BLACKPOINT S50 User manual

USER MANUAL
S50 RECHARGEABLE SPEAKER
User’s Guide
Thank you for purchasing S50 Blackpoint’s
Rechargeable Speaker.
Please read the manual carefully before operating.
FEATURES
Wireless BT connection
TWS-True wireless stereo
Led lights effects
Led display
FM radio
USB/TF card
Rechargeable battery
Microphone input
25W power output
SPECIFICATIONS
Tweeter Unit: 1.5”
Subwoofer Unit: 15”
AUX in
Lithium battery:
3000mAH
INTERNATIONAL WARRANTY
Terms and Conditions
1. BLACKPOINT warrants the operation of this product to
be free from any manufacturing and/or material defect for a
period of 6 months from the date of purchase by the user.
2. This warranty is limited to the repair and/or replacement
of this product, according to our own criterion, free of
charge within the stipulated term and it does not extend to
consequential or incidental damages to other products that
may be used with this unit.
3. The warranty shall be voided in the following cases: a)
repair or attempt to repair by third parties not authorized
by the company. b) in case of performing any type of cut
in connection cables, plugs, connectors, or other adapters
different from the original ones provided by the company.
4. To make this warranty effective, you shall contact the
Authorized Service Center of your country and they shall carry
out the pertinent procedure. In order to start the necessary
procedure to get said warranty, you shall hand in the Original
Purchase Invoice where the purchase date, dealer name and
product identication shall be stated clearly.
5. Transportation, freight, stay and/or insurance expenses, if
any, are not covered by this warranty.
REPAIR SERVICE
To ask for customer service please call 0810-888-7262.
1. Mic input
2. Microphone Volume Knob: Adjust from Min to Max
3.Echo of Microphone Volume Knob: Adjust
from Min to Max
4. MICRO SD Slot
5. USB Slot
6. Mode Button:Toggle between AUX, USB, MICRO SD,
FM, BT by Short Press;
Long Press to turn on/ off the light
7. Previous Track Button: Select previous track by Short
press;Recording play by Long press
8. Play/Pause Button by Short press;
9. Next Track Button: Select next track by Short press;
Recording by Long press
10. AUX input
11. Power ON/OFF; Adjust the master volume.
12.Charge Indicator
13. Power Supply: DC in
DISPLAY SYSTEM SETTINGS
1. Input Mode: The LED display screen will display the
information of input mode for USB/IF CARD/BT/AUX /
FM. When a USB ash drive / TF Card is inserted into
the USB/TF Card input, the unit will automatically switch
to USB/TF Card mode and begin playing Mp3 audio les
from the USB ash drive / TF Card.
2.Track Number: The track number currently playing from
the USB/TF Card. will display.
3. FM Mode: All FM channels display here. Short Press
“play/pause” button for auto scan all channels.
CONTROL PANEL
www.blackpoint.life
WIRELESS BT CONNECTION
BT connection Mode: Open the BT connection of phone.
Find the BT connection name of the unit called “S50”
to connect. After a successful match, you can play the
music from speaker. You won’t need reconnect the BT
connection when switching mode.
TWS / TRUE WIRELESS STEREO
(1) TWS connection: TWS Connection is only for two
speakers.
(2) Turn on the Speakers, press the MODE button to
switch to BT connection mode.
(3) Please long press each unit’s TWS Button for about 3
seconds, then two speakers connected as a pair.
(4) Connect the phone: Open the phone BT connection
settings, Search and Connect the main device BT
connection Name “S50”.
(5) Select music from phone and enjoy TWS playing in
pairs with two Speakers.
(6) Exit TWS: Long press(almost 3 seconds) the TWS
button on the device.
Note:
It is recommended to regulate the listening volume from
the linked BT device (cellphone, etc), kepping the volume
of each speaker to the maxiumun.
1
2
3
45
6
7
8
9
10
11
12
13
15
