bitmore BM-BT5WEC User manual

1
0
0
%
R
E
C
Y
C
L
E
D
P
L
A
S
T
I
C
LED PULSE SPEAKER
USER GUIDE

IMPORTANT: READ AND RETAIN THIS MANUAL BEFORE FIRST USE!
BM-BT5WEC LED PULSE SPEAKER | 1
LED PULSE SPEAKER
PRODUCT OVERVIEW:
1. Charging Cable:
2. USB – Micro USB charging cable
3. LED Pulse Controls:
Volume Decrease (long press) /Previous track
(short press)
Play/Pause
Volume Increase (long press) / Next track
(short press)
4. Power Button
5. Micro SD/TF card slot
6. Micro USB Charging Port
SPECIFICATION:
Bluetooth: 5.0
Battery: Lithium-Polymer / 300mAh
Speaker output: 3W
Wireless Range: 10m
Product Size: 59 x 59 x 51mm
Material: 35% Wheat Straw + ABS
Light Indicators:
Red light: indicates charging and switches o when charging is complete.
Blue light: i) Quickly flashes when Bluetooth is in pairing mode.
ii) Solid illumination when successfully connected to a Bluetooth device. iii) Solid illumination
when audio is paused. iv) Slow flash whilst audio is playing.
.

Charging the LED Pulse:
Connect the Micro USB end of the supplied cable (or use another authorised cable) to the
Micro USB port on the LED Pulse
Connect the USB end to a mains adaptor (not supplied)
Charge the LED Pulse for appox 2-3 hours (you will see a red light whilst charging) or until the
red light switches o.
Connecting to Bluetooth:
Press the power button (6) to turn on the speaker
Ensure that your device has Bluetooth switched on
Search for and select “LED Pulse” -
You will see a quick blue flashing light whilst the LED Pulse and your device pairs.
Once connected, the blue light will turn solid
Use the buttons on the LED Pulse to control your audio experience
Micro SD/TF Card Audio:
Insert your Micro SD/TF card into the slot (5) with the contact surface facing downwards –
make sure to take extra care to insert it the correct way round, and do not force it. You could
damage your Micro SD/TF card or the LED Pulse.
Playback will automatically start.
Use the buttons on the LED Pulse to control your audio experience
SAFETY INFORMATION:
DO NOT place any metals or mental objects (including a device case/cover that has metal
components) on your device or this product whilst in use and connected to a power source. You
risk potential electrical shocks, static or other more dangerous incidents such as fire or death
DO NOT leave your device connected to this product when not in use or when charging
is complete
DO NOT cover this product or your device when in use
DO NOT expose this product to heat sources (including fire or direct sunlight)
DO NOT use or expose this product or your device to areas of high humidity, any liquids, gels or
aerosols or heavy dust, keep it dry and clean If this product encounters any liquid, immediately
unplug the product from any connected power sources or devices
DO NOT disassemble or modify this product – this could cause risk of injury, death,
or damage to property
BM-BT5WEC LED PULSE SPEAKER | 2

This product must only be used and stored in an ambient environment with a temperature
between 0-45 °C
Avoid dropping this product (or any other heavy impact which might damage the internal circuit)
Avoid cleaning this product using liquids or chemical substances (use a dry cloth only)
Only use attachments/accessories supplied by Bitmore or those certified by your
device manufacturer
This product is not a toy, DO NOT leave children unsupervised with this product.
Please use a genuine certified wall adaptor, such as one that is supplied with your
device manufacturer
DO NOT use a wall adaptor with a fast charge or high AMP output
DO NOT leave your device unattended for charging overnight
DO NOT use faulty, damaged or none certified (by your device manufacturer) plugs to charge
or discharge your devices
DO NOT use a plug with more than a 5W output
DO NOT operate this product where aerosols are or have recently been used or where oxygen is
being administered
DO NOT operate in a closed environment such as a pocket, handbag, backpack, under
a pillow etc
Get your 24-month Limited Guarantee and become a Bitmore member!
You must register your device via bitmore.co.uk within 30 days of purchase for the manufactur-
ing guarantee to be valid.
Plus get a “bit more” by gaining access to exclusive product giveaways, membership rewards and
discounts!
Subject to applicable law, parent company Bitmore Limited (UK) and Nuwave Channel Partners
BV (operating in the EU on behalf of Bitmore Limited) (hereinafter “Bitmore”4), sell its prod-
ucts (hereinafter “Product(s)”) with the intent that they are free of defects in manufacture and
workmanship for 24-months from the date of original purchase, except as noted below. Bitmore
warrants that its Products will be free of defects in material and workmanship under normal use
and service. This guarantee extends only to consumers and does not extend to Retailers. Bitmore
does not authorize anyone, including, but not limited to, retailers, the subsequent consumer
purchaser of the product from a retailer or remote purchasers, to obligate Bitmore in any way
beyond the terms set forth herein. This guarantee does not cover damage caused by misuse or
abuse; accident; the attachment of any unauthorized accessory; alteration to the product;
improper installation; unauthorized repairs or modifications; improper use of electrical/power
supply; loss of power; dropped Product; malfunction or damage of an operating part from failure
to provide manufacturer’s recommended maintenance; transportation damage; theft; neglect;
vandalism; or environmental conditions; loss of use; or any other conditions whatsoever that are
beyond the control of Bitmore.
BM-BT5WEC LED PULSE SPEAKER | 3

THE GUARANTEE PROVIDED HEREIN SHALL BE THE SOLE AND EXCLUSIVE GUARANTEE.
THERE SHALL BE NO OTHER WARRANTIES EXPRESS OR IMPLIED INCLUDING ANY
IMPLIED GUARANTEE OF MERCHANTABILITY OR FITNESS OR ANY OTHER OBLIGATION
ON THE PART OF THE COMPANY WITH RESPECT TO PRODUCTS COVERED BY THIS
GUARANTEE. BITMORE SHALL HAVE NO LIABILITY FOR ANY INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES. IN NO EVENT SHALL THIS GUARANTEE
REQUIRE MORE THAN THE REPLACEMENT OF ANY PART OR PARTS WHICH ARE FOUND
TO BE DEFECTIVE WITHIN THE EFFECTIVE PERIOD OF THE GUARANTEE. REFUNDS WILL
BE GIVEN IF REPLACEMENT PARTS FOR DEFECTIVE MATERIALS ARE NOT AVAILABLE,
BITMORE RESERVES THE RIGHT TO MAKE PRODUCT SUBSTITUTIONS IN LIEU OF REPAIR
OR REPLACEMENT.
This guarantee does not extend to the purchase of opened, used, repaired, repackaged and/or
resealed products, including but not limited to sale of such products on Internet auction sites
and/or sales of such Products by surplus or bulk resellers. All warranties or guarantees shall
immediately cease and terminate as to any Products or parts thereof which are repaired,
replaced, altered, or modified, without the prior express and written consent of Bitmore.
This Agreement is made for the benefit of the parties and is not intended to benefit any third
party or be enforceable by any third party. The rights of the parties to terminate, rescind, or
agree any amendment, waiver, variation, or settlement under or relating to this Agreement are
not subject to the consent of any third party.
This guarantee provides you with specific legal rights. You may have additional rights which may
vary from country to country. Because of individual regulations, some of the above limitations
and exclusions may not apply to you.
NOTE:
Failure to follow the instructions in this manual will result in the manufacturing guarantee being
void. Please take extra care when connecting cables to your devices or the product to avoid
damaging the ports.
Wear and tear aren’t covered by the guarantee. Submersion in liquids will void the guarantee.
Devices connected to this product or App are not covered by the Bitmore guarantee.
For Bitmore products containing a Lithium-ion battery:
Lithium-ion battery powered devices are dispatched from our factory with a partial charge,
depending on the storing temperature and the length of storage during transit and with the
retailer, the charge held by the device will naturally decrease, for best performance we
recommend charging the device fully,
BM-BT5WEC LED PULSE SPEAKER | 4

Any product that is powered by a Lithium-ion battery, as with all devices using Lithium, the
amount of charge the lithium cells can hold decreases over time and with use or if left in a cold
environment, experiencing fluctuations in temperature or when unused for long periods of time
(charge and discharged the battery often, even if you are not using it). Therefore, you may find
that the amount of charge this product holds and oers may be slightly less. This is typically a
slow process and a naturally recurring phenomenon and is not covered by the guarantee
or guarantee.
BM-BT5WEC LED PULSE SPEAKER | 5

Our roots are in creating high quality
products, which has now grown in to
developing an extensive range of
audio, power and tech accessories.
Stemming from our passion for the
environment, we strive to make
Bitmore as eco-friendly as possible.
The combination of innovative
sustainable solutions with our tech
expertise means we create products
that are great for you, and the planet.
@bitmoreuk
www.bitmore.co.uk
[email protected]
A BIT MORE
ABOUT US
IMPORTED AND DISTRIBUTED BY:
BITMORE LTD, PARK HOUSE,
15-19 GREENHILL CRESCENT,
WATFORD, WD18 8PH, UK
BITMORE BV,
KAPELLERLAAN 19,
6041 JB ROERMOND, NL
