Black & Decker BCE27 Installation instructions

Compact Refrigerator
Réfrigerateur Compact
Refrigerador Compacto
Please Read and Save this Use & Care Book
Por favor lea este instructivo antes de usar el producto
Veuillez lire et conserver ce guide d'entretien et d'utilisation
Models
Modelos
Modéles
❏ BCE27

1
English
GENERAL SAFETY RULES
WARNING: Read all of the instructions before using this appliance.
When using this appliance, always exercise basic
safety precautions, including the following:
NOTE: If the refrigerator has been placed in a horizontal or tilted
position for any period of time wait 24 hours before plugging the
unit in.
1) Use this appliance only for its intended purpose as described in this use
and care guide.
2) This refrigerator must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in
the installation section.
3) Never unplug your refrigerator by pulling on the power cord. Always
grasp the plug firmly and pull straight out from the outlet.
4) Repair or replace immediately, all electric service cords that have
become frayed or otherwise damaged. Do not use a cord that shows
cracks or abrasion damage along its length, the plug or the
connector end.
5) Unplug your refrigerator before cleaning or before making any repairs.
Note: If for any reason this product requires service, please call
customer service hotline at 1-866-927-4833.
6) Do not use any electrical device or any sharp instrument in defrosting
your refrigerator.
7) If your old refrigerator is not being used, we recommend that you
remove the doors and leave the shelves in place. This will reduce the
possibility of danger to children.
8) WARNING: After your refrigerator is in operation, do not touch
the cold surfaces in the freezer compartment, particularly when
hands are damp or wet. Skin may adhere to these extremely cold
surfaces.
9) Do not refreeze foods that have been thawed completely. The United
States Department of Agriculture in Home and Garden Bulletin No. 69
reads: “…You may safely refreeze frozen foods that have thawed if
they still contain ice crystals or if they are still cold-below 40˚F.
“…Thawed ground meats, poultry, or fish that have any off-odor or
off-color should not be refrozen and should not be eaten. Thawed ice
cream should be discarded. If the odor or color of any food is poor or
questionable, discard it. The food may be dangerous to eat.

2
English
Staple your receipt to your manual. You will need it to obtain
warranty service.
“…Even partial thawing and re-freezing reduce the eating quality of foods,
particularly fruits, vegetables, and prepared foods. The eating quality of
red meats is affected less than that of many other foods. Use refrozen
foods as soon as possible, to save as much of its eating quality as you
can.”
10) This refrigerator should not be recessed or built-in in an enclosed
cabinet. It is designed for freestanding installation only.
11) Do not operate your refrigerator in the presence of explosive fumes.
SAVE THESE INSTRUCTIONS
DANGER
Risk of child entrapment. Before you throw away your old
refrigerator or freezer, take off the doors. Leave the shelves
in place so that children may not easily climb inside.

3
English
1. Freezer Compartment
2. Ice Cube Tray
3. Drip Tray
4. Temperature Control
5. Full Width Shelves (2)
6. Leveling Legs (2)
7. Door Storage Shelf (2)
Parts And Features
1
3
4
5
6
7
2

4
English
1. Remove all packaging material. This includes the foam base and all
adhesive tape holding the refrigerator accessories inside and outside.
2. Inspect and remove any remains of packing, tape or printed materials
before powering on the refrigerator.
• Your refrigerator has two leveling legs which are located in the front
bottom corners of your refrigerator. After properly placing your
refrigerator in its final position, you can level your refrigerator.
• Leveling legs can be adjusted by turning them counterclockwise to
raise your refrigerator or by turning them clockwise to lower your
refrigerator. The refrigerator door will close easier when the leveling
legs are extended.
• To ensure your refrigerator works at the maximum efficiency it was
designed for, you should install it in a location where there is proper
air circulation, plumbing and electrical connections.
• The following are recommended clearances around the refrigerator:
Sides……………3/4" (19mm)
Top....................2" (50mm)
Back..................2" (50mm)
Installing Your Refrigerator
Unpacking Your Refrigerator
Proper Air Circulation
Leveling Your Refrigerator

5
English
• Make sure there is a suitable power outlet (115 volts, 15 amps outlet)
with proper grounding to power the refrigerator.
• Avoid the use of three prong adapters or cutting off the third
grounding prong in order to accommodate a two prong outlet. This is
a dangerous practice since it provides no effective grounding for the
refrigerator and may result in shock hazard.
• Avoid the use of an extension cord because of potential safety hazards
under certain conditions. If it is necessary to use an extension cord,
use only a 3-wire extension cord that has a 3-blade grounding plug
and a 3-slot outlet that will accept the plug. The marked rating of the
extension cord must be equal to or greater than the electrical rating of
the appliance. DO NOT USE EXTENSION CORD LONGER THAN
12 FT.
• Do not install your refrigerator in any location not properly insulated
or heated, e.g. garage, etc. Your refrigerator was not designed to
operate in temperature settings below 55˚ Fahrenheit.
• Select a suitable location for the refrigerator on a hard even surface
away from direct sunlight or heat source, e.g. radiators, baseboard
heaters, cooking appliances, etc. Any floor unevenness should be
corrected with the leveling legs located on the front bottom corners of
the refrigerator.
Electrical Requirement
Installation Limitations
Use of Extension Cords
WARNING: ELECTRICAL REQUIREMENT - SHOCK HAZARD
WARNING: USE OF EXTENSION CORDS- POTENTIAL SAFETY HAZARD
Door Alignment (see fig. # 1)
1. Remove hinge cover screw.
2. Remove the top hinge cover.
3. Loosen the top hinge screws using a Phillips head
screwdriver.
4. Adjust the door or put a spacer
in between and tighten the screws.
5. Replace the top hinge cover.
fig. 1

6
English
WARNING: USE OF EXTENSION CORDS- POTENTIAL SAFETY HAZARD
Reversing the Door Hinge
1. Remove the top hinge cover screw and then remove the top hinge cover.
(see fig. # 1)
2. Using a Phillips Head Screwdriver, loosen and remove the screws holding the top
hinge in place. (see fig. # 1)
3. Remove the top hinge and carefully lift off the door.
4. Remove the screw holes plugs and door plug from the opposite side and insert the
plugs in the screw holes openings of the just removed screws. (see fig. # 2)
5. Remove the door pin from the bracket of the lower hinge by turning counter
clockwise. Move the pin to the opposite hole and tighten. (see fig. # 3)
6. Loosen the screws holding the lower hinge bracket and remove the hinge.
(see fig. # 3)
7. Remove screws on opposite side of the cabinet and align the lower hinge bracket
with holes.
8. Align the bottom hole on the left side of the door with the pin of the lower hinge
and slide into place.
screw holes plugs
9. Align the pin of the top hinge with top hole on the left side of the door and push
into place. Replace the screws in the upper hinge bracket but do not tighten all the
way. (see fig. # 2)
10. Make sure the door closes easily but forms a tight seal. Adjust the door as
needed. Once you are satisfied with the door alignment, completely tighten
the upper door hinge screws.
11. Replace the hinge cover, insert the screw and tighten completely. (see fig. # 2)
12. If the door does not close properly, refer to the section titled “Door Alignment”.
door pin
lower hinge bracket
screws
fig. 2
fig. 3

7
English
Refrigerator Features And Use
To remove or replace a full-width slide-out shelf:
(see fig. # 2)
1. Gently tilt the shelf up and slide forward until the shelf has been
completely removed.
2. To replace the shelf, gently slide the shelf back.
General Features
Adjustable temperature dial:
Your refrigerator will automatically maintain the temperature level you select. The
temperature control dial has 5 settings plus 0. 1 is the warmest. 5 is the coldest. At
first, set the dial to 3 and allow 24 hours to pass before adjusting the temperature to
your needs.
(Note: If the refrigerator has been placed in a horizontal or
tilted position for any period of time wait 24 hours before
plugging the unit in.)
Refrigerator Interior Shelves
This compartment is designed for making ice cubes and for short-term food
storage (a few days at most).
WARNING: This compartment is not cold enough to freeze foods safely for
more than 5 days.
• If ice cube tray freezes to the bottom of the compartment, pour a little
warm water around it to loosen it. Do not use boiling water, which
can damage plastic parts, or sharp metal objects such as a knife or
screwdriver, which can damage the cooling system tubing. Wash the ice
cube tray in lukewarm water only. Do not wash in the dishwasher.
Freezer Compartment / Use of the Ice Cube Trays
fig. 2

8
English
Fresh Food
• When storing fresh food that is not prepackaged, be sure to wrap or store
food in airtight and moisture proof material unless otherwise noted. This
will ensure proper shelf life and prevent the transfer of odors and tastes.
• Wipe containers before storing to avoid needless spills.
• Eggs should be stored in an upright position in their original carton to
maximize shelf life.
• Fruit should be washed and dried, then stored in sealed plastic bags
before storing in the refrigerator.
• Vegetables with skins should be stored in plastic bags or containers.
• Leafy vegetables should be washed and drained and then stored in
plastic bags or containers.
• Hot food should be allowed to cool before storing in the refrigeration.
This will prevent unnecessary energy use.
• Fresh seafood should be used the same day as purchased.
• When storing meats in the fresh food section, keep in the original
packaging or rewrap as necessary. Follow the suggestions below for safe
storage:
• Chicken 1-2 Days
• Ground Beef 1-2 Days
• Cold Cuts 3-5 Days
• Steaks/Roasts 3-5 Days
• Smoked/Cured Meats 7-10 Days
For detailed storage chart visit FDA website:
www.cfsan.fda.gov/~dms/fttstore.html
Food Storage Information

9
English
Normal Operating Sounds You May Hear
• Boiling water, gurgling sounds or slight vibrations that are the result of
the refrigerant circulating through the cooling coils.
• The thermostat control will click when it cycles on and off.
WARNING: To avoid electric shock, always unplug your
refrigerator before cleaning. Ignoring this warning may result
in death or injury.
CAUTION: Before using cleaning products, always read and follow
manufacturer’s instructions and warnings to avoid personal
injury or product damage.
General: Prepare a cleaning solution of 3-4 tablespoons of baking
soda mixed with warm water. Use sponge or soft cloth,
dampened with the cleaning solution, to wipe down your
refrigerator.
• Rinse with clean warm water and dry with a soft cloth.
• Do not use harsh chemicals, abrasives, ammonia, chlorine
bleach, concentrated detergents, solvents or metal scouring
pads. Some of these chemicals may dissolve, damage and/
or discolor your refrigerator.
Door Gaskets: Clean door gaskets every three months according to general
instructions. Gaskets must be kept clean and pliable to assure
a proper seal
• Petroleum jelly applied lightly on the hinge side of gaskets
will keep the gasket pliable and ensure a good seal.
Proper Refrigerator Care and
Cleaning
Cleaning and Maintenance

10
English
Defrosting
Defrost whenever frost on the wall of the freezer compartment becomes
1/8" thick. Never us a sharp or metallic instrument to remove frost as it
may damage the cooling coils. (A punctured cooling coil will cause serious
damage to the product and will void the warranty). We recommend using a
plastic scraper. To defrost, remove foods and ice cube tray from the freezer
compartment. Make sure the drip tray is in place and unplug the unit.
Defrosting usually takes a few hours. To defrost faster, keep the door open
and place a bowl of warm water in the refrigerator. After defrosting, empty
water from the drip tray and wash the drip tray in warm water.
WARNING: IF OUTAGE IS FOR A PROLONGED PERIOD, INSPECT
AND DISCARD SPOILED OR THAWED FOOD IN
FREEZER AND REFRIGERATOR. CLEAN REFRIGERATOR
BEFORE REUSING.
Power Interruptions
• Occasionally there may be power interruptions due to thunderstorms
or other causes. Remove the power cord from AC outlet when a power
outage occurs. When power has been restored, replug power cord
to AC outlet. If outage is for a prolonged period, inspect and discard
spoiled or thawed food in freezer and refrigerator. Clean refrigerator
before reusing.

11
English
Vacation and Moving Care
• For long vacations or absences, empty food from refrigerator and
freezer, move the temperature dial to the OFF position and clean
the refrigerator and door gaskets according to "General Cleaning"
section. Prop doors open, so air can circulate inside.When moving,
always move the refrigerator vertically. Do not move with the unit
lying down. Possible damage to the sealed system could occur.
Energy Saving Tips
• The refrigerater should be located in the coolest area of the room,
away from heat-producing appliances or heating ducts, and out of
direct sunlight.
• Let hot foods cool to room temperature before placing in the
refrigerator. Overloading the refrigerator forces the compressor to run
longer and thus increases energy consumption. Foods that refrigerate
too slowly may lose quality or spoil.
• Be sure to wrap foods properly, and wipe containers dry before
placing in the refrigerator.
• The wire shelves should not be lined with aluminum foil, wax paper,
or paper towels. Liners interfere with cold air circulation, making the
refrigerator less efficient.
• Organize food to reduce door openings and extended searches.
Remove as many items as needed at one time, and close the door as
soon as possible.

Refrigerator does not operate:
• Check if thermostat control is not in the “0” position.
• Check if refrigerator is plugged in.
• Check if there is power at the AC outlet, by checking the circuit breaker.
Food temperature appears too warm:
• Frequent door openings.
• Allow time for recently added warm food to reach fresh food temperature.
• Check gaskets for proper seal.
• Adjust temperature control to colder setting.
Food temperature is too cold:
• If temperature control setting is too cold, adjust to a warmer setting and allow
several hours for temperature to adjust.
Refrigerator runs too frequently:
• This may be normal to maintain constant temperature during high temperature
and humid days.
• Doors may have been opened frequently or for an extended period of time.
• Check gasket for proper seal.
• Check to see if doors are completely closed.
Moisture build up on interior or exterior
of the refrigerator:
• This is normal during high humidity periods.
• Prolonged or frequent door openings.
• Check door gaskets for proper seal.
Refrigerator has an odor:
• Interior needs cleaning.
• Foods improperly wrapped or sealed are giving off odors.
Refrigerator door does not shut properly:
• Level the refrigerator.
• Re-align refrigerator door.
• Check for blockages, e.g. food containers, crisper cover,shelves, bins, etc.
Popping or cracking sound when the compressor
comes on:
• Check to ensure the refrigerator is level.
• The floor may be uneven or weak. The refrigerator rocks on the floor when it is
moved slightly. Be sure the floor can adequately support the refrigerator. Level
the refrigerator by putting wood or metal shims under part of the refrigerator.
• The refrigerator is touching the wall. re-level the refrigerator and move it from
the wall. See the “Installing Your Refrigerator” section.
Troubleshooting
12
English

13
Limited Warranty
English
What is covered and for how long?
This warranty covers all defects in
workmanship or materials for a period of:
1 year parts (carry in only)
1 year labor (carry in only)
5 years sealed system
(carry in only)
The warranty commences on the date
the item was purchased and the original
purchase receipt must be presented to the
authorized service center before warranty
repairs are rendered.
EXCEPTION: Commercial or Rental
Use Warranty
90 days labor (carry-in only)
90 days parts
No other warranty applies
What is covered.
1. The mechanical and electrical parts,
which serve as a functional, purpose of
this appliance for a period of 1 year.
This includes all parts except finish, and
trim.
2. The components of the sealed system
e.g. hermetic compressor, condenser
and evaporator from manufacturing
defects for a period of 5 years from the
date of purchase. Any damages to such
components caused by mechanical abuse
or improper handling or shipping will not
be covered.
What will be done?
1. We will repair or replace, at our
discretion any mechanical or electrical
part which proves to be defective in
normal usage during the warranty period
so specified.
2. There will be no charge to the
purchaser for parts and labor on any
covered items during the initial 1 year
period. Beyond this period only parts are
covered in the remaining warranty. Labor
is not provided and must be paid by
the customer.
3. Contact customer service:
1-866-927-4833.
THIS WARRANTY COVERS
APPLIANCES WITHIN THE
CONTINENTAL UNITED STATES,
PUERTO RICO AND CANADA.
IT DOES NOT COVER
THE FOLLOWING:
Damages from improper installation.
Damages in shipping.
Defects other than manufacturing.
Damage from misuse, abuse, accident,
alteration, lack of proper care and
maintenance or incorrect current or
voltage.
Damage from other than household use.
Damage from service by other than an
authorized dealer or service center.
Decorative trims or replaceable
light bulbs.
Transportation and shipping.
Labor (after the initial 1 year).
THIS LIMITED WARRANTY IS GIVEN
IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE
The remedy provided in this warranty is
exclusive and is granted in lieu of all other
remedies.
This warranty does not cover incidental
or consequential damages, so the above
limitations may not apply to you. Some
States do not allow limitations on how long
an implied warranty lasts, so the above
limitations may not apply to you.
This warranty gives you specific legal rights,
and you may have other rights, which vary,
from state to state.
New York, NY 10018

14
Francais
ATTENTION: Lire l’ensemble des instructions avant d’utiliser
l’appareil. Lors de l’utilisation de cet appareil,
prendre toutes les mesures de sécurité de base, y
compris les suivantes:
REMARQUE: Si le réfrigérateur a été placé en position horizontale ou
en position inclinée, que ce soit pour longtemps ou non,
attendez 24 heures avant de brancher l’appareil.
1) N’utiliser cet appareil que pour l’usage pour lequel il est prévu,
tel qu’il est indiqué dans le guide d’utilisation et d’entretien.
2) Ce réfrigérateur doit être correctement installé conformément aux
instructions d’installation avant d’être utilisé. Consulter les instructions
de mise à la terre du chapitre Installation.
3) Ne jamais tirer sur le cordon d’alimentation pour débrancher le
réfrigérateur. Toujours saisir fermement la fiche et la retirer
complètement de la prise.
4) Réparer ou remplacer immédiatement tout cordon électrique effiloché ou
endommagé d’une quelconque manière. Ne pas utiliser un cordon fissuré,
abrasé ou dont la prise ou le connecteur est endommagé.
5) Débrancher le réfrigérateur avant de le nettoyer ou d’effectuer des
réparations. Remarque: Si pour une raison quelconque ce produit a
besoin de maintenance, veuillez appeler la ligne sans frais du Service
Clients au 1-866-927-4833.
6) Ne pas utiliser d’appareils électriques ou d’objets pointus pour dégivrer le
réfrigérateur.
7) Si vous n’avez plus l’usage de votre ancien réfrigérateur, nous vous
conseillons d’en retirer les portes. Ceci permet d’éviter tout danger
potentiel pour les enfants.
8) ATTENTION: Une fois le réfrigérateur en fonctionnement, ne pas
toucher les surfaces froides du compartiment de congélation, en
particulier avec des mains mouillées ou humides. La peau risquerait
d’adhérer à ces surfaces extrêmement froides.
9) Ne pas recongeler les aliments qui ont été complètement décongelés. Le
bulletin Maisons et Jardins du Ministère de l’Agriculture des États-Unis n°
69 stipule que: « ...Les aliments congelés peuvent être recongelés en toute
sécurité s’ils contiennent toujours des cristaux de glace ou si leur
température reste inférieure à 4,5°C. »
CONSIGNES GÉNÉRALES DE SECURITÉ

Francais
15
« …Les viandes hachées, la volaille et le poisson présentant une odeur
désagréable ou une couleur suspecte ne doivent ni être recongelés, ni être
consommés. La crème glacée dégelée doit être jetée. Tout aliment
présentant une odeur ou couleur douteuse doit être jeté. L’ingestion d’un
aliment de ce type peut s’avérer dangereuse. »
« …La décongélation ou la recongélation, même partielle, fait diminuer les
qualités gustatives des aliments, en particulier des fruits, légumes et plats
préparés. La qualité gustative des viandes rouges est affectée à un bien moindre
degré que celle de nombreux autres aliments. Utiliser les aliments recongelés dès
que possible, afin de conserver la majeure partie de leurs qualités gustatives. »
10) Ce réfrigérateur ne doit être ni encastré, ni enclos dans un placard. Il a été conçu
pour être installé tel qu’il se présente.
11) Ne pas faire marcher le congélateur en présence de fumées pouvant entraîner
une explosion.
VEUILLEZ CONSERVER CES
INSTRUCTIONS
DANGER
Les enfants pourraient se retrouver coincés dans votre
réfrigérateur ou congélateur usagé avant que vous ne
puissiez vous en débarrasser. Retirer les portes. Laisser les
étagères en place de manière à ce que les enfants ne
puissent pas grimper facilement à l’intérieur.
Agrafer le ticket de caisse au guide. Il devra être présenté pour
tout service après-vente sous garantie.

Francais
16
1. Compartiment congélateur
2. Tiroir à glace
3. Bac de récupération
4. Réglage de la température
5. Clayettes larges (2)
6. Mise à niveau des jambes (2)
7. Compartiments de la porte (2)
Piéces et Caractéristiques
1
3
4
5
6
7
2

Francais
17
1. Retirer l’ensemble du matériel d’emballage. Ceci comprend la base
en mousse ainsi que l’ensemble du matériel adhésif qui maintient les
accessoires du réfrigérateur à l’intérieur tout comme à l’extérieur.
2. Inspecter et enlever tout restant d’emballage, de scotch ou de
matériaux imprimés avant de brancher le réfrigérateur.
• Le réfrigérateur possède deux pieds de mise à niveau qui sont situés
sur les coins avant du réfrigérateur. Après avoir convenablement
installé le réfrigérateur à la place qu’il occupera, procéder à la mise
à niveau.
• Pour régler les pieds de mise à niveau, les tourner dans le sens des
aiguilles d’une montre afin de surélever le réfrigérateur et dans le
sens inverse des aiguilles d’une montre pour l’abaisser. La porte du
réfrigérateur se ferme plus facilement lorsque les pieds de mise à
niveau sont surélevés.
• Pour être sûr que le réfrigérateur fonctionne à son maximum
d’efficacité, l’installer dans un environnement favorable à une
bonne circulation d’air et possédant des connexions de plomberie et
d’électricité saines.
• Les indications suivantes concernent l’espace recommandé autour du
réfrigérateur:
Latéralement...................19mm (3/4")
Partie supérieure.............50mm (2")
Arrière...........................50 mm (2")
Installation du Réfrigérateur
Désemballage du Réfrigérateur
Mise á Niveau du Réfrigérateur
Circulation d’Air Adéquate

Francais
18
• Pour l’alimentation du réfrigérateur, veiller à utiliser une prise
de courant convenable (prise de 115 volts,15 amp) raccordée à
la terre.
• Eviter d’utiliser des adaptateurs à trois fiches ou de sectionner la
troisième fiche reliée à la terre dans le but d’utiliser un branchement
à deux fiches. Cette pratique pourrait s’avérer dangereuse dans la
mesure où le réfrigérateur n’est pas relié convenablement à la terre,
et risquerait de causer des risques d’électrocution.
• Éviter d’utiliser une rallonge électrique car, dans certains cas, cela
peut entraîner des risques pour la santé. S’il est nécessaire d’utiliser
une rallonge, utiliser uniquement une rallonge possédant une fiche
male à deux broches plus terre à une extrémité et une prise femelle
de même type à l’autre extrémité. La capacité électrique de la
rallonge doit être égale ou supérieure à la capacité de l’appareil.
N’UTILISEZ PAS DE RALLONGES D’UNE LONGUEUR
SUPÉRIEURE À 12 PIEDS/3,65 MÈTRES.
• Ne pas installer le réfrigérateur dans un endroit qui n’est pas
convenablement isolé ou chauffé; comme par exemple un garage,
etc. Le réfrigérateur n’est pas conçu pour fonctionner à des
températures inférieures à 12°C.
• Choisir un endroit convenable et placer le réfrigérateur sur une
surface solide et plane, loin de sources de chaleur telles que: les
radiateurs, les éléments chauffants à plinthes, les cuisinières, etc.
Toute irrégularité au sol doit être corrigée à l’aide des pieds de mise
à niveau situés sur les coins avant de la partie inférieure
du réfrigérateur.
Limitations relatives à l’Installation
ATTENTION: EXIGENCES ÉLECTRIQUES – RISQUE DE
CHOC ÉLECTRIQUE
Caractéristiques Electriques
Utilisation de Rallonges
ATTENTION: UTILISATION DE RALLONGES – RISQUE DE
DANGER POTENTIEL

Francais
19
Alignement de la porte (Voir figure 1)
1. Retirez la vis du cache-charnière
2. Retirez le cache-charnière supérieur.
3. Desserrez les vis de la charnière supérieure
à l’aide d’un tournevis Phillips.
4. Ajustez la porte ou placez
un espaceur entre les deux
et serrez les vis.
5. Replacez le cache-charnière
supérieur.
Charnière de la porte réversible
(Orientation de l’ouverture de la porte changeable)
1. Retirez la vis du cache-charnière supérieure et retirez ensuite le cache-charnière
supérieure. (voir fig. 1)
2. À l’aide d’un tournevis à tête plate Phillips desserrez et retirez les vis d’attache de
la charnière supérieure en les tournant dans le sens contraire des aiguilles d’une
montre. (voir fig. 1)
3. Retirez la charnière supérieure et soulevez doucement la porte.
4. Retirez les chevilles de trous de vis et la cheville de la porte du côté opposé et
insérez les chevilles dans les ouvertures des trous des vis des vis que vous venez
juste de retirer. (voir fig. 2)
5. Retirez la goupille de la porte de la charnière inferieure en la tournant dans le sens
inverse des aiguilles d’une montre. Déplacez la goupille au trou du côté opposé et
serrez-la. (voir fig. 3)
6. Desserrez les vis d’attache du support de la charnière inférieure et retirez la
charnière. (voir fig.3)
7. Retirez les vis du côté opposé de la carrosserie et alignez le support de la
charnière inférieure avec les trous.
8. Alignez le trou au bas du côté gauche de la porte avec le support inférieur de la
goupille de la porte et poussez délicatement et fermement la porte en place.
screw holes plugs
fig. 2
fig. 1
