QUICK START GUIDE
Model: BWA18SB003
Home Theater System x 1
RC with two
batteries x 1
Audio cable x 1
Center speaker x 1 Front speaker x 2
AM Antenna x 1
Quick Start Guide x 1
FM Antenna x 1
Subwoofer
Rear speaker x 2
QUICK START GUIDE
What's included
Connecting the Speakers
Center
speaker
Front Left
speaker
Front Right
speaker
Rear Left
speaker
* For optimal wireless reception, the Wireless Subwoofer should be placed
within 20 feet from the AV Receiver.
* During use, press HDMI button repeatedly on the remote control to select
desired HDMI input.
Rear Right
speaker
Wireless
Subwoofer
2Positioning 3 4 Connecting to HDMI Components
Blu-ray DiscTM Player,
DVD Player, Satellite
Receiver or Cable Box
Operating
Instructions x 1
Operating instructions
1Identication of all buttons and jacks
ON/STANDBY
/
(SURROUND buttons)
/
(TUNING buttons)
AUX 2 jacks LINE-IN jack PHONES jack
WIRELESS LINK
PAIRING indicator
WIRELESS LINK button
Rear speaker terminals
Power switch
/
(PRESET buttons)
MASTER
VOLUME -/+
SOURCE
button
AM/FM terminals HDMI IN
jacks
COAXIAL DIGITAL
AUDIO IN jack
OPTICAL DIGITAL
AUDIO IN jacks
ANALOG AUDIO IN (AUX 1) jacks Speaker terminalsHDMI OUT jack
Back of Home Theater System
Front of Home Theater System Back of Subwoofer
Speakers on the System Speakers on the Subwoofer
Front
Right Speaker
Red
and
Black
White
and
Black
Front
Left Speaker
Green
and
Black
Center Speaker
Rear
Right Speaker
Grey
and
Black
Rear
Left Speaker
Blue
and
Black
Insert
Press Release
ON
OFF
AV Receiver
Less than
20 feet

6Pairing the Subwoofer with System
1) Press and hold the WIRELESS LINK button on the back of
Subwoofer and the OK button on the Remote Control at
the same time until the“WIRELESS“ indicator blinks on the
System display.
The Home Theater System and Subwoofer will pair up
automatically after power on.
If the pairing fails accidentally, please follow below steps to
reconnect:
2) The “WIRELESS CONNECTED” indicator appears on Home
Theater System display, the pairing between Home Theater
System and Subwoofer is complete and successful.
7Bluetooth pairing
1) Press button on remote control to select the BT
(Bluetooth) mode.
2) On your device (smart phone, etc.), select BW HTiB from
the list of available Bluetooth connections.
It will show “CONNECTED” on the Home Theater System
display.
5Connecting to Audio Components
TV, GAME, Blu-ray DiscTM Player,
DVD Player, Satellite Receiver or Cable Box
AM / FM Operation
ST indicator is o.
• Adjust the antenna.
• Press MONO / ST button to insure you are not outputting in mono.
The signal is Mono. Severe hum or noise.
• The signal is too weak.Connect an external antenna.
• Adjustantenna.
• Repositionantennaawayfromanyelectronics.
There is interference to FM reception.
• Turn off other electrical devices (e.g. DVD, CD player) near the unit.
General
No audio.
• Make sure the speakers are connected.
• Check the input connections.
• Check the power cord connections.
• Make sure MUTE is off.
• Make sure the digital setting (optical, coaxial or analog) is correct.
• Check that the headphone is not inserted.
No audio from one channel.
• Check the speaker level setting.
• Check the speaker wire or external source cable connections.
Noise occurs when the TV is turned on.
• The TV is too close to the audio system.
No sound from the wireless subwoofer
• Turn off and turn on the Home Theater System and Subwoofer again.
• Set up the wireless subwoofer connection manually (Refer to the Pairing the Subwoofer
with System).
Troubleshooting
Printed in China
811-298191W020
Connect the AM and FM antennas to the AM and FM terminals on the
system’s back panel.
Connecting the Antennas
Option 1 - Best
TV, GAME, Blu-ray DiscTM Player,
DVD Player, Satellite Receiver or Cable Box
Option 2 - Better
VCR or TV
Option 3 - good
