FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in
a particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves
the right to revise this publication and to make changes to the contents
here of without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without
first obtaining the vendor’s approval in writing.
The content of this user’s manual is subject to be changed without notice
and we will not be responsible for any mistakes found in this user’s
manual. All the brand and product names are trademarks of their
respective companies.

C
C
Co
o
on
n
nt
t
te
e
en
n
nt
t
t
ii
LAYOUT OF M7SUA ...............................................................................1
COMPONENT INDEX.............................................................................2
ENGLISH...................................................................................................3
M7SUA Features ........................................................................................................ 3
Package contents......................................................................................................4
How to setup Jumper ................................................................................................ 4
CPU Installation ......................................................................................................... 5
DDR DIMM Modules: DDR1/ DDR2 ........................................................................... 6
Installing DDR Module............................................................................................... 6
Jumpers, Headers, Connectors & Slots................................................................... 6
ESPAÑOL.................................................................................................12
Características del M7SUA.....................................................................................12
Contenido del Paquete............................................................................................ 13
Cómo instalar un Puente......................................................................................... 13
Instalación del CPU ................................................................................................. 14
Módulos DDR DIMM: DDR1/ DDR2......................................................................... 14
Instalación del Módulo DDR ................................................................................... 15
Puentes, Cabezales, Conectores y Ranuras ......................................................... 15
DEUTSCH................................................................................................22
Spezifikationen von M7SUA.................................................................................... 22
Verpackungsinhalt................................................................................................... 23
Einstellung der Jumper........................................................................................... 23
Installation der CPU................................................................................................. 24
DDR-DIMM-Modules: DDR1/ DDR2......................................................................... 25
Installation von DDR-Modul....................................................................................25
Jumpers, Headers, Anschlüsse & Slots ................................................................25
TROUBLE SHOOTING.........................................................................31
SOLUCIÓN DE PROBLEMAS.............................................................32
PROBLEMLÖSUNG..............................................................................33

1
Layout of M7SUA
※NOTE: ●represents the first pin.
JKBMS1
JAUDIO
JUSB1
JPRNT1
JCOM1
JVGA1
JUSBLAN2
1
2
13
14
JUSBV2
1CPU1
JCFAN1
1
JATXPWR1
DDR2
DDR1
SIS 740
SIS 962L
PRIMARY IDE CONN.
IDE1IDE2
SECONDARY IDE CONN.
12
23
24
JPANEL1
1
JSFAN1
JWOL1
1
JCMOS1
1JUSBV1
1
PCI3
PCI2
PCI1
JUSB2
29
10
1
1
Codec
Phy
11
LAN
Phy
FDD1
JGAME1
1
216
15
BIOS
Winbond
I/O
BAT1
1 2
JUSBV3
1
JCI1
1

2
Component Index
A. 5V/5VSB Selection for USB K. 5V/5VSB Selection for USB
(JUSBV2) (JUSBV1)
B. Back Panel Connectors L. Clear CMOS Jumper (JCMOS1)
C. Front Audio Header (JAUDIO1) M. System Fan Header (JSFAN1)
D. Audio Modem Riser (AMR1) N. Front Panel Connector (JPANEL1)
E. Floppy Disk Connector (FDD1) O. Wake On LAN Header (JWOL1)
F. CD-ROM Audio-In Header (JCDIN1) P. Frequency Selection (JCLK1)
G. CD-ROM Audio-In Header (JCDIN2) Q. Hard Disk Connectors (IDE1-2)
H. Digital Audio Connector R. DDR DIMM Modules (DDR1-2)
(SPDIF_OUT1) S. ATX Power Connector (JATXPWR1)
I. Peripheral Component T. CPU Fan Connector (JCFAN1)
Interconnect Slot (PCI1-3) U. Case Open Connector (JCI1)
J. Front USB Header (JUSB2) V. Game Header (JGAME1)
W. 5V/5VSB Selection for USB (JUSBV3)
DDR2
DDR1
SIS 740
SIS 962L
PRIMARY IDE CONN.
SECONDARY IDE CONN.
Codec
Phy
LAN
Phy
BIOS
Winbond
I/O
BAT1
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
V
W U

3
English
M7SUA Features
A. Hardware
CPU
Provides Socket A.
Supports the single AMD®for AthlonTM (ThunderbirdTM )/ Athlon XPTM/ DuronTM
processors.
Front Side Bus at 200/ 266/ Fuzzy333 MHz.
Chipset
North Bridge: SIS 740.
South Bridge: SIS 962L
Main Memory
Supports up to 2 DDR devices.
Supports 200/ 266/ Fuzzy333 MHz (without ECC) DDR devices.
Maximum memory size of 2GB.
Super I/O
Chip: ITE IT8705.
Slots
Three 32-bit PCI bus master slots.
One AMR slot.
On Board IDE
Supports four IDE disk drives.
Supports PIO Mode 4, Bride Mode and Ultra DMA 33/66/100/133 Bus Master
Mode.
On Board AC’97 Sound Codec
Chip: VT1612A. (only for AC97 2.2)
Compliant with AC’97 specification.
AC97 2.2 interface.
Supports 2 audio output channels.
On Board Peripherals
1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes.
1 serial port.
1 VGA port.
1 parallel port. (SPP/EPP/ECP mode)
1 vertical audio port.
1 LAN port. (optional)
PS/2 mouse and PS/2 keyboard.

4
6 USB2.0 ports. (front*2 + rear*4)
Front Side I/O Header
Front side audio header.
Front side USB headers.
Dimensions
Micro ATX Form Factor: 19.1 X 22.9cm (W X L)
B. BIOS & Software
BIOS
Award legal BIOS.
Supports APM1.2.
Supports ACPI.
Supports USB Function.
Software
Supports 9th TouchTM, FLASHER™ and StudioFun!TM (optional)
Offers the highest performance forWindows 98 SE, Windows 2000, Windows Me,
Windows XP, SCO UNIX etc.
Package Contents
HDD Cable X1
FDD Cable X1
User’s Manual X1
USB Cable X1 (optional)
Rear I/O Panel for ATX Case X1 (optional)
Fully Setup Driver CD X1
StudioFun! Application CD X1 (optional)
S/PDIF Out Cable X1 (optional)
How to setup Jumper
The illustration shows how jumpers are setup.When the Jumper cap is placed on pins, the
jumper is “close”. If no jumper cap is placed on the pins, the jumper is ”open”. The
illustration shows a 3-pin jumper whose pin 1and 2 are “close” when jumper cap is placed
on these 2 pins.
Jumper close Jumper open Pin1-2 close

5
CPU Installation
Step1: Pull the lever sideways away from the socket and then raise the lever up to a
90-degree angle.
Step2: Look for the white dot/cut edge. The white dot/cut edge should point towards the
lever pivot. The CPU will fit only in the correct orientation.
Step3: Hold the CPU down firmly, and then close the lever.
Step4: Put the CPU fan on the CPU and buckle it. Connect the CPU fan power cable to
the JCFAN1. This completes the installation.
CPU Fan Headers: JCFAN1
Pin No. Assignment
1 Ground
2 +12V
1
3
JCFAN1 3 FAN R.P.M. Sense
System Fan Headers: JSFAN1
Pin No. Assignment
1 Ground
2 +12V
1
JSFAN1
3 FAN R.P.M. Sense
Step1 Step2 Step3 Step4

6
DDR DIMM Modules: DDR1/ DDR2
DRAM Access Time: 2.5V Unbuffered DDR 200/ 266/ Fuzzy333 MHz Type required.
DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin)
Total Memory Size with Unbuffered DIMMs
DIMM Socket
Location DDR Module Total Memory Size (MB)
DDR1 64MB/128MB/256MB/512MB/1GB
*1
DDR2 64MB/128MB/256MB/512MB/1GB
*1
Max is
2GB
***Only for reference***
Installing DDR Module
1. Unlock a DIMM slot by pressing the
retaining clips outward. Align a DIMM on
the slot such that the notch on the DIMM
matches the break on the slot.
2. Insert the DIMM firmly and vertically into
the slot until the retaining chip snap back in
place and the Dimm is properly seated.
Jumpers, Headers, Connectors & Slots
Floppy Disk Connector: FDD1
The motherboard provides a standard floppy disk connector that supports 360K,
720K, 1.2M, 1.44M and 2.88M floppy disk types. This connector supports the
provided floppy drive ribbon cables.
Hard Disk Connectors: IDE1/ IDE2
The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO
Mode 0~4, Bus Master, and Ultra DMA 33/ 66/ 100/ 133 functionality. It has two
HDD connectors IDE1 (primary) and IDE2 (secondary).
The IDE connectors can connect a master and a slave drive, so you can connect
up to four hard disk drives. The first hard drive should always be connected to
IDE1.
Peripheral Component Interconnect Slots: PCI1-3
This motherboard is equipped with 3 standard PCI slots. PCI stands for Peripheral
Component Interconnect, and it is a bus standard for expansion cards. This PCI

7
slot is designated as 32 bits.
Audio Modem Riser Slot: AMR1
(Only support slave card)
The AMR specification is an open Industry Standard Architecture and that defines
a hardware scalable riser card interface, which supports audio and modem only.
Front Panel Connector: JPANEL1
Front USB Header: JUSB2
Pin Assignment Pin Assignment
1 +5V(fused) 2 +5V(fused)
3 USBP3- 4 USBP2-
5 USBP3+ 6 USBP2+
7 Ground 8 Ground
2
1
10
9
JUSB2 9 KEY 10 NA
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
(+) (-)
(+) (-)(+)
Pin Assignment Function Pin Assignment Function
1 +5V 2 Sleep Control
3 NA 4 Ground Sleep
Button
5 NA 6 NA NA
7 Speaker
Speaker
Connector
8 Power LED (+)
9 HDD LED (+) 10 Power LED (+)
11 HDD LED (-) Hard Drive
LED 12 Power LED (-)
POWER
LED
13 Ground 14 Power Button
15 Reset Control Reset
Button 16 Ground Power-on Button
17 NA 18 KEY
19 NA 20 KEY
21 +5V 22 Ground
23 IRTX
IrDA
Connector
24 IRRX
IrDA
Connector
JPANEL1

8
Wake On LAN Header: JWOL1
Pin Assignment
1 +5V_SB
2 Ground
13
JWOL1
3 Wake up
Power Connectors: JATXPWR1
PIN Assignment PIN Assignment
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 Ground 13 Ground
4 +5V 14 PS_ON
5 Ground 15 Ground
6 +5V 16 Ground
7 Ground 17 Ground
8 PW_OK 18 -5V
9 +5V_SB 19 +5V
20
11
10
1
JATXPWR1
10 +12V 20 +5V
5V/ 5VSB Selection for USB (optional): JUSBV1/ JUSBV2/
JUSBV3
JUSBV1/ JUSBV2/
JUSBV3 Assignment Description
1 3
Pin 1-2 close
+5V JUSBV1: 5V for JUSB2 port
JUSBV2: 5V for JUSB1 port
JUSBV3: 5V for JUSBLAN2 port
1 3
Pin 2-3 close
+5V_SB JUSBV1: JUSB2 port powered with
standby voltage 5V
JUSBV2: JUSB1 port powered with
standby voltage 5V
JUSBV3: JUSBLAN2 port powered with
standby voltage 5V

9
Clear CMOS Jumper: JCMOS1
※Clear CMOS Procedures:
1. Remove AC power line.
2. Set the jumper to “Pin 2-3 close”.
3. Wait for five seconds.
4. Set the jumper to “Pin 1-2 close”.
5.PoweronAC.
6. Reset your desired password or clear the CMOS data.
Case Open Connector: JCI1 (optional)
Pin Assignment
1 Case Open Signal
1
JCI1 2 Ground
JCMOS1 Assignment
1
3
Pin 1-2 Close
Normal Operation (default)
1
3
Pin 2-3 Close
Clear CMOS Data
The following procedures are for resetting the
BIOS password. It is important to follow these
instructions closely.

10
Front Panel Audio Header: JAUDIO1
1
2
13
14
JAUDIO1
Pin Assignment Pin Assignment
1 Mic In 2 Ground
3 Mic Power 4 Audio Power
5 RT Line Out 6 RT Line Out
7 Reserved 8 Key
9 LFT Line Out 10 LFT Line Out
11 RT Line In 12 RT Line In
13 LFT Line In 14 LFT Line In
Digital Audio Connector: SPDIF_OUT1
Pin Assignment
1 +5V
2 SPDIF_OUT
13
SPDIF_OUT1 3 Ground
GAME Header: JGAME1 (optional)
1
216
15
JGAME1
Pin Assignment Pin Assignment
1 +5V 2 +5V
3 GPSB1 4 GPSA1
5 GPX2 6 GPX1
7 MIDI-OUT 8 Ground
9 GPY2 10 Ground
11 GPSB2 12 GPY1
13 MIDI-IN 14 GPSA2
15 NA 16 +5V

11
CD-ROM Audio-In Header: JCDIN1/ JCDIN2
Pin Assignment
1 Left Channel Input
2 Ground
3 Ground
1
JCDIN1/ 2 4 Right Channel Input
Frequency Selection: JCLK1 (optional)
CPU Clock PIN 1-2
100MHz OPEN
133MHz CLOSE
Note: Frequency Selection for Fuzzy333 MHz is selected throught BIOS
setup.
Back Panel Connectors
1 3
13
Keyboard
Mouse
COM1
JCOM1
JKBMS1
USB
JUSB1
USB
JUSBLAN2
Speaker Out
Line In/ Surround
Mic In/ Bass&Center
JAUDIO
LAN
Parallel
JVGA1

12
Español
Características del M7SUA
A. Hardware
CPU
Proporciona Socket A.
Soporta single AMD®para procesadores AthlonTM (ThunderbirdTM )/ Athlon XPTM/
DuronTM.
Front Side Bus 200/ 266/ Fuzzy333 MHz.
Chipset
North Bridge: SIS 740.
South Bridge: SIS 962L
Memoria Principal
Soporta hasta up to 2 DDR devices.
Soporta dispositivos DDR 200/ 266/ Fuzzy333 MHz (sin ECC).
Tamaño de memoria máxima 2GB.
Super I/O
Chip: ITE IT8705.
Ranuras
Tres PCI bus master de 32-bit.
Una ranura AMR.
IDE Onboard
Soporta cuatro discos duros IDE.
Soporta modo PIO 4, modo Bride y Ultra DMA 33/66/100/133 Bus modo Master.
AC’97 Sound Codec Onboard
Chip: VT1612A. (solamente para AC97 2.2)
Conforma con la especificación AC’97.
Interface AC97 2.2.
Soporta 2 canales de salida de audio.
Periféricos Onboard
1 puerto de disquetera que soporta 2 FDDs con 360K, 720K, 1.2M, 1.44M y
2.88Mbytes.
1 puerto serie.
1 puerto VGA.
1 puerto paralelo. (modo SPP/EPP/ECP)
1 puerto de audio vertical.
1 puerto LAN. (opcional)
Ratón PS/2 y teclado PS/2.

13
6 puertos USB2.0 (frontal*2 + traseros*4)
Cabezal del lado frontal I/O
Cabezal frontal de audio.
Cabezal frontal USB.
Dimensiones
Factor de Forma Micro ATX: 19.1 X 22.9 cm (W X L)
B. BIOS & Software
BIOS
Award legal BIOS.
APM1.2.
ACPI.
Función USB.
Software
Soporta 9th TouchTM , FlasheTM and StudioFun!TM (optional).
Ofrece el más alto funcionamiento para Windows 98 SE, Windows 2000,
Windows Me, Windows XP, SCO UNIX etc.
Contenido del Paquete
Cable HDD X1
Cable FDD X1
Manual del Usuario X1
Cable USB X1 (opcional)
Panel Trasero I/O para carcasa ATX X1 (opcional)
Configuración completa del Driver CD X1
Aplicación del CD StudioFun! X1 (opcional)
Cable S/PDIF Out X1 (opcional)
Cómo instalar un Puente
La ilustración muestra cómo instalar un puente. Cuando el Jumper Cap está ubicado en
los contactos, el puente está en “close”. Si no hay Jumper Cap ubicado en los contactos,
el puente está en ”open”. La siguiente ilustración muestra un contacto 3 en el que los
contactos 1y 2 están “close” cuando el Jumper Cap está ubicado en los dos contactos.
Puente open Puente close Contacto 1-2 close

14
Instalación del CPU
Paso 1: Empuje la palanca hacia afuera del socket y levante lapalanca hasta un ángulo de
90 grados.
Paso 2: Fíjese por el punto blanco o márgen cortado. El punto blanco o márgen cortado
debería apuntar hacia el pivote de la palanca. La CPU solamente se fijará en una
sola correcta orientación.
Paso 3: Tome el CPU firmemente hacia abajo, y cierre la palanca para completar la
instalación.
Paso 4: Ponga el ventilador de la CPU en el CPU y asegúrelo. Conecte el cable de
corriente del ventilador de la CPU al JCFAN1. Ésto completa la instalación.
paso1 paso2 paso3 paso4
Cabezales de Ventilación de la CPU: JCFAN1
Contacto No. Asignación
1 Tierra
2 +12V
1
3
JCFAN1 3 FAN R.P.M. Sense
System Fan Headers: JSFAN1
Contacto No. Asignación
1 Tierra
2 +12V
1
JSFAN1
3 FAN R.P.M. Sense
Módulos DDR DIMM: DDR1/ DDR2
DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/ 266/ Fuzzy333 MHz Tipo

15
requerido.
DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulos DIMM (contactos 184)
Total del Tamaño de Memoria con Unbuffered DIMMs
Localización
del DIMM
Socket
Módulo DDR Total del
Tamaño de
Memoria
(MB)
DDR1 64MB/128MB/256MB/512MB/1GB
*1
DDR2 64MB/128MB/256MB/512MB/1GB
*1
Máxima
2GB
***Solamente para referencia***
Instalación del Módulo DDR
1. Abra una ranura de DIMM presionando el clip
de retención hacia afuera. Aliñe el DIMM en la
ranura tales que la muesca en el DIMM encaje
en la cumbrera de la ranura.
2. Inserte el DIMM verticalmente y firmemente en
la ranura hasta que el clip de retención vuelva a
su posición original y el DIMM esté
correctamente colocado.
Puentes, Cabezales, Conectores y Ranuras
Conector para Disquetera: FDD1
La placa madre proporciona un conector estándar para disquete que soporta
disquetera de 360K, 720K, 1.2M, 1.44M y 2.88M. Éste conector utiliza cables
proporcionados por el disquete.
Conectores de Disco Duro: IDE1/ IDE2
La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO
0~5, Bus Master, y funcionalidad Ultra DMA 33/ 66/ 100. Tiene dos conectores
HDD: IDE1 (primario) y IDE2 (secundario).
Los conectores IDE puede conectar a un disco master y uno esclavo, así puede
conectar hasta cuatro discos duros. El primer disco duro debe estar siempre
conectado al IDE1.
Ranuras de Interconexión del Componente Periférico: PCI1-3
Ésta placa madre está equipada con 3 ranuras estándar PCI. PCI es la sigla para

16
Interconexión del Componente Periférico, y es un bus estándar para tarjetas de
expansión. Ésta ranura PCI está diseñado con 32 bits.
Ranura Audio Módem Riser: AMR1
(Solamente soporta tarjeta esclava)
AMR es una industria estándar de arquitectura abierta en el que define interface
de tarjeta hardware escalable soportando solamente audio y módem.
Conector del Panel Frontal: JPANEL1
Cabezal Frontal USB: JUSB2
Contac
tos Asignación Contac
tos Asignación
SPK
PWR_LED
HLED
SLP
RST
224
IR
123
IRON/OFF
(+) (-)
(+) (-)(+)
Con-
tacto Asignación Función Con- tacto Asignación Función
1 +5V 2 Control de
Suspension
3 NA 4 Tierra
Botón
de Suspensión
5 NA 6 NA NA
7 Altavoz
Conector
del
Altavoz
8 Corriente LED(+)
9 HDD LED (+) 10 Corriente LED(+)
11 HDD LED (-) LED del
Disco Duro 12 Corriente LED (-)
LED
del Corriente
13 Tierra 14 Botón de
Encendido
15 Control de
Reinicio
Botón
de Reinicio 16 Tierra
Botón
de Encendido
17 NA 18 KEY
19 NA 20 KEY
21 +5V 22 Tierra
23 IRTX
Conector IrDA
24 IRRX
Conector IrDA
JPANEL1

17
1 +5V(fused) 2 +5V(fused)
3 USBP3- 4 USBP2-
5 USBP3+ 6 USBP2+
7 Tierra 8 Tierra
2
1
10
9
JUSB2 9 KEY 10 NA
Cabezal Wake On LAN: JWOL1
Contactos Asignación
1 +5V_SB
2 Tierra
13
JWOL1
3 Wake up
Conector de Corriente: JATXPWR1
Contac
tos Asignación Contac tos Asignación
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 Tierra 13 Tierra
4 +5V 14 PS_ON
5 Tierra 15 Tierra
6 +5V 16 Tierra
7 Tierra 17 Tierra
8 PW_OK 18 -5V
9 +5V_SB 19 +5V
20
11
10
1
JATXPWR1
10 +12V 20 +5V

18
5V/ 5VSB Selección para USB (opcional): JUSBV1/ JUSBV2/
JUSBV3
JUSBV1/ JUSBV2/
JUSBV3 Asignación Descripción
1 3
Contactos 1-2 close
+5V JUSBV1: 5V para puerto JUSB2
JUSBV2: 5V para puerto JUSB1
JUSBV3: 5V para puerto JUSBLAN2
1 3
Contactos 2-3 close
+5V_SB JUSBV1: puerto JUSB2 voltaje standby
de 5V
JUSBV2: puerto JUSB1 voltaje standby
de 5V
JUSBV3: puerto JUSBLAN2 voltaje
standby de 5V
Puente de Borrar CMOS: JCMOS1
※Procesos para Borrar CMOS:
1. Quite el cable de corriente del AC.
2. Fijar el puente en el “contacto 2-3 close”.
JCMOS1 Assignment
1
3
Contacto 1-2 Close
Operación Normal (default)
1
3
Contactos 2-3 Close
Borrar Datos CMOS
Los siguientes procesos son para reiniciar la
contrasena del BIOS. Es importante que siga los
siguientes pasos cuidadosamente.
~
