Birch Carisma n2800 User manual

The information contained in this document is subject to change without notice. We make no

warranty of any kind with regard to this material, including, but not limited to, the

implied warranties of merchantability and fitness for a particular purpose. We shall not be

liable for errors contained herein or for incidental or consequential damages in connection

with the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copy right. All rights are

reserved. No part of this document may be photocopied, reproduced or translated to another

language without the prior written consent of the manufacturer.

TRADEMARK

Intel®, Pentium® and MMX are registered trademarks of Intel® Corporation. Microsoft®

and Windows® are registered trademarks of Microsoft Corporation.

Main Board

CPU

PP7000CQ-T15 Intel® Atom™ processor N2800 (1M Cache, 1.86 GHz)

Chipset Intel® NM10 Express Chipset

System Memory Socket-type RAM device, 204PIN SO-DIMM DDR3 RAM, up to 4GB

Graphic Memory Shared system memory up to 256MB

LCD Panel

PP7000CQ-T15

Panel Size 15”

Maximum Resolution 1024 x 768

Brightness 250 cd/m2

Contrast Ratio 600 : 1

Response Time 8 ms

View Angles (H/V) 160 / 160

Touch Panel Five Wires Resistive

Storage

HDD 2.5” SATA interface

Compact Flush Type Ⅰ&Ⅱ

Expansion

Mini-PCIE Socket One

Power

Power Adaptor Input AC 100-240V 2.5A 50/60Hz, Output DC 12V 6.66A

I / O

USB Six

Serial Four COM ports with RJ-45 Connector

Pin 9 with 5V / 12V power selectable

Parallel One LPT with adaptor cable

LAN One

2nd VGA Output One with optional adaptor cable

PS/2 One

Audio One Earphone & One Microphone

Control/Indicator

Power Button One

LED Indicators Power (Green), HDD (Red), LAN(Orange)

Optional Peripherals

Magnetic Card Reader ISO Track 1/2/3, USB interface

VFD customer display 20 x 2 characters, RS-232 interface

Dimensions

PP-7000CQ-T15 358(W) X 300(L) X 52(H) mm

Environment

Operating Temperature 0°C ~ 40°C ( 32°F ~ 104°F )

Storage Temperature - 20°C ~ 60°C ( - 4°F ~ 140°F )

Operating Humidity 10% - 80% RH non condensing

Storage Humidity 10% - 80% RH non condensing

Model Number

PP7000CQ – 15 15＂TFT LCD Intel® Atom™ processor N2800 (1M Cache, 1.86 GHz)

If any item is missing, please contact your sale agent immediately.

Take the system unit out from the carton. Remove the unit by carefully holding the foam inserts

and remove slowly to protect the system. The following items should be found in the carton:

1. CD that including all

driver and manual

2. The System

. Power Adaptor 4. AC Power Cord

5. Printer Port conversion cable 6. Two RS-232 port

conversion cables

7. Second Display cable (Optional)

Please unplug the AC power of the adapter before opening any part of the system.

Since the standby power is always on after the adapter is plugged in. It may cause

permanent damage to your system when you open any part of it.

MSR(Optional)

VFD(Optional)

USB5

USB6

Earphone

MIC

PowerSW

The connector panel

Please notice that all Four COM ports using RJ-45 connector and two RJ-45 to

DB-9 conversion cables are provided in the package.

Please notice that the Printer and VGA connectors in the second level, using JST PHD

pitch 1.25 type connectors. The package includes a Printer Port adapter cable to connect

to this connector and a centronic connector. The VGA, Audio adapter is optional

accessory.

Introducing BIOS

Notice! The BIOS options in this manual are for reference only.

Different configurations may lead to difference in BIOS

screen and BIOS screens in manuals are usually the first BIOS

version when the board is released and may be different from

your purchased motherboard. Users are welcome to download the

latest BIOS version form our official website.

The BIOS is a program located on a Flash Memory on the motherboard. This program

is a bridge between motherboard and operating system. When you start the computer,

the BIOS program will gain control. The BIOS first operates an

auto-diagnostic test called POST (power on self test) for all the necessary hardware, it

detects the entire hardware device and configures the parameters of the hardware

synchronization. Only when these tasks are completed done it gives up control of

the computer to operating system (OS). Since the BIOS is the only channel for

hardware and software to communicate, it is the key factor for system stability, and in

ensuring that your system performance as its best.

Entering Setup

Power on the computer and by pressing <Del> immediately allows you to enter Setup.

If the message disappears before your respond and you still wish to enter Setup,

restart the system to try again by turning it OFF then ON or pressing the “RESET”

button on the system case. You may also restart by simultaneously pressing <Ctrl>,

<Alt> and <Delete> keys. If you do not press the keys at the correct time and the

system does not boot, an error message will be displayed and you will again be

asked to Press <Del> to enter Setup

BIOS Menu Screen

The following diagram show a general BIOS menu screen:

Menu Bar

General Help Items

Menu Items Current Setting Value

Function Keys

3-3 Function Key BIOS Menu Screen

In the above BIOS Setup main menu of, you can see several options. We will explain

these options step by step in the following pages of this chapter, but let us first see a

short description of the function keys you may use here:

Press←→ (left, right) to select screen

Press ↑↓ (up, down) to choose, in the main menu, the option you want to confirm

or to modify.

Press <Enter> to select.

Press <+>/<–> keys when you want to modify the BIOS parameters for the active

option.

[F1]: General help.

[F2]: Previous value.

[F3]: Optimized defaults.

[F4]: Save & Reset.

Press <Esc> to quit the BIOS Setup.

Getting Help

Main Menu

The on-line description of the highlighted setup function is displayed at the top

right corner the screen.

Status Page Setup Menu/Option Page Setup Menu

Press F1 to pop up a small help window that describes the appropriate keys to use

and the possible selections for the highlighted item. To exit the Help Window, press

<Esc>.

Menu Bar

There are six menu bars on top of BIOS screen:

Main To change system basic configuration

Advanced To change system advanced configuration

Chipset To change chipset configuration

Boot To change boot settings

Security Password settings

Save & Exit Save setting, loading and exit options.

User can press the right or left arrow key on the keyboard to switch from menu bar.

The selected one is highlighted.

Main Menu

Main menu screen includes some basic system information. Highlight the item

and then use the <+> or <-> and numerical keyboard keys to select the value you want

in each item.

System Date

Set the date. Please use [TAB] to switch between data elements.

System Time

Set the time. Please use [TAB] to switch between time elements.

Advanced Menu

Launch PXE OpROM/

Use this item to enable or disable boot option for legacy network devices.

Launch Storage OpROM

Use this item to enable or disable boot option for legacy mass storage devices with

option ROM.

PCI Subsystem Settings

Press [Enter] to enter and make settings for PCI Express Settings and PCI Express

PCI ROM Priority

In case of multiple Option ROMs (Legacy and EFI Compatible), specifies what PCI

Option ROM to launch

ACPI Settings

Enable ACPI Auto Configuration

Enables or Disables BIOS ACPI Auto Configuration

ACPI Sleep State

Use this item to select the highest ACPI sleep state the system will enter when the

suspend button is pressed.

The optional settings are: [S1(CPU Stop Clock)]; [S3(Suspend to RAM)].

Lock Legacy Resources

Enable or Disable Lock of Legacy Resources

PCI Express Wake

Enable Resume by PCI Exp

Resume by RTC Alarm

Set Resume by RTC Alarm

CPU Configuration

Hyper-Threading

Enable For Windows XP and Linux (OS optimized for Hyper-Threading Technology)

and Disable for other OS (OS not optimized for Hyper-Threading Technology)

Execute Disable Bit

XD can Prevent certain classes of malicious buffer overflow attacks

when combined with a supporting OS (Windows Server 2003 SP1, Windows XP

SP2, SuSE Linux 9.2, Redhat Enterprise 3 Update 3.)

Limit CPUID Maximum

Disable For Windows XP

IDE Configuration

SATA Controller

The optional settings are: [Disabled]; [Enhanced]

Configure SATA as

Select a configuration for SATA Controller

USB Configuration

Legacy USB Support

The optional settings are: [Auto]; [Disabled]; [Enabled].

EHCI Hand-off

The optional settings are: [Disabled]; [Enabled].

F81866 Super IO Configuration

Serial Port 0 Configuration

Press [Enter] to make settings for the following items:

Serial Port
