BITMAIN AntMiner L3+ User manual

L3+ Server
Installation Guide
Document Version 0.1
April 2017
© Copyright Bitmain Technologies Holding Company 2007 – 2022. All rights reserved.
Bitmain Cayman (hereinafter referred to as ‘Bitmain’) reserves the right to make corrections, modifications,
enhancements, improvements, and other changes to its products and services at any time and to discontinue
any product or service without notice.
Customers should obtain the latest relevant information before placing orders and should verify that such
information is current and complete. All products are sold subject to Bitmain's terms and conditions of sale
supplied at the time of order acknowledgment.
Bitmain warrants performance of its products to the specifications applicable at the time of sale in
accordance with Bitmain's standard warranty. Testing and other quality control techniques are used to the
extent Bitmain

L3+ Server Installation Guide
--‐2-
-‐
deems necessary to support this warranty. Except where mandated by government requirements, testing of
all parameters of each product is not necessarily performed.
Bitmain assumes no liability for thirdm party applications assistance. Customers are responsible for their
products and applications using Bitmain components. To minimize the risks associated with customer
products and applications, customers should provide adequate design and operating safeguards.
Bitmain does not warrant or represent that any license, either express or implied, is granted under any
Bitmain patent right, copyright or other Bitmain intellectual property right relating to any combination,
machine, or process in which Bitmain products or services are used. Information published by Bitmain
regarding thirdm party products or services does not constitute a license from Bitmain to use such products
or services or a warranty or endorsement thereof. Use of such information may require a license from a third
party under the patents or other intellectual property of the third party, or a license from Bitmain under the
patents or other intellectual property of Bitmain.
Resale of Bitmain products or services with statements different from or beyond the parameters stated by
Bitmain for that product or service voids all express and any implied warranties for the associated Bitmain
product or service and is an unfair and deceptive business practice. Bitmain is not responsible or liable for any
such statements.
All company and brand products and service names are trademarks or registered trademarks of their
respective holders.
All text and figures included in this publication are the exclusive property of Bitmain, and may not be copied,
reproduced, or used in any way without the express written permission of Bitmain. Information in this
document is subject to change without notice and does not represent a commitment on the part of Bitmain.
Although the information in this document has been carefully reviewed, Bitmain does not warrant it to be free
of errors or omissions. Bitmain reserves the right to make corrections, updates, revisions or changes to the
information in this document.
Bitmain
Tel:[phone]
www.bitmain.com

L3+ Server Installation Guide
--‐3-
-‐
Table of Contents
1. Overview 4
1.1 L3+ Server Components ____________________________________________________________________ 5
1.2 Specifications__________________________________________________________________________ 6
2. Connecting the Power Supply __________________________________________________________________ 7
3. Setting Up the Server _________________________________________________________________________
9
4. Configuring the Server
11
4.1 Setting Up the Pool 11
4.2 Modifying the Frequency 12
5. Monitoring Your Server
13
6. Administering Your Server
14
6.1 Checking Your Firmware Version 14
6.2 Upgrading Your System 14
6.3 Modifying Your Pass word 15
6.4 Restoring Initial Settings 15

L3+ Server Installation Guide
1. Overview
--‐4-
-‐
1. Overview
The L3+ server is Bitmain’s newest version in the L3+ server series. It boasts a state-of-the-art BM1485
custom-made chip. All L3+ servers are tested and configured prior to shipping to ensure easy set up.
Power supply unit is not included. Please provide your own ATX power supply.

L3+ Server Installation Guide
1. Overview
--‐5-
-‐
1.1 L3+ Server Components
The L3+ server main components and controller front panel are shown in the following figure:
1.2 Specification

L3+ Server Installation Guide
1. Overview
--‐6-
-‐
The server does not contain a DC/DC converter; therefore, higher input voltage will cause higher
Mining enfficiency.
Feature
Description
Ideal Hash Rate
504MH/S
Default chip frequency
384M
Estimated wall outlet power
consumption (with APW3, 93%
efficiency, 25°C ambient
temperature)
800W +10%
Rated voltage
11.6 --‐ 13.00V
Estimated wall outlet power
efficiency (with APW3, 93%
efficiency, 25°C ambient
temperature)
1.6J/MH +10%
Dimensions (L x W x H)
352mm (l) x 130mm (w) x 187.5mm (h)
Net weight
5.2kg
Operating ambient temperature
0 -- ‐ 40°C

L3+ Server Installation Guide
--‐7-
-‐
Each hashboard must be powered by the same PSU on both connectors to prevent
possible damage and instability.
If you are using more than one PSU,power up the PSU connected to the controller AFTER you have
powered up the other PSU(s).
2. Connecting the Power Supply
2. Connecting the Power Supply
Nine PCI-e connectors are located at the top of the L3+ server for connecting the PSU as follows:
● Eight PCI- - ‐e connectors for the hash boards. Each hash board has a set of two PCI- - ‐e connectors.
● One PCI--‐e connector located on the controller.
To connect the power supply:
1. Connect PSU power cable connectors to each of the eight PCI-e connectors on the top of the L3+ server,
ensuring that each hash board is powered by the same PSU.
2. Connect a PSU power cable connector to the L3+ server PCI-e connector on the controller.
3. Connect the network cable to the ETH port.
4. To power up your L3+ server, connect the PSUs to the power wall outlet.

L3+ Server Installation Guide
--‐8-
-‐
2. Connecting the Power Supply
Figure 2- - ‐1. PCI- - ‐E Connectors -- ‐ Correct Connection
Figure 2- - ‐ 2. PCI- - ‐ E Connectors -- ‐ Incorrect Connection

L3+ Server Installation Guide
--‐9-
-‐
The file IPReporter.zip is supported by Microsoft Windows only.
The default DHCP network protocol distributes IP addresses automatically.
3. Setting Up the Server
3. Setting Up the Server
To set up the server:
1. Go to the following site: https://shop.bitmain.com/support/download
2. Choose ‘Others’ and download the following file: IPReporter.zip
3. Extract the file.3.
4. Rightm click IPReporter.exe and run it as Administrator.
5. Select one of the following options:
■ Shelf, Step, Position – suitable for farm servers to mark the location of the servers.
■ Default – suitable for home servers.
6. Click Start.

L3+ Server Installation Guide
-- ‐
10
-
- ‐
3. Setting Up the Server
7. On the controller board, click the IP Report button. Hold it down until it beeps (about 5 seconds).
The IP address will be displayed in a window on your computer screen.
8. In your web browser, enter the IP address provided.
9. Proceed to login using root for both the username and password.
10. In the Network section, you can assign a Static IP address (optional).
11. Click Save & Apply .

L3+ Server Installation Guide
-- ‐
11
-
- ‐
4. Configuring the Server
4. Configuring the Server
4.1 Setting Up the Pool
To configure the server:
1. click General Settings .
2. Set the options according to the following table:
Option
Description
Pool URL
Enter the URL of your desired pool.
The L3+ server can be set up with three mining pools, with decreasing
priority from the first pool (pool 1) to the third pool (pool 3).
The pools with low priority will only be used if all higher priority pools are
offline.
Worker
Your worker ID on the selected pool.
Password
The password for your selected worker.
3. Click Save & Apply to save and restart the server.

L3+ Server Installation Guide
-- ‐
12
-
- ‐
4. Configuring the Server
4.2 Modifying the Frequency (Applied only to fixed frequency firmware)
To modify the frequency value:
1. click Advanced Settings
2. Select a frequency. The default frequency for the L3+ server is 384M

L3+ Server Installation Guide
-- ‐
13
-
- ‐
table:
5. Monitoring Your Server
5. Monitoring Your Server
To check the operating status of your server:
1. Click the status marked below.
2. Monitor your server according to the descriptions in the following
Option
Description
ASIC#
Number of chips detected in the chain.
Frequency
ASIC frequency setting.
GH/S(RT)
Hash rate of each hash board ( MH/s)
Temp(PCB)
Temperature of each hash board (°C).(Applied only to server with fixed frequency)
Temp(Chip)
Temperature of the chips on each hash board (°C).
ASIC status
One of the following statuses will appear:
● O --‐ indicates OK
● X --‐ indicates error
● -- ‐ --‐ indicates dead
Note :The server will stop running when the PCB temperatu re is over 85°C

L3+ Server Installation Guide
-- ‐
14
-
- ‐
Make sure that the L3+ server remains powered during the upgrade process. If power fails
before the upgrade is completed, you will need to return it to Bitmain for repair.
6. Administering Your Server
6. Administering Your Server
6.1 Checking Your Firmware Version
To check your firmware version:
1. In System , click the Overview tab.
2. File System Version displays the date of the firmware your server use. In the example below, the server
is using firmware version 20170120.
6.2 Upgrading Your System
To upgrade the server’s firmware:
1. In System, click Upgrade .

L3+ Server Installation Guide
-- ‐
15
-
- ‐
Resetting your server will reboot it and restore its default settings. The red LED will
automatically flash once every 15 seconds if the reset is operated successfully.
6. Administering Your Server
2. For Keep Settings :
■ Select the check box to keep your current settings (default).
■ Clear the check box to reset the server to default settings.
3. Click the (Browse) button and navigate to the upgrade file. Select the upgrade file, then click Flash
image. A message appears notifying you if the L3+ server firmware can be upgraded and if yes, will
then proceed to flash the image.
4. When the upgrade is completed, the following message appears:
5. Click one of the following options:
■ Reboot - to restart the server with the new firmware.
■ Go Back - to continue mining with the current firmware. The server will load the new firmware
next time it is restarted.
6.3 Modifying Your Password
To change your login password:
1. In System , click the Administration tab.
2. Set your new password, then click Save & Apply.
6.4 Restoring Initial Settings
To restore your initial settings
1. Turn on the server and let it run for 5 minutes.
2. On the controller front panel, press and hold the Reset button for 10 seconds.

L3+ Server Installation Guide
- 16 -
