M7 VIQ
ENGINEERING VALIDATION TEST REPORT
COVER SHEET
CHANGE CONTROL
Description of Change Revision Sections/Pages Affected Date
Initial Release 0.90 2002/6/11
1.0 2002/6/24
1.1 2002/7/18
Project: M7 VIQ
Date: 2002/6/11
Owner: Biostar Group
Contact: TEL: [phone] FAX: [phone]
Home Page: http://www.biostar.com.tw

2
CONTENTS
PRODUCT INFORMATION.....................................................................4
Motherboard General Information..................................................................... 4
Chipset Details........................................................................................................ 4
BIOS Details ........................................................................................................... 4
CPU Supports.......................................................................................................... 4
Memory Supports................................................................................................... 4
On-board Features and Devices.......................................................................... 4
Mechanical............................................................................................................... 5
DESIGN REVIEW ver 1.1..........................................................................7
Mainboard Voltage Measurement...................................................................... 7
Bus Clock................................................................................................................. 7
REQUIRED BIOS DEFAULT SETTINGS...............................................8
BIOS FEATURES SETUP.................................................................................. 8
CHIPSET FEATURES SETUP......................................................................... 8
POWER MANAGEMENT SETUP.................................................................. 9
PnP / PCI CONFIGURATION........................................................................... 9
INTEGRATED PERIPHERALS..................................................................... 10
PC Health Statues................................................................................................. 10
FUNCTIONALITY ...................................................................................12
Setup Installation Test Of Operating System................................................ 12
Basic On-board Function Test.......................................................................... 12
MS-DOS Operating............................................................................................. 12
Windows ME Operating..................................................................................... 15
Windows2000 Operating ................................................................................... 18
Windows XP (Home Edition ) Operating...................................................... 21
Windows XP (Professional ) Operating......................................................... 27
Linux (Red Hat 7.3) Operating......................................................................... 29
RELIABILITY TEST................................................................................30
Motherboard General Information................................................................... 30
Burn-in Step........................................................................................................... 30
OVER CLOCK TEST...............................................................................31
Windows XP Home Edition (FSB:100 MHz).............................................. 31
Windows XP Home Edition (FSB:133 MHz)................................................... 32
PERFORMANCE TEST...........................................................................33
Windows ME ........................................................................................................ 33
Windows XP Professional................................................................................. 34
Windows XP ......................................................................................................... 35
Display Card Performance.................................................................................... 36

3
HARDWARE COMPATIBILITY LIST.................................................37
CPU ......................................................................................................................... 37
CD-ROM................................................................................................................ 38
Camera Device...................................................................................................... 38
DVD-ROM............................................................................................................ 39
Display Card.......................................................................................................... 39
FDD......................................................................................................................... 40
HDD ........................................................................................................................ 40
Joystick................................................................................................................... 41
Keyboard................................................................................................................ 42
LAN Card............................................................................................................... 42
LAN HUB.............................................................................................................. 42
Memory .................................................................................................................. 42
Modem Card.......................................................................................................... 43
Mouse...................................................................................................................... 44
Monitor................................................................................................................... 44
Power Supply........................................................................................................ 45
Printer...................................................................................................................... 45
Scanner ................................................................................................................... 45
SCSI Card .............................................................................................................. 45
Sound Card ............................................................................................................ 46
USB HUB & USB 2.0 DEVICE...................................................................... 46
ZIP/LS120.............................................................................................................. 46
SOFTWARE COMPATIBILITY LIST...................................................48
DOS......................................................................................................................... 48
Windows................................................................................................................. 48
THERMAL IMAGE TEST.......................................................................49
VCORE WAVEFORM MEASUREMENT-Ver1.1................................50
VCORE WAVEFORM MEASUREMENT.............................................50
Vcore Ripple Test(Dos Mode).......................................................................... 50
Vcore Transient Test(Dos Mode).................................................................... 51
Vcore Ripple Test(Open up the DOS Editor)............................................... 52
Vcore Ripple Test(Standby/Resume Mode).................................................. 53
Vcore Ripple Test(Standby/Resume Mode).................................................. 54
Vcore Ripple Test(Standby/Resume Mode).................................................. 55
FOUR CORNER TEST-Ver1.1................................................................56
Test Equipment & Environment............................................................................... 56
VCORE OCP & OVP TEST-Ver1.1............................................................57

4
PRODUCT INFORMATION
Motherboard General Information
Vendor Biostar
Model Number M7VIQ
Version Number V0.90/V1.0/V1.1
Platform AT ATX ;Micro ATX Flex ATX
Chipset Details
System Chipset Vendor VIA
North Bridge Revision VT8375
South Bridge Revision VT8235
Super I/O Chip Vendor Winbond
Super I/O Revision Number W83697HF
Clock Generator Vendor CY
Clock Generator Revision W312-02H
Audio Chipset Vendor VIA
Audio Chipset Revision VT1612A
LAN Chipset Vendor VIA
LAN Chipset Revision VT6103 BIOS Details
BIOS Vendor AMI ;Award Phoenix Others
BIOS Revision Number VIQ0903x
BIOS Memory Size 1M ;2M 4M
Flash EPROM BIOS ;Yes No
CPU Supports
Type CPU CPU Frequency Front Side Bus Comments:
Socket A AMD Athlon XP Max = 2.6G Hz Max = 133
Socket A AMD Duron Max = 1.3G Hz Max = 100
Memory Supports
Maximum Memory Support DDR 1024 (MB)
Number of Memory Slots ;DIMM 2 .
Type of Memory Supported VCM SDRAM RDRAM ;DDR RAM
Parity Support Yes ;No
ECC Support Yes ;No
On-board Features and Devices
No of PCI Full Length Slots 2 ;3 4 5
No of ISA Full Length Slots 1 2 3 4 ;None
AMR Slot Support Yes ;No
CNR Slot Support ;Yes No
ACR Slot Support Yes ;No
Number of Shared Slots ;1 None

5
66/100/133 MHz Front Side Bus Supports ;Yes No
PC 133 Support ;Yes No
DDR 266 Support ;Yes No
PCI v2.2 Compliance ;Yes No
ATA-3 Compliance ;Yes No
ATAPI Compliance ;Yes No
Ultra DMA 33 Support ;Yes No
Ultra DMA 66 Support ;Yes No
ATA-100 Support ;Yes No
USB 1.1 Connector Support ;Yes No
USB 2.0 Connector Support ;Yes No
AGP (4X) Slot Support ;Yes No
Support AGP SideBand Addressing Mode ;Yes No
Infrared Support ;Yes No
Enhanced Parallel Port ;Yes No
DMI Compliance ;Yes No
Hardware Monitor Support ;Yes No
ACPI v1.0B/APM v1.2 Compliance ;Yes No
On-board Graphics Controller ;Yes No
On-board Network Adapter 1Mb 10Mb ;100Mb No
On-board Audio Device Hardware ;AC97 CODEC No
Digital Video Connector Support ;Yes No
Other Function Support
Mechanical
Board Dimensions Length 24.4 cm Width 22.9 cm
Visual Inspection of Soldering ;Excellent Fair Poor
Visual Inspection of Layout Placement Connectors Quality
Screw Holes Line Up with Case ;Yes No ;Excellent Fair Poor
Power Connector placement in PCB ;Yes No ;Excellent Fair Poor
DIMM/RIMM Socket placement in PCB ;Yes No ;Excellent Fair Poor
CPU Socket placement in PCB ;Yes No ;Excellent Fair Poor
FAN Connector placement in PCB ;Yes No ;Excellent Fair Poor
FDD Connector placement in PCB ;Yes No ;Excellent Fair Poor
IDE Connector placement in PCB ;Yes No ;Excellent Fair Poor
Front Panel Connectors in PCB ;Yes No None ;Excellent Fair Poor
PS/2 Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
USB Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
COM Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
Printer Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
VGA Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
Audio Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor
Game Port Connectors Line Up in Case ;Yes No None ;Excellent Fair Poor

6
AGP Slot(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor
ISA Slots(Card) Line Up in Case Yes No ;None Excellent Fair Poor
PCI Slots(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor
AMR Slot(Card) Line Up in Case Yes No ;None Excellent Fair Poor
CNR Slot(Card) Line Up in Case ;Yes No None ;Excellent Fair Poor
ACR Slot(Card) Line Up in Case Yes No ;None Excellent Fair Poor
Daughter Card Slot in PCB Yes No ;None Excellent Fair Poor
Wake-on LAN connector in PCB ;Yes No None ;Excellent Fair Poor
Wake-on Modem connector in PCB Yes No ;None Excellent Fair Poor
CD Audio-in Connector in PCB ;Yes No None ;Excellent Fair Poor
AUX Audio-in Connector in PCB Yes No ;None Excellent Fair Poor
Telephony Connector in PCB ;Yes No None ;Excellent Fair Poor
Digital Video Connector Yes No ;None Excellent Fair Poor
Other Jumper in PCB ;Yes No None ;Excellent Fair Poor
Comments:

7
DESIGN REVIEW ver 1.1
Mainboard Voltage Measurement
Voltage List Voltage SPEC Voltage Measured Result
Battery Voltage 3.0V 3.15 Pass
Battery Current 7uA 1.9 Pass
+5V 5.0V+-5% 5.03 Pass
+12V 12.0V+-5% 12.25 Pass
-5V -5.0V+-5% -5.00 Pass
-12V -12.0V+-10% -12.57 Pass
+3.3V +3.3V+-5% 3.34 Pass
Bus Clock
Clock Frequency Spec Value
(MHz) Measured Value (MHz) Pass/Fail
CPU and Clock Host 100.00 100.0 Pass
133.33 133.0 Pass
DDR_RAM Clock 100.00 100.0 Pass
133.33 133.7 Pass
PCI Clock 33 33.33 Pass
AGP Clock 66.67 66.67 Pass
USB Clock 48 47.85 Pass
Reference Clock 14.31818 14.29 Pass
Clock Voltage Level Spec Value (v) Measured Value Pass/Fail
CPU and Host Clock Voltage Level 2.5v 2.5 Pass
DDR_RAM Clock Voltage Level 2.5v 2.46 Pass
PCI Clock Voltage Level 3.3v 3.30 Pass
AGP Clock Voltage Level 3.3v 3.30 Pass
Reference Clock Voltage Level 3.3v 3.18 Pass
Clock Timing Spec Value (v) Measured Value Pass/Fail
CPU Clock High Time 100.00 Min 2.5ns 3.32 Pass
133.33 Min 1.4ns 3.22 Pass
CPU Clock Low Time 100.00 Min 2.4ns 5.28 Pass
133.33 Min 1.4ns 3.40 Pass
CPU Clock Rising Time 100.00 ~ 2.52 Pass
133.33 ~ 0.32 Pass
CPU Clock Falling Time 100.00 0.4ns~1.6ns 1.04 Pass
133.33 0.4ns~1.6ns 0.56 Pass
PCI Clock High Time Min.11ns 12.4 Pass
PCI Clock Low Time Min.11ns 12.9 Pass
PCI Clock Rising Time 1ns~4ns 2.3 Pass
PCI Clock Falling Time 1ns~4ns 2.4 Pass

8
REQUIRED BIOS DEFAULT SETTINGS
Lists Specification Result
BIOS FEATURES SETUP
Virus Warning Disabled Pass
Boot Seq/ Floppy Setup Press Enter Pass
First Boot Device Floppy Pass
Second Boot Device HDD-0 Pass
Third Boot Device LS120 Pass
Boot Other Device Enabled Pass
Swap Floppy Drive Disabled Pass
Boot Up Floppy Seek Enabled Pass
CPU Internal cache Enabled Pass
External Cache Enabled Pass
CPU L2 Cache ECC Checking Enable Pass
Quick Power On Self Test Enabled Pass
Boot Up NumLock Status On Pass
Gate A20 Option Fast Pass
Typematic Rate Setting Disabled Pass
Typematic Rate(Chars/Sec) 6 Pass
Typematic Delay(MSEC) 250 Pass
Security Option Setup Pass
APIC Mode Enabled Pass
MPS Version Control For OS 1.4 Pass
OS Select For DRAM>64MB Non-OS2 Pass
Video BIOS Shadow Enabled Pass
Summary Screen Show Disabled Pass
CHIPSET FEATURES SETUP
DRAM Clock/Drive Control Press Enter Pass
Current FSB Frequency 133 MHZ Pass
Current DRAM Frequency 133 x 2 MHZ Pass
DRAM Clock By SPD Pass
DRAM Timing By SPD Pass
x SDRAM CAS Latency 2.5 Pass
x Bank Interleave Disabled Pass
x Precharge to Active(Trp) 3T Pass
x Active to Precharge(Tras) 6T Pass
x Active to CMD(Trcd) 3T Pass
DRAM Command Rate 2T Command Pass
AGP & P2P Bridge Control Press Enter Pass
AGP Aperture Size 64M Pass
AGP Mode 4X Pass
AGP Driving Control AUTO Pass

9
x AGP Driving Value DA Pass
AGP Fast Write Disabled Pass
AGP Master 1 WS Write Disabled Pass
AGP Master 1 WS Read Disabled Pass
CPU & PCI Bus Control Press Enter Pass
PCI 1Master 0 WS Write Enabled Pass
PCI 2Master 0 WS Write Enabled Pass
PCI1 Post Write Enabled Pass
PCI2 Post Write Enabled Pass
PCI Delay Transaction Enabled Pass
Memory Hole Disabled Pass
System BIOS Cacheable Disabled Pass
Video RAM Cacheable Disabled Pass
VGA Share Memory Size 32M Pass
POWER MANAGEMENT SETUP
ACPI function Enabled Pass
ACPI Suspend Type S1(POS) Pass
Power Management Option User Define Pass
HDD Power Down Disabled Pass
Suspend Mode Disabled Pass
Video Off Option Suspend -> Off Pass
Video Off Method V/H SYNC+Blank Pass
MODEM Use IRQ 3 Pass
Soft-Off by PWRBTN Instant-Off Pass
State After Power-Failure OFF Pass
Wake Up/Power On Control Press Enter Pass
PowerOn by PCI Card Disabled Pass
Wake Up On LAN/Ring Disabled Pass
RTC Alarm Resume Disabled Pass
Date (of Month) 0 Pass
Resume Time (hh:mm:ss) 0 : 0 : 0 Pass
Reload Global Timer Event Press Enter Pass
VGA OFF Pass
LPT & COM LPT/COM Pass
HDD & FDD ON Pass
PCI Master Off Pass
PnP / PCI CONFIGURATION
PnP OS Installed NO Pass
Reset Configuration Data Disabled Pass
Resources Controlled By Auto(ESCD) Pass
IRQ Resources Press Enter Pass
PCI/VGA Palette Snoop Disabled Pass
Assign IRQ for VGA Enabled Pass

10
Assign IRQ for USB Enabled Pass
INTEGRATED PERIPHERALS
OnChip IDE Device Press Enter Pass
OnChip Primary PCI IDE Enabled Pass
OnChip Secondary PCI IDE Enabled Pass
IDE Prefetch Mode Enabled Pass
Primary Master PIO Auto Pass
Primary Slave PIO Auto Pass
Secondary Master PIO Auto Pass
Secondary Slave PIO Auto Pass
Primary Master UDMA Auto Pass
Primary Slave UDMA Auto Pass
Secondary Master UDMA Auto Pass
Secondary Slave UDMA Auto Pass
IDE HDD Block Mode Enabled Pass
OnChip PCI Device Press Enter Pass
VIA-3058 AC97 Audio Auto Pass
VIA-3068 MC97 Modem Auto Pass
VIA-3043 OnChip LAN Enabled Pass
Onboard Lan Boot ROM Disabled Pass
SuperIO Device Press Enter Pass
Onboard FDC Controller Enabled Pass
Onboard Serial Port 1 3F8/IRQ4 Pass
Onboard Serial Port 2 Disabled Pass
UART Mode Select IrDA Pass
RxD ,TxD Active Hi,Lo Pass
IR Trasmission Delay Enabled Pass
UR2 Duplex Mode Half Pass
Use IR Pins IR-RX2TX2 Pass
Onboard Parallel Port 378/IRQ7 Pass
Parallel Port Mode EPP Pass
EEP Mode Select EPP1.7 Pass
ECP Mode Use DMA 3 Pass
Game Port Address 201 Pass
Midi Port Address 330 Pass
Midi Port IRQ 10 Pass
Init Display First PCI Slot Pass
OnChip USB Controller Enabled Pass
USB Keyboard Support Disabled Pass
PC Health Statues Write Actual Values
Current CPU Temp 63°C/ 145°F
Current CPU FAN Speed 7031 RPM

11
Current SYS FAN Speed 4782 RPM
CPU Voltage 1.66 V
+ 3.3 V 3.24 V
+ 5.0 V 4.86 V
+ 12 .0V 12.34 V
- 12.0 V (- )12.11 V
- 5 .0V (-) 5.09 V
Show H/W Monitor in POST Enabled
Shutdown Temperature Disabled
Comments:

12
FUNCTIONALITY
Setup Installation Test Of Operating System Pass/Fail
Windows ME Pass
Windows 2000 Professional Pass
Windows XP Home Edition Pass
Windows XP Professional Pass
Linux (Red Hat 7.3) Pass
Basic On-board Function Test
Test Platform MS-DOS Operating Comment
CPU AMD ATHLON XP 2000+
Memory SAMSUNG 128 M * 2
HDD QUANTUM 40 G
CDROM PIONNER / DVD105S
Sound Card Onboard / VIA VT1612A
Video Card Onboard
LAN Card Intel 82557
Test Item Pass/Fail
Clear CMOS with Jumper Pass
Cold Boot (Power Turn on ) Pass
CMOS Load Default Setup Pass
Memory Size Counter Check Pass
BIOS Lock Function Pass
Warm Boot (HW/SW Reset) Pass
System Configuration Review (CPU Type/Cache/SDRAM/HDD…) Pass
Power Fail Function Test Pass
Prompt Into DOS Mode Pass
Typing Some DOS Comment Pass
Run Scandisk Pass
PS/2 Keyboard Test Pass
USB Keyboard Legacy Support Test Pass
Boot Floppy Driver A Pass
FDISK Hard Disk Driver Pass
Format Hard Disk Driver Pass
Boot Hard Disk Driver C Pass
Power LED Check Pass
HDD LED Check Pass
Systems Speaker Pass
Buzz N/A
BIOS / Update BIOS Utility Test Pass
SMI Function Test ---
SMI Pin Function Test Pass

13
Time Out Function Test Pass
Power LED Flash Check Pass
Power On Control ---
Power On By RTC Test Pass
Power On By LAN Test Pass
Power On By Modem Test Pass
Boot Management ---
Boot Form CD-ROM Pass
Boot From SCSI HDD Pass
Boot From ATAPI ZIP/LS120 Drive Pass
Boot From LAN Pass
RTC Test ---
CMOS RTC Date Check Pass
Windows ME RTC Date Check Pass
CMOS RTC Time Out Test Pass
Windows ME RTC Time Out Test Pass
Memory Comparability Test ---
BMEM Pass
Checkit 4.0 ---
System Board Test Pass
Memory Test Pass
Hard Disk Test Pass
Floppy Test Pass
Serial Port Test Pass
Parallel Port Test Pass
Modem Test Pass
Video Card Test Pass
Printer Test Pass
Keyboard Test Pass
AMIDiag 6.13U ---
System ---
Processor Test Pass
DMA Controller Test Pass
Interrupt Controller Test Pass
Timer Test Pass
Real Time Clock Test Pass
CMOS Validity Test Pass
Speaker Test Pass
PCI System Test Pass
Plug-n-Play Test Pass
DMI Test Pass
Memory ---
BIOS ROM Test Pass

14
Parity Test Pass
Pattern Test Pass
Extended Pattern Test Pass
Walking 1’s Test Pass
Walking 0’s Test Pass
Random Memory Test Pass
Address Test Pass
Refresh Test Pass
Data Bus Test Pass
Cache Memory Test Pass
Quick Test Pass
IDE ---
IDE HDD Test Pass
IDE CD Test Pass
FDD ---
Floppy Controller Test Pass
Drive Speed Test Pass
Diskette Read Test Pass
Elevator Seek Test Pass
Disk Change Line Test Pass
KBD ---
Controller Test Pass
Scan/ASCII code test Pass
LED Test Pass
Clock Line Test Pass
Data Line Test Pass
Video ---
VGA Controller Test Pass
Video Memory Test Pass
AGP Test Pass
Attribute Test Pass
Page Selection Test Pass
Color Test Pass
Text Mode Test Pass
Graphics Mode Test Pass
VESA Video Mode Test Pass
VESA Monitor Test Pass
Misc. ---
Serial Port Test Pass
Parallel Port Test Pass
PS/2 Mouse Test Pass
APM Functionality Test Pass
Device APM Test Pass

15
ACPI Test Pass
I82557 Ethernet chip Pass
Comments:
Test Platform Windows ME Operating Comment
CPU Athlon 2.2G
Memory Samsung 256M X2
HDD Seagate 40G
CDROM Sony DVD DOU-1621
Sound Card Onboard
Video Card Onboard
LAN Card Onboard
Test Item Pass/Fail
System Comparability Test ---
Windows ME Setup Installation Test Pass
Supports Driver Installation Test Pass
System Properties Information Review (System Device Manager) Pass
Standby Mode Test Pass
Shut Down Test Pass
Restart Test Pass
Scandisk Test Pass
Reboot The Windows Test For Over Night Pass
Suspend To RAM (S3) Test ---
Standby Button for S3 (Enter) Pass
Power Button for S3 (Enter and Wake up) Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Power LED Flash check Pass
Onboard Audio For S3 Function Supports Test (Play CD/DVD) Pass
Hibernate(S4) Test ---
Standby Button for S4 (Enter) Pass
Power Button for S4 (Enter and Wake up) Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Device Comparability Test ---
PS/2 Connector Test ---
PS/2 Keyboard Test Pass
PS/2 Mouse Test Pass
COM Port Test ---
Add Serial Mouse PnP Test Pass
Add Modem PnP Test Pass
Print Port Test ---

16
Add Printer PnP Test Pass
FDD Connector Test ---
Create Windows ME Startup Disk Pass
Format 1.44 Floppy Driver Pass
IDE Connectors Test ---
CD-ROM Data Read Test Pass
DVD-ROM Data Read Test Pass
Ultra DMA 100/133 Hard Disk Test Pass
USB Ports Test ---
Add Keyboard PnP Test Pass
Add Mouse PnP Test Pass
PCI Slots Test ---
Add LAN Cards Test ---
Boot ROM Function Test Pass
Login Server Test Pass
ADSL Link Test Pass
Add SCSI Cards Test ---
Add SCSI Cards For PnP Function Test Pass
Add Sound Card Test ---
Add Sound Cards For PnP Function Test Pass
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Audio Control Panel Function Test Pass
Game Port Test Pass
Sound Recorder Test Pass
Speaker Out Quality Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MP3 Test Pass
CNR Slots Test ---
Add CNR Software Modem Card Test Pass
Connect Performance Check Pass
VGA Function Test ---
VGA Drivers Setup Installation Test Pass
Display Properties Information Review Pass
Run 3D Screen Saver Pass
VGA Resolution Test ( Monitor : ViewSonic GF775 /AGP: on-board ) ---
Resolution Color Depth Optimal 75 Hz 85 Hz 100 Hz ---
640x480 16 bit √√√√Pass
640x480 32 bit √√√√Pass
800x600 16 bit √√√none Pass
800x600 32 bit √√√none Pass

17
1024x768 16 bit √√√√Pass
1024x768 32 bit √√√√Pass
1152x864 16 bit √√√none Pass
1152x864 32 bit √√√none Pass
Check Screen Have No Any Shadow Or Garbage Pass
Audio Function Test ---
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Audio Control Panel Function Test Pass
Sound Recorder Test Pass
Run MPG Files Pass
Speaker Out Quality Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MIDI Test Pass
Playing Video Test Pass
Playing MP3 Test Pass
Onboard Audio For S1 Function Supports Test Pass
Windows Utility Test ---
BCM Diagnostics ---
System Info Pass
DMI Info Pass
Processor Test Pass
Memory Test Pass
Audio Test Pass
Video Test Pass
Graphics Test Pass
Hard Disk Test Pass
Floppy Disk Test Pass
CD-ROM Test Pass
Stress Test –Loop 100 Pass
MS Mouse Pass
MS Joystick Pass
MS ScanDisk Pass
Winstone 2001 ---
Business Winstone 2001 Pass
Content Creation Winstone 2002 Pass
Winbench 99 V1.2 ---
Business Disk WinMark 99 Pass
Business Graphics WinMark 99 Pass
DirectDraw Tests Pass
Disk Inspection Tests Pass

18
Disk WinMark Pass
GDI/USER Inspection Tests Pass
High-End Disk WinMark 99 Pass
High-End Graphics WinMark 99 Pass
Video Tests Pass
3D Mark 2001 SE ---
3D Marks Pass
Demo Mode Pass
PC Mark2002 ---
CPU Score Pass
Memory Score Pass
HDD Score Pass
Others ---
Final Reality Pass
USBready Pass
WinDVD 2000 Pass
Wintune 98 Test Pass
Comments:
Test Platform Windows2000 Operating Comment
CPU ATHLON XP 2.2 G +
Memory TWINMOS / HYNIX 256M * 2
HDD IBM 76.8 G /
CDROM PIONNER / DVD-116
Sound Card Onboard / VIA
Video Card Onboard
LAN Card Onboard LAN / VIA VT6103
Test Item Pass/Fail
System Comparability Test ---
Windows 2000 Setup Installation Test Pass
Supports Driver Installation Test Pass
System Properties Information Review Pass
S1, S3 ,S4 Mode Test Pass
Shut Down Test Pass
Restart Test Pass
Scandisk Test Pass
Setup installation Microsoft Office 2000 Test Pass
Hibernate(S4) Test ---
Standby Button for S4 (Enter) Pass
Power Button for S4 (Enter and Wake up) Pass

19
Windows Set RTC Time out for S4 (Enter and Wake up) Pass
Enter S4 mode For 1/5/10/30/60/120 Minutes Then To Do Wake Up Test. Pass
Wake Up By LAN Test Pass
Wake Up By Ring Test Pass
Enable Scheduled Task Runs at Specified time Test (RTC wake up) Pass
Device Comparability Test ---
PS/2 Connector Test ---
PS/2 Keyboard Test Pass
PS/2 Mouse Test Pass
COM Port Test ---
Add Serial Mouse PnP Test Pass
Add Modem PnP Test Pass
Print Port Test ---
Add Printer PnP Test Pass
FDD Connector Test ---
Format 1.44 Floppy Driver Pass
IDE Connectors Test ---
Ultra DMA 33 Hard Disk Test Pass
Ultra DMA 66 Hard Disk Test Pass
Ultra DMA 100 Hard Disk Test Pass
CD-ROM Test Pass
DVD-ROM Data Read Test Pass
ZIP Device Driver Test Pass
Format ZIP Driver With Floppy A Type Pass
LS120 Device Driver Test Pass
Onboard LAN Test ---
Boot ROM Function Test Pass
Login Server Test Pass
Peer to Peer 10Mbps or 100Mbps Data Transfer Test Pass
Wake On LAN Test (Standby Mode) Pass
ADSL Link Test Pass
PCI Slots Test ---
Add SCSI Card Test Pass
Add LAN Card Test Pass
Wake On LAN Test (Standby Mode) Pass
Add Sound Card Test Pass
Add Modem Card Test Pass
Wake On Modem Test (Standby Mode) Pass
CNR Slots Test ---
Add Modem Card Test Pass
VGA Function Test ---
VGA Drivers Setup Installation Test Pass
Display Properties Information Review Pass

20
VGA Resolution All Test Pass
Screen Saver Test Pass
Check Screen Have No Any Shadow Or Garbage Pass
Playing MPEG Files Test Pass
Playing VCD Test Pass
Playing DVD Test(With WinDVD 2000) Pass
Audio Function Test ---
Audio Drivers Setup Installation Test Pass
System Properties Information Review Pass
Speaker Out Quality Test Pass
R/L Channel Check Pass
CD-In Function Check Pass
Line-In Function Check Pass
Mic-In Function Check Pass
Audio Control Panel Function Test Pass
Sound Recorder Test Pass
Playing Audio CD Test Pass
Playing Wave Test Pass
Playing MIDI Test Pass
Playing Video Test Pass
Playing MP3 Test Pass
Game Port Test Pass
Windows2000 Utility Test Pass/Fail
BCM Diagnostics ---
System Info Pass
DMI Info Pass
Processor Test Pass
Memory Test Pass
Audio Test Pass
Video Test Pass
Graphics Test Pass
Hard Disk Test Pass
Floppy Disk Test Pass
CD-ROM Test Pass
Stress Test –Loop 100 Pass
MS Mouse Pass
MS Joystick Pass
MS ScanDisk Pass
BurnIn Test ---
CPU-Maths Pass
CPU-MMX/SSE Pass
Memory (RAM) Pass
2D Graphics Pass
