INSTRUCTION MANUAL
2.7 CU. FT.
FRONT LOAD WASHER
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER
purchase, go to www.blackanddecker.com/instantanswers.
If you can’t find the answer or do not have access to the Internet, call
844-299-0879 from 10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an
agent. Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CATALOG NUMBER
BFLW27MW

Page 2
ENGLISH
CONTENTS
PRODUCT REGISTRATION
SAFETY INFORMATION
Important Safety Instructions..........................................................................................................................................3-5
Important Installation Information ....................................................................................................................................6
SET UP & USE
Before First Use .......................................................................................................................................................................... 7
Quick Start Guide ...................................................................................................................................................................... 7
Control Panel ......................................................................................................................................................................... 8-12
Using the Washer ...............................................................................................................................................................12-13
CLEANING & CARE
Cleaning and Maintenance............................................................................................................................................ 14-16
INSTALLATION INSTRUCTIONS
Installation Warnings and Precautions ....................................................................................................................17-18
Grounding Instructions ..........................................................................................................................................................19
Usage and Maintenance Cautions............................................................................................................................ 20-21
Usage and Maintenance Warnings ..........................................................................................................................22-23
Transporting the Machine .................................................................................................................................................. 24
Removing the Transport Bolts..........................................................................................................................................25
Parts and Features................................................................................................................................................................. 26
Tools Needed.............................................................................................................................................................................27
Choose the Proper Location......................................................................................................................................27-30
TROUBLESHOOTING & WARRANTY
Before You Call For Service.................................................................................................................................................31
Troubleshooting................................................................................................................................................................ 32-34
Limited Warranty.....................................................................................................................................................................35
Staple your receipt to your manual.
You will need it to obtain warranty service.
Thank you for purchasing our
BLACK+DECKER product. This
easy-to-use manual will guide you
in getting the best use of your
product.
Remember to record the model and
serial numbers. They are on a label
on the back of the product.
_____________________________
Model number
_____________________________
Serial number
_____________________________
Date of purchase

Page 3
ENGLISH
SAFETY INFORMATION
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
1. READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
2. Do not wash articles that have been previously cleaned in, washed in, soaked in,
or spotted with gasoline, dry-cleaning solvents, or other ammable or explosive
substances, as they give off vapors that could ignite or explode.
3. Do not add gasoline, dry-cleaning solvents, or other ammable or explosive
substances to the wash water. These substances give off vapors that could ignite
or explode.
4. Under certain conditions, hydrogen gas may be produced in a hot-water system
that has not been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE.
If the hot-water system has not been used for such a period, before using a
washing machine, turn on all hot-water faucets and let the water ow from each
for several minutes. This will release any accumulated hydrogen gas. As the gas is
ammable, do not smoke or use an open ame during this time.
5. Always unplug the washing machine from the power supply before attempting
any service. Disconnect the power cord by grasping the plug, not the cord.
6. To reduce the risk of re, any articles that have traces of any ammable
substance, such as vegetable oil, cooking oil, petroleum based oils or distillates,
waxes, fats, etc., must not be placed in the washing machine. These items may
contain ammable substances that, even after washing, may smoke or catch re.
7. Never place items in the washer that have been dampened with gasoline or any
combustible or explosive substance. Do not wash anything that has been soaked
in or spotted with any type of oil (including cooking oils). Doing so can result in
re, explosion, or death.
8. Do not allow children to play on or in the appliance. Close supervision is
necessary when the appliance is used near children.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
when using electrical appliances, basic safety precautions
should be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THE UNIT
WARNING: To reduce the risk of re, electric shock, or injury to persons when
using your appliance, follow basic precautions, including the
following:

Page 4
ENGLISH
SAFETY INFORMATION
9. Pets and kids may climb into the machine. Check the machine before every
operation.
10. Glass door or protector may be very hot during operation. Keep kids and pets far
away from the machine during operation.
11. This machine is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
machine by a person responsible for their safety.
12. Kids should be supervised to ensure that they do not play with the machine.
13. When children become old enough to operate the appliance, it is the legal
responsibility of parents or legal guardians to ensure that they are instructed in
safe practices by qualied persons.
14. Do not machine wash ber glass materials (such as curtains and window
coverings that use ber glass materials). Small particles may remain in the
washing machine and stick to fabrics in subsequent wash loads causing skin
irritation.
15. Before appliance is removed from service or discarded, remove door.
16. Do not reach into the appliance if the tub or agitator is moving.
17. Do not install or store this appliance where it will be exposed to the weather.
18. Do not tamper with controls.
19. Do not repair or replace any part of the appliance or attempt any servicing unless
specically recommended in the user-maintenance instructions or in published
user-repair instructions that you understand and have the skills to carry out.
20. Pull out its plug from the power socket before cleaning or maintenance.
21. Make sure that all pockets are emptied from articles of clothing before placing in
machine.
22. Sharp and rigid items such as coin, brooch, nail, screw or stone etc. may cause
serious damage to this machine.
23. Pull out its plug and cut off water supply after operation.
24. Please check whether the water inside the drum has been drained before opening
its door. Please do not open the door if there is any water visible.
25. If the plug (power cord) is damaged, it shall be replaced by the manufacturer or a
service agent to avoid any danger.
26. Take care that power voltage and frequency shall be identical to those of
washing machine.
27. Do not use any socket with rated current less than that of washing machine.
Never pull out power plug with wet hand.
28. To ensure your safety, power cord plug must be inserted into a grounded three
pole socket. Check carefully and make sure that your socket is properly and
reliably grounded. See page 19 for additional information about grounding.

Page 5
ENGLISH
29. This machine shall be repaired only by an authorized service center and only
authentic accessories can be used.
30. An appliance shall be clearly and permanently marked with a warning that the
appliance is intended for use only with fabrics that have been washed with water
as a cleaning agent.
31. If connected to a circuit protected by fuses, use time-delay fuses with this
appliance.
32. Do not use fabric softeners or products to eliminate static unless recommended
by the manufacturer of the fabric softener or product.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
SAFETY INFORMATION

Page 6
ENGLISH
SET UP & USE
IMPORTANT INSTALLATION INFORMATION
1. This unit must be properly installed and located according to the installation
instructions before it is used.
2. Store and install the washer where it will not be exposed to temperatures below
freezing or exposed to outdoor weather conditions. This could damage the unit
and void the warranty.
3. The (red) hot water hose should be connected to the (red) hot water inlet and
the (blue) cold water hose should be connected to the (blue) cold water inlet.
4. The washer must be plugged into an appropriate outlet that is properly installed
and grounded in accordance with all local codes and ordinances. Follow all
installation instructions.
5. The unit should be installed on a level oor with a maximum slope of 1” (25 mm)
over a 3 ft distance.
WHEN NOT IN USE
Turn off the water supply when the unit is not in use in case of leaking or ruptured
hoses. It is recommended to replace the hoses every 5 years.

Page 7
ENGLISH
SET UP & USE
QUICK START GUIDE
Default settings can be changed. See USING THE CONTROL PANEL section for more
details.
1. Add HE detergent to the detergent dispenser according to detergent
manufacturer’s instructions. HE detergent pods can be added to the wash tub
before adding clothes.
Add optional pre-wash and/or fabric softener to the detergent dispenser.
2. Load clothing, maximum ¾full.
3. Close the Door.
NOTE: Unit will not start with the door open.
4. Press ON/OFF to power on the unit.
5. Turn the selector dial to a cycle such as NORMAL/COTTON.
Defaults are set for each wash cycle. These default settings can be changed on
the control panel.
6. Press the Start/Pause button.
For more details on cycles and default setting refer to the wash program chart.
Before First Use
Before washing clothes for the first time, the washing machine should be operated
without clothing added.
1. Connect power source and water supply.
2. Put a small amount of detergent into the dispenser and close the dispenser.
3. Close the Door.
4. Select a wash cycle using the dial.
5. Press ON/OFF.
6. Press the Start/Pause button.
NOTE: If water leaks while water is being supplied or drained, check the water
connections.
If the washer rocks and vibrates excessively, level your washer again.
During rinse cycle when washer is spinning at a very high speed, some
vibration is normal.
NOTE: For best performance do not load the tub more than ¾full of dry clothes. DO
NOT OVERLOAD.

Page 8
ENGLISH
SET UP & USE
CONTROL PANEL
On/O
Press once to turn the
washing machine on, press
again to turn the washing
machine off.
LED Display Selector Dial Start/Pause
Press the button to start
or pause the wash cycle.
Buzzer
Time Save

Page 9
ENGLISH
SET UP & USE
1. ON/OFF
Press to turn the POWER ON. Press again to turn it OFF.
2. Selector Dial
Turn the dial to select the cycle.
My
cycle
This is a setting to save a frequently used program. Select the settings you wish to save. Press and
hold SPIN for 3 seconds. The will illuminate on the control panel. Turn the dial to MyCycle to use the
saved setting. To change the saved setting to a dierent program select the new settings. Press and
hold SPIN again to save the new settings.
Type of clothing Washer Load
(lbs/kgs)
Temperature.
Default
temperature
in bold
Default
Time
(hours)
Time
save
Extra
Rinse
Easy
Iron
Pre
Wash Delay
Soil
Level
Default
in bold
Spin Speed.
Default in
bold
Normal/
Cotton
Cotton or blends with
medium soil. 26.4lbs/12kgs
Hot+, Hot,
Warm,
Eco, Cold
0:55 O O O O O
Light,
Medium,
Heavy
Low, Med,
High, Highest
Perm Press Used to resist wrinkles in
washing. 13.2lbs/6kgs Warm, Eco,
Cold 0:57 O O O O O
Light,
Medium,
Heavy
Low, Med
Heavy Duty
Heavy items to be washed
in hot temperatures such
as towels.
26.4lbs/12kgs
Hot+, Hot,
Warm, Eco,
Cold
1:40 O O O O O
Light,
Medium,
Heavy
Low, Med,
High, Highest
Bulky/Large Large items such as blankets. 13.2lbs/6kgs Hot, Warm,
Eco, Cold 1:23 O O O O O
Light,
Medium,
Heavy
Low, Med,
High, Highest
Sportswear Removes odor and soil from
activewear. 13.2lbs/6kgs Hot, Warm,
Eco, Cold 0:57 O O O O O
Light,
Medium,
Heavy
Low, Med,
High, Highest
Spin Only Extra spin after water has been
drained. 26.4lbs/12kgs -- 0:13 -- -- O-- O-- Low, Med,
High, Highest
Drain Only Drains all water from the tub. 26.4lbs/12kgs -- 0:01 -- -- -- O-- --
Rinse &
Spin
Extra Rinse with spin to be used
without detergent. 26.4lbs/12kgs -- 0:23 -- -- O-- O-- Low, Med,
High, Highest
Tub Clean Cleans the empty tub. -- Hot+ 1:28 -- -- -- -- O-- --
Sanitary Use for heavily soiled items. 13.2lbs/6kgs Hot+ 2:18 -- O O O O
Light,
Medium,
Heavy
Low, Med,
High, Highest
Cold Wash Dark or bright fabrics. Lightly
soiled delicates. 26.4lbs/12kgs Cold 1:09 -- O O O O
Light,
Medium,
Heavy
Low, Med,
High, Highest
Baby Wear Longer rinse time to remove
detergent residue. 26.4lbs/12kgs
Hot+, Hot,
Warm, Eco,
Cold
1:37 -- O O O O
Light,
Medium,
Heavy
Low, Med,
High, Highest
Wool Wool items labeled as
washable. 4.4lbs/2kgs Warm, Eco,
Cold 1:01 -- O-- -- O
Light,
Medium,
Heavy
Low, Med,
High
Delicates
Uses lower temperature and
low spin speed for delicates
suitable for a washing machine.
5.5lbs/2.5kgs Warm, Eco,
Cold 0:58 -- O-- -- O
Light,
Medium,
Heavy
Low, Med,
High
Quick Wash Short wash cycle for small
quantity of lightly soiled items. 4.4lbs/2kgs Hot, Warm,
Eco, Cold 0:36 -- -- -- -- OLight Low, Med,
Wash Program Chart

Page 10
ENGLISH
SET UP & USE
TO CHANGE DEFAULT SETTINGS ON THE LED DISPLAY
The default settings will be illuminated on the control panel.
To change the default temperature, press the Temp button on the control panel
repeatedly to scroll through the selections.
To change the spin speed, press Spin button on the control panel repeatedly to scroll
through the selections.
To change the Soil level, press the Soil button on the control panel repeatedly to
scroll through the selections.
NOTE: Not all options are available for each cycle. Please note cycle chart.
3. Time Display
Indicates remaining cycle time, delay start time and error codes. For each cycle
time the display will show the remaining time counting down until it reaches 0:00
indicating the end of the cycle.
4. Time Save
Decreases wash time. When selected, the new cycle time and the symbol will
illuminate on the time display. The amount of time saved, depends on the wash cycle.
5. Delay
To delay the start of your washer up to 24 hours, press the Delay button to activate
after the wash cycles have been selected. The number shown on the digital display
will indicate when the wash cycle will start. 1 hour will be added to the start time
each time you press the Delay button up to 24 hours. Once the delay time has been
selected, press Start/Pause to activate.
Pressing the Delay button to exceed 24 hours until the display indicates 0H will
deactivate the delay function and the display will turn off.
To cancel the Delay Start function after the wash program has started, press On/Off.
NOTE: In case of disruption of power supply while operating the program, Press
Start/Pause to resume.

Page 11
ENGLISH
SET UP & USE
6. Temp
Press Temp continuously to scroll through the selections: Hot+, Hot, Warm, Eco, Cold.
The selected temperature will be illuminated on the LED Display.
7. Spin
Press Spin continuously to scroll through the selections: Highest, High, Med, Low, No
Spin. The selected spin speed will be illuminated on the LED Display.
8. Soil
Press Soil continuously to scroll through the selections: Heavy (For heavily soiled
clothes), Med, Light. The selected soil level will be illuminated on the LED Display.
9. Mute
Press the Soil button 3 seconds to mute the buzzer at the end of the cycle. Press
again for 3 seconds to unmute the buzzer.
10. Function
Press the Function button continuously to select Prewash, Easy Iron, Extra Rinse
functions. The corresponding symbol will illuminate on the LED display to indicate
which functions are activated.
Prewash cycle
Rinses heavily soiled clothes before the main wash cycle.
Easy Iron
After the spin cycle, the tub rotates to prevent clothes from sticking to the side of the
tub to prevent wrinkles and creasing.
Extra Rinse
Add extra rinse time.
11. Child Lock
Use this option to disable the controls except for the ON/OFF. This feature can
prevent children from changing cycles. The washer can only be locked during a cycle.
To activate this function after starting the washer, press and hold the Delay and Temp
buttons at the same time for 3 seconds. There will be an audible sound and the child
lock indicator light will turn on. To cancel this function select the Temp and Program
buttons again.
12. Press START/PAUSE to start a cycle after all settings are programmed.
Press START/PAUSE to pause a cycle and to add a garment.
Press START/PAUSE for 3 seconds to pause the washer.
To add a Garment
A garment can be added to the load in the beginning of a cycle. Press START/PAUSE,
then open the door. Add the item, close the door, and then press the START/PAUSE
button again to resume the cycle.
NOTE: A garment can be added when the water level reaches just below the door.
Once the water level becomes elevated, the door will not open and should not be
forced.
CAUTION: Do not attempt this function when there is hot water in the tub. The
door will not open and should not be forced. Attempting to force the
door to open could cause damage to the unit.

Page 12
ENGLISH
NOTE: In case of disruption of power supply while operating the program, Press
Start/Pause to resume.
USING THE WASHER
WARNING: Never insert hands inside washer until drum stops spinning.
Do not insert any fabric with gasoline, petroleum, benzene, paint
thinner, alcohol or any other flammable substances.
Do not put oil soaked items in the washer.
Do not attempt to wash items with plastic, foam or rubber.
Never keep clothing in the tub for long periods of time. This can
cause mildew, wrinkling etc.
Detergent
1. This washer is designed for high eciency (HE) detergent only, to avoid
excessive sudsing.
2. Add the manufacturer’s recommended amount of detergent directly into the
detergent compartment before starting your washer.
3. Always reduce the amount of detergent if the load is small or lightly soiled,
or if your water is very soft. Never use more than the maximum amount
recommended by the detergent manufacturer.
SET UP & USE
Detergent Dispenser
1. Pull out the drawer. The high eciency detergent should
be added to the left drawer (II). If using a detergent POD,
it can be added directly into the wash tub.
2. Optional prewash detergent should be added to the far
right compartment for heavily soiled items (I).
3. Fabric softener (optional) can be used in the middle
compartment ( ).
I
II

Page 13
ENGLISH
SET UP & USE
Sorting and Loading
1. Before loading your laundry, be sure to take out coins, keys and other hard
objects, and fasten all hooks and zippers.
2. Follow manufacturer’s instructions on clothing tag for washing instructions.
Sort laundry according to color (light, medium, dark), Fabric type, (delicates,
permanent press items) required wash temperature, soil level etc., Washing items
that are not color safe can discolor the other items in the load. Mixing colors can
cause the dyes to bleed into the other clothes.
3. Items with embroidery or buttons should be turned inside out.
4. Clothes with hooks or zippers can be washed in a mesh bag as to not get caught
on other clothing or scratch the drum.
5. Items that produce a lot of lint should be washed separate.
6. Single heavy items can cause the load to be unbalanced. If the washer vibrates
and makes loud sound press start/pause to redistribute the load.
7. Do not load more than ¾ full of dry clothes.

Page 14
ENGLISH
CLEANING AND MAINTENANCE
WARNING: Unplug the power cord before cleaning any part of the unit.
The washer should be cleaned regularly. Failure to maintain the unit
in a clean condition could lead to deterioration of the surface which
could adversely aect the life of the appliance. Do not use harsh
chemicals or solvents on any part of the machine or pour water or
cleaner directly on it.
Cleaning the exterior
Clean with a soft, damp cloth or a mild soap and water solution. Do not use abrasive
powders or pads. Do not spray cleaners directly onto the control panel.
Cleaning the interior
Select the Tub Clean Cycle and operate the washer without any laundry loaded. 1 cup
of bleach can be added directly into the tub. Tub cleaning tablets or powder can be
used according to manufacturer’s instructions.
Metal objects (safety pins, hair pins, etc.) in the tub may scratch the surface of the
tub and cause it to rust. If rust appears on the surface of the tub, apply a neutral
cleansing agent to the surface and use a sponge to clean it. Never use a metal brush
or scouring pad to clean.
Cleaning Detergent Dispenser
1. Open the Detergent dispenser and press down as shown by the arrow.
2. Lift up the clip and remove the cover.
3. Rinse with water.
4. Replace the cover and push the dispenser back to its original position.
CLEANING AND CARE

Page 15
ENGLISH
Cleaning the Inlet Filter
Shut off the water supply and disconnect the inlet hose.
Pull out the lter with pliers, removing as shown. Clean the
lter and reinstall it.
Reconnect the inlet hose.
Turn on the water supply and make sure there is no
water leakage.
Drain Pump Filter:
The drain pump filter collects lint and small items so it does not pass through the
drain. It should be cleaned approximately once a month depending on frequency of
use.
If the washer does not empty or spin properly or if it makes an unusual noise during
draining, there may be an obstruction.
WARNING: The drain pump filter should not be accessed while the unit is
operating or cycle has just been completed. There may be hot water
in the pump. Allow time for water to cool before access.
NOTE: To avoid spills, place a tray underneath the compartment.
CLEANING AND CARE
1
1To access the drain
pump lter, open
the compartment
on the bottom right
of the machine.
Remove debris.
Rinse off the pump
lter.
Reinsert the pump
lter and close the
compartment.
Turn the cap 90°
and pull out the
small hose.
Drain the water
from the small hose
into a container (not
included).
Remove the pump
lter by turning it
counterclockwise to
remove it.
2
Emergenc y
drain hose
3
4
5
6

Page 16
ENGLISH
Washer Door:
The washer door cannot be opened if there is a power failure. If it is necessary to
open the door, use the pull cord in the lower right compartment. Replace the pull
cord in the original position after opening the door.
WARNING: Do not use this pull cord during the wash cycle.
STORAGE:
Do not store the washer in any area that it can be exposed to outdoor weather or
cold temperatures that would cause pipes to freeze.
For long term storage, or if washer will not be used for a long period of time,
disconnect the power supply. Disconnect all the hoses and drain. Clean inside of the
unit and keep door open until dried thoroughly. Clean all lters.
CLEANING AND CARE

Page 17
ENGLISH
INSTALLATION INSTRUCTIONS
WARNING:
1. Plug the power cord into an AC 120V/60Hz wall socket rated at 15 amps or
higher. Use the socket for this washer only.
2. Do not use an extension cord.
- Sharing a wall socket with another appliance, using a power strip, or extending
the power cord may result in electric shock or re.
- Do not use an electric transformer. It may result in electric shock or re.
- Ensure that the power voltage, frequency, and current match the product’s
specications. Failing to do so may result in electric shock or re.
3. Have this appliance installed by a qualied technician or service company.
- Failing to do so may result in electric shock, re, explosion, problems with the
product, or injury.
4. Remove all foreign substances such as dust or water from the power plug
terminals and contact points using a dry cloth on a regular basis.
- Unplug the power plug and clean it with a dry cloth.
- Failing to do so may result in electric shock or re.
5. Plug the power plug into the wall socket rmly. Do not use a damaged power
plug, or loosen wall socket.
- This may result in electric shock or re.
6. Do not pull or excessively bend the power cord.
7. Do not twist or tie the power cord.
8. Do not hook the power cord over a metal object, place a heavy object on the
power cord, insert the power cord between objects, or push the power cord into
the space behind the appliance.
- This may result in electric shock or re.
9. Do not pull the power cord when unplugging the power plug.
- Unplug the power plug by holding the plug.
- Failing to do so may result in electric shock or re.
10. If the power plug or power cord are damaged, contact your nearest service
center.
11. Do not install this appliance near a heater or inammable material.
12. Do not install this appliance in a humid, oily, or dusty location, or in a location
exposed to direct sunlight or water (rain drops).
13. Do not install this appliance in a location where gas may leak.
- This may result in electric shock or re.
14. If the washer is moved to a new location, have it checked and re-installed by a
qualied service technician.
- Failing to follow this warning may result in electric shock or re.
INSTALLATION WARNINGS
AND PRECAUTIONS

Page 18
ENGLISH
INSTALLATION INSTRUCTIONS
15. Do not install on carpet. Install washer on a level and solid oor that can support
its weight.
- Failing to do so may result in abnormal vibrations, noise, or problems with the
product.
16. The washer is heavy. Two or more people may be needed to install and move the
appliance.
- Failing to do so may result in bodily or other injuries.
17. Store and install the washer where it will not be exposed to temperatures below
freezing or exposed to outdoor weather conditions.
- Failing to do so may result in serious leak damage.
18. Position the appliance so that the power plug is easily accessible.
- Failing to do so may result in electric shock or re due to electric leakage.
19. To reduce the risk of injury to persons, adhere to all industry recommended
safety instructions.
- Failing to follow all of the safety warnings in this manual may result in property
damage, or injury to persons.
WARNING:

Page 19
ENGLISH
GROUNDING INSTRUCTIONS
Consult a qualied electrician or serviceman if:
1) The grounding instructions are not completely understood.
2) You are unsure that the appliance is properly grounded.
3) You have any questions about the grounding or electrical instructions.
Do not modify the plug provided with the appliance - if it will not t the outlet, have a
proper outlet installed by a qualied electrician.
WARNING
Improper use of the grounding plug can result in a risk of electric shock.
WARNING
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualied electrician or serviceman if you are in doubt as
to whether the appliance is properly grounded.
INSTALLATION INSTRUCTIONS
Electrical grounding is required for this washer.
This appliance must be grounded. In the event of malfunction or breakdown,
grounding will reduce the risk of electric shock by providing a path of least resistance
for electric current. This appliance is equipped with a power cord having a three
prong grounding plug for use in a properly installed and grounded outlet. The plug
must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING: An improperly connected equipment-grounding conductor can
increase the risk of electrical shock. Check with a qualied electrician
or serviceman if you are not sure whether the appliance is properly
grounded. Do not modify the plug provided with the appliance. If it
does not t the outlet, have a proper outlet installed by a qualied
electrician. To prevent unnecessary risk of re, electrical shock or
personal injury, all wiring and grounding must be done in accordance
with the National Electrical Code ANSI/FNPA, No.70 Latest Revision
and local codes and ordinances. It is the personal responsibility of
the appliance owner to provide adequate electrical service for this
appliance. Never connect the ground wire to plastic plumbing lines,
gas lines, or hot water pipes.
WARNING: Certain internal parts are intentionally not grounded and may present
a risk of electric shock only during servicing.
Service Personnel: Do not make contact the following parts while the
appliance is energized: Electrical Valve, Drain Pump, Door or Lock.
WARNING: The maximum current through the unit is 12A when you are using its
heating function. Make sure the power supply system
(current, voltage and wire) can meet the normal
loading requirements of the electrical appliances.

Page 20
ENGLISH
INSTALLATION INSTRUCTIONS
WARNING:
1. If the appliance is ooded, cut the power immediately and contact your nearest
service center.
2. If the appliance emits a strange noise, a burning smell, or smoke, unplug the
power plug immediately and contact your nearest service center.
- Failing to do so may result in electric shock or re.
3. In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate the area
immediately. Do not turn any appliance or light on or off.
- Do not use a ventilating fan.
- A spark may result in an explosion or re.
4. Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner,
alcohol, dry cleaning detergent or other ammable or explosive substances.
- This may result in electric shock, re, or an explosion.
5. Do not force the washer door open while the washer is operating (high
temperature washing/spinning).
- Water owing out of the washer may cause burns or cause the oor to be
slippery. This may result in injury.
- Forcing the door open can damage the product or cause injury.
6. Make sure to remove the packaging (sponge, styrofoam) attached to the bottom
of the washer and also remove the (4) transport bolts before using the machine.
7. Do not insert your hand or a metal object under the washer.
- This may result in injury.
8. Do not attempt to operate this appliance if it is damaged, malfunctioning,
partially disassembled, or has missing or broken parts, including a damaged cord
or plug.
- This may result in electric shock, re or death.
9. Do not touch the power plug with wet hands.
- This may result in electric shock.
10. Do not turn the appliance off by unplugging the power plug while the washer is
in operation.
- Plugging the power plug into the wall socket again may cause a spark and
result in electric shock or re.
11. Keep all packaging material well out of the reach of children, as packaging
materials can be dangerous to children.
- To avoid danger of suffocation, keep out of reach of babies and children.
USAGE AND
MAINTENANCE WARNINGS
Table of contents
Languages:
Other Black & Decker Washer manuals
