 Ground
4 Right Channel Input
14

1515
1515
15 EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
(12) Power Source Selection for Keyboard and Mouse: JKBV1
(20) Back Panel Connectors
PS/2
Keyboard
PS/2
Mouse Parallel Port
JPRNT1
COM2 COM1 USB
MIC In
Speaker Out
Line In
LAN
(optional)
1394
USB
1
1
JKBV1 Assignment Description
Pin 1-2 close +5V 5V for keyboard and mouse
Pin 2-3 close +5V Standby 5V standby for keyboard and
voltage mouse to power on your system
6 Channel Speakers
Speaker Out/
Front Speaker
(Right & Left)
Line In/
Rear Speaker (Left & Right)
Mic In/ Center & Bass

1616
1616
16
EnglishEnglish
EnglishEnglish
English
BIOSTAR Motherboard
Section 6. Trouble Shooting
PROBABLE
No power to the system at all; power light
doesn't illuminate; fan inside power supply
does not turn on. Indicator light on keyboard
does not turn on.
System inoperative. Keyboard lights are on,
power indicator lights are lit, and hard drive
is spinning.
System does not boot from hard disk drive,
but it can be booted from CD-ROM drive.
System only boots from CD-ROM. Hard
disk can be read and applications can be
used but booting from hard disk is
impossible.
Screen message says "Invalid
Configuration" or "CMOS Failure."
Cannot boot system after installing second
hard drive.
Error message reading "SECTOR NOT
FOUND" or other error messages not
allowing certain data to be retrieved.
SOLUTION
* Make sure power cable is securely
plugged in.* Replace cable.
* Contact technical support.
* Using even pressure on both ends of
the DIMM, press down firmly until the
module snaps back in places.
* Check cable running from disk to disk
controller board. Make sure both ends
are securely plugged in; check the drive
type in the standard CMOS setup.
* Backing up the hard drive is extremely
important. All hard disks are capable
of breaking down at any time.
* Back up data and applications files.
Reformat the hard drive. Re-install
applications and data using backup
disks.
* Review system's equipment. Make sure
correct information is in setup.
* Set master/slave jumpers correctly.
* Run SETUP program and select correct
drive types. Call drive manufacturers
for compatibility with other drives.
* Back up any salvageable data. Then,
low-level format, partition, and high-
level format the hard drive. Re-install
all saved data when completed.
