Frigidaire FRS26ZSG User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRS26ZSGB3 FRS26ZSG Gallery Pro stainless/black 115
FRS26ZSGB4 FRS26ZSG Gallery Pro stainless/black 115
FRS26ZSGW3 FRS26ZSG Gallery Pro stainless/white 115
FRS26ZSGW4 FRS26ZSG Gallery Pro stainless/white 115
MARKET
North American
Publication No.
5995318705
990226
-EN/SERVICE/KB
357
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZSG
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
SIDE BY SIDE
REFRIGERATOR
WIRING DIAGRAM - # 218875901
OWNER’S GUIDE - # 218854500
SERVICE DATA SHEET - # 218902000
101 Masters Blvd.
Anderson, SC 29624

02/99 2
Publication No. FRS26ZSG
5995318705
FREEZER DOOR

# = Fast-moving Parts 3 02/99
* = Non-Illustrated Parts
FRS26ZSG Publication No.
5995318705
FREEZER DOOR
A = FRS26ZSG (FRS26ZSGB3)
B = FRS26ZSG (FRS26ZSGB4)
C = FRS26ZSG (FRS26ZSGW3)
D = FRS26ZSG (FRS26ZSGW4)
POS. NO PART NO DESCRIPTION
1# 215734323 A B - - Gasket-frzr door,black ,magnetic
1# 215734313 - - C D Gasket-frzr door,white ,magnetic
6 5303323484 A B C D Support-door rack,white ,LH
6A 5303323485 A B C D Support-door rack,white ,RH
8A 215474039 A B C D Rack-door
9 218470101 A B C D Panel-inner door,frzr
11 218631500 A B C D Panel-frzr door, stainless steel, w/foam insulatn
13 5303289522 A B C D Door Stop
18 218756501 A B C D Handle-door, stainless steel, with insert
21 218709100 A B C D Screw-handle mtg,hex head ,10-32 x 1/2
21A 218578600 A B C D Screw-door stop mtg, phl truss hd, 10-16 x 3/4
22A 215615300 A B C D Bushing-door,bronze
23 5303001020 A B C D Screw,cr flat head ,8-32D x 1/2
47 218850101 A - C - Harness-wiring,frzr door
47 218896201 - B - D Harness-wiring,frzr door
49 218592301 A B C D Bin-door,"Mongo"
58 218781100 A B C D Screw,pan head ,#8-18 x 5/8
68 218495200 A B C D Chute-ice
140 218518700 A B C D Elbow-water tube
* 215598900 A B C D Washer-flat, .691x1x.05, zinc, I&W hinge brkt
* 218490900 A B C D Cleaner,stainless steel
* 218789501 A B C D Heater-lower flange
* 5303917276 A B C D Insulation-door,fiberglass ,(bulk)

02/99 4
Publication No. FRS26ZSG
5995318705
REFRIGERATOR DOOR
P58R0054
2
3
49
7
58
15
12
22
26
21A
13
70
75
18
21
27
76
77
27A

# = Fast-moving Parts 5 02/99
* = Non-Illustrated Parts
FRS26ZSG Publication No.
5995318705
A = FRS26ZSG (FRS26ZSGB3)
B = FRS26ZSG (FRS26ZSGB4)
C = FRS26ZSG (FRS26ZSGW3)
D = FRS26ZSG (FRS26ZSGW4)
POS. NO PART NO DESCRIPTION
2 # 215734324 A B - - Gasket-refr door,black ,magnetic
2 # 215734314 - - C D Gasket-refr door,white ,magnetic
3 215434301 A B C D Panel-inner door,refr
7 218383101 A B C D Door-dairy
12 218395401 A B - - Nameplate,black
12 218395402 - - C D Nameplate,white
13 5303289522 A B C D Door Stop
15 218631600 A B C D Panel-refr door, stain/ steel, w/foam insulatn
18 218756501 A B C D Handle-door, stainless steel, with insert
21 218709100 A B C D Screw-handle mtg,hex head ,10-32 x 1/2
21A 218578600 A B C D Screw-door stop mtg, phl truss hd, 10-16 x 3/4
22 5303289320 A B C D Bearing-hinge
26 3204522 A B C D Container-egg
27 218370101 A B C D Snugger-door bin, "paddle type", gal. door bin
27A 218714201 A B C D Retainer,tall bottle
49 218592303 A B C D Bin-door,"Mongo"
58 218781100 A B C D Screw,pan head ,#8-18 x 5/8
70 218836302 A B C D Housing-dairy compt
75 218716300 A B C D Bumper-dairy door
76 218423600 A B C D Rack-microwave dish
77 218423501 A B C D Dish-microwave,(2)
* 218490900 A B C D Cleaner,stainless steel
* 5303917276 A B C D Insulation-door,fiberglass ,(bulk)
REFRIGERATOR DOOR

02/99 6
Publication No. FRS26ZSG
5995318705
CABINET

# = Fast-moving Parts 7 02/99
* = Non-Illustrated Parts
FRS26ZSG Publication No.
5995318705
A = FRS26ZSG (FRS26ZSGB3)
B = FRS26ZSG (FRS26ZSGB4)
C = FRS26ZSG (FRS26ZSGW3)
D = FRS26ZSG (FRS26ZSGW4)
POS. NO PART NO DESCRIPTION
10 215637602 A B C D Cover-air duct
10* 5308009617 A B C D Washer,ext tooth lock ,#10
10A 215637401 A B C D Cover-evap coil,lower
11 5303208309 A B C D Plug-hole,factory test
12 215230400 A B C D Plug-harness hole
15A 218708700 A B C D Light Bulb/Lamp,crisper light ,(2)
16A 5303299157 A B C D Socket-light/lamp,crisper light
18 5303289043 A B C D Support-air duct cvr,2.55" long
18* 5303289044 A B C D Support-air duct cvr,1.83" long
28 5303289062 A B C D Bolt-roller adj,hex head ,5/16-24 x 7/8
29 215598900 A B C D Washer-flat, .691x1x.05, zinc, I&W hinge brkt
29* 215314301 A B C D Washer,.40 x .75 x .06 ,nylon
29* 218871201 A B C D Washer,nylon ,0.363 ID w/nibs
30 215008900 A B C D Bracket-lower hinge,w/hinge pin
30* 218730800 A B C D Tapping Plate,RH
30A 215009100 A B C D Bracket-lower hinge,LH ,w/hinge pin
30A* 218730700 A B C D Tapping Plate,LH
37 5303321083 A B - - Trim-cabinet corner,black
37 5303321081 - - C D Trim-cabinet corner,white
38 218215218 A B - - Bracket-upper hinge, with closer, black, LH
38 218215220 A B - - Bracket-upper hinge, with closer, black, RH
38 218215217 - - C D Bracket-upper hinge, with closer, white, LH
38 218215219 - - C D Bracket-upper hinge, with closer, white, RH
40 5303323268 A B - - Cover-upper hinge,black
40 5303318773 - - C D Cover-upper hinge,white
43 218615300 A B C D Roller Assy,front ,(2)
43* 5308017044 A B C D Screw-roller mtg, spcl ind hex hd,
44 218738300 A B C D Roller Assy,rear ,(2)
47 218659500 A B C D Channel-shelf mtg,side ,(2)
52 215454600 A B C D Tube-water inlet
58 5308002748 A B C D Screw, hex wshr hd, 8-15A x 0.500, special
66 215050201 A B C D Damper-meat keeper
66A 218171301 A B C D Cover-meat kpr dmpr
71 218515401 A B C D Clip-grille
72 218359609 A B - - Grille/Kickplate,black
72 218359601 - - C D Grille/Kickplate,white
77 5303001216 A B C D Washer-nylon,3/16 x 5/8 OD
78 5303274237 A B C D Screw-bracket, hex wshr hd, 8-32CA x 0.500
80 218249802 A B C D Seal-coil cover,(2)
80* 5303289036 A B C D Gasket-coil cover,(2)
80* 5303289037 A B C D Gasket-air duct cvr,(2)
81 5308016566 A B C D Screw, hex wshr hd, 8-15A x 0.625, low profile
85 218359806 A B - - Cover-lower hinge,black
85 218359802 - - C D Cover-lower hinge,white
89 218871501 A B C D Cover-machine compt
90 215022602 A B C D Seal-foam
90* 5303322647 A B C D Tape-foam
91 218770000 A B C D Deflector-air,air duct cover
92 5303001479 A B C D Screw-hinge mtg, hex hd, 1/4-20 x 0.875, (6)
100 5303288973 A B C D Support-pan cover
101 215305702 A B C D Seal-foam
101* 218663102 A - C - Gasket-air duct/liner
101* 218663103 - B - D Gasket-air duct cvr
107 218835901 A B C D Shield-light,crisper
108 218834202 A B C D Cover-wiring,crisper light
* 218902101 - B - D Cap-protector, lower hinge
* 5303001038 A B C D Washer,.28 x .62 x .19 ,nylon
* 5303305345 A B - - Paint,touch-up ,black
* 5303305324 - - C D Paint,touch-up ,white
* 5308016571 A B C D Plug-button, cabinet liner, icemaker holes
CABINET

02/99 8
Publication No. FRS26ZSG
5995318705
SHELVES

# = Fast-moving Parts 9 02/99
* = Non-Illustrated Parts
FRS26ZSG Publication No.
5995318705
A = FRS26ZSG (FRS26ZSGB3)
B = FRS26ZSG (FRS26ZSGB4)
C = FRS26ZSG (FRS26ZSGW3)
D = FRS26ZSG (FRS26ZSGW4)
POS. NO PART NO DESCRIPTION
2 218383601 A B C D Handle-frzr basket
11 218298003 A B C D Shelf-freezer,sliding ,wire
11A 218298004 A B C D Shelf-freezer,sliding ,wire
11C 218815501 A B C D Shelf-pizza,24B
24 215029002 A B C D Shelf-"Spill-Safe",cantilever ,sliding
24* 215019701 A B C D Frame-cantilever,spill-safe shlf
24* 215036602 A B C D Shelf-"Spill-Safe", sliding, included w/#24
24A 218636601 A B C D Shelf-"Spill-Safe", split, flip/slide, includes #110
25 218147701 A B C D Cover-storage pan
25A 5303307878 A B C D Trim-storage pan cvr, upper, w/humidity hole
25A* 5303307881 A B C D Control-humidity
25B 5303289586 A B C D Trim-storage pan cvr,lower
26 5303289500 A B C D Pan-storage,upper
26A 5303289501 A B C D Pan-storage,lower
39 215217543 A B C D Trim-frzr shelf
42 215002301 A B C D Hanger-pan/tray,LH
42* 215002401 A B C D Hanger-pan/tray,RH
46 218278201 A B C D Front-storage pan,upper
46A 218278202 A B C D Front-storage pan,lower
47 215723574 A B C D Insert-pan cover, glass, clear, w/teal graphics
47A 5303289387 A B C D Insert-pan cover,glass ,clear
49 218384701 A B C D Basket-sliding,(3)
51 5303296575 A B C D Hanger-basket,RH
51A 5303307887 A B C D Hanger-basket,RH
52 215162504 A B C D Hanger-basket,LH ,with spring
52A 215162502 A B C D Hanger-basket,LH,with spring
52A* 5303299662 A B C D Hanger-basket,LH
57 5303271653 A B C D Ferrule-inner
62 218285701 A B C D Tray-deli
66 5304402116 A B C D Rack-wine
67 218278501 A B C D Front-deli tray
81 5308016566 A B C D Screw, hex wshr hd, 8-15A x 0.625, low profile
96 215192600 A B C D Support-water tank
97 218871301 A B C D Water Tank
101 215005000 A B C D Screw, hex wshr hd, 8-18AB x 0.750, gusset/hanger
110 218641901 A B C D Shelf-"Spill-Safe",flip-up
123 215005100 A B C D Screw-roller/hanger,8-10 x .438
126 218867401 A B C D Channel,auger mtg ,LH
126 218867402 A B C D Channel,auger mtg ,RH
129 5303299152 A B C D Roller-hanger
129* 5303299153 A B C D Bearing-roller
* 215328300 A B C D Clip-shelf
* 5303001038 A B C D Washer,.28 x .62 x .19 ,nylon
SHELVES

02/99 10
Publication No. FRS26ZSG
5995318705
CONTROLS

# = Fast-moving Parts 11 02/99
* = Non-Illustrated Parts
FRS26ZSG Publication No.
5995318705
A = FRS26ZSG (FRS26ZSGB3)
B = FRS26ZSG (FRS26ZSGB4)
C = FRS26ZSG (FRS26ZSGW3)
D = FRS26ZSG (FRS26ZSGW4)
POS. NO PART NO DESCRIPTION
2 5303307883 A B C D Knob-damper control,white/teal line
5 # 5308000010 A B C D Fan Blade,red
7 5308000124 A B C D Ring-fan orifice
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303205118 A B C D Bracket-motor mtg,front
12 215809600 A B C D Diffuser-air
13 # 215426200 A B C D Motor-evap fan
13* 215474201 A B C D Washer,"slinger" ,nylon ,evap fan shaft
14 5303205119 A B C D Bracket-motor mtg,rear
15 5303001179 A B C D Light Bulb/Lamp,40 W
16 5303289050 A B C D Socket-light/lamp
17 5304410657 A B C D Control Box
17A 5303296581 A B C D Control Box,frzr
18 5303307882 A B C D Knob-temp control
20 5303307884 A B C D Label-control box,refr
20A 5303307888 A B C D Label-control box,frzr
20A* 215188300 A B C D Screw-contr box mtg, hex head, 8-15A x 1.000,refr/frzr
21 # 5303300027 A B C D Control-temperature
22 5303319683 A B C D Housing-temp sensor,plastic
22* 218731102 A B C D Tube, insulator, PVC, white, on temp sensor
23 # 215846602 A B C D Timer-defrost
23* 215277000 A B C D Cover-defrost timer,top
23* 5303001259 A B C D Screw-timer mtg,pan hd ,6-20 x 0.438
23* 5303289058 A B C D Shield-defrost timr,btm
41 5308000039 A B C D Screw, hex wshr hd, 8-32CA x 0.500, serrated head
41* 5303209814 A B C D Nut,"U" type ,8-15(A) ,fan mtr mtg
53 215809508 A B C D Box-damper control
65 5303001361 A B C D Pin-mounting,push-in ,plastic
75 218465101 A B C D Shield-light,refr
76 218225800 A B C D Cover-light socket
78 5303274237 A B C D Screw-bracket, hex wshr hd, 8-32CA x 0.500
81 5308016566 A B C D Screw, hex wshr hd, 8-15A x 0.625, low profile
83 5308000107 A B C D Bracket-connector
111 5303297842 A B C D Wireway,frzr
112 215277102 A B C D Rod-damper extn
113 5303296580 A B C D Cover-dmpr rod ext
114# 5303289051 A B C D Switch-light/lamp,white
115 215011505 A B C D Damper Assy,w/seal
116 215011400 A B C D Seal-damper,foam
125 215334201 A B C D Switch-auger kill,white
137# 218710901 A B C D Filter-water, carbon, with o’rings, and wrench
* 218710300 A B C D • Wrench-filter
138 218657401 A B C D Cup-water filter
139 218657500 A B C D Housing-water filtr
140 218518700 A B C D Elbow-water tube
141# 218832401 A B C D Valve-water,dual solenoid ,115 V ,w/nut
142 218657701 A B C D Knob-indicator,filter replment
143 218696700 A B C D Heater-water filter
* # 218859701 A B C D Valve-water, single solenoid, 115 V, w/nut
* 218646000 A B C D Harness-wiring,filter heater
CONTROLS

02/99 12
Publication No. FRS26ZSG
5995318705
SYSTEM

# = Fast-moving Parts 13 02/99
* = Non-Illustrated Parts
FRS26ZSG Publication No.
5995318705
A = FRS26ZSG (FRS26ZSGB3)
B = FRS26ZSG (FRS26ZSGB4)
C = FRS26ZSG (FRS26ZSGW3)
D = FRS26ZSG (FRS26ZSGW4)
POS. NO PART NO DESCRIPTION
1 # 218787900 A B C D Condenser
1* 5303289026 A B C D Spacer-tube
2 5303289029 A B C D Clip-cond mtg,(4)
3 218679603 A B C D Block-evap coil,styrofoam ,(2)
4 # 218541000 A B C D Drier-filter
5 218646100 A B C D Harness-wiring,main
5* 215005200 A B C D Harness-wiring,refr controls
5* 218463600 A B C D Harness-wiring,crisper lights
5* 218646000 A B C D Harness-wiring,filter heater
5* 218815101 A B C D Harness-wiring,frzr controls
6 218872701 A - C - Harness-wiring,w/valve diodes
6 218896001 - B - D Harness-wiring,w/valve diodes
7 215459201 A B C D Cord-electric power
8 218803400 A B C D Cover-wiring
13 # 215006701 A B C D Heat Exchanger,suction line
14 # 218169802 A B C D Heater-defrost
15 # 218691301 A B C D Evaporator,R134a System
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 5303289496 A B C D Insulator-evap
19 218631200 A B C D Tube,rubber
21 # 5316269001 A B C D Thermostat-defrost
22 218811100 A B C D Base-compressor mtg,(drain pan)
23 218513300 A B C D Grommet-compr mtg,(4)
25 218773500 A B C D Screw-compressor mtg,hex washer head,10Bx11/4
29 # 218894802 A B C D Compressor,R134a ,w/o electricals
30 # 5304407494 A B C D Relay
31 # 5304407495 A B C D Overload Protector
33 218895701 A B C D Cover-terminal
41 218754500 A B C D Screw,hex hd ser wshr ,#8-18 x 3/8
43 5303001199 A B C D Clamp-wiring harness, strain relief, galv steel
43* 3051070 A B C D Screw 10-24 X 7/16, hex washer head, special
43* 215174700 A B C D Clamp-service cord, strain relief, galv steel
43* 5308000133 A B C D Clamp,nylon ,.75 OD tube
45 5300141713 A B C D Screw,hex wshr hd ,8-32 x .625 ,spec
45 5303001343 A B C D Screw,hex wshr hd ,8-15A x .5 ,spec
49 215506900 A B C D Bracket-evap mtg
54 5303289027 A B C D Rail-cabinet base,rear
54A 5303289311 A B C D Rail-compr support
54B 5303289292 A B C D Rail-cabinet base,front
55 # 218492303 A B C D Capacitor-run
55* 218897001 A B C D Screw,hex washer head ,8-32 x 1/4
56 218769300 A B C D Insert-compressor mtg
57 218247300 A B C D Clip-wiring harness
58 215004600 A B C D Screw-cond fan mtr, hx serr wshr hd, 8-36 x 7/16,(2)
59 5303289031 A B C D Shroud-cond fan mtr
60 # 215501901 A B C D Motor-condenser fan
61 5303289032 A B C D Blade-cond fan
61* 215004700 A B C D Nut,speed
61* 215004800 A B C D Grommet-silencer
62 215048701 A B C D Trough-drain, w/shield assy & #17 insulator
64 5303289063 A B C D Tube-drain
65 5303289301 A B C D Spacer-tube
70 5303289041 A B C D Bracket-evap/cvr mtg
81 5308016566 A B C D Screw, hex wshr hd, 8-15A x 0.625, low profile
* 5303917166 A B C D Hot Tube Repair Kit,Service
SYSTEM

02/99 14
Publication No. FRS26ZSG
5995318705
DISPENSER

# = Fast-moving Parts 15 02/99
* = Non-Illustrated Parts
FRS26ZSG Publication No.
5995318705
A = FRS26ZSG (FRS26ZSGB3)
B = FRS26ZSG (FRS26ZSGB4)
C = FRS26ZSG (FRS26ZSGW3)
D = FRS26ZSG (FRS26ZSGW4)
POS. NO PART NO DESCRIPTION
1 5318582501 A B C D Tube-water inlet, 93", plastic, cut-to-size
1* 215294101 A B C D Tube-water inlet, formed, plastic, dispenser
1* 218658301 A B C D Tube-water inlet, filter, to filter valve,w/elbow
1* 218832301 A B C D Tube-water inlet,inlet valve ,to filter
1* 218859801 A B C D Tube-water inlet,inlet valve ,to filter
2 218505303 A B - - Deflector-ice disp,black
2 218505301 - - C D Deflector-ice disp,white
3 # 215484300 A B C D Heater-door housing
4 218432103 A B - - Housing-dispenser,black
4 218432101 - - C D Housing-dispenser,white
7 # 218841901 A B C D Switch-actuator,micro
7* 215944300 A B C D Shield-micro switch
8 218835701 A B C D Module-dispenser
10 218209800 A B C D Spring,dispenser door
12 218836203 A B - - Knob-selector,black
12 218836201 - - C D Knob-selector,white
13 215748101 A B C D Ring-snap,actuator
14 218416166 A B - - Label-module cover,black
14 218416165 - - C D Label-module cover,white
15 218284900 A B C D Light Bulb/Lamp,4 W ,115 V
16 215284900 A B C D Socket-light/lamp
17 215794400 A B C D Screw,#6 x 1/4
17A 215840700 A B C D Screw,truss head ,6-20 x 3/8
17A* 215923400 A B C D Washer-flat
23 5303299660 A B - - Drip Tray,black
23 5303297844 - - C D Drip Tray,white
24 218796503 A B - - Actuator,black
24 218796501 - - C D Actuator,white
26 215503200 A B C D Screw, cr pan hd, 10-16 x ½, spec/hi-lo
27 218432600 A B C D Cam-slide
27A 218814901 A B C D Rocker-switch
28 218700603 A B - - Cover-module,black
28 218700601 - - C D Cover-module,white
30 215753600 A B C D Door Assy-ice chute,w/gasket,insul
33 # 218870201 A B C D Heater-disp throat
35 # 218740003 A B C D Heat Motor,115V
36 218835601 A B C D Cover-slctr switch,ice dispenser
38A# 218479900 A B C D Switch-micro,single pole ,double throw
38B# 218835401 A B C D Switch-micro,single pole ,single throw
39 218284600 A B C D Wire-ice door
40 218284500 A B C D Yoke-heat motor
41 215765400 A B C D Spring-actuator
43 5303001083 A B C D Screw,tw hx cr pan hd ,8-16 x 0.500
49 215794000 A B C D Bracket-heat motor
56 218434300 A B C D Screw-micro switch, pan head, 4-24 x 9/16
61 215766000 A B C D Ring-retainer,micro switch
82 215296300 A B C D Screw,plask h/l ,#6 x 3/8
* 215781700 A B C D Clip-tube
* 218863101 A B C D Harness-wiring,disp
* 5300460947 A B C D Tape-I&W dispenser, double faced, foam,
60 x1-1/4 x1/32,(2)
DISPENSER

02/99 16
Publication No. FRS26ZSG
5995318705
ICE CONTAINER

# = Fast-moving Parts 17 02/99
* = Non-Illustrated Parts
FRS26ZSG Publication No.
5995318705
A = FRS26ZSG (FRS26ZSGB3)
B = FRS26ZSG (FRS26ZSGB4)
C = FRS26ZSG (FRS26ZSGW3)
D = FRS26ZSG (FRS26ZSGW4)
POS. NO PART NO DESCRIPTION
2 5304404344 A B C D Auger-ice
3 5304404343 A B C D Cam-drive
4 218815300 A B C D Container-ice
6 5304404346 A B C D Drum-ice disp
7 218815400 A B C D Front-ice container
10 5304404337 A B C D Bar-drive
13 5304404359 A B C D Gate
15 5303001179 A B C D Light Bulb/Lamp,40 W
16 5303289050 A B C D Socket-light/lamp
17 5304404345 A B C D Drive Blade
18 # 5304404330 A B C D Motor-auger
18* 5304404335 A B C D Harness-wiring,auger motor
20 5304404332 A B C D Cover-motor
21 215285100 A B C D Nut-drive
23 5304404347 A B C D Plate-front
25 5304404362 A B C D Screw
26 215503200 A B C D Screw, cr pan hd, 10-16 x ½, spec/hi-lo
33 5304404351 A B C D Spacer
34 5304404349 A B C D Spacer
35A 5304404353 A B C D Fixed Blade,round
35B 5304404352 A B C D Fixed Blade,square
37A 5304404348 A B C D Blade-crusher,#1
37B 5304404350 A B C D Blade-crusher,#2
37C 5304404356 A B C D Blade-crusher,#3
39 5304404365 A B C D Screw
41 5304404358 A B C D Housing-crusher
44 218359200 A B C D Screw,pan head ,8-32 x .25
45 # 5304404333 A B C D Solenoid Assy
45A 5304406816 A B C D Spring-solenoid
45B 5304406817 A B C D E-Ring-solenoid
45C 5304406818 A B C D Actuator-solenoid
45D 5304406819 A B C D Solenoid
46 5304404341 A B C D Control Rod
47 5304404342 A B C D Spring-control rod
48 5304404340 A B C D Bracket-control rod
48* 5304404364 A B C D Screw-bracket
49 5304404329 A B C D Rail Assy
50 5304404334 A B C D Guide-solenoid
51 5304404336 A B C D Rotation Stop
52 5304404354 A B C D Spacer-fixed blades
53 5304404355 A B C D Pin-spiral,fixed blades
54 5304404357 A B C D Nut-auger
55 5304404360 A B C D Washer
56 5304404361 A B C D E-ring
57 5304404363 A B C D Door-access
58 5304404331 A B C D Screw-solenoid
* 215781700 A B C D Clip-tube
* 218842802 A B C D Ice Container Assy
ICE CONTAINER

02/99 18
Publication No. FRS26ZSG
5995318705
ICE MAKER

# = Fast-moving Parts 19 02/99
* = Non-Illustrated Parts
FRS26ZSG Publication No.
5995318705
A = FRS26ZSG (FRS26ZSGB3)
B = FRS26ZSG (FRS26ZSGB4)
C = FRS26ZSG (FRS26ZSGW3)
D = FRS26ZSG (FRS26ZSGW4)
POS. NO PART NO DESCRIPTION
1 5318582501 A B C D Tube-water inlet, 93", plastic, cut-to-size
1* 218658301 A B C D Tube-water inlet, filter, to filter valve w/elbow
1* 218832301 A B C D Tube-water inlet,inlet valve ,to filter
2 3206348 A B C D Spring,shut-off arm
3 3206299 A B C D Plate-I.D.
4 3206301 A B C D Gear
5 3206303 A B C D Plate-mounting
6 3206305 A B C D Screw-ground wire,8-32 x 1/4
7 # 3206306 A B C D Motor-ice maker
8 3206312 A B C D Spacer-holding sw
9 3206313 A B C D Cam
10 3206315 A B C D Clamp
11 # 3206319 A B C D Thermal Cutoff,icemaker ,complete assy
12 3206321 A B C D Connector Plug,wiring harness
12 # 3206349 A B C D Harness-wiring,IM internal ,with plug
13 # 3206322 A B C D Thermostat Assy,ice maker
14 3206323 A B C D Screw-switch mtg, 4-24 x ¾, sw to support,(2)
15 # 3206324 A B C D Switch,(3)
16 3206326 A B C D Support
17 # 5303320545 A B C D Mold-ice maker,radius cube ,with heater
18 3206328 A B C D Ejector
19 3206330 A B C D Bearing & Inlet
20 3206331 A B C D Screw,8-18 x 3/8 ,(2)
21 3206332 A B C D Ice Stripper
22 3206333 A B C D Arm,shut-off
23 3206334 A B C D Screw-sup/mold body,8-18 x 1 ,(4)
24 3206335 A B C D Lever-arm
25 3206336 A B C D Screw-arm levr/sprt,8-18 x 9/16
26 3206337 A B C D Screw-thermo/sprt,4-24 x 3/8 ,(4)
27 3206338 A B C D Screw-sw&spcr/plate,4-40 x 1
28 3206339 A B C D Screw-timing stop,4-40 x 3/8
29 3206340 A B C D Screw-mtr & sw/plate,4-40 x 3/4
30 3206341 A B C D Screw-timing,8-32 x 1
31 3206342 A B C D Insulator
32 3206343 A B C D Plate-valve switch
33 3206344 A B C D Spring
34 3206345 A B C D Screw-mtg plate/sprt,8-18 x 7/16
35 3206346 A B C D Screw-gear/cam,6-20 x 0.437
36 3206347 A B C D Cover-ice maker,complete
37 5303320544 A B C D Data Sheet,ice maker
38 5303207445 A B C D Envelope-data sheet
44 5308000133 A B C D Clamp,nylon ,.75 OD tube
45 5303001343 A B C D Screw,hex wshr hd ,8-15A x .5 ,spec
46 5303001193 A B C D Clamp-inlet tube,metal
51 215811600 A B C D Tube-fill
55 # 218859701 A B C D Valve-water, single solenoid, 115 V, w/nut
55* 218873001 A B C D Cap-water valve
59 5303001191 A B C D Sleeve-tube insert
60 5303207328 A B C D Screw,hex wshr hd ,8-15A x 1
61 218721500 A B C D Bracket-leveling,ice maker
62 218737900 A B C D Screw-IM mtg brkt,hex hd ,#8-32 x 3/8
64 5303001549 A B C D Clamp-copper tube,steel
141# 218832401 A B C D Valve-water,dual solenoid ,115 V ,w/nut
* 218699501 A B C D Icemaker,*
* 218731600 A B C D Nut,7/16 x 20 ,nylon
ICE MAKER

02/99 20
Publication No. FRS26ZSG
5995318705
WIRING
