BlackVue Power Magic Ultra Battery B-130X User manual

ENGLISH / NEDERLANDS /
NORSK / SUOMI / SVENSKA /
 / 
Power Magic Ultra Battery B-130X
User Manual
www.blackvue.com

For the latest version of the manual and customer support go to www.blackvue.com
Voor de nieuwste versie van de handleiding en klantenservice, gaat u naar www.blackvue.com
Du nner den nyeste utgaven av brukermanualen og kundesupport på nettstedet www.blackvue.com
Katso käyttöoppaan uusin versio ja ota yhteyttä asiakaspalveluun siirtymällä osoitteeseen www.blackvue.com
För den senaste versionen av manualen och kundtjänst, gå till www.blackvue.com
 www.blackvue.com
www.blackvue.com 
BLACKVUE
POWER MAGIC ULTRA BATTERY B-130X

Power Magic Ultra Battery B-130X 3
FCC Compliance Information
FCC Part 15.19 Statements
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Part 15.105 Statement (Class B)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Part 15.21 Statement
Any changes or modications not expressly approved by the party responsible for compliance could void the user's authority to
operate this equipment.
MPE
The antenna(s) must be installed such that a minimum separation distance of at least 20 cm is maintained between the radiator
(antenna) and all persons at all times. This device must not be co-located or operating in conjunction with any other antenna
or transmitter.

4BLACKVUE
BlackVue Power Magic Ultra Battery B-130X
The Power Magic Ultra Battery is designed to power your BlackVue dashcam in Parking Mode for extended periods of time
without using your vehicle’s battery.
Hardwiring
power cable
Cigarette lighter plug power cable
Hardwiring power cable
(Output cable for dashcam)
Cigarette lighter socket
(Output cable for dashcam)
or or
Safety instructions
Incorrect use of the Power Magic Ultra Battery can lead to poor performance and may cause overheating, ignition, explosion,
etc. To use the product correctly please observe the following directions:
yFamiliarize yourself with the contents of the user manual before using the product.
yOnly use original BlackVue cables provided by the manufacturer. For replacements contact customer support or your
nearest distributor.
yOnly use the product to power a dashcam.
yDo not expose the product to direct sunlight or heat.
yDo not expose to high temperatures.
yDo not use a cigarette lighter multi-socket splitter (adapter) with the product.
yDo not put the product in a microwave oven or place it in a high-pressure environment.
yDo not repair or modify the product yourself.
yDo not throw the battery or subject it to any physical shock.
yDo not disassemble, compress or puncture the product.
yDo not use the product in an electrostatic environment as it can aect the operation of the battery protection circuitry.

ENGLISH
Power Magic Ultra Battery B-130X 5
yIf the product emits an unusual odor during use, unplug it immediately and contact customer support or your nearest
distributor.
yIf the battery swells up, immediately discontinue using the product. Contact customer support or your nearest distributor.
yKeep the product away from children and pets.
yDo not allow metal objects to contact the terminals of the power and output cables.
yEnsure the battery does not come into contact with water or other liquids.
yPittasoft Co., Ltd. is not liable for damage resulting from disassembling, opening or modifying the product.
Disposal of your battery pack
1. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated
collection facilities appointed by the government or the local authorities. Contact local authorities to learn about disposal
and recycling options available in your area.
2. Do not incinerate or expose to re. Exposure to excess heat may result in re or an explosion.
Components
Check the box for each of the following items before installing the Power Magic Ultra Battery B-130X.
Power Magic Ultra
Battery B-130X User Manual
XT60
Cigarette lighter plug power
cable
Output cable for dashcam
(Cigarette lighter socket)
XT60
Hardwiring power cable Output cable for dashcam
(Hardwiring power cable)
Velcro strips (2 EA) Fuse tap kit (3 types)

6BLACKVUE
At a glance
33.6mm(H)
206.0mm(L)
152.7mm(W)
Dashcam
(Port to output cable
for dashcam)
USB output
DC in (power cable
connection)
LEDs
: Charging battery
: Fully-charged battery
: Bluetooth on
Power switch
yOFF: Turn o the Ultra Battery
yON: Turn on the Ultra Battery

ENGLISH
Power Magic Ultra Battery B-130X 7
LED indicators and beeps
LEDs Sound alert
Powered on All 3 LEDs turn on together and then
turn o one by one.
Welcome chime
Started charging Red LED blinks for 5 seconds Beeps once
Charging Red LED is on
Fully charged Green LED is on
Bluetooth connected Blue LED is on
Low input voltage
warning/High input
voltage warning
Red and Green LED blink together Beeps twice (Repeated)
Overheated warning Red LED and Green LED blink one
after another
Beeps twice (Repeated)
* Beeping can be activated over Bluetooth using the BlackVue app.
* Welcome chime and beeping sound for overheated warning cannot be muted for safety reasons.
Product features
yApproximately 30 hours of power from 50 minutes of charging by hardwired installation / 90 minutes of charging by plug-
in installation (based on a dashcam that uses 3 W).
yCompatible with 2 installation methods:
ū Plug-in installation: Simply plug-in cigarette lighter plug power cable (standard 5A charging); or
ū Hardwired installation: Connect the hardwiring power cable for faster charge (rapid 9 A charging).
yCongure settings via Bluetooth with the BlackVue app.
yCompatible with both car (12 V) and heavy vehicle (24 V) electrical systems.
yBattery protection circuitry for increased safety and extended battery life.
ySimultaneously charge your Ultra Battery and power your dashcam while driving.
yPower output automatically switches to draw power from the Ultra Battery when the engine is o.
yBattery cycle life: Designed to retain more than 80% of its original capacity at 1,500 complete charge/discharge cycles.
yTemperature Cut-o functions:
-High Temperature: Shuts down the battery's charging power if the internal temperature reaches 80°C (176°F) or above.
-Low Temperature: Shuts down the battery's charging power if the internal temperature reaches below 0°C (32°F).
y1 USB port (5 V) allows you to simultaneously charge another device (smartphone, mobile Wi-Fi hotspot, etc.) while
powering the dashcam.

8BLACKVUE
Installation guide
Set the power switch to the OFF position before installation.
Caution
Make sure to use the genuine power cables included in the package. Otherwise, it may result in product failure,
overheating, ignition, etc.
1. For a plug-in installation using a cigarette lighter plug power cable:
a. Plug the cigarette lighter plug power cable into the Ultra Battery’s DC in port. Plug the other end of the power cable
into the vehicle’s cigarette lighter socket.
Cigarette lighter plug power cable
b. Proceed to step 2.
or
1. For a hardwired installation using a hardwiring power cable:
a. Plug the hardwiring power cable into the Ultra Battery’s DC in port.

ENGLISH
Power Magic Ultra Battery B-130X 9
Hardwiring
power cable
b. Referring to your vehicle Owner’s Manual, identify a Switched (accessory power) fuse of 10A or less in your interior
fuse panel. Typical examples are the cigarette lighter and car stereo fuse slots.
Caution
If you connect the Ultra Battery to a Constant Power (BATT) fuse it may result in depletion of your vehicle’s
battery.
c. Remove the identied Switched fuse and match its type with one of the 3 fuse taps.
d. Insert the ACC wire into the connector end of the fuse tap. Use a crimping tool or pliers to crimp the connector onto
the wire.
ACC
Ground wire
(ring)
To Ultra Battery

10 BLACKVUE
e. Insert the fuse you removed from the fuse panel into the slot closest to the blades on the fuse tap.
Note
If the original fuse is a low-prole mini type, use the new 10A mini type fuse instead (included).
f. Insert a new 20A fuse into the slot furthest away from the fuse tap blades.
Input power
e.
f.
Output power
Connector to hardwiring
power cable (ACC)
g. Insert the fuse tap into the empty Switched fuse slot in the fuse panel.
Caution
Refer to the diagram and insert the fuse tap in the correct orientation. In the correct orientation the new fuse (f.) gets
power directly from the fuse slot without putting an additional load on the original fuse (e.). If you insert the fuse tap
in the reversed orientation the additional load on the original fuse may cause it to blow.
h. Connect the ground wire (ring) to a ground point, such as a bolt, that is
directly on a bare metal part of the vehicle's frame. Secure the ground
wire to the bare metal frame (for example by securing it under the bolt).
GND
