Sony SA-WA10R - Wireless Speaker System Component User manual

SERVICE MANUAL
Sony Corporation
Audio&Video Business Group
Published by Sony Techno Create Corporation
SA-WA10R
SPECIFICATIONS
WIRELESS SPEAKER SYSTEM
9-889-586-01
2009G05-1
© 2009.07
US Model
Ver. 1.0 2009.07
• SA-WA10R is the subwoofer in AIR-SW10Ti.
• When the operation of the ATS-SW10Ti or SA-
WA10R is confirmed, it is necessary to communi-
cate the set of both and confirm.
Confirm that all units included in AIR-SW10Ti are
prepared beforehand when you repair.
• “S-AIR” and its logo are trademarks of Sony Corporation.
• iPod is a trademark of Apple Inc., registered in the U.S. and other countries.
• iPhone is a trademark of Apple Inc.
• The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is
under license. Other trademarks and trade names are those of their respective owners.
• All other trademarks and registered trademarks are of their respective holders. In this manual, ™ and ®marks are not specified.
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
(e United States model only)
With 6 ohm loads, from 50 – 120 Hz; rated 50 watts minimum
RMS power, with no more than 10% total harmonic distortion.
Amplier section
DIN power output (rated):
40 watts (6 ohms at 60 Hz, DIN)
Continuous RMS power output (reference):
50 watts (6 ohms at 60 Hz, 10% THD)
Speaker
Speaker system:
Woofer, 100 mm, cone type, bass-reex
Rated impedance:
6 ohms
General
Power requirements:
120V AC, 60Hz
Power consumption:
17 watts
Dimensions (w/h/d):
Approx. 123 × 282 × 375 mm
Mass:
Approx. 4.3 kg
Design and specications are subject to change without notice.
• JIG
When disassembling the set, use the fol-
lowing jig (for speaker removal).
Part No. J-2501-238-A JIG FOR SPEAK-
ER REMOVAL

SA-WA10R
2
1. SERVICING NOTES ............................................. 3
2. DISASSEMBLY
2-1. Disassembly Flow........................................................... 4
2-2. PANEL (SW) Board/Panel (Front) Assy......................... 4
2-3. Chassis (Net) Assy .......................................................... 5
2-4. Rear Panel Block ............................................................ 5
2-5. POWER (SW) Board...................................................... 6
2-6. MAIN (SW) Board ......................................................... 6
3. TEST MODE ............................................................ 7
4. DIAGRAMS
4-1. Block Diagram................................................................ 9
4-2. Schematic Diagram - PANEL (SW) Board - .................. 10
4-3. Printed Wiring Boards - MAIN Section - ....................... 11
4-4. Schematic Diagram - MAIN (SW) Board (1/2) - ........... 12
4-5. Schematic Diagram - MAIN (SW) Board (2/2) - ........... 13
4-6. Schematic Diagram - POWER (SW) Board -................. 14
4-7. Printed Wiring Board - POWER (SW) Board - .............. 15
5. EXPLODED VIEWS
5-1. Front Panel Section......................................................... 21
5-2. Rear Panel Section.......................................................... 22
6. ELECTRICAL PARTS LIST .............................. 23
TABLE OF CONTENTS
NOTES ON CHIP COMPONENT REPLACEMENT
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
SAFETY CHECK-OUT
After correcting the original service problem, perform the follow-
ing safety check before releasing the set to the customer:
Check the antenna terminals, metal trim, “metallized” knobs,
screws, and all other exposed metal parts for AC leakage.
Check leakage as described below.
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes.).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instruments.
2. A battery-operated AC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The “limit” indication
is 0.75 V, so analog meters must have an accurate low-voltage
scale. The Simpson 250 and Sanwa SH-63Trd are examples
of a passive VOM that is suitable. Nearly all battery operated
digital multimeters that have a 2 V AC range are suitable. (See
Fig. A)
1.5 kΩ0.15 μF
AC
voltmeter
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground
Fig. A. Using an AC voltmeter to check AC leakage.
SAFETY-RELATED COMPONENT WARNING!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.

SA-WA10R
3
SECTION 1
SERVICING NOTES
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
• Unleaded solder melts at a temperature about 40 °C higher
than ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350 °C.
Caution: The printed pattern (copper foil) may peel away if
the heated tip is applied for too long, so be careful!
• Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
• Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
ADVANCE PREPARATION WHEN CONFIRMING OP-
ERATION
When the operation of the ATS-SW10Ti or SA-WA10R is con-
firmed, it is necessary to communicate the set of both and confirm.
Confirm the ATS-SW10Ti, SA-WA10R and EZW-RT10A are pre-
pared beforehand when you repair.
NOTE OF WHEN REPAIRING
Please get remote commander from the service parts when remote
commander is necessary for the repair.
Part No. A-1717-785-A RM-ANU066
DIRECTION OF EZW-RT10A INSTALLATION
When EZW-RT10A is install with the MAIN (SW) board detached
of the set, the label of EZW-RT10A is the under and install.
label
EZW-RT10A
MAIN (SW) board
NOTES OF THE REPLACING THE IC602 ON THE
MAIN (SW) BOARD
IC602 on the MAIN (SW) board cannot exchange with single.
When this part on the MAIN (SW) board is damaged, exchange
the entire mounted board.
CAPACITOR ELECTRICAL DISCHARGE PROCESSING
When checking the board, for the electric shock prevention, con-
nect the resistors to both ends of respective capacitors (C12 and
C13) to discharge the capacitors (C12 and C13).
– POWER (SW) Board (Conductor Side) –
800 :/2 W
800 :/2 W
C12
C13

SA-WA10R
4
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
Note: Follow the disassembly procedure in the numerical order given.
2-2. PANEL (SW) BOARD/PANEL (FRONT) ASSY
SET
2-2. PANEL (SW) BOARD/
PANEL (FRONT) ASSY
(Page 4)
2-3. CHASSIS (NET) ASSY
(Page 5)
2-4. REAR PANEL BLOCK
(Page 5)
2-5. POWER (SW) BOARD
(Page 6)
2-6. MAIN (SW) BOARD
(Page 6)
2Insert a flat-head screwdriver
in the bottom of the set to raise
the panel (front) assy a little.
1two rubber foots (SW)
5three screws
(BVTP3
u8)
8PANEL (SW) board
7sheet (1)
6connector (CN603)
1two rubber foots (SW)
7panel (front) assy
4Raise the panel (front) assy a little by
little from bottom to top of the set.
six bosses
bottom side
3Insert the jig (Part No. J-2501-238-A) into a space and
raise the panel (front) assy gradually.
Note: When using a jig, please work so as not to
injure panel (front) assy and speaker box.
3Insert the jig (Part No. J-2501-238-A)
into a space and raise the
panel (front) assy gradually.
Note: When using a jig, please
work so as not to injure
panel (front) assy and
speaker box.
bottom side

SA-WA10R
5
2-3. CHASSIS (NET) ASSY
2-4. REAR PANEL BLOCK
2Raise the chassis (net)
assy a little by little.
five bosses
1Insert the jig (Part No. J-2501-238-A) into a space and
raise the chassis (net) assy gradually.
Note: When using a jig, please work so as not to
injure chassis (net) assy and speaker box.
7chassis block
4connector (CN703)
3connector (CN602)
2
6power cord connector (CN01)
8rear panel bloc
k
1four screws (3.5 u14)
5four screws (BVTP3 u8)

SA-WA10R
6
2-5. POWER (SW) BOARD
2-6. MAIN (SW) BOARD
3screw (BVTP3 u8)
3five screws (BVTP3 u8)
4barrier (fuse SW)
5fuse (H.B.C.)
(T5AH/250V) (F01)
1connector (CN706)
2connector (CN704)
6POWER (SW) board
9two screws (BVTP3 u8)
7screw (BVTP3 u8)
3two screws (BVTP3 u8)
1three screws (BVTP3 u8)
4two screws (BVTP3 u6)
5shield case (main PWB SW)
4screw (BVTP3 u6)
4screw (BVTP3 u6)
7two screws
(BVTP3
u8)
7three screws (BVTP3 u8)
0heat sink (AMP PWB SW) block
2barrier (cord SW)
8holder (S-AIR) block
6two screws (BVTP2.6)
qs MAIN (SW) board
qa cushion (10 u20)

SA-WA10R
7
SECTION 3
TEST MODE
Note: Please get remote commander from the service parts when remote
commander is necessary for the repair.
• Use the bundled remote commander when remote commander is
bundled to the repairing set.
Part No. A-1717-785-A RM-ANU066
1. COLD RESET
Procedure:
1. Press the [?/1] button to turn on the system.
2. Press the [PAIRING] and [?/1] buttons, and hold for more
than three seconds.
3. Cold reset is executed and turn off the system.
2. VERSION CHECK
Procedure:
1. Press the [?/1] button to turn on the system.
2. S-AIR ID slide switch select the “A”.
3. Press the [PAIRING] button, and hold for more than three sec-
onds.
4. The color of STANDBY indicator LED is confirmed.
RED: Normal version
ORG: TEST version
GRN: ROMOUT version
5. The frequency to which S-AIR indicator LED blinks is con-
firmed. The blinking frequency shows the place of ten of the
version.
6. The frequency to which PAIRING indicator LED blinks is
confirmed. The blinking frequency shows the place of one of
the version.
7. Example: Normal version, Ver. 0.12
STANDBY indicator LED is red, S-AIR indicator LED blink-
ing once, PAIRING indicator LED blinking twice.
8. To release from this mode, press the [PAIRING] button, and
hold for more than three seconds.

SA-WA10R
8
MEMO

SA-WA10R
SA-WA10R
99
SECTION 4
DIAGRAMS
4-1. BLOCK DIAGRAM
S603
I/1
SHUNT
REGULATOR
IC901
(AC IN)
F01
TH02
D11
RECT
D01
RESET SWITCH
Q606
LINE FILTER
L01
POWER CONTROL
IC02
T01
SUB POWER
TRANSFORMER
DRAIN5
POWER CONTROL
IC01
VS
15
VSENS
1
+3.3V
REGULATOR
IC703
+3.3V
REGULATOR
IC701
+3.3V
REGULATOR
IC604
POWER ON/OFF
CONTROL SWITCH
Q901
ISOLATOR
PH01
VCC
4
FB2
ISOLATOR
PH02
OVER VOLTAGE
DETECT
Q902, 903
ISOLATOR
PH03
FB
2
VG-H16
VG-L12
D12
Q01
+4V
T02
MAIN POWER
TRANSFORMER
SWITCHING
Q03
SWITCHING
Q04
OCP9
VC1
8
D902
D905
RECT
D904
VD 18
O-DISCHARGE 42
RESET 5
I-AC CUT 2
O-SA_POW-ON 16
I-3.3V_POWER_MONI 47
O-POWER_ON 48
I-POWER_MONITOR-2 43
I-P-ON_DET 29
Q904D915Q610
DISCHARGE
Q601
AUDIO +3.3V
+1.8V
REGULATOR
IC702
+1.8V
+12
REGULATOR
IC708
SYSTEM CONTROLLER
IC602
+12V
+27V
VCC +3.3V
uCOM +3.3V
RESET SIGNAL
GENERATOR
IC603
CN701
SP701
DOUTA_DINC 19
I2C_SDA 14
I2C_SCL 11
GPIO-2_ASIC_INT_ 7
RESN_ 12
SA_DAT
SA_CLK
/SA_INT
/SA_RST
VCC +3.3V
BCK 17
LRCK 15
VCC-3.3V 2
MCLK 4
SA_DATA15
O-SA_CLOCK14
I-SA_INT18
O-SA_RESET
17
SA_DAT
SA_CLK
/SA_INT
/SA_RST
STREAM PROCESSOR
IC704
XFSOIN48
LRCK
29
BCK
30
DATA
31
O-AMP_RESET 20
I-AMP_SD 30
OUTL1 11
OUTL2 9
POWER AMP
IC707
AP
17
BP
2OUT_B 29
OUT_B 30
OUT_A 25
OUT_A 26
SCDT 21
SCSHIFT 22
SCLATCH
AMP_SCDT
AMP_SCSHIFT
AMP_SCLATCH
/AMP_INIT
23
INIT_ 27 /AMP_PGMUTE
PGMUTE_ 20 /AMP_SOFTMUTE
SOFTMUTE_ 19 /AMP_NSPMUTE
NSPMUTE_ 18
O-AMP_SCDT 35
O-AMP_SCSHIFT 37
O-AMP_SCLATCH
AMP_SCDT
AMP_SCSHIFT
AMP_SCLATCH
/AMP_INIT
36
O-AMP_INIT 26 /AMP_PGMUTE
O-AMP_PGMUTE 23 /AMP_SOFTMUTE
O-AMP_SOFTMUTE 22 /AMP_NSPMUTE
O-AMP_NSPMUTE 21
CLOCK BUFFER
IC706
SHIFT CLOCK
IC705
XFSIIN36
X702
49.152MHz /SD 13
/OTW 15
/RST 4
OVER LOAD
DETECT
Q702, 703
PROTECT DETECT
Q701
EEPROM_SDA3
O-EEPROM_SCL
4
EEPROM
IC601
SDA 5
SCL 6
KEY_WAKEUP1
I-KEY0
40
S601
PAIRING I-KEY_PAIRING19
I-SA_ID41
7
6
X602
32.768kHz
10
9
X601
16MHz
XT1
XT2
X1
X2
LED DRIVE
Q603, 608 O-SA_STBY_LED49
LED DRIVE
Q602, 607 O-STBY_LED
(GREEN)
(RED) 28
D605
I/1
LED DRIVE
Q605 O-PAIR_LED50
D605
A
B
C
LED DRIVE
Q604, 609 O-SA_LED32
D606
S-AIR
S602
S-AIR ID
EZW-RT10A
WIRELESS
TRANSCEIVER
(EZW-RT10A)
PAIRING
TH01
: AUDIO
SIGNAL PATH

SA-WA10R
SA-WA10R
1010
4-2. SCHEMATIC DIAGRAM - PANEL (SW) Board -
1IC602 6(XT2)
2 V/DIV, 20 Ps/DIV
30.4 Ps
3.4 Vp-p
2IC602 9(X2)
2 V/DIV, 50 ns/DIV
64 ns
3 Vp-p
3IC705 qs (DAT-2)
2 V/DIV, 50 ns/DIV
82 ns
5.6 Vp-p
4IC706 4(OUT_)
2 V/DIV, 10 ns/DIV
20.6 ns
4.6 Vp-p
• Waveforms
– MAIN (SW) Board –
For Schematic Diagrams.
Note:
• All capacitors are in μF unless otherwise noted. (p: pF) 50
WV or less are not indicated except for electrolytics and
tantalums.
• All resistors are in Ωand 1/4 W or less unless otherwise
specified.
• f: internal component.
• 2: Nonflammable resistor.
• C: panel designation.
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
• A: B+ Line.
• Voltages and waveforms are dc with respect to ground
under no-signal conditions.
no mark : POWER ON
• Voltages are taken with VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production
tolerances.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal production
tolerances.
• Circled numbers refer to waveforms.
• Signal path.
F: AUDIO
For Printed Wiring Boards.
Note:
• X: Parts extracted from the component side.
• Y: Parts extracted from the conductor side.
• f: Internal component.
• : Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
• Indication of transistor.
C
B
These are omitted.
E
Q
Caution:
Pattern face side:
(Conductor Side)
Parts face side:
(Component Side)
Parts on the pattern face side seen
from the pattern face are indicated.
Parts on the parts face side seen from
the parts face are indicated.
Note: The components identified by mark 0or dotted
line with mark 0are critical for safety.
Replace only with part number specified.
BOARD
(1/2)
CN602
A
100
R675
0.01
C625
47
R677
SLR325MC-M-T31-NP
D606
S603
100
R676
(GRN)
(RED)
SML72423C-TP15
D607
100
R674
1
2
3
4
5
5P
CN603
KEY_0
GND
STBY_LED
SA_STBY_LED
SA_LED
JL1
JL2
JL3
JL4
JL5
PANEL (SW) BOARD
/
/
S-AIR
GRN: POWER ON
ORG (RED and GRN):
RED: STANDBY
POWER SAVE MODE
MAIN (SW)
4
B
D
3
C
1
A
2
(Page 12)

SA-WA10R
SA-WA10R
1111
4-3. PRINTED WIRING BOARDS - MAIN Section - • : Uses unleaded solder.
JL80
JL81
JL82
JL83
JL84
JL85
D755
JL86
D756
D759
R602
R603
R635
C611
C613
C616
C617
R660
R674
L701
L709
CL01
CL23
CL24
CL26
CL27
CL28
FB704
CL36
CL40
R701
R705
R708 R710
R711
R714
R736 R745
R756
R757
R758
R759 R761
R762
R763
R766
JL02
JL03
R770
JL04
C735
R771
JL05
JL06
C736
R772
R773
JL07
R774
JL08
R775
JL09
R777
JL10
JL11
JL12
JL13
JL14
R781
JL15 JL16
JL17
JL18
R785
JL19
R786
R787
R788
R789
JL20
R790
C754
R791
R792
C756
C760
C761
C762
C763 C764
C765
C767
C768
D713
C773
C777
C779
C780
C781
C782
C783
C784
C785
C786
C787
C788
C789
C790
C791
JL61
JL62
JL63
JL64
JL65
C797
JL71
JL72
JL73
JL74
JL75
JL76 JL77
JL78
12
19
20
CN701
1
2
1
3
EP706
EP707
L705 L706
L710
FB708
CN703
C705
C711
C713
C714
C715
C716 C717
C718 C719
C769 C772
C775 C776 IC708
C793
1
4
1
5
EP701
EP702
S601
S602
D605
CN704
CN706
C706
C707
C708 C709
C710
A001
C712
C720
1
2
7
6
1
5
CN601
CN602
C603
X601
X602
C601
C602
C604
C605
FB601
C625
R674
R675
R676
R677
JL1
JL2
JL3
JL4
JL5
1
5
CN603
S603
JW601
D606
D607
B
E
BE
BE
5
8
1
4
113
27
14
26
39
40
52
B
E
BE
BE
BE
B
E
B
E
BE
BE
BE
B
E
1
24
25
36
37
48
12
13
1
18
19 36
D758
R601
R604
R605
R606
R607
R608
R609
R610
R611
R612
R613
R614
R615
R616
R617
R618
R619
R620
R621
R622
R623
R624
R625 R627
R628
R629
R630
R631 R632 R633 R634
R636
R637
R638
R639
R640 R641
R642
C606
R643
C607
R644
C608
R645
C609
R646
R647
R648
R649
R650
C614
R651
C615
R652
R653
R654
R655
C619
R656
R657
R658
R659
C620
C621
C622
C623
C624
C625
R661
R662
R663
R664
R665
R666
R667
R668
R669
R670
R671
R672
R673
R675
R676
R677
R678
R679
D602
D603
D604
Q701
Q702
Q703
L702
L703
L704
IC601
IC602
IC603
IC604
CL02
CL03
CL10
CL11
CL12
CL13
CL15
CL16
CL19
CL20
CL22
CL25
CL30
CL31
CL32
CL33
CL34
FB705 CL35
FB706
FB707
CL37
CL41
R702
CL42
R703
CL43
CL45
CL46
CL47
R709
CL50
CL52
CL53
R716
R717
R718
R719
R720
R721
R722
R723
R725
R726
R727
R728
R729
R730
R731
R732
R733
R734
R735
R737
R738
R739
C701
C702
C703
C704
R740
R741
R742
R744
R747
R748
R749
X702
R750
R752
R753
R754
R755
C721
C722
C723
C724
C725
C726
C727
C728
R764
R765
R767
R768
R769
C738
C739
R778
C740
C741
C742
C743
C744
R780
C745
C746
R782
C747
C749
C750
C751
C753
C755
C758
Q601
C759
Q602
Q603
Q604
Q605
Q606
Q607
Q608
Q609
C766
D708
Q610
C770
C771
C774
IC701
IC702
IC703
IC704
IC705
IC706
IC707
C794
C795
C796
C
POWER (SW)
BOARD
W905
B
POWER (SW)
BOARD
W904
(CHASSIS)
(CHASSIS)
1-879-293-
11
(11)
MAIN (SW) BOARD (CONDUCTOR SIDE)
EZW-RT10A
WIRELESS
TRANSCEIVER
(EZW-RT10A)
S-AIR ID
$
3
%
S
&
PAIRING
PAIRING
(NC)
SP701
(CHASSIS)
(CHASSIS)
1-879-295-
11
(11)
PANEL (SW) BOARD
S-AIR
D607
(RED) (GRN)
(RED) (GRN)
RED: STAMDBY
GRN: POWER ON
ORG (RED and GRN):
POWER SAVE MODE
1
34
5
1
7
8
14
1
34
5
1
34
5
1
34
5
1
34
5
1-879-293-
11
(11)
MAIN (SW) BOARD (COMPONENT SIDE)
1
5
A
B
C
D
E
F
G
H
I
J
12345678910 11 12 13
Note: IC602 cannot exchange with single. When this part is damaged, exchange the entire mounted board.
(Page 15)
(Page 15)

SA-WA10R
SA-WA10R
1212
4-4. SCHEMATIC DIAGRAM - MAIN (SW) Board (1/2) - • See page 10 for Waveforms. • See page 16 for IC Block Diagrams. • See page 19 for IC Pin Function Description.
Note: IC602 cannot exchange with single. When this part
is damaged, exchange the entire mounted board.
MAIN (SW)
BOARD
1
(2/2)
BOARD
A
PANEL (SW)
CN603
BOARD
2
MAIN (SW)
(2/2)
BOARD
3
MAIN (SW)
(2/2)
BOARD
4
MAIN (SW)
(2/2)
IC B/D
IC B/D
1
2
0
3
0
3.3
3.3
0
3.3
4.1
4.1
3.3
0
3.3
0
3
4.1
4.1
3.3
4.1
0
0
4.1
4.1
4.1
0
3.3
3.3
3.3
3.3
3.3
3.3
3.3
0
3.3
0
3.3
3.3
2.7
3.3
3.3
3.3
3.3
3.3 1.6
1 0
1.8
1.4 2.5
3.3 3.1 2.4 3.5
3.3
0
3.3
0
0
0
3.3
0
0
0
0
3.3
0
0 0 0 3.3 0 3.3
2.9 0 0 3.3 0 3.3
3.2
3.3
3.5
1.3
3.1 4.1
3.3
12345678910111213
15
16
17
18
19
20
21
22
23
24
25
26
2930313233343536373839
43
44
45
46
47
48
49
50
51
52 14
28
41
42
40
27
PPD78F0526GB(S)-UET-A
IC602
KEY_WAKEUP I-AC CUT EEPROM_SDA O-EEPROM_SCL RESET XT2 XT1 FLMD0 X2 X1 REGC VSS VDD
SA_DATA
O-SA_POW-0N
O-SA_RESET
I-SA_INT
I-KEY_PAIRING
O-AMP_RESET
O-AMP_NSPMUTE
O-AMP_SOFTMUTE
O-AMP_PGMUTE
I-SUFIX
I-AMP_OVFFLAGL
O-AMP_INIT
NC
I-P-ON_DET
I-AMP_SD
I-AMP_OTW
O-SA_LED
O-FLASH_SI
O-FLASH_SO
O-AMP_SCDT
O-AMP_SCLATCH
O-AMP_SCSHIFT
AVREF
AVSS
I-KEY0
I-POWER_MONITOR-2
NC
NC
NC
I-3.3V_POWER_MONI
O-POWER_ON
O-SA_STBY_LED
0-PAIR_LED
NC
NC O-SA_CLOCK
O-STBY_LED
I-SA_ID
O-DISCHARGE
8765
4321
S-24CS02AFJ-TB-G
IC601
A0
A1
A2
GND SDA
SCL
WP
VCC
54
321
PST3629NR
IC603
OUT
VDD
GND NC
CD
0
R660
C603
10V
220
R624
1k
R625
1k
R627
47k
C620
1
C619
0.1
MA2J1110GLS0
D603
47k
R638
47k
R637
2SC3052F-T1-LF
Q606
10k
R662
S602
S601
C617
1
54
321
TK11133CSCL-G
IC604
ON-OFF_ GND Np V_OUT
V_IN
10V
220
C604
0.01
C623
100k
R664
1
C624
10V
100
C605
1
C622
10k
R636
C621
0.1
C614
0.1
C615
0.1
1
C609
C616
1
1kR609
1k
R617
4.7kR618
10k
R612 10kR613
10kR614
10kR619
1kR620
1kR621
1kR622
1k
R623
10kR615
10k
R616
C602
10V
220
P_ON_DET
+4V
GND
POW_ON
SA_POW_ON
10k
R603
7
6
5
4
3
2
1
7P
CN601
FLMD
3.3v
GND
RST
SI
SO
NC
C608 1
100
R629
10k
R610
MA2J1110GLS0
D602
1M
R628
47k
R639
SA_DAT
SA_CLK
/SA_INT
/SA_RST
100R656
100
R655
100
R654
2.2k
R653
1k
R652
10k
R659
1k
R647
1k
R649
1k
R650
1k
R651
10k
R648
10k
R663
10kR608
10k
R601
10
R657
10
R658
100R630 100R631 100R632 100R633 100R634 100R640
10k
R641
100
R643
100
R644
220R645
/AMP_INIT
AMP_SCLATCH
AMP_SCSHIFT
AMP_SCDT
/AMP_PGMUTE
/AMP_SOFTMUTE
/AMP_NSPMUTE
/AMP_SD_OTW
/AMP_RST
10k
R646
CL11
CL15
CL16
0.01
C606
0.01
C607
3_3V_P_MONI
R606
220
R607
220
CL20
JL81
JL82
JL83
JL84
JL85
JL86
CL23
CL24
CL19
220kR635
C613
22p
10k
R642
100
R602
10
R667
10k
R666
ISA1235AC1TP-1EF
Q602
1k
R665
10k
R669
ISA1235AC1TP-1EF
Q603
1k
R668
10
R670
10k
R673
ISA1235AC1TP-1EF
Q604
1k
R672
10
R671
1
2
3
4
5
5P
CN602
KEY_0
GND
STBY_LED
SA_STBY_LED
SA_LED
4.7k
R661
MA2J1110GLS0
D604
RT1N141C-TP-1
Q609
RT1N141C-TP-1
Q608
RT1N141C-TP-1
Q607
2SC3052F-T1-LF
Q605
10k
R604
10k
R605
100
R674
X602
32.768kHz
JL61
JL62
JL63
JL64
JL65
16MHz
X601
1k
R675
10k
R676
ISA1235AC1TP-1EF
Q610
1k
R677
/P_MONI_2 10V
C601
220 10kR678
10k
R679
E
EP701
CL22
CL12
CL13
1L034FY11A0MR601
D605
10k
R611
1.1uH
FB601
C625
1000p
2SC3052EF-T1-LEF
Q601
C611
22p
/SA_RST
/SA_INT
/SA_RST
SA_DAT
/SA_INT
SA_POW_ON
/AMP_RST
/AMP_NSPMUTE
/AMP_SOFTMUTE
/AMP_PGMUTE
/AMP_INIT
STBY_LED
AMP_SCDT
AMP_SCLATCH
/AMP_SD_OTW
/AMP_NSPMUTE
/AMP_SOFTMUTE
/AMP_PGMUTE
AMP_SCDT
AMP_SCSHIFT
AMP_SCLATCH
/AMP_INIT
FLASH_SI
FLASH_SO
SA_LED
SA_CLK
SA_POW_ON
POW_ON
SA_DAT
SA_CLK
3_3V_P_MONI
3_3V_P_MONI
POW_ON
FLASH_SO
FLASH_SI
SA_STBY_LED
SA_STBY_LED
SA_LED
STBY_LED
P_ON_DET
P_ON_DET
/P_MONI_2
AMP_SCSHIFT
KEY_0
/P_MONI_2
/AMP_SD_OTW
/AMP_RST
KEY_0
(CHASSIS)
(CHASSIS)
(CHASSIS)
IC601
EEPROM
IC604
+3.3V
REGULATOR
RESET SIGNAL
GENERATOR
IC603
IC602
SYSTEM
CONTROLLER
MAIN (SW) BOARD (1/2)
S-AIR ID
PAIRING
INVERTER
LED DRIVE
DISCHARGE
PAIRING
LED DRIVE
Q602, 607
LED DRIVE
Q603, 608
LED DRIVE
Q604, 609
RESET
SWITCH
A
B
C
(NC)
J
4
B
166911
D
15
H
10
K
1735 12
C
F
181
E
8
G
14
A
213
I
7
(Page
13)
(Page 13)
(Page 13)
(Page 13)
(Page 10)

SA-WA10R
SA-WA10R
1313
4-5. SCHEMATIC DIAGRAM - MAIN (SW) Board (2/2) - • See page 10 for Waveforms. • See page 16 for IC Block Diagrams.
B
W904
POWER (SW)
BOARD
C
W905
POWER (SW)
BOARD
(1/2)
3
MAIN (SW)
BOARD
(1/2)
1
MAIN (SW)
BOARD
(1/2)
4
MAIN (SW)
BOARD
(1/2)
2
MAIN (SW)
BOARD
IC B/D
IC B/D
IC B/D
IC B/D
IC B/D
IC B/D
3
4
1.6
3.3
1.6
3.3
1.6
1.6
3.3
3.3 3.3
1.6 1.6 1.6
1.6
3.3
3.3
0
3.3
1.6
0
1.8
0
1.6
0 3.3 3.3 3.3 3.3 0
3.3
3.3
1.8
2.7 3.3
4.1
1.3 2.9
1.3
2.9
3.3 1.8
4.1 3.3
1.6
1.7
3.3
1.6
1.6
3.3
3.3 1.7 1.6 3.3 1.6
3.3
3.3
1.6

25
13.7
13.7
13.7
25
12.1
12.1
13.7
27.3
27.3
3.3
1.6
12.1
3.3
0
3.3
3.3
3.3
3.3
1.6
27.3
12.1
12.1
27.3
27.3
12.1
0
3.3 13.5
13.5
0
13.5
13.5
0
5
43
2
1
MC74VHC1GU04DFT1
IC706
NC
IN
GND OUT_
VCC
4.7
R775
10k
R770
10k
R771
2200p
C782
4.7
R774
2200p
C780
0.1
C784
10k
R772
2200p
C779
10k
R773
0.1
C783
2200p
C781
2.2
C774
220k
R768
100k
R767
220k
R769
ISA1235AC1TP-1EF
Q702
ISA1235AC1TP-1EF
Q703
10
R766
47k
R765
2SC3052EF-T1-LEF
Q701
PROTECT DETECT
1
C771
10
R764
10uH
L709
50V
10
C719
16V
1000
C718 0.1
C785
0.1
C773
6.3V
1000
C713
1000p
C744
1000p
C742
100
R732
100
R731
100
R730
100
R729
100
R728
100
R727
100
R726
100
R719
10k
R720
100
R717 CL35
0R721
470
R722
47k
R718
0
R723
CL33
CL25
10R738
10R739
10
R740
10
R741
1M
R752
10uH
L703
22
R754
22
R755
CL34
2
1
CN703
2P
SP -
SP +
CL36
0R744
31
32
33
34
35
36
1
2
3
4
5
6
30
29
28
27
26
8
7
9
10
11
21
22
23
24
2512
13
14
15
20
19
16
17
18
CXD9774M
IC707
RGND
BP
BM
/RST
RGND
GREG
M3
DREG
DVSS
M1
M2
DVDD
/SD
RESV
/OTW
AM
AP
RGND GREG
PVDD
PVSS
BST_A
PVDD_A
PVDD_A
OUT_A
OUT_A
PVSS
PVSS
OUT_B
OUT_B
PVDD_B
PVDD_B
BST_B
PVSS
PVDD
GREG
390
R735
22k
R737
47p
C753
100
R736
100
R747
1k
R757 1k
R763
1k
R762
1k
R758
1k
R756 CL40
L705
P6SMB39AT3
D755
P6SMB39AT3
D756
0.22
C761
0.22
C762 3.3
R759
0
R742
470
R750
0.1
C754
100
R745
100
R749
0.1
C756
100
R748
1
C759
1
C766
0.047
C760
0.047
C763
L706
0.22
C764 0.22
C765
3.3
R761
35V
2200
C716
0.1
C769
0.01
C770
CL43
CL41
CL47
CL45
CL50
IO
G
KIA7812API-U/PF
IC708
1
C735 1
C738 1
C747
1
C746
1
C724
1
C723
1
C725
1
C741
1
C740
1
C745
1
C743
1
C749
1
2
3
4
5
6
7
8
9
10
11
12
131415161718192021222324
25
26
27
28
29
30
31
32
33
34
35
36
37 38 39 40 41 42 43 44 45 46 47 48
CXD9788AR
IC704
XVSS
VSUBC
VSSR
OUTR2
VDDR
OUTR1
VSSR
VSSL
OUTL2
VDDL
OUTL1
VssL
XOVSS
XFsoOUT
XOVDD
DVDD
DVSS
NSPMUTE_
SOFTMUTE_
PGMUTE_
SCDT
SCSHIFT
SCLATCH
OVFFLAGR
OVFFLAGL
SFLAG
INIT_
MCKSEL
LRCK
BCK
DATA
BFVDD
BFVSS
TEST
DVDD
XFSIIN
FSOCKO FSOI HPOUTR2 HPVSSR HPOUTR1 HPVDDR HPOUTL2 HPVSSL HPOUTL1 HPVDDL XVDD XFSOIN
1
C704
10V
100
C707
0.1
C772
35V
2200
C717
JL73
JL74
CL42
CL46
JL76
JL75
JL77
JL78
10V
220
C711
6.3V
1000
C720
1
C786
10kR701
10
R710
100
R705
10
R711
10k
R708
100
R714
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
20P
CN701
GND
VCC-3.3V
GND(DET)
MCLK
A0
A1
GPIO-2_ASIC_INT_
GPIO3_ASIC
GPIO0_ASIC
GPIO1_ASIC_LINK
I2C_SCL
RESN_
DINB_DOUTD
I2C_SDA
LRCK
DOUTB_DIND
BCK
D-GND
DOUTA_DINC
DINA_DOUTC
SA_DAT
SA_CLK
/SA_INT
/SA_RST
SA_POW_ON
POW_ON
P_ON_DET
/AMP_INIT
AMP_SCLATCH
AMP_SCDT
AMP_SCSHIFT
/AMP_PGMUTE
/AMP_SOFTMUTE
/AMP_NSPMUTE
/AMP_RST
/AMP_SD_OTW
JL06
JL07
JL10
JL09
JL15
JL04
JL02
JL18
JL13
6.3V
1000
C705
10V
100
C706
1
C703
1
C755
+4V
1
C789
GND
D713
UDZW-TE17-2.4B
CL26
CL27
CL28
CL30
CL31
2.2k
R777 2.2k
R778
100k
R785
22k
R780
CL37
3_3V_P_MONI
MC2836
D758
3
21
4
10uH
L710
10kR781
12345
BD33KA5WFP-E2
IC701
CTL VCC GND OUT NC
0R782
MC2836
D708
10V
100
C709
0.01
C727
10V
220
C712
1
C722
10k
R725
54
321
TK11133CSCL-G
IC703
ON-OFF_ GND Np V_OUT
V_IN
CL32
1
C721
10V
100
C708
0.01
C726
47k
R716
6.3V
1000
C710
54
321
TK11118CSCL-G
IC702
ON-OFF_ GND Np V_OUT
V_IN
10uH
L702
CL10
10p
C728
10p
C739
10V
220
C714
47
R734
141312111098
7654321
MC74VHC74DTR2
IC705
RST-1 DAT-1 CLK-1 SET-1 Q1 Q1_ GND Q2_
Q2
SET-2
CLK-2
DAT-2
RST-2
Vcc
CL52
CL53
47
R733
1
C736
JL71
JL72
CL01
JL03
JL05
JL08
JL11
JL12
JL14
JL16
JL17
JL19
JL20
/P_MONI_2
JL80
4
3
2
1
CN704
4P
P-GND
+27V
P-GND
+27V
1
C775
1
C776
10V
220
C715
E
EP706
E
EP707
1000p
C758
100
R753
10p
C750
10p
C751
49.152MHz
X702
E
EP702
CL02
CL03
4.7k
R786
4.7k
R787
1k
R788
UDZW-TE17-8.2B
D759
1.1uH
FB708
100p
C701
100p
C702
0
FB704
1uH
L704
1uH
L701
220
R789
220
R790
1
2
3
4
5
5P
CN706
D-GND
+4v
P-ON/OFF_
P_ON_DET
P-MONI-2
10kR791
10kR792
1
C792
1
C793
C767 0
C768 0
0
C790
0
C791
100p
C794
100p
C795
100p
C796
C787 0
0C788
0
C797
10
R702
10
R703
10R709 10FB705
10
FB706
10
FB707
/AMP_NSPMUTE
/AMP_SOFTMUTE
/AMP_PGMUTE
AMP_SCDT
AMP_SCSHIFT
AMP_SCLATCH
/AMP_RST
SA_DAT
/AMP_INIT
AMP_SCLATCH
AMP_SCSHIFT
AMP_SCDT
/AMP_PGMUTE
/AMP_SOFTMUTE
/AMP_NSPMUTE
/AMP_SD_OTW
SA_DAT
/SA_RST
SA_CLK
/SA_INT
POW_ON
P_ON_DET
/AMP_SD_OTW
/P_MONI_2
P_ON_DET
POW_ON
3_3V_P_MONI
SA_POW_ON
3_3V_P_MONI
POW_ON
/SA_RST
SA_CLK
/SA_INT
/P_MONI_2
/AMP_RST
/AMP_INIT
SA_POW_ON
IC701
+3.3V
REGULATOR
IC705
CLOCK BUFFER
IC706
IC702
IC703
IC704
STREAM
PROCESSOR
IC707
POWER AMP
(CHASSIS)
IC708
(CHASSIS)
(CHASSIS)
MAIN (SW) BOARD (2/2)
SP701
+3.3V
REGULATOR
+1.8V
REGULATOR
CLOCK
SHIFT
+12V
REGULATOR
1
2
3
EZW-RT10A
TRANSCEIVER
(EZW-RT10A)
WIRELESS
OVER LOAD DETECT
Q702, 703
J
4
B
166911
D
15
H
10
K
1735 12
C
F
18119
E
8
G
14
A
213
I
7
(Page 12)
(Page 12)
(Page 12)
(Page 12)
(Page 14)
(Page 14)

SA-WA10R
SA-WA10R
1414
4-6. SCHEMATIC DIAGRAM - POWER (SW) Board - • See page 16 for IC Block Diagrams. • See page 19 for IC Pin Function Description.
MIAN (SW)
BOARD
(2/2)
CN706
C
MAIN (SW)
BOARD
(2/2)
CN704
B
IC B/D
2.6
3.9
2.4
2.6
0
2.6
20.2
0
330
169.2
164.3
4.7
10.5
174.9
5.9 0.9 2.4
16.2
169.2
330
4.7
164.3
164.3
2.5
2.6
1.7
1.1
1.1 0
2.8
2.8
2.8
0
3.5
0.1
2.6
4.1
3.2
5.9
1.6
1
3.3
1.1
0
0
F01
1/2W
2.2M
R01
275V
0.22
C01
250V
470p
C10
250V
470p
C11
D3SB60F3
D01
~
~
2SC3052EF-T1-LEF
Q01
1k
R14
4.7M
R13
4.7M
R12
150k
R04
1k
R02
330k
R11
470kR07
0.01C04
1000p
C07
0.01
C02
1.1uH
FB01
S
2SK3563(LB2SONY)
Q03
S
2SK3563(LB2SONY)
Q04
1kV
220p
C19
1kV
220p
C20
800V
0.033
C25
2W
0.1
R032
PC123Y22JOOF
PH02
PC123Y22JOOF
PH03
10ERB20-TB5
D12
35V
330
C27
1k
R34
470
R905
1k
R903
100k
R904
UDZW-TE17-15B
D05
10
R23
UDZW-TE17-15B
D08
25V
47
C18
0.1
C15
68
R15
100
R08
1000pC03
UF4005/23
D06
27k
R05
47k
R06
50V4.7
C05
50V10C08
10k
R27
10k
R28
87 5
4321
MIP2F20MS1SO
IC02
VDD FB CL VCC DRAIN
SOURCE SOURCE
ST02D-200TA
D10
470k
R31
0.1
C16
47
R29
10ERB20-TB5
D11
10ERB20-TB5
D901
2200p
C24
1
R19
3
1
2
FAN431AZXA
IC901
PC123Y22JOOF
PH01
E
ET01
0.1
C904
8.2k
R907
1k
R901
470
R902
47
R906
47k
R909
35V
2200
C907
1k
R910
10k
R911
47k
R912
10k
R913
10k
R915
2SC3052EF-T1-LEF
Q901
2SC3052EF-T1-LEF
Q902
ISA1235AC1TP-1EF
Q903
0.01
C910
50V
10
C913
1k
R914
TH01
TH02
C22
0.1
1 23
4
L01
LINE FILTER
T01
SUB POWER
TRANSFORMER
1
5
9
3
6
7
JW02
18
16
15
14
12
11
10
9
8
7
6
5
4
3
2
1
CXD9841P
IC01
VSENSE
F/B
CT
RT
GND
PROTECT
SS
VC1
OCP VC2
P-GND
VG-L
VB
VS
VG-H
VD
10
R25
0.22
C14
BAT54HT1
D04
0.1
C06
22k
R908
0.1
C917
1k
R916
1.5k
R917
0.22
C945
0.47
C901 0.47
C903
10V
220
C902
15k
R22
10k
R948
50V
1
C21
D905
MTZJ-T-77-27A
C13
250V
390
C12
250V
390
6.3V
1000
C905
4.7k
R933
1k
R934
2SC3052EF-T1-LEF
Q904
INVERTER
22k
R931
4.7k
R932
1k
R949
FCH08A10
D904
CL10
CL11
CL04
CL05
CL01
CL06
CL07
CL08
E
ET901
4.7k
R950
1k
R951
220
R952 CL02
T02
3
6
9
7
8
10
1
12
13
11
4
5
1
3
CN01
3P
AC_LIVE
2NC
AC_NEYTRAL
CL09
275V
0.1
C09
D917
UDZW-TE17-2.4B
D906
UDZW-TE17-8.2B
FH01 FH02
4
3
2
1
4P
W904
P-GND
+27V
P-GND
+27V
C909
0.1
C908
0.1
VDR01
5
4
3
2
1
5P
W905
D-GND
+4V
P-ON/OFF_
P_ON_DET
P_MONI-2
33
R33
250V
470p
C31
MC2836
D915
10uH
L901
MA2J1110GLS0
D902
T5.0AH 250V
IC02
(CHASSIS)
(CHASSIS)
POWER (SW) BOARD
(AC IN)
IC901
SHUNT
REGULATOR
POWER
CONTROL
IC01
INVERTER
SWITCHING
SWITCHING
ISOLATOR
ISOLATOR
TRANSFORMER
MAIN POWER
ISOLATOR
POWER
CONTROL
CONTROL SWITCH
POWER ON/OFF
Q902, 903
DETECT
OVER VOLTAGE
J
4
B
166911
D
15
H
10 1735 12
C
F
181
E
8
G
14
A
213
I
7
JW06
JW05
(Page 13)
(Page 13)

SA-WA10R
15
4-7. PRINTED WIRING BOARD - POWER (SW) Board - • : Uses unleaded solder.
B
E
B
E
B
E
B
E
BE
C22
C24
Q01
Q901
Q902
Q903
Q904
CL01
CL02
CL04
CL05
CL06
CL07
CL08
CL09
CL10
CL11
D04
D05
D08
R901 R902
R903
R904
R905
R906
R907
R908
R909
R910
R911
R912
R913
R914
R915
R916
R917
R02
R04
R05
R06
R07
R08
R11
R15
R931
R932
R933
R934
C901
R22
R23
C903
C904
R25
R27
R28
C908
C909
R948
R949
C910
R31
R950
R34
R951
R952
C917
C945
D902
D906
D915 D917
C02
C03
C04
C06
C07
C14
C15
C16
12
34
18
109
1
+
-
1
3
12
34
1
45
8
G
S
12
34
G
S
1
4
1
5
C20
C21
C25
C27
C31
Q03
Q04
JW02
JW05
JW06
L901
CN01
D01
D06
F01
D10
D11
D12
W904
W905
L01
R01
TH01
TH02
T01
T02
R12 R13
R14
R19
C902
C905
C907
R29
R32
R33
C913
JW101
JW102
JW103
JW104
JW105
JW106
JW107
JW108
JW109
JW110
JW111
JW112
JW113
JW114
JW115
JW116JW117
JW118
JW119
JW120
JW121
JW122
JW123
JW124
JW125
JW126
PH01
PH02
PH03
FB01
VDR01
D901
D904
D905
ET01
ET901
C01
FH01
IC901
FH02
C05
C08
C09
IC01
IC02
C10
C11
C12
C13
C18
C19
MAIN POWER
TRANSFORMER
SUB POWER
TRANSFORMER
(CHASSIS)
(CHASSIS)
(AC IN)
23
1
C
MAIN (SW)
BOARD
CN706
B
MAIN (SW)
BOARD
CN704
1-879-294-
11
(11)
POWER (SW) BOARD
AK
EC
AK
EC
AK
EC
D
D
LINE FILTER
A
B
C
D
E
F
G
H
I
1 2 3 4 5 6
(Page 11)
(Page 11)

SA-WA10R
16
• IC Block Diagrams
– MAIN (SW) Board –
IC603 PST3629NR
VDD 2
OUT 1
GND 3
+
–
VREF
CD5
NC4
IC604, 703 TK11133CSCL-G
IC702 TK11118CSCL-G
CONTROL
CIRCUIT
BANDGAP
REFERENCE
+
–
OVER HEAT &
OVER CURRENT
PROTECTION
1
VCONT
3
NP
2
GND
4
VOUT
5
VIN
IC704 CXD9788AR
12
11
10
9
8
7
6
5
4
3
VSUBC
XVSS
OUTR2
VSSR
OUTR1
VDDR
VSSL
VSSR
OUTL2
OUTL1
VSSL
VDDL
2
1
PWM
CLOCK
GENERATOR
(SECONDARY)
CLOCK
GENERATOR
(PRIMARY)
31
29
25 OVFFLAGL
26 SFLAG
27 INIT
30
S gP
GAIN
CONTROL
INIT/
MUTE
SAMPLING
RATE
CONVERTER
FILTER &
LOW CUT
FILTER
LINER
INTERPOLATOR
'6
48
XFSOIN
47
XVDD HPVDDL
46 45
HPOUTL1 HPVSSL
44 43
HPOUTL2 HPVDDR
42 41
HPOUTR1 HPVSSR
40
HPOUTR2
39 37
FSOCKO
38
FSOI
13
XOVSS
14
XFSOOUT
15
XOVDD
16
DVDD
17
DVSS
18
NSPMUTE
19
SOFTMUTE
20
PGMUTE
SERIAL
CONTROLLER
21
SCDT
22
SCSHIFT
23
SCLATCH
24
OVFFLAGR
28 MCKSEL
32 BFVDD
33 BFVSS
34 TEST
35 DVDD
36 XFSIIN
LRCK
BCK
DATA

SA-WA10R
17
IC701 BD33KA5WFP-E2
THERMAL
SHUT DOWN
OVER CURRENT
PROTECT
VDD
VCC
2
GND
3
NC
5
OUT
4
CTL
1
–
+
VREF DRIVER
IC705 MC74VHC74DTR2
14
1 2 3 4 5 6 7
13 12 11 10 9 8
VCC
GND
CK
CLR
CK
CLR
Q
PR
Q
Q
PR
Q
D
D
IC707 CXD9774M
RESET 4
GND 1
GND 3
PWM BP 2
DREG RTN 5
GVDD 6
M3 7
M1 10
M2 11
DVDD 12
DREG 8
DGND 9
DGND 14
GND 16
GND 18
PWM
RECEIVER
TIMING
CONTROL
&
PROTECTION
SD 13
OTW 15
DIGITAL
REGULATOR
PROTECTION
LOGIC
OT
&
UVP
DVDD DREG DREG
DGND
PWM AP 17 PWM
RECEIVER
DVDD DREG
DGND
DREG
GVDD
DREG
GATE
DRIVE
GVDD B35
GVDD B36
BST B33
PVDD B32
PVDD B
31
OUT B
30
OUT B
29
GND
28
GND
34
GATE
DRIVE
OCH
OCL
TIMING
CONTROL
&
PROTECTION
DREG
GATE
DRIVE
GVDD A
20
GVDD A
19
BST A
22
PVDD A
23
PVDD A
24
OUT A
25
OUT A
26
GND
27
GND21
GATE
DRIVE
OCH
OCL
GVDD
GVDD

SA-WA10R
18
– POWER (SW) Board –
IC02 MIP2F20MS1SO
CONSTANT
CURRENT
SOURCE
2FB
1VDD
4VCC 5 DRAIN
8 SOURCE
7 SOURCE
3CL
VCL
CLAMP CIRCUIT
(ILIMIT SETTING)
IN
ICL.LOW
VCL.OUT
ILIMIT VARIABLE
CIRCUIT
+
–
+
–
+
–
7.2V
+
–2.4V
VCC UV
VCC OVP
OVERHEAT
PROTECTION
S
R
Q
Q
RESTARTING
TRIGGER
R
S
Q
Q
+
–
27%
22%
FOR LIGHT LOAD
DETECTION INTERMITTENT
OSCILLATION CONTROL
GENERATOR
CLOCK
12kHz
MAXDC
5.7V
5.0V
VDD UV
5.7V
REGULATOR
VDD CLAMP
CIRCUIT
6.6V
+
–
ILIMIT
CORRECTION
CIRCUIT
FOR
DRAIN CURRENT
DETECT
GATE DRIVER
POWER
MOSFET
AT TURNING ON
BLANKING PULSE
GENERATION CIRCUIT

SA-WA10R
19
• IC Pin Function Description
MAIN (SW) BOARD IC602 μPD78F0526GB (S)-UET-A (SYSTEM CONTROLLER)
Pin No. Pin Name I/O Description
1 KEY-WAKEUP I Key wake-up signal input terminal
2 I-AC CUT I AC cut on/off detection signal input terminal “H”: AC cut on
3 EEPROM-SDA I/O Two-way I2C data bus with the EEPROM
4 O-EEPROM-SCL O I2C clock signal output to the EEPROM
5 RESET ISystem reset signal input from the reset signal generator “L”: reset
For several hundreds msec. after the power supply rises, “L” is input, then it change to “H”
6 XT2 O Sub system clock output terminal (32.768 kHz)
7 TX1 I Sub system clock input terminal (32.768 kHz)
8 FLMD0 I Flash memory programming mode setting terminal
9 X2 O Main system clock output terminal (16 MHz)
10 X1 I Main system clock output terminal (16 MHz)
11 REGC - External capacitor connecting terminal of regulator output for internal operation
12 VSS - Ground terminal
13 VDD - Power supply terminal (+3.3V)
14 O-SA_CLOCK O I2C clock signal output to the wireless transceiver
15 SA-DATA I/O Two-way I2C data bus with the wireless transceiver
16 O-SA_POW-ON I Power supply on/off control signal output terminal for wireless transceiver “H”: power on
17 O-SA_RESET O Reset signal output to the wireless transceiver “L”: reset
18 I-SA_INT I Interrupt signal input from the wireless transceiver
19 I-KEY_PAIRING I PAIRING key input terminal
20 O-AMP_RESET O Reset signal output to the power amplifier “L”: reset
21 O-AMP_NSPMUTE O NSP muting on/off control signal output to the stream processor “L”: muting on
22 O-AMP_SOFTMUTE O Soft muting on/off control signal output to the stream processor “L”: muting on
23 O-AMP_PGMUTE O PG muting on/off control signal output to the stream processor “L”: muting on
24 I-SUFIX I Destination setting terminal Fixed at “L” in this set
25 I-AMP_OVFFLAGL I Overflow flag input terminal Not used
26 O-AMP_INIT O Initialize signal output to the stream processor “L”: initialize
27 NC - Not used
28 O-STBY_LED O LED drive signal output terminal for power level indicator “H”: LED on
29 I-P-ON_DET I Power on detection signal input terminal
30 I-AMP_SD I Shut down signal input from the power amplifier “L” shut down
31 I-AMP_OTW I Over temperature warming signal input terminal Not used
32 O-SA_LED O LED drive signal output terminal for S-AIR indicator “H”: LED on
33 O-FLASH_SI I Serial data input terminal for flash writing
34 O-FLASH_SO O Serial data output terminal for flash writing
35 O-AMP_SCDT O Serial data output to the stream processor
36 O-AMP_SCLATCH O Serial data latch pulse signal output to the stream processor
37 O-AMP_SCSHIFT O Serial data transfer clock signal output to the stream processor
38 AVREF I Reference voltage (+3.3V) input terminal
39 AVSS - Ground terminal
40 I-KEY O POWER key input terminal
41 I-SA_ID I S-AIR ID selection switch input terminal “L”: A, “M”: B, “H”: C
42 O-DISCHARGE O Discharge control signal output terminal “H”: discharge
43 I-POWER_MONITOR2 I Power monitor terminal for main power transformer
44 to 46 NC - Not used
47 I-3.3V_POWER_MONI I Power monitor terminal for +3.3V power supply
48 O-POWER_ON O Power supply on/off control signal output terminal “H”: power on
49 O-SA_STBY_LED O LED drive signal output terminal for power level indicator “H”: LED on
50 O-PAIR_LED O LED drive signal output terminal for PAIRING indicator “H”: LED on
51, 52 NC - Not used

SA-WA10R
20
Pin No. Pin Name I/O Description
1 VSENSE I AC line voltage detection signal input terminal
2 F/B I Feed back signal input terminal for frequency modulation of oscillator
3 CT I Connected to the external capacitor for oscillator duty/frequency setting
4 RT I Connected to the external resistor for oscillator frequency setting
5 GND - Ground terminal
6 PROTECT I Connected to the external capacitor for determines intermittent operation period when abnor-
mal detection state
7 SS I Connected to the external capacitor for soft start timing
8 VC1 I Power supply terminal for control circuit “L”: stop
9 OCP I Over current detection signal and didt protection signal input terminal
10 VC2 O Power supply output terminal for driver
11 P-GND - Ground terminal for low voltage side driver
12 VG-L O Low voltage side driver drive signal output terminal
13 - - Not used
14 VB O Power supply output terminal for high voltage side driver
15 VS I High voltage side driver reference voltage input terminal
16 VG-H O High voltage side driver drive signal output terminal
17 - - Not used
18 VD I Terminal for drain-kick startingWhen starting, current is supplied directly from the rectification
diode to VC1
POWER (SW) BOARD IC01 CXD9841P (POWER CONTROL)
