Bixpy K-1 Installation and operating manual

K-1 Motor

K-1 Motor - User Manual and Safety Guide

BEFORE YOU BEGIN
Thank you for purchasing a Bixpy Product. You are now part of a family of adventure seekers who own one of the
most advanced, versatile and portable personal water propulsion systems in the world.
Bixpy products combine the latest in motor and battery technology along with finely tuned mechanical engineering
to give you gadgets that redefine the way you interact with the elements. As such, they take a bit of learning and
require some extra care. There are also hidden features and trouble-shooting information that are critical to the
operation and well being of your Bixpy device.
So, before anything else, and definitely before you hit the water, PLEASE read through this User Manual and learn
how to use and take care of your Bixpy Power Pack. Misuse and lack of care can be dangerous to you and those
around you, void your warranty and render your device useless.
Page 2

SAFETY, RESPONSIBILITY AND RELEASE
Using a motor/motor and batteries on any watercraft can be dangerous and involves certain risks which often
cannot be predicted or avoided. Those risks include but are not limited to personal injury or death, property
damage which may result from loss of control, collisions with other users or watercraft swimmers, and natural and
man-made objects and/or animals/plants. By choosing to use a Bixpy product you assume these risks and
thereby need to know and practice water safety rules, responsible motoring and proper use and maintenance of
your Bixpy product(s) to reduce these risks. Since it is impossible to anticipate every situation or condition which
can occur while under motor power in water Bixpy can make no representation or warranty about the use and
safety of Bixpy products under all conditions.
By purchasing and/or using Bixpy Products you acknowledge, agree and understand the danger(s) involved in
using Bixpy products and accessories. You on behalf of yourself and your heirs, executors, administrators,
successors and assignees: (1) Fully assume the risks involved in using Bixpy products and agree to use your best
judgment in undertaking your activities to reduce such risks. (2) Agree to strictly and fully follow all safety
instructions in this document and/or provided on the Bixpy Website or related communications. (3) Fully and
voluntarily waive relinquish covenant not to sue release and agree to indemnify and hold harmless Bixpy its
members, employees, officers, managers, agents, resellers and representatives from any claim or loss for personal
injury, property damage and/or death resulting from the use of Bixpy products and/or accessories.
You further: (1) acknowledge and agree that this waiver and assumption of risk is intended to be as broad and
inclusive as is permitted by applicable law and that if any portion thereof is held invalid the balance shall
nonetheless continue in full force and effect (2) acknowledge and agree this assumption of risk and waiver
provides for the release of legal rights and (3) expressly waive whatever benefits may be available under Section
1542 of the California Civil Code as follows: A general release does not extend to claims which the creditor does
not know or suspect to exist in his or her favor at the time of executing the release which if known by him or her
must have materially affected his or her settlement with the debtor.
Please note that your insurance policies may not provide coverage for incidents resulting from the use of Bixpy
products. Please contact your insurance company to determine your coverage prior to using Bixpy products.
IF YOU DO NOT AGREE FULLY TO ALL OF THESE PROVISIONS YOU SHOULD NOT USE BIXPY
PRODUCTS.
Page 3

WARNINGS & PRECAUTIONS
Please read and keep these warnings and precautions handy for future reference. Failure to safely operate and
care for your Bixpy products can result in loss of warranty, property damage, serious injury or death.
NEVER use Bixpy Jets to go further than you can swim, paddle or pedal back on your own power. Like any other
electronic device there is a chance that at any moment your device may cease to function as expected. Always
ensure that its seizure will not put you in danger.
In case of a malfunction whereby the motor will not stop operating, remove motor from water as soon as possible
and unplug from Power Pack. Remember in an emergency it is better to abandon your device than to risk your
well being.
You must take the following precautions when using a Bixpy Products:
• Do not run your motor in air at high speed or for prolonged periods
• Bixpy Outboard batteries are ONLY made to run Bixpy motors
•Bixpy Motors only run with Bixpy Outboard Batteries
• Never use under the influence of drugs or alcohol
• Be careful of getting long hair from getting into the propeller
• Do not wear loose clothing or objects when using Bixpy Jets
• Always wear an approved Personal Flotation Device
• Not to be used by children under 8 years old
• Must be used by all children only under adult supervision
• Misuse can lead to serious injury or death
• Always rinse in clean fresh water after use in salt water
• Do not expose bare connectors to water - connectors are only waterproof when mated
• Always use provided connector caps when connectors are not mated
• Operate and store above 0°C (32°F) and below 45°C (113°F)
• Do not use harsh chemicals to clean any Bixpy products
• NEVER spray Bixpy Products with anything - including paints and/or water sealants
Page 4

ATTACHING YOUR BIXPY K-1 MOTOR TO ADAPTERS
Your Bixpy K-1 motor has a four hole attachment point that is used to attached it to a variety of Bixpy Mounting
Adapters available at www.bixpy.com/adapters. The same attachment can be used to allow you to mount the
motor to your own (DIY) adapter. To secure your Bixpy motor to your adapter, open the provided M4 nuts and
bolts slide your adapter into the opening making sure the outlet of the motor is pointing to the rear of your
adapter. Use a Phillips screwdriver to secure the four nuts and bolts (DO NOT over tighten).
Use zip-ties and provided Bixpy Pipe Clips to secure the power cable to your adapter (not necessary for all
adapters) - see below.
Make sure there are no sharp kinks or bends in your wire on its way to your Bixpy Power Pack.
Page 5
Use the provided M4 nuts and bolts (1) to secure
your Bixpy motor to your Bixpy Adapter (2).
If you are making your own adapter for a DIY
application visit www.bixpy.info for instructions
and to download a template to make your own hole
patterns on your DIY receiver or adapter.
DO NOT over tighten your screws and
bolts as it may cause damage to the
adapter or standard attachment.
If you’re using your own hardware be
sure to use high grade stainless steel
fasteners to avoid corrosion.
1
1
2

RUNNING YOUR MOTOR CABLES
Make sure your cables makes a clean exit out of your motor and around your adapter. Don’t make sharp bends
pull the cable or try to modify the cable in any way. Doing so may damage the signal wire cores inside and
prevent your device from running.
Page 6
If you are using a fin or rudder adapter simply run
the cable from your motor to your battery. Use
zip-ties or cords to secure your wire and prevent it
from dangling or snagging.
If you are using a Bixpy Adapter with a vertical pipe
you can use the provided Bixpy Wire Clips (1) and
zip-ties to secure the cable to your adapter pipe and
run the cable as far up the adapter pipe as you
desire before running it to your Bixpy Power Pack.
Additional Bixpy Wire Clips are available for
purchase at www.bixpy.com
1

TAKING CARE OF YOUR BIXPY MOTOR
The Bixpy K-1 Motor is a direct drive system and as such operates quietly and efficiently using rechargeable
lithium batteries. The motor housing and all Bixpy Power Packs are fully sealed and require minimal
maintenance. Keep them clean and rinse or run them in fresh water after each use. The Motor and Power
Packs are happiest when kept clean and stored in cool dry conditions.
●The front of your Bixpy Motor acts as a water cooling system for the electronics inside the housing
and the plastic “face” acts as a bumper for your motor in case of impact. Do not block the intakes
and do not operate without the bumper.
●The Bixpy Propeller is designed with a “cutting” mechanism at its base to break weed and grass.
Even so eelgrass and other long and fibrous plants can make their way into the intake and wrap
around the propeller. Do not run the motor if grass or weed is clogging your propeller housing. This
can overheat the motor and in the long run can ruin your motor and/or Power Packs. Use forceps to
remove grass or other debris from your propeller housing. In extreme cases you can open the outlet
using a 3 millimeter Allen wrench and clean out your propeller housing. In the rare event that you
break your propeller DO NOT run your motor with a broken propeller.
●Your Jet uses some of the most advanced alloys to ensure maintenance free use in saltwater. Even
so we recommend rinsing or running your equipment in fresh water after use in salt water to extend
its life.
●Your Bixpy Motor is made to run in water. It uses water as a coolant and to moderate propeller
speed. Running it in air can damage your motor and/or Power Packs. DO NOT RUN IN AIR.
●Visit www.bixpy.com/spare-parts or an authorized Bixpy dealer for replacement parts.
Page 7

TROUBLESHOOTING
Every Bixpy Motor and Power Pack and accessories have been checked for defects multiple times and
operated individually for quality control and defect-free operation. However, if you experience a problem or
encounter a built-in safety feature that results in your motor or batteries not operating as expected the table
below offers some simple troubleshooting hints. If you experience other issues always feel free to reach out
to us for support: www.bixpy.com/support
Page 8
Motor connected but does not
respond
Check that your connectors are mated well and dry. Water in the connectors can cause
the motor to seize. Make sure your remote control has a fresh battery and working. Try
to run the motor using the “Emergency 4 Click”. Click here:
www.bixpy.com/4taps
Motor seems to be seized and makes
rough sounds
If you have not mated your connectors well water will short your signal wires and the
motor will act in a convulsive manner. At times it may seem as though the propeller
has seized but once power is disconnected you should be able to spin the propeller
with your fingers. In case water ingress into the connectors remove the connector use
compressed air and alcohol to rinse and dry the connectors re-mate the connectors
and try to run the motor again.
My motor will not stop running This is likely due to water intake into the motor or your battery or a possible hard blow
to the battery pack that has caused circuitry damage to the battery pack. Disconnect
your battery from your motor, stop using your product and contact Bixpy at:
[e-mail] as soon as possible.

USEFUL LINKS & RESOURCES
Page 9
ITEM(S) DETAILS RESOURCE
Installation Guides and
Downloads (including
videos and pictures)
This includes all adapters and also links to
common maintenance items link changing
remote batteries, cleaning your device,
downloading User Manuals and more
www.bixpy.com/guides
Adapter listing Find the best mounting adapter for your
specific kayak, paddleboard or other personal
watercraft
www.bixpy.info
Social Media YouTube Channel www.youtube.com/bixpy
Instagram www.instagram.com/bixpymotors
www.instagram.com/bixpybatteries
FaceBook www.facebook.com/bixpy
Twitter www.twitter.com/bixpy
Pinterest www.pinterest.com/bixpy
FAQs Find common questions and answers about
the products we make
www.bixpy.com/faqs
All Bixpy Adapters available List of all the adapters we sell for different water
craft
www.bixpy.com/adapters
Troubleshooting Learn how to troubleshoot common issues with
the jets and user errors.
www.bixpy.com/trouble
Store Maps Check out were we sell Bixpy Jets www.bixpy.com/find-a-store-near-you
Get support For repairs, warranty and product support www.bixpy.com/support/

LIMITED WARRANTY
Bixpy warrants its hardware products against defects in materials and workmanship for a period of one (1)
year from the date of original purchase provided the purchase was made from an authorized Bixpy Dealer or
directly from Bixpy or the Bixpy website. This warranty is void if the equipment is opened, altered, misused,
mishandled, maladjusted, suffers excessive wear or is serviced by any parties not authorized by Bixpy LLC.
Bixpy Jets are made for recreational consumer use and are not warrantied for commercial or rental use. The
warranty does not include transportation costs incurred because of the need for service. Bixpy reserves the
right to make changes in design and improve upon its products without obligation to install these
improvements in any of its products previously manufactured and sold. For warranty services or for a copy of
Bixpy’s Warranty Policy including a complete list of exclusions and limitations contact Bixpy LLC at
1-866-249-7910.
BEFORE you send us anything back please contact our customer service to discuss your issue and obtain
an RMA (Return Merchandise Authorization). There are limitations on shipping lithium-ion batteries and we
will not accept service returns without prior arrangements. Please contact us for details on how to deal with
defective products at: [e-mail]
We are not equipped to handle walk-in traffic at our headquarters in San Diego so even if you are local please
do not bring your product to our offices unless you have made prior arrangements.
Page 10

BIXPY K-1 MOTOR SPECIFICATIONS
MOTOR SIZE
Width along motor body: 80mm 3.15”
Width along the output nozzle: 91.5 mm 3.60”
Length: 230mm 9.05”
Height (including top fin adapter): 155 mm 6.10”
Weight: 1270 grams 2.8 lb
POWER OUTPUT
Max. output using PP-378 V4: 400 watts
Thrust equivalent: Up to 33 lbs 15 kg
Water movement: ~130 GPM ~500 L/min
Max. output using PP-768: 450 watts
Thrust equivalent: Up to 38 lbs 17 kg
Water movement: ~145 GPM ~550 L/min
CONNECTORS: Bixpy 5 pin connector - rated for max. 30V usage with Bixpy batteries
MOTOR IP RATING: IP68 rated
CORROSION RATING: All components are fresh and saltwater resistant
Page 11

FINE PRINTS
Bixpy®
Bixpy, Bixpy Jet and the Bixpy Logo, Life Boosted brand are trademarks of Bixpy LLC. Copyright 2023®.
Registering your vessel
In certain municipalities, counties, states or countries it is required that you register motorized kayaks, SUPs
or canoes with your local licensing body. For example in many US states the state Department of Motor
Vehicles (DMV) or the Coast Guard will require you to register your motorized kayak as a motorized vessel.
Please be sure to take the necessary steps to comply with local laws and regulations that apply to your
vessel once motorized. In the US a good resource to find more information is www.takemefishing.org. For
the purposes of registration or exemption from registering in certain places please note that Bixpy Jets are
electric motors that produce less than 10 horse powers.
Product variation
Some of the products photographed may have slight differences from the products in the package both
cosmetically and functionally.
Page 12

K-1 Motor - Manual del usuario y guía de seguridad

ANTES DE EMPEZAR
Gracias por adquirir un producto Bixpy. Ahora formas parte de una familia de aventureros que poseen uno de
los sistemas personales de propulsión acuática más avanzados, versátiles y portátiles del mundo.
Los productos Bixpy combinan lo último en tecnología de motores y baterías junto con una afinada ingeniería
mecánica para ofrecerte dispositivos que redefinen tu forma de interactuar con los elementos. Como tales,
requieren un poco de aprendizaje y un cuidado especial. También hay funciones ocultas e información sobre
resolución de problemas que son fundamentales para el funcionamiento y el bienestar de tu dispositivo Bixpy.
Así que, antes de nada, y definitivamente antes de lanzarte al agua, POR FAVOR, lee este Manual de Usuario
y aprende a usar y cuidar tu Bixpy Power Pack. El mal uso y la falta de cuidado pueden ser peligrosos para ti
y para los que te rodean, anular la garantía e inutilizar el dispositivo.
Página 2

SEGURIDAD, RESPONSABILIDAD Y LIBERACIÓN
El uso de un motor/motor y baterías en cualquier embarcación puede ser peligroso e implica ciertos riesgos que a
menudo no pueden predecirse ni evitarse. Dichos riesgos incluyen, entre otros, lesiones personales o muerte, daños
materiales que pueden derivarse de la pérdida de control, colisiones con otros usuarios o nadadores de la embarcación,
y objetos naturales y artificiales y/o animales/plantas. Al elegir utilizar un producto Bixpy, asumes estos riesgos y, por lo
tanto, debes conocer y practicar las normas de seguridad en el agua, la conducción responsable y el uso y
mantenimiento adecuados de tu(s) producto(s) Bixpy para reducir estos riesgos. Dado que es imposible anticipar todas
las situaciones o condiciones que pueden ocurrir mientras se está bajo la fuerza del motor en el agua Bixpy no puede
hacer ninguna representación o garantía sobre el uso y la seguridad de los productos Bixpy en todas las condiciones.
Al comprar y/o utilizar los productos Bixpy, reconoces, aceptas y comprendes los peligros que conlleva el uso de los
productos y accesorios Bixpy. Usted, en su nombre y en el de sus herederos, albaceas, administradores, sucesores y
cesionarios: (1) Asume plenamente los riesgos que conlleva el uso de los productos Bixpy y se compromete a utilizar su
mejor criterio en la realización de sus actividades para reducir dichos riesgos. (2) Se comprometen a seguir estricta y
plenamente todas las instrucciones de seguridad contenidas en este documento y/o proporcionadas en el sitio Web de
Bixpy o en comunicaciones relacionadas. (3) Renuncia total y voluntariamente a no demandar y se compromete a
indemnizar y mantener indemne a Bixpy sus miembros, empleados, funcionarios, gerentes, agentes, revendedores y
representantes de cualquier reclamación o pérdida por lesiones personales, daños a la propiedad y / o la muerte
resultante del uso de productos Bixpy y / o accesorios.
Además: (1) reconoce y acepta que esta renuncia y asunción de riesgos pretende ser tan amplia e inclusiva como lo
permita la ley aplicable y que si cualquier parte de la misma se considera inválida, el resto continuará en pleno vigor y
efecto (2) reconoce y acepta que esta asunción de riesgos y renuncia proporciona la liberación de derechos legales y (3)
renuncia expresamente a cualquier beneficio que pueda estar disponible bajo la Sección 1542 del Código Civil de
California de la siguiente manera: Una exoneración general no se extiende a reclamaciones que el acreedor no conozca
o sospeche que existen a su favor en el momento de ejecutar la exoneración y que, de haberlas conocido, habrían
afectado materialmente a su acuerdo con el deudor.
Tenga en cuenta que es posible que sus pólizas de seguro no proporcionen cobertura para incidentes derivados del uso
de productos Bixpy. Póngase en contacto con su compañía de seguros para determinar su cobertura antes de utilizar los
productos Bixpy.
SI NO ESTÁ TOTALMENTE DE ACUERDO CON TODAS ESTAS DISPOSICIONES, NO DEBE UTILIZAR LOS
PRODUCTOS BIXPY.
Página 3

ADVERTENCIAS Y PRECAUCIONES
Lea y tenga a mano estas advertencias y precauciones para futuras consultas. Si no utiliza y cuida sus productos
Bixpy de forma segura, puede perder la garantía, sufrir daños materiales, lesiones graves o incluso la muerte.
NUNCA utilices los Bixpy Jets para ir más lejos de lo que puedas nadar, remar o pedalear por tus propios medios.
Como cualquier otro dispositivo electrónico, existe la posibilidad de que en cualquier momento su dispositivo deje
de funcionar como se espera de él. Asegúrese siempre de que su detención no le pondrá en peligro.
En caso de que el motor no deje de funcionar, sáquelo del agua lo antes posible y desenchúfelo de la fuente de
alimentación. Recuerde que en caso de emergencia es mejor abandonar el aparato que arriesgar su bienestar.
Debe tomar las siguientes precauciones cuando utilice un producto Bixpys:
• Do not run your motor in air at high speed or for prolonged periods
• Bixpy Outboard batteries are ONLY made to run Bixpy motors
•Bixpy Motors only run with Bixpy Outboard Batteries
• Never use under the influence of drugs or alcohol
• Be careful of getting long hair from getting into the propeller
• Do not wear loose clothing or objects when using Bixpy Jets
• Always wear an approved Personal Flotation Device
• Not to be used by children under 8 years old
• Must be used by all children only under adult supervision
• Misuse can lead to serious injury or death
• Always rinse in clean fresh water after use in salt water
• Do not expose bare connectors to water - connectors are only waterproof when mated
• Always use provided connector caps when connectors are not mated
• Operate and store above 0°C (32°F) and below 45°C (113°F)
• Do not use harsh chemicals to clean any Bixpy products
• NEVER spray Bixpy Products with anything - including paints and/or water sealants
Página 4

FIJACIÓN DEL MOTOR BIXPY K-1 A LOS ADAPTADORES
Tu motor Bixpy K-1 tiene un punto de fijación de cuatro agujeros que se utiliza para fijarlo a una variedad de adaptadores de
montaje Bixpy disponibles en www.bixpy.com/adapters. El mismo accesorio se puede utilizar para que puedas montar el
motor en tu propio adaptador (DIY). Para fijar tu motor Bixpy a tu adaptador, abre las tuercas y tornillos M4 suministrados y
desliza tu adaptador en la abertura asegurándote de que la salida del motor apunta hacia la parte trasera de tu adaptador.
Utilice un destornillador Phillips para fijar las cuatro tuercas y tornillos (NO apriete demasiado).
Utiliza bridas y las abrazaderas Bixpy suministradas para fijar el cable de alimentación al adaptador (no es necesario para
todos los adaptadores).
Asegúrate de que no hay dobleces ni curvas pronunciadas en el cable que va a la unidad de alimentación Bixpy.
Página 5
Utiliza los tornillos y tuercas M4 suministrados (1) para
fijar el motor Bixpy al adaptador Bixpy (2).
Si vas a hacer tu propio adaptador para una aplicación
de bricolaje, visita www.bixpy.info para obtener
instrucciones y descargar una plantilla para hacer tus
propios patrones de orificios en tu receptor o adaptador
de bricolaje.
NO apretar demasiado los tornillos y
pernos, ya que puede causar daños en el
adaptador o el accesorio estándar.
Si utilizas tus propios herrajes, asegúrate
de utilizar tornillería de acero inoxidable de
alta calidad para evitar la corrosión.
1
1
2

PASAR LOS CABLES DEL MOTOR
Asegúrese de que sus cables hacen una salida limpia fuera de su motor y alrededor de su adaptador. No hagas
curvas cerradas ni intentes modificar el cable de ninguna manera. Hacerlo puede dañar los núcleos del cable de
señal en el interior y evitar que su dispositivo funcione.
Página 6
Si utilizas un adaptador de aleta o timón,
simplemente pasa el cable desde el motor hasta la
batería. Utiliza bridas o cordones para fijar el cable y
evitar que cuelgue o se enganche.
Si utilizas un adaptador Bixpy con un tubo vertical,
puedes utilizar las abrazaderas de alambre Bixpy (1)
y las bridas para fijar el cable al tubo adaptador y
llevarlo hasta el tubo adaptador que desees antes
de conectarlo a la unidad de alimentación Bixpy.
Puede adquirir más pinzas para cables Bixpy en
www.bixpy.com
1

CUIDADO DEL MOTOR BIXPY
El motor Bixpy K-1 es un sistema de transmisión directa y, como tal, funciona de forma silenciosa y eficiente
utilizando baterías de litio recargables. La carcasa del motor y todos los Bixpy Power Packs están totalmente
sellados y requieren un mantenimiento mínimo. Manténgalos limpios y enjuáguelos o páselos por agua dulce
después de cada uso. El motor y las fuentes de alimentación funcionan mejor si se mantienen limpios y se
guardan en un lugar fresco y seco.
●La parte delantera de su Motor Bixpy actúa como un sistema de refrigeración por agua para la
electrónica dentro de la carcasa y la "cara" de plástico actúa como un parachoques para su motor
en caso de impacto. No bloquee las entradas y no opere sin el parachoques.
●La hélice Bixpy está diseñada con un mecanismo de "corte" en su base para romper la maleza y la
hierba. Aun así, la hierba marina y otras plantas largas y fibrosas pueden introducirse en la toma de
aire y envolver la hélice. No haga funcionar el motor si la hierba o la maleza obstruyen el alojamiento
de la hélice. Esto puede sobrecalentar el motor y a la larga puede arruinar su motor y/o Power Packs.
Utilice unas pinzas para retirar la hierba u otros residuos del alojamiento de la hélice. En casos
extremos, puede abrir la salida con una llave Allen de 3 milímetros y limpiar el alojamiento de la
hélice. En el raro caso de que rompa su hélice NO haga funcionar su motor con una hélice rota.
●Tu Jet utiliza algunas de las aleaciones más avanzadas para asegurar un uso libre de mantenimiento
en agua salada. Aun así recomendamos enjuagar o hacer funcionar su equipo en agua dulce
después de su uso en agua salada para alargar su vida útil.
●Tu motor Bixpy está hecho para funcionar en agua. Utiliza el agua como refrigerante y para moderar
la velocidad de la hélice. Hacerlo funcionar en el aire puede dañar tu motor y/o los Power Packs. NO
LO HAGAS FUNCIONAR EN EL AIRE.
● Visita www.bixpy.com/spare-parts o un distribuidor autorizado Bixpy para piezas de repuesto.
Página 7
