Black Stone Signature ONE User manual

OWNERS MANUAL
& INSTALLATION GUIDE

2
saunas
BLACKSTONE
Congratulations on your purchase of an infrared sauna, the newest
generation of infrared saunas in the world! We are condent that
you will enjoy the many benets of using your infrared sauna for
years to come. Carefully and thoroughly read this manual in its
entirety before using your sauna for the rst time. We recommend
keeping this manual for regular review and future reference.
We attribute our growth and success as a business entirely to our
customer satisfaction, the recognized health benets of our
products, and the quality of our workmanship. We use only the
best materials coupled with state-of-the-art construction and
the highest safety standards in the industry. You will be surprised
at the noticeable effects on pain relief, weight control, skin
stimulation, increase in blood circulation, and stress reduction.
Whatever your needs, we invite you to experience a personal
difference with your sauna: a difference in health benets, a dif-
ference in quality, and a difference in service and support. Our
entire Blackstone Saunas team is looking forward to serving you!
Enjoy your new Blackstone Sauna!

WWW.BLACKSTONESAUNAS.COM3
TABLE OF
CONTENTS
04
05
06
12
19
20
21
22
23
24
25
26
27
CONNECTING THE PANELS
WHERE TO START
SIGNATURE MODEL INSTALLATION
CORNER MODEL INSTALLATION
KEYPAD FUNCTIONS
STEREO & LIGHT OPERATIONS
FREQUENTLY ASKED QUESTIONS
SAUNA ACCESSORIES
IONIZER OPERATIONS
OPTIMAL SAUNA PROTOCOL
HEALTH & SAFETY
WARRANTY DISCLAIMER
ACTIVATE WARRANTY

saunas
BLACKSTONE
4
CONNECTING THE PANELS
The sauna offers two types of panel locking systems to connect the different sides of the sauna. Please
use the instructions below as a reference guide on how to connect the sauna panels.
INNER LOCKING SYSTEM:
The inner locking system is designed to be completely invisible when the sauna is installed. The locks
are built on the side of each panel and they connect by sliding one over the other (Figure G-2).
Latch System Continued on Next Page
To connect two panels, follow these few steps:
1. Lift the panel with the male locks up a few inches.
2. Push it against the opposite panel; make sure
to apply pressure around the top and bottom
corners.
3. Slide the panel down to lock it in place. Make
sure all the locks are connected (top and bot-
tom).
4. Inspect the panels and make sure they are level
(the panel tops is at and matching).
(Figure G-2) Inner Locking System

WWW.BLACKSTONESAUNAS.COM5
CONNECTING THE PANELS CONT.
QR CODES
LATCH LOCKING SYSTEM:
The Latch Locking System is two brackets that lock together by passing the main loop over the opposite
side and locking the latch (Figure G-3).
Throughout this manual your may notice QR codes at certain steps, these QR codes are meant to be
scanned by your mobile device and it will direct you to a certain website, video or section of a videos
that will help in the current step you are in.
1) Open your phones camera and hover over the QR code
2) A notication or button may appear around the code
3) Tap the link that appears and it will take you to the corresponding page
(Figure G-3) Latch Locking System
GIVE IT A GO!
THIS QR CODE WILL DIRECT YOU TO GOOGLE REVIEWS
TELL US WHAT YOU THINK ABOUT YOUR SAUNA?

6
SIGNATURE MODEL
INSTALLATION
NEED MORE HELP?
SCAN HERE TO WATCH THE INSTALL VIDEO

WWW.BLACKSTONESAUNAS.COM7
INSTALLATION SET - SIGNATURE MODEL
The following installation instructions apply to following models:
• Signature ONE
• Signature TWO
• Signature THREE
**Continue to the next section if you have a CORNER model.
FLOOR PANEL
Place the oor panel at on the ground in the desired location. Make sure to leave a space around
the side walls for one person to stand and install the side panels (Figure A-1). You can slide the sauna
around to the desired location once it’s complete
**Tip: An “X” mark will point to the back of the sauna and the oor heater points to the front of the sau-
na.
REAR PANEL
Place the rear panel on the back end of the oor panel (Figure A-2). At this point, someone should hold
the rear panel until the next connection is made.
LEFT PANEL
Install the left panel (the left panel has 2-4 sockets on the lower end) as the image below shows. Make
sure the top of both panels are at and level.
Refer to “Connecting the Panels” section (page 4) on how to lock the panels together.
Reference Images on Next Page...
(Figure A-1) Floor Panel

saunas
BLACKSTONE
8
INSTALLATION - SIGNATURE MODEL CONT.
BENCH INSTALLATION
Slide the bench stand panel between the two vertical guides on the side panels. Connect the heaters’
plugs under the bench to the appropriate sockets. The matching plugs and sockets are labeled alpha-
betically.
e.g. connect “A” plug into the “A” socket.
Install the bench top by placing it on top of the bench stand and the horizontal guide on the rear panel.
Make sure the smooth and nished side is facing up and forward (Figure A-3).
(Figure A-2) Back & Left Panel
(Figure A-3) Bench Installation

WWW.BLACKSTONESAUNAS.COM9
INSTALLATION - SIGNATURE MODEL CONT.
FRONT PANEL
STOP: Install the door handle before installing the front panel.
Connect the front panel to the left side panel as shown in the image below (Figure A-4).
• Make sure to align the corners of the side panel and the edges of the front panel.
• The front panel is heavy because of the glass door. At least two people are needed to lift it.
• For inner locking system, a person can stand inside the sauna to align the edges and corners
of the panels.
• For inner locking system, make sure to put pressure on the top and bottom corners to ensure
the locks are connecting.
Refer to “Connecting the Panels” section (page 4) on how to lock the panels together.
(Figure A-4) Front Panel

saunas
BLACKSTONE
10
INSTALLATION - SIGNATURE MODEL CONT.
RIGHT PANEL
Install the right panel as shown in the image below (Figure A-5). Make sure the top of all the panels are
at and level.
Refer to “Connecting the Panels” section (page 4) on how to lock the panels together.
Tip: Someone can stand inside the sauna to match the bench stand with the vertical guide on the right
panel and level the corners for easy installation. If the lower lock is not connecting, make sure the
bench stand is not blocking the panel by aligning it with the vertical guide.
(Figure A-5) Right Panel

WWW.BLACKSTONESAUNAS.COM11
INSTALLATION - SIGNATURE MODEL CONT.
TOP PANEL
Raise the top panel over the sauna body. Insert the wires for the control panel, temperature sensor and
heaters through the openings in the ceiling.
Connect the control panel wire (white ribbon) and the heat sensor (2-pin wire) on top of the sauna.
Connect the heaters’ plugs to the control box. Even though the heaters’ plugs might be labeled, they
can connect into any sockets on the control box (Figure A-6).
Place the dust cover over the sauna roof and pass the main power plug through the opening. Make
sure to match the holes for the vent on the dust cover with the saunas vent holes.
(Figure A-6) Top Panel

12
CORNER MODEL
INSTALLATION
NEED MORE HELP?
SCAN HERE TO WATCH THE INSTALL VIDEO

WWW.BLACKSTONESAUNAS.COM13
INSTALLATION SET - CORNER MODEL
The following installation instructions apply to following models:
• Corner TWO
• Corner THREE
FLOOR PANEL
Place the oor panel at on the ground in the desired location. Make sure to leave a space around
the side walls for one person to stand and install the side panels (Figure B-1). You can slide the sauna
around to the desired location once it’s complete..
** Tips: The triangle corner will point to the back of the sauna and the heater (on some models) point to
the front of the sauna.
(Figure B-1) Floor Panel

saunas
BLACKSTONE
14
INSTALLATION - CORNER MODEL CONT
FIRST BACK PANEL
Place the rst back panel on the oor panel (Figure B-2). At this point, someone should hold the back
panel until the next connection is made.
• The rst panel will have female locks on both sides.
SECOND BACK PANEL
Connect the second back panel to the rst panel as the image below (Figure B-3).
Refer to “Connecting the Panels” section (page 4) on how to lock the panels together.
(Figure B-2) First Back Panel (Figure B-3) Second Back Panel

WWW.BLACKSTONESAUNAS.COM15
INSTALLATION - CORNER MODEL CONT
FRONT SIDE PANELS
Install the two front side panels (Figure B-4). Using the same inner locking system.
(Figure B-4) Connecting Front Side Panels
THE SIDE & FRONT WALLS
CAN BE TRICKY TO INSTALL, SCAN HERE TO WATCH
A STEP BY STEP VIDEO OF HOW WE DO IT

saunas
BLACKSTONE
16
INSTALLATION - CORNER MODEL CONT
INSTALLING THE BENCHES - CONT.
Place the bench stand panels by lining up their sides with the vertical guides on the back panels. Con-
nect the heaters’ plugs to under the bench and slide the bench panel over the horizontal guide on the
back panels. Make sure the smooth and nished side is facing up and forward (Figure B-5).
(Figure B-5) Installing Benches

WWW.BLACKSTONESAUNAS.COM17
INSTALLATION - CORNER MODEL CONT
DOOR PANEL
Connect the door panel to the front side panels. For the inner lock system, make sure to match the edg-
es of the front panels to the corners of the door panel (Figure B-6).
• The front panel is heavy because of the glass door. At least two people are needed to lift it.
• For inner lock system, a person should stand inside the sauna to align the corners and
edges of the panels.
• Make sure to put pressure on the top and bottom corners of each side to insure the locks are
connecting, then slide down to lock into place.
(Figure B-6) Installing door panel

saunas
BLACKSTONE
18
INSTALLATION - CORNER MODEL CONT
TOP PANEL
• Raise the top panel over the sauna body. Insert the wires for the control panel, temperature
sensor and heaters through the openings in the ceiling.
• Connect the control panel wire (white ribbon) and the heat sensor (2-pin wire) on top of the sauna.
• Connect the heaters’ plugs into the control box. Even though the heaters’ plugs might be
labeled, they can connect into any sockets on the control box (Figure B-7).
• Place the dust cover over the sauna roof and pass the main power plug through the opening.
Make sure to match the holes for the vent on the dust cover with the saunas vent holes.
(Figure B-7) Installing top panel

WWW.BLACKSTONESAUNAS.COM19
KEYPAD FUNCTIONS & CONTROLS
• Turn on sauna by pressing power button.
• Set desired temperature with temperature button +/-
• Press “+” and “—” (below the power button) together to change between °F and °C
• Set the desired time by pressing “+” and “—” below the LIGHT icon
• Use the LIGHT icon to turn on the LED light inside
• When time reaches “0”, all heaters will automatically shut off.
• Turn off sauna at end of session.

saunas
BLACKSTONE
20
STEREO OPERATIONS
CHROMOTHERAPY LIGHTING
The stereo is an ALWAYS ON functioning system. When the sauna is on, the stereo is ready to be used.
Simply connect the sauna to your phone using your phones bluetooth, then begin playing music. Your
volume controls will be done on your phone.
BLUETOOTH CONNECTION
1. Go to Bluetooth settings on your mobile device
2. Click on the device named BT-SAUNA
3. Your device will automatically connect. You can now play music wirelessly from your device to the stereo
The chromotherapy mood lighting is controlled via a remote. First you will need to turn the power to
the light ON via a small one way switch that will be found on the ceiling of the sauna in the corner. Turn
that switch on and it will show a red indicator light stating it is on.
Find your remote as pictured below to function the colored LED light.
1) Turn on LED light by pressing -
2) Turn off LED light by pressing O
3) Move your nger around the colored dial to choose a color
4) Slide your nger up or down on the B slider to adjust the brightness
5) Slide nger up or down the M slider to adjust blink mode
6) Slide nger up or down the S slider to adjust the speed of blink
