Black & Decker CM5000BD User manual

MILL & BREW
12-CUP PROGRAMMABLE
COFFEE MAKER
CAFETERA
DE
12 TAZAS PROGRAMABLE
CAFETIÈRE PROGRAMMABLE
DE
12 TASSES
TM
use & care manual
manual de uso y cuidado
guide d’utilisation et d’entretien
CM5000BD
CM5000GD
CM5000RD
CM5000WD

1
CONTENTS
Important Safeguards
Getting to know your Mill & Brew Coffee Maker
Mill & Brew Coffee Maker Product Benefits
Getting to know your Control Panel
Before Brewing
Programming your Mill & Brew Coffee Maker
4 Elements to Brew the Perfect Cup
Tips for a Perfect Cup of Coffee
Brewing Coffee
Care and Cleaning
Troubleshooting
Warranty and Customer Service Information
2-3
4–5
6
7
8
8–9
10
11
12–13
14–15
16
17
WARNING
RISK OF FIRE OR ELECTRIC SHOCK. DO NOT OPEN.
The lightning symbol refers to “dangerous voltage”; the exclamation symbol refers
to maintenance instructions. See below.
Warning: To reduce the risk of fire or electric shock, do not remove the cover of the
coffeemaker. There are no user-serviceable parts inside. Repair should be done by
authorized service personnel only.

2
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS.
When using electrical appliances, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and/or injury, including the following:
• Read all instructions
• Do not touch hot surfaces. Use
handles or knobs.
• To protect against fire, electric
shock and injury to persons do not
immerse cord, plugs or appliance
in water or other liquid.
• Close supervision is necessary
when any appliance is used by
or near children.
• Unplug from outlet when not
in use and before cleaning.
Allow to cool before putting on
or taking off parts, and before
cleaning the appliance.
• Do not operate any appliance
with a damaged cord or
plug, or after the appliance
malfunctions or has been
damaged in any manner.
Contact the Consumer Support
department listed in these
instructions
• The use of accessory
attachments not recommended
by the appliance manufacturer
may result in fire, electric shock
or injury to persons.
• Do not use outdoors.
• Do not let cord hang over edge
of table or counter, or touch hot
surfaces.
• Do not place on or near a hot gas or
electric burner, or in a heated oven.
• To disconnect, turn any control to
off, then remove plug from wall
outlet.
• Do not use this appliance for
other than intended use.
• Keep lid on the carafe when in use.
• Scalding may occur if the lid is
removed during the brewing
cycles.
• The carafe is designed for use
with this appliance. It must
never be used on a range top.
• Do not set a hot carafe on a wet
or cold surface.
• Do not use a cracked carafe
or a carafe having a loose or
weakened handle.
• Do not clean carafe with
cleansers, steel wool pads or
other abrasive material.
• This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
• Children should be supervised
to ensure that they do not play
with the appliance.
• Scalding and/or burns may occur if the
integrated grinder lid is removed
during the brewing cycle.
• Check the grinder basket for presence
of foreign objects before using.
• Only coffee beans and coffee grounds
should be placed into the grinder
basket.
• Avoid contact with moving
parts

3
POLARIZED PLUG (120V models only)
This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If
the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw to prevent
removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt
to remove the outer cover. There are no user-serviceable parts inside. Repair should
be done only by authorized service personnel.
ELECTRICAL CORD
1. A short power-supply cord is provided to reduce the risk resulting from becoming
entangled in or tripping over a longer cord.
2. Extension cords may be used if care is exercised in their use.
3. If a long detachable extension cord is used:
a) The marked electrical rating of the
power cord or extension cord should
be at least as great as the electrical
rating of the appliance.
b) If the appliance is of the grounded
type, the extension cord should be a
grounding-type 3-wire cord.
c) The cord should be arranged so that
it will not drape over the countertop
or tabletop where it can be pulled on
by children or tripped over.
Note: If the power cord is damaged, please contact the warranty department listed
in these instructions.
SAVE THESE INSTRUCTIONS.
This product is for household use only.

4
GETTING TO KNOW YOUR
MILL & BREW COFFEE MAKER
1. Control panel
2. Lift latch
3. Lid
4. Water reservoir cover
5. Easy viewing water window
6. Duralife™ glass carafe
(Part# CM5000-01 )
7. “Keep hot” carafe plate
8. Coffee scoop
(Part# CM5000-02 )
1
2
3
8
4
5
6
7
Product may vary slightly
from what is illustrated.

5
GETTING TO KNOW YOUR
MILL & BREW COFFEE MAKER
1. 2-in-1 grinder and
permanent filter basket
(Part# CM5000-03)
2. Washable brew basket
(Part# CM5000-04)
3. Lift latch
4. Grinder lid
5. Removable showerhead
(press highlighted tabs
to remove)
(Part# CM5000-05)
2
1
3
4
5

6
MILL & BREW COFFEE MAKER
PRODUCT BENEFITS
Fresh Brew Timer
After the brew cycle is complete,
the time since brewed will be
displayed in 1-minute increments.
This information will be in place of
the digital clock during keep warm.
2-in-1 Grinder and
Permanent Filter Basket
Whole coffee beans are ground
and brewed in the same grinder
assembly, allowing for fast brewing
and easy clean-up.
Eco-Friendly Permanent Filter
The high-performance Bronze Tone
permanent filter eliminates the need
for paper filters and minimizes any
coffee staining appearance.
Washable Brew Basket
The washable brew basket can easily
be removed and washed after brewing,
and is top rack dishwasher safe.
Removable Showerhead
The coffeemaker’s showerhead is
removable for easy cleaning.
Auto Brew
The programmable Auto Brew delay
start allows you to set the 24-hour
timer to brew coffee at the selected
time, day or night.
Digital Clock with Backlighting
The LCD display features a
programmable digital clock and
backlighting for easy-viewing in low
light conditions.
Adjustable Auto-Shutoff
This feature allows you to select
automatic shutoff times from 0-2
hours in 30 minute increments.
The “Keep Hot” carafe plate will
be activated until the automatic
shutoff time is reached.
Brew Strength Selector
Customize the flavor of your coffee
by selecting from three brew
strength settings: regular, strong,
or bold.
Sneak-A-Cup™
Can’t wait for the full pot of coffee
to finish brewing? Sneak-A-Cup™
of coffee before brewing using this
great feature, which stops the flow
of coffee into your carafe. Replace
the carafe back in the coffee maker
within 20 seconds to prevent brew
basket overflow.
Grind Select
Cycles through optimal grind
settings (4, 6, 8, 10, 12) correlating
with the number of cups to be
brewed, or turns the grinder OFF
for brewing pre-ground coffee.
Duralife™ Glass Carafe
Durable construction provides an
extended carafe life. Water level
markings make for easy filling and
pouring.
Non-stick “Keep Hot” Carafe Plate
This feature allows you to keep your
carafe of coffee hot after brewing
until the selected auto-shutoff time
has been reached.
Easy Viewing Water Window
The water window shows the
amount of water in the reservoir for
easy and accurate filling.
Cord Storage
Keep excess cord out of the way
and your countertop neat with
simple cord storage.

7
GETTING TO KNOW YOUR CONTROL PANEL
Clock / Backlit LCD Display
Power: Turns the unit ON or OFF.
Auto: Turns on the Auto
Brew delayed start.
Program: Auto Brew, press and
release button once.
Keep Warm, press and hold.
Hour: Use to program
the clock (see “Programming”
section).
Minute: Use to program
the clock (or cycle through
different keep warm settings when
in that program mode to adjust
“Keep Warm” time.)
Grind: Cycles through optimal grind
settings (4, 6, 8, 10, 12) correlating
with the number of cups to be
brewed. Also, turns the grinder OFF
( )for brewing pre-ground coffee.
Strong: Use to select the
Brew Strength setting (3 levels)
No bars = regular (default setting)
1 bar ( ) = strong
2 bars ( ) = bold
Indicates the delay start timer is set
Brew
strength
settings
Optimal grind setting correlating with
the number of cups to be brewed
Indicates if the whole bean grinder function
has been turned OFF ( ) or ON ( )

8
BEFORE BREWING
PROGRAMMING YOUR
MILL & BREW COFFEE MAKER
1. Carefully unpack your coffeemaker, removing all packaging materials, labels,
and/or stickers from your coffeemaker.
2. Clean your coffeemaker thoroughly before using for the first time. Wash
the Glass Carafe, Washable Brew Basket, 2-in-1 Grinder and Permanent Filter
Basket, and Removable Showerhead in warm, soapy water. Rinse and dry, then
place back into your coffeemaker.
3. Clean the inside of your coffeemaker by running two full brewing cycles with
water only, no coffee.
a. Pour fresh, cold water into the water reservoir up to the 12-cup MAX
mark, then place carafe on the warming plate.
b. Plug cord into standard electrical outlet.
c. Press the GRIND button until you reach the symbol to turn the grinder
OFF ( )
d. Push the ON-OFF / Power Button to immediately brew water through
the coffeemaker without adding coffee.
e. Once the cycle is finished, discard water and rinse out the 2-in-1
Grinder and Permanent Filter Basket.
f. Turn off appliance, unplug and allow to cool down for 15 minutes
before repeating.
Setting the Digital Clock
1. Plug the coffeemaker into a standard electrical outlet.
2. The digital clock display flashes “12:00”.
3. To set the time, press the HR button until the correct hour appears on the
display. The “PM” symbol will appear in the upper right corner of the digital
display for PM time settings.
4. Press the MIN button to select minutes.
Note: If the unit is unplugged or power interrupted, the time will need to
be reset, as will the Auto Brew delay start time.
Setting the Auto Brew Delay Start
The programmable Auto Brew delay start allows you to set the 24-hour timer
to brew coffee at the selected time, day or night. To activate the Auto Brew
timer, follow the steps on the next page:
Note: The first button press illuminates the backlit display and any
subsequent presses will perform the programming.

9
PROGRAMMING YOUR
MILL & BREW COFFEE MAKER
1. After the digital clock is set, press the PROG button. The timer icon ( ) will
begin to flash and display will read 12:00.
2. Press the HR button and then MIN button to select the time you would
like automatic brewing to begin (for example: 7:30 AM). Make sure the PM light
is not on, if needed.
3. The timer display will flash several times then switch back to the current time of day.
4. Press and release the AUTO button to activate the delay start time that was just
programmed. The timer icon ( ) will remain solid, indicating Auto Brew is activated.
5. When the time of day matches the programmed Auto Brew set time, your
coffeemaker will activate the brew cycle.
6. To cancel the Auto Brew function, press the AUTO button until the timer
icon ( ) disappears.
Note: To check the preset Auto Brew time, press PROG button and the preset
Auto Brew time is displayed. Press AUTO button to reactivate the timer.
Setting the Adjustable Auto-off, Keep Warm Time
This feature allows you to select automatic shutoff times from 0-2 hours in
30 minute increments. The “Keep Hot” carafe plate will be activated until the
automatic shutoff time is reached.
1. Press and hold PROG button for 3 seconds. This will show the default (120
minutes) keep warm time setting.
2. Press the MIN button to toggle through the keep warm settings (00,
30, 60, 90, 120). The values correlate to length of time (in minutes) the keep
warm will remain on after brewing.
3. Press the PROG button to lock in the keep warm setting.
Note: To check the time Auto Brew is set for without making changes, press
the PROG button to display the Auto Brew time, then press the AUTO button.”
Setting the Brew Strength Selector
The Brew Strength Selector customizes the flavor of your coffee by selecting
from three brew strength settings.
1. Press the STRONG button to cycle through the different Brew Strength settings
(3 levels).
a. No bars = regular (default setting)
b. 1 bar ( ) = strong
c. 2 bars ( ) = bold
