Jarv X97 User manual

USERS GUIDE
RUGGED OUTDOOR
PORTABLE BLUETOOTH
SPEAKER
with bike mount
X97
SKU: JRV-X97BLK

Thank you for purchasing the Jarv X97 Bluetooth
Speaker!
Please take the time to read this manual carefully, even
if you are already familiar with a similar product. We
recommend that you use this speaker at low volume for
the first 30 minutes to calibrate its membrane and
ensure optimum performance. The Jarv X97 Bluetooth
Speaker offers a unique blend of power and
convenience and features incredible sound quality and
volume making it the perfect complimentary accessory
for use anywhere.

1x Jarv X97 Bluetooth Speaker
1x Micro USB Cable
1x 3.5mm Audio Cable
1x Carrying Strap
1x User Manual
1x Bicycle Mount
**Please charge your new device for a minimum of four
hours before first use.
WHAT’S IN THE PACKAGE

CONTROL UNIT
12381
4756

(1)
•Press to navigate between tracks when Bluetooth
device is connected.
•Press and hold to adjust volume. While in Bluetooth
mode, a beeping sound will alert you when you have
reached maximum volume.
(2) LED Indicator Lights
(3) Play / Pause (in Bluetooth Mode)
•Answer a call – Press once to answer
•Redial a call - Press twice to redial
•Reject a call - press/hold for 3 seconds and release
•Bluetooth pairing - Press and hold to initiate, then
continue to use normally for playing and pausing.
(4) TF card
Support up to 32G memory card
Support MP3/WAV/WMV
(5) Power Button
Switch to turn speaker on / off.
When powering on, you will hear a beep-like sound and
the LED light will turn blue.
(6) Micro USB Charging Port
Use this port to charge your speaker using the provided
USB charging cable.
(7) AUX Input
Use this input to connect your speaker to your media
device via AUX cable.
(8) MIC
For best results, keep within 3 feet of the mic while
speaking.
Blue light:
•Speaker is powered on
•Speaker is successfully connected via Bluetooth
•Speaker is in AUX mode
Red light:
•Speaker is charging
Slow Flashing Blue light:
•Speaker is in Bluetooth Pairing mode

(1)
•Press to navigate between tracks when Bluetooth
device is connected.
•Press and hold to adjust volume. While in Bluetooth
mode, a beeping sound will alert you when you have
reached maximum volume.
(2) LED Indicator Lights
(3) Play / Pause (in Bluetooth Mode)
•Answer a call – Press once to answer
•Redial a call - Press twice to redial
•Reject a call - press/hold for 3 seconds and release
•Bluetooth pairing - Press and hold to initiate, then
continue to use normally for playing and pausing.
(4) TF card
Support up to 32G memory card
Support MP3/WAV/WMV
(5) Power Button
Switch to turn speaker on / off.
When powering on, you will hear a beep-like sound and
the LED light will turn blue.
(6) Micro USB Charging Port
Use this port to charge your speaker using the provided
USB charging cable.
(7) AUX Input
Use this input to connect your speaker to your media
device via AUX cable.
(8) MIC
For best results, keep within 3 feet of the mic while
speaking.

(1)
•Press to navigate between tracks when Bluetooth
device is connected.
•Press and hold to adjust volume. While in Bluetooth
mode, a beeping sound will alert you when you have
reached maximum volume.
(2) LED Indicator Lights
(3) Play / Pause (in Bluetooth Mode)
•Answer a call – Press once to answer
PAIRING YOUR
BLUETOOTH SPEAKER
In order to use your Jarv X97 Bluetooth Speaker with a
Bluetooth-enabled device, you will first need to pair the two.
1. Place the Bluetooth Speaker and the Bluetooth enabled
device where they are easily viewable and no more than 3ft.
apart.
2. Turn ON your Bluetooth pairing function on your device
3. Turn the Power button which is located on your Jarv X97
speaker to the ON position. A chime will be heard confirming
that the speaker is powered on.
•Redial a call - Press twice to redial
•Reject a call - press/hold for 3 seconds and release
•Bluetooth pairing - Press and hold to initiate, then
continue to use normally for playing and pausing.
(4) TF card
Support up to 32G memory card
Support MP3/WAV/WMV
(5) Power Button
Switch to turn speaker on / off.
When powering on, you will hear a beep-like sound and
the LED light will turn blue.
(6) Micro USB Charging Port
Use this port to charge your speaker using the provided
USB charging cable.
(7) AUX Input
Use this input to connect your speaker to your media
device via AUX cable.
(8) MIC
For best results, keep within 3 feet of the mic while
speaking.
4. The speaker will appear as “Jarv X97” when scanning for
available Bluetooth devices within range.
5. When selecting “Jarv X97” from the list, if prompted for a
Password (sometimes called a “Passkey”, “PIN Number”),
enter “0000”
6. A second chime will be heard once the Bluetooth enabled
device has successfully been paired to the speaker
7. Incoming calls will override music and other media with a
voice alert, press button to answer or press and hold to
reject/ end the call.

In order to use your Jarv X97 Bluetooth Speaker with a
Bluetooth-enabled device, you will first need to pair the two.
1. Place the Bluetooth Speaker and the Bluetooth enabled
device where they are easily viewable and no more than 3ft.
apart.
2. Turn ON your Bluetooth pairing function on your device
3. Turn the Power button which is located on your Jarv X97
speaker to the ON position. A chime will be heard confirming
that the speaker is powered on.
4. The speaker will appear as “Jarv X97” when scanning for
available Bluetooth devices within range.
5. When selecting “Jarv X97” from the list, if prompted for a
Password (sometimes called a “Passkey”, “PIN Number”),
enter “0000”
6. A second chime will be heard once the Bluetooth enabled
device has successfully been paired to the speaker
7. Incoming calls will override music and other media with a
voice alert, press button to answer or press and hold to
reject/ end the call.
Settings
Bluetooth
Bluetooth
JARV
X97
Passcode
0000

RANGE
Be sure to keep the speaker within 30 feet (10 meters)
of the connected media device at all times for optimal
performance.
AUX
Press and hold the button to switch to AUX mode.
While in AUX mode, the Bluetooth connection will be
paused automatically.
BICYCLE MOUNT
Enclosed Bicycle mount installs to your frame or handle
of your bicycle

•Bluetooth 4.1 -Increased Bluetooth transmission
rate and higher audio fidelity with decreased power
consumption.
•Battery status shows on IOS devices.
•Subwoofer + high-performance amplifier combine
for high quality sound.
•Advanced Lithium Battery allows for up to 10 hours
playing time!
•Built-in phone functions allow you to redial and
answer/reject calls from your speaker
•Included Bike Mount to enjoy music on the go!
•Wireless Bluetooth speaker with 33ft. range
•Rugged and dustproof – perfect for camping and
hiking
•Built in Micro SD/TF card slot allows for
independent playback
FEATURES

•Output: 5V 1A
•Power: 3W*2
•Frequency Response: 60Hz ~ 20Khz
•Lithium Battery Capacity: 2200mAh
•THD < 0.5%
•SNR > 85dB
•Dimensions: 4.63X 2.78 X 2.76 inches
SPECIFICATIONS

CARE AND MAINTENANCE
1. Please charge your new speaker for at least four
hours before first use.
2. To prevent damage and risk of electrical shock, do
not expose this device to dust, vibration, rain, water or
liquids of any kind.
3. Do not place device in close proximity to open flames
or extreme heat sources.
Always place your device on level, flat and stable
surfaces.
4. Avoid placing items on top of the speaker.
5. Do not use excessive force when pressing buttons or
handling your speaker.
6. To clean your speaker, use only a dry, soft cloth or
minimally damp cloth without any corrosive solvent or
cleaning agent.

SAFETY
To prevent fires, shock or injury, please do not
disassemble or replace any parts of this device. In the
event that your device may be damaged or in need of
repair, please contact a professional maintenance or
qualified service center for assistance. We are not
responsible for any personal injury or property damage
caused by improper use of this product.
Please do not allow the use of this device by small
children without proper adult supervision.
FCC COMPLIANT
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
This device must accept any interference received,
including interference that may cause undesired
operation.

WARRANTY
At Jarv, we are dedicated to making the best quality
product. To back this up, your Jarv X97 Bluetooth
Speaker is covered by a One (1) Year Limited
Manufacturer’s Warranty.
Details of the warranty are as follows: for a period of
one (1) year from the date of retail purchase, Jarv
warrants that this product is free of any defects in
manufacturing, materials and workmanship. During the
warranty period, we shall, at our sole discretion, repair
or replace any defective parts within a reasonable
period of time and free of charge.
Please visit our website www.jarvmobile.com for
more details
Or Email us at: [e-mail]
for any questions or concerns about your product.
