Biostar M6VCG User manual

User manual
Motherboard M6VCG

Federal Communications Commission (F.C.C) Statement
-This device complies with Part 15 of the FCC Rules. Operation of this device is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
-Accessories: This device has been tested and found to comply with the limits of a Class B digital
device, the accessories associated with this equipment are as follows:
1. Shielded serial cable. (Can be obtained from multiple retail outlets)
2. Shielded printer cable. (Can be obtained from multiple retail outlets)
3. Shielded video cable. (Can be obtained from multiple retail outlets)
4. Shielded power cord. (Provided by manufacturer)
These accessories are required to ensure compliance with FCC Rules. It is the responsibility of
the user to provide and use these accessories properly.
-This equipment has been tested and found to comply with the limits of a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. There is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, you are
encouraged to try to correct the interference by one or more of the following measures:
1. Reorient / relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV technician for help.
-Caution: Changes or modifications not expressly approved by the manufacturer could void the
user’s authority to operate the equipment.
Disclaimer
-The vendor makes no representations or warranties with respect to the contents here of and
specially disclaims anyimplied warranties of merchantability or fitness for anypurpose. Further the
vendor reserves the right to revise this publication and to make changes the contents here- of
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first obtaining the vendor’s
approval in writing.
Trademarks and Remarks
-MS-DOS, Windows, Windows NT, and Windows 9x are products of Microsoft Corp, with its
ownership of trademark, and are distributed by the Vendor under a license agreement.
-All trademarks used in this manual are the property of their respective owners.
-Copyright©1999
All Rights Reserved
Canadian D.O.C. Statement
-This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the radio interference regulations of the Canadian Department of
Communications.
Cet appareil numbérique n’emet pas de bruits radioélectriques dépassant les limites appliqués
aux appareils numbériques de Class B préscrits dans le reglement du brouillage radioélectrique
edict par le ministere Des Communications du Canada.

Contents
i
CONTENTS
Introduction ..............................................................................................................................1
1 Motherboard Description .....................................................................................................1
1.1 Features.........................................................................................................................................................1
1.1.1 Hardware...............................................................................................................................................1
1.1.2 Software................................................................................................................................................3
1.2 Motherboard Installation ..............................................................................................................................4
1.2.1 Layout of Motherboard.........................................................................................................................4
1.3 Motherboard Connectors..............................................................................................................................5
1.3.1 Front Panel Connectors: PANEL1........................................................................................................6
1.3.2 ATX 20-pin Power Connector:.............................................................................................................7
1.3.3 Hard Disk Connectors: IDE1 / IDE2 ....................................................................................................8
1.3.4 Floppy Disk Connector: FDD1.............................................................................................................8
1.4 Back Panel Connectors.................................................................................................................................8
1.4.1 PS/2 Mouse / Keyboard Connector: CN1.............................................................................................8
1.4.2 USB Connectors: USB1........................................................................................................................9
1.4.3 Front USB Connector (USB2) (option) ................................................................................................9
1.5 Serial and Parallel Interface Ports...............................................................................................................10
1.6 CPU Installation..........................................................................................................................................12
1.6.1 CPU Installation Procedure: Socket 370.............................................................................................12
1.6.2 CPU Jumper Settings..........................................................................................................................13
1.7 Jumper Settings...........................................................................................................................................14
1.7.1 System Fan Connector: J5...................................................................................................................14
1.7.2 CPU Fan Connector: J6 ......................................................................................................................14
1.7.3 Wake-On-LAN Connector: JWOL1 ...................................................................................................14
1.7.4 CMOS Function Selection: JBAT1.....................................................................................................15
1.8 DRAM Installation .....................................................................................................................................16
1.8.1 DIMM.................................................................................................................................................16
1.8.2 How to install a DIMM Module..........................................................................................................17
1.9 Audio Subsystem........................................................................................................................................18
1.9.1 CD Audio-In Connectors: J7/J8..........................................................................................................18
1.9.2 AUX Audio in Connector: J10 (Optional)..........................................................................................18
2. BIOS Setup..........................................................................................................................19
2.1 Main Menu .................................................................................................................................................20
2.2 Standard CMOS Features ...........................................................................................................................21
2.3 Advanced BIOS Features............................................................................................................................23
2.4 Advanced Chipset Features.........................................................................................................................25

Contents
ii
2.5 Integrated Peripherals.................................................................................................................................26
2.6 Power Management Setup ..........................................................................................................................28
2.7 PnP/PCI Configurations..............................................................................................................................30
2.8 PC Health Status.........................................................................................................................................32
2.9 Frequency Control ......................................................................................................................................33
2.10 Load Optimized Defaults..........................................................................................................................33
2.11 Set Supervisor/User Password..................................................................................................................34
2.12 Save & Exit Setup.....................................................................................................................................34
2.13 Exit Without Saving..................................................................................................................................35

Motherboard Description
1
Introduction
System Overview
Thanks for buying this product! This manual was written to help you start using this product as
quickly and smoothly as possible. Inside you will find adequate explanations to solve most
problems. In order for this reference material to be of greatest use, refer to the “expanded table of
contents” to find relevant topics.
This board incorporates the all new VIA694X/686A serial chipset, AGP and PCI IDE into one board
that provides a total PC solution. The motherboard, a CeleronTM / Pentium, processor based
PC / ATX system, supports 128kbyte or 256kbyte or cache on CPU, PCI Local Bus to support
upgrades to your system performance. On-Board Sound Subsystem to support high 3D sound
quality the AMR Slot to support the solution of high performance, low cost modem. It is ideal for
multi-tasking and fully supports MS-DOS, Windows 3x, Windows NT, Windows 2000, Novell,
OS/2, Windows9x, Windows Millennium ,UNIX, SCO UNIX, Linux etc. This manual explains how to
install the motherboard for operation and setup BIOS.
1 Motherboard Description
1.1 Features
1.1.1 Hardware
CPU − The CeleronTM processor and the PentiumMicro-Processor provides the new generation
power for high-end workstations and servers.
− Provides Socket 370 .
− Running at 66/100 or 133MHz Front Side Bus frequency.
Speed − Supports from 233MHz to 1GHz CPU core speeds.
− Supports 33MHz PCI Bus speed.
DRAM Memory
− Supports three 8/16/32/64/128/256MB DIMM modules.
− Supports synchronous DRAM (3.3V).
− Supports a maximum memory size of 768 MB with SDRAM.
− 133MHz Bus frequency.
Green Function
− Supports power management operation via BIOS.
− Power down timer from 1 min to 1 hour.
− Wakes up by any key pressed or mouse activity.
− Wake On LAN connector.
BUS Slots
− Provide one (2X/4X)AGP slot.
− Four / Five 32-bit PCI bus master slots (Optional).
− PCI V2.2 compliant.
PCI Enhanced IDE Built-in onboard
− Supports 4 IDE hard disk drives.
− Supports Mode 4, bus master mode, high performance hard disk drives.
− Supports Ultra DMA33/66, bus master mode.
− Supports IDE interface with CD-ROM.
− Supports high capacity hard disk drives.
− Supports LBA mode.

Motherboard Description
2
− Supports booting from LS-120 “SuperDisk” or iomega ™ZIP disk.
Super I/O Built-in onboard
− Support one multi-mode Parallel Port.
(1) Standard & Bidirection Parallel Port (SPP).
(2) Enhanced Parallel Port (EPP).
(3) Extended Capabilities Port (ECP).
− Supports two serial ports, 16550 UART with 16 byte FIFO.
− UART data rates up to 1.5 Mbaud.
− Supports PS/2 Mouse.
− Supports 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB floppy disk drives.
Power Management
− Supports both ACPI (Advanced and Configuration and Power Interface) and legacy (APM) power
management.
− ACPI v1.0 Compliant.
− APM v1.2 Compliant.
− CPU clock throttling and clock stop control for complete ACPI C0 to C3 state support.
− PCI bus clock run, Power Management Enable (PME) control, and PCI/CPU clock generator stop
control.
− Supports multiple system suspend types: power-on suspends with flexible CPU/PCI bus reset
options, and suspend to disk (soft-off), all with hardware automatic wake-up.
− Multiple suspend power plane controls and suspend status indicators.
− One idletimer,one peripheraltimer and one general purpose timer, plus 24/32-bit ACPI compliant
timer.
− Normal, doze, sleep, suspend,and conserve modes.
− Global and local device power control.
− System event monitoring with two event classes.
− Primary and secondary interrupt differentiation for individual channels.
− Dedicated inputpinsfor power and sleep buttons, external modem ring indicator, and notebook lid
open/close for system wake-up.
− Multiple internal and external SMI sources for flexible power management models.
− One programmable chip select and one microcontroller chip select.
− Enhanced integrated real time clock (RTC) with date alarm, month alarm, and century field.
− Thermal alarm on either external or any combination of two internal temperature sensing circuits.
− I/O pad leakage control.
Universal Serial Bus
− USB v.1.1 and Intel Universal HCI v.1.1 compatible.
− Eighteen level (doublewords) data FIFO with full scatter and gather capability.
− Root hub and four function ports.
− Intrgrated physical layer transceivers with optional over-current detection status on USB inputs.
− Keyboard and mouse support.
Platform
− ATX Form Factor.
Dimension
− 21.3 cm X 30.6 cm (W x L).

Motherboard Description
3
Full Featured Accerated Graphics Port (AGP) Controller
− Synchronous and pseudo-synchronous with the CPU bus with optimal skew control.
− AGP v2.0 compliant.
− Supports SideBand Addressing (SBA) mode (non-multiplexed address / data).
− Supports 266 MHZ 4x mode for AD and SBA signaling.
− Pipelined split-transaction long-burst transfers up to 1GB /sec.
− Eight level read request queue.
− Four level posted-write request queue.
− Thirty-two level (quadworks) read data FIFO (256 bytes).
− Sixteen level (quadworks) write data FIFO (128 bytes).
− Intelligent request reordering for maximum AGP bus utilization.
− Suppots Flush/Fence commands.
− Graphics Address Relocation Table (GART).
(1)One level TLB structure.
(2)Sixteen entry fully associative page table.
(3)LRU replacement scheme.
(4)Independent GART lookup control for host /AGP /PCI master
accesses.
− Windows 95 OSR-2 VXD and integrated Windows 98/ Windows Millennium /NT2000 /WINNT
miniport driver support.
1.1.2 Software
BIOS − AWARD legal & user-friendly BIOS.
− Supports PnP functions.
Operating Systems
− Offers the highest performance for MS-DOS OS/2, Windows NT, Windows 2000, Windows 31 / 95
/ 98 / Millennium , Novell, UNIX, SCO UNIT, and others.

Motherboard Description
4
1.2 Motherboard Installation
1.2.1 Layout of Motherboard
Model No.M6VCG
CPU
Socket 370
CN1
KB
&
MouseUSB1
USB
J20A1
J20B1
J20C1J20D1 Speaker
Out
Line In
MIC In
J7 J8
J10
PCI3
PCI1
PCI2
PCI BUS SLOT
PCI BUS SLOT
PCI BUS SLOT
PCI BUS SLOT
PCI BUS SLOT
AGP SLOT
AMR SLOT
VT82C694X
VT82C686A
AMR1
AGP1
DIMM3 DIMM2 DIMM1
J6
IDE1 IDE2
JWOL1
JFREQ1
J5
BIOS
BAT1
JBAT1
USB2
CN7B1
COM1
Parallel Port
COM2
CN7A1
CN7C1
PANEL1
Game Port
FDD1
JP1
POWER1
PCI4
PCI5

Motherboard Description
5
1.3 Motherboard Connectors
A. Back panel I/O Connectors K. Front Panel CONN. (PANEL1)
B. AGP BUS Slot (AGP1) L. CMOS Function Selection (JBAT1)
C. CPU Frequency Selection (JP1) M. System Fan Connector (J5)
D. AMR Slot (AMR1) N. Ratio Selection (JFREQ1)
E. PCI BUS Slots (PCI1-5) P. Wake On LAN (JWOL1)
F. CD Audio-In Connectors (J7/J8) Q. IDE Connectors (IDE1-2)
G. AUX Audio In Connector (J10) R. FDD Connector (FDD1)
J Front USB Connector (USB2) T. CPU Fan Connector (J6)
(option) U. DIMMs (DIMM1-3)
V. ATX Power Connector
ABCDEFG
JK
LMN
PQR
TU
V

Motherboard Description
6
1.3.1 Front Panel Connectors: PANEL1
Pin Assignment Function Pin Assignment Function
No. No.
1 Speaker 14 +5V VCC
2 NC Speaker 15 Ground Ground
3 Ground Connector 16 NC NC
4 +5V 17 Sleep Switch SMI
5 Power LED(+) 18 Ground
6 NC Power LED 19 NC NC
7 Ground 20 HDD LED(-) HDD
8 NC No 21 HDD LED(+) LED
9 NC Function 22 +5V
10 Power Switch ATX Power 23 NC IrDA
11 Ground Button 24 IRRX Connector
12 Reset Switch Reset 25 Ground
13 Ground Button 26 IRTX
Speaker Connector
An external speaker can be installed on the motherboard as a manufacturing option. An external speaker
can be connected to the motherboard at the front panel connector. The speaker (onboard or external)
provides error beep code information during the Power On Self-Test when the computer cannot use the
video interface. The speaker is not connected to the audio subsystem and does not receive output from the
audio subsystem.
Reset Button
This connector can be connected to a momentary SPST type switch that is normally open. When the switch
is closed, the motherboard resets and runs the POST.
Power LED Connector
This connector can be connected to an LED that will light when the computer is powered on.
Hard Drive LED Connector
This connector can be connected to an LED to provide a visual indicator that data is being read from or
writtento aharddrive.For theLED to function properly, an IDE drive must be connected to the onboard hard
drive controller.
Infrared Connector
After the IrDA interface is configured, files can be transferred from or to portable devices such as laptops,
PDAs, and printers using application software.
1
14
13
26
SPK POWER LED PWR RST
IRHLEDSMIGV
NC

Motherboard Description
7
SMI (Sleep/Resume Switch)
When APM is enabled in the system BIOS, and the operating system’s APM driver is loaded, the system can
enter sleep (standby) mode in one of the following ways:
• Optional front panel SMI button
• Prolonged system inactivity using the BIOS inactivity timer feature
The 2-pin header located on the front panel I/O connector supports a front panel SMI switch, which must be
a momentary SPST type that is normally open.
Closing the SMI switch sends a System Management Interrupt (SMI) to the processor, which immediately
goes into System Management Mode (SMM).While the computer is in sleep mode it is fully capable of
responding to and servicing external interrupts (such as an incoming fax) even though the monitor turns on
only if a keyboard or mouse interrupt occurs. To reactivate or resume the system, the SMI switch must be
pressed again, or the keyboard or mouse must be used.
Power On Button
Thisconnector can be connected to a front panel power switch. The switch must pull the Power Button pin to
ground for at least 50 ms to signal the power supply to switch on or off. (The time requirement is due to
internal debounce circuitry on the motherboard). At least two seconds must pass before the power supply
will recognize another on/off signal.
1.3.2 ATX 20-pin Power Connector:
This connector supports the power button on-board. Using the ATX power supply, functions such as
Modem Ring Wake-Up and Soft Power Off are supported on this motherboard. This power connector
supports instant power-on functionality, which means that the system will boot up instantly when the power
connector is inserted on the board.
PIN VOLTAGE PIN VOLTAGE
1 3.3 V 11 3.3 V
2 3.3 V 12 -12 V
3 GND 13 GND
4 5 V 14 PS_ON
5 GND 15 GND
6 5 V 16 GND
7 GND 17 GND
8 PW_OK 18 -5 V (Optional)
9 5V_SB 19 5 V
10 12 V 20 5 V
Wa g S ce t e ot e boa d as t e sta t powe o f ct o , a e s e t at a co po ts
a e sta ed p ope y befo e se t g t e powe co ecto to e s e t at o da age e do

Motherboard Description
8
1.3.3 Hard Disk Connectors: IDE1 / IDE2
The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and
Ultra DMA 33 / 66 functionality. It has two HDD connectors IDE1 (primary) and IDE2 (secondary). You can
connect up to four hard disk drives, a CD-ROM, a 120MB Floppy (reserved for future BIOS) and other
devices to IDE1 and IDE2. These connectors support the IDE hard disk cable provided.
!"
IDE1 (Primary IDE Connector)
The first hard drive should always be connected to IDE1. IDE1 can connect a Master and a Slave drive. You
must configure the second hard drive on IDE1 to Slave mode by setting the jumper accordingly.
!"
IDE2 (Secondary IDE Connector)
The IDE2 controller can also support a Master and a Slave drive. The configuration is similar to IDE1. The
second drive on this controller must be set to slave mode.
1.3.4 Floppy Disk Connector: FDD1
The motherboard provides a standard floppy disk connector (FDC) that supports 360K, 720K, 1.2M, 1.44M
and 2.88M floppy disk types. This connector supports the provided floppy drive ribbon cables.
1.4 Back Panel Connectors
1.4.1 PS/2 Mouse / Keyboard Connector: CN1
The motherboard provides a standard PS/2 mouse / Keyboard mini DIN connector for attaching a PS/2
mouse. You can plug a PS/2 mouse / Keyboard directly into this connector. The connector location and pin
definition are shown below:
PS/2 Mouse / Keyboard Connectors
Pin Signal Name
1 Data
2 No connect
3 Ground
4 +5 V (fused)
5 Clock
6 No connect
PS/2
Keyboard
PS/2
Mouse
USB COM2
P arallel Game Port
Speaker
out Line
in Mic in
CN1
USB1
CN7A1
COM1

Motherboard Description
9
1.4.2 USB Connectors: USB1
The motherboard provides a UHCI (Universal Host Controller Interface) Universal Serial Bus Roots for
attaching USB devices such as keyboard, mouse and other USB devices. You can plug the USB Devices
directly into this connector.
Stacked USB Connectors
Pin Signal Name
1 +5 V (fused)
2 USBP0- [USBP1-]
3 USBP0+ [USBP1+]
4 Ground
Note: (1) Signal names in brackets ([]) are for USB port 1.
1.4.3 Front USB Connector (USB2) (option)
Pin Signal Name Pin Signal Name
1 +5V 2 Ground
3 USBP2- 4 Ground
5 USBP2+ 6 USBP3+
7 Ground 8 USBP3-
9 Ground 10 +5V
USB1
USB2
1
2
9
10

Motherboard Description
10
1.5 Serial and Parallel Interface Ports
This system comes equipped with two serial ports and one parallel port. Both types of interface ports will be
explained in this chapter.
The Serial Interface Port : COM1 / COM2
The serial interface port is sometimes referred to as an RS-232 port or an asynchronous communications
port. Mice, printers, modems and other peripheral devices can be connected to a serial port. The serial port
can also be used to connect your computer with another computer system. If you wish to transfer the
contents of your hard disk to another system it can be accomplished by using each machine’s serial port.
The serial ports on this system has two 9-pin connector. Some older computer systems and peripherals
used to be equipped with only one 25-pin connector. As you need to connect your 9-pin serial port to an
older 25-pin serial port, you can purchase a 9-to-25 pin adapter.
Connectivity
The serial port can be used many ways, and it can be necessary to become familiar with the pin-out diagram.
The following chart gives you the function of each pin on the 9-pin connector and some of the 25-pin
connector. This information can be used when configuring certain software programs to work with the serial
port.
Signal Name DB9 PIN DB25 PIN
DCD Data Carrier Detect 1 8
RX Receive Data 2 3
TX Transmit Data 3 2
DTR Data Terminal Ready 4 20
GND Signal Ground 5 7
DSR Data Set Ready 6 6
RTS Request to Send 7 4
CTS Clear to Send 8 5
RI Ring Indicator 9 22
Special Applications
There are two types of serial devices that can be connected to a serial port. One of the devices is called
“DTE” (Data Terminal Equipment) and the other device is called “DCE” (Data Communications Equipment).
If a modem is connected to a computer, for example, the modem is called the DCE and the computer is
called the DTE. In situations such as this, the pins on the serial ports can be connected straight through.
In instances when there are two DTE devices connected together, such as a computer and a printer, a
special adapter called a “Null Modem” is needed to make communication between the two devices possible.
When using the serial port to communicate between devices, one problem in particular may arise. Some
manufacturers use one set of signals to begin communication with another device and other manufacturers
do not use these signals to initiate communication. If you encounter a communication problem that cannot
be resolved using a null modem, it can generally be assumed that one device is using the initialization

Motherboard Description
11
signals and the other device is not. This can usually be resolved by wiring the RTS, CTS, and DCD pins
together.
Serial Ports/COM Ports
The two serial ports on the computer are called COM1 and COM2, respectively. If you wish, two more serial
ports can be added onto the computer using optional hardware. Should you choose to add the extra Serial
ports (COM ports) they would be called COM3 and COM4.
When using serial ports to communicate with a peripheral device, be sure to assign only one COM port
number to each device. For example, if a printer and a scanner are both connected to your computer through
serial ports, the printer must be assigned one COM port (i.e. COM1) and the scanner must be assigned the
other COMport (i.e. COM2). No two devices can be assigned to one COM port. Each peripheral must have
its own COM port.
NOTE: Four serial ports may be installed on the computer. However, no more than two ports can be used
simultaneously.
*If you have installed an internal modem, be careful not to assign a COMport number that has already been
assigned to another device. This error is common.
When installing a device that is going to require the use of a serial port, use a diagnostic program to find out
which ports are available. It may be necessary to remove expansion cards that have serial ports in order to
check their jumper settings. The jumper settings will indicate which COM port the card has been assigned.
Checking the expansion card will eliminate mistakes in overlapping COM ports. Once you have completed
the installation of peripheral devices using the serial ports, be sure that the communication parameters such
as baud rate, parity bit, etc. are matching. If your computer is set for a baud rate of 9600 and your modem is
set for a baud rate of 2400 you will not be able to send messages. The manuals that accompany the
peripheral devices will inform you on the procedure for setting their parameters. Software manuals also have
instructions on setting parameters.
Parallel Interface Port : CN7A1
Unlike the serial port, parallel interface ports have been standardized and should not present any difficulty
interfacing peripherals to your system. Sometimes called a Centronics port, the parallel port is almost
exclusively used with printers. The parallel port on you system has a 25-pin, DB25 connector (see picture
below). The pin-out for the parallel port are shown in the table below.
Signal Pin
-Strobe 1
Data 0 2
Data 1 3
Data 2 4
Data 3 5
Data 4 6
Data 5 7
Data 6 8
Data 7 9
-Ack 10
Busy 11
Paper Empty 12
+Select 13
-Auto FDXT 14
-Error 15
-Init 16
-SLCTN 17
Ground 18
Ground 19
Ground 20
Ground 21
Ground 22
Ground 23
Ground 24
Ground 25

Motherboard Description
12
1.6 CPU Installation
1.6.1 CPU Installation Procedure: Socket 370
1. Pull the lever sideways away from the socket then raise the lever up to a 90-degree angle.
2. Locate Pin A in the socket and look for the white dot or cut edge in the CPU. Match Pin A with
the white dot/cut edge then insert the CPU.
3. Press the lever down to complete the installation.
Socket 370

Motherboard Description
13
1.6.2 CPU Jumper Settings
1.6.2.1 CPU Ratio Selection: JFREQ1
JFREQ1
RATIO
1 2 3 4
x 2.0 CLOSE CLOSE CLOSE CLOSE
x 2.5 CLOSE CLOSE OPEN CLOSE
x 3.0 CLOSE OPEN CLOSE CLOSE
x 3.5 CLOSE OPEN OPEN CLOSE
x 4.0 OPEN CLOSE CLOSE CLOSE
x 4.5 OPEN CLOSE OPEN CLOSE
x 5.0 OPEN OPEN CLOSE CLOSE
x 5.5 OPEN OPEN OPEN CLOSE
x 6.0 CLOSE CLOSE CLOSE OPEN
x 6.5 CLOSE CLOSE OPEN OPEN
x 7.0 CLOSE OPEN CLOSE OPEN
x 7.5 CLOSE OPEN OPEN OPEN
x 8.0 OPEN CLOSE CLOSE OPEN
1.6.2.2 CPU Frequency Selection: JP1
JP1
FREQ.
1 2 3 4 5 6 PCI
FREQ.
66MHz OPEN OPEN CLOSE CLOSE CLOSE CLOSE 33 Mhz
100MHz OPEN OPEN OPEN CLOSE OPEN CLOSE 33 Mhz
133 MHz OPEN OPEN OPEN OPEN CLOSE OPEN 33 Mhz
1
JP1
JFREQ1
1

Motherboard Description
14
1.7 Jumper Settings
The jumper has two or more pins that can be covered by a plastic jumper cap, allowing you to select
different system options.
1.7.1 System Fan Connector: J5
Pin No. Assignment
1 Sense
2 +12 V
3 Control Signal
1.7.2 CPU Fan Connector: J6
Pin No. Assignment
1 Sense
2 +12 V
3 Control Signal
1.7.3 Wake-On-LAN Connector: JWOL1
Pin No. Assignment
15V_SB
2 Ground
3 Wake-up
1
JBAT1
J5
JWOL1
J6
1
1
1

Motherboard Description
15
1.7.4 CMOS Function Selection: JBAT1
JBAT1 Assignment
1 3
1-2 Closed Normal Operation (default)
1 3
2-3 Closed Clear CMOS Data (*Note)
1 3
Open Onboard Battery Disabled
Note: Please follow the procedure as below to clear CMOS Data.
Note: Please follow the procedure as below to clear BIOS Password if your password is lost
or forgotten.
Remove AC
Power Line JBAT1 (2-3)
closed Wait three
seconds JBAT1 (1-2)
closed
AC Power On Reset your desired password
or Clear CMOS Data
Plug AC
Power Line

Motherboard Description
16
1.8 DRAM Installation
1.8.1 DIMM
DRAM Access Time : 3.3V Unbuffered SDRAM PC66, PC100 & PC133 Type required.
DRAM Type : 8MB/16MB/32MB/64MB/128MB/256MB DIMM Module (168pin)
Total Bank 0 Bank 1 Bank 2
Memory Size (MB) DIMM1 DIMM2 DIMM3
8 M 8M x 1 pc ---- ----
16 M 16M x 1 pc ---- ----
32 M 32M x 1 pc ---- ----
64 M 64M x 1 pc ---- ----
128 M 128M x 1 pc ---- ----
256 M 256M x 1 pc ---- ----
16 M 8M x 1 pc 8M x 1 pc ----
32 M 16M x 1 pc 16M x 1 pc ----
64 M 32M x 1 pc 32M x 1 pc ----
128 M 64M x 1 pc 64M x 1 pc ----
256 M 128M x 1 pc 128M x 1 pc ----
512 M 256M x 1 pc 256M x 1 pc ----
24 M 8M x 1 pc 8M x 1 pc 8M x 1 pc
40 M 16M x 1 pc 16M x 1 pc 8M x 1 pc
72 M 32M x 1 pc 32M x 1 pc 8M x 1 pc
136 M 64M x 1 pc 64M x 1 pc 8M x 1 pc
264 M 128M x 1 pc 128M x 1 pc 8M x 1 pc
520 M 256M x 1 pc 256M x 1 pc 8M x 1 pc
32 M 8M x 1 pc 8M x 1 pc 16M x 1 pc
48 M 16M x 1 pc 16M x 1 pc 16M x 1 pc
80 M 32M x 1 pc 32M x 1 pc 16M x 1 pc
144 M 64M x 1 pc 64M x 1 pc 16M x 1 pc
272 M 128M x 1 pc 128M x 1 pc 16M x 1 pc
528 M 256M x 1 pc 256M x 1 pc 16M x 1 pc
48 M 8M x 1 pc 8M x 1 pc 32M x 1 pc
64 M 16M x 1 pc 16M x 1 pc 32M x 1 pc
96 M 32M x 1 pc 32M x 1 pc 32M x 1 pc
160 M 64M x 1 pc 64M x 1 pc 32M x 1 pc
288 M 128M x 1 pc 128M x 1 pc 32M x 1 pc
544 M 256M x 1 pc 256M x 1 pc 32M x 1 pc
80 M 8M x 1 pc 8M x 1 pc 64M x 1 pc
96 M 16M x 1 pc 16M x 1 pc 64M x 1 pc
128 M 32M x 1 pc 32M x 1 pc 64M x 1 pc
192 M 64M x 1 pc 64M x 1 pc 64M x 1 pc
320 M 128M x 1 pc 128M x 1 pc 64M x 1 pc
576 M 256M x 1 pc 256M x 1 pc 64M x 1 pc
Total Bank 0 Bank 1 Bank 2
Memory Size (MB) DIMM1 DIMM2 DIMM3
144 M 8M x 1 pc 8M x 1 pc 128M x 1 pc
160 M 16M x 1 pc 16M x 1 pc 128M x 1 pc
192 M 32M x 1 pc 32M x 1 pc 128M x 1 pc
256 M 64M x 1 pc 64M x 1 pc 128M x 1 pc
384 M 128M x 1 pc 128M x 1 pc 128M x 1 pc
640 M 256M x 1 pc 256M x 1 pc 128M x 1 pc
272 M 8M x 1 pc 8M x 1 pc 256M x 1 pc
288 M 16M x 1 pc 16M x 1 pc 256M x 1 pc
320 M 32M x 1 pc 32M x 1 pc 256M x 1 pc
384 M 64M x 1 pc 64M x 1 pc 256M x 1 pc
512 M 128M x 1 pc 128M x 1 pc 256M x 1 pc
768 M 256M x 1 pc 256M x 1 pc 256M x 1 pc
*The list shown above for DRAM configuration is only for reference.
