Blade CG02+ 3-Axis User manual

®CG02+ 3-Axis
Brushless Camera/Gimbal
Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni

2
EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product
before operating. Failure to operate the product correctly can result in damage to the product, personal
property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some
basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury
or damage to the product or other property. This product is not intended for use by children without direct adult
supervision. Do not use with incompatible components or alter this product in any way outside of the instruc-
tions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance.
It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or
use, in order to operate correctly and avoid damage or serious injury.
The following terms are used throughout the product literature to indicate various levels of potential harm
when operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a
little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND
a possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral
damage, and serious injury OR create a high probability of superficial injury.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of
Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for
this product.
Meaning of Special Language
Age Recommendation: Not for children under 14 years. This is not a toy.

3EN
• Always keep a safe distance in all directions
around your model to avoid collisions or injury. This
model is controlled by a radio signal subject to in-
terference from many sources outside your control.
Interference can cause momentary loss of control.
• Always operate your model in open spaces away
from full-size vehicles, traffic and people.
• Always carefully follow the directions and warnings
for this and any optional support equipment
(chargers, rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and any-
thing electrical out of the reach of children.
• Always avoid water exposure to all equipment
not specifically designed and protected for this
purpose. Moisture causes damage to electronics.
• Never place any portion of the model in your mouth
as it could cause serious injury or even death.
• Never operate your model with low transmitter
batteries.
• Always keep the aircraft in sight and under control.
• Always move the throttle fully down at rotor strike.
• Always use fully charged batteries.
• Always keep the transmitter powered on while the
aircraft is powered.
• Always remove batteries before disassembly.
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Never operate an aircraft with damaged wiring.
• Never touch moving parts.
Safety Precautions and Warnings

4
EN
Table of Contents
Box Contents
Box Contents ........................................................... 4
Technical Specifications........................................... 5
Loading the CGO2 App to Your WiFi Smart Device..... 5
Gimbal Components................................................. 6
Installing the Mounting Plate.................................... 7
Installing the Gimbal ................................................ 7
Routing the Wiring ................................................... 8
Connecting the Gimbal............................................. 9
Transmitter Programming ...................................... 10
Using the Gimbal ................................................... 10
Using the CGO2 App............................................... 11
LED Codes ............................................................ 11
Troubleshooting ..................................................... 12
Optional Parts........................................................ 12
Limited Warranty ................................................... 14
Service Contact Information................................... 16
FCC Information..................................................... 16
IC Information........................................................ 17
Compliance Information for the European Union..... 17
A
D
CB
F
G
E
H
A.CG02+ 3-axis camera/gimbal
B.Chroma™mounting plate
C.350 QX3 mounting plate
D.(3) M2.5 x 10 mounting screws
E. 4 pin Y-harness
F. 3-wire signal lead (not used)
G.2-wire power lead (not used)
H.4-pin to servo harness (not used)

5EN
Technical Specifications
Loading the CGO2 App to Your WiFi Smart Device
Dimensions LxWxH (with lens): 3.00 x 101.62 x 129.12mm
Weight: 163 g
Working Voltage: 12V
Wireless Frequency Range:
North America: 5745MHz–5825MHz**
Europe: 5180MHz–5240MHz**
Lens Sensor: 16M
Angle of view: 155°
Controlled Rotation Range: Pitch Axis Control: –90°–0°
Effective Pixels: 16 million
White Balance: Automatic
Focusing System: Fixed
Microphone Onboard
Storage Temperature: –20°–60°C
Working Temperature: 0°–50°C
• Download the free CGO2+ App to your smartphone or
tablet at the iTunes App Store or Google Play Store.
• Install the app to your WiFi capable device.
**IMPORTANT: Your WiFi capable device must operate in the same wireless frequency range as broadcast by the
product purchased in your region.

6
EN
Gimbal Components
Left side Right side
Front
LEDMicrophone
Bottom
Camera lense
Mounting rails
WiFi antenna
Micro SD
card slot
12V gimbal
power port
PWM ports

7EN
Installing the Mounting Plate
Installing the Gimbal
The CGO2+ camera gimbal is compatible with
350 QX3 and Chroma™quadcopters. Install the
appropriate mounting plate using the 3 included
M2.5 x 10 screws. Do not overtighten.
IMPORTANT: If you are mounting the CGO2+ to the
350 QX3, you must first install the 350 QX3 tall
landing gear (BLH8105).
Install the gimbal by lining up the mounting rails of the
gimbal and the mounting plate and pushing towards
the rear of the plate as shown at left until it locks into
place.
To remove the gimbal, push in the retaining clip at
the front of the mounting plate and pull the gimbal
forward.
Connect the harness from the gimbal to either
the exposed wire harness from the 350 QX3 or
to the recessed plug in the bottom of the Chroma
quadcopter.

8
EN
Transmitter Programming
Transmitter control of the pitch angle of the CG02+ is
possible with most 6-channel and above Spektrum™
transmitters. Control of the pitch angle in flight is
achieved on the DX6i and DX6 by temporarily using
the throttle control stick to adjust pitch. If you are
using the DX7s, DX8, DX7, DX9 or DX18, pitch control
is achieved via the rotary knob on your transmitter.
To program your transmitter:
DX6i
• Set the Channel 6 (FLAP) Travel Adj. to
120 up and 100 down.
• Set the values in the FLAP menu to
100 up and 100 down.
To change gimbal angle BEFORE starting the motors
for flight, set the flap switch to position 1. The throttle
stick will now control the angle of the gimbal. Set the
flap switch to position 0 before flight.
To change the gimbal angle IN FLIGHT, cycle the flap
switch to position 1. The throttle stick will now control
the gimbal angle for approximately 5 seconds before
returning to throttle control. Return the flap switch to
position 0.
DX6
In Channel Input Configuration:
• Assign channel 6 (AUX1) to switch A.
• Assign Gear to switch B.
In Servo Setup:
• Reverse AUX1.
• Set the travel values for AUX1 to:
120%
140%
To change the gimbal angle BEFORE starting the
motors for flight, set switch A to position 1. The
throttle stick will now control the angle of the gimbal.
Set switch A to position 0 before flight.
To change the gimbal angle IN FLIGHT, cycle switch
A to position 1. The throttle stick will now control
the gimbal angle for approximately 5 seconds
before returning to throttle control. Return switch A to
position 0.
DX7s
In Channel Input Configuration:
• Assign Channel 7 Input (AUX2) to the rotary knob.
• Assign AUX1 to the Gear switch.
In Servo Setup:
• Set the Channel 6 (AUX1) travel to the values below:
120%
140%
To change the gimbal angle, set the gear switch
to position 0 and adjust the angle of the gimbal by
rotating the knob on your transmitter at any time.
DX8
In Channel Input Configuration:
• Assign Channel 7 Input (AUX2) to the rotary knob.
• Assign AUX1 to the Gear switch.
In Servo Setup:
• Set the Channel 6 (AUX1) travel to the values below:
120
140
To change the gimbal angle, set the gear switch
to position 0 and adjust the angle of the gimbal by
rotating the knob on your transmitter at any time.

9EN
DX7, DX9, DX18
In Channel Input Configuration:
• Assign Channel 7 Input (AUX2) to R Knob.
• Assign AUX1 to A.
In Servo Setup:
• Set the AUX1 travel to the values below:
140
120
To change the gimbal angle, set switch A to position 0
and adjust the angle of the gimbal by rotating the
R Knob at any time.
ST10+ Personal Ground Station
The ST10+ requires no additional programming to use
the CGO2+. Proceed to “Using the CGO2+ With Your
ST10+ Personal Ground Station.”
Using the Gimbal
1. Insert the micro SD card into the slot on the bottom
of the camera.
2. Place the quadcopter on a flat and stable surface.
Ensure there are no obstructions in the path of the
CG02 GB.
3. Switch on your transmitter.
4. Switch on your quadcopter.
After the CGO2+ powers on, the LED will glow red for
approximately 40 seconds while the gimbal initializes.
When the LED changes to green the CGO2 is ready to
connect via WiFi.
See the “Using the CGO2 App” section for instructions
on how to connect your gimbal to your smart device
and for a description of the camera controls available.
The gimbal will now compensate for any roll, pitch
and yaw movements encountered by your quadcopter
in flight.
If desired, you may change the pitch angle of
the gimbal at any time using your programmed
transmitter controls.

10
EN
Using the CGO2 App
• With the CGO2+ powered on, open the WiFi
settings on your smartphone or tablet and
connect to the CGO2 GB network
(CGO2 GB_******) using the password
“1234567890”.
• Open the CGO2 GB App on your device.
You can now take still photos or start/stop recording
video by using the on-screen controls on your
device.
It is possible to take still photos at any time, even
while you are recording live video.
Be sure to check for updates to the CGO2 App in the
iTunes App Store, or Google Play Store.
Using the CGO2+ With Your ST-10+ Personal Ground Station
NOTICE: The ST-10+ transmitter is not compatible
with any receiver equipped with Spektrum™DSM®,
DSM2®or DSMX®technology.
1. Insert the micro SD card into the slot on the bottom
of the camera.
2. Place the quadcopter on a flat and stable surface.
Ensure there are no obstructions in the path of the
CG03.
3. Switch on your transmitter.
4. Switch on your quadcopter.
After the CGO2+ camera powers on, the LED on the
gimbal will glow red for approximately 40 seconds.
When the LED changes to yellow, complete the
following steps to bind the CGO2+ to the ST-10+:
5. Select Flight Settings from the main menu on the
ST-10+.
6. Select the Bind option.
7. Under Camera, select the CGO2 network
(CGO2_******).
8. Touch the Password line on the screen and enter
the password “1234567890” on the touchscreen.
9. Select OK.
10. The ST-10+ will indicate a successful connection.
Select OK.
11. Return to the Main Menu.
The live video feed is now visible on the ST-10+
display.
Double tap on the image to expand the video to fill the
display. Double tap again to return to the main menu
with live video.

11 EN
LED Codes
Green Blue YellowRed
Initializing..................................................................
Ready to connect to WiFi...........................................
Video recording.........................................................
SD card error ............................................................
WiFi error..................................................................
Use the buttons on the top of the ST-10+ to control the camera functions and the left slider to control
the vertical angle of the camera gimbal.
Video Start/
Stop Button
Button
Camera Tilt Slider

12
EN
Troubleshooting
Problem Possible Cause Solution
The gimbal vibrates after
switching ON
Gimbal did not initialize correctly
or was obstructed
Re-initialize with the gimbal clear of
obstructions
Gimbal does not respond to
control input Gimbal did not initialize
Keep the quadcopter and gimbal level
and immobile for 5 seconds after
switching ON
Gimbal is not ON Incorrect gimbal connections Correctly connect gimbal
Gimbal does not respond to
transmitter Incorrect transmitter set up
Review transmitter programming
section and make corrections to
transmitter set up
Gimbal does not respond
to control inputs. RED and
BLUE LEDs are solid
Incorrect gimbal connections Correctly connect gimbal
Gimbal is not ON and RED
LED flashes slowly Gimbal gyro board damage Contact Horizon Product Support
Gimbal LED Flashing RED in
Angle or Velocity Mode Sensor Error Check for correct gimbal connection or contact Horizon Product Support
Optional Parts
Part # Description
BLH8105 Tall Landing Gear Set: 350 QX3

13 EN
Limited Warranty
What this Warranty Covers
Horizon Hobby, LLC, (Horizon) warrants to the original
purchaser that the product purchased (the “Product”) will
be free from defects in materials and workmanship at the
date of purchase.
What is Not Covered
This warranty is not transferable and does not cover
(i) cosmetic damage, (ii) damage due to acts of God,
accident, misuse, abuse, negligence, commercial
use, or due to improper use, installation, operation or
maintenance, (iii) modication of or to any part of the
Product, (iv) attempted service by anyone other than a
Horizon Hobby authorized service center, (v) Product not
purchased from an authorized Horizon dealer, (vi) Product
not compliant with applicable technical regulations, or (vii)
use that violates any applicable laws, rules, or regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON
MAKES NO OTHER WARRANTY OR REPRESENTATION,
AND HEREBY DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES, INCLUDING, WITHOUT LIMITATION,
THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. THE PURCHASER ACKNOWLEDGES THAT
THEY ALONE HAVE DETERMINED THAT THE PRODUCT
WILL SUITABLY MEET THE REQUIREMENTS OF THE
PURCHASER’S INTENDED USE.
Purchaser’s Remedy
Horizon’s sole obligation and purchaser’s sole and
exclusive remedy shall be that Horizon will, at its option,
either (i) service, or (ii) replace, any Product determined
by Horizon to be defective. Horizon reserves the right to
inspect any and all Product(s) involved in a warranty claim.
Service or replacement decisions are at the sole discretion
of Horizon. Proof of purchase is required for all warranty
claims. SERVICE OR REPLACEMENT AS PROVIDED
UNDER THIS WARRANTY IS THE PURCHASER’S SOLE AND
EXCLUSIVE REMEDY.
Limitation of Liability
HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT,
INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF
PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN
ANY WAY, REGARDLESS OF WHETHER SUCH CLAIM IS
BASED IN CONTRACT, WARRANTY, TORT, NEGLIGENCE,
STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY,
EVEN IF HORIZON HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. Further, in no event
shall the liability of Horizon exceed the individual price of
the Product on which liability is asserted. As Horizon has
no control over use, setup, nal assembly, modication
or misuse, no liability shall be assumed nor accepted for
any resulting damage or injury. By the act of use, setup
or assembly, the user accepts all resulting liability. If you
as the purchaser or user are not prepared to accept the
liability associated with the use of the Product, purchaser
is advised to return the Product immediately in new and
unused condition to the place of purchase.
Law
These terms are governed by Illinois law (without regard to
conict of law principals). This warranty gives you specic
legal rights, and you may also have other rights which vary
from state to state. Horizon reserves the right to change or
modify this warranty at any time without notice.
WARRANTY SERVICES
Questions, Assistance, and Services
Your local hobby store and/or place of purchase cannot
provide warranty support or service. Once assembly, setup
or use of the Product has been started, you must contact
your local distributor or Horizon directly. This will enable
Horizon to better answer your questions and service
you in the event that you may need any assistance. For
questions or assistance, please visit our website at www.
horizonhobby.com, submit a Product Support Inquiry,
or call the toll free telephone number referenced in the
Warranty and Service Contact Information section to speak
with a Product Support representative.

14
EN
Inspection or Services
If this Product needs to be inspected or serviced and is
compliant in the country you live and use the Product in,
please use the Horizon Online Service Request submission
process found on our website or call Horizon to obtain a
Return Merchandise Authorization (RMA) number. Pack
the Product securely using a shipping carton. Please note
that original boxes may be included, but are not designed
to withstand the rigors of shipping without additional
protection. Ship via a carrier that provides tracking and
insurance for lost or damaged parcels, as Horizon is not
responsible for merchandise until it arrives and is accepted
at our facility. An Online Service Request is available
at http://www.horizonhobby.com/content/_service-
center_render-service-center. If you do not have internet
access, please contact Horizon Product Support to obtain
a RMA number along with instructions for submitting
your product for service. When calling Horizon, you will
be asked to provide your complete name, street address,
email address and phone number where you can be
reached during business hours. When sending product
into Horizon, please include your RMA number, a list of
the included items, and a brief summary of the problem.
A copy of your original sales receipt must be included
for warranty consideration. Be sure your name, address,
and RMA number are clearly written on the outside of the
shipping carton.
NOTICE: Do not ship Li-Po batteries to Horizon. If you
have any issue with a Li-Po battery, please contact the
appropriate Horizon Product Support ofce.
Warranty Requirements
For Warranty consideration, you must include
your original sales receipt verifying the proof-of-
purchase date. Provided warranty conditions have been
met, your Product will be serviced or replaced free of
charge. Service or replacement decisions are at the sole
discretion of Horizon.
Non-Warranty Service
Should your service not be covered by warranty,
service will be completed and payment will be
required without notification or estimate of the
expense unless the expense exceeds 50% of the
retail purchase cost. By submitting the item for service
you are agreeing to payment of the service without
notication. Service estimates are available upon request.
You must include this request with your item submitted
for service. Non-warranty service estimates will be billed
a minimum of ½ hour of labor. In addition you will be
billed for return freight. Horizon accepts money orders
and cashier’s checks, as well as Visa, MasterCard,
American Express, and Discover cards. By submitting any
item to Horizon for service, you are agreeing to Horizon’s
Terms and Conditions found on our website http://www.
horizonhobby.com/content/_service-center_render-
service-center.
ATTENTION: Horizon service is limited to Product
compliant in the country of use and ownership.
If received, a non-compliant Product will not be
serviced. Further, the sender will be responsible
for arranging return shipment of the un-serviced
Product, through a carrier of the sender’s choice
and at the sender’s expense. Horizon will hold
non-compliant Product for a period of 60 days from
notification, after which it will be discarded.

15 EN
Service Contact Information
Country of
Purchase Horizon Hobby Contact Information Address
United States
of America
Horizon Service Center
(Repairs and Repair Requests) servicecenter.horizonhobby.com/ RequestForm/
4105 Fieldstone Rd
Champaign, Illinois, 61822 USA
Horizon Product Support
(Product Technical Assistance)
www.quickbase.com/db/
bghj7ey8c?a=GenNewRecord
888-959-2304
Sales [e-mail]
888-959-2304
United
Kingdom Service/Parts/Sales: Horizon Hobby Limited
[e-mail] Units 1–4 , Ployters Rd, Staple Tye
Harlow, Essex, CM18 7NS,
United Kingdom
[phone]
Germany Horizon Technischer Service [e-mail] Christian-Junge-Straße 1
25337 Elmshorn, Germany
Sales: Horizon Hobby GmbH [phone]
France Service/Parts/Sales:
Horizon Hobby SAS
[e-mail] 11 Rue Georges Charpak
77127 Lieusaint, France
[phone]
China Service/Parts/Sales:
Horizon Hobby – China
[e-mail] Room 506, No. 97 Changshou Rd.
Shanghai, China 200060
[phone]
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
CAUTION: Changes or modifications not
expressly approved by the party responsible
for compliance could void the user’s authority to
operate the equipment.
Antenna Separation Distance
When operating your CGO2+ camera gimbal, please
be sure to maintain a separation distance of at least
20 cm between your body (excluding fingers, hands,
wrists, ankles and feet) and the antenna to meet RF
exposure safety requirements as determined by FCC
regulations.
FCC Information

16
EN
Compliance Information for the European Union
Instructions for disposal of WEEE by users in the European Union
This product must not be disposed
of with other waste. Instead, it is the
user’s responsibility to dispose of their
waste equipment by handing it over
to a designated collections point for
the recycling of waste electrical and
electronic equipment. The separate
collection and recycling of your
waste equipment at the time of disposal will help
to conserve natural resources and ensure that it is
recycled in a manner that protects human health and
the environment. For more information about where
you can drop off your waste equipment for recycling,
please contact your local city office, your household
waste disposal service or where you purchased the
product.
EU Compliance Statement:
Horizon Hobby, LLC hereby declares that
this product is in compliance with the
essential requirements and other relevant provisions
of the R&TTE.
A copy of the EU Declaration of Conformity is available
online at: http://www.horizonhobby.com/content/
support-render-compliance.
IC Information
This device complies with Industry Canada license-
exempt RSS standard(s). Operation is subject to the
following two conditions:
(1) this device may not cause interference,
and (2) this device must accept any interference,
including interference that may cause undesired
operation of the device.

©2015 Horizon Hobby, LLC.
Blade, Chroma, DSM, DSM2 and DSMX are trademarks or registered trademarks of Horizon Hobby, LLC.
iTunes is a trademark of Apple, Inc. Registered in the U.S. and other countries. Google is a registered trademark of Google, Inc.
All other trademarks, service marks or logos are property of their respective owners.
Created 05/15 49846 BLH8621
