Black & Decker BMO700 User manual

700W, 17L Microwave Oven
YEAR
RE
PLACEMENT
WARRA
NT
Y
BMO700

2

3
Important Safeguards
When using electrical appliances, in order to reduce
the risk of re, electric shock, and/or injury to
persons, basic safety precautions should always be
followed, including:
For Your Safety
Read all instructions carefully, even if you are quite
familiar with the appliance.
 To protect against the risk of electric shock DO
NOT IMMERSE this appliance into water or any
other liquid.
 This appliance is not intended for use by children
or inrm persons without supervision.
 Never leave an appliance unattended when in use.
 Young children should be supervised to ensure
they do not play with the appliance.
 Do not operate any appliance with a damaged
cord or plug, after the appliance malfunctions, or
is dropped or damaged in any manner.
 Do not attempt to override the door lock
mechanism.
 Do not use outdoors.
 Use unit indoors in a dry location.
 Do not let the cord hang over the edge of table or
counter, or touch hot surfaces. Do not operate or
place any part of this appliance on or near a hot
gas or electric burner or in a heated oven.
 The use of attachments or accessories not
recommended or sold by the manufacturer may
cause re, electric shock or injury.
 Operate on a level surface. Operation on sinks,
drainboards or uneven surfaces must be avoided.
 Do not use any appliance for anything other than
its intended use. This product is intended for
household use only.
 Do not attempt to repair or disassemble the
appliance. There are no user serviceable parts.
 To reduce the risk of re in the oven cavity:
a) When heating food in plastic or paper containers,
check the oven frequently due to the possibility of
ignition.
b) Remove wire twist-ties from paper or plastic bags
before placing bag in oven.
c) If smoke is observed, switch off or unplug the
appliance and keep the door closed in order to
stie any ames.
d) Do not use the oven for storage purposes. Do not
leave paper products, cooking utensils or food in
the oven when not in use.
 Microwave heating of beverages can result in
delayed eruptive boiling, therefore care has to be
taken when handling the container. Do not place
face directly over container when removing from
oven.
 Do not fry food in the oven, hot oil can damage
oven parts and utensils, and even result in skin
burns.
 Eggs in their shell and whole hard-boiled eggs
shall not be heated in the microwave oven since
they may explode. Raw, cracked eggs may be
cooked in microwave safe containers, but the yolk
must be pierced.
 Pierce foods with heavy skins such as potatoes,
whole squash, apples and chestnuts before
cooking.
 The contents of feeding bottles and baby
food jars are to be stirred or shaken and
the temperature is to be checked before
consumption, in order to avoid burns.
 Cooking utensils may become hot because of
heat transferred from the heated food. Potholders
may be needed to handle the utensil.
 Utensils should be checked to ensure that they
are suitable for use in microwave oven.

4
Utensil Test
Fill the utensil (or serving dish) to be tested with
one cup of cold water. Microwave for 90 seconds
at 100% power. If the water becomes warm and the
utensil stays cool, it is safe to use. If the water stays
cool and the utensil becomes very hot, it should not
be used in the microwave.
WARNING
If the door or door seals are damaged, the oven
must not be operated until it has been repaired by a
qualied person.
WARNING
It is hazardous for anyone other than a qualied
person to carry out any service or repair operation
which involves the removal of any cover which gives
protection against exposure to microwave energy.
WARNING
Liquids or other foods must not be heated in sealed
containers since they are liable to explode.
WARNING
Only allow children to use the oven without
supervision when adequate instructions have been
given so that the child is able to use the oven in a
safe way and understands the hazards of improper
use.
COMPULSORY WARNING
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or similarly
qualied person in order to avoid a hazard.
This product has not been designed for any uses
other than those specied in this booklet.
Save These Instructions
Precautions to Avoid Possible
Exposure to Excessive
Microwave Energy
 Do not attempt to operate this oven with the
door open since open-door operation can result
in harmful exposure to microwave energy. It is
important not to interfere or tamper with the
safety interlocks.
 Do not place any object between the oven front
face and the door or allow soil or cleaner residue
to accumulate on sealing surfaces.
 Do not operate the oven if it is damaged. It is
particularly important that the oven door closes
properly and that there is no damage to the:
1. Door (bent),
2. Hinges and latches (broken or loosened),
3. Door seals and sealing surfaces.
 The oven should not be adjusted or repaired
by anyone except properly qualied service
personnel.
 If moving or transporting microwave, keep
microwave well protected as rough treatment can
cause damage.
Before You Call for Service
If the oven fails to operate:
 Check to ensure that the oven is plugged in
securely to the power outlet. If it is not, remove
the plug from the outlet, wait 10 seconds and
plug it in again securely, and switch on.
 Check for a blown circuit fuse or a tripped main
circuit breaker. If these seem to be operating
properly, test the outlet with another appliance.
 Check to ensure that the control panel is
programmed correctly and the timer is set.
 Check to ensure that the door is securely closed,
engaging the door safety lock system, otherwise
the microwave energy will not ow into the oven.
IF NONE OF THE ABOVE RECTIFY THE SITUATION
THEN CONTACT A QUALIFIED TECHNICIAN. DO NOT
TRY TO ADJUST OR REPAIR THE OVEN YOURSELF.

5
Features of Your Microwave Oven
Electronic Control Pad
Electronic Display
Shaft
Glass Viewing Window
Hinged Door
Door Safety
Lock System
Oven Air Vent
Door Release Button
Roller Ring
Glass Tray

6
Installation
 Make sure that all the packing materials are
removed from the inside of the oven.
Note: It is important not to remove or unscrew
the panel from the inside right hand side of the
microwave oven.
 Check the oven for any damage, such as
misaligned or bent door, damaged door seals and
sealing surface, broken or loose door hinges and
latches and dents inside the cavity or on the door.
If there is any damage, do not operate the oven,
and return to the place of purchase.
 This microwave oven must be placed on a at,
stable surface to hold its weight and the heaviest
food likely to be cooked in the oven.
 Do not place the oven where heat, moisture or
high humidity are generated, or near combustible
materials.
 For correct operation, the oven must have
sufcient air ow. Allow 20cm of space above the
oven, 10cm at back and 5cm at both sides. Do
not cover or block any openings on the appliance.
Do not remove feet.
 Do not operate the oven without glass tray, roller
support, and shaft in their proper positions.
 Make sure that the power supply cord is
undamaged and does not run under the oven or
over any hot or sharp surface.
 The socket must be readily accessible so that it
can be easily unplugged in an emergency.
 Do not use the oven outdoors.
Grounding Instructions
This appliance must be grounded. This oven is
equipped with a cord having a grounding wire with a
grounding plug. It must be plugged into
a wall receptacle that is properly installed and
grounded. In the event of an electrical short circuit,
grounding reduces risk of electric shock by providing
an escape wire for the electric current.
WARNING
Improper use of the grounding plug can result in a
risk of electric shock.
Note: If you have any questions about the
grounding or electrical instructions, consult a
qualied electrician or service person.
Radio Interference
 Operation of the microwave oven can cause
interference to your radio, TV or similar
equipment.
 When there is interference, it may be reduced or
eliminated by taking the following measures:
1. Clean door and sealing surface of the oven.
2. Reorientate the receiving antenna of radio or
television.
3. Relocate the microwave oven with respect to the
receiver.
4. Move the microwave oven away from the receiver.
5. Plug the microwave oven into a different outlet so
that microwave oven and receiver are on different
branch circuits.
Microwave Cooking Principles
 Arrange food carefully. Place thickest areas
towards outside of dish.
 Watch cooking time. Cook for the shortest
amount of time indicated and add more as
needed. Food severely overcooked can smoke or
ignite.
 Cover foods while cooking. Covers prevent
spattering and help foods to cook evenly.
 Turn foods over once during microwaving to
improve cooking of such foods as chicken and
hamburgers. Large items like roasts must be
turned over at least once.

7
 Rearrange foods such as meatballs halfway
through cooking both from top to bottom and
from the centre of the dish to the outside.
Utensils Guide
 The ideal material for a microwave cooking utensil
is transparent to microwaves as it allows energy
to pass through the container and heat the food.
 Microwaves CANNOT penetrate metal, so metal
utensils or dishes with a metallic trim must not
be used. Use of metal utensils will damage the
microwave oven.
 Do not use recycled paper products when
microwave cooking, as they may contain small
metal fragments which may cause sparks and/or
res.
 Round/oval dishes rather than square/oblong
ones are recommended, as food in corners tends
to overcook.
The list below is a general guide to help you select
the correct utensils.
Cookware Microwave Cooking
Heat-Resistant Glass Yes
Non Heat-Resistant Glass No
Heat-Resistant Ceramics Yes
Microwave-Safe Plastic Dish Yes
Kitchen Paper Yes
Metal Tray No
Metal Rack No
Aluminium Foil
& Foil Containers No
Control Panel
Special Features
 Auto Reminder
 Minute Timer
 Child Lock
Features
 Numeral Pads
 Weight Defrost
 Jet Defrost
 Power
 Express
 Time
 Pre-Set
 Clock
 Memory
 Cancel
 Start



PROGRAM COMBINATION
PRE-SET
JET DEFROST WEIGHT DEFROST
1ST STAGE: TIME & POWER LEVEL COOKING
2ND STAGE: TIME & POWER LEVEL COOKING

8
Pre-set
Use to set the oven to start-up at a later time. The
pre-set indicator will icker when the oven is in the
PRE-SET State. The clock must be set before the
pre-set function can be programmed.
Understanding the Oven
Controls
Jet Defrost
 Use to defrost foods by time.
 This cycle starts at medium-high power, then
automatically reduces to medium-low power and
then to low power as the food thaws.
 Use numbers when setting time, power level, etc.
 JET DEFROST indicator light and cooking
indicator light will both turn on during the
defrosting cycle.
Weight Defrost
 Use to defrost frozen meat, poultry and seafood
by weight. The defrosting time and power level
are automatically set once the food category and
the weight are programmed.
Note: The maximum allowable weight for each
category is shown below.
 For foods exceeding these maximum weights,
use the JET DEFROST program. If you program
weight in excess of the maximum recommended,
the oven will not operate properly.
Express
 Use this feature to program the oven for 4
popular microwave timings. With each touch of
the EXPRESS pad you can program the oven for:
15 seconds …TOUCH ONCE
30 seconds …TOUCH TWICE
1 minute …TOUCH 3 TIMES
2 minutes …TOUCH 4 TIMES
 The oven will operate at HIGH power (100%
power output) for EXPRESS cooking program.
Defrost Food Maximum
Program Category Weight Display
1 Meat 2.3kg d1
2 Poultry 4.0kg d2
3 Seafood 0.9kg d3
Power % of Power Approx.
Level Outlet Wattage
0 Timer 0
1 10% 70
2 20% 140
3 30% 210
4 40% 280
5 50% 350
6 60% 420
7 70% 490
8 80% 560
9 90% 630
10 100% 700
Clock
 Use to set the time of day or recall the time of
day. The time of day will be displayed at all times
except when the oven is operating. In the event
of a power failure or if the oven is unplugged, the
clock will have to be reset.
Time
 Use to set cooking time. Allows you to set up to
99 minutes and 99 seconds.
Power
 Use to set the power level.
 This oven has 10 power levels. The power level
selections are from 10% to 100% of power
output. The oven will automatically cook at 100%
unless it is set for a lower power level. To check
power level during cooking, touch POWER pad,
the selected power level will show on the display
for 5 seconds. The oven will continue to operate
after 5 seconds and the remaining time will be
displayed.
The following table shows the percentage of power
output at each power level.

9
Setting the Clock
Suppose you want to enter the correct time of day
3:45 ( a.m. OR p.m.).
Step: 1. Touch CLOCK pad.
2. Touch CANCEL pad.
3. Touch numerical pads 3.4.5.
4. Touch CLOCK pad again to conrm.
Note: When the oven was plugged in, “1:01”
should have appeared on the display. To reset
the time of day, repeat the steps given above.
To check the time of day while the oven is
operating, touch the CLOCK pad, then the time
will be displayed for 5 seconds on the display.
Time and Power Level Cooking
Suppose you want to cook for 1 minute at 60%.
Step: 1. Touch TIME pad.
2. Touch numerical pads 1.0.0.
3. Touch power pad, then touch
numerical pad 6.
4. Touch START pad.
Note: Step 3 is not necessary for cooking at
100% power level.
Pre-set
Suppose you want to set the oven to start up at
2 o’clock.
Step: 1. Touch PRE-SET pad
2. Touch numerical pads 2.0.0
3. Set the cooking program you require
– for example you want it to cook
for 20 minutes at 80%
· Touch TIME pad
· Touch Numerical pads 2.0.0.0.
· Touch POWER pad, then touch
numerical pad 8
4. Touch START pad.
Note: Be sure the time of day clock is set at
the correct time before programming PRE-SET.
Memory
 When programming the oven to cook by time, use
the memory pad when setting both the 1st and
the 2nd cooking stage.
The respective lights will come on to indicate which
stage the oven is operating in.
Cancel
 Touch pad to cancel the selected power level,
cook or defrost times that were previously
programmed.
Start
 Touch to start the cooking or defrosting
programs.
The cooking indicator light and the oven light will turn
on and the cooling fan will operate.
Special Features
Auto Reminder
 After a cooking or defrosting program has
completed, the oven will automatically continue
to sound three beeps every two minutes until the
oven is opened or the CANCEL pad is touched.
Kitchen Timer
 Use as an all-purpose timer for general kitchen
activities (i.e. cooking, not using the microwave
oven). Three beeps will sound at the end of the
elapsed time. The oven light and cooling fan will
turn on while the time is counting down but there
are no microwaves present.
Electronic Child Lock
Use to prevent unsupervised operation of the oven
by children. The CHILD LOCK indicator light will be lit
on display and the oven cannot be operated while the
CHILD LOCK is set.
How To Use the Oven Controls
Each time a pad is touched, a beep will sound to
verify the touch.

10
Express
Suppose you want to set the oven to cook for 1
minute at 100% by using this feature.
Step: 1. Touch the EXPRESS pad 3 times then
“1.00” will appear on the display.
2. Touch START pad.
Jet Defrost
Suppose you want to set the oven to JET DEFROST
for ve minutes and 30 seconds.
Step: 1. Touch JET DEFROST pad.
2. Touch numerical pads 5.3.0.
3. Touch START pad.
Weight Defrost
Suppose you want to defrost 600gms of prawns.
Step: 1. Touch WEIGHT DEFROST pad 3 times.
“d3” will appear on the display
2. Touch numerical pads 6.0.0.
3. Touch START pad.
Note: During the defrosting process, there will
be two beeps to remind you to rearrange or
turn over the food.
Program Cooking
The oven has the ability to be programmed to do
several consecutive functions.
Remember
Always touch the cancel pad before programming.
Suppose you want to set the following program:
JET DEFROST – for 6 minutes & 45 seconds.
Ist Stage: TIME AND POWER -
10 minutes at 100%
2nd Stage: TIME AND POWER -
5 minutes at 50%
Set as follows –
1. Touch CANCEL pad.
2. Touch JET DEFROST pad, then touch
numerical pads 6.4.5.
3. Program 1st Stage – touch TIME pad and
touch numerical pads 1.0.0.0. Touch POWER
pad – because as you are cooking at 100%,
the display should already read 10. If cooking
at a different power level – use numerical pads
to adjust to the desired power level.
4. Touch MEMORY pad.
5. Program 2nd Stage – touch TIME pad and
then touch numerical pads 5.0.0. Touch
POWER pad and then touch numerical pad 5.
6. Touch START pad.
Note: JET DEFROST and WEIGHT DEFROST can
only be selected before the cooking stage in a
program. It cannot be selected between or after
stage 1 or stage 2.
Child Lock
To set the child lock.
Step: 1. Touch CANCEL PAD
2. Touch pads 5 and 7 at the same time.
A beep will sound and the child lock
indicator light will turn on.
To release Child Lock
Touch pads 5 and 7 at the same time. A beep will
sound and the child lock indicator light will go out.
Note: You cannot operate the oven while the
child lock is set.
Kitchen Timer
Step: 1. Touch TIME pad.
2. Use numerical pads to input
required time.
3. Touch POWER pad.
4. Touch numerical pad 0
5. Touch START pad.

11
Care and Cleaning
 Turn off the oven and remove the power plug
from the wall socket before cleaning.
 Keep the inside of the oven clean. When food
splatters or spilled liquids adhere to oven walls,
wipe with a damp cloth. Mild detergent may be
used if the oven gets very dirty. Avoid the use of
spray and other harsh cleaners as they may stain,
streak or dull the door surface.
 The oven door seal and adjacent parts should be
wiped clean with a soft damp cloth, and a mild
detergent if needed.
 The outside surfaces should be cleaned with a
damp cloth. To prevent damage to the operating
parts inside the oven, water should not be
allowed to seep into the ventilation openings.
 Wipe the window on both sides with a damp cloth
to remove any spills or splatters.
 Do not allow the control panel to become wet.
Clean with a soft, damp cloth. When cleaning the
control panel, leave door open to prevent oven
from accidentally turning on.
 If steam accumulates inside or around the outside
of the oven door, wipe with a soft cloth. This
may occur when the microwave oven is operated
under high humidity conditions. This is normal.
 It is occasionally necessary to remove the glass
tray for cleaning. Wash the tray in warm sudsy
water.
 The roller ring and the oven oor should be
cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the oven with
mild detergent. The roller ring may be washed in
warm, sudsy water. When removing the roller ring
from cavity oor for cleaning, be sure to replace
in the proper position.
 Remove odours from your oven by combining a
cup of water with the juice and skin of one lemon
in a deep microwave safe bowl, microwave for
5 minutes. Wipe thoroughly and dry with a soft
cloth.
Specications
Power Consumption
240V~ 50Hz, 1200W
Output
700W
Operation Frequency
2450MHz
Outside Dimensions
295mm(H) x 458mm(W) x 335mm(D)
Oven Cavity Dimensions
206mm(H) x 300(W) x 284mm(D)
Oven Capacity
17 Litres
Cooking Uniformity
Turntable System { 270mm}
Net Weight

Warranty
The benets conferred by this warranty are in
addition to all implied warranties, other rights
and remedies in respect of the product which the
consumer has under the Trade Practices Act and
similar State and Territory Laws.
The original purchaser of this Black & Decker product
is provided with the following warranty subject to the
following conditions.
Mistral International Pty Ltd warrant this product for
a period of 2 years from the date of purchase for
all parts defective in workmanship or materials. This
product or defective parts will be replaced free of
charge.
WARRANTY CONDITIONS
1. This warranty is only valid for appliances used
according to the manufacturer’s instructions.
2. This appliance must not be modied or changed
in any way.
3. Connection must be to the voltage requirements
as specied in the ratings label located on the
product.
4. The manufacturer does not accept liability for
any direct or consequential damage, loss or
other expense arising from misuse or incorrect
installation and operation of the appliance.
5. Warranty will only be given where proof of
purchase is provided, e.g. original invoice.
6. Not designed or warranted for industrial or
commercial use.
DO NOT SEND IN THIS WARRANTY
Fill out the following details and le with your
purchase invoice.
RETAIN & FILE WITH YOUR RECEIPT.
Your Purchase Receipt/Invoice is proof of date of
purchase. You must be able to present it at the place
of purchase to obtain a replacement or service under
warranty.
Mistral International Pty Ltd reserves the right to
discontinue items, modify designs and change
specications without incurring obligation. Whilst
every effort is made to ensure that descriptions,
specications and other information in this publication
is correct, no warranty is given in respect thereof
and the company shall not be liable for any errors
therein.
Purchased from:
Co. Name:
Address:
Date of Purchase:
Note: Consistent with our continuing product
development policy, improvements may have
been made which render the contents of this
package slightly different to that shown.
Cat. No. BMO700
September 2003
Product of Mistral International Pty Ltd ABN 25 006 680 315
324 Frankston-Dandenong Road
Dandenong South, Victoria, Australia 3175
Facsimile [phone]
Consumer Hotline: [phone]
RINGGRIP (NZ) Pty Ltd ACN 006 771 922
PO Box 33672, Takapuna, Auckland NZ
Telephone [phone] Facsimile 0800 328 238
Mistral is a registered trademark of Mistral International Pty. Ltd.
© 2003
is a trademark of Black & Decker Corporation, Towson, Maryland, USA
